Volvo V40 (2018 year). Manual - part 23

SPECIFICATIONS

395

Fuel tank - volume

Fuel tank volume for each respective engine
alternative can be read in the table.

V40

Engine

Volume (litres)

Prescribed grade

Petrol

approx. 62

Fuel - petrol (p. 297)

Diesel

approx. 62

(approx. 40

)

Fuel - diesel (p. 298)

Option for D2 (D4204T8) with manual gearbox.

Applies to D2 (D4204T8) with manual gearbox.

Related information

•

Filling up with fuel (p. 296)

•

Engine specifications (p. 388)

SPECIFICATIONS

396

Air conditioning, fluid - volume and

grade

The climate control system in the car uses a
refrigerant, either R1234yf or R134a, depend-
ing on market. Information about which refriger-
ant the car's climate control system uses can be
seen on a decal, located on the inside of the
bonnet.

Prescribed grades and volumes of fluids and
lubricants in the air conditioning system can be
read in the tables below.

A/C decal

Decal for R134a

The label is fitted on the inside of the bonnet.

Decal for R1234yf

The label is fitted on the inside of the bonnet.

Symbol explanation R1234yf

Symbol

Meaning

Caution

Mobile air conditioning system
(MAC)

Lubricant type

Symbol

Meaning

A trained and certified technician is
required in order to service the
mobile air conditioning system
(MAC)

Flammable refrigerants

Refrigerant

Cars with refrigerant R134a

Weight

Prescribed grade

625 g

R134a

WARNING

The air conditioning system contains pressur-

ised refrigerant R134a. This system must only

be serviced and repaired by an authorised

workshop.

SPECIFICATIONS

397

Cars with refrigerant R1234yf

Weight

Prescribed grade

575 g

R1234yf

WARNING

The air conditioning system contains pressur-

ised refrigerant R1234yf. In accordance with

SAE J2845 (Technician Training for Safe

Service and Containment of Refrigerants

Used in Mobile A/C System), service and

repair of the refrigerant system must only be

performed by trained and certified technicians

in order to ensure the safety of the system.

Compressor oil

Volume

Prescribed grade

60 ml

PAG oil

Evaporator

IMPORTANT

The A/C system's evaporator must never be
repaired or replaced with a previously used
evaporator. A new evaporator must be certi-
fied and labelled in accordance with SAE
J2842.

Related information

•

Climate control system - fault tracing and
repair (p. 347)

SPECIFICATIONS

398

Fuel consumption and CO2

emissions

Fuel consumption in a vehicle is measured in
litres per 100 km and CO2 emissions in grams
CO2 per km.

Explanation

gram CO

/km

litre/100 km

urban driving

extra-urban driving

combined driving

manual gearbox

Automatic gearbox

NOTE

If the consumption and emission data is miss-
ing then it is included in the enclosed supple-
ment.

NOTE

Not all engines are available in all markets.

V40

(B4204T38)

167

7.3

104

4.6

127

5.6

(B4204T38)

163

7.2

100

4.4

123

5.4

(B4154T5)

170

7.3

106

4.5

129

5.5

(B4154T5)

168

7.2

101

4.4

125

5.4

T3 (B4204T37)

167

7.3

104

4.6

127

5.6

T3 (B4154T4)

170

7.3

106

4.5

129

5.5

SPECIFICATIONS

}}

399

V40

T4 (B4204T19)

167

7.3

104

4.6

127

5.6

T4 (B4204T19)

165

7.2

107

4.6

128

5.5

T5 (B4204T11)

185

7.9

110

4.8

137

5.9

(D4204T8)

105

4.0

3.3

3.6

(D4204T8)

3.7

3,2

3.4

(D4204T8)

120

4.6

3.6

104

3.9

(D4204T8)

115

4.4

3.4

3.8

(D4204T9)

112

4.3

3.6

101

3.8

(D4204T9)

107

4.0

3.4

3.6

(D4204T9)

126

4.8

3.8

108

4.1

(D4204T9)

122

4.7

3.6

104

4.0

(D4204T14)

110

4.2

3.6

3.8

SPECIFICATIONS

400

V40

(D4204T14)

108

4.1

3.5

3.7

(D4204T14)

132

5.0

3.7

109

4.2

(D4204T14)

129

4.9

3.5

106

4.0

Does not apply to the low-emission variant.

This only applies to the low-emissions variant.

Fuel consumption

Fuel consumption and emission values in the
table above are based on specific EU driving
cycles (see below), that apply to cars with kerb
weight in the basic version and without extra
equipment. The car's weight may increase
depending on equipment. This, as well as how
heavily the car is loaded, increases fuel consump-
tion and carbon dioxide emissions.

There are several reasons for increased fuel con-
sumption compared with the table's values.
Examples of this are:

•

If the car is equipped with extra equipment
that affects the car's weight.

•

The driver's driving style.

•

If the customer chooses wheels other than
those fitted as standard on the model's basic
version then rolling resistance may increase.

•

High speed results in increased wind resis-
tance.

•

Fuel quality, road and traffic conditions,
weather and the condition of the car.

A combination of the above-mentioned examples
can result in significantly increased consumption.

Large deviations in fuel consumption may arise in
a comparison with the EU driving cycles (see
below) which are used in the certification of the
car and on which the consumption figures in the
table are based. For further information, please
refer to the regulations referred to.

Consumption is higher and power output lower
for fuel with an octane rating of 91 RON.

