Volvo XC60 Twin Engine (2019 year). Manual - part 15

KEY, LOCKS AND ALARM

* Option/accessory.

257

Alternative unlocking method

Alternative unlocking method using side door opening
handle

–

Pull either of the side door inside opening
handles and release.
> Depending on the remote key settings,

either all doors will be unlocked or just the
selected door will be unlocked and
opened.

To change this setting, tap

Settings

My Car

Locking

Remote and

Interior Unlock

in the Top view of the

center display.

Locking using the front door buttons

–

Press the

button (both front doors must

be closed).
> All doors and the tailgate will lock.

Locking using the rear door button*

Button with indicator light for locking/unlocking in rear
door.

The lock buttons in the rear doors only lock/
unlock that particular door.

Unlocking the rear door

1. Pull the opening handle to unlock the rear

door.

2. Pull the opening handle again to open the

rear door

Related information

•

Settings for remote and inside door unlock
(p. 241)

•

Unlocking the tailgate from inside the vehicle
(p. 258)

•

Activating and deactivating child safety locks
(p. 258)

The illustration is generic - details may vary according to vehicle model.

Provided the child safety lock is not activated.

KEY, LOCKS AND ALARM

* Option/accessory.

258

Unlocking the tailgate from inside

the vehicle

The tailgate can be locked from the inside using
a button on the dashboard.

Press the

button on the dashboard.

> The tailgate will unlock and can be

opened from the outside by pressing the
rubberized pressure plate on the handle.

2. With the optional power tailgate* -

Press and hold the

button on the dash-

board.
> The tailgate will open.

Related information

•

Locking and unlocking from inside the vehi-
cle (p. 256)

•

Opening and closing the power tailgate*
(p. 260)

Activating and deactivating child

safety locks

Child safety locks help prevent children from
opening the rear doors from inside the vehicle.
There is an electric safety lock* and a manual
safety lock.

Activating and deactivating electric
child safety locks*

The electric child safety lock can be activated
and deactivated in any ignition mode higher than
0. The lock can be activated and deactivated up
to 2 minutes after the ignition is turned off if no
door has been opened.

Button for electric activation and deactivation.

1. Turn on the ignition and select any ignition

mode higher than 0.

KEY, LOCKS AND ALARM

259

2. Press the button on the driver's door control

panel.
> The message

Rear child lock

Activated

will be shown in the instrument panel and
the indicator light will illuminate to show
that the child safety locks are activated.

When the electric child safety locks are activated:

•

the rear windows can only be opened using
the driver's door control panel

•

the rear doors cannot be opened from the
inside.

To deactivate the child safety locks:

–

Press the button on the driver's door control
panel.
> The message

Rear child lock

Deactivated

will be shown in the instru-

ment panel and the indicator light will go
out to show that the child safety locks are
deactivated.

When the ignition is switched off, the current set-
ting will be saved. If the child safety locks were
activated when the ignition was switched off, they
will remain activated the next time the ignition is
started.

Symbol

Message

Meaning

Rear child
lock

Acti-

vated

The child safety
locks are acti-
vated.

Rear child
lock

Deacti-

vated

The child safety
locks are deacti-
vated.

Activating and deactivating manual
child safety locks

Manual child safety lock (this is not the manual door
lock).

–

Use the detachable key blade in the remote
key to turn the control.

The door cannot be opened from the inside.

The door can be opened from both the out-
side and the inside.

NOTE

•

The door's knob control only locks that
specific door, not both rear doors simulta-
neously.

•

There are no manual child safety locks on
models equipped with electronic child
safety locks.

Related information

•

Locking and unlocking from inside the vehi-
cle (p. 256)

•

Detachable key blade (p. 248)

KEY, LOCKS AND ALARM

* Option/accessory.

260

Automatic locking when driving

The doors and tailgate will automatically lock
when the vehicle begins to move.

Related information

•

Locking and unlocking from inside the vehi-
cle (p. 256)

Opening and closing the power

tailgate*

The tailgate can be opened and closed automat-
ically with the optional power tailgate.

Opening

To open the power tailgate, do one of the follow-
ing:

–

Press and hold the

button on the

remote key until the tailgate begins to open.

–

Press and hold the

button on the dash-

board until the tailgate begins to open.

–

Press lightly on the tailgate's outside handle.

KEY, LOCKS AND ALARM

}}

* Option/accessory.

261

–

Move your foot in a kicking motion* under the
rear bumper.

Closing

To close

the power tailgate, do one of the fol-

lowing:

–

Press the

button on the lower edge of

the tailgate to close.

> The tailgate will close automatically – the

tailgate will remain unlocked.

NOTE

•

The button remains active 24 hours after
the tailgate was opened. After this time,
the tailgate must be closed manually.

