LOCKS AND ALARM

237

NOTE

Volvo recommends that the batteries used in
the remote control meet the UN Manual of
Test and Criteria, Part III, sub-section 38.3.

Batteries installed in the key from the factory
and batteries exchanged by an authorized
Volvo workshop fulfill the above criteria.

Old batteries should be disposed of properly
at a recycling center or at your Volvo retailer.

Put the battery cover in place and turn it
clockwise until the marker points to CLOSE.

 Put the rear cover in position and press

down until it clicks into place.

 Slide the cover into place as indicated by

arrow 2 in the illustration.
> Another click indicates that it is correctly

in position and closed.

 Turn the key over and press the front

cover (with the Volvo logo) until it clicks into
place.

Slide the cover into position as indicated

by arrow 2 in the illustration.
> Another click indicates that it is correctly

in position and closed.

Dispose of old batteries properly, preferably at
recycling station.

Related information

•

Remote key (p. 238)

LOCKS AND ALARM

238

Remote key

The remote key is used to lock/unlock the vehi-
cle and must be in the passenger compartment
in order to start the engine.

The standard remote key (left) and the Key Tag (right)

In models with the standard Passive Start system,
the remote key only needs to be in the front sec-
tion of the passenger compartment or in the tun-
nel console cup holders in order to start the
engine.

The keyless Passive Entry system for locking/
unlocking the vehicle is available as an option.
This system has a range of approximately 5 feet
(1.5 meters) from the sides of the vehicle or
approximately 3 feet (1 meter) from the tailgate.
With this system, a remote key can be anywhere
in the vehicle.

Each of the remote keys provided with the vehicle
can be linked to a driver profile containing unique
personal settings that will be applied when that
particular key is used. See also the article "Driver
profile" for additional information.

NOTE

Avoid placing the remote key closer than
approx. (4-6 in.) (10-15 cm) to any metallic
objects or electronic devices such as cell
phones, tablets, laptops or chargers.

If interference persists, unlock the vehicle with
the detachable key blade and place the remote
key in the backup key reader in the tunnel con-
sole cup holder to disarm the alarm.

WARNING

Always remove the remote key from the pas-
senger compartment when leaving the vehicle
and ensure that the ignition in mode 0, espe-
cially if there are children in the vehicle.

Key Tag

In addition to the two remote keys provided, a
smaller third key, called a Key Tag, is also provi-
ded for vehicles equipped with the optional
Passive Entry system.

This key functions in the same way as a standard
remote key but does not have a detachable key
blade and its battery cannot be replaced; a new
Key Tag has to be ordered.

Ordering new keys

Two remote keys are provided with the vehicle (a
Key Tag

2

 is also included for vehicles equipped

with the optional Passive Entry system). Addi-
tional keys (a total of 12) can be ordered and
used with the vehicle.

2

The Key Tag is also referred to as a Sport key. This key is designed to be waterproof to a depth of approximately 30 ft (10 meters) for up to 60 minutes, making it suitable for use in activities in and around water.

LOCKS AND ALARM

* Option/accessory, for more information, see Introduction.

239

The remote key's buttons

The remote key has four buttons: one on the left side
and three on the right side

  Lock: Press to lock the doors/tailgate and
arm the alarm.
  Unlock: Press to unlock the driver's door
and disarm the alarm. Press again to unlock
the other doors and the tailgate. This setting
can be changed in the center display's Set-
tings menu.
  Tailgate: Press to unlock the tailgate only
(and disarm the alarm for the tailgate). On
vehicles equipped with the power tailgate

*,

press and hold to open the tailgate. Press
and hold to close an open tailgate (an audi-
ble warning signal will sound).
  Panic alarm: Press to attract attention dur-
ing emergency situations. To activate, press
and hold this button for at least 3 seconds or
press it twice within 3 seconds to activate

the turn signals and horn. To deactivate,
wait approximately 5 seconds and press the
button again (the panic alarm will also deac-
tivate automatically after several minutes).

