Toyota Tundra (2019 year). Manual

450

Other interior features

To  set  the  visor  in  the  forward
position, flip it down.
To set the visor in the side posi-
tion,  flip  down,  unhook,  and
swing it to the side.
To use the side extender, place
the  visor  in  the  side  position,
then slide it backward.

Open the cover

The light turns on when the cover
is opened.

Sun visors

Vanity mirrors (if equipped)

NOTICE

Do not leave the vanity lights on for extended periods while the engine is
stopped.

451

6-4. Using the other interior features

Interio

r features

The clock is displayed on the
screen.

■

Setting the clock



Vehicles with Entune Audio (Multimedia system types:

P. 322)

P. 331



Vehicles with Entune Audio Plus or Entune Premium Audio
(Multimedia system types:

P. 322)

Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

■

The clock is displayed when
The engine switch is in the “ACC” or “ON” position.

■

When disconnecting and reconnecting battery terminals
The clock data will be reset.

Clock

452

6-4. Using the other interior features

Please use as a power supply for electronic goods that use less than
12 VDC/10 A (power consumption of 120 W).
When using electronic goods, make sure that the power consumption
of all the connected power outlets is less than 120 W.



Type A (instrument panel)

Open the lid.



Type B (back of the front center seatback)

Open the lid.

Power outlets

453

6-4. Using the other interior features

Interio

r features



Type C (back of the front center seatback)

Open the lid.



Type D (inside of the console box)

Pull the knob up and lift the lid,
and open the lid.



Type E (back of the console box)

Open the lid.

454

6-4. Using the other interior features



Type F (back of the console box)

Open the lid.

■

The power outlets can be used when
The engine switch is in the “ACC” or “ON” position.

■

Passing a cable from the console box (type D)
P. 435

Fold down the armrest for use.

NOTICE

●

Close the power outlet lids when the power outlets are not in use.
Foreign objects or liquids that enter the power outlets may cause a short
circuit.

●

Do not use the power outlets longer than necessary when the engine is
not running.

Armrest (CrewMax models)

NOTICE

Do not apply too much load on the armrest.

455

6-4. Using the other interior features

Interio

r features

An assist grip (type A) installed on the ceiling can be used to support
your body while sitting on the seat.
An assist grip (type B) installed on the pillar can be used when getting
in or out of the vehicle and others.

Assist grip (type A)
Assist grip (type B)

Assist grips

WARNING

■

Assist grip (type A)
Do not use the assist grip when getting in or out of the vehicle or rising from
your seat.
Doing so could damage the assist grip, or could cause you to injure yourself
by falling over.

NOTICE

Do not hang any heavy object or put a heavy load on the assist grip.

456

6-4. Using the other interior features

Garage door opener



The HomeLink

wireless control system in your vehicle has 3 buttons

which can be programmed to operate 3 different devices. Refer to the
programming methods on the following pages to determine the
method which is appropriate for the device.

HomeLink

indicator light

Garage door operation indica-
tors
Buttons

■

Before programming the HomeLink

● During programming, it is possible that garage doors, gates, or

other devices may operate. For this reason, make sure that peo-
ple and objects are clear of the garage door or other devices to
prevent injury or other potential harm.

● It is recommended that a new battery be placed in the remote

control transmitter for more accurate programming.

● Garage door opener motors manufactured after 1995 may be

equipped with rolling code protection. If this is the case, you may
need a stepladder or other sturdy, safe device to reach the
“learn” or “smart” button on the garage door opener motor.



: If equipped

The garage door opener can be programmed to operate garage
doors, gates, entry doors, door locks, home lighting systems,
security systems, and other devices.

HomeLink

457

6-4. Using the other interior features

Interio

r features

■

Programming the HomeLink

Steps

through

must be performed within 60 seconds, other-

wise the indicator light will stop flashing and programming will not
be able to be completed.

Press and release the HomeLink

button you want to program

and check that the HomeLink

indicator light flashes orange.

Point  the  remote  control
transmitter  for  the  device  at
the rear view mirror, 1 to 3 in.
(25  to  75  mm)  from  the
HomeLink

buttons.

Keep the HomeLink

indicator

light in view while programming.

Program a device.



Programming a device
other than an entry gate
(for U.S.A. owners)

Press and hold the remote
control transmitter button
until the HomeLink

indicator

light  changes  from  slowly
flashing  orange  to  rapidly
flashing  green  (rolling  code)
or  continuously  lit  green
(fixed code), then release the
button.



Programming an entry gate (for U.S.A. owners)/Programming
a device in the Canadian market

Press and release the remote control transmitter button at 2 sec-
ond intervals, repeatedly, until the HomeLink

indicator light

changes from slowly flashing orange to rapidly flashing green
(rolling code) or continuously lit green (fixed code).

458

6-4. Using the other interior features

Test the HomeLink

operation by pressing the newly pro-

grammed button and observing the indicator light:
● Indicator light illuminates: Programming of a fixed code device

has completed. The garage door or other device should oper-
ate when a HomeLink

button is pressed and released.

● Indicator light flashes rapidly: The garage door opener motor

or other device is equipped with a rolling code. To complete
programming, firmly press and hold the HomeLink

button for

2 seconds then release it.

● If the garage door or other device does not operate, proceed

to “Programming a rolling code system”.

Repeat the steps above to program another device for any of the
remaining HomeLink

buttons.

