ISO 32000-1 Document management — Portable document format — Part 1: PDF 1.7 - page 13

Table 255 - Entries in the UR transform parameters dictionary (continued)

Key

Type

Value

Form

array

(Optional) An array of names specifying additional form-field-related usage

rights for the document. Valid names (PDF 1.5) are:

Add

Permits the user to add form fields to the document.

Delete

Permits the user to delete form fields to the document.

FillIn

Permits the user to save a document on which form fill-in

has been done.

Import

Permits the user to import form data files in FDF, XFDF and

text (CSV/TSV) formats.

Export

Permits the user to export form data files as FDF or XFDF.

SubmitStandalone Permits the user to submit form data when the document is

not open in a Web browser.

SpawnTemplate Permits new pages to be instantiated from named page

templates.

The following names (PDF 1.6) shall be permitted only when the signature

dictionary is referenced from the UR3 entry of the permissions dictionary; see

Table 258:

BarcodePlaintext Permits (PDF 1.6) text form field data to be encoded as a

plaintext two-dimensional barcode.

Online

Permits

(PDF

1.6) the use of forms-specific online

mechanisms such as SOAP or Active Data Object.

Signature

array

(Optional) An array of names specifying additional signature-related usage

rights for the document. The only defined value shall be Modify, which permits

a user to apply a digital signature to an existing signature form field or clear a

signed signature form field.

EF

array

(Optional; PDF 1.6) An array of names specifying additional usage rights for

named embedded files in the document. Valid names shall be Create, Delete,

Modify, and Import, which shall permit the user to perform the named operation

on named embedded files.

P

boolean

(Optional; PDF 1.6) If true, permissions for the document shall be restricted in

all consumer applications to those permissions granted by a conforming

reader, while allowing permissions for rights enabled by other entries in this

dictionary. Default value: false.

12.8.2.4

FieldMDP

The FieldMDP transform method shall be used to detect changes to the values of a list of form fields. The

entries in its transform parameters dictionary are listed in Table 256.

Table 256 - Entries in the FieldMDP transform parameters dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be TransformParams for a transform parameters dictionary.

Action

name

(Required) A name that, along with the Fields array, describes which form

fields do not permit changes after the signature is applied.

Valid values shall be:

All

All form fields.

Include

Only those form fields that specified in Fields.

Exclude

Only those form fields not specified in Fields.

Fields

array

(Required if Action is Include or Exclude) An array of text strings containing

field names.

473

Table 256 - Entries in the FieldMDP transform parameters dictionary (continued)

Key

Type

Value

V

name

(Optional: PDF 1.5 required) The transform parameters dictionary version. The

value for PDF 1.5 and later shall be 1.2.

NOTE

This value is a name object, not a number.

Default value: 1.2.

On behalf of a document author creating a document containing both form fields and signatures the following

shall be supported by conforming writers:

•

The author specifies that form fields shall be filled in without invalidating the approval or certification

signature. The P entry of the DocMDP transform parameters dictionary shall be set to either 2 or 3 (see

Table 254).

•

The author can also specify that after a specific recipient has signed the document, any modifications to

specific form fields shall invalidate that recipient’s signature. There shall be a separate signature field for

each designated recipient, each having an associated signature field lock dictionary (see Table 233)

specifying the form fields that shall be locked for that user.

•

When the recipient signs the field, the signature, signature reference, and transform parameters

dictionaries shall be created. The Action and Fields entries in the transform parameters dictionary shall

be copied from the corresponding fields in the signature field lock dictionary.

NOTE

This copying is done because all objects in a signature dictionary must be direct objects if the dictionary

contains a byte range signature. Therefore, the transform parameters dictionary cannot reference the

signature field lock dictionary indirectly.

FieldMDP signatures shall be validated in a similar manner to DocMDP signatures. See Validating Signatures

That Use the DocMDP Transform Method in 12.8.2.2, “DocMDP” for details.

12.8.3

Signature Interoperability

12.8.3.1

General

It is intended that conforming readers allow interoperability between signature handlers; that is, a PDF file

signed with a handler from one vendor shall be able to be validated with a handler from a different vendor.

If present, the SubFilter entry in the signature dictionary shall specify the encoding of the signature value and

key information, while the Filter entry shall specify the preferred handler that should be used to validate the

signature. When handlers are being registered according to Annex E they shall specify the SubFilter encodings

they support enabling handlers other than the preferred handler to validate the signatures that the preferred

handler creates.

There are several defined values for the SubFilter entry, all based on public-key cryptographic standards

published by RSA Security and also as part of the standards issued by the Internet Engineering Task Force

(IETF) Public Key Infrastructure (PKIX) working group; see the Bibliography for references.

12.8.3.2

PKCS#1 Signatures

The PKCS#1 standard supports several public-key cryptographic algorithms and digest methods, including

RSA encryption, DSA signatures, and SHA-1 and MD5 digests (see the Bibliography for references). For

signing PDF files using PKCS#1, the only value of SubFilter that should be used is adbe.x509.rsa_sha1, which

uses the RSA encryption algorithm and SHA-1 digest method. The certificate chain of the signer shall be stored

in the Cert entry.

474

•

Online Certificate Status Protocol (OCSP) Responses, described in RFC 2560, X.509 Internet Public Key

Infrastructure Online Certificate Status Protocol—OCSP (see the Bibliography): These are generally small

and constant in size and should be the data type included in the PKCS#7 object.

•

Custom revocation information: The format is not prescribed by this specification, other than that it be

encoded as an OCTET STRING. The application should be able to determine the type of data contained

within the OCTET STRING by looking at the associated OBJECT IDENTIFIER.

adbe's Revocation Information attribute value has ASN.1 type RevocationInfoArchival:

RevocationInfoArchival ::= SEQUENCE {

crl

[0] EXPLICIT SEQUENCE of CRLs, OPTIONAL

ocsp

[1] EXPLICIT SEQUENCE of OCSP Responses, OPTIONAL

otherRevInfo [2] EXPLICIT SEQUENCE of OtherRevInfo, OPTIONAL

}

OtherRevInfo ::= SEQUENCE {

Type OBJECT IDENTIFIER

Value OCTET STRING

}

For byte range signatures, Contents shall be a hexadecimal string with “<” and “>” delimiters. It shall fit

precisely in the space between the ranges specified by ByteRange. Since the length of PKCS#7 objects is not

entirely predictable, the value of Contents shall be padded with zeros at the end of the string (before the “>”

delimiter) before writing the PKCS#7 to the allocated space in the file.

The format for encoding signature values should be adbe.pkcs7.detached. This encoding allows the most

options in terms of algorithm use. The following table shows the algorithms supported for the various SubFilter

values.

Table 257 - SubFilter value algorithm support

SubFilter value

adbe.pkcs7.detached

adbe.pkcs7.sha1

adbe.x509.rsa.sha1^a

Message Digest

SHA1 (PDF 1.3)

SHA1 (PDF 1.3)

SHA1 (PDF 1.3)^b

SHA256 (PDF 1.6)

SHA256 (PDF 1.6)

SHA384 (PDF 1.7)

SHA384 (PDF 1.7)

SHA512 (PDF 1.7)

SHA512 (PDF 1.7)

RIPEMD160 (PDF 1.7)

RIPEMD160 (PDF 1.7)

RSA Algorithm Support

Up to 1024-bit (PDF 1.3)

See

See

adbe.pkcs7.detached

adbe.pkcs7.detached

Up to 2048-bit (PDF 1.5)

Up to 4096-bit (PDF 1.5)

DSA Algorithm Support

Up to 4096-bits (PDF 1.6)

See

No

adbe.pkcs7.detached

^a Despite the appearance of sha1 in the name of this SubFilter value, supported encodings shall not

be limited to the SHA1 algorithm. The PKCS#1 object contains an identifier that indicates which al-

gorithm shall be used.

^b Other digest algorithms may be used to digest the signed-data field; however, SHA1 shall be used

to digest the data that is being signed.

12.8.4

Permissions

The Perms entry in the document catalogue (see Table 28) shall specify a permissions dictionary (PDF 1.5).

Each entry in this dictionary (see Table 258 for the currently defined entries) shall specify the name of a

permission handler that controls access permissions for the document. These permissions are similar to those

476

defined by security handlers (see Table 22) but do not require that the document be encrypted. For a

permission to be actually granted for a document, it shall be allowed by each permission handler that is present

in the permissions dictionary as well as by the security handler.

NOTE

An example of a permission is the ability to fill in a form field.

Table 258 - Entries in a permissions dictionary

Key

Type

Value

DocMDP

dictionary

(Optional) An indirect reference to a signature dictionary (see Table 252).

This dictionary shall contain a Reference entry that shall be a signature

reference dictionary (see Table 252) that has a DocMDP transform method

(see 12.8.2.2, “DocMDP”) and corresponding transform parameters.

If this entry is present, consumer applications shall enforce the permissions

specified by the P attribute in the DocMDP transform parameters dictionary

and shall also validate the corresponding signature based on whether any of

these permissions have been violated.

UR3

dictionary

(Optional) A signature dictionary that shall be used to specify and validate

additional capabilities (usage rights) granted for this document; that is, the

enabling of interactive features of the conforming reader that are not

available by default.

For example, A conforming reader does not permit saving documents by

default, but an agent may grant permissions that enable saving specific

documents. The signature shall be used to validate that the permissions

have been granted by the agent that did the signing.

The signature dictionary shall contain a Reference entry that shall be a

signature reference dictionary that has a UR transform method

(see

12.8.2.3, “UR”). The transform parameter dictionary for this method indicates

which additional permissions shall be granted for the document. If the

signature is valid, the conforming reader shall allow the specified

permissions for the document, in addition to the application’s default

permissions.

