BACKOUT

BACKOUT is an ISQL command that is meaningful only while you are using the

INPUT command with AUTOCOMMIT on. It nullifies all changes made since the

last SAVE command. If no SAVE command has been issued, all changes are

nullified since the start of the INPUT command.

With AUTOCOMMIT off, BACKOUT has no effect. You must enter a ROLLBACK

statement to nullify all input data. This also nullifies all changes made during the

current logical unit of work. You must end the INPUT command (by using the

END command) before issuing the ROLLBACK statement.

106

Interactive SQL Guide and Reference

BACKWARD

rows_integer

MAX

This ISQL display command displays the rows above or before those currently

being displayed.

rows_integer

is a number that indicates the number of rows backward that you want to

move the display.

MAX

moves the display to the beginning of the query result.

If neither rows_integer nor MAX is specified, the display moves backward half a

display.

Moving backward through the query result is limited: you can go backward to a

limit of one full display from the last FORWARD command, or you can return to

the beginning of the query result by issuing BACKWARD MAX.

Scrolling backward a half display at a time can be done by pressing PF7 (or PF19).

Because you can reset your PF keys, you can assign the BACKWARD function to

any PF key. The default function key is PF7 (or PF19).

Note: You cannot receive a prompt response when you enter a BACKWARD MAX

command, because the query must be reexecuted to move the display back

to the first display.

Chapter 10. ISQL Commands

107

CANCEL

CANCEL is an ISQL command that you can use to cancel a command, an SQL

statement, or logical unit of work in progress. CANCEL can be typed anytime you

are entering data, commands, or statements.

DB2 Server for VSE

Canceling a command or statement also causes a ROLLBACK to be

processed.

DB2 Server for VM

Canceling a command or statement also causes a ROLLBACK RELEASE to be

processed. If you have previously issued an explicit CONNECT command,

you must reconnect to the database manager.

If AUTOCOMMIT is on and the previous statement was an SQL INSERT,

UPDATE, or DELETE statement that affected more than one row, all changes made

by the previous statement are rolled back.

If AUTOCOMMIT is off, all work since the last COMMIT, or since the beginning of

the logical unit of work performed by the following, is rolled back:

v SQL statements

v ISQL commands that cause changes to table data, stored SQL statements, or

routines.

DB2 Server for VSE

Except for long-running SQL statements, to start a cancel operation, type:

cancel

DB2 Server for VM

To start a cancel operation, type:

cancel

When canceling a command with AUTOCOMMIT off, you are prompted to verify

if a CANCEL should be performed. If you type NO, the CANCEL processing is not

performed. If you answer YES, all changes made to the data since the last

COMMIT, or since the start of the logical unit of work if there was no COMMIT,

are rolled back.

108

Interactive SQL Guide and Reference

When you cancel an ISQL INPUT command with AUTOCOMMIT on, all changes

since the last SAVE command, or since the start of the INPUT command if there

was no SAVE command, are rolled back.

DB2 Server for VSE

Long-running SQL statements are those for which message ARI7044I is issued

to tell you that the terminal is free. These statements are cancelled by

pressing CLEAR and typing the CANCEL command prefixed by the ISQL

transaction identifier, ISQL. (If your location has redefined the ISQL

transaction identifier, prefix the CANCEL command with the transaction

identifier that your location has defined.)

The command looks like:

isql cancel

When canceling long-running SQL statements, a ROLLBACK is always

performed.

Chapter 10. ISQL Commands

109

CHANGE

CHAnge

/ replaced_string

replacing_string

CHANGE is an ISQL command that modifies the current SQL statement in the

SQL command buffer and displays the results. If data in the SELECT or FROM

clauses of a SELECT statement is changed, associated formatting information for

that statement is erased. However, if the changed information is contained in the

WHERE, GROUP BY, ORDER BY, or HAVING clauses, associated formatting

information for the statement is saved.

is any non-blank character that identifies the beginning and end of a string.

The slash is a good choice unless you are changing data that contains a slash.

This character must be separated from the command name by at least one

blank and must not occur in either string.

replaced_string

is the characters to be replaced in the current SQL statement. The string can

contain DBCS characters.

replacing_string

is the characters to replace the first occurrence of the characters in

replaced_string. If replacing_string is omitted, the first occurrence of

replaced_string is deleted. The string can contain DBCS characters.

Example

If the current SQL statement is:

select * from activity

and you type the following ISQL CHANGE command:

change /*/actno/

the result in the SQL command buffer is:

select actno from activity

110

Interactive SQL Guide and Reference

COLUMN

COLumn

position_in_select_list

COLUMN is an ISQL display command that displays the query result to be

formatted so that it begins with the specified column at the left edge of the display.

blank

causes column 1, or the first displayable column if column 1 is being excluded,

to be displayed at the left edge of the display.

position_in_select_list

is the number of the specified column.

The number refers to the columns provided by the SELECT statement, not

those currently displayed. You must choose a number that represents the

desired column’s position in the SELECT clause of the SELECT statement that

provided the query result.

If the value of position_in_select_list represents a column being excluded, the

display starts at the next column to the right that is not being excluded. If

there are no more displayable columns to the right, a blank display is the

result.

Specifying a value greater than the number of columns in the query result

displays the last column or a blank display if the last column is being

excluded.

Chapter 10. ISQL Commands

111

COUNTER

name

COUNTER is an operator command that is used primarily to monitor system

activity. It is not allowed during a logical unit of work. Before typing COUNTER,

you must end any logical unit of work that is in progress.

The SHOW command can only be used when the target application server is a

local application server. It cannot be used when the application server is a remote

application server.