NOTE

Extreme weather conditions, driving with a
trailer or driving at high altitudes in combina-
tion with fuel quality are factors that consider-
ably increase the car's fuel consumption.

SPECIFICATIONS

401

EU driving cycles

Official fuel consumption figures are based on
two standardised driving cycles in a laboratory
environment ("EU driving cycles") all in accord-
ance with EU Regulation no 692/2008 and
715/2007 (Euro 5 / Euro 6) and UN ECE
Regulation no 101. Since the driving cycles are
also used for quality control, there are significant
requirements for repeatability of the tests. For
this reason the tests are carried out under close
scrutiny and only with the car's basic functions
(e.g. air conditioning, radio, etc. switched off). As
a consequence of this the results from the official
figures are not obviously representative of what
the customer sees during actual usage.

The regulations cover the driving cycles for
"Urban driving" and "Extra-urban driving":

•

Urban driving - the measurement starts with
cold starting the engine. The driving is simu-
lated.

•

Extra-urban driving - the car is accelerated
and braked at speeds between 0-120 km/h
(0-75 mph). The driving is simulated.

Cars with manual gearbox are started in 2nd
gear.

The official value for combined driving, which is
reported in the table, is a combination of the
results from the "Urban driving" and "Extra-urban
driving" driving cycles, in accordance with legal
requirements.

The exhaust gases are collected in order to
extrapolate the carbon dioxide emissions (CO

emissions) during the two driving cycles. These
are then analysed and give the value for CO

emissions.

Related information

•

Economical driving (p. 301)

•

Fuel - petrol (p. 297)

•

Fuel - diesel (p. 298)

•

Weights (p. 385)

SPECIFICATIONS

402

Wheels and tyres - approved

dimensions

In certain countries not all approved dimensions
are indicated by the registration document or
other documents. The following table shows all

approved combinations of wheel rims and tyres.
Information on engine and type of gearbox is
required to read the table. For information with
respect to these details, see Type designations
(p. 380).

For information on the minimum permitted load
index (LI) and the minimum permitted speed rat-
ing (SS), see Load index and speed rating
(p. 404).
✓ = Approved

V40

Engine

man/

aut

205/55R16

7x16x50

6,5x16x52,5

205/50R17

7x17x50

7x17x52.5

225/45R17

7,5x17x52,5

7x17x50

225/40R18

7,5x18x52,5

235/35R19

8x19x50

B4154T5

aut

✓

B4154T5

aut

✓

B4204T38

man

✓

B4204T38

man

✓

B4154T4

aut

✓

B4204T37

man

✓

B4204T19

man/aut

✓

B4204T11

aut

✓

B4204T41

aut

✓

D4204T8

man/aut

✓

D4204T8

man/aut

✓

D4204T9

man/aut

✓

D4204T9

man/aut

✓

SPECIFICATIONS

403

V40

Engine

man/

aut

205/55R16

7x16x50

6,5x16x52,5

205/50R17

7x17x50

7x17x52.5

225/45R17

7,5x17x52,5

7x17x50

225/40R18

7,5x18x52,5

235/35R19

8x19x50

D4204T14

man/aut

✓

D4204T14

man/aut

✓

Only approved for cars equipped with 19" tyres from the factory.

This only applies to the low-emissions variant.

Does not apply to the low-emission variant.

Related information

•

Tyres - dimensions (p. 317)

•

Tyres - speed ratings (p. 318)

•

Tyres - load index (p. 318)

•

Wheel and wheel rim dimensions (p. 317)

SPECIFICATIONS

404

Load index and speed rating

The table below shows the minimum permitted
load index (LI) and speed rating (SS). Informa-

tion on engine and type of gearbox is required to
read the table. For information with respect to
these details, see Type designations (p. 380).

V40

Engine

man/

aut

Minimum permitted load index (LI)

Minimum permitted speed rating (SS)

B4154T5

aut

B4204T38

man

B4154T4

aut

B4204T37

man

B4204T19

man/aut

B4204T11

aut

B4204T41

aut

D4204T8

man/aut

D4204T9

man/aut

D4204T14

man/aut

The tyre's load index must be at least equal to or greater than indicated in the table.

The tyre's speed rating must be at least equal to or greater than indicated in the table.

Related information

•

Wheels and tyres - approved dimensions
(p. 402)

•

Tyres - approved tyre pressures (p. 405)

•

Tyres - load index (p. 318)

•

Tyres - speed ratings (p. 318)

SPECIFICATIONS

405

Tyres - approved tyre pressures

Approved tyre pressures for each respective
engine alternative can be read in the table.

V40

Engine

Tyre size

Speed

(km/h)

Load, 1-3 persons

Max. load

ECO pressure

Front

(kPa)

Rear

(kPa)

Front

(kPa)

Rear

(kPa)

Front/rear

(kPa)

All engines

205/55 R16

205/50 R17

225/45 R17

0 - 160

230

260

260 (280

)

160+

250

300

280

225/40 R18

235/35 R19

0 - 160

230

260

160+

270

320

300

Temporary Spare Tyre

max. 80

420

Economical driving.

In certain countries there is the "bar" unit beside the SI unit "Pascal": 1 bar = 100 kPa.

0 - 100 mph

Only applies to 16" wheels for D2/D4 manual, low emission variant.

100+ mph

max 50 mph

NOTE

All engines, tyres or combinations of these
are not always available in all markets.

Related information

•

Wheels and tyres - approved dimensions
(p. 402)

•

Tyres - dimensions (p. 317)

•

Tyres - air pressure (p. 316)

•

Type designations (p. 380)