Interference

Metallic objects or electromagnetic fields may
interfere with the remote key's function. Avoid
placing the remote key within 4-6 in. (10-15 cm)
of a cell phone or a metallic object.

If interference persists, use the remote key's
detachable key blade to unlock the vehicle and
place the remote key in the backup key reader in
the tunnel console cup holder.

Loss of a remote key

If a remote keys is lost, a new one can be
ordered. The other keys should be taken with the
vehicle to a Volvo retailer or authorized independ-
ent locksmith. As an anti-theft measure, the code
of the lost remote key must be erased from the
system. The number of registered keys for the
vehicle can be found in the center display's Top
view.

Loss of a remote key

If a remote key is lost, the others should be taken
with the vehicle to a Volvo retailer. As an anti-
theft measure, the code of the lost remote key
must be erased from the system. The number of
registered keys for the vehicle can be found in
the center display's Top view.

NOTE

Additional or duplicate remote control keys
can be obtained from any authorized Volvo
retailer.

You can also obtain additional or duplicate
remote control keys from certain independent
repair facilities and locksmiths that are quali-
fied to make remote control keys. Each key
must be programmed to work with your vehi-
cle.

A list of independent repair facilities and/or
locksmiths known to Volvo that can cut and
code replacement keys can be found:

•

on the Volvo website,
www.volvocars.com/us

•

by calling Volvo Customer Care at
1-800-458-1552.

Related information

•

Remote key's range (p. 240)

•

Detachable key blade (p. 242)

•

Changing the remote key's battery (p. 235)

•

Driver profiles (p. 181)

LOCKS AND ALARM

* Option/accessory, for more information, see Introduction.

240

Remote key's range

In order to function correctly, the remote key
must be within a certain distance of the vehicle.

Manual use

The remote key's functions, such as locking and
unlocking the vehicle, which are activated by
pressing the

 or

 buttons, have a range

of approx. 65 feet (20 meters) from the vehicle.

Buildings or other obstacles may interfere with
the function of the remote key. The vehicle can
also be locked or unlocked with the key blade.

If the vehicle's locks do not react, move closer
and try again.

Keyless use

3

The shaded areas illustrate the range of the Passive
Entry system's antennas

For keyless entry into the vehicle, the remote key
must be within approximately 5 feet (1.5 meters)
of the sides of the vehicle or approximately 3 feet
(1 meter) of the tailgate as shown in the illustra-
tion.

The remote key may not function properly due to
ambient radio waves, buildings or topographical
obstructions, etc. The vehicle can always be
locked/unlocked with the detachable key blade.

If the remote key is removed from the
vehicle

If all of the remote keys are removed from the
vehicle while the engine is running,

Vehicle key

not found



Removed from vehicle

 will be dis-

played in the instrument panel and an audible
signal will sound when all of the doors have been
closed. The message will be erased when a
remote key has been returned to the vehicle and
the O button on the right-side steering wheel
keypad has been pressed or when all of the
doors have been closed again.

Related information

•

Remote key (p. 238)

•

Antenna locations for the start and lock sys-
tem (p. 247)

Red Key

*

The Red Key (also referred to as a restricted
key) makes it possible to limit several of the vehi-
cle's functions to help ensure that it is operated
safely, for instance if the vehicle is used by a
young driver.

A Red Key makes it possible to limit the vehicle's
maximum speed, add speed reminders and limit
the audio system's volume. Several of the vehi-
cle's safety systems will also always be active.
Otherwise, this key functions in the same way as
a standard remote key.

One or more Red Keys can be ordered from a
Volvo retailer after the vehicle has been pur-
chased. A total of 11 keys can be programmed
and used for the same vehicle, one of which has
to be a standard remote key.

3

Models equipped with the optional Passive Entry only.

LOCKS AND ALARM

* Option/accessory, for more information, see Introduction.