* specifies that all counters are to be displayed.

name

is the name of the counters to be specified. Valid names are:

BEGINLUW

DBSSCALL

LDIRBUFF

PAGEREAD

CHKPOINT

DEADLCK

LOCKLMT

PAGWRITE

DASDIO

DIRREAD

LOGREAD

RDSCALL

DASDREAD

DIRWRITE

LOGWRITE

ROLLBACK

DASDWRIT

ESCALATE

LPAGBUFF

WAITLOCK

For an explanation of these counters, see the DB2 Server for VSE & VM

Operation manual.

The COUNTER command results in one or more displays. To proceed to the next

display, press CLEAR. It is not possible to move backward. You must first type the

END command, and then retype the COUNTER command. To exit from the

COUNTER command, type END. The COUNTER command is not available on a

non-DB2 Server for VSE & VM application server or if you are using DRDA

protocol.

Note: If the national language of the application server differs from the national

language that the user set for the ISQL session, the messages generated by

this operator command are issued in the national language of the

application server.

112

Interactive SQL Guide and Reference

DISPLAY

DISPLAY is an ISQL display command that can only be used in a routine. When

encountered, DISPLAY causes its associated SELECT statement results to be

displayed at your display terminal.

Any ISQL display commands placed in the routine after the associated SELECT

statement and before the DISPLAY command affect the display at the terminal. You

can, in addition, format the display or print the query result by typing ISQL

display commands from the keyboard after the query result is displayed, or from

the routine after the display is ended and before the END statement that is

associated with the SELECT statement whose results are being displayed. To end

the display of the query result initiated by the DISPLAY command and to return to

the routine, type the ISQL END command from the keyboard.

Example

In the following routine, you select all the rows from the DEPARTMENT table,

specify the format commands to be performed on the rows, and display the

formatted results on the display terminal. You must type end to end the display.

select * from department

format separator ' | '

format ttitle 'departments'

display

end

To get the same result as the above routine, you can type these lines in a routine:

select * from department

display

end

to see the DEPARTMENT table. Next, type these commands from the keyboard:

format separator ' | '

format ttitle 'departments'

and you see the DEPARTMENT table with column separators and a title just like

the first example.

Chapter 10. ISQL Commands

113

FORMAT

BTITLE

TTITLE

string

ERASE

COLumn column_id

DPLACes integer

NAME string

WIDTH integer

OFF

ZEROs

EXCLude

column_id

ALL BUT

(

column_id

)

GROUP

column_id

SUBTotal

EXCEPT

TOTal

(

column_id

)

ERASE

INCLude

column_id

ONLY

(

column_id

)

NULL string

OFF

OUTLINE

OFF

SEParator

BLANKs

integer

string

VARChar

integer

FORMAT is an ISQL display command that controls the format of the query result

currently being displayed. Modifications made to the display format by a FORMAT

command are reflected on the current display and the printed output obtained

from any subsequent PRINT command.

You can perform formatting only on the first 45 columns of a query result.

Any formatting command containing the keywords EXCLUDE, GROUP,

INCLUDE, ON/OFF, OUTLINE, SUBTOTAL, or TOTAL, causes the query to be

reexecuted.

Note: You can use DBCS characters in strings or column lists.

Chapter 10. ISQL Commands

117

BTITle

specifies the bottom title to be printed on reports. This bottom title is centered

on the bottom line of the report. Unless specified, no bottom title is printed.

string

is the characters to use for the bottom title on a subsequent PRINT

command.

The maximum length of the bottom title is that which fits on a line of the

page (up to a maximum of 100 characters). If the bottom title exceeds the

maximum, only those characters that fit on the line are printed.

Enclose the title in single quotation marks if it contains any blanks, but do

not include any single quotation marks in the title itself.

ERASE

causes the current bottom title to be deleted, resulting in no bottom title.

If FORMAT BTITLE is issued without either ERASE or a character string, the

current bottom title is displayed if it does not contain DBCS data. If the title

does contain DBCS data, message ARI7970I is issued.

TTITle

specifies the top title to be printed on reports. This top title is centered on the

top line of the report between the date and page number. If no top title is

specified, the first 100 characters of the SELECT statement are used for the top

title on printed reports.

string

is the characters to use for the top title on a subsequent PRINT command.

The maximum length of the top title is that which fits on the top line

between the date and page number (to a maximum of 100 characters). If

the top title exceeds the maximum, only those characters that fit between

the date and page number are printed.

Enclose the title in single quotation marks if it contains any blanks, but do

not include any single quotation marks in the title itself.

ERASE

causes the current top title to be deleted and the default to be used. The

default TTITLE is the first 100 characters of the SELECT statement.

If FORMAT TTITLE is issued without ERASE or a character string, the current

top title is displayed if it does not contain DBCS data. If the title does contain

DBCS data, message ARI7970I is issued.

COLumn

provides display formatting for a particular column.

column_id

specifies the column to be formatted.

If a number n is specified, it identifies the column to be formatted as the

nth column of the query result. The number refers to the position of the

columns provided by the SELECT statement, not those currently displayed.

Therefore, you must choose a number that represents the position of the

desired column in the SELECT clause of the SELECT statement that

provided the query result.

118

Interactive SQL Guide and Reference

If a number is not specified, column_id refers to the current column

heading of the column to be formatted. Enclose the name in single

quotation marks if it either contains a blank or refers to a column with a

solely numeric heading.

If the column_id represents a column being excluded, the formatting

specified is performed on the excluded column although you cannot see

the formatting until the column is included.

The following keywords describe how the current display is to be

formatted for the column specified by column_id:

DPLACes

specifies the number of decimal places (integer) to be displayed for a

numeric field. Rounding is not performed. The DPLACes must be less

than the column width.

