Yanmar engines LV series (L48V, L70V, L100V). Manual - part 6

SAFETY

LV Operation Manual

9

CAUTION

If any problem is noted during the visual
check, the necessary corrective action
should be taken before you operate the
engine.

0000021en

CAUTION

NEVER hold the key in the START
position for longer than 15 seconds or
the starter motor will overheat.

0000007en

CAUTION

The illustrations and descriptions of
optional equipment in this manual, such
as the operator’s console, are for a
typical engine installation. Refer to the
documentation supplied by the optional
equipment manufacturer for specific
operation and maintenance instructions.

0000018en

CAUTION

If any indicator illuminates during
engine operation stop the engine
immediately. Determine the cause and
repair the problem before you continue
to operate the engine.

0000029en

CAUTION

Observe the following environmental
operating conditions to maintain engine
performance and avoid premature
engine wear:

• Avoid operating in extremely dusty

conditions.

• Avoid operating in the presence of

chemical gases or fumes.

• Avoid operating in a corrosive

atmosphere such as salt water spray.

• NEVER install the engine in a

floodplain unless proper precautions
are taken to avoid being subject to a
flood.

• NEVER expose the engine to the rain.

0000003en

CAUTION

NEVER allow the recoil handle to snap
back against the engine. Return the
handle to the starting position gently to
prevent damage to the starter.

0000066en

SAFETY

10

LV Operation Manual

CAUTION

Observe the following environmental
operating conditions to maintain engine
performance and avoid premature
engine wear:

• NEVER run the engine if the ambient

temperature is above +104°F (+40°C)
or below +14°F (-10°C)

◆

If the ambient temperature exceeds
+104°F (+40°C) the engine may
overheat and cause the engine oil to
break down.

◆

If the ambient temperature falls
below +14°F (-10°C) rubber
components such as gaskets and
seals will harden causing premature
engine wear and damage.

◆

Contact your authorized Yanmar
industrial engine dealer or
distributor if the engine will be
operated in either temperature
extreme.

• Contact your authorized Yanmar

industrial engine dealer or distributor
if you need to operate the engine at
high altitudes. At high altitudes the
engine will lose power, run rough, and
produce exhaust gases that exceed
the design specifications.

0000065enLV

CAUTION

• Only use the engine oil specified.

Other engine oils may affect warranty
coverage, cause internal engine
components to seize, or shorten
engine life.

• Prevent dirt and debris from

contaminating the engine oil. Carefully
clean the oil cap / dipstick and the
surrounding area before you remove
the cap.

• NEVER mix different types of engine

oil. This may adversely affect the
lubricating properties of the engine oil.

• NEVER overfill. Overfilling may result

in white exhaust smoke, engine
overspeed or internal damage.

0000005en

CAUTION

• NEVER overfill the engine with engine

oil.

• ALWAYS keep the oil level between the

upper and lower lines on the oil
cap / dipstick.

0000015en

CAUTION

For maximum engine life, Yanmar



recommends that when shutting the
engine down, you allow the engine to
idle, without load, for 5 minutes. This
will allow the engine components that
operate at high temperatures, such as
the turbocharger (if equipped) and
exhaust system, to cool slightly before
the engine itself is shut down.

0000008en

CAUTION

NEVER use an engine starting aid such
as ether. Engine damage will result.

0000009en

SAFETY

LV Operation Manual

11

CAUTION

Make sure the engine is installed on a
level surface. If a continuously running
engine is installed at an angle greater
than 20° (in any direction) or if an engine
runs for short periods of time (less than
3 minutes) at an angle greater than 25°
in any direction, engine oil may enter the
combustion chamber causing exessive
engine speed and generate white
smoke. This may cause serious engine
damage.

0000010enTNE

CAUTION

New Engine Break In:

• On the initial engine start-up, allow the

engine to idle for approximately 15
minutes while you check for proper
engine oil pressure, diesel fuel leaks,
engine oil leaks, coolant leaks, and for
proper operation of the indicators
and / or gauges.

• During the first hour of operation, vary

the engine speed and the load on the
engine. Short periods of maximum
engine speed and load are desirable.
Avoid prolonged operation at
minimum or maximum engine speeds
and loads for the next 4 to 5 hours.

• During the break-in period, carefully

observe the engine oil pressure and
engine temperature.

• During the break-in period, check the

engine oil and coolant levels
frequently.

0000011en

CAUTION

NEVER engage the starter motor while
the engine is running. This may damage
the starter motor pinion and / or ring
gear.

0000012en

CAUTION

• NEVER attempt to modify the engine’s

design or safety features such as
defeating the engine speed limit
control or the fuel injection quantity
control.

• Failure to comply may impair the

engine’s safety and performance
characteristics and shorten the
engine’s life. Any alterations to this
engine may affect the warranty
coverage of your engine. See Yanmar
Limited Warranty on page vii.

0000044enLVOM

CAUTION

Be environmentally responsible. Follow
these procedures for hazardous waste
disposal. Failure to follow these
procedures may seriously harm the
environment.

• Follow the guidelines of the EPA or

other governmental agency for the
proper disposal of hazardous
materials such as engine oil, diesel
fuel and engine coolant. Consult the
local authorities or reclamation facility.

• NEVER dispose of hazardous

materials irresponsibly by dumping
them into a sewer, on the ground or
into ground water or waterways.

0000013en

CAUTION

Protect the air cleaner, turbocharger (if
equipped) and electric components
from damage when you use steam or
use high-pressure water to clean the
engine.

0000014en

SAFETY

12

LV Operation Manual

CAUTION

The tightening torque in the Standard
Torque Chart (page 64) should be
carefully observed.

• Apply 60% torque to bolts that are not

listed.

• Apply 80% torque when tightened to

aluminum alloy.

0000023enLVOM

CAUTION

Establish a periodic maintenance plan
according to the engine application and
make sure you perform the required
periodic maintenance at intervals
indicated. Failure to follow these
guidelines will impair the engine’s safety
and performance characteristics,
shorten the engine’s life and may affect
the warranty coverage on your engine.
See Yanmar Limited Warranty on
page vii.

Consult your authorized Yanmar
industrial engine dealer or distributor for
assistance when checking items marked
with a  .

0000024enLVOM

CAUTION

It is important to perform daily checks.
See Daily Checks on page 34.

Periodic maintenance prevents
unexpected downtime, reduces the
number of accidents due to poor
machine performance and helps extend
the life of the engine.

0000060enLVOM

CAUTION

• When the engine is operated in dusty

conditions, clean the air cleaner
element more frequently.

• NEVER operate the engine with the air

cleaner or element(s) removed.  This
may cause foreign material to enter the
engine and damage it.

0000026en

CAUTION

The maximum air intake restriction shall
be:

• L48V: 0.10 psi (0.69 kPa; 70 mm Aq) or

less

• L70V: 0.20 psi (1.37 kPa; 140 mm Aq)

or less

• L100V: 0.21 psi (1.47 kPa; 150 mm Aq)

or less.

Clean or replace the air cleaner element
if the air intake restriction exceeds the
above mentioned value.

0000046enLV

CAUTION

Tips while starting engine with recoil
starter (See Start The Engine on
page 46.):

• Pulling out the recoil starter handle

too hard or fast will damage the
equipment.

• ALWAYS pull recoil starter handle all

the way out or the engine will not start.

• NEVER allow the recoil starter handle

to snap back against the engine.
Return the handle to the starting
position gently to prevent damage to
the recoil starter.

0000068enLVOM