•

If the tailgate has been open for more than
30 minutes, it will automatically close
slowly.

–

Press and hold the

button on the

remote key.
> The tailgate closes automatically and an

audible signal sounds – the tailgate will
remain unlocked.

–

Press and hold the

button on the dash-

board.
> The tailgate closes automatically and an

audible signal sounds – the tailgate will
remain unlocked.

–

Move your foot in a kicking motion* under
the rear bumper.
> The tailgate closes automatically and an

audible signal sounds – the tailgate will
remain unlocked.

Vehicles equipped with keyless locking and unlocking (Passive Entry*) have a button for closing and a button for closing and locking.

KEY, LOCKS AND ALARM

* Option/accessory.

262

Closing and locking

–

Press the

button on the lower edge of

the tailgate to close and simultaneously lock
both the tailgate and doors (all doors must
be closed in order to lock).
> The tailgate closes automatically – the

tailgate and doors lock, and the alarm* is
armed.

NOTE

•

One of the vehicle's remote keys must be
within range for locking and unlocking to
be possible.

•

When the keyless locking or closing* func-
tions are used, three audible signals will
sound if the key is not detected close
enough to the tailgate.

CAUTION

When operating the tailgate manually, open
and close it slowly. If you encounter resis-
tance, do not use force. This could lead to
damage and loss of function.

Interrupting opening or closing

Interrupt opening or closing by doing one of the
following:

•

Press the button on the dashboard.

•

Press the button on the remote key.

•

Press the close button on the underside of
the tailgate.

•

Press the rubberized pressure plate on the
underside of the tailgate's outer handle.

•

Using a foot movement*.

Tailgate movement is interrupted and stops. The
tailgate can then be opened or closed manually.

If the tailgate stops near the closed position, it
will open the next time it is activated.

Pinch protection

If anything obstructs the tailgate with enough
force to prevent it from opening or closing, pinch
protection will be activated.

•

When opening - the tailgate will stop moving
and an audible signal will sound.

•

When closing - the tailgate will stop, a long
audible signal will sound and the tailgate will
return to the programmed maximum opening
position.

WARNING

Be aware of the risk of serious injury when

operating the tailgate. Before opening/clos-

ing, make sure that no one is in the path of

the tailgate who could be injured by its move-

ment.
Always operate the tailgate with caution.

Preloaded springs

Preloaded springs for the power tailgate.

WARNING

Do not attempt to open or access the preloa-

ded springs in the power tailgate struts. They

are preloaded with high pressure and can

cause injury if opened.

Vehicles equipped with keyless locking and unlocking (Passive Entry*) have a button for closing and a button for closing and locking.

KEY, LOCKS AND ALARM

* Option/accessory.

263

Related information

•

Setting a maximum height for the power tail-
gate* (p. 263)

•

Foot movement tailgate operation* (p. 264)

•

Remote key range (p. 242)

Setting a maximum height for the

power tailgate*

The tailgate can be set to stop opening at a cer-
tain height, for example if the tailgate needs to
be opened in a garage with a low ceiling.

Setting maximum opening height:

1. Open the tailgate to the desired opening

height.

NOTE

It is not possible to program an opening posi-
tion lower than half-open tailgate.

2. Press the

button on the lower edge of

the tailgate and hold for at least 3 seconds.
> Two brief audio signals will sound to indi-

cate that the position has been stored.

Resetting to maximum opening position:

–

Move the tailgate manually to its highest
possible position and press the

button

on the tailgate for at least 3 seconds.
> Two audio signals will sound to indicate

that the stored position has been erased.
The tailgate can then be opened to its
maximum position.

NOTE

•

If the system has been working continu-
ously for a prolonged period of time, it will
be switched off to avoid overload. It can
be used again after approximately
2 minutes.

Related information

•

Opening and closing the power tailgate*
(p. 260)

KEY, LOCKS AND ALARM

* Option/accessory.

264

Foot movement tailgate operation*

To make it easier to operate the tailgate when
your hands are full, it can be opened and closed
by moving your foot in a forward kicking motion
under the rear bumper.

The sensor is located to the left of center under the rear
bumper

One of the vehicle's remote keys must be within
range behind the vehicle (approx. 1 meter (3
feet)) for opening and closing to be possible. This
applies even if the vehicle is unlocked in order to
prevent the trunk lid from inadvertently opening
e.g. at a car wash.

Foot movement operation

Kicking motion within the sensor's activation area.

–

Make one slow forward kicking motion with
your foot under the left section of the rear
bumper. Take a step back. Do not touch the
bumper.
> A brief audible signal will be heard when

opening or closing is activated - the tail-
gate will open/close.

If the tailgate is open, it will close

when

the foot motion sensor is activated.

If several opening attempts have been made
without the remote key in range behind the vehi-
cle, foot movement operation will not be available
for a short period of time.