NAME

specifies a column heading to be used for the display.

string

is the actual column heading to be displayed.

A maximum of 30 characters can be used for the column heading. All

characters except single quotation marks are valid. Enclose the column

heading in single quotation marks if it contains a blank, but do not

include any single quotation marks in the column heading itself.

WIDth

specifies the display length attribute (integer) of the column.

integer

For character type columns, the leftmost integer characters are

displayed.

For numeric type columns, the leftmost integer significant digits

counting the sign and decimal marker, if any, are displayed. The

sign character for a positive number is a blank.

For VARCHAR type columns, characters up to the current setting

of VARCHAR (using a SET or FORMAT command) are displayed.

For GRAPHIC type columns, integer represents the number of

DBCS characters. Two bytes are reserved for the SO/SI characters.

ZEROs

specifies whether leading zeros for numeric columns are displayed

(ON) or not (OFF).

EXCLude

specifies columns to be excluded (omitted) from the display. When SQL

processes a FORMAT command containing this keyword, it reexecutes the

query and repositions the display to the top of the query result.

ALL BUT

indicates that all columns except those specified are excluded. For example:

format exclude all but (1 job 4)

includes the JOB column, and columns 1 and 4, but excludes all other

columns.

Chapter 10. ISQL Commands

119

column_id

specifies the column to be formatted.

If a number is specified, it identifies the column to be formatted as the nth

column of the query result. The number refers to the position of the

columns provided by the SELECT statement, not those currently being

displayed. Therefore, you must choose a number that represents the

position of the desired column in the SELECT clause of the SELECT

statement that provided the query result.

If a number is not specified, column_id refers to the current column

heading of the column to be formatted. Enclose the name in single

quotation marks if it contains a blank or refers to a column with a solely

numeric heading.

When more than one column is specified, separate the column_ids with a

blank and enclose them in parentheses.

For example, the command:

format exclude (3 5)

causes the third and fifth column of the original position in the query

result to be excluded from the display. The command:

format exclude job

prevents the JOB column from being displayed during the current query

result. If JOB is selected two or more times, only the first occurrence of the

JOB column is excluded.

GROUP

specifies the columns to outline (when outlining is on) and the columns to use

for determining when subtotals are taken. Subtotals are taken whenever the

values change in the columns specified. When SQL processes a FORMAT

command containing this keyword, it reexecutes the query and repositions the

display to the top of the query result.

SUBTotal

specifies the columns in which subtotals are to be calculated. Subtotals are

taken whenever the values change in the columns being grouped. A (final)

total is also provided for the columns unless otherwise specified by a FORMAT

TOTAL command. When SQL processes a FORMAT command containing this

keyword, it reexecutes the query and repositions the display to the top of the

query result.

TOTal

specifies the columns in which (final) totals are to be calculated. If not

specified, totals are provided for all columns being subtotaled. When SQL

processes a FORMAT command containing this keyword, it reexecutes the

query and repositions the display to the top of the query result.

EXCEPT

specifies the columns to be grouped or totalled or subtotaled except those

specified by column_id.

column_id

is the name or position of each column in the query result to be grouped

for outlining, subtotals, or totals.

120

Interactive SQL Guide and Reference

When used with the SUBTOTAL and TOTAL keywords, column_id

specifies the columns on which subtotals or totals are to be calculated.

If a number is specified, it identifies the column to be formatted as the nth

column of the query result. The number refers to the position of the

columns provided by the SELECT statement, not those currently displayed.

Therefore, you must choose a number that represents the position of the

desired column in the SELECT clause of the SELECT statement that

provided the query result.

If a number is not specified, column_id refers to the current column

heading of the column to be formatted. Enclose the name in single

quotation marks if it contains a blank or refers to a column with a solely

numeric heading.

When specifying more than one column, separate the column_ids with a

blank and enclose them in parentheses.

If the column represents one that you are excluding, ISQL groups the

columns using that excluded column, although you do not see the

excluded column.

Subtotals or totals are calculated on the excluded column. You cannot see

the subtotals or totals until the column is included. When arithmetic errors

occur, the value of the column in error is calculated as zero.

The usual use of GROUP is to first order the rows of the columns that you

want grouped. Use an ORDER BY clause in the SELECT statement issued

to obtain the query result. The left to right ordering of the columns

themselves depends on the order in which they appear in the SELECT

clause of the SELECT statement.

Rows containing arithmetic errors from an outer select are displayed

together at the end of the list, followed by rows containing NULL values.

Rows containing arithmetic errors are displayed as asterisks (*).

ERASE

deletes all the previous specifications of GROUP for the current query

result. When used with SUBTOTAL, ERASE suspends subtotals. When

used with TOTAL, ERASE suspends totals.

INCLude

reverses the effect of a previous FORMAT EXCLUDE command. When SQL

processes a FORMAT command containing this keyword, it reexecutes the

query and repositions the display to the top of the query result.

ONLY

indicates that only those columns specified are displayed; all others are

excluded.

Note: Do not use ONLY for a column name with an INCLUDE keyword.

In this case, use its column number.

column_id

specifies the column to be formatted.

If a number n is specified, it identifies the column to be formatted as the

nth column of the query result. The number refers to the position of the

Chapter 10. ISQL Commands

121

columns provided by the SELECT statement, not those currently being

displayed. You must choose a number that represents the position of the

desired column in the SELECT clause of the SELECT statement that

provided the query result.

If a number is not specified, column_id refers to the current column

heading of the column to be formatted. Enclose the name in single

quotation marks if it contains a blank, or if it refers to a column with a

solely numeric heading.