■

Programming a rolling code system
2 or more people may be necessary to complete rolling code pro-
gramming.

Locate the “Learn” or “Smart”
button on the garage door
opener motor in the garage.

This button can usually be found
where the hanging antenna wire
is  attached  to  the  unit.  The
name  and  color  of  the  button
may  vary  by  manufacturer.
Refer  to  the  Owner’s  manual
supplied  with  the  garage  door
opener motor for details.

Press and release the
“Learn” or “Smart” button.
Perform

within 30 sec-

onds after performing

459

6-4. Using the other interior features

Interio

r features

Press and hold the desired
HomeLink

button (inside the

vehicle) for 2 seconds and
release it. Repeat this
sequence

(press/hold/

release)  up  to  3  times  to
complete programming.
If  the  garage  door  opener
motor  operates  when  the
HomeLink

button

pressed, the garage door
opener motor recognizes the
HomeLink

signal.

■

Enabling 2-way communication with a garage door (only avail-
able for compatible devices)
When enabled, 2-way communication allows you to check the sta-
tus of the opening and closing of a garage door through indicators
in your vehicle.
2-way communication is only available if the garage door opener
motor used is a compatible device. (To check device compatibility,
refer to www.HomeLink.com.)

Within 5 seconds after programming the garage door opener has
been completed, if the garage door opener motor is trained to
HomeLink

, both garage door operation indicators will flash rap-

idly green and the light on the garage door opener motor will
blink twice, indicating that 2-way communication is enabled.

If the indicators do not flash, perform

and

within the first 10

presses of the HomeLink

button after programming has been

completed.

460

6-4. Using the other interior features

Press a programmed HomeLink

button to operate a garage

door.
Within 1 minute of pressing the HomeLink

button, after the

garage door operation has stopped, press the “Learn” or “Smart”
button on the garage door opener motor. Within 5 seconds of the
establishment of 2-way communication with the garage door
opener, both garage door operation indicators in the vehicle will
flash rapidly green and the light on the garage door opener motor
will blink twice, indicating that 2-way communication is enabled.

■

Reprogramming a single HomeLink

button

When the following procedure is performed, buttons which already
have devices registered to them can be overwritten:

With one hand, press and hold the desired HomeLink

button.

When the HomeLink

indicator starts flashing orange, release

the HomeLink

button and perform “Programming the Home-

Link

”

(it takes 20 seconds for the HomeLink

indicator to

start flashing).

Press the appropriate HomeLink

button. The HomeLink

indicator

light should turn on.

Operating the HomeLink

461

6-4. Using the other interior features

Interio

r features

The status of the opening and
closing of a garage door is shown
by the indicators.

Opening
Closing

This function is only available if the
garage door opener motor used is
a compatible device. (To check
device compatibility, refer to
www.HomeLink.com.)

The indicators can operate within approximately 820 ft. (250 m) of
the garage door. However, if there are obstructions between the
garage door and the vehicle, such as houses and trees, feedback
signals from the garage door may not be received.
To recall the previous door operation status, press and release

either HomeLink

buttons

and

simultaneously. The last recorded status will be displayed for 3 sec-
onds.

Garage door operation indicators

Color

Status

Orange (flashing)

Currently opening/closing

Green

Opening/closing has completed

Red (flashing)

Feedback signals cannot be received

462

6-4. Using the other interior features

Press and hold the 2 outside but-
tons for 10 seconds until the
HomeLink

indicator

light

changes from continuously lit
orange to rapidly flashing green.

If you sell your vehicle, be sure to
erase the programs stored in the
HomeLink

memory.

■

Codes stored in the HomeLink

memory

●

The registered codes are not erased even if the battery cable is discon-
nected.

●

If learning failed when registering a different code to a HomeLink

button

that already has a code registered to it, the already registered code will not
be erased.

■

Before programming

●

Install a new battery in the transmitter.

●

The battery side of the transmitter must be pointed away from the Home-
Link

Erasing the entire HomeLink

memory (all three codes)

463

6-4. Using the other interior features

Interio

r features

■

Certification for the garage door opener



For vehicles sold in the U.S.A.

FCC ID: NZLAECHL5
NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interfer-
ence, and (2) This device must accept any interference received, including
interference that may cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.



For vehicles sold in Canada

NOTE:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, includ-
ing interference that may cause undesired operation of the device.
REMARQUE:
Le present appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisee aux deux
conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage radioelectrique subi,
meme si le brouillage est susceptible d’en compromettre le fonctionnement.

■

When support is necessary
Visit on the web at www.homelink.com/toyota or call 1-800-355-3515.

■

About HomeLink

HomeLink and the HomeLink house icon are registered trademarks of Gen-
tex Corporation.

464

6-4. Using the other interior features

WARNING

■

When programming a garage door or other remote control device
The garage door or other device may operate, so ensure people and
objects are out of danger to prevent potential harm.

■

Conforming to federal safety standards
Do not use the HomeLink

compatible transceiver with any garage door

opener or device that lacks safety stop and reverse features as required by
federal safety standards.
This includes any garage door that cannot detect an interfering object. A
door or device without these features increases the risk of death or serious
injury.

■

When operating or programming HomeLink

Never allow a child to operate or play with the HomeLink

buttons.

Toyota Tundra (2019 year). Manual - part 29