12.8.5

Legal Content Attestations

The PDF language provides a number of capabilities that can make the rendered appearance of a PDF

document vary. These capabilities could potentially be used to construct a document that misleads the recipient

of a document, intentionally or unintentionally. These situations are relevant when considering the legal

implications of a signed PDF document.

Therefore, a mechanism shall be provided by which a document recipient can determine whether the document

can be trusted. The primary method is to accept only documents that contain certification signatures (one that

has a DocMDP signature that defines what shall be permitted to change in a document; see 12.8.2.2,

“DocMDP”).

When creating certification signatures, conforming writers should also create a legal attestation dictionary,

whose entries are shown in Table 259. This dictionary shall be the value of the Legal entry in the document

catalogue (see Table 28). Its entries shall specify all content that may result in unexpected rendering of the

document contents. The author may provide further clarification of such content by means of the Attestation

entry. Reviewers should establish for themselves that they trust the author and contents of the document. In the

case of a legal challenge to the document, any questionable content can be reviewed in the context of the

information in this dictionary.

477

Table 259 - Entries in a legal attestation dictionary

Key

Type

Value

JavaScriptActions

integer

(Optional) The number of JavaScript actions found in the document

(see 12.6.4.16, “JavaScript Actions”).

LaunchActions

integer

(Optional) The number of launch actions found in the document (see

12.6.4.5, “Launch Actions”).

URIActions

integer

(Optional) The number of URI actions found in the document (see

12.6.4.7, “URI Actions”).

MovieActions

integer

(Optional) The number of movie actions found in the document (see

12.6.4.9, “Movie Actions”).

SoundActions

integer

(Optional) The number of sound actions found in the document (see

12.6.4.8, “Sound Actions”).

HideAnnotationActions

integer

(Optional) The number of hide actions found in the document (see

12.6.4.10, “Hide Actions”).

GoToRemoteActions

integer

(Optional) The number of remote go-to actions found in the

document (see 12.6.4.3, “Remote Go-To Actions”).

AlternateImages

integer

(Optional) The number of alternate images found in the document

(see 8.9.5.4, “Alternate Images”)

ExternalStreams

integer

(Optional) The number of external streams found in the document.

TrueTypeFonts

integer

(Optional) The number of TrueType fonts found in the document (see

9.6.3, “TrueType Fonts”).

ExternalRefXobjects

integer

(Optional) The number of reference XObjects found in the document

(see 8.10.4, “Reference XObjects”).

ExternalOPIdicts

integer

(Optional) The number of OPI dictionaries found in the document

(see 14.11.7, “Open Prepress Interface (OPI)”).

NonEmbeddedFonts

integer

(Optional) The number of non-embedded fonts found in the

document (see 9.9, “Embedded Font Programs””)

DevDepGS_OP

integer

(Optional) The number of references to the graphics state parameter

OP found in the document (see Table 58).

DevDepGS_HT

integer

(Optional) The number of references to the graphics state parameter

HT found in the document (see Table 58).

DevDepGS_TR

integer

(Optional) The number of references to the graphics state parameter

TR found in the document (see Table 58).

DevDepGS_UCR

integer

(Optional) The number of references to the graphics state parameter

UCR found in the document (see Table 58).

DevDepGS_BG

integer

(Optional) The number of references to the graphics state parameter

BG found in the document (see Table 58).

DevDepGS_FL

integer

(Optional) The number of references to the graphics state parameter

FL found in the document (see Table 58).

Annotations

integer

(Optional) The number of annotations found in the document (see

12.5, “Annotations”).

OptionalContent

boolean

(Optional) true if optional content is found in the document (see 8.11,

“Optional Content”).

Attestation

text string

(Optional) An attestation, created by the author of the document,

explaining the presence of any of the other entries in this dictionary

or the presence of any other content affecting the legal integrity of the

document.

478

12.9

Measurement Properties

PDF documents, such as those created by CAD software, may contain graphics that are intended to represent

real-world objects. Users of such documents often require information about the scale and units of

measurement of the corresponding real-world objects and their relationship to units in PDF user space.

This information enables users of conforming readers to perform measurements that yield results in the units

intended by the creator of the document. A measurement in this context is the result of a canonical function that

takes as input a set of n coordinate pairs

{

(

x₀,y₀

),

…,(xn-1,yn-1

)}

and produces a single number as output depending on the type of measurement. For example, distance

measurement is equivalent to

n-2

+

(

y_i – y_i+1

)²

∑ (xi – xi + 1)²

i =0

for

n ≥ 2.

Beginning with PDF 1.6, such information may be stored in a measure dictionary (see Table 261). Measure

dictionaries provide information about measurement units associated with a rectangular area of the document

known as a viewport.

A viewport (PDF 1.6) is a rectangular region of a page. The optional VP entry in a page dictionary (see

Table 30) shall specify an array of viewport dictionaries, whose entries shall be as shown in Table 260.

Viewports allow different measurement scales (specified by the Measure entry) to be used in different areas of

a page, if necessary.

The dictionaries in the VP array shall be in drawing order. Since viewports might overlap, to determine the

viewport to use for any point on a page, the dictionaries in the array shall be examined, starting with the last

one and iterating in reverse, and the first one whose BBox entry contains the point shall be chosen.

NOTE 1

Any measurement that potentially involves multiple viewports, such as one specifying the distance between

two points, shall use the information specified in the viewport of the first point.

Table 260 - Entries in a viewport dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; shall be

Viewport for a viewport dictionary.

BBox

rectangle

(Required) A rectangle in default user space coordinates specifying the

location of the viewport on the page.

The two coordinate pairs of the rectangle shall be specified in normalized

form; that is, lower-left followed by upper-right, relative to the measuring

coordinate system. This ordering shall determine the orientation of the

measuring coordinate system (that is, the direction of the positive x and y

axes) in this viewport, which may have a different rotation from the page.

The coordinates of this rectangle are independent of the origin of the

measuring coordinate system, specified in the O entry (see Table 262) of the

measurement dictionary specified by Measure.

479

Table 260 - Entries in a viewport dictionary (continued)

Key

Type

Value

Name

text string

(Optional) A descriptive text string or title of the viewport, intended for use in

a user interface.

Measure

dictionary

(Optional) A measure dictionary (see Table 261) that specifies the scale and

units that shall apply to measurements taken on the contents within the

viewport.

A measure dictionary shall specify an alternate coordinate system for a region of a page. Along with the

viewport dictionary, it shall provide the information needed to convert coordinates in the page’s coordinate

system to coordinates in the measuring coordinate system. The measure dictionary shall provide information

for formatting the resulting values into textual form for presentation in a graphical user interface.

Table 261 shows the entries in a measure dictionary. PDF 1.6 defines only a single type of coordinate system,

a rectilinear coordinate system, that shall be specified by the value RL for the Subtype entry, which is defined

as one in which the x and y axes are perpendicular and have units that increment linearly (to the right and up,

respectively). Other subtypes may be used, providing the flexibility to measure using other types of coordinate

systems.

Table 261 - Entries in a measure dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; shall be

Measure for a measure dictionary.

Subtype

name

(Optional) A name specifying the type of coordinate system to use for

measuring.

Default value: RL, which specifies a rectilinear coordinate system

Table 262 shows the additional entries in a rectilinear measure dictionary. Many of the entries in this dictionary

shall be number format arrays, which are arrays of number format dictionaries (see Table 263). Each number

format dictionary shall represent a specific unit of measurement (such as miles or feet). It shall contain

information about how each unit shall be expressed in text and factors for calculating the number of units.

Number format arrays specify all the units that shall be used when expressing a specific measurement. Each

array shall contain one or more number format dictionaries, in descending order of granularity. If one unit of

measurement X is larger than one unit of measurement Y then X has a larger order of granularity than Y. All the

elements in the array shall contain text strings that, concatenated together, specify how the units shall be

displayed.

NOTE 2

For example, a measurement of 1.4505 miles might be expressed as “1.4505 mi”, which would require one

number format dictionary for miles, or as “1 mi 2,378 ft 7 5/8 in”, which would require three dictionaries (for

miles, feet, and inches).

EXAMPLE 1

A number format dictionary specifying feet should precede one specifying inches.

480

Table 262 - Additional entries in a rectilinear measure dictionary

Key

Type

Value

R

text string

(Required) A text string expressing the scale ratio of the drawing in the

region corresponding to this dictionary. Universally recognized unit

abbreviations should be used, either matching those of the number format

arrays in this dictionary or those of commonly used scale ratios.

EXAMPLE 1

a common scale in architectural drawings is “1/4 in = 1 ft”,

indicating that

1/4 inches in default user space is

equivalent to 1 foot in real-world measurements.

If the scale ratio differs in the x and y directions, both scales should be

specified.

EXAMPLE 2

“in X 1 cm = 1 m, in Y 1 cm = 30 m”.

X

array

(Required) A number format array for measurement of change along the x

axis and, if Y is not present, along the y axis as well. The first element in the

array shall contain the scale factor for converting from default user space

units to the largest units in the measuring coordinate system along that axis.

The directions of the x and y axes are in the measuring coordinate system

and are independent of the page rotation. These directions shall be

determined by the BBox entry of the containing viewport (see Table 260).

Y

array

(Required when the x and y scales have different units or conversion factors)

A number format array for measurement of change along the y axis. The first

element in the array shall contain the scale factor for converting from default

user space units to the largest units in the measuring coordinate system

along the y axis.

D

array

(Required) A number format array for measurement of distance in any

direction. The first element in the array shall specify the conversion to the

largest distance unit from units represented by the first element in X. The

scale factors from X, Y (if present) and CYX (if Y is present) shall be used to

convert from default user space to the appropriate units before applying the

distance function.

A

array

(Required) A number format array for measurement of area. The first

element in the array shall specify the conversion to the largest area unit from

units represented by the first element in X, squared. The scale factors from

X, Y (if present) and CYX (if Y is present) shall be used to convert from

default user space to the appropriate units before applying the area function.

