If you think something is wrong

● Fluid leaks under the vehicle.

(Water dripping from the air conditioning after use is normal.)

● Flat-looking tires or uneven tire wear
● Engine coolant temperature gauge needle continually points higher

than normal.

● Voltmeter continually points higher or lower than normal
● Engine oil pressure gauge continually points lower than normal
● Automatic transmission fluid temperature warning message is dis-

played

● Changes in exhaust sound
● Excessive tire squeal when cornering
● Strange noises related to the suspension system
● Pinging or other noises related to the engine

● Engine misses, stumbling or running roughly
● Appreciable loss of power
● Vehicle pulls heavily to one side when braking
● Vehicle pulls heavily to one side when driving on a level road
● Loss of brake effectiveness, spongy feeling, pedal almost touches

the floor

If you notice any of the following symptoms, your vehicle proba-
bly needs adjustment or repair. Contact your Toyota dealer as
soon as possible.

Visible symptoms

Audible symptoms

Operational symptoms

546

Fuel pump shut off system

Follow the procedure below to restart the engine after the system is
activated.

Turn the engine switch to the “ACC” or “LOCK” position.
Restart the engine.

To minimize the risk of fuel leakage when the engine stalls or
when an airbag inflates upon collision, the fuel pump shut off
system stops supply of fuel to the engine.

NOTICE

■

Before starting the engine
Inspect the ground under the vehicle.
If you find that fuel has leaked onto the ground, the fuel system has been
damaged and is in need of repair. Do not restart the engine.

547

If a warning light turns on or a warning

buzzer sounds

Calmly perform the following actions if any of the warning lights
comes on or flashes. If a light comes on or flashes, but then
goes off, this does not necessarily indicate a malfunction in the
system. However, if this continues to occur, have the vehicle
inspected by your Toyota dealer.

Warning light and warning buzzer list

Warning light

Warning light/Details/Actions

(U.S.A.)

(Canada)

Brake system warning light (warning buzzer)

• Low brake fluid
• Malfunction in the brake system

 Immediately stop the vehicle in a safe place and con-

tact your Toyota dealer.

Charging system warning light

Indicates a malfunction in the vehicle’s charging system

 Immediately stop the vehicle in a safe place and con-

tact your Toyota dealer.

(U.S.A.)

(Canada)

Malfunction indicator lamp

Indicates a malfunction in:
• The electronic engine control system;
• The electronic throttle control system; or
• The electronic automatic transmission control system.

 Have the vehicle inspected by your Toyota dealer

immediately.

SRS warning light

Indicates a malfunction in:
• The SRS airbag system;
• The front passenger occupant classification system; or
• The seat belt pretensioner system

 Have the vehicle inspected by your Toyota dealer

immediately.

548

(U.S.A.)

(Canada)

ABS warning light

Indicates a malfunction in:
• The ABS; or
• The brake assist system

 Have the vehicle inspected by your Toyota dealer

immediately.

Low fuel level warning light



Standard fuel tank
Indicates remaining fuel is approximately 4.0 gal. (15.0 L,
3.3 Imp.gal.) or less



Large fuel tank
Indicates remaining fuel is approximately 3.8 gal. (14.4 L,
3.2 lmp.gal.) or less

 Refuel the vehicle.

Seat belt reminder light (warning buzzer)

Warns the driver and/or front passenger to fasten their
seat belts

 Fasten the seat belt.

If the front passenger’s seat is occupied, the front
passenger’s seat belt also needs to be fastened to
make the warning light (warning buzzer) turn off.

Master warning light

A buzzer sounds and the warning light comes on and
flashes to indicate that the master warning system has
detected a malfunction.

 P. 555

(U.S.A.)

(Canada)

Parking brake warning light (warning buzzer)

Indicates that the parking brake is engaged.

 Release the parking brake.

Warning light

Warning light/Details/Actions

549

Tire pressure warning light

When the light comes on:

Low tire inflation pressure such as

• Natural causes (

P. 552)

• Flat tire (

P. 565)

 Adjust the tire inflation pressure to the specified

level.

The light will turn off after a few minutes. In case

the light does not turn off even if the tire inflation

pressure is adjusted, have the system checked by

your Toyota dealer.

When the light comes on after blinking for 1 minute:

Malfunction in the tire pressure warning system.

 Have the system checked by your Toyota dealer.

Slip indicator

Indicates a malfunction in:
• The VSC system;
• Trailer Sway Control system;
• The TRAC system;
• The hill-start assist control system; or
• The AUTO LSD system.