When more than one column is specified, separate the column IDs with a

blank and enclose them in parentheses.

When arithmetic errors occur, the value of the column in error is calculated

as zero.

The columns that are not mentioned in the INCLUDE command, and that

are not currently being excluded, continue to participate in the display. If

INCLUDE is issued by itself and with no options, all excluded columns are

restored.

NULL

specifies the characters to display for null fields.

string

specifies the actual characters to display (up to a maximum of 20). If

blanks are included, you must enclose the string in single quotation marks,

but do not use single quotation marks in the string itself.

For example, the following command,

format null empty

causes the word EMPTY to be displayed for all null fields.

A question mark (?) is displayed for null values unless otherwise specified

with a FORMAT or SET command.

OFF

controls the status of outlining, subtotals, and totals on query results. When

SQL processes a FORMAT command containing this keyword, it reexecutes the

query and repositions the display to the top of the query result. Until OFF is

specified, outlining, subtotals, and totals are active.

permits outlining, subtotals, and totals. The ON status stays in effect for

the current query result until you type FORMAT OFF.

OFF

suspends outlining, subtotals, and totals.

OUTLINE

controls the outline report format for columns specified with FORMAT

GROUP. When SQL processes a FORMAT command containing this keyword,

it reexecutes the query and repositions the display to the top of the query

result.

122

Interactive SQL Guide and Reference

If OUTLINE is not specified, outlining is performed whenever GROUP is

specified unless you type FORMAT OFF.

specifies that successive duplicate values in grouped columns are repeated

only when they are the first line at the top of the display or at the

beginning of each page on printed reports. If the first line is a subtotal line

or a blank line between groups, successive duplicate values are not

displayed or printed at the beginning of the next group.

OFF

specifies that successive duplicate values in grouped columns are to be

displayed wherever they occur.

SEParator integer BLANKs

specifies the number of spaces (integer) to be displayed between columns. The

maximum number of blanks that can be specified is 254. Unless otherwise

specified with a FORMAT or SET command, the separation between columns

consists of two blanks.

SEParator string

specifies the characters to be displayed between columns. If blanks are

included, the string must be enclosed in single quotation marks, but do not

include any single quotation marks in the separator itself.

For example, if you want a vertical line between the columns, you type:

format separator ' | '

which places a blank, a vertical bar, and a blank between all columns. The

maximum number of characters that can be used for a separator is 254.

VARChar

specifies the display width of variable length columns.

integer

is the length desired up to 254. Unless otherwise specified with a SET

command, ISQL displays only the first 20 characters of a variable-length

column.

The SET command value for VARCHAR columns can be overridden for a

particular query by specifying the desired value with this keyword on the

FORMAT command.

When you type a FORMAT VARCHAR, the SELECT statement is reissued and

you are returned to the beginning of the query result.

Example

The following FORMAT commands used during a query exclude the first column,

change the name of the PRSTAFF column heading to ESTMEAN, display all

projected mean staff numbers in this column with three decimal places, and

display leading zeros:

format exclude 1

format column prstaff name estmean

format column estmean dplaces 3

format column estmean zeros on

Chapter 10. ISQL Commands

123

Note: If you rename a column heading, further FORMAT commands that refer to

that column by name must use the new name. When referring to the column

by a number, you must specify its original position in the SELECT clause of

the SELECT statement.

You can specify more than one keyword in a FORMAT command. For example, the

FORMAT commands described above can be expressed with a single command:

format exclude 1 column prstaff name estmean dplaces 3 zeros on

By using more than one keyword in a single FORMAT command, you can reduce

the amount of data you must type and improve the performance of ISQL.

124

Interactive SQL Guide and Reference

FORWARD

rows_integer

MAX

FORWARD is an ISQL display command that lets you move your display forward

through a query result.

rows_integer

is the number of rows you want to move forward.

MAX

causes the last display of the query result to be displayed along with an

indication of the number of rows in the query result and the Query Cost

Estimate (QCE) message. For query results that contain many rows, a

FORWARD MAX command can take a long time.

If nothing is specified, the display moves forward one-half of a display.

Scroll forward through the query result one-half of a display at a time by typing

FORWARD. (You can also press PF8 or PF20.) Because you can reset your PF keys,

you can assign the FORWARD function to another PF key.

You can activate FORWARD by pressing ENTER if it is the first display command

to be issued for a query result. The display moves forward one entire display each

time you press ENTER.

Chapter 10. ISQL Commands

125

HELP

CONTENTs

topic_name

This ISQL command retrieves online HELP information. This online HELP

information is for ISQL users who need quick reference information at their display

for:

SQL statements

ISQL commands

Messages, codes, and SQLSTATEs.

Note: The online HELP information is not serviced by the IBM Support Center.

The information is extracted from this book, and from the DB2 Server for

VSE Messages and Codes and DB2 Server for VM Messages and Codes manuals.

Use the readers’ comment form in the back of these books to express

concerns and comments on this information.

You can view this information in the language of your choice if your site chose to

install different language versions of the online HELP information. See the SET

command later in this chapter for more information on setting the language of

your choice.

Online HELP information is stored as a table. After you retrieve a topic, you can

use any of the ISQL display commands, or PF keys that provide display

commands, to assist in viewing the text. You can also type SQL statements or ISQL

commands at this time. You can format retrieved topics with the ISQL FORMAT

command and print them with the ISQL PRINT command. A top title is provided

for printed topics.