T

array

(Optional) A number format array for measurement of angles. The first

element in the array shall specify the conversion to the largest angle unit

from degrees. The scale factor from CYX (if present) shall be used to convert

from default user space to the appropriate units before applying the angle

function.

S

array

(Optional) A number format array for measurement of the slope of a line. The

first element in the array shall specify the conversion to the largest slope unit

from units represented by the first element in Y divided by the first element in

X. The scale factors from X, Y (if present) and CYX (if Y is present) shall be

used to convert from default user space to the appropriate units before

applying the slope function.

O

array

(Optional) An array of two numbers that shall specify the origin of the

measurement coordinate system in default user space coordinates. The

directions by which x and y increase in value from this origin shall be

determined by the viewport’s BBox entry (see Table 260).

Default value: the first coordinate pair (lower-left corner) of the rectangle

specified by the viewport’s BBox entry.

481

Table 262 - Additional entries in a rectilinear measure dictionary (continued)

Key

Type

Value

CYX

number

(Optional; meaningful only when Y is present) A factor that shall be used to

convert the largest units along the y axis to the largest units along the x axis.

It shall be used for calculations (distance, area, and angle) where the units

are be equivalent; if not specified, these calculations may not be performed

(which would be the case in situations such as x representing time and y

representing temperature). Other calculations (change in x, change in y, and

slope) shall not require this value.

The X and Y entries in a measure dictionary shall be number format arrays that shall specify the units used for

measurements in the x and y directions, respectively, and the ratio between user space units and the specified

units. Y is present only when the x and y measurements are in different units or have different ratios; in this

case, the CYX entry shall be used to convert y values to x values when appropriate.

Table 263 - Entries in a number format dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; shall be

NumberFormat for a number format dictionary.

U

text string

(Required) A text string specifying a label for displaying the units represented

by this dictionary in a user interface; the label should use a universally

recognized abbreviation.

C

number

(Required) The conversion factor used to multiply a value in partial units of

the previous number format array element to obtain a value in the units of

this dictionary. When this entry is in the first number format dictionary in the

array, its meaning (that is, what it shall be multiplied by) depends on which

entry in the rectilinear measure dictionary (see Table 262) references the

number format array.

F

name

(Optional; meaningful only for the last dictionary in a number format array) A

name indicating whether and in what manner to display a fractional value

from the result of converting to the units of this dictionary by means of the C

entry. Valid values shall be:

D Show as decimal to the precision specified by the D entry.

F Show as a fraction with denominator specified by the D entry.

R No fractional part; round to the nearest whole unit.

T No fractional part; truncate to achieve whole units.

Default value: D.

D

integer

(Optional; meaningful only for the last dictionary in a number format array) A

positive integer that shall specify the precision or denominator of a fractional

amount:

When the value of F is D, this entry shall be the precision of a decimal

display; it shall be a multiple of 10. Low-order zeros may be truncated unless

FD is true. Default value: 100 (hundredths, corresponding to two decimal

digits).

When the value of F is F, this entry shall be the denominator of a fractional

display. The fraction may be reduced unless the value of FD is true. Default

value: 16.

FD

boolean

(Optional; meaningful only for the last dictionary in a number format array) If

true, a fractional value formatted according to the D entry may not have its

denominator reduced or low-order zeros truncated.

Default value: false.

482

Table 263 - Entries in a number format dictionary (continued)

Key

Type

Value

RT

text string

(Optional) Text that shall be used between orders of thousands in display of

numerical values. An empty string indicates that no text shall be added.

Default value: COMMA (2Ch).

RD

text string

(Optional) Text that shall be used as the decimal position in displaying

numerical values. An empty string indicates that the default shall be used.

Default value: PERIOD (2Eh).

PS

text string

(Optional) Text that shall be concatenated to the left of the label specified by

U. An empty string indicates that no text shall be added.

Default value: A single ASCII SPACE character (20h).

SS

text string

(Optional) Text that shall be concatenated after the label specified by U. An

empty string indicates that no text shall be added.

Default value: A single ASCII SPACE character (20h).

O

name

(Optional) A name indicating the position of the label specified by U with

respect to the calculated unit value. Valid values shall be:

S The label is a suffix to the value.

P The label is a prefix to the value.

The characters specified by PS and SS shall be concatenated before

considering this entry.

Default value: S.

To use a number format array to create a text string containing the appropriately formatted units for display in a

user interface, apply the following algorithm:

Algorithm: Use of a number format array to create a formatted text string

a) The entry in the rectilinear measure dictionary (see Table 262) that references the number format array

determines the meaning of the initial measurement value. For example, the X entry specifies user space

units, and the T entry specifies degrees.

b) Multiply the value specified previously by the C entry of the first number format dictionary in the array,

which converts the measurement to units of the largest granularity specified in the array. Apply the value of

RT as appropriate.

c) If the result contains no nonzero fractional portion, concatenate the label specified by the U entry in the

order specified by O, after adding spacing from PS and SS. The formatting is then complete.

d) If there is a nonzero fractional portion and no more elements in the array, format the fractional portion as

specified by the RD, F, D, and FD entries of the last dictionary. Concatenate the label specified by the U

entry in the order specified by O, after adding spacing from PS and SS. The formatting is then complete.

e) If there is a nonzero fractional portion and more elements in the array, proceed to the next number format

dictionary in the array. Multiply its C entry by the fractional result from the previous step. Apply the value of

RT as appropriate. Then proceed to step 3.

The concatenation of elements in this process assumes left-to-right order. Documents using right-to-left

languages may modify the process and the meaning of the entries as appropriate to produce the correct

results.

483

EXAMPLE 2

The following example shows a measure dictionary that specifies that changes in x or y are expressed in

miles; distances are expressed in miles, feet, and inches; and area is expressed in acres. Given a sample

distance in scaled units of 1.4505 miles, the formatted text produced by applying the number format array

would be

“1 mi 2,378 ft 7 5/8 in”.

<</Type /Measure

/Subtype /RL

/R (1in = 0.1 mi)

/X [ <</U (mi)

% x offset represented in miles

/C .00139

% Conversion from user space units to miles

/D 100000

]

/D [<< /U (mi) /C 1 >>

% Distance: initial unit is miles; no conversion needed

<< /U (ft) /C 5280 >>

% Conversion from miles to feet

<< /U (in) /C 12

% Conversion from feet to inches

/F /F /D 8 >>

% Fractions of inches rounded to nearest 1/8

]

/A [<</U (acres)

% Area: measured in acres

/C 640 >>

% Conversion from square miles to acres

]

>>

12.10

Document Requirements

12.10.1

General

Beginning with PDF 1.7, a document may specify requirements that shall be present in a conforming reader in

order for the document to function properly. The Requirements entry in the document catalogue (see 7.7.2,

“Document Catalog”) shall specify an array of requirement dictionaries, whose entries are shown in Table 264.

Table 264 - Entries common to all requirement dictionaries

Key

Type

Description

Type

name

(Optional) The type of PDF object that this dictionary

describes. If present, shall be Requirement for a

requirement dictionary.

S

name

(Required) The type of requirement that this dictionary

describes. The value shall be EnableJavaScripts.

RH

array

(Optional) An array of requirement handler dictionaries (see

Table 265). This array lists the requirement handlers that

shall be disabled (not executed) if the conforming reader can

check the requirement specified in the S entry.

The RH entry ensures backward-capability for this feature. Some PDF documents include JavaScript segments

that verify compliance with certain requirements. Such JavaScript segments are called requirement handlers.

Backward-compatibility shall be achieved by ensuring that either the conforming reader checks the requirement

or the JavaScript segment checks the requirement, but not both.

When a PDF document is first opened, all JavaScript segments in the document shall be executed, including

the requirement handlers. If the conforming reader understands the requirement dictionary, it shall disable

execution of the requirement handlers named by the RH entry. If the requirement handler is in JavaScript, the

conforming reader shall look up the segment using the Names dictionary (7.7.4, “Name Dictionary”).

In PDF 1.7, the only defined requirement type shall be EnableJavaScripts. This requirement indicates that the

document requires JavaScript execution to be enabled in the conforming reader. If the EnableJavaScripts

requirement is present, an interactive conforming reader may allow the user to choose between keeping

JavaScript execution disabled or temporarily enabling it to benefit from the full function of the document.

484

If the EnableJavaScripts requirement is present in a requirement dictionary, the inclusion of the RH entry that

specifies a JavaScript segment would be pointless. Writing a JavaScript segment to verify that JavaScript is

enabled would not achieve the desired goal. The RH entry shall not be used in PDF 1.7.

12.10.2

Requirement Handlers

A requirement handler is a program that verifies certain requirements are satisfied. Table 265 describes the

entries in a requirement handler dictionary.

Table 265 - Entries in a requirement handler dictionary

Key

Type

Description

Type

name

(Optional) The type of PDF object that this dictionary

describes. If present, shall be ReqHandler for a requirement

handler dictionary.

S

name

(Required) The type of requirement handler that this

dictionary describes. Valid requirement handler types shall be

JS (for a JavaScript requirement handlers) and NoOp.

A value of NoOp allows older conforming readers to ignore

unrecognized requirements. This value does not add any

specific entry to the requirement handler dictionary.

Script

text string

(Optional; valid only if the S entry has a value of JS) The

name of a document-level JavaScript action stored in the

document name dictionary (see 7.7.4, “Name Dictionary”). If

the conforming reader understands the parent requirement

dictionary and can verify the requirement specified in that

dictionary, it shall disable execution of the requirement

handler identified in this dictionary.

485

reader, it shall not affect the viability of the object. If a media criteria dictionary is present in both MH and BE,

the entries in both dictionaries shall be individually evaluated, with MH taking precedence (corresponding BE

entries shall be ignored).

