593

9-1. Specifications

9

Ve
hicle

 spe
cifi

cati

ons



4WD models

*

1

: Unladen vehicle

*

2

: P255/70R18 tires

*

3

: P275/65R18 tires

*

4

: P275/55R20 tires

Cab type

Double Cab

CrewMax

Bed type

Standard

Long

Short

Overall length

228.9 in. (5815

mm)

247.8 in.

(6295 mm)

228.9 in.

(5815 mm)

Overall width

79.9 in. (2030 mm)

Overall
height

*

1

76.3 in.

(1940 mm)

*

2

76.1 in.

(1935 mm)

*

2

76.1 in.

(1935mm)

*

3,

*

4

75.9 in.

(1930mm)

*

3,

*

4

Wheelbase

145.6 in. (3700

mm)

164.5 in.

(4180 mm)

145.6 in.

(3700 mm)

Front tread

67.9 in. (1725 mm)

Rear tread

67.9 in. (1725 mm)

594

9-1. Specifications



Double Cab models

Vehicle capacity weight

Model code

*

1

Engine

Driving

system

Bed type

Vehicle capacity

weight

(Occupants + lug-

gage)

UPK51L-

CRTSKA

1UR-FE

engine

2WD

Standard

1435 lb. (650 kg)

1485 lb. (675 kg)

*

2

UPK56L-

CRTSKA

4WD

1330 lb. (605 kg)

1380 lb. (625 kg)

*

2

USK51L-

CRTSKA

3UR-FE

engine

2WD

1605 lb. (730 kg)

1540 lb. (700 kg)

*

3

1425 lb. (645 kg)

*

4

USK51L-

CRTLKA

1570 lb. (710 kg)

1505 lb. (680 kg)

*

3

1385 lb. (630 kg)

*

4

USK52L-

CHTSKA

Long

1580 lb. (715 kg)

1515 lb. (685 kg)

*

3

1395 lb. (635 kg)

*

4

USK56L-

CRTSKA

4WD

Standard

1500 lb. (680 kg)

1435 lb. (650 kg)

*

3

1320 lb. (600 kg)

*

4

USK56L-

CRTLKA

1485 lb. (675 kg)

1420 lb. (645 kg)

*

3

1300 lb. (590 kg)

*

4

595

9-1. Specifications

9

Ve
hicle

 spe
cifi

cati

ons

*

1

: The model code is indicated on the Certification Label. (



P. 599)

*

2

: Vehicles with towing package (hitch only)

*

3

: Vehicles with towing package

*

4

: Vehicles with towing package and large fuel tank

Model code

*

1

Engine

Driving

system

Bed type

Vehicle capacity

weight

(Occupants + lug-

gage)

USK57L-

CHTSKA

3UR-FE

engine

4WD

Long

1475 lb. (670 kg)

1410 lb. (640 kg)

*

3

1290 lb. (585 kg)

*

4

USK56L-

CRTSGA

3UR-FBE

engine

Standard

1500 lb. (680 kg)

1435 lb. (650 kg)

*

3

1320 lb. (600 kg)

*

4

USK56L-

CRTLGA

1485 lb. (675 kg)

1420 lb. (645 kg)

*

3

1300 lb. (590 kg)

*

4

USK57L-

CHTSGA

Long

1475 lb. (670 kg)

1410 lb. (640 kg)

*

3

1290 lb. (585 kg)

*

4

596

9-1. Specifications



CrewMax models

Model code

*

1

Engine

Driving

system

Bed type

Vehicle capacity

weight

(Occupants + lug-

gage)

UPK51L-

PSTSKA

1UR-FE

engine

2WD

Short

1440 lb. (655 kg)

1405 lb. (635 kg)

*

2

1390 lb. (630 kg)

*

3

1355 lb. (615 kg)

*

6

UPK56L-

PSTSKA

4WD

1330 lb. (605 kg)

1295 lb. (590 kg)

*

2

1280 lb. (580 kg)

*

3

1245 lb. (565 kg)

*

6

USK51L-

PSTSKA

3UR-FE

engine

2WD

1545 lb. (700 kg)

1510 lb. (685 kg)

*

2

1480 lb. (670 kg)

*

4

1360 lb. (615 kg)

*

5

1445 lb. (655 kg)

*

7

1325 lb. (600 kg)

*

8

USK51L-

PSTLKA

1510 lb. (685 kg)

1475 lb. (670 kg)

*

2

1445 lb. (655 kg)

*

4

1330 lb. (600 kg)

*

5

1410 lb. (640 kg)

*

7

1295 lb. (585 kg)

*

8

USK51L-

PSTZKA

1500 lb. (680 kg)

1465 lb. (665 kg)

*

2

1435 lb. (650 kg)

*

4

1315 lb. (595 kg)

*

5

1400 lb. (635 kg)

