1037973 ENGINE BREAKDOWN

6-32

Fig. 25 -- Water Flange and Thermostat Group

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

8

3

15

Ref. Part No.

Description

Qty.

o

1

368090

)

Flange, Water [Ku]

1

Y

2

384859

Pipe, Water, Return

1

3

9005043

Fitting, Pipe, Plug [Ku]

2

4

70994

Gasket, Hsg, Thermostat [Ku]

1

5

71995

Screw, Hex [Ku]

3

6

72995

Screw, Hex [Ku]

1

7

73633

Hose, Water [Ku]

1

8

73634

Clamp, Hose, Heater [Ku]

2

9

361654

Thermostat, 160deg, 1.7d [Ku]

1

10 368091

Housing, Thermostat [Ku]

1

11 10851

Gasket

1

12 73535

Screw, Hex [Ku]

1

13 9003868

Pipe, Water [Kubota]

1

14 9003869

Pipe, Water [Kubota]

1

15 9003870

Clamp [Kubota]

1

1037973 ENGINE BREAKDOWN

6-33

Fig. 26 -- Water Pump Group

1

2

3

4

5

6

7

8

9

Ref. Part No.

Description

Qty.

o

1

9004402

)

Pump Assy, Water [Ku]

1

Y

2

70919

Flange, Pump, Water [Ku]

1

Y

3

9004403

Bearing [Ku]

1

Y

4

9004404

Seal Assy [Ku]

1

Y

5

9004405

Impeller, Pump, Water [Ku]

1

6

361440

Fitting, Pipe, Water [Ku]

1

7

70920

Gasket, Pump, Water [Ku]

1

8

9004406

Bolt [Ku]

4

9

9004407

Bolt [Ku]

2

1037973 ENGINE BREAKDOWN

6-34

Fig. 27 -- Alternator and Pulley Group

1

2

3

4

5 6

7

8

9

10

11

12

13

14

Ref. Part No.

Description

Qty.

1

361387

)

Alternator

1

2

361399

Stay,Dynamo

1

3

9005030

Screw, Hex [Ku]

1

4

361360

Bolt

1

5

361364

Washer,Plain

1

6

9005031

Washer, Spring [Ku]

1

7

71995

Screw, Hex [Ku]

1

8

9005032

Guard, Belt [Ku]

1

9

55847

Sheave, Fan [Ku]

1

10 361386

Sheave, Cshft [Ku]

1

11 73532

Screw, Hex, Cshft [Ku]

1

12 368082

Belt, V, 9.5mm 37.4l [Ku]

1

13 368075

Connector, Blade, 2 Terminal [Altv]

1

14 368078

Terminal, Qf, .25

2

1037973 ENGINE BREAKDOWN

6-35

Fig. 28 -- Fan Group

2

1

Ref. Part No.

Description

Qty.

1

361626

)

Fan

1

2

393588

Bolt, Flng

4