Table 266 - Entries common to all rendition dictionaries

Key

Type

Value

Type

name

(Optional) The type of PDF object that dictionary describes; if present, shall

be Rendition for a rendition object.

S

name

(Required) The type of rendition that this dictionary describes. May be MR

for media rendition or SR for selector rendition. The rendition shall be

considered non-viable if the conforming reader does not recognize the value

of this entry.

N

text string

(Optional) A Unicode-encoded text string specifying the name of the

rendition for use in a user interface and for name tree lookup by JavaScript

actions.

MH

dictionary

(Optional) A dictionary whose entries (see Table 267) shall be honoured for

the rendition to be considered viable.

BE

dictionary

(Optional) A dictionary whose entries (see Table 267) shall only be honoured

in a “best effort” sense.

Table 267 - Entries in a rendition MH/BE dictionary

Key

Type

Value

C

dictionary

(Optional) A media criteria dictionary (see Table 268).

The media criteria dictionary behaves somewhat differently than other MH/

BE entries described in 13.2.2, “Viability.” The criteria specified by all of its

entries shall be met regardless of whether it is in an MH or a BE dictionary.

The only exception is that if an entry in a BE dictionary is unrecognized by

the conforming reader, it shall not affect the viability of the object.

Table 268 - Entries in a media criteria dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be MediaCriteria for a media criteria dictionary.

A

boolean

(Optional) If specified, the value of this entry shall match the user’s

preference for whether to hear audio descriptions in order for this object to

be viable.

NOTE 1

Equivalent to SMIL’s systemAudioDesc attribute.

C

boolean

(Optional) If specified, the value of this entry shall match the user’s

preference for whether to see text captions in order for this object to be

viable.

NOTE 2

Equivalent to SMIL’s systemCaptions attribute.

O

boolean

(Optional) If specified, the value of this entry shall match the user’s

preference for whether to hear audio overdubs in order for this object to be

viable.

S

boolean

(Optional) If specified, the value of this entry shall match the user’s

preference for whether to see subtitles in order for this object to be viable.

489

Table 268 - Entries in a media criteria dictionary (continued)

Key

Type

Value

R

integer

(Optional) If specified, the system’s bandwidth (in bits per second) shall be

greater than or equal to the value of this entry in order for this object to be

viable.

NOTE 3

Equivalent to SMIL’s systemBitrate attribute.

D

dictionary

(Optional) A dictionary (see Table 269) specifying the minimum bit depth

required in order for this object to be viable.

NOTE 4

Equivalent to SMIL’s systemScreenDepth attribute.

Z

dictionary

(Optional) A dictionary (see Table 270) specifying the minimum screen size

required in order for this object to be viable.

NOTE 5

Equivalent to SMIL’s systemScreenSize attribute.

V

array

(Optional) An array of software identifier objects (see 13.2.7.4, “Software

Identifier Dictionary”). If this entry is present and non-empty, the conforming

reader shall be identified by one or more of the objects in the array in order

for this object to be viable.

P

array

(Optional) An array containing one or two name objects specifying a

minimum and optionally a maximum PDF language version, in the same

format as the Version entry in the document catalog (see Table 28). If this

entry is present and non-empty, the version of multimedia constructs fully

supported by the conforming reader shall be within the specified range in

order for this object to be viable.

L

array

(Optional) An array of language identifiers

(see

14.9.2.2,

“Language

Identifiers”). If this entry is present and non-empty, the language in which the

conforming reader is running shall exactly match a language identifier, or

consist only of a primary code that matches the primary code of an identifier,

in order for this object to be viable.

NOTE 6

Equivalent to SMIL’s systemLanguage attribute.

Table 269 - Entries in a minimum bit depth dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be MinBitDepth for a minimum bit depth dictionary.

V

integer

(Required) A positive integer (0 or greater) specifying the minimum screen

depth (in bits) of the monitor for the rendition to be viable. A negative value

shall not be allowed.

M

integer

(Optional) A monitor specifier (see Table 270) that specifies which monitor

the value of V should be tested against. If the value is unrecognized, the

object shall not be viable.

Default value: 0.

490

Table 270 - Entries in a minimum screen size dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be MinScreenSize for a rendition object.

V

array

(Required) An array containing two non-negative integers. The width and

height (in pixels) of the monitor specified by M shall be greater than or equal

to the values of the first and second integers in the array, respectively, in

order for this object to be viable.

M

integer

(Optional) A monitor specifier (see Table 293) that specifies which monitor

the value of V should be tested against. If the value is unrecognized, the

object shall be not viable.

Default value: 0.

13.2.3.2

Media Renditions

Table 271 lists the entries in a media rendition dictionary. Its entries specify what media should be played (C),

how (P), and where (SP) it should be played. A media rendition object shall be viable if and only if the objects

referenced by its C, P, and SP entries are viable.

C may be omitted only in cases where a referenced player takes no meaningful input. This requires that P shall

be present and that its referenced media play parameters dictionary (see Table 279) shall contain a PL entry,

whose referenced media players dictionary (see 13.2.7.2, “Media Players Dictionary”) has a non-empty MU

array or a non-empty A array.

Table 271 - Additional entries in a media rendition dictionary

Key

Type

Value

C

dictionary

(Optional) A media clip dictionary (see 13.2.4, “Media Clip Objects”) that

specifies what should be played when the media rendition object is played.

P

dictionary

(Required if C is not present, otherwise optional) A media play parameters

dictionary (see 13.2.5, “Media Play Parameters””) that specifies how the

media rendition object should be played.

Default value: a media play parameters dictionary whose entries

(see

Table 279) all contain their default values.

SP

dictionary

(Optional) A media screen parameters dictionary (see 13.2.6, “Media Screen

Parameters”) that specifies where the media rendition object should be

played.

Default value: a media screen parameters dictionary whose entries (see

Table 282) all contain their default values.

13.2.3.3

Selector Renditions

A selector rendition dictionary shall specify an array of rendition objects in its R entry (see Table 272). The

renditions in this array should be ordered by preference, with the most preferred rendition first. At play-time, the

renditions in the array shall be evaluated and the first viable media rendition, if any, shall be played. If one of

the renditions is itself a selector, that selector shall be evaluated in turn, yielding the equivalent of a depth-first

tree search. A selector rendition itself may be non-viable; in this case, none of its associated media renditions

shall be evaluated (in effect, this branch of the tree is skipped).

NOTE

This mechanism may be used, for example, to specify that a large video clip should be used on high-

bandwidth machines and a smaller clip should be used on low-bandwidth machines.

491

Table 272 - Additional entries specific to a selector rendition dictionary

Key

Type

Value

R

array

(Required) An array of rendition objects. The first viable media rendition

object found in the array, or nested within a selector rendition in the array,

should be used. An empty array is legal.

13.2.4

Media Clip Objects

13.2.4.1

General

There are two types of media clip objects, determined by the subtype S, which can be either MCD for media

clip data (see 13.2.4.2, “Media Clip Data”) or MCS for media clip section (see 13.2.4.3, “Media Clip Section”).

The entries common to all media clip dictionaries are listed in Table 273.

Table 273 - Entries common to all media clip dictionaries

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be MediaClip for a media clip dictionary.

S

name

(Required) The subtype of media clip that this dictionary describes. May be

MCD for media clip data (see 13.2.4.2, “Media Clip Data”) or MCS for a

media clip section (see 13.2.4.3, “Media Clip Section”). The media clip shall

be considered non-viable if the conforming reader does not recognize the

value of this entry.

N

text string

(Optional) The name of the media clip, for use in the user interface.

13.2.4.2

Media Clip Data

A media clip data dictionary defines the data for a media object that can be played. Its entries are listed in

Table 274

NOTE 1

It may reference a URL to a streaming video presentation or a movie embedded in the PDF file.

Table 274 - Additional entries in a media clip data dictionary

Key

Type

Value

D

file

(Required) A full file specification or form XObject that specifies the actual

specification or

media data.

stream

CT

ASCII string

(Optional; not allowed for form XObjects) An ASCII string identifying the type

of data in D. The string should conform to the content type specification

described in Internet RFC

2045, Multipurpose Internet Mail Extensions

(MIME) Part One: Format of Internet Message Bodies

(see the

Bibliography).

P

dictionary

(Optional) A media permissions dictionary

(see Table 275) containing

permissions that control the use of the media data. Default value: a media

permissions dictionary containing default values.

Alt

array

(Optional) An array that provides alternate text descriptions for the media clip

data in case it cannot be played; see 14.9.2.4, “Multi-language Text Arrays.”

492

Table 274 - Additional entries in a media clip data dictionary (continued)

Key

Type

Value

PL

dictionary

(Optional) A media players dictionary

(see

13.2.7.2,

“Media Players

Dictionary”) that identifies, among other things, players that are legal and not

legal for playing the media.

If the media players dictionary is non-viable, the media clip data shall be

non-viable.

MH

dictionary

(Optional) A dictionary whose entries (see Table 276) shall be honoured for

the media clip data to be considered viable.

BE

dictionary

(Optional) A dictionary whose entries

(see Table 276) should only be

honoured in a “best effort” sense.

The media clip data object shall be considered non-viable if the object referenced by the D entry does not

contain a Type entry, the Type entry is unrecognized, or the referenced object is not a dictionary or stream.

This shall effectively exclude the use of simple file specifications (see 7.11, “File Specifications”).

If D references a file specification that has an embedded file stream (see 7.11.4, “Embedded File Streams”), the

embedded file stream’s Subtype entry shall be ignored if present, and the media clip data dictionary’s CT entry

shall identify the type of data.

If D references a form XObject, the associated player is implicitly the conforming reader, and the form XObject

shall be rendered as if it were any other data type.

NOTE 2

The F and D entries in the media play parameters dictionary (see Table 279) should apply to a form XObject

just as they do to a QuickTime movie.