CONTENTs

displays the available online topics and the correct names to use in retrieving

specific topics.

topic_name

is the name of the topic to be retrieved. It can be one or more words and can

be placed within quotation marks. Most topic_names are either a statement

name (such as SELECT or INSERT), a message number (such as ARI7399I or

ARI7307A), a message code (such as -205 or 100), or an SQLSTATE (such as

SQLSTATE 01512). For example, to retrieve online HELP information for the

UPDATE statement, type:

help update

If the HELP command is issued with no parameters, a description of how to use

the HELP command is returned along with a list of the available topics. The HELP

command without additional parameters can be invoked by pressing PF1 (or

PF13). Because you can reset your PF keys, you can assign the HELP function to

any PF key. The default function key is PF1 (or PF13).

You can type SQL statements while the online HELP information is displayed.

126

Interactive SQL Guide and Reference

HOLD

HOLD sql_statement

HOLD is an ISQL command that prevents an SQL statement from being processed

when it is typed. The SQL statement is placed in the SQL command buffer and

remains there until it is replaced with another SQL statement. You can check the

SQL statement for typing errors before it is processed by a START command. You

can also type an SQL statement containing placeholders and substitute values for

the placeholders when the statement is started using a START command.

sql_statement

is the SQL statement to be held. (ISQL commands cannot be held).

The following example illustrates the use of a HOLD command to place an SQL

statement in the command buffer without executing it:

hold select * from employee

The HOLD command can also be invoked by pressing PF9 (or PF21) prior to,

during, or after typing. By pressing PF9 instead of ENTER, the SQL statement

typed is placed in the SQL command buffer without being processed. The HOLD

PF key does not store the command in the SQL command buffer; you must press

ENTER after pressing HOLD PF. The default key for the HOLD function is PF9 (or

PF21).

Chapter 10. ISQL Commands

127

INPUT

INPut

table_name

view_name

(

column_name

)

INPUT is an ISQL command that enables you to insert several rows of data into a

table or view.

INPUT is issued to identify the table, view, or column(s) where the data is

inserted.

table_name

view_name

is the name of the table or view in which data is to be inserted. A view_name

can only be used if it applies to a single table. The names can contain DBCS

characters.

column_name

is one or more column names, separated by commas, into which data is to be

inserted. The order in which the column names are specified determines the

order in which the data must be typed. All columns of the new row that are

not listed receive a null value, and unlisted columns must have been defined

to accept null values or an error occurs. This is because the INPUT command

is essentially inserting a new row of data, and null values are inserted into any

columns not specified. Omitting the column_name is the same as naming all

the columns of the table in their created order. The names can contain DBCS

characters.

Successful execution of the INPUT command causes the column names and their

data types to be displayed in the order in which the data must be typed. Data can

then be typed one row at a time. Press the ENTER key after each row is typed.

When typing data:

v Use commas to separate each data item of a row.

v Enclose the data item in single quotation marks if it is a CHAR, VARCHAR,

DATE, TIME, or TIMESTAMP data type.

v Do not enclose the keyword NULL, or any of the special registers, such as

CURRENT SERVER, in single quotation marks.

v If your data includes a single quotation mark, type two single quotation marks.

When you type:

'julie's book shop'

JULIE'S BOOK SHOP is inserted into the table.

v If you are typing graphic data, you type:

G'so...si'

where so stands for shift-out character, si stands for shift-in character, and ... is

graphic data (a DBCS character string).

Note: You can use N' as a synonym for G'

Chapter 10. ISQL Commands

129

v If you are typing hexadecimal data, you type X'F140F2'.

v If all the data for a single row does not fit in the input area, type the

continuation character. Press ENTER to continue.

v Be sure to include a space before the continuation character, if required, because

the continuation character does not provide one.

v When null values are allowed, you can type NULL to insert a null value for the

data-item value.

After you press ENTER for a row of data, the data is moved to the output area of

the display and the input area is cleared so that another row of data can be typed.

When all the data has been typed, type the END command to signify the end of

input data.

With AUTOCOMMIT on, the data you type is not committed to the table until the

INPUT command is ended by the END command or the END PF key (usually

PF3). You can use the ISQL SAVE command to commit data in the table prior to

typing an END command.

The SAVE command stores all data typed since the previous SAVE command or, if

one had not been typed, since the start of the INPUT command. It has the same

effect as the END command but lets you continue to type data.

In addition to storing data prior to ending an INPUT command, you can also

prevent the storing of data typed since the last SAVE command or since the start

of the INPUT command if no SAVE has been issued. You type the ISQL BACKOUT

command instead of more data.

If AUTOCOMMIT is off, the data you type on an INPUT command is not

committed to the table until you type a COMMIT command after ending the

INPUT command. With AUTOCOMMIT off, the SAVE and BACKOUT commands

have no effect.

Example

The following illustrates how you can fill the ACTIVITY table by using the INPUT

command:

input activity

160,'ADMDB','Adm databases'

100,'TEACH','Teach classes'

end

130

Interactive SQL Guide and Reference

Interactive Select

interactive-select-statement

fullselect

WITH

ASC

ORDER BY

column_name

integer

DESC

fullselect:

subselect

(fullselect)

UNION

subselect

UNION ALL

(fullselect)

subselect:

ALL

SELECT

DISTINCT

expression

table_name.*

view_name.*

correlation_name.*

FROM

table_name

view_name

correlation_name

WHERE search_condition

HAVING search_condition

GROUP BY

column_name

The interactive-select statement retrieves data from a table or view. The data

retrieved can only be viewed; you cannot change it. For more information about

the terminology used in this diagram, refer to the DB2 Server for VSE & VM SQL

Reference manual.

If a SELECT statement contains a placeholder in the WHERE, GROUP BY, ORDER

BY, or HAVING clauses, FORMAT information is saved until the next SELECT

statement is entered. Formatting information is saved permanently if the SELECT

statement is stored. However, if the SELECT or FROM clauses contain placeholders

or parameters, FORMAT information is not saved. In addition, FORMAT

information is not saved if you change any data in the SELECT or FROM clauses

by using the CHANGE command.