241

Settings for the Red Key can be made by a
standard remote key user from the center dis-
play's Top view under:

Settings

System

Driver Profile

Red key

.

Several of the vehicle's safety function cannot be
turned off by a Red Key user.

The restrictions are designed to help reduce the
risk of an accident and they cannot be changed
by a Red Key user. These settings cannot be
changed by the Red Key's user.

Possible settings

The following settings can be made for a Red
Key:

Speed Limiter

* (On/Off)

•

Setting interval: 30-160 mph (50-250 km/h)

•

Default setting: 75 mph (120 km/h)

•

Increments: 1 mph (1 km/h)

This symbol will appear in the instru-
ment panel and the message

Red

keySpeed limitation cannot be
exceeded

 will be displayed if the

driver attempts to exceed the set maximum
speed.

See the article "Speed limiter" for additional
information.

Speed reminder (On/Off):

•

Setting interval: 0-155 mph (0-250 km/h

•

Default settings: 30, 45 and 55 mph (50, 70
and 90 km/h.)

•

Increments: 1 mph (1 km/h)

•

Max. number of reminders: 6

Reduced max. volume (on/off)

•

Default setting: On

Adaptive cruise control

* (On/Off)

•

Initial setting: On at the longest interval

•

See the article "Adaptive cruise control" for
additional information

Safety functions

The following safety functions will always be
active for a Red Key user:

•

Blind Spot Information (BLIS)

*

•

Lane Keeping Aid (LKA)

*

•

Distance Alert

*

•

City Safety

*

•

Driver Alert Control (DAC)

*

•

Road Sign Information (RSI)

*

Related information

•

Remote key (p. 238)

•

Adaptive Cruise Control (ACC)

* (p. 281)

•

Speed limiter (SL)

* (p. 267)

•

Blind Spot Information (BLIS)

* (p. 339)

•

Driving lane assistance (p. 350)

•

Distance Alert

* (p. 279)

•

City Safety

™ (p. 326)

•

Driver Alert Control (DAC) (p. 348)

•

Road Sign Information (RSI)

* (p. 346)

LOCKS AND ALARM

242

Detachable key blade

Your vehicle's remote key contains a detachable
key blade that can be used to unlock the driver's
door, etc.

A Volvo retailer can provide you with the key
blade's unique code.

Using the detachable key blade

The remote key's detachable key blade can be
used to:

•

Unlock the driver's door if the central locking
system cannot be activated using the remote
key

•

Lock all doors

•

Activate/deactivate the mechanical child
safety locks in the rear doors

The Key Tag

4

 does not have a detachable key

blade.

Detaching the key blade

 Hold the remote key with the front side

(with the Volvo symbol) toward you and move
the button on lower edge of the key near the
key ring to the right. Slide the front cover
slightly upward.

 The cover will loosen and can be

removed from the key.

 Remove the key blade.

 After use, press the key blade back into

its position in the key, put the cover back on
the key and slide it into position.
> A click indicates that the cover is correctly

in place.

Related information

•

Locking/unlocking with the detachable key
blade (p. 254)

•

Child safety locks (p. 257)

4

Models with the optional Passive Entry system only.

LOCKS AND ALARM

}}

* Option/accessory, for more information, see Introduction.

243

Foot movement tailgate operation

*

The foot movement sensor

* simplifies opening or

closing the tailgate if your hands are full.

5

The foot movement sensor is located to the left of cen-
ter under the rear bumper

6

NOTE

One of the remote keys must be in your pos-
session or within range when you are behind
the vehicle in order to activate the foot move-
ment sensor, even if the tailgate is already
unlocked. This is done to help prevent the
sensor from inadvertently opening the tail-
gate, for example, in a car wash.

Be sure that the key is not within range when
the vehicle is in an automatic carwash.