*

7

1280 lb. (580 kg)

*

8

597

9-1. Specifications

9

Ve
hicle

 spe
cifi

cati

ons

USK56L-

PSTSKA

3UR-FE

engine

4WD

Short

1450 lb. (660 kg)

1415 lb. (640 kg)

*

2

1385 lb. (630 kg)

*

4

1265 lb. (575 kg)

*

5

1350 lb. (610 kg)

*

7

1230 lb. (560 kg)

*

8

USK56L-

PSTLKA

1400 lb. (635 kg)

1365 lb. (620 kg)

*

2

1335 lb. (605 kg)

*

4

1220 lb. (555 kg)

*

5

1300 lb. (590 kg)

*

7

1185 lb. (535 kg)

*

8

USK56L-

PSTZKA

1405 lb. (635 kg)

1370 lb. (620 kg)

*

2

1340 lb. (610 kg)

*

4

1220 lb. (555 kg)

*

5

1305 lb. (590 kg)

*

7

1185 lb. (540 kg)

*

8

Model code

*

1

Engine

Driving

system

Bed type

Vehicle capacity

weight

(Occupants + lug-

gage)

598

9-1. Specifications

*

1

: The model code is indicated on the Certification Label. (



P. 599)

*

2

: Vehicles with electric moon roof

*

3

: Vehicles with towing package (hitch only)

*

4

: Vehicles with towing package

*

5

: Vehicles with towing package and large fuel tank

*

6

: Vehicles with towing package (hitch only) and electric moon roof

*

7

: Vehicles with towing package and electric moon roof

*

8

: Vehicles with towing package, electric moon roof and large fuel tank

USK56L-

PSTSGA

3UR-FBE

engine

4WD

Short

1450 lb. (660 kg)

1415 lb. (640 kg)

*

2

1385 lb. (630 kg)

*

4

1265 lb. (575 kg)

*

5

1350 lb. (610 kg)

*

7

1230 lb. (560 kg)

*

8

USK56L-

PSTLGA

1400 lb. (635 kg)

1365 lb. (620 kg)

*

2

1335 lb. (605 kg)

*

4

1220 lb. (555 kg)

*

5

1300 lb. (590 kg)

*

7

1185 lb. (535 kg)

*

8

USK56L-

PSTZGA

1405 lb. (635 kg)

1370 lb. (620 kg)

*

2

1340 lb. (610 kg)

*

4

1220 lb. (555 kg)

*

5

1305 lb. (590 kg)

*

7

1185 lb. (540 kg)

*

8

Model code

*

1

Engine

Driving

system

Bed type

Vehicle capacity

weight

(Occupants + lug-

gage)

599

9-1. Specifications

9

Ve
hicle

 spe
cifi

cati

ons

■

Vehicle identification number
The  vehicle  identification  number  (VIN)  is  the  legal  identifier  for
your  vehicle.  This  is  the  primary  identification  number  for  your
Toyota. It is used in registering the ownership of your vehicle.
This number is stamped on the
top left of the instrument panel.

This number is also on the Cer-
tification Label.

■

Engine number
The engine number is stamped on the engine block as shown.

Vehicle identification



1UR-FE engine



3UR-FE

and

3UR-FBE

engines

600

9-1. Specifications

Engine

Model

1UR-FE, 3UR-FE, 3UR-FBE

Type

8-cylinder V-type, 4-cycle, gasoline

Bore and stroke



1UR-FE engine
3.70

 3.27 in. (94.0  83.0 mm)



3UR-FE and 3UR-FBE engines
3.70

 4.02 in. (94.0  102.0 mm)

Displacement



1UR-FE engine
281.2 cu.in. (4608 cm

3

)



3UR-FE and 3UR-FBE engines
345.6 cu.in. (5663 cm

3

)

Drive belt tension

Automatic adjustment

Valve clearance
(engine cold)

Automatic adjustment

Fuel

Engine

Model

1UR-FE  and  3UR-FE
engines

3UR-FBE engine

Type

Gasoline engine

Flex-fuel engine

Fuel type

Unleaded gasoline only

Unleaded gasoline,

E85, or a blend of the

two fuels

Octane rating
(Unleaded gasoline)

87 (Research Octane Number 91) or higher

Ethanol percentage
(E85)

—

85% or less

Fuel tank capacity
(Reference)

Standard fuel tank:

26.4 gal. (100.0 L, 22.0 Imp.gal.)

Large fuel tank:

38.0 gal. (144.0 L, 31.7 Imp.gal.)

601

9-1. Specifications

9

Ve
hicle

 spe
cifi

cati

ons

*

: The engine oil capacity is a reference quantity to be used when changing

the engine oil. Warm up and turn off the engine, wait more than 5 minutes,
and check the oil level on the dipstick.

