ERROR_ACTION CHARACTER(1) NOT NULL, //action taken when a send queue

//is in error; default "I"- invalidate;

//or "S" - stop Q Capture.

HEARTBEAT_INTERVAL INTEGER NOT NULL, //interval in seconds between

//heartbeat msg sent when no

//transactions to publish; must be

//multiple of commit_interval; default 0

//- do not send;

MAX_MESSAGE_SIZE INTEGER NOT NULL , //max size of buffer in KB used

for

//sending msg over the send queue;

//default 64K

APPLY_SERVER VARCHAR(18), //dbname of Q Apply server where the

//target tables are defined

APPLY_ALIAS VARCHAR(8), //alias of the name defined in the

//previous column

APPLY_SCHEMA VARCHAR(128), //schema of the Q Apply which applies

//the changes on this receive queue

DESCRIPTION VARCHAR(254), //user maintained description attribute

primary key ( SENDQ )

) IN XXXXXX;

The following index is created on this table:

CREATE UNIQUE INDEX ASN.IX1PUBMAPCOL ON ASN.IBMQREP_SENDQUEUES

(PUBQMAPNAME ASC);

MESSAGE_FORMAT - The default value is ″C″ for compact message type. Q

Capture for VSE/VM only supports this type of message. The XML (″X″) encoding

format is not supported.

IBMQREP_SUBS control table

The IBMQREP_SUBS control table identifies tables for which changes are captured,

and onto which queue the transaction is published.

CREATE TABLE ASN.IBMQREP_SUBS (

SUBNAME VARCHAR(132) NOT NULL, //subscript name; for any instance,

//the subname has to be unique.

SOURCE_OWNER VARCHAR(128) NOT NULL, //qualifier of the source

//tables

SOURCE_NAME VARCHAR(128) NOT NULL, //source table names

TARGET_SERVER VARCHAR(18), //dbname of the Q Apply server

//where target tables are defined

TARGET_ALIAS VARCHAR(8), //alias of the dbname

TARGET_OWNER VARCHAR(128), //target table owner

TARGET_NAME VARCHAR(128), //target table name

TARGET_TYPE INTEGER, //target type; always 1 - user table

APPLY_SCHEMA VARCHAR(128), //schema of the Q Apply prg which applies

//changes that are captured by this Q

DB2 DataPropagator Q Capture Supplement

IBM Confidential

//Capture instance

SENDQ VARCHAR(48) NOT NULL , //queue name for writing the changes

//involving this table

SEARCH_CONDITION VARCHAR(2048), //not supported by Q Capture VSE/VM

SUB_ID INTEGER, //sub id generated by Q Capture and supplied

//to Q Apply in the schema msg

SUBTYPE CHARACTER(1) NOT NULL, //subscription type; default "U" -

//unidirectional. This is the only

//type supported by Q Capture

//VSE/VM.

ALL_CHANGED_ROWS CHARACTER(1) NOT NULL, //whether to send the row if any

//column in the row is changed;

//default "N" (send only when s

//subscripted column is changed

BEFORE_VALUES CHARACTER(1) NOT NULL, //whether to send before-value of the

//column; for UPDATE and DELETE

//only; default "N"

CHANGED_COLS_ONLY CHARACTER(1) NOT NULL, //send the after-value for only

//changed columns; for

//UPDATE only; default "Y"

HAS_LOADPHASE CHARACTER(1) NOT NULL, //whether or not the source table

//will be loaded at the target; default

//"I"- internal load; "E"- external

//load; and "N" for no load

STATE CHARACTER(1) NOT NULL , //initial state for the subscription;

//default "N" - new; "L" - loading; "A" - active

//and "I" - inactive.

