Volvo XC90 Excellence (2018 year). Manual - part 3

Preparation for charging the hybrid battery
(p. 470)

Never connect the charging cable when there
is a risk of thunderstorm or lightning strike.

The hybrid battery is the Lithium-ion type and can
be recharged in different ways:

•

A charging cable with control unit can be
connected between the car and a 230 VAC
socket

. Charging time depends on charg-

ing current. Read more in the section
"Charging the hybrid battery".

•

The hybrid battery is recharged during gentle
braking with the brake pedal. The car's
kinetic energy is then converted to electrical
energy, which is used to charge the hybrid
battery. The hybrid battery is also recharged
during engine braking in gear position B
when e.g. travelling downhill. Read more in
the sections "Gear positions for automatic
gearbox" and "Hybrid related information in
the driver display".

•

The hybrid battery can also be charged by
the car's engine.

Related information

•

•

Starting the car (p. 414)

•

Hybrid battery (p. 573)

•

Drive modes (p. 425)

•

Engine compartment overview (p. 560)

•

Starting/stopping preconditioning (p. 209)

•

Charging the hybrid battery (p. 462)

•

Gear positions for automatic gearbox
(p. 419)

The voltage in the socket may vary depending on market.

SAFETY

Safety

The vehicle is equipped with several safety sys-
tems that work together to protect the vehicle's
driver and passengers in the event of an acci-
dent.

The car is equipped with a number of sensors
that react in the event of an accident and activate
different safety systems, such as different types
of airbags and seatbelt tensioners. Depending on
the specific accident situation, such as collisions
at different angles, rollover or driving off the road,
the systems react in different ways to provide the
best protection.

There are also mechanical safety systems such
as Whiplash Protection System. The car is also
constructed so that a large part of the force of a
collision is distributed to beams, pillars, floor, roof
and other parts of the body.

The car's safety mode may be activated after a
collision if an important function in the car has
been damaged.

Warning symbol in driver display

The warning symbol is illuminated in
the driver display when the car's elec-
trical system is set in ignition position
II. The symbol is extinguished after

approx. 6 seconds if the car's safety system is
fault-free.

WARNING

If the warning symbol remains illuminated or

is switched on during driving and the mes-

sage

SRS airbag

Service urgent Drive to

workshop

is shown in the driver display, it

means that part of one of the safety systems

does not have full functionality. Volvo recom-

mends that an authorised Volvo workshop

should be contacted as soon as possible.

WARNING

Never modify or repair the car's various safety

systems yourself. Defective work in one of the

systems can cause malfunction and result in

serious personal injury. Volvo recommends

that an authorised Volvo workshop should be

contacted.

If the specific warning symbol is broken
then the general warning symbol is illu-
minated instead and the driver display
shows the same message.

Related information

•

Safety during pregnancy (p. 60)

•

•

Whiplash Protection System (p. 61)

•

•

Safety mode (p. 73)

•

Child safety (p. 74)

Safety during pregnancy

It is important that the seatbelt is used correctly
during pregnancy, and that pregnant drivers
adjust their seating position.

Seatbelt

The diagonal section should wrap over the shoul-
der then be routed between the breasts and to
the side of the abdomen.

The lap section should lay flat over the thighs and
as low as possible under the abdomen. – It must
never be allowed to ride upward. Remove the
slack from the seatbelt and ensure that it fits as
close to the body as possible. In addition, check
that there are no twists in the seatbelt.

Seating position

As the pregnancy progresses, pregnant drivers
must adjust the seat and steering wheel such
that they can easily maintain control of the vehi-

SAFETY

}}

* Option/accessory.

cle as they drive (which means that they must be
able to easily operate the foot pedals and steer-
ing wheel). The aim should be to position the
seat with as large a distance as possible between
abdomen and steering wheel.

Related information

•

•

Manual front seat (p. 127)

•

•

Power front seat

* (p. 128)

Whiplash Protection System

Whiplash Protection System (WHIPS) reduces
the risk of whiplash injuries. The system consists
of energy-absorbing backrests and seat cush-
ions, and specially designed head restraints in
the front seats.

WHIPS is deployed in the event of a rear-end
collision, where the angle and speed of the colli-
sion and the nature of the colliding vehicle all
have an influence.