 Have the vehicle inspected by your Toyota dealer

immediately.

The light will flash when any of the above systems other
than the hill-start assist control are operating.

Warning light

Warning light/Details/Actions

550

: Driver’s seat belt buzzer:

The driver’s seat belt buzzer sounds to alert the driver that his or her seat
belt is not fastened. Once the engine switch is turned to the “ON” or
“START” position, the buzzer sounds for 6 seconds. If the vehicle reaches
a speed of 12 mph (20 km/h), the buzzer sounds once. If the seat belt is
still unfastened after 30 seconds, the buzzer will sound intermittently for 10
seconds. Then, if the seat belt is still unfastened, the buzzer will sound in a
different tone for 20 more seconds.
Front passenger’s seat belt buzzer:

The front passenger’s seat belt buzzer sounds to alert the front passenger
that his or her seat belt is not fastened. The buzzer sounds once if the
vehicle reaches a speed of 12 mph (20 km/h). If the seat belt is sill unfas-
tened after 30 seconds, the buzzer will sound intermittently for 10 seconds.
Then, if the seat belt is still unfastened, the buzzer will sound in a different
tone for 20 more seconds.

: Parking brake engaged warning buzzer:

A buzzer will sound if the vehicle is driven at a speed of approximately
3 mph (5 km/h) or more.

(Flashes or

illuminates)

PCS warning light (If equipped)

Indicates a malfunction in the PCS (Pre-Collision System)
or that the system is temporarily unavailable due to the
vehicle being extremely hot/cold, or dirt around a front
sensor, etc. (

P. 242, 555)

 Follow the instructions displayed on the multi-infor-

mation display. (

P. 242, 555)

If the PCS (Pre-Collision System) or VSC (Vehicle Stability
Control) system is disabled, the PCS warning light will illu-
minate.

 P. 242

(Yellow)

LDA (Lane Departure Alert) indicator (If equipped)

The indicator comes on and a warning message is dis-
played to indicate that the LDA (Lane Departure Alert)
system is not available temporarily or has detected a mal-
function.

 P. 555

Warning light

Warning light/Details/Actions

551

■

SRS warning light
This warning light system monitors the airbag sensor assembly, front impact
sensors, side impact sensors (front door), side impact sensors (rear), driver’s
seat position sensor, driver’s seat belt buckle switch, front passenger occu-
pant classification system (ECU and sensors), “AIR BAG ON” indicator light,
“AIR BAG OFF” indicator light, front passenger’s seat belt buckle switch, seat
belt pretensioners assemblies, airbags, interconnecting wiring and power
sources. (

P. 40)

■

Front passenger detection sensor, seat belt reminder and warning
buzzer

●

If luggage is placed on the front passenger seat, the front passenger detec-
tion sensor may cause the warning light to flash and the warning buzzer to
sound even if a passenger is not sitting in the seat.

●

If a cushion is placed on the seat, the sensor may not detect a passenger,
and the warning light may not operate properly.

■

If the malfunction indicator lamp comes on while driving
First check the following:

●

Is the fuel tank empty?
If it is, fill the fuel tank immediately.

●

Is the fuel tank cap loose?
If it is, tighten it securely.

The light will go off after several driving trips.
If the light does not go off even after several trips, contact your Toyota dealer
as soon as possible.

■

When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level. Push-

ing the tire pressure warning reset switch will not turn off the tire pressure

warning light.

552

■

The tire pressure warning light may come on due to natural causes
The tire pressure warning light may come on due to natural causes such

as natural air leaks and tire inflation pressure changes caused by tem-

perature. In this case, adjusting the tire inflation pressure will turn off the

warning light (after several minutes).

■

When a tire is replaced with a spare tire
The temporary spare tire is not equipped with a tire pressure warning

valve and transmitter. If a tire goes flat, the tire pressure warning light will

not turn off even though the flat tire has been replaced with the temporary

spare tire. Replace the temporary spare tire with the repaired tire and

adjust the tire inflation pressure. The tire pressure warning light will go off

after several minutes.

■

Conditions that the tire pressure warning system may not function

properly
P. 501

■

If the tire pressure warning light frequently comes on after blinking

for 1 minute
If the tire pressure warning light frequently comes on after blinking for 1

minute when the engine switch is turned to “ON” position, have it checked

by your Toyota dealer.

■

Warning buzzer
In some cases, the buzzer may not be heard because of noisy place or an
audio sound.