For media other than form XObjects, the media clip object shall provide enough information to allow a

conforming reader to locate an appropriate player. This may be done by providing one or both of the following

entries, the first being the preferred method:

•

A CT entry that specifies the content type of the media. If this entry is present, any player that is selected

shall support this content type.

•

A PL entry that specifies one or more players that may be used to play the referenced media. if CT is

present, there should also be a PL present.

The P entry specifies a media permissions dictionary (see Table 275) specifying the manner in which the data

referenced by the media may be used by a conforming reader. These permissions allow authors control over

how their data is exposed to operations that could allow it to be copied. If the dictionary contains unrecognized

entries or entries with unrecognized values, it shall be considered non-viable, and the conforming reader shall

not play the media.

493

Table 275 - Entries in a media permissions dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be MediaPermissions for a media permissions dictionary.

TF

ASCII

(Optional) An ASCII string indicating the circumstances under which it is

string

acceptable to write a temporary file in order to play a media clip. Valid values

are:

(TEMPNEVER) Never allowed.

(TEMPEXTRACT) Allowed only if the document permissions allow content

extraction; when bit 5 of the user access permissions

(see Table 22) is set.

(TEMPACCESS) Allowed only if the document permissions allow content

extraction, including for accessibility purposes; when bits

5 or 10 of the user access permissions (see Table 22) are

set, or both.

(TEMPALWAYS) Always allowed.

Default value: (TEMPNEVER).

An unrecognized value shall be treated as (TEMPNEVER).

The BU entry in the media clip data MH and BE dictionaries (see Table 276) specifies a base URL for the

media data. Relative URLs in the media (which point to auxiliary files or are used for hyperlinking) should be

resolved with respect to the value of BU. The following are additional requirements concerning the BU entry:

•

If BU is in the MH dictionary and the base URL is not honoured the media clip data shall be non-viable.

NOTE 3

An example of this is that the player does not accept base URLs.

•

Determining the viability of the object shall not require checking whether the base URL is valid

NOTE 4

The target host exists.

•

Absolute URls within the media shall not be affected.

•

If the media itself contains a base URL, that value shall be used in preference to BU.

NOTE 5

An example of this is that the <BASE> element is defined in HTML.

•

BU is completely independent of and unrelated to the value of the URI entry in the document catalogue

(see 7.7.2, “Document Catalog”).

•

If BU is not present and the media is embedded within the document, the URL to the PDF file itself shall be

used as if it were the value of a BU entry in the BE dictionary; that is, as an implicit best-effort base URL.

Table 276 - Entries in a media clip data MH/BE dictionary

Key

Type

Value

BU

ASCII

(Optional) An absolute URL that shall be used as the base URL in resolving

string

any relative URLs found within the media data.

13.2.4.3

Media Clip Section

A media clip section dictionary (see Table 277) defines a continuous section of another media clip object

(known as the next-level media clip object). The next-level media clip object, specified by the D entry, may be

either a media clip data object or another media clip section object. However, the linked list formed by the D

494

entries of media clip sections shall terminate in a media clip data object. If the next-level media object is non-

viable, the media clip section shall be also non-viable.

NOTE 1

A media clip section could define a 15-minute segment of a media clip data object representing a two-hour

movie.

Table 277 - Additional entries in a media clip section dictionary

Key

Type

Value

D

dictionary

(Required) The media clip section or media clip data object (the next-level

media object) of which this media clip section object defines a continuous

section.

Alt

array

(Optional) An array that provides alternate text descriptions for the media clip

section in case it cannot be played; see 14.9.2.4, “Multi-language Text

Arrays.”

MH

dictionary

(Optional) A dictionary whose entries (see Table 278) shall be honoured for

the media clip section to be considered viable.

BE

dictionary

(Optional) A dictionary whose entries (see Table 278) shall only be honoured

in a “best effort” sense.

The B and E entries in the media clip section’s MH and BE dictionaries (see Table 278) shall define a

subsection of the next-level media object referenced by D by specifying beginning and ending offsets into it.

Depending on the media type, the offsets may be specified by time, frames, or markers (see 13.2.6.2, “Media

Offset Dictionary”). B and E are not required to specify the same type of offset.

The following rules apply to these offsets:

•

For media types where an offset makes no sense (such as JPEG images), B and E shall be ignored, with

no effect on viability.

•

When B or E are specified by time or frames, their value shall be considered to be relative to the start of

the next-level media clip. However, if E specifies an offset beyond the end of the next-level media clip, the

end value shall be used instead, and there is no effect on viability.

•

When B or E are specified by markers, there shall be a corresponding absolute offset into the underlying

media clip data object. If this offset is not within the range defined by the next-level media clip (if any), or if

the marker is not present in the underlying media clip, the existence of the entry shall be ignored, and there

is no effect on viability.

•

If the absolute offset derived from the values of all B entries in a media clip section chain is greater than or

equal to the absolute offset derived from the values of all E entries, an empty range shall be defined. An

empty range is legal.

•

Any B or E entry in a media clip section’s MH dictionary shall be honoured at play-time in order for the

media clip section to be considered viable.

NOTE 2

The entry may not be honored if its value was not viable or if the player did not support its value; for example,

the player did not support markers.

•

If a B or E entry is in a media clip section’s MH dictionary, all B or E entries, respectively, at deeper levels

(closer to the media clip data), shall be evaluated as if they were in an MH dictionary (even if they are

actually within BE dictionaries).

•

If B or E entry in a BE dictionary cannot be supported, it may be ignored at play-time.

495

Table 278 - Entries in a media clip section MH/BE dictionary

Key

Type

Value

B

dictionary

(Optional) A media offset dictionary (see 13.2.6.2, “Media Offset Dictionary”)

that specifies the offset into the next-level media object at which the media

clip section begins. Default: the start of the next-level media object.

E

dictionary

(Optional) A media offset dictionary (see 13.2.6.2, “Media Offset Dictionary”)

that specifies the offset into the next-level media object at which the media

clip section ends. Default: the end of the next-level media object.

13.2.5

Media Play Parameters

A media play parameters dictionary specifies how a media object should be played. It shall be referenced from

a media rendition (see 13.2.3.2, “Media Renditions”).

Table 279 - Entries in a media play parameters dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be MediaPlayParams for a media play parameters dictionary.

PL

dictionary

(Optional) A media players dictionary

(see

13.2.7.2,

“Media Players

Dictionary”) that identifies, among other things, players that are legal and not

legal for playing the media.

If this object is non-viable, the media play parameters dictionary shall be

considered non-viable.

MH

dictionary

(Optional) A dictionary whose entries (see Table 278) shall be honoured for

the media play parameters to be considered viable.

BE

dictionary

(Optional) A dictionary whose entries (see Table 278) shall only be honoured

in a “best effort” sense.

Table 280 - Entries in a media play parameters MH/BE dictionary

Key

Type

Value

V

integer

(Optional) An integer that specifies the desired volume level as a percentage

of recorded volume level. A zero value shall be equivalent to mute; negative

values shall be illegal. Default value: 100.

C

boolean

(Optional) A flag specifying whether to display a player-specific controller

user interface when playing.

EXAMPLE

play/pause/stop controls.

Default value: false

496

Table 280 - Entries in a media play parameters MH/BE dictionary (continued)

Key

Type

Value

F

integer‘

(Optional) The manner in which the player shall treat a visual media type that

does not exactly fit the rectangle in which it plays.

0The media’s width and height shall be scaled while preserving the aspect

ratio so that the media and play rectangles have the greatest possible

intersection while still displaying all media content.

NOTE 1

Same as “meet” value of SMIL’s fit attribute.

1

The media’s width and height shall be scaled while preserving the aspect

ratio so that the play rectangle is entirely filled, and the amount of media

content that does not fit within the play rectangle shall be minimized.

NOTE 2

Same as “slice” value of SMIL’s fit attribute.

2

The media’s width and height shall be scaled independently so that the

media and play rectangles are the same; the aspect ratio shall not be

preserved.

NOTE 3

Same as “fill” value of SMIL’s fit attribute.

3

The media shall not be scaled. A scrolling user interface shall be

provided if the media rectangle is wider or taller than the play rectangle.

NOTE 4

Same as “scroll” value of SMIL’s fit attribute.

4

The media shall not be scaled. Only the portions of the media rectangle

that intersect the play rectangle shall be displayed.

NOTE 5

Same as “hidden” value of SMIL’s fit attribute.

5

Use the player’s default setting (author has no preference).

Default value: 5.

An unrecognized value shall be treated as the default value if the entry is in a

BE dictionary. If the entry is in an MH dictionary and it has an unrecognized

value, the object shall be considered non-viable.

D

dictionary

(Optional) A media duration dictionary (see Table 281). Default value: a

dictionary specifying the intrinsic duration (see RC).

A

boolean

(Optional) If true, the media shall automatically play when activated. If false,

the media shall be initially paused when activated.

EXAMPLE

The first frame is displayed.

Relevant only for media that may be paused. Default value: true.

RC

number

(Optional) Specifies the number of iterations of the duration D to repeat.

NOTE 6

Similar to SMIL’s repeatCount attribute. Zero means repeat

forever. Negative values shall be illegal; non-integral values

shall be legal.

Default value: 1.0.

The value of the D entry is a media duration dictionary, whose entries are shown in Table 281. It specifies a

temporal duration.

NOTE 1

The D entry dictionary temporal duration corresponds to the notion of a simple duration in SMIL.

The duration may be a specific amount of time, it may be infinity, or it may be the media’s intrinsic duration.

EXAMPLE

The intrinsic duration of a two-hour QuickTime movie is two hours.

497

The intrinsic duration may be modified when a media clip section (see 13.2.4.3, “Media Clip Section”) is used:

the intrinsic duration shall be the difference between the absolute begin and end offsets. For a media type

having no notion of time (such as a JPEG image), the duration shall be considered to be infinity.

