BBM OUTLAW XP MODELS ZERO-TURN MOWER. Manual - part 4
PAGE
13
SECTION 6:
TROUBLESHOOTING
6.1
Q: How do I prevent an uneven cutting pattern and increase the quality of cut?
6.1
A: Check tire pressure, check blade sharpness (replace blades or sharpen at least once
per year or when needed), make sure blades are tightened properly, check spring and belt
tension, check the underside of the deck to ensure the mower deck is free of grass build-up
and debris, make sure your machine is at full throttle, and vary your mowing pattern each
time you cut your grass.
6.2
Q: What should I do if my mower won’t start?
6.2
A: Check battery charge and connection (grounds), check your fuel (make sure fuel is less
than 30 days old and contains no water), make sure your spark plug is in good condition
and spark plug wire is attached, and make sure air filter is clean (a dirty filter makes it more
difficult for the engine to draw air). Check the integrity of the 25 amp main fuse; also check
for any bare wires and/or bad connections.
6.3
Q: What should I do if the blades won’t engage?
6.3
A: Make sure the safety switch is plugged in on the bottom of seat. Check the underside of
the PTO engager to ensure the plug is secure at switch.
6.4
Q: What type of fuel is recommended for my mower?
6.4
A: We recommend that you use a name brand fuel to ensure quality. Use fuel with an octane
rating near 87. Higher octane fuels offer no benefit. By law, E-15 fuel is not permitted. Usage
of E-15 will result in premature engine failure.
6.5
Q: Do you offer touch-up paint for your mowers?
6.5
A: Touch-up paint is available. Contact your local dealer for more information.
6.6
Q: How durable is the electric deck lift?
6.6
A: The actuator which controls the deck height is designed for moving loads of up to 1000
pounds and has a static holding capability which exceeds 3,000 pounds. Our ¼˝ deck weighs
approximately 250 pounds which is only 25% of working capability.
6.7 Q:
How do I clean my mower?
6.7 A: It is recommended that you use an air hose or blower to remove dust and debris from the
mower, to ensure there is not a build up of grass on the mower deck and engine
compartment, which could become a fire hazard. If you must wash the mower,
ensure you run the engine to operating temp to dry water and engage the blades to
spin off any standing water on the pulleys. Avoid spraying water onto electrical
components and bearings, to prevent premature failure of these parts.