553

WARNING

■

If both the ABS and the brake system warning lights remain on
Stop your vehicle in a safe place immediately and contact your Toyota
dealer. The vehicle will become extremely unstable during braking, and the
ABS system may fail, which could cause an accident resulting in death or
serious injury.

■

If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could cause a
loss of vehicle control and result in death or serious injury.

●

Stop your vehicle in a safe place as soon as possible. Adjust the tire infla-
tion pressure immediately.

●

If the tire pressure warning light comes on even after tire inflation pressure
adjustment, it is probable that you have a flat tire. Check the tires. If a tire
is flat, change it with the spare tire and have the flat tire repaired by the
nearest Toyota dealer.

●

Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you
could lose control of the steering wheel or the brakes.

■

If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.

■

Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly

when cold and inflated to the inflation pressure recommended by the

vehicle manufacturer on the vehicle placard or tire inflation pressure

label (tire and load information label). (If your vehicle has tires of a dif-

ferent size than the size indicated on the vehicle placard or tire inflation

pressure label [tire and load information label], you should determine

the proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire

pressure monitoring system (TPMS-tire pressure warning system) that

illuminates a low tire pressure telltale (tire pressure warning light) when

one or more of your tires is significantly under-inflated. Accordingly,

when the low tire pressure telltale (tire pressure warning light) illumi-

nates, you should stop and check your tires as soon as possible, and

inflate them to the proper pressure. Driving on a significantly under-

inflated tire causes the tire to overheat and can lead to tire failure.

Under-inflation also reduces fuel efficiency and tire tread life, and may

affect the vehicle’s handling and stopping ability.

554

WARNING

Please note that the TPMS (tire pressure warning system) is not a sub-

stitute for proper tire maintenance, and it is the driver’s responsibility to

maintain correct tire pressure, even if under-inflation has not reached

the level to trigger illumination of the TPMS low tire pressure telltale (tire

pressure warning light).
Your vehicle has also been equipped with a TPMS (tire pressure warn-

ing system) malfunction indicator to indicate when the system is not

operating properly. The TPMS (tire pressure warning system) malfunc-

tion indicator is combined with the low tire pressure telltale (tire pressure

warning light). When the system detects a malfunction, the telltale will

flash for approximately one minute and then remain continuously illumi-

nated. This sequence will continue upon subsequent vehicle start-ups

as long as the malfunction exists. When the malfunction indicator is illu-

minated, the system may not be able to detect or signal low tire pres-

sure as intended.
TPMS (tire pressure warning system) malfunctions may occur for a vari-

ety of reasons, including the installation of replacement or alternate tires

or wheels on the vehicle that prevent the TPMS (tire pressure warning

system) from functioning properly. Always check the TPMS (tire pres-

sure warning system) malfunction telltale after replacing one or more

tires or wheels on your vehicle to ensure that the replacement or alter-

nate tires and wheels allow the TPMS (tire pressure warning system) to

continue to function properly.

NOTICE

■

To ensure the tire pressure warning system operates properly
Do not install tires with different specifications or makers, as the tire

pressure warning system may not operate properly.

555

If a warning message is displayed

Master warning light

The  master  warning  light  also
comes  on  or  flashes  in  order  to
indicate  that  a  message  is  cur-
rently being displayed on the multi-
information display.

Multi-information display

If any of the warning light comes on again after the following actions
have been performed, contact your Toyota dealer.

If a warning is shown on the multi-information display, stay calm
and perform the following actions:

Warning message and warning buzzer list

Warning message

Details/Actions

(If equipped)

Indicates that:
• There is a high possibility of a frontal collision;

• The pre-collision braking function is operating

A buzzer also sounds.

 Slow the vehicle by applying the brakes.

(If equipped)

Indicates that your vehicle is nearing the vehicle
ahead (in vehicle-to-vehicle distance control
mode)

A buzzer also sounds.

 Slow the vehicle by applying the brakes.

BRAKE!

556

(If equipped)

Indicates that the vehicle has deviated from the
lane (while the LDA [Lane Departure Alert] sys-
tem is operating).

• The lane line on the side the vehicle has

deviated from flashes in Yellow.

• A buzzer also sounds.

 Check around the vehicle and back to

inside of the lane lines.

(Flashes)

Indicates that the engine was stopped with the
shift lever not in P.

A buzzer also sounds.

 Shift the shift lever to P.

(Flashes)

Indicates that the engine was stopped while driv-
ing.

A buzzer also sounds.

 Stop the vehicle in a safe place such as the

shoulder of a road.

Indicates that the engine coolant temperature is
too high

A buzzer also sounds.