If the simple duration is longer than the intrinsic duration, the player shall freeze the media in its final state until

the simple duration has elapsed. For visual media types, the last appearance (frame) shall be displayed. For

aural media types, the media is logically frozen but shall not continue to produce sound.

NOTE 2

In this case, the RC entry, which specifies a repeat count, applies to the simple duration; therefore, the entire

play-pause sequence is repeated RC times.

Table 281 - Entries in a media duration dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be MediaDuration for a media duration dictionary.

S

name

(Required) The subtype of media duration dictionary. Valid values are:

I

The duration is the intrinsic duration of the associated media

F The duration is infinity

T The duration shall be specified by the T entry

The media duration dictionary shall be considered non-viable if the

conforming reader does not recognize the value of this entry.

T

dictionary

(Required if the value of S is T; otherwise ignored) A timespan dictionary

specifying an explicit duration (see Table 289). A negative duration is illegal.

13.2.6

Media Screen Parameters

13.2.6.1

General

A media screen parameters dictionary (see Table 282) shall specify where a media object should be played. It

shall contain MH and BE dictionaries (see Table 283), which shall function as discussed in 13.2.2, “Viability.” All

media clips that are being played shall be associated with a particular document and shall be stopped when the

document is closed.

NOTE

Conforming readers should disallow floating windows and full-screen windows unless specifically allowed by

the user. The reason is that document-based security attacks are possible if windows containing arbitrary

media content can be displayed without indicating to the user that the window is merely hosting a media

object. This recommendation may be relaxed if it is possible to communicate the nature of such windows to the

user; for example, with text in a floating window’s title bar.

Table 282 - Entries in a media screen parameters dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be MediaScreenParams for a media screen parameters dictionary.

MH

dictionary

(Optional) A dictionary whose entries (see Table 283) shall be honoured for

the media screen parameters to be considered viable.

BE

dictionary

(Optional) A dictionary whose entries (see Table 283) should be honoured.

498

Table 283 - Entries in a media screen parameters MH/BE dictionary

Key

Type

Value

W

integer

(Optional) The type of window that the media object shall play in:

0

A floating window

1

A full-screen window that obscures all other windows

2

A hidden window

3

The rectangle occupied by the screen annotation

(see

12.5.6.18,

“Screen Annotations”) associated with the media rendition

Default value: 3. Unrecognized value in MH: object is non-viable; in BE: treat

as default value.

B

array

(Optional) An array of three numbers in the range 0.0 to 1.0 that shall specify

the components in the DeviceRGB colour space of the background colour

for the rectangle in which the media is being played. This colour shall be

used if the media object does not entirely cover the rectangle or if it has

transparent sections. It shall be ignored for hidden windows.

Default value: implementation-defined. The conforming reader should

choose a reasonable value based on the value of W.

EXAMPLE 1

A system default background colour for floating windows

or a user-preferred background colour for full-screen

windows.

If a media format has an intrinsic background colour, B shall not override it.

However, the B colour shall be visible if the media has transparent areas or

otherwise does not cover the entire window.

O

number

(Optional) A number in the range 0.0 to 1.0 specifying the constant opacity

value that shall be used in painting the background colour specified by B. A

value below 1.0 means the window shall be transparent.

EXAMPLE 2

Windows behind a floating window show through if the

media does not cover the entire floating window.

A value of 0.0 shall indicate full transparency and shall make B irrelevant. It

shall be ignored for full-screen and hidden windows.

Default value: 1.0 (fully opaque).

M

integer

(Optional) A monitor specifier

(see Table 293) that shall specify which

monitor in a multi-monitor system, a floating or full-screen window shall

appear on. Ignored for other types.

Default value: 0 (document monitor). Unrecognized value in MH: object is

non-viable; in BE: treat as default value.

F

dictionary

(Required if the value of W is 0; otherwise ignored) A floating window

parameters dictionary (see Table 284) that shall specify the size, position,

and options used in displaying floating windows.

The F entry in the media screen parameters MH/BE dictionaries shall be a floating window parameters

dictionary, whose entries are listed in Table 284. The entries in the floating window parameters dictionary shall

be treated as if they were present in the MH or BE dictionaries that they are referenced from. That is, the

contained entries shall be individually evaluated for viability rather than the dictionary being evaluated as a

whole. (There may be an F entry in both MH and BE. In such a case, if a given entry is present in both floating

window parameters dictionaries, the one in the MH dictionary shall take precedence.)

The D, P, and RT entries shall be used to specify the rectangle that the floating window occupies. Once

created, the floating window’s size and position shall not be tied to any other window, even if the initial size or

position was computed relative to other windows.

Unrecognized values for the R, P, RT, and O entries shall be handled as follows: if they are nested within an

MH dictionary, the floating window parameters object (and hence the media screen parameters object) shall be

499

considered non-viable; if they are nested within a BE dictionary, they shall be considered to have their default

values.

Table 284 - Entries in a floating window parameters dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be FWParams for a floating window parameters dictionary.

D

array

(Required) An array containing two non-negative integers that shall

represent the floating window’s width and height, in pixels, respectively.

These values shall correspond to the dimensions of the rectangle in which

the media shall play, not including such items as title bar and resizing

handles.

RT

integer

(Optional) The window relative to which the floating window shall be

positioned:

0

The document window

1

The application window

2

The full virtual desktop

3

The monitor specified by M in the media screen parameters MH or BE

dictionary (see 9.22)

Default value: 0.

P

integer

(Optional) The location where the floating window (including such items as

title bar and resizing handles) shall be positioned relative to the window

specified by RT:

0

Upper-left corner

1

Upper center

2

Upper-right corner

3

Center left

4

Center

5

Center right

6

Lower-left corner

7

Lower center

8

Lower-right corner

Default value: 4.

O

integer

(Optional) Specifies what shall occur if the floating window is positioned

totally or partially offscreen (that is, not visible on any physical monitor):

0

Take no special action

1

Move and/or resize the window so that it is on-screen

2

Consider the object to be non-viable

Default value: 1

T

boolean

(Optional) If true, the floating window shall have a title bar. Default value:

true.

UC

boolean

(Optional; meaningful only if T is true) If true, the floating window shall

include user interface elements that allow a user to close a floating window.

Default value: true

R

integer

(Optional) Specifies whether the floating window may be resized by a user:

0

May not be resized

1

May be resized only if aspect ratio is preserved

2

May be resized without preserving aspect ratio

Default value: 0.

500

Table 284 - Entries in a floating window parameters dictionary (continued)

Key

Type

Value

TT

array

(Optional; meaningful only if T is true) An array providing text to display on

the floating window’s title bar. See 14.9.2.4, “Multi-language Text Arrays.” If

this entry is not present, the conforming reader may provide default text.

13.2.6.2

Media Offset Dictionary

A media offset dictionary (Table 285) shall specify an offset into a media object. The S (subtype) entry indicates

how the offset shall be specified: in terms of time, frames or markers. Different media types support different

types of offsets.

EXAMPLE

Time, “10 seconds”; frames, “frame 20”; markers, “Chapter One.”

Table 285 - Entries common to all media offset dictionaries

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be MediaOffset for a media offset dictionary.

S

name

(Required) The subtype of media offset dictionary. Valid values shall be:

T A media offset time dictionary (see Table 286)

F A media offset frame dictionary (see Table 287)

M A media offset marker dictionary (see Table 288)

The rendition shall be considered non-viable if the conforming reader does

not recognize the value of this entry.

Table 286 - Additional entries in a media offset time dictionary

Key

Type

Value

T

dictionary

(Required) A timespan dictionary

(see Table 289) that shall specify a

temporal offset into a media object. Negative timespans are not allowed in

this context. The media offset time dictionary is non-viable if its timespan

dictionary is non-viable.

Table 287 - Additional entries in a media offset frame dictionary

Key

Type

Value

F

integer

(Required) Shall specify a frame within a media object. Frame numbers

begin at 0; negative frame numbers are not allowed.

Table 288 - Additional entries in a media offset marker dictionary

Key

Type

Value

M

text string

(Required) A text string that identifies a named offset within a media object.

501

13.2.6.3

Timespan Dictionary

A timespan dictionary shall specify a length of time; its entries are shown in Table 289.

Table 289 - Entries in a timespan dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be Timespan for a timespan dictionary.

S

name

(Required) The subtype of timespan dictionary. The value shall be S (simple

timespan). The rendition shall be considered non-viable if the conforming

reader does not recognize the value of this entry.

V

number

(Required) The number of seconds in the timespan. Non-integral values

shall be allowed. Negative values shall be allowed, but may be disallowed in

some contexts.

(PDF 1.5) Negative values are not allowed.

This entry shall be used only if the value of the S entry is S. Subtypes

defined in the future need not use this entry.

13.2.7

Other Multimedia Objects

13.2.7.1

General

This sub-clause defines several dictionary types that are referenced by the previous sub-clauses.

13.2.7.2

Media Players Dictionary

A media players dictionary may be referenced by media clip data (see 13.2.4.2, “Media Clip Data”) and media

play parameters (see 13.2.5, “Media Play Parameters”) dictionaries, and shall allow them to specify which

players may or may not be used to play the associated media. The media players dictionary references media

player info dictionaries (see 13.2.7.3, “Media Player Info Dictionary”) that shall provide specific information

about each player.

Table 290 - Entries in a media players dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be MediaPlayers for a media players dictionary.

MU

array

(Optional) An array of media player info dictionaries (see Table 291) that

shall specify a set of players, one of which shall be used in playing the

associated media object.

Any players specified in NU are effectively removed from MU.

EXAMPLE

If MU specifies versions 1 through 5 of a player and NU

specifies versions 1 and 2 of the same player, MU is

effectively versions 3 through 5.

A

array

(Optional) An array of media player info dictionaries (see Table 291) that

shall specify a set of players, any of which may be used in playing the

associated media object. If MU is also present and non-empty, A shall be

ignored.