Do not keep your foot under the vehicle in a kick-
ing motion. This may prevent activation.

Interrupting opening or closing with a foot
movement
–

Make one slow forward kicking motion while
the tailgate is opening or closing to stop its
movement.

The remote key does not need to be within range
of the vehicle to interrupt opening or closing.

If the tailgate stops near the closed position, it
will open the next time it is activated.

NOTE

There is a risk of reduced or lost function if
there are large amounts of snow, ice, dirt, etc.
on the rear bumper. Make sure to keep the
bumper clean.

NOTE

Please note that the system could be inadver-
tently activated in a car wash or similar if the
remote key is within range.

Vehicle with skid plate accessory*

If the vehicle is equipped with skid plate, the sen-
sor is located towards the left corner of the
bumper.

If the vehicle is equipped with skid plate*, the sensor is located towards the left corner of the bumper.

Applies to vehicles with power tailgate*.

KEY, LOCKS AND ALARM

* Option/accessory.

265

To activate opening and closing using a foot
movement on a vehicle with skid plate, make a
kicking motion from the side of the vehicle. One
of the vehicle's remote keys must be within range
(approx. 1 meter (3 feet)) for opening and closing
to be possible.

Kicking motion within the sensor's activation area.

Related information

•

Keyless and touch-sensitive surfaces*
(p. 252)

•

Opening and closing the power tailgate*
(p. 260)

•

Remote key range (p. 242)

Private Locking

The tailgate can be locked using the private
locking function to prevent it from being opened,
e.g. when the vehicle is left at a workshop or
with a valet.

The function button for private
locking is located in the center
display's Function view.
Depending on the current sta-
tus of the lock,

Private

Locking Unlocked

Private

Locking Locked

will be dis-

played.

Related information

•

Activating and deactivating private locking
(p. 266)

KEY, LOCKS AND ALARM

* Option/accessory.

266

Activating and deactivating private

locking

Private locking is activated using the function
button in the center display and a PIN code.

NOTE

For the valet lock function to be activated the
car must be in at least ignition mode I.

Entering security code before initial use

The first time the function is used, a security
code must be selected. This code can then be
used to deactivate private locking if the selected
PIN code has been lost or forgotten. The security
code functions as a PUK (security) code for all
PIN codes used for private locking.

Save the security code in a safe place.

To create a security code:

1. Tap the button for private locking in Function

view.

> A pop-up window will appear.

2. Enter your security code.

> The security code is saved. The private

locking function is now ready for activa-
tion.

If the system has been reset, the above proce-
dure will need to be repeated.

Activating private locking

1. Tap the button for private locking in Function

view.

> A pop-up window will appear.

2. Enter the code you would like to use to

unlock the tailgate and tap

Confirm

> The tailgate will lock. A green indicator

light will illuminate next to the button in
Function view to confirm locked status.

Deactivating private locking

1. Tap the button for private locking in Function

view.

> A pop-up window will appear.

2. Enter the code used for locking and tap

Confirm

> The tailgate will unlock. The green indica-

tor light next to the button in Function
view will go out to confirm unlocked sta-
tus.

NOTE

If you have forgotten or lost your PIN code or
if the PIN code has been entered incorrectly
more than three times, the security code can
be used to deactivate private locking.

NOTE

If private locking is activated and the vehicle
is unlocked using Volvo On Call* or the Volvo
On Call* app, private locking will be deacti-
vated automatically.

KEY, LOCKS AND ALARM

}}

267

Related information

•

Private Locking (p. 265)

Alarm

The alarm emits sound and light signals if any-
one without a valid remote key attempts to break
into the vehicle or interferes with the start battery
or alarm siren.

When armed, the alarm will be triggered if:

•

the hood, tailgate or any door is opened.

•

a battery cable is disconnected.

•

the alarm siren is disconnected.

Alarm signals

The following occurs if the alarm is triggered:

•

A siren will sound for 30 seconds or until the
alarm is turned off.

•

All turn signals will flash for 5 minutes or
until the alarm is turned off.

If the reason the alarm was triggered is not recti-
fied, the alarm cycle will repeat up to 10 times

Alarm indicator

A red indicator light on the dashboard shows the
status of the alarm:

•

Indicator off - the alarm is disarmed.

•

Indicator flashes once every two seconds -
the alarm is armed.

•

The indicator flashes quickly after the alarm
has been disabled for up to 30 seconds or
until the ignition is put in I mode – the alarm
has been triggered.

Certain markets only.

KEY, LOCKS AND ALARM

* Option/accessory.

268

In the event of alarm system failure

If a problem is detected in the alarm
system, a symbol and the message

Alarm system failure

Service

required

will appear in the instrument

panel. Contact a workshop - an authorized Volvo
workshop is recommended.