 Immediately stop the vehicle in a safe place

and contact your Toyota dealer.

Indicates a malfunction in the automatic transmis-
sion system

A buzzer also sounds.

 Have the vehicle inspected by your Toyota

dealer immediately.

Warning message

Details/Actions

(Yellow/

flashes)

Engine Stopped

Shift Into P

Engine Stopped

Stop In a Safe Place

Engine Coolant

Temp High

Stop in a Safe Place

See Owner’s Manual

CHECK

TRANSMISSION

SYSTEM

557

(If equipped)

Indicates a malfunction in the intuitive parking
assist

The malfunctioning assist-sensor is flashing.

 Have the vehicle inspected by your Toyota

dealer immediately.

(If equipped)

Indicates a malfunction in the Blind Spot Monitor

A buzzer also sounds.

 Have the vehicle inspected by your Toyota

dealer immediately.

Indicates that one or more of the doors or the
hood is not fully closed

The system also indicates which doors are not
fully closed.
If the vehicle reaches a speed of 3 mph

(5 km/h),

flashes and a buzzer

sounds to indicate that the door(s) are not
yet fully closed.

 Make sure that all the doors and the hood

are closed.

Indicates that the automatic transmission fluid
temperature is to high

A buzzer also sounds.

 Immediately stop the vehicle in a safe

place, shift the shift lever to P and wait until
the light goes off.
If the light goes off, you may start the vehi-
cle again. If the light does not go off, con-
tact your Toyota dealer.

Indicates that the parking brake is still engaged

If the vehicle reaches a speed of 3 mph

(5 km/h),

flashes and a buzzer

sounds to indicate that the parking brake is
still engaged.

 Release the parking brake.

Warning message

Details/Actions

Parking Assist

Malfunction

Blind Spot Monitor

Malfunction

Visit Your Dealer

High Transmission

Fluid Temp

See Owner’s Manual

Release

Parking Brake

(U.S.A)

(Canada)

558

Indicates that the washer fluid level is low

 Add washer fluid.

(If equipped)

Indicates that intuitive parking assist is dirty or
covered with ice

 Clean the sensor.

(If equipped)

Indicates that the Blind Spot Monitor sensors or
the surrounding area on the bumper is dirty or
covered with ice

A buzzer also sounds.

 Clean the sensor and its surrounding area

on the bumper.



Standard fuel tank

Indicates remaining fuel is approximately 4.0 gal.
(15.0 L, 3.3 Imp.gal.) or less



Large fuel tank

Indicates remaining fuel is approximately 3.8 gal.
(14.4 L, 3.2 lmp.gal.) or less

A buzzer also sounds.

 Refuel the vehicle.

(U.S.A.)

Indicates that all maintenance according to the
driven distance on the maintenance schedule

should be performed soon.
Comes on approximately 4500 miles (7200 km)
after the message has been reset.

 If necessary, perform maintenance.

Warning message

Details/Actions

Windshield

Washer Fluid

Low

Clean Parking Assist

Sensor

Blind Spot

Monitor

Unavailable

Fuel Low

Maintenance

Required Soon

559

(U.S.A.)

Indicates that all maintenance is required to cor-
respond to the driven distance on the mainte-
nance schedule

Comes on approximately 5000 miles (8000 km)
after the message has been reset.
(The indicator will not work properly unless the
message has been reset.)

 Perform the necessary maintenance.

Please reset the message after the mainte-
nance is performed. (

P. 477)

Indicates a malfunction in the tire pressure warn-
ing system.

The tire pressure warning light comes on after
flashing for 1 minute.

 Have the vehicle inspected by your Toyota

dealer.

Indicates a malfunction in the cruise control sys-
tem.

• Press the “ON-OFF” button once to deacti-

vate the system, and then press the button
again to reactivate the system.

• A buzzer also sounds.

 Have the vehicle inspected by your Toyota

dealer.

Indicates a malfunction in the Brake Override
System.

A buzzer also sounds.

 Have the vehicle inspected by your Toyota

dealer immediately.

Indicates that the accelerator and brake pedals
are being depressed simultaneously, and the
Brake Override System is operating. (

P. 161)

 Release the accelerator pedal and depress

the brake pedal.

Warning message

Details/Actions

Maintenance

Required

Visit Your Dealer

Tire Pressure Warning System

Malfunction, Visit Your Dealer

(Flashes

and then

remains on)

Cruise Control

Malfunction

Visit Your Dealer

Brake Override

Malfunction

Visit Your Dealer

Accelerator and

Brake Pedals

Pressed

Simultaneously

560