■

Engine oil selection
“Toyota  Genuine  Motor  Oil”  is  used  in  your  Toyota  vehicle.  Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat-
isfy the following grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE  0W-20  is  the  best  choice
for  good  fuel  economy  and
good starting in cold weather.
If  SAE  0W-20  is  not  available,
SAE  5W-20  oil  may  be  used.
However,  it  must  be  replaced
with SAE 0W-20 at the next oil
change.

Lubrication system

Oil capacity
(Drain and refill - reference

*

)

With filter
Without filter

8.5 qt. (8.0 L, 7.0 Imp.qt.)
7.9 qt. (7.5 L, 6.6 Imp.qt.)

Outside temperature

602

9-1. Specifications

Oil viscosity (0W-20 is explained here as an example):

• The 0W in 0W-20 indicates the characteristic of the oil which allows cold

startability. Oils with a lower value before the W allow for easier starting
of the engine in cold weather.

• The 20 in 0W-20 indicates the viscosity characteristic of the oil when the

oil  is  at  high  temperature. An  oil  with  a  higher  viscosity  (one  with  a
higher  value)  may  be  better  suited  if  the  vehicle  is  operated  at  high
speeds, or under extreme load conditions.

How to read oil container label:
The  International  Lubricant
Specification Advisory  Commit-
tee  (ILSAC)  Certification  Mark
is added to some oil containers
to  help  you  select  the  oil  you
should use.

603

9-1. Specifications

9

Ve
hicle

 spe
cifi

cati

ons

Cooling system

Capacity

1UR-FE
engine



Vehicles without towing package
11.4 qt. (10.8 L, 9.5 Imp.qt.)



Vehicles with towing package
12.6 qt. (11.9 L, 10.5 Imp.qt.)

3UR-FE,
3UR-FBE
engines



Vehicles without towing package
11.4 qt. (10.8 L, 9.5 Imp.qt.)



Vehicles with towing package
12.4 qt. (11.7 L, 10.3 Imp.qt.)

Coolant type

Use either of the following.

• “Toyota Super Long Life Coolant”
• Similar  high-quality  ethylene  glycol-

based  non-silicate,  non-amine,  non-
nitrite,  and  non-borate  coolant  with
long-life hybrid organic acid technology

Do not use plain water alone.

Ignition system

Spark plug

Make

DENSO SK20HR11

Gap

0.043 in. (1.1 mm)

NOTICE

■

Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

Electrical system

Battery

Open  voltage  at  68

F

(20

C):

12.6





12.8 V Fully charged

12.2





12.4 V Half charged

11.8



12.0 V Discharged

(Voltage is checked 20 minutes after the engine
and all lights are turned off.)

Charging rates

5 A max.

604

9-1. Specifications

*

: Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at

the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or
an  equivalent  oil  of  matching  quality  to  satisfy  the  above  specification.
Please contact your Toyota dealer for further details.

*

: The fluid capacity is the quantity of reference.

If replacement is necessary, contact your Toyota dealer.

Differential

Oil
capacity

Front (4WD models)

2.2 qt. (2.05 L, 1.8 Imp.qt.)

Rear

1UR-FE engine

4.9 qt. (4.60 L, 4.0 Imp.qt.)

3UR-FE
and
3UR-FBE
engines

Double Cab
models



With standard bed
3.8 qt. (3.60 L, 3.2 Imp.qt.)



With long bed
4.0 qt. (3.75 L, 3.3 Imp.qt.)

CrewMax
models



2WD models
4.0 qt. (3.75 L, 3.3 Imp.qt.)



4WD models
3.8 qt. (3.60 L, 3.2 Imp.qt.)

Oil type and viscosity

*

Toyota  Genuine  Differential
Gear  Oil  LT  75W-85  GL-5  or
equivalent

Automatic transmission

Fluid
capac-
ity

*

1UR-FE engine



2WD models
11.6 qt. (11.0 L, 9.7 Imp.qt.)



4WD models
11.3 qt. (10.7 L, 9.4 Imp.qt.)

3UR-FE
and
3UR-FBE
engines

Vehicles  without
towing package

11.7 qt. (11.1 L, 9.8 Imp.qt.)

Vehicles

with

towing package

12.3 qt. (11.6 L, 10.2 Imp.qt.)

Fluid type

Toyota Genuine ATF WS

605

9-1. Specifications

9

Ve
hicle

 spe
cifi

cati

ons

*

1

: Minimum pedal clearance when depressed with a force of 110 lbf (490 N,

50 kgf) with the engine running.

*

2

: Parking  brake  pedal  travel  when  depressed  with  a  force  of  67.1  lbf

(300 N, 30.6 kgf).

NOTICE

■

Transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause
deterioration in shift quality, locking up of the transmission accompanied by
vibration and, ultimately, damage to the vehicle’s transmission.