NU

array

(Optional) An array of media player info dictionaries (see Table 291) that

shall specify a set of players that shall not be used in playing the associated

media object (even if they are also specified in MU).

502

The MU, A, and NU entries each shall specify one or more media player info dictionaries. An empty array shall

be treated as if it is not present. The media player info dictionaries shall be allowed to specify overlapping

player ranges.

NOTE 1

MU could contain a media player info dictionary describing versions 1 to 10 of Player X and another describing

versions 3 through 5 of Player X.

If a non-viable media player info dictionary is referenced by MU, NU, or A, it shall be treated as if it were not

present in its original array, and a media player info dictionary containing the same software identifier dictionary

(see 13.2.7.4, “Software Identifier Dictionary”) shall logically considered present in NU. The same rule shall

apply to a media player info dictionary that contains a partially unrecognized software identifier dictionary.

Since both media clip data and media play parameters dictionaries may be employed in a play operation, and

each may reference a media players dictionary, there is a potential for conflict between the contents of the two

media players dictionaries. At play-time, the viewer shall use the following algorithm to determine whether a

player present on the machine may be employed. The player may not be used if any of the following conditions

are true:

Algorithm: Media Player

a) The content type is known and the player does not support the type.

b) The player is found in the NU array of either dictionary.

c) Both dictionaries have non-empty MU arrays and the player is not found in both of them, or only one of the

dictionaries has a non-empty MU array and the player is not found in it.

d) Neither dictionary has a non-empty MU array, the content type is not known, and the player is not found in

the A array of either dictionary.

If none of the conditions are true, the player may be used.

NOTE 2

A player is “found” in the NU, MU, or A arrays if it matches the information found in the PID entry of one of the

entries, as described by the Algorithm in 13.2.7.4, “Software Identifier Dictionary.”

13.2.7.3

Media Player Info Dictionary

A media player info dictionary shall provide a variety of information regarding a specific media player. Its entries

(see Table 291) shall associate information with a particular version or range of versions of a player. As of PDF

1.5, only the PID entry shall provide information about the player, as described in the next sub-clause, 13.2.7.4,

“Software Identifier Dictionary.”

Table 291 - Entries in a media player info dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be MediaPlayerInfo for a media player info dictionary.

PID

dictionary

(Required) A software identifier dictionary (see 13.2.7.4, “Software Identifier

Dictionary”) that shall specify the player name, versions, and operating

systems to which this media player info dictionary applies.

MH

dictionary

(Optional) A dictionary containing entries that shall be honored for this

dictionary to be considered viable

Currently, there are no defined entries for this dictionary

BE

dictionary

(Optional) A dictionary containing entries that need only be honored in a

“best effort” sense.

Currently, there are no defined entries for this dictionary

503

13.2.7.4

Software Identifier Dictionary

13.2.7.4.1

General

A software identifier dictionary shall allow software to be identified by name, range of versions, and operating

systems; its entries are listed in Table 292. A conforming reader uses this information to determine whether a

given media player may be used in a given situation. If the dictionary contains keys that are unrecognized by

the conforming reader, it shall be considered to be partially recognized. The conforming reader may or may not

decide to treat the software identifier as viable, depending on the context in which it is used.

The following procedure shall be used to determine whether a piece of software is considered to match a

software identifier dictionary:

Algorithm: Software identifier

a)

The software name shall match the name specified by the U entry (see “Software URIs” in 13.2.7.4,

“Software Identifier Dictionary”).

b)

The software version shall be within the interval specified by the L, H, LI, and H1 entries (see “Version

arrays” in 13.2.7.4, “Software Identifier Dictionary”).

c)

The machine’s operating system name shall be an exact match for one present in the OS array. If the array

is not present or empty, a match shall also be considered to exist.

Table 292 - Entries in a software identifier dictionary

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be SoftwareIdentifier for a software identifier dictionary.

U

ASCII string

(Required) A URI that identifies a piece of software (see “Software URIs” in

13.2.7.4, “Software Identifier Dictionary”).

L

array

(Optional) The lower bound of the range of software versions that this

software identifier dictionary specifies

(see “Version arrays” in 13.2.7.4,

“Software Identifier Dictionary”). Default value: the array [0].

LI

boolean

(Optional) If true, the lower bound of the interval defined by L and H is

inclusive; that is, the software version shall be greater than or equal to L (see

“Version arrays” in 13.2.7.4, “Software Identifier Dictionary”). If false, it shall

not be inclusive. Default value: true.

H

array

(Optional) The upper bound of the range of software versions that this

software identifier dictionary specifies

(see “Version arrays” in 13.2.7.4,

“Software Identifier Dictionary”). Default value: an empty array [].

HI

boolean

(Optional) If true, the upper bound of the interval defined by L and H is

inclusive; that is, the software version shall be less than or equal to H (see

“Version arrays” in 13.2.7.4, “Software Identifier Dictionary”). If false, it shall

not be inclusive. Default value: true.

OS

array

(Optional) An array of byte strings representing operating system identifiers

that shall indicate to which operating systems this object applies. The

defined values are the same as those defined for SMIL

2.0’s

systemOperatingSystem attribute. There may not be multiple copies of the

same identifier in the array. An empty array shall be considered to represent

all operating systems. Default value: an empty array.

504

Table 293 - Monitor specifier values

Value

Description

0

The monitor containing the largest section of the document window

1

The monitor containing the smallest section of the document window

2

Primary monitor. If no monitor is considered primary, shall treat as

case 0

3

Monitor with the greatest colour depth

4

Monitor with the greatest area (in pixels squared)

5

Monitor with the greatest height (in pixels)

6

Monitor with the greatest width (in pixels)

For some of these values, it is possible have a “tie” at play-time; for example, two monitors might have the

same colour depth. Ties may be broken in an implementation-dependent manner.

13.3

Sounds

A sound object (PDF 1.2) shall be a stream containing sample values that define a sound to be played through

the computer’s speakers. The Sound entry in a sound annotation or sound action dictionary (see Table 185

and Table 208) shall identify a sound object representing the sound to be played when the annotation is

activated.

Since a sound object is a stream, it may contain any of the standard entries common to all streams, as

described in Table 5. In particular, if it contains an F (file specification) entry, the sound shall be defined in an

external file. This sound file shall be self-describing, containing all information needed to render the sound; no

additional information need be present in the PDF file.

NOTE

The AIFF, AIFF-C (Mac OS), RIFF (. wav), and snd (. au) file formats are all self-describing.

If no F entry is present, the sound object itself shall contain the sample data and all other information needed to

define the sound. Table 294 shows the additional dictionary entries specific to a sound object.

Table 294 - Additional entries specific to a sound object

Key

Type

Value

Type

name

(Optional) The type of PDF object that this dictionary describes; if present,

shall be Sound for a sound object.

R

number

(Required) The sampling rate, in samples per second.

C

integer

(Optional) The number of sound channels. Default value: 1.

B

integer

(Optional) The number of bits per sample value per channel. Default value: 8.

E

name

(Optional) The encoding format for the sample data:

Raw Unspecified or unsigned values in the range 0 to 2B − 1

Signed Twos-complement values

muLaw m-law-encoded samples

ALaw A-law-encoded samples

Default value: Raw.

506

Table 294 - Additional entries specific to a sound object (continued)

Key

Type

Value

CO

name

(Optional) The sound compression format used on the sample data. (This is

separate from any stream compression specified by the sound object’s Filter

entry; see Table 5 and

7.4,

“Filters.”) If this entry is absent, sound

compression shall not be used; the data contains sampled waveforms that

shall be played at R samples per second per channel.

CP

(various)

(Optional) Optional parameters specific to the sound compression format

used.

No standard values have been defined for the CO and CP entries.

Sample values shall be stored in the stream with the most significant bits first (big-endian order for samples

larger than 8 bits). Samples that are not a multiple of 8 bits shall be packed into consecutive bytes, starting at

the most significant end. If a sample extends across a byte boundary, the most significant bits shall be placed in

the first byte, followed by less significant bits in subsequent bytes. For dual-channel stereophonic sounds, the

samples shall be stored in an interleaved format, with each sample value for the left channel (channel 1)

preceding the corresponding sample for the right (channel 2).

To maximize the portability of PDF documents containing embedded sounds, conforming readers should

support at least the following formats (assuming the platform has sufficient hardware and OS support to play

sounds at all):

R

8000, 11,025, or 22,050 samples per second

C

1 or 2 channels

B

8 or 16 bits per channel

E Raw, Signed, or muLaw encoding

If the encoding (E) is Raw or Signed, R shall be 11,025 or 22,050 samples per channel. If the encoding is

muLaw, R shall be 8000 samples per channel, C shall be 1 channel, and B shall be 8 bits per channel. Sound

players shall convert between formats, downsample rates, and combine channels as necessary to render

sound on the target platform.

13.4

Movies

The features described in this sub-clause are obsolescent and their use is no longer recommended. They are

superseded by the general multimedia framework described in 13.2, “Multimedia.”

PDF shall embed movies within a document by means of movie annotations (see 12.5.6.17, “Movie

Annotations”). Despite the name, a movie may consist entirely of sound with no visible images to be displayed

on the screen. The Movie and A (activation) entries in the movie annotation dictionary shall refer, respectively,

to a movie dictionary (Table 295) that shall describe the static characteristics of the movie and a movie

activation dictionary (Table 296) that shall specify how it shall be presented.

507

Table 295 - Entries in a movie dictionary

Key

Type

Value

F

file specification

(Required) A file specification identifying a self-describing movie file.

NOTE

The format of a self-describing movie file shall be left

unspecified, and there is no guarantee of portability.

Aspect

array

(Optional) The width and height of the movie’s bounding box, in pixels,

and shall be specified as [ width height ]. This entry should be omitted

for a movie consisting entirely of sound with no visible images.