Operation

Kicking motion under the sensor's activation area

Opening/closing
–

With the remote key within range, move your
foot slowly forward in a kicking motion below
the left section of the rear bumper without
touching the bumper and take a step back.
> A brief audible signal will sound when the

tailgate begins to open/close.

The tailgate can be closed (or closed and locked)
by pressing the

 or

 buttons on the lower

edge of the tailgate

7

.

It can also be operated manually or by pressing
the button on the lighting panel in the passenger
compartment or on the remote key.

If several attempts have been made to open/
close the tailgate using the foot sensor without a
remote key within range, the function will time
out and will not be available for a short period.

NOTE

Foot operation may not be possible or func-
tion normally if the sensor is obstructed by
snow, ice, dirt, etc.

5

Models equipped with the optional power tailgate only.

6

If the vehicle is equipped with a skid plate/diffuser

*, the sensor is located under the left corner of the bumper.

7

Vehicles equipped with the optional Passive Entry system only.

||

LOCKS AND ALARM

* Option/accessory, for more information, see Introduction.

244

Interrupting opening/closing
–

Move your foot slowly forward in a kicking
motion while the tailgate is opening/closing
to stop its movement.

No remote keys need to be within range in order
to interrupt movement of the tailgate.

Vehicles equipped with a skid plate/
diffuser

*

If the vehicle is equipped with a skid plate/
diffuser

*, the sensor is located under the left cor-

ner of the rear bumper.

Sensor location on vehicles equipped with a skid plate/
diffuser

*

To open/close the tailgate, make the kicking
motion from the side of the rear bumper.

Kicking motion under the sensor's activation area

Related information

•

Power tailgate

* (p. 251)

•

Locking/unlocking the tailgate (p. 249)

•

Remote key's range (p. 240)

Locking/unlocking from outside the

vehicle

The buttons on the remote key can be used to
lock or unlock all doors and the tailgate at the
same time. This can also be done without press-
ing the remote key buttons on models equipped
with the optional keyless Passive Entry system.
The power tailgate

* can also be opened/closed

by moving your foot under a sensor beneath the
rear bumper.

Locking and unlocking

The lock/unlock settings can be changed in the
center display's Top view.

Go to:

Settings

My Car

Remote Unlock

and select

Unlock All Doors

 or

Driver Door

Only

.

In order to lock the vehicle, the driver's door must
be closed. If the tailgate or any of the other doors
are open, they will be locked and the alarm will be
armed when they are closed.

NOTE

Be sure the remote key is outside of the vehi-
cle before the other doors/tailgate are closed
to help avoid locking the remote inside the
vehicle.

The settings made for the

Remote Unlock

 func-

tion also affect the central locking system when a

LOCKS AND ALARM

}}

* Option/accessory, for more information, see Introduction.

245

door is opened from inside the vehicle using a
door handle. See also the article "Locking/
unlocking from inside the vehicle" for additional
information.

If the locks repeatedly do not react when the
unlock button is pressed, begin by moving closer
to the vehicle. However, it may be necessary to
replace the battery in the remote. In this case, the
driver's door can be unlocked with the detacha-
ble key blade. See also the article "Detachable
key blade" for additional information.

Keyless Passive Entry

*

If the vehicle is equipped with this system, it is
only necessary to have a remote key in your pos-
session to operate the central locking system.

Models with Passive Entry have an indentation on
the outside of the handle for locking the vehicle
and a pressure sensitive surface on the inside of
the handle for unlocking.

The tailgate has a rubberized button used only
for unlocking.

Outer indentation for locking, the pressure sensitive sur-
face on the inside of the handle is for unlocking

Pressure sensitive indentation for locking

Pressure sensitive surface for unlocking

Rubberized button on the tailgate used only for unlock-
ing

Locking

All of the doors have to be closed before the
vehicle can be locked but the tailgate can be
open.

Lock the doors and tailgate by pressing the pres-
sure sensitive indentation on the outside of any
of the door handles. The lock indicator light on
the dashboard will begin to flash to show that the
vehicle is locked and the alarm has been armed.