When you enter a SELECT statement from a terminal, the row length of the

information you can see at one time is limited by the terminal screen size.

Chapter 10. ISQL Commands

131

The number of bytes per row includes the bytes used as column separators.

UNION

combines two or more queries into a single query by merging the rows

returned by each query. Duplicate rows are eliminated.

ALL

combines the results of two or more queries without eliminating the

duplicate rows.

ALL

specifies that duplicate values are to be selected. If ALL is specified when you

select all department numbers from the PROJECT table, each and every

department number listed in the department number column is selected. This

is the default.

DISTINCT

specifies that duplicate values are not to be selected. DISTINCT can be used

only once for each SELECT statement. You can use it to eliminate duplicates

from the SELECT result:

select distinct deptno from project

You can also use it to eliminate duplicates from a column function:

select count (distinct deptno) from project

If you specify DISTINCT, the maximum number of columns you can put in the

expression list is 16. In addition, the length of the encoded key derived from the

expression list must not exceed 255 characters. That is, the sum of the lengths of

the columns in the expression list, plus approximately 25% of the lengths of

those columns that are of varying-length character type, must not exceed 255

EBCDIC or 127 DBCS characters.

* indicates that the data in all the columns is to be selected.

Note: If the table contains more than 45 columns, only the first 45 columns

will be displayed. To see the other columns in the table, you can create a

view. A view may contain no more than 140 columns. If more columns

are needed, you can create additional views.

expression

is a definition of the data desired. An expression may be a column name, a

constant, a character expression, a special register, a column function, a scalar

function, an arithmetic expression, or a labeled duration.

You can specify a list of expressions, separating each with a comma, and the

items are retrieved in the same left-to-right order as they appear in the list. The

value of USER is interpreted as a CHAR(8) string whose value is the user ID of

the user currently connected. The maximum number of columns that you can

specify in the list is 45.

You can use the following operators to connect numeric data types:

(plus, add)

−

(minus, subtract)

(times, multiply)

(divided by)

If you use these operators for numeric data types, see the DB2 Server for VSE &

VM SQL Reference manual for information about data conversion.

132

Interactive SQL Guide and Reference

You can use the concatenation operator, CONCAT, to join two or more

compatible operands to form a string. An operand may be a column, a name, a

constant, or an expression.

An operand can be the result of an expression. For example, if the USER

special register is used, it is treated as CHAR(8). If the CURRENT DATE,

CURRENT TIME, CURRENT TIMESTAMP, or CURRENT TIMEZONE special

registers are used, the values are treated as the character representation of the

value in the format defined by the system. A datetime value can be

concatenated with a character string because the datetime data types are

compatible with character data types.

When varying-length operands are concatenated, only the actual length of the

operand is concatenated.

The result of the expression is the concatenation of the operand expressions.

The resulting data type is null if either operand is nullable. The resulting data

type is character if both operands are CHARACTER. If both operands are

GRAPHIC, the result data type is GRAPHIC. If both operands are fixed length,

the resulting data type is fixed length. If either operand is varying length, the

resulting data type is a varying length string. The associated defined length is

the sum of the defined lengths not exceeding 254 bytes.

In the following example, the employee number and the first name of the

employee are concatenated with a hyphen between them:

select empno concat '-' concat

firstnme from employee

If a column function is used in an expression, all expressions in the list must

contain a column function unless grouping is being performed. An example is:

select min(edlevel),avg(bonus) from employee

table_name.*

view_name.*

correlation_name.*

identifies the table or view to which the column belongs. The asterisk (*) can

be replaced with a column name. These prefixes are especially useful for

differentiating columns that have the same name, but that belong to different

tables or views. The correlation_name can be used to simplify a query, or to join

a table to itself. See “correlation_name” below for more information.

FROM table_name

FROM view_name

identifies the table or view from which data is to be selected.

table_name

view_name

is the name of the table or view.

You can further qualify the table or view by specifying the owner of the

table or view. You must separate the owner’s name from the table name or

view name with a period. The owner’s name is unnecessary for tables or

views that you own. You must have the SELECT privilege or DBA

authority to select information from tables or views owned by other users.

Chapter 10. ISQL Commands

133

correlation_name

is the name you define as an alternative name for the table or view to be

selected. It can be any string up to 18 characters long, and must begin with a

letter.

WHERE search_condition

is one or more conditions to apply in selecting data.

GROUP BY column_name

A query can have the column functions SUM, AVG, MAX, MIN, and COUNT

applied to groups of rows that have matching values in a column. Rows can

also be grouped by matching values in more than one column. The definition

of the groups is specified with a GROUP BY clause.

column_name

is the name of one or more columns, separated by commas, to be used

when forming a group.

For example, the maximum, minimum, and average activity staff for each project

in the PROJ_ACT table could be selected by the following query:

select projno,max(acstaff),min(acstaff),avg(acstaff) -

from proj_act -

group by projno

When a query uses the grouping feature, it returns only one result row for

each group. Therefore, the items selected by such a query must be properties

of the groups, not properties of individual rows. The expression list may contain

columns that are also in the GROUP BY clause together with column functions

on any columns. It may not contain any non-grouped column without a

column function. If the column function COUNT(*) is used, it evaluates to the

number of rows in the group.

If any rows have a null value in a grouped column, ISQL groups the null

values in those columns together. The null values returned may be due either

to unknown column values or to arithmetic exception errors.