When WHIPS is deployed, the front seat back-
rests are lowered backward and the seat cush-
ions move downward to change the seating posi-
tion of the driver and front seat passenger. Its
movement helps to absorb some of the forces
that can arise and cause whiplash.

WARNING

WHIPS is a supplement to the seatbelts.

Always use a seatbelt.

WARNING

Never modify or repair the seat or WHIPS

yourself. Volvo recommends that an author-

ised Volvo workshop should be contacted.
If the front seats have been subjected to a

major load, such as in conjunction with a colli-

sion, the seats must be replaced. Some of the

seats' protective properties may have been

lost even if they do not appear damaged.

Do not leave any objects on the floor behind or under

the front seats or in the rear seat that may prevent

WHIPS from functioning.

SAFETY

* Option/accessory.

WARNING

Do not squeeze rigid objects between the

rear seat cushion and the front seat's back-

rest.
If a backrest in the rear seat is lowered then

any load must be secured to prevent it from

sliding up to the front seat backrest in the

event of a collision.

WARNING

If a backrest in the rear seat is lowered or a

rear-facing child seat is used in the rear seat,

the corresponding front seat must be moved

forward so that it does not make contact with

the lowered backrest or child seat.

Seating position

For optimum protection from WHIPS the driver
and passenger must have the correct seating
position and make sure that the system's func-
tion is not obstructed.

Set the correct seating position in the front seat
before driving starts.

Driver and front seat passenger should sit in the
centre of the seat with as little space as possible
between the head and the head restraint.

WHIPS and child seats

The protection provided by the car to children
seated in a child seat or on a booster cushion is
not diminished by WHIPS.

Related information

•

Manual front seat (p. 127)

•

•

Power front seat

* (p. 128)

•

Rear Collision Warning (p. 358)

•

Seatbelt

Heavy braking can have serious consequences
if the seatbelts are not used.

It is important that the seatbelt lies against the
body so it can provide maximum protection. Do
not lean the backrest too far back. The seatbelt is
designed to protect in a normal seating position.

WARNING

Remember not to clip or hook the seatbelt to

hooks or other interior fittings, as this pre-

vents the belt from tightening properly.

WARNING

The seatbelts and airbags interact. If a seat-

belt is not used or is used incorrectly, this may

diminish the protection provided by the airbag

in the event of a collision.

SAFETY

}}

WARNING

Never modify or repair the seatbelts yourself.

Volvo recommends that an authorised Volvo

workshop should be contacted.
If the seatbelt has been subjected to a major

load, such as in conjunction with a collision,

the entire seatbelt must be replaced. Some of

the seatbelt's protective properties may have

been lost even if the seatbelt does not appear

damaged. The seatbelt must also be replaced

if it shows signs of wear or damage. The new

seatbelt must be type-approved and designed

for installation at the same location as the

replaced seatbelt.

Related information

•

•

Fastening/unfastening a seatbelt (p. 64)

•

•

Door and seatbelt reminder (p. 65)

Seatbelt tensioner

The car is fitted with pyrotechnic and electric
seatbelt tensioners that can tension the seat-
belts in critical situations and collisions.

Seatbelt tensioner during collision

All the seatbelts are equipped with a pyrotechnic
seatbelt tensioner.

The pyrotechnic seatbelt tensioner tensions the
seatbelt in the event of a collision with sufficient
force in order to more effectively restrain the
occupant.

Seatbelt tensioner during critical
situations

The driver and front passenger seatbelts are
equipped with an electric seatbelt tensioner.

The seatbelt tensioners work together and can
be activated together with the driver support sys-
tems City Safety and Rear Collision Warning. In
critical situations, such as panic braking, driving
off the road (e.g. the car rolls into a ditch, lifts off
the ground or hits something in the terrain), skid-
ding, or risk of collision, the seatbelt can be ten-
sioned by the seatbelt tensioner's electric motor.

The electric seatbelt tensioner adjusts the occu-
pant to a better position, reducing the risk of
striking the car's interior and improving the effect
of safety systems, such as the car's airbags.

If the passenger airbag is deactivated, the
electric seatbelt tensioner on the passenger
side will also be deactivated.

Resetting the electric seatbelt tensioner

Once the critical situation has passed, the seat-
belt and electric seatbelt tensioner are reset
automatically.

If the belt still remains tensioned:

1. Stop the car at a safe place.

2. Unfasten the seatbelt and then refasten it.

> The seatbelt and electric seatbelt ten-

sioner are reset.