NOTE

Only one of a door handle's lock/unlock sur-
faces should be pressed at a time. If both
areas are pressed simultaneously, the desired
locking/unlocking action may not occur or
may be delayed.

To close windows or the panoramic roof

* when

locking the vehicle, hold the pressure sensitive
surface on the outside of a door handle until the
window(s)/panoramic roof have closed com-
pletely. The windows/panoramic roof will stop if
the button is released before they are fully
closed.

||

LOCKS AND ALARM

* Option/accessory, for more information, see Introduction.

246

Unlocking

Pull a door handle to unlock and open the door
or press the rubberized button under the tailgate
opening control. The lock indicator light on the
dashboard will go out to show that the vehicle is
unlocked and the alarm has been disarmed.

The lock/unlock settings can be changed in the
center display's Top view:

Go to:

Settings

My Car

Keyless Unlock

and select

All Doors

 or

Single Door

.

Automatic relocking

If no door or the tailgate is opened within two
minutes after being unlocked, the vehicle will
automatically relock.

Remote door unlock

The vehicle can be unlocked using the Volvo On
Call app.

Related information

•

Remote key (p. 238)

•

Remote key's range (p. 240)

•

Detachable key blade (p. 242)

•

Alarm (p. 256)

•

Locking/unlocking from inside the vehicle
(p. 246)

•

Foot movement tailgate operation

* (p. 243)

•

Locking/unlocking the tailgate (p. 249)

Locking/unlocking from inside the

vehicle

The lock buttons on either of the front doors can
be used to lock or unlock all doors and the tail-
gate at the same time. The rear doors can be
locked using their respective lock buttons

*.

The central locking system

Central locking/unlocking buttons and indicator lights
on the front doors

–

Press the

 button to lock the vehicle.

Press

 to unlock.

Unlocking

•

Press the

 button to unlock all doors and

the tailgate.

•

Pull the door opening handle on either of the
front doors. This will unlock the vehicle com-
pletely

8

 and the door will open.

Locking

–

Press the

 button on either of the front

doors to lock the vehicle (both front doors
must be closed).

Lock buttons on the rear doors

*

Lock button and indicator light in a rear door

The lock buttons in the rear doors lock/unlock
each door respectively.

8

The unlock setting "

All Doors

" must be selected. If the setting "

Driver door, then all

" has been selected, only that door will unlock and open.

LOCKS AND ALARM

247

To unlock a rear door:

–

To open one of the rear doors individually,
pull its handle to unlock and open the door

9

.

Automatic locking

All of the doors/tailgate will lock automatically
when the vehicle begins to move.

Related information

•

Locking/unlocking from outside the vehicle
(p. 244)

•

Locking and unlocking confirmation (p. 248)

•

Child safety locks (p. 257)

Antenna locations for the start and

lock system

The vehicle is equipped with a keyless

10

 start

and lock system that requires a number of anten-
nas located at various points in the vehicle.

Location of the antennas

Under the cup holders in the front section of
the tunnel console
In the upper front section of the driver side
rear door

10

In the upper front section of the passenger
side rear door

10

In the center of the rear seat backrest

10,11

WARNING

People with implanted pacemakers should not
allow the pacemaker to come closer than
9 inches (22 cm) to any of the Passive Entry
system's antennas. This is to help prevent
interference between the pacemaker and the
Passive Entry system.

Related information

•

Remote key (p. 238)

•

Remote key's range (p. 240)

9

Assuming that the child safety locks are not activated.

10

Vehicles with the optional Passive Entry system only.

11

In a seven-seat model, the antenna is located between the seats where the backrest and seat cushion meet.

LOCKS AND ALARM

248

Locking and unlocking confirmation

The turn signals can be used to indicate that the
vehicle has been locked/unlocked with the
remote key. These settings can also be changed
in the center display's Top view by going to:

Settings

My Car

Locking

Locking and

Unlocking Feedback

.