A grouping query may have a standard WHERE clause that serves as a filter,

keeping only those rows which satisfy the search_condition. The WHERE clause

filters out the non-qualifying rows before the groups are formed and the

column functions are computed.

The following example query finds the average and minimum activity staff for

each project, considering only activities whose starting date is 1 January 1982:

select projno,avg(acstaff),min(acstaff) -

from proj_act -

where acstdate = '1982-01-01' -

group by projno

HAVING search_condition

is one or more conditions that apply to groups. ISQL returns a result only for

those groups that satisfy the condition. The HAVING clause may contain one

or more group-qualifying conditions connected by ANDs and ORs. Each

group-qualifying condition compares some property of the group, such as

AVG(ACSTAFF), with another group property or with a constant.

The following example query lists the maximum and minimum activity staff

for various projects in the PROJ_ACT table, considering only projects that have

more than three activities:

134

Interactive SQL Guide and Reference

select projno,max(acstaff),min(acstaff) -

from proj_act -

group by projno -

having count(*) > 3

One of the functions in a HAVING clause may specify DISTINCT (for example,

COUNT(DISTINCT PROJNO)). However, DISTINCT may be used only once in

a query. It may not be used in both the expression list and the HAVING clause.

It is possible, though unusual, for a query to contain a HAVING clause but no

GROUP BY clause. In this case, the entire table is treated as one group. If the

HAVING condition is true for the table as a whole, the selected result, which

must consist entirely of column functions, is returned.

ORDER BY

orders, or sorts, the rows to be retrieved by the column(s) specified. A

maximum of 16 columns may be specified in the ORDER BY clause.

column_name

refers to a column name in the expression list. For example, to order a

query primarily by the values in the ACTNO column and secondarily by

the values in the PROJNO column, you would type:

select actno,projno,acstdate,acendate -

from proj_act -

order by actno,projno

integer

refers to the items in the expression list. For example, to order a query

primarily by the first item and secondarily by the third item of the list, you

would type:

select projno,acstdate,acendate,acstaff -

from proj_act -

order by 1,3

These items may be columns or more complex expressions such as

BONUS+COMM.

ASC

DESC

indicates the order in which results are returned: either ascending (ASC) or

descending (DESC). The default is ASC. For example, to indicate ascending

order on item 3 and descending order on item 5, you could type:

order by 3,5 desc

because ASC is the default.

In contrast, to indicate descending order on item 3 and item 5, you would

type:

order by 3 desc,5 desc

Blanks sort first in ascending order, last in descending order, and are

ignored if the data type is VARCHAR or VARGRAPHIC.

Chapter 10. ISQL Commands

135

ISQLTRACE

ISQLTrace

DUMP

DISPLAY

integer

The ISQLTRACE command traces activity within ISQL. This ISQL command traces

calls to and returns from other ISQL modules, SQL return codes, and ISQL

messages. Trace information is saved in storage for dump debugging.

DUMP

specifies that the trace information is to be printed. ISQL creates an

unformatted storage dump hardcopy of the trace table.

DB2 Server for VM

ISQL uses the CP DUMP command to dump to the lowest priority virtual

printer defined.

DB2 Server for VSE

ISQL issues a CICS dump to the CICS dump data set.

You must run a job to print the dump data set.

DISPLAY

specifies that the formatted trace table is to be displayed on the display. If

more than 50 entries or more than the specified integer number of entries have

been made in the trace table, the entries wrap. The more recent entries are

written over the earlier entries. As a result, only the last 50 entries or integer

number of entries in the table are displayed. The entries are displayed in

reverse order of the order that they were put into the trace table.

integer

changes the size of the trace table. Replace integer with the number of trace

entries that are to be contained in the trace table. integer must be a number

from 50 to 1000.

136

Interactive SQL Guide and Reference

LEFT

integer

LEFT is an ISQL display command that causes the display to start integer columns

to the left, counting from the leftmost column on the display and as long as no

columns are being excluded. The number refers to the columns provided by the

SELECT statement, not those currently displayed. You must use the order of the

columns specified in the SELECT clause of the SELECT statement that provided

the query result to determine the value to specify for integer. If the value of integer

represents a column being excluded, the display starts at the next displayable

column to the right of the excluded column.

Specifying a value greater than the number of columns remaining to the left, starts

the display at column 1 or at the first displayable column if column 1 is excluded.

If no number is specified, the display moves one column to the left. No change in

the display occurs if that column is excluded.

Chapter 10. ISQL Commands

137

LIST

SQL

stored-statement-name

SET

AUTOCommit

CASE

(1)

CLAss

CONTInue

(1)

COPies

COSTest

DECimal

ISOLation

LANGuage

NULL

PAGEsize

(1)

PRINTRoute

RUNMode

SEParator

VARChar

Notes:

The parameters CLAss, COPies, and PRINTRoute are not applicable to VM.

LIST is an ISQL command that lists information about stored SQL statements or

the settings of operational characteristics set by the SET command.

SQL

lists stored SQL statement(s) on the display. See “STORE” on page 161 for more

information.

stored_statement_name

is the name of the stored SQL statement to be listed. The entire statement

stored with the specified name is displayed.

* specifies that all your stored SQL statements are to be listed. The name of

each statement and its first 50 characters are displayed.

SET

lists the current operational characteristics in effect for the specified function of

the SET command. For example, if you type:

list set continue

the current continuation character is displayed. Valid functions are any of those

functions performed by the SET command.

If * is specified, the current operational characteristics in effect for all SET

command functions are listed. For a description of the SET characteristics, see

“SET” on page 149. for more information.