STATE_TIME TIMESTAMP NOT NULL, //time stamp for last state change

STATE_INFO CHARACTER(8), //explanation on why the sub is in current state

STATE_TRANSITION VARCHAR(256) FOR BIT DATA, //internal column

SUBGROUP VARCHAR(30), //n/a to Q Capture VSE/VM

SOURCE_NODE SMALLINT NOT NULL , //n/a; always 0 for Q Capture VSE/VM

TARGET_NODE SMALLINT NOT NULL , //n/a; always 0 for Q Capture VSE/VM

GROUP_MEMBERS CHARACTER(254) FOR BIT DATA, //not used by Q Capture VSE/VM

OPTIONS_FLAG CHARACTER(4) NOT NULL , //reserved for future use

SUPPRESS_DELETES CHARACTER(1) NOT NULL, //do not send delete operation row;

default

"N"

DESCRIPTION VARCHAR(200), //description for the subscription

TOPIC VARCHAR(256), //n/a

primary key ( SUBNAME ) , FOREIGN KEY FKSENDQ ( SENDQ ) REFERENCES ASN.IBMQREP_SENDQUEUES

) IN XXXXXX;

IBMQREP_SRC_COLS control table

The IBMQREP_SRC_COLS control table lists the source table columns for which

changes are captured.

Appendix. Q Capture control tables

IBM Confidential

CREATE TABLE ASN.IBMQREP_SRC_COLS (

SUBNAME VARCHAR(132) NOT NULL , //subscription name

SRC_COLNAME VARCHAR(30) NOT NULL, //column name

IS_KEY SMALLINT NOT NULL, //whether this column is part of the

//key; default 0 - not key column;

//n - the key column number

primary key ( SUBNAME, SRC_COLNAME ) ,

FOREIGN KEY FKSUBS ( SUBNAME) REFERENCESASN.IBMQREP_SUBS)

IN XXXXXX;

IBMQREP_SIGNAL control table

The IBMQREP_SIGNAL control table is used for communication between the

user/subscriber and the Q Capture program.

CREATE TABLE ASN.IBMQREP_SIGNAL(

SIGNAL_TIME TIMESTAMP NOT NULL , //time the signal is inserted into the table

SIGNAL_TYPE VARCHAR(30) NOT NULL, //type of signal; "CMD" or "USER"

SIGNAL_SUBTYPE VARCHAR(30), //subtype for "CMD" signals;

SIGNAL_INPUT_IN VARCHAR(250),

SIGNAL_STATE CHARACTER(1) NOT NULL, //default "P" - pending; "R" - received by

//Capture; "C" - completed; "F" - failed.

SIGNAL_LSN CHARACTER(10) FOR BIT DATA, //LSN of the log record of this insert

primary key ( SIGNAL_TIME ) ) DATA CAPTURE CHANGES IN XXXXXX;

v SIGNAL_SUBTYPE

Values:

’CAPSTART’: Start capturing for the subscription sname on queue_name

–

’CAPSTOP’: Stop capturing for subscription sname on queue_name

–

’QINERROR’: Error occurred on the send queue or the receive queue that is

associated with the send queue. Error action for the send queue specified will

be executed according to the SENDQUEUES table.

’LOADDONE’: Tell the Q Capture program that the replicated table is now

loaded.

’STOP’: Stop the Q Capture program.

–

’IGNORETRANS’: Ignore transaction that contains this signal

v SIGNAL_INPUT_IN - If the signal_type is ’USER’, then this column contains

user-defined input. If the signal_type is ’CMD’, then the meaning of this value

depends on the signal_subtype for this signal:

Values:

- Subscription name for CAPSTART, CAPSTOP, and LOADDONE

- Send queue name and message text for QINERROR where message text is the

ASN message number and tokens separated by space characters

- NULL for STOP and IGNORETRANS

DB2 DataPropagator Q Capture Supplement

IBM Confidential

IBMQREP_CAPTRACE control table

The IBMQREP_CAPTRACE control table contains information and error messages

generated by the Q Capture program.

CREATE TABLE ASN.IBMQREP_CAPTRACE(

OPERATION CHARACTER(8) NOT NULL , //values "INFO", "WARNING" or

//"ERROR"

TRACE_TIME TIMESTAMP NOT NULL , //time when msg was written

DESCRIPTION VARCHAR(1024) NOT NULL //asn msg id followed by the

//msg text

) IN XXXXXX;

IBMQREP_ADMINMSG control table

The IBMQREP_ADMINMSG control table contains administration messages from

the Q Apply program received by the Q Capture program.

CREATE TABLE ASN.IBMQREP_ADMINMSG(

MQMSGID CHARACTER(24) FOR BIT DATA NOT NULL , //MQ message id of the

//admin msg

MSG_TIME TIMESTAMP NOT NULL , //time the msg was inserted into the table

primary key ( MQMSGID ) ) IN XXXXXX;

Appendix. Q Capture control tables

IBM Confidential