NOTE

Do not attempt to repair or alter any of the
components in the alarm system yourself. Any
such attempt could affect the terms and con-
ditions of your insurance policy.

Related information

•

Arming and disarming the alarm (p. 268)

Arming and disarming the alarm

The alarm is armed when the vehicle is locked.

Arming the alarm

Lock and arm the vehicle by:

•

pressing the lock button on the remote key

•

touch the marked surface on the outside of
the door handle or the rubberized pressure
plate on the tailgate

If the vehicle is equipped with both keyless lock-
ing/unlocking* and power tailgate*, the button

on the lower edge of the tailgate can also

be used to lock and arm the vehicle.

A red LED light on the dashboard will flash every other
second when the vehicle is locked and the alarm is
armed.

Disarming the alarm

Unlock and disarm the vehicle alarm by:

•

pressing the unlock button on the remote
key

•

grip a door handle or press the tailgate's rub-
berized pressure plate

Only vehicles with keyless locking and unlocking* (Passive Entry).

KEY, LOCKS AND ALARM

269

Disarming the alarm without a functioning
remote key

The vehicle can be unlocked and disarmed even
if the remote key is not functioning, e.g. if the
battery is discharged.

1. Open the driver's door using the detachable

key blade.
> This will trigger the alarm.

Location of the backup key reader in the cup holder.

2. Place the remote key on the key symbol in

the backup reader in the tunnel console's
cup holder.

3. Turn the start knob clockwise and release.

> The alarm will be disarmed.

Turning off a triggered alarm

–

Press the unlock button on the remote key
or put the ignition into mode I by turning the
start knob clockwise and then releasing it.

NOTE

•

Remember that the alarm is armed when
the vehicle is locked.

•

The alarm will be triggered if any of the
doors is opened from the inside.

Automatically arming and disarming the
alarm

Automatically arming the alarm helps prevent
inadvertently leaving the vehicle without alarm
protection.

If the vehicle is unlocked using the remote key
(and the alarm is disarmed) but none of the
doors or tailgate are opened within two minutes,
the alarm will be automatically rearmed. The vehi-
cle will also re-lock.

On some markets, the alarm will be automatically
armed following a slight delay after the driver's
door has been opened and closed without being
locked.

To change this setting:

1. Tap

Settings

in the center display's Top

view.

2. Tap

My Car

Locking

3. Select

Passive Arming Deactivation

temporarily deactivate the function.

Related information

•

Alarm (p. 267)

DRIVER SUPPORT

DRIVER SUPPORT

* Option/accessory.

272

Driver support systems

The vehicle is equipped with a number of driver
support systems that can provide the driver with
active or passive assistance in various situations.

The systems can, for example, help the driver:

•

maintain a set speed

•

maintain a set time interval to the vehicle
ahead

•

help prevent a collision by warning the driver
and applying the brakes

•

park the vehicle.

Some of the systems are standard and others are
options. This also varies from market to market.

Related information

•

Speed-dependent steering wheel resistance
(p. 272)

•

Electronic Stability Control (p. 273)

•

Stability system Roll Stability Control
(p. 273)

•

Speed limiter (p. 277)

•

Automatic Speed Limiter (p. 281)

•

Cruise control (p. 285)

•

Distance Alert* (p. 290)

•

Adaptive Cruise Control* (p. 294)

•

Pilot Assist (p. 310)

•

Radar sensor (p. 326)

•

Camera (p. 331)

•

City Safety™ (p. 335)

•

Rear Collision Warning (p. 349)

•

BLIS* (p. 350)

•

Cross Traffic Alert* (p. 355)

•

Road Sign Information* (p. 359)

•

Driver Alert Control (p. 365)

•

Lane Keeping Aid (p. 367)

•

Steering assistance at risk of collision
(p. 375)

•

Park Assist* (p. 385)

•

Park Assist Camera* (p. 391)

•

Park Assist Pilot* (p. 401)

Speed-dependent steering wheel

resistance

Speed-dependent power steering increases the
steering wheel resistance in pace with the vehi-
cle's speed to give the driver an enhanced feel-
ing of control and stability.

Steering may feel stiffer on highways. When
parking and at low speeds, it will be easier to
move the steering wheel.

NOTE

In some situations, the power steering may
become too hot and require temporary cool-
ing – during such time the power steering will
work at reduced output and the steering
wheel may feel more difficult to move.

In parallel with the temporarily reduced steer-
ing assistance, the driver display shows a
message as well as a STEERING WHEEL
symbol.

WARNING

While the power steering is working at

reduced power, the driver support functions

and systems with steering assistance are not

available.
In such a situation, the driver display shows

the

Power steering failure

message, com-

bined with a STEERING WHEEL symbol.

Content .. 13 14 15 16 ..