WARNING

Never modify or repair the seatbelts yourself.

Volvo recommends that an authorised Volvo

workshop should be contacted.
If the seatbelt has been subjected to a major

load, such as in conjunction with a collision,

the entire seatbelt must be replaced. Some of

the seatbelt's protective properties may have

been lost even if the seatbelt does not appear

damaged. The seatbelt must also be replaced

if it shows signs of wear or damage. The new

seatbelt must be type-approved and designed

for installation at the same location as the

replaced seatbelt.

SAFETY

* Option/accessory.

Related information

•

Fastening/unfastening a seatbelt (p. 64)

•

•

Door and seatbelt reminder (p. 65)

•

City Safety (p. 346)

•

Rear Collision Warning (p. 358)

•

Activating/deactivating the passenger air-
bag

* (p. 69)

Fastening/unfastening a seatbelt

Make sure that all passengers have fastened
their seatbelts before starting to drive.

Fastening a seatbelt

1. Pull out the seatbelt slowly and make sure it

is not twisted or damaged.

Make sure that the seatbelt is correctly in the
belt guide available for the second seat row's
centre seat.

The seatbelt locks and cannot be withdrawn:

•

if it is pulled out too quickly

•

during braking and acceleration

•

if the car leans heavily.

2. Lock the belt by inserting the locking tab in

the intended buckle.
> A loud "click" indicates that the belt has

locked.

WARNING

Always insert the tongue of the seatbelt into

the buckle on the correct side. The seatbelts

and buckles would otherwise possibly not

function as intended in the event of a colli-

sion. There is a risk of serous injury.

3. In the front seats and in the outer seats in

the second seat row the seatbelt can be
adjusted for height.

Press together the seat mounting and move
the seatbelt up or down.

Position the belt as high as possible without
it chafing against your throat.

SAFETY

}}

The seatbelt must pass over the shoulder (not down over

the arm).

4. Tension the hip strap over the lap by pulling

the diagonal shoulder belt up towards the
shoulder.

The hip strap must be positioned low down (not over the

abdomen).

WARNING

Each seatbelt is designed for only one person.

WARNING

Remember not to clip or hook the seatbelt to

hooks or other interior fittings, as this pre-

vents the belt from tightening properly.

WARNING

Do not make any damages on seatbelts nor

insert any foreign objects into a buckle. The

seatbelts and buckles would then possibly not

function as intended in the event of a colli-

sion. There is a risk of serous injury.

Unfastening a seatbelt

1. Press the red button on the seatbelt buckle

and then let the belt retract.

2. If the seatbelt does not retract fully, feed it in

by hand so that it does not hang loose.

Make sure that the seatbelt is correctly in the
belt guide available for the second seat row's
centre seat.

Related information

•

•

Door and seatbelt reminder (p. 65)

•

Door and seatbelt reminder

The system reminds unbelted occupants to wear
a seatbelt, and also warns about an open door,
bonnet, tailgate or fuel filler flap.

Driver display graphics

Graphics in the driver display with different types of

warnings. The warning colour on the door and tailgate is

dependent on the vehicle's speed.

The driver display's graphics show which seats in
the car are occupied by belted and unbelted pas-
sengers.

The same graphic also shows if the bonnet, tail-
gate, fuel filler flap or any door is open.

The graphic can be acknowledged by pressing
the O button on the right-hand steering wheel
keypad.

SAFETY

Seatbelt reminder

Visual reminder in the roof console.

A visual reminder is given in the roof console and
by means of the warning symbol in the driver dis-
play.

The acoustic reminder is dependent on speed,
driving time and distance.

The belt status of the driver and passengers is
shown in the driver display graphics when a belt
is buckled or unbuckled.

Child seats are not covered by the seatbelt
reminder system.

Front seat

A visual and acoustic reminder remind the driver
and front seat passenger to use a seatbelt if
either of them is not wearing one.

Rear seat

The seatbelt reminder in the rear seat has two
subfunctions:

•

Provides information on which seatbelts are
being used in the rear seat. The driver dis-
play's graphics are shown when the seatbelts
are in use.

•

Reminding that a seatbelt in the rear seat is
unfastened during a journey by means of a
visual and acoustic reminder. The reminder
will cease once the seatbelt has been put on
again.