Exterior confirmation

•

Locking: the turn signals flash once and the
door mirrors will fold in (retract)

12

•

Unlocking: the turn signals flash twice and
the door mirrors will fold out

12

When the vehicle is locked, confirmation will only
be given if all doors/tailgate and the hood are
closed.

If the vehicle is locked while only the driver's door
is closed

13

, all doors/tailgate will lock but confir-

mation will only be given when all doors/tailgate/
hood are closed.

Interior confirmation

Lock and alarm indicator light on the dashboard

A long flash indicates the vehicle is locked. While
the vehicle is locked, the indicator will flash
briefly.

LEDs in the lock buttons on the doors illuminate
when the doors are locked.

Indicators in the interior lock buttons

Lock buttons in the front doors

Front door lock button and indicator light

Indicator lights on: all doors are locked.

If a door is opened, the lights in both doors will
go out.

12

Models with electrically retractable door mirrors only.

13

This does not apply to vehicles equipped with the optional keyless Passive Entry system.

LOCKS AND ALARM

}}

249

In all doors

Rear door lock button and indicator light

Indicator light in the respective door on: that door
is locked. If a door is opened, the light in that
door will out but the other indicator lights will
remain on.

Confirmation alternatives

Various alternatives for locking/unlocking confir-
mation can be selected in the center display.

1. Tap

Settings

 in the center display's Top

view.

2. Tap

My Car

Locking

.

3. Change the settings under

Locking and

Unlocking Feedback

.

Related information

•

Locking/unlocking from outside the vehicle
(p. 244)

•

Home safe lighting (p. 155)

•

Adjusting the power door mirrors (p. 108)

Locking/unlocking the tailgate

The tailgate can be locked/unlocked in different
ways, depending on whether the vehicle is
equipped with the optional keyless Passive Entry
system.

Unlocking with the remote key

Remote key tailgate button

1. Press the

 button on the remote key.

> The tailgate will be unlocked but remain

closed. The alarm indicator on the dash-
board will go out to indicate that the tail-
gate alarm is no longer armed. The other
doors will remain locked and the alarm will
remain armed for them.

2. Open the tailgate.

> If the tailgate is not opened within two

minutes, it will relock and the alarm will
rearm.

||

LOCKS AND ALARM

* Option/accessory, for more information, see Introduction.

250

Keyless unlocking

*

Rubberized pressure plate

Opening the tailgate:

1. With the remote key in your possession,

unlock the tailgate by pressing lightly on the
rubberized pressure plate under the outer
tailgate handle. If the remote key is not
detected, the tailgate cannot be unlocked/
opened. Three audible signals will sound.

2. Lift the handle to open the tailgate fully.

CAUTION

•

When pressing the rubberized pressure
plate, only light pressure is necessary to
release the tailgate's electronic locking
mechanism.

•

When opening the tailgate, pull it up
using the handle. Too much pressure on
the rubberized pressure plate can dam-
age its electrical connections.

WARNING

Avoid driving with the tailgate open if at all
possible. Doing so could allow exhaust gases
to enter the passenger compartment.

Unlocking the tailgate from inside the
vehicle

Tailgate unlock button

To unlock the tailgate:

–

Press the

 button on the lighting panel.

> The tailgate will unlock and can be

opened within two minutes (if the vehicle
has been locked from the inside).

Locking with the remote key

–

Press the

 button on the remote key.

> The alarm indicator on the dashboard will

begin to flash to show that the alarm has
been armed.

Related information

•

Remote key (p. 238)

•

Power tailgate

* (p. 251)

•

Foot movement tailgate operation

* (p. 243)

•

Remote key's range (p. 240)

LOCKS AND ALARM

}}

* Option/accessory, for more information, see Introduction.