138

Interactive SQL Guide and Reference

CLAss

character

COPies

integer

TERMid termid

DESTid wkstat

SYStem

TOUSER

userid

DB2 Server for VSE

PRINT is an ISQL display command that requests printed copies of a query

result by sending it to the system printer, POWER remote printer, or

CICS/VSE terminal.

DB2 Server for VM

PRINT is an ISQL display command that requests printed copies of a query

result by sending it to the system printer.

The data that is printed is based on the query result obtained by the SELECT

statement.

All the rows of the query result, as modified by FORMAT commands, are printed

regardless of the position of your display of the result. A query result that is longer

than what can be viewed on one display, can be printed with one PRINT

command. The printed report starts with the column and the character position

within the column that is at the left edge of the display when the PRINT command

is typed. The number of characters of each row that is printed depends on the

setting of the PAGESIZE WIDTH value specified by the SET command. You receive

a message if the width of the row of data exceeds the WIDTH setting.

The output class to use can be obtained from the people responsible for data

processing at your location.

DB2 Server for VSE

Note: CLASS and COPIES cannot be specified for a CICS/VSE terminal

printer.

140

Interactive SQL Guide and Reference

DB2 Server for VM

Note: You must use the CP TAG and CP SPOOL commands to direct printed

output.

CLAss

specifies the output class.

character

is the output class desired. For DB2 Server for VSE, the output class can be

a letter (A to Z).

For DB2 Server for VM, the CLASS value can be an integer (0 to 9) or a

letter (A to Z). The default is class A.

? (DB2 Server for VSE only)

specifies that the default printer class of the system is to be used.

For DB2 Server for VSE, if CLASS is not included in the PRINT command

at all, the current class set by the SET command is used. If no class has

been set by a SET command, the default printer class for the system is

used.

For DB2 Server for VM, there is no SET command for CLASS. You can set

the CLASS value by a CP SPOOL command.

COPies

specifies the number of copies.

integer

is the number of copies desired. For DB2 Server for VSE, you can request

up to 99 copies. For DB2 Server for VM, you can specify a COPIES value

from 1 to 255.

If this keyword is not specified, one copy is the default unless otherwise

determined by a SET command (in DB2 Server for VSE).

DB2 Server for VM

You can also use the CP SPOOL command to specify the number of

copies. The value for copies that is specified on the CP SPOOL

command remains in effect until another value is specified by another

CP SPOOL command.

Note: If you specify the number of copies on the PRINT command

after you specified it using a CP SPOOL command, the PRINT

command quantity is used for that print operation. All

following PRINT commands use the quantity specified by the

CP SPOOL command, unless you specify it using the COPIES

keyword.

Because you can reset your PF keys, you can assign the PRINT

function to any PF key. The default function key is PF4 or PF16.

Chapter 10. ISQL Commands

141

TERMid (DB2 Server for VSE only)

specifies that printed output is to be directed to the designated CICS/VSE

terminal.

termid

is the terminal identifier of the CICS/VSE terminal that you want. termid

must be from one to four alphanumeric characters.

DESTid (DB2 Server for VSE only)

specifies that the printed output is to be directed to the designated POWER

remote workstation.

wkstat

is the ID of the desired remote workstation. wkstat can be any number

from 0 to 250. When wkstat is 0, the printed output is to be directed to the

system printer.

SYStem (DB2 Server for VSE only)

specifies that the printed output is to be directed to the system printer.

TOUSER (DB2 Server for VSE only)

specifies that the printed output is to be directed to a user identified by userid.

userid

is the VSE POWER user identifier of the user to whom the output is being

spooled. An identifier cannot be longer than 8 alphanumeric characters.

If you enter the PRINT TOUSER command without specifying a userid,

ISQL spools the output to the ISQL user ID used at time of log on.

The PRINT TOUSER nnn command has the same effect as the PRINT

DESTid nnn command, where nnn is the ID of the remote workstation to

which you want to direct your printed output. This ID can be any number

from 1 to 250.

DB2 Server for VSE

Any TERM, DEST, or SYS indication on the PRINT command applies for that

particular PRINT operation only.

The PRINT command can be started by pressing PF4.

Each printed page is numbered and dated at the top. A title is automatically

provided at the top of each printed page. This title consists of the first 100

characters of the SELECT statement issued unless you specified your own title

with an ISQL FORMAT command.

You can specify more than one keyword option on a single PRINT command. For

example, the following command specifies both the class and number of copies:

print copies 3 class a

142

Interactive SQL Guide and Reference

DB2 Server for VM

If there is an error in the command, all valid changes are made until the

mistake is determined. For example, in the following command, you type a $

sign instead of the letter a:

print copies 3 class $

The command sets the number of print copies to 3. However, the class

remains at the default class A, because $ is an incorrect output class. This

output class error does not change the number of copies to the original value.

Neither does the number of copies or the class change from their current

settings if the following command is issued:

print class $ copies 3

The output class value is again incorrect, so processing stops when this error

is detected.

Chapter 10. ISQL Commands

143

RECALL

stored_statement_name

RECALL is an ISQL command that retrieves a stored SQL statement. The stored

statement is inserted into the SQL command buffer and is shown in your display.

You must enter the START command before the statement is started.

stored_statement_name

is the name of the stored SQL statement to be recalled.

specifies that the previous SQL statement (the one typed prior to the current

SQL statement) is to be recalled. The current SQL statement is then saved with

the name PREVIOUS.

Entering RECALL with no name specified, or pressing the appropriate PF key,

displays the statement currently contained in the SQL command buffer. The

RECALL command can be invoked by pressing PF5. You can assign the RECALL

function to any PF key; the default is PF5 or PF17.

144

Interactive SQL Guide and Reference

DB2 Server for VSE. Operations Guide / Handbooks (2004-2007) - page 19