Reminder for doors, bonnet, tailgate
and fuel filler flap

If the bonnet, tailgate, fuel filler flap or a door is
not closed properly, the driver display's graphics
show what is open. Stop the car in a safe place
as soon as possible and close the source of the
warning.

If the car is driven at a speed lower
than approx. 10 km/h (6 mph) then the
driver display's information symbol illu-
minates.

If the car is driven at a speed higher
than approx. 10 km/h (6 mph) then the
driver display's warning symbol illumi-
nates.

Related information

•

•

Fastening/unfastening a seatbelt (p. 64)

•

SAFETY

}}

Airbags

The car is equipped with airbags and inflatable
curtains for driver and passengers.

WARNING

The airbag system's control module is located

in the centre console. If the centre console is

drenched with water or other liquid, discon-

nect the cables to the starter battery. Do not

attempt to start the car since the airbags may

deploy. Recovering the car. Volvo recom-

mends that it is transported to an authorised

Volvo workshop.

Deployed airbags

If any of the airbags have deployed, the following
is recommended:

•

Recovering the car. Volvo recommends that it
is transported to an authorised Volvo work-
shop. Do not drive with deployed airbags.

•

Volvo recommends engaging an authorised
Volvo workshop to handle the replacement of
components in the car's safety systems.

•

Always contact a doctor.

WARNING

Never drive with deployed airbags. They can

make steering difficult. Other safety systems

may also be damaged. The smoke and dust

created when the airbags are deployed can

cause skin and eye irritation/injury after inten-

sive exposure. In case of irritation, wash with

cold water. The rapid deployment sequence

and airbag fabric may cause friction and skin

burns.

Related information

•

Driver and passenger airbags (p. 67)

•

•

Side airbag (p. 71)

•

Inflatable curtain (p. 72)

Driver and passenger airbags

As a supplement to the seatbelts, the vehicle is
equipped with airbags on the driver and passen-
ger sides in the front seat.

Driver and passenger airbags.

In the event of a frontal collision, the airbags help
to protect the head, face and chest of the driver
and passenger as well as the knees and legs of
the driver.

A sufficiently violent collision trips the sensors
and the airbag/airbags is inflated. The airbag
cushions the initial collision impact for the occu-
pant. The airbag deflates when compressed by
the collision. When this occurs, smoke escapes
into the car. This is completely normal. The entire
process, including inflation and deflation of the
airbag, occurs within tenths of a second.

SAFETY

The detectors react differently depending on
the nature of the collision and whether or not
the seatbelts are fastened. Applies to all belt
positions.

It is therefore possible that only one (or none)
of the airbags may inflate in a collision. The
detectors sense the force of the collision on
the vehicle and the action is adapted accord-
ingly so that none, one or more airbags are
deployed.

WARNING

The seatbelts and airbags interact. If the belt

is not used or is used incorrectly, this may

diminish the protection provided by the airbag

in the event of a collision.
To minimise the risk of injury if the airbag

deploys, passengers must sit as upright as

possible with their feet on the floor and backs

against the backrest.

WARNING

Volvo recommends that an authorised Volvo

workshop should be contacted for repair.

Defective work in the airbag system could

cause malfunction and result in serious per-

sonal injury.

Driver airbags

Airbag in the steering wheel

This airbag is fitted into the centre of the steering
wheel. The steering wheel is marked AIRBAG.

Knee airbag

The airbag is folded up in the lower part of the
instrument panel on the driver's side. Its cover
panel is marked AIRBAG.

WARNING

Do not place or attach any object on the top

or front of the panel where the knee airbag is

stowed.

Passenger airbag

The airbag is folded up into a compartment
above the glovebox. Its cover panel is marked
AIRBAG.

WARNING

Do not put objects in front of or above the

dashboard where the passenger airbag is

located.

Label for passenger airbag

Label on the passenger side's sun visor.

Label on the passenger side's door pillar. The label

becomes visible when the passenger door is opened.

The warning label for the passenger airbag is
positioned as shown above.

SAFETY

}}

* Option/accessory.

WARNING

If the car is not equipped with a switch to acti-

vate/deactivate the passenger airbag, the air-

bag will always be activated.

WARNING

Never allow anybody to stand or sit in front of

the front passenger seat.
Never use a rear-facing child seat on the front

passenger seat if the airbag is activated.
Front-facing passengers (children and adults)

must never sit on the front passenger seat if

the passenger airbag is deactivated.
Failure to follow the advice given above can

endanger life or lead to serious personal

injury.

