BBM DIESEL 1500cc MODEL ZERO-TURN MOWER. Manual - part 3

PAGE



 10

Every 50

First

Every 100

Every

Every

Daily

hours or

75

hours or

250

500

Section

Maintenance

annually*

hours

annually*

hours

hours

Check and add engine oil

●

Section 3

Section2

●

(Pump) 6

(Deck)

Check condition of blades

●

Section 6

Check for fuel and oil leakage

●

Section 3

Check cooling system coolant

●

Section 3

Engine air cleaner inspection

●

Section 3

●

Section 3

Tighten nuts and screws

●

Section 5

Grease mower

●

Section 5

Engine oil sample**

Dealer

●

Change hydraulic oil and filter

●

Section 1

Engine oil and filter change

●

Section 3

Replace fuel filter ◊

●

Section 3

●

Radiator  - clean

●

Section 3

Interval

Check all belts for proper

alignment
Check tire pressure and wheel

lug nut

Check battery terminal

connections

●

●

Section 5

Section 4

Initial change of hydraulic oil

and filter

●

Section 1

Replace air element and pre-

cleaner ◊

Fuel system primary filter/water

sepatator inspection
Fuel tank water and sediment

drain

●

◊ Check air and fuel filter more often in dusty conditions

Dealer

Get maintenance performed at a registered dealership

Section 3

Cooling system coolant sample

Dealer

●

*Maintenance by hour or annually, whichever comes first

**Maintenance by hour or every six months, whichever comes first

Cooling system supplemental

coolant additive - test/add

Dealer

●

SECTION 4:

MOWER MAINTENANCE



PAGE 11

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Performed:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

MAINTENANCE LOG

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

Date:

Hours:

PAGE



 12

SECTION 5:

 MOWER STORAGE & TRANSPORTATION

5.1   Keep machine from collecting debris by storing in a covered area while not in use.
5.2   Fuel can harm your machine if left for more than 30 days without changing.
5.3   Disconnect the negative battery cable when machine will be stored for more than 30 days.
5.4   Always secure machine properly when transporting machine.
5.5  Do not load machine on trailer with blades engaged.
5.6   Do not use ramps to load the machine.
5.7  Make sure Parking Brake is in “up” position.
5.8   In wet conditions tires may spin while loading / unloading. If necessary, wait for dry

conditions before loading / unloading.

5.9   Make sure mode of transportation is suitable to bear the weight of mower.
5.10   Deck height should be set at maximum before attempting to load.
5.11   Secure mower with at least two straps capable of securing weight of mower.

PAGE



13

SECTION 6:

 TROUBLESHOOTING

6.1

Q: How do I prevent an uneven cutting pattern and increase the quality of cut?

6.1

A: Check tire pressure, check blade sharpness (replace blades or sharpen at least once
per year or when needed), make sure blades are tightened properly, check spring and belt
tension, check the underside of the deck to ensure the mower deck is free of grass build-up
and debris, make sure your machine is at full throttle, and vary your mowing pattern each
time you cut your grass.

6.2

Q: What should I do if my mower won’t start?

6.2

A: Check battery charge and connection (grounds), check your fuel (make sure fuel is less
than 30 days old and contains no water), and make sure air filter is clean (a dirty filter makes
it more difficult for the engine to draw air). Check the integrity of the 25 amp main fuse; also
check for any bare wires and/or bad connections.

6.3

Q: What should I do if the blades won’t engage?

6.3

A: Make sure the safety switch is plugged in on the bottom of seat. Check the underside of
the PTO engager to ensure the plug is secure at switch.

6.4

Q: What type of fuel is recommended for my mower?

6.4

A: We recommend that you use a name brand fuel to ensure quality. Use only Ultra Low
Sulfur Diesel Fuel.

6.5

Q: Do you offer touch-up paint for your mowers?

6.5

A: Touch-up paint is available. Contact your local dealer for more information.

6.6

Q: How durable is the electric deck lift?

6.6

A: The actuator

, which controls the deck height, is designed for moving loads of up to 1000

pounds and has a static holding capability which exceeds 3,000 pounds. Our ¼˝ deck weighs
approximately 250 pounds which is only 25% of working capability. If deck lift will not
operate, check fuse located underneath operator console (15amp).

6.7 Q:

How do i clean my mower?

6.7 A: It is recommended that you use an air hose or blower to remove dust and debris from the

mower, to ensure there is not a build up of grass on the mower deck and engine

compartment, which could become a fire hazard. If you must wash the mower,

ensure you run the engine to operating temp to dry water and engage the blades to

spin off any standing water on the pulleys. Avoid spraying water onto electrical

components and bearings, to prevent premature failure of these parts.