Rotate

integer

(Optional) The number of degrees by which the movie shall be rotated

clockwise relative to the page. The value shall be a multiple of 90.

Default value: 0.

Poster

boolean or stream

(Optional) A flag or stream specifying whether and how a poster image

representing the movie shall be displayed. If this value is a stream, it

shall contain an image XObject (see 8.9, “Images”) to be displayed as

the poster. If it is the boolean value true, the poster image shall be

retrieved from the movie file; if it is false, no poster shall be displayed.

Default value: false.

Table 296 - Entries in a movie activation dictionary

Key

Type

Value

Start

(various)

(Optional) The starting time of the movie segment to be played. Movie

time values shall be expressed in units of time based on a time scale,

which defines the number of units per second. The default time scale

shall be defined in the movie data. The starting time shall be nominally

a non-negative 64-bit integer, specified as follows:

•

If it is representable as an integer (subject to the implementation

limit for integers, as described in Annex C), it shall be specified as

such.

•

If it is not representable as an integer, it shall be specified as an

8-byte string representing a 64-bit twos-complement integer, most

significant byte first.

•

If it is expressed in a time scale different from that of the movie

itself, it shall be represented as an array of two values: an integer

or byte string denoting the starting time, followed by an integer

specifying the time scale in units per second.

If this entry is omitted, the movie shall be played from the beginning.

Duration

(various)

(Optional) The duration of the movie segment to be played, that shall

be specified in the same form as Start. If this entry is omitted, the

movie shall be played to the end.

Rate

number

(Optional) The initial speed at which to play the movie. If the value of

this entry is negative, the movie shall be played backward with respect

to Start and Duration. Default value: 1.0.

Volume

number

(Optional) The initial sound volume at which to play the movie, in the

range −1.0 to 1.0. Higher values shall denote greater volume; negative

values shall mute the sound. Default value: 1.0.

ShowControls

boolean

(Optional) A flag specifying whether to display a movie controller bar

while playing the movie. Default value: false.

508

Table 296 - Entries in a movie activation dictionary (continued)

Key

Type

Value

Mode

name

(Optional) The play mode for playing the movie:

Once

Play once and stop.

Open

Play and leave the movie controller bar open.

Repeat

Play repeatedly from beginning to end until stopped.

Palindrome Play continuously forward and backward until stopped.

Default value: Once.

Synchronous

boolean

(Optional) A flag specifying whether to play the movie synchronously

or asynchronously. If this value is true, the movie player shall retain

control until the movie is completed or dismissed by the user. If the

value is false, the player shall return control to the conforming reader

immediately after starting the movie. Default value: false.

FWScale

array

(Optional) The magnification (zoom) factor at which the movie shall be

played. The presence of this entry implies that the movie shall be

played in a floating window. If the entry is absent, the movie shall be

played in the annotation rectangle.

The value of the entry shall be an array of two positive integers,

[numerator denominator ], denoting a rational magnification factor for

the movie. The final window size, in pixels, shall be

(numerator ÷ denominator) × Aspect

where the value of Aspect shall be taken from the movie dictionary

(see Table 295).

FWPosition

array

(Optional) For floating play windows, the relative position of the

window on the screen. The value shall be an array of two numbers

[horiz vert ]

each in the range 0.0 to 1.0, denoting the relative horizontal and

vertical position of the movie window with respect to the screen.

EXAMPLE

The value [ 0.5 0.5 ] centers the window on the

screen.

Default value: [ 0.5

0.5 ].

13.5

Alternate Presentations

Beginning with PDF 1.4, a PDF document shall contain alternate presentations, which specify alternate ways in

which the document may be viewed. The optional AlternatePresentations entry (PDF 1.4) in a document’s

name dictionary (see Table 31) contains a name tree that maps name strings to the alternate presentations

available for the document.

NOTE 1

Since conforming readers are not required to support alternate presentations, authors of documents containing

alternate presentations should define the files such that something useful and meaningful can be displayed

and printed. For example, if the document contains an alternate presentation slideshow of a sequence of

photographs, the photographs should be viewable in a static form by viewers that are not capable of playing

the slideshow.

As of PDF 1.5, the only type of alternate presentation is a slideshow. Slideshows may be invoked by means of

JavaScript actions (see 12.6.4.16, “JavaScript Actions”) initiated by user action on an interactive form element

(see 12.7, “Interactive Forms”).

The following table shows the entries in a slideshow dictionary.

509

Table 297 - Entries in a slideshow dictionary

Key

Type

Value

Type

name

(Required; PDF 1.4) The type of PDF object that this dictionary describes;

shall be SlideShow for a slideshow dictionary.

Subtype

name

(Required; PDF 1.4) The subtype of the PDF object that this dictionary

describes; shall be Embedded for a slideshow dictionary.

Resources

name

(Required; PDF 1.4) A name tree that maps name strings to objects

tree

referenced by the alternate presentation.

NOTE

Even though PDF treats the strings in the name tree as strings

without a specified encoding, the slideshow shall interpret

them as UTF-8 encoded Unicode.

StartResource

byte

(Required; PDF 1.4) A byte string that shall match one of the strings in the

string

Resources entry. It shall define the root object for the slideshow

presentation.

NOTE 2

The Resources name tree represents a virtual file system to the slideshow. It associates strings (“file names”)

with PDF objects that represent resources used by the slideshow. For example, a root stream may reference a

file name, which would be looked up in the Resources name tree, and the corresponding object would be

loaded as the file. (This virtual file system is flat; that is, there is no way to reference subfolders.)

NOTE 3

Typically, images are stored in the document as image XObjects (see 8.9.5, “Image Dictionaries”), thereby

allowing them to be shared between the standard PDF representation and the slideshow. Other media objects

are stored or embedded file streams (see 7.11.4, “Embedded File Streams”).

To allow conforming readers to verify content against their own supported features all referenced objects shall

include a Type entry in their dictionary, even when the Type entry is normally optional for a given object.

EXAMPLE

The following example illustrates the use of alternate presentation slideshows.

1 0 obj

<</Type /Catalog

/Pages 2 0 R

/Names 3 0 R

% Indirect reference to name dictionary

>>

3 0 obj

% The name dictionary

<</AlternatePresentations 4 0 R >>

endobj

4 0 obj

% The alternate presentations name tree

<</Names [(MySlideShow) 5 0 R]>>

endobj

5 0 obj

% The slideshow definition

<</Type /SlideShow

/Subtype /Embedded

/Resources <</Names [ (mysvg.svg) 31 0R

(abc0001.jpg) 35 0 R (abc0002.jpg) 36 0 R

(mysvg.js) 61 0 R (mymusic.mp3) 65 0 R ]>>

/StartResource (mysvg.svg)

>>

31 0 obj

<</Type /Filespec

% The root object, which

/F (mysvg.svg)

% points to an embedded file stream

/EF <</F 32 0 R>>

>>

endobj

32 0 obj

% The embedded file stream

<</Type /EmbeddedFile

/Subtype /image#2Fsvg+xml

510

•

3D streams shall contain the actual specification of a piece of 3D artwork (see 13.6.3, “3D Streams””). This

specification supports the Standard ECMA-363, Universal 3D file format developed by the 3D Industry

Forum (see Bibliography).

•

3D views shall specify information about the relationship between the camera and the 3D artwork (see

13.6.4, “3D Views”). Beginning with PDF 1.7, views may also describe additional parameters such as

render mode, lighting, cross sections, and nodes. Nodes shall be 3D graphic objects or collections thereof.

•

3D coordinate systems are described in 13.6.5, “Coordinate Systems for 3D.”

•

2D markup annotations applied to 3D artwork views are described in 13.6.6, “3D Markup.”

NOTE

Many of the concepts and terminology of 3D rendering are beyond the scope of this reference. Readers

interested in further information are encouraged to consult outside references.

13.6.2

3D Annotations

3D annotations (PDF 1.6) are the means by which 3D artwork shall be represented in a PDF document.

Table 298 shows the entries specific to a 3D annotation dictionary. Table 164 describes the entries common to

all annotation dictionaries.

In addition to these entries, a 3D annotation shall provide an appearance stream in its AP entry (see Table 164)

that has a normal appearance (the N entry in Table 168). This appearance may be used by applications that do

not support 3D annotations and by all applications for the initial display of the annotation.

Table 298 - Additional entries specific to a 3D annotation

Key

Type

Value

Subtype

name

(Required) The type of annotation that this dictionary describes; shall be

3D for a 3D annotation.

3DD

stream

or

(Required) A 3D stream (see 13.6.3, “3D Streams”) or 3D reference

dictionary

dictionary (see 13.6.3.3, “3D Reference Dictionaries”) that specifies the

3D artwork to be shown.

3DV

(various)

(Optional) An object that specifies the default initial view of the 3D artwork

that shall be used when the annotation is activated. It may be either a 3D

view dictionary (see 13.6.4, “3D Views”) or one of the following types

specifying an element in the VA array in the 3D stream (see Table 300):

•

An integer specifying an index into the VA array.

•

A text string matching the IN entry in one of the views in the VA

array.

•

A name that indicates the first (F), last (L), or default (D) entries in

the VA array.

Default value: the default view in the 3D stream object specified by 3DD.

3DA

dictionary

(Optional) An activation dictionary (see Table 299) that defines the times

at which the annotation shall be activated and deactivated and the state

of the 3D artwork instance at those times. Default value: an activation

dictionary containing default values for all its entries.

3DI

boolean

(Optional) A flag indicating the primary use of the 3D annotation. If true, it

is intended to be interactive; if false, it is intended to be manipulated

programmatically, as with a JavaScript animation. Conforming readers

may present different user interface controls for interactive

3D

annotations (for example, to rotate, pan, or zoom the artwork) than for

those managed by a script or other mechanism.

Default value: true.

512

Content      ..     11      12      13      14     ..