Related information

•

Activating/deactivating the passenger air-
bag

•

* (p. 69)

Activating/deactivating the

passenger airbag

The passenger airbag can be deactivated if the
car is equipped with a switch, Passenger Airbag
Cut Off Switch (PACOS).

Switch

The switch for the passenger airbag is located on
the passenger end of the instrument panel and is
accessible when the passenger door is open.

Check that the switch is in the required position.

ON - the airbag is activated and all front-fac-
ing passengers (children and adults) can sit
safely on the passenger seat.
OFF - The airbag is deactivated and children
in rear-facing child seats can sit safely on the
passenger seat.

WARNING

If the car is not equipped with a switch to acti-

vate/deactivate the passenger airbag, the air-

bag will always be activated.

SAFETY

Activating the passenger airbag

Pull the switch outward and turn from OFF
(B) to ON (A).
> The driver display shows the message

Passenger airbag on

Please

acknowledge

If the passenger airbag has been activated/
deactivated with the car in ignition position I
or lower, a message is shown in the driver
display and the following indicator in the roof
console approx. 6 seconds after the car's
electrical system has been set in ignition
position II.

2. Confirm the message by pressing the right-

hand steering wheel keypad's O button.

> A text message and a warning symbol in

the roof console indicate that the airbag
for the front passenger seat is activated.

WARNING

Never use a rear-facing child seat on the front

passenger seat when the airbag is activated.
The passenger airbag must always be acti-

vated when front-facing passengers (children

and adults) are sitting in the front passenger

seat.
Failure to follow the advice given above can

endanger life or lead to serious personal

injury.

Deactivating the passenger airbag

Pull the switch outward and turn from ON
(A) to OFF (B).
> The driver display shows the message

Passenger airbag off

Please

acknowledge

SAFETY

}}

2. Confirm the message by pressing the right-

hand steering wheel keypad's O button.

> A text message and a symbol in the roof

console indicate that the airbag for the
front passenger seat is deactivated.

WARNING

Front-facing passengers (children and adults)

must never sit on the passenger seat when

the airbag is deactivated.
Failure to follow the advice given above can

endanger life or lead to serious personal

injury.

Driver and passenger airbags (p. 67)

If the passenger airbag is deactivated, the
electric seatbelt tensioner on the passenger
side will also be deactivated.

Related information

•

•

•

Side airbag

The side airbags on the driver and passenger
seats protect the chest and hip in the event of a
collision.

The side airbags are fitted in the outer backrest
frames of the front seats and help to protect the
driver and passengers in the front seat.

A sufficiently violent collision trips the sensors
and the side airbags are inflated. The airbag
inflates between the occupant and the door
panel and thereby cushions the initial impact. The
airbag deflates when compressed by the collision.
The side airbag is normally only deployed on the
side of the collision.

SAFETY

WARNING

Volvo recommends that an authorised Volvo

workshop should be contacted for repair.

Defective work in the side airbag system

could cause malfunction and result in serious

personal injury.

WARNING

Do not put objects in the area between the

outside of the seat and the door panel, since

this area is required by the side airbag.
Volvo recommends the use only of car seat

covers approved by Volvo. Other seat covers

may impede the operation of the side airbags.

WARNING

Side airbags are a supplement the seatbelts.

Always use a seatbelt.

Side airbag and child seats

The protection provided by the car to children
seated in a child seat or on a booster cushion is
not diminished by the side airbag.

Related information

•

•

Inflatable curtain

The inflatable curtain, Inflatable Curtain (IC),
helps to prevent the driver and passengers from
striking their heads on the inside of the car dur-
ing a collision.

The inflatable curtain is mounted along both
sides of the headlining and helps protect the
driver and outer seat passengers of the car. The
panels are labelled with IC AIRBAG.

A sufficiently violent collision trips the sensors
and the inflatable curtain is inflated.

WARNING

Volvo recommends that an authorised Volvo

workshop should be contacted for repair.

Defective work in the inflatable curtain system

can cause malfunction and result in serious

personal injury.

WARNING

Never hang or attach heavy items onto the

handles in the roof. The hooks are only

designed for light coats and jackets (not for

solid objects such as umbrellas).
Do not screw or install anything onto the car's

headlining, door pillars or side panels. This

could compromise the intended protection.

