6400 Diesel. Manual - part 31
OPTIONS
3--28
Fig. 19 -- Radial Tire and Wheel Kit, Front
1
2
4
3
5
8
9
10
11
12
13
4
5
6
7
352049 -- IC
Ref. Part No.
Serial Number
Description
Qty.
o
366112
(000000--
) Wheel and Tire Kit, Radial Front
1
Y
o
1
366107
(000000--
) Hub Assembly
2
YY
2
375001
(000000--
) Hub, Wheel w/studs
1
YY
3
32126
(000000--
) Stud, Wheel .50--20 X 1.50
5
YY
4
360074
(000000--
) Bearing, Ball, 1.18B 2.44D 0.6
2
Y
o
366114
(000000--
) Tire and Wheel Assembly, 16x6 RS Radial
2
YY
5
366104
(000000--
) Rim Assembly
1
YY
6
08714
(000000--
) Nut, Hex, Lock, M10 X 1.5, Nl, Ss
1
YY
7
39283
(000000--
) Screw, Hex, M10 X 1.50 X 25, 8.8
1
YY
8
366093
(000000--
) Tire, Tube & Flap Assy
1
YY
9
360300
(000000--
) Tire, 150/75R8 Pneumatic
1
YY
10 361077
(000000--
) Tube, Tire--Inner 16X6--8
1
YY
11 366092
(000000--
) Flap, Tire 2F 500
1
YY
12 45786
(000000--
) Cap, Valve Stem
1
Y
13 24339
(000000--
) Nut--Wheel .50--20 60 Angle
10