251

Power tailgate

*

The optional power tailgate can be opened/
closed in several ways.

The power tailgate can be opened/closed using
the

 button on the lighting panel in the pas-

senger compartment, the

 on the remote key,

by moving your foot under a sensor under the
rear bumper

* or manually.

WARNING

When operating the tailgate manually, do not
use force to open or close it. This could result
in injury.

Buttons in the lower edge of the tailgate

Button on the lighting panel in the passenger compart-
ment

Opening the tailgate

The power tailgate can be opened electrically by:

•

Pressing and holding the

 button on the

lighting panel until the tailgate begins to
open.

•

Pressing and holding the

 button on the

remote key until the tailgate begins to open.

•

Pressing lightly on the rubber-covered button
under the tailgate's outside handle.

•

Moving your foot under a sensor under the
rear bumper

*.

Closing the tailgate

The tailgate can be closed by moving your foot
under a sensor beneath the rear bumper

*, by

pressing the button on the lighting panel, with
the remote key or by pressing the button on the
lower edge of the tailgate

*

14

To close the tailgate

15

:

–

Press the

 button on the lighting panel

or on the

 button on the remote key.

> The tailgate will close automatically and

audible signal will sound. This will not
lock the tailgate.

Buttons on the lower edge of the tailgate

14

Models equipped with the optional Passive Entry system have a button to close the tailgate and a button to close and lock the tailgate.

15

See also the article "Foot movement tailgate opening/closing."

||

LOCKS AND ALARM

* Option/accessory, for more information, see Introduction.

252

–

Press the

 button

14

 on the lower edge of

the tailgate.
> The tailgate will close automatically but

will not be locked.

–

Press the

 button

14

 on the lower edge of

the tailgate.
> The tailgate will close automatically. The

tailgate and doors will also be locked and
the alarm will be armed.

If the remote key is not close enough to the tail-
gate, automatic locking/unlocking/opening/clos-
ing will not be possible. Three short audible sig-
nals will sound.

Interrupting opening/closing

–

This can be done in five ways:

•

Press the button on the lighting panel

•

Press the button on the remote key

•

Press either of the buttons on the lower
edge of the tailgate

•

Press lightly on the rubber-covered button
under the tailgate's outside handle

•

Move your foot under a sensor beneath
the rear bumper

*

> The tailgate will stop moving

Programming the tailgate's maximum
opening angle

The tailgate's maximum opening angle can be
programmed, for example, if the tailgate has to be
opened in a garage with a low ceiling.

Programming the opening angle:

–

Open the tailgate manually to the desired
angle and press and hold the closing button
on the tailgate's lower edge for at least 3
seconds. Release the tailgate.
> Two audible signals will sound to indicate

that the selected opening angle has been
stored.

Erasing tailgate programming

–

Open the tailgate manually to its highest
position and press and hold the closing but-
ton on the tailgate's lower edge for at least 3
seconds. Release the tailgate.
> Two audible signals will sound to indicate

that the programmed opening angle has
been erased.

NOTE

If the tailgate has been opened and closed
continuously too long, the automatic function
will be deactivated to avoid overloading the
electrical system. The automatic function can
be used again after approximately 2 minutes.

If the vehicle's battery has been discharged or
disconnected, or if the tailgate has been open
for more than 24 hours, the tailgate must be
opened and closed once manually to reset
the system.

Pinch protection

If the tailgate is obstructed when being opened/
closed, a pinch protection mechanism is acti-
vated.

•

While opening: the tailgate will stop moving
and an audible signal will sound.

•

While closing: the tailgate will stop and
return to the currently programmed maximum
opening position. An audible signal will
sound.

WARNING

Pay attention to the risk of injury when open-
ing/ closing the tailgate. Before opening/
closing: Make sure that no one is in the path
of the tailgate as an injury could occur.

14

Models equipped with the optional Passive Entry system have a button to close the tailgate and a button to close and lock the tailgate.