Volvo recommends only using Volvo genuine

parts that are approved for fitting within these

areas.

WARNING

Leave 10 cm (4 inches) space between the

load and the side windows if the car is loaded

to above the top edge of the door windows.

Otherwise, the intended protection of the

inflatable curtain, which is concealed in the

headlining, may be compromised.

WARNING

The inflatable curtain is a supplement to the

seatbelts. Always use a seatbelt.

Related information

•

SAFETY

}}

Safety mode

Safety mode is a protective state that is trig-
gered when a collision may have damaged any
of the car's vital functions, such as the fuel lines,
sensors for any of the safety systems, or the
brake system.

If the car has been in a collision, the message

Safety mode

See Owner's manual

may be

shown on the driver display with a warning sym-
bol as long as the display is not damaged and the
car's electrical system is still in working order.
This message means that the car has reduced
functionality.

WARNING

Never, under any circumstances, attempt to

restart the car if it smells of fuel when the

Safety mode

See Owner's manual

mes-

sage is shown in the driver display. Leave the

car at once.

If the car is in safety mode, it is possible to
attempt to reset the system in order to start and
move the car for a short distance, if in a danger-
ous traffic situation for example.

WARNING

Never attempt to repair your car or reset the

electronics yourself if the car has been in

safety mode. This could result in personal

injury or the car not functioning as normal.

Volvo recommends that engaging an author-

ised Volvo workshop to check and restore the

car to normal status after

Safety mode

See

Owner's manual

has been shown.

WARNING

If the car is in safety mode it must not be

towed. It must be transported from its loca-

tion. Volvo recommends that it is transported

to an authorised Volvo workshop.

Related information

•

Starting/moving the car after safety mode
(p. 73)

•

•

Recovering the car (p. 461)

Starting/moving the car after safety

mode

If the car is in safety mode, it is possible to
attempt to reset the system in order to start and
move the car for a short distance, if in a danger-
ous traffic situation for example.

Starting the car after safety mode

1. Check the general damage situation of the

car and whether any fuel has been leaking.
There must be no smell of fuel either.

If there is only minor damage and a check
has revealed no fuel leaks, starting can be
attempted.

WARNING

Never, under any circumstances, attempt to

restart the car if it smells of fuel when the

Safety mode

See Owner's manual

mes-

sage is shown in the driver display. Leave the

car at once.

2. Turn the start knob clockwise to switch off

the car.

3. Then try to start the car.

> The driver's display shows the message

Car start

System check, wait

while the

car's electronics carry out a systems
check and then try to resume normal sta-
tus. This can take up to one minute.

SAFETY

* Option/accessory.

4. Then try to start the car again when the mes-

sage

Car start

System check, wait

is no

longer shown in the driver's display.

Recovering the car (p. 461)

If the message

Safety mode

See Owner's

manual

is still shown on the display the car

must not be driven or towed but a vehicle
recovery service must then be used instead.
Even if the car appears to be driveable, hid-
den damage may make the car impossible to
control once moving.

Moving the car after safety mode

1. If the driver display shows the message

Normal mode

The car is now in normal

mode

after a start attempt, the car can be

carefully moved if standing in a dangerous
position.

2. Do not move the car further than necessary.

WARNING

If the car is in safety mode it must not be

towed. It must be transported from its loca-

tion. Volvo recommends that it is transported

to an authorised Volvo workshop.

Related information

•

Safety mode (p. 73)

•

Child safety

Volvo has child safety equipment (child seats,
booster cushions and attachment devices)
which is designed for fitting in this particular car.

Using Volvo's child safety equipment, the opti-
mum conditions are obtained for the child to
travel safely in the car. In addition, the child safety
equipment fits well and is simple to use.

Children of all ages and sizes must always sit
correctly secured in the car. Never allow a child to
sit on the knee of a passenger.

Volvo recommends that children travel in rear-
facing child seats until as late an age as possible,
at least up to 3-4 years of age, and then in front-
facing booster cushions/child seats until the
child is 140 cm tall.

Legal provisions about the type of child seat
that must be used for children of different
ages and heights vary from country to coun-
try. Check what does apply.

In the event of questions when fitting child
safety products, contact the manufacturer for
clearer instructions.

Related information

•

•