Transfer (4WD models)

Oil capacity

1.6 qt. (1.5 L, 1.3 Imp.qt.)

Oil type

Toyota  Genuine Transfer  Gear  oil  LF  or
equivalent

Recommended oil viscosity

SAE 75W

Brakes

Pedal clearance

*

1

4.1 in. (104 mm) Min.

Pedal free play

0.04

 0.24 in. (1  6 mm)

Brake pad wear limit

0.04 in. (1.0 mm)

Parking brake lining wear limit

0.04 in. (1.0 mm)

Parking brake pedal travel

*

2

6 — 9 clicks

Fluid type

FMVSS No. 116 DOT 3 or SAE J1703

Steering

Free play

Less than 1.2 in. (30 mm)

Power steering fluid type Automatic transmission fluid DEXRON

®

 II or III

606

9-1. Specifications



Type A



Type B

Tires and wheels

Tire size

P255/70R18 112T

Tire inflation pressure

(Recommended  cold

tire inflation pressure)

Front tires:

30 psi (210 kPa, 2.1 kgf/cm

2

 or bar)

Rear tires:

33 psi (230 kPa, 2.3 kgf/cm

2

 or bar)

Spare tire:

33 psi (230 kPa, 2.3 kgf/cm

2

 or bar)

Wheel size

18

 8J

Wheel nut torque

Steel wheels:

154 ft·lbf (209 N·m, 21.3 kgf·m)

Aluminum wheels:

97 ft·lbf (131 N·m, 13.4 kgf·m)

Tire size

P275/65R18 114T

Tire inflation pressure

(Recommended  cold

tire inflation pressure)

Front tires:

30 psi (210 kPa, 2.1 kgf/cm

2

 or bar)

Rear tires:

33 psi (230 kPa, 2.3 kgf/cm

2

 or bar)

Spare tire:

33 psi (230 kPa, 2.3 kgf/cm

2

 or bar)

Wheel size

18

 8J

Wheel nut torque

Steel wheels:

154 ft·lbf (209 N·m, 21.3 kgf·m)

Aluminum wheels:

97 ft·lbf (131 N·m, 13.4 kgf·m)

607

9-1. Specifications

9

Ve
hicle

 spe
cifi

cati

ons



Type C



Type D

Tire size

P275/65R18 114T,

P255/70R18 112T (spare tire)

Tire inflation pressure

(Recommended  cold

tire inflation pressure)

Front tires:

30 psi (210 kPa, 2.1 kgf/cm

2

 or bar)

Rear tires:

33 psi (230 kPa, 2.3 kgf/cm

2

 or bar)

Spare tire:

33 psi (230 kPa, 2.3 kgf/cm

2

 or bar)

Wheel size

18

 8J,

18

 8J (spare wheel)

Wheel nut torque

Steel wheels:

154 ft·lbf (209 N·m, 21.3 kgf·m)

Aluminum wheels:

97 ft·lbf (131 N·m, 13.4 kgf·m)

Tire size

P275/55R20 111H,

P255/70R18 112T (spare tire)

Tire inflation pressure

(Recommended  cold

tire inflation pressure)

Front tires:

30 psi (210 kPa, 2.1 kgf/cm

2

 or bar)

Rear tires:

33 psi (230 kPa, 2.3 kgf/cm

2

 or bar)

Spare tire:

33 psi (230 kPa, 2.3 kgf/cm

2

 or bar)

Wheel size

20

 8J,

18

 8J (spare wheel)

Wheel nut torque

Steel wheels:

154 ft·lbf (209 N·m, 21.3 kgf·m)

Aluminum wheels:

97 ft·lbf (131 N·m, 13.4 kgf·m)

608

9-1. Specifications

*

1

: If equipped

*

2

: Vehicles with bulb type headlights

*

3

: Vehicles with LED type headlights

A: HB2 halogen bulbs

B: H16 halogen bulbs

C: Wedge base bulbs (amber)

D: Wedge base bulbs (clear)

E: Double end bulbs

Light bulbs

Light Bulbs

Bulb No.

W

Type

Exterior

Headlights

*

2

HB2

60/55

A

Front  fog  lights  (bulb
type)

*

1

H16

19

B

Front side marker lights

W5W

5

D

Front  turn  signal  lights/
parking lights

*

2

4157NAK

27/8

C

Front turn signal lights

*

3

7444NA

28

C

Rear turn signal lights

921

16

D

Stop/tail  and  rear  side
marker lights

3157KX

27/8

D

Back-up lights

7440

21

D

License plate lights

W5W

5

D

High mounted stoplight and
cargo lamp

921

16

D

Outer foot light

—

5

D

Interior

Vanity lights

7065

5

E

Personal/interior lights

Front
Rear

W5W
W5W

5
5

D
D

Foot well lighting

—

1.4

D
