Battery-saving function
In the following circumstances, the entry function is disabled in order to pre-
vent the vehicle battery from discharging and the electronic key battery from
discharging.

When the entry function has not been used for 5 days or more

When the electronic key has been left within approximately 6 ft. (2 m) of the
vehicle for 10 minutes or more

If the entry function has not been used for 14 days or more, the vehicle can-
not be unlocked by a door other than the driver’s door. To unlock the vehicle,
grip the driver’s door handle or use the wireless remote control or the
mechanical key.

The system will resume operation when...

The vehicle is locked using the lock sensor when carrying the electronic key
on your person.

The vehicle is locked/unlocked using the wireless remote control. (

P. 111)

The vehicle is locked/unlocked using the mechanical key. (

P. 503)

Conditions affecting operation
P. 119

Notes for the entry function

Even when the electronic key is within the effective range (detection areas),
the system may not operate properly in the following cases.
• The electronic key is too close to the window or outside door handle, near

the ground, or in a high place when the doors are locked or unlocked.

• The electronic key is on the instrument panel, floor or in the glove box

when the engine is started or engine switch modes are changed.

Do not leave the electronic key on top of the instrument panel or near the
door pockets when exiting the vehicle. Depending on the radio wave recep-
tion conditions, it may be detected by the antenna outside the cabin and the
door will become lockable from the outside, possibly trapping the electronic
key inside the vehicle.

As long as the electronic key is within the effective range, the doors may be
locked or unlocked by anyone. However, only the doors detecting the elec-
tronic key can be used to unlock the vehicle.

The doors may unlock or lock if a large amount of water splashes on the
door handle, such as in the rain or in a car wash when the electronic key is
within the effective range. (The doors will automatically be locked after
approximately 60 seconds if the doors are not opened and closed.)

If the wireless remote control is used to lock the doors when the electronic
key is near the vehicle, there is a possibility that the door may not be
unlocked by the smart key system. (Use the wireless remote control to
unlock the doors.)

If power slide door is unable to operate due to prohibition by the power slid-
ing door main switch, the door unlock and open operation will not be per-
formed. (

P. 124)

146

SIENNA_OM_OM08025U_(U)

Note for locking the doors

Touching the door lock sensor while wearing gloves may delay or prevent
lock operation. Remove the gloves and touch the lock sensor again.

When the lock operation is performed using the lock sensor, recognition sig-
nals will be shown up to two consecutive times. After this, no recognition
signals will be given.

If the door handle becomes wet while the electronic key is within the effec-
tive range, the door may lock and unlock repeatedly. Place the key in a posi-
tion 6 ft. (2 m) or more separate from the vehicle while the vehicle is being
washed. (Take care to ensure that the key is not stolen.)

If the electronic key is inside the vehicle and a door handle becomes wet
during a car wash, a message may be shown on the multi-information dis-
play and a buzzer will sound outside the vehicle. To turn off the alarm, lock
all the doors.

The lock sensor may not work properly if it comes into contact with ice,
snow, mud, etc. Clean the lock sensor and attempt to operate it again, or
use the lock sensor on the lower part of the door handle.

Fingernails may scrape against the door during operation of the door han-
dle. Be careful not to injure fingernails or damage the surface of the door.

Notes for the unlocking function

Gripping the front door handle when wearing a glove may not unlock or lock
the door.

A sudden approach to the effective range or door handle operation may pre-
vent the doors from being unlocked. In this case, return the door handle to
the original position and check that the doors have unlocked before pulling
the door handle.

If there is another electronic key in the detection area, it may take slightly
longer to unlock the doors after one of the front door handles is gripped or
one of sliding door handles is pulled.

When the vehicle is not driven for extended periods

To prevent theft of the vehicle, do not leave the electronic key within 6 ft.
(2 m) of the vehicle.

The smart key system can be deactivated in advance. (

P. 544)

SIENNA_OM_OM08025U_(U)

147

To operate the system properly
Make sure to carry the electronic key when operating the system. Do not get
the electronic key too close to the vehicle when operating the system from the
outside of the vehicle.
Depending on the position and holding condition of the electronic key, the key
may not be detected correctly and the system may not operate properly. (The
alarm may go off accidentally, or the door lock prevention may not operate.)

If the smart key system does not operate properly

Locking and unlocking the doors: Use the mechanical key. (

P. 503)

Starting the engine (

P. 503)

Certification for the smart key system



For vehicles sold in the U.S.A.

FCC ID: HYQ14ADR

FCC ID: HYQ14AEH

FCC ID: HYQ13CZM

FCC ID: HYQ13CZN

FCC ID: NI4TMLF8-20
NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.



For vehicles sold in Canada

NOTE:
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, includ-
ing interference that may cause undesired operation of the device.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, includ-
ing interference that may cause undesired operation of the device.

148

SIENNA_OM_OM08025U_(U)

Customization
Settings (e.g. smart key system) can be changed.
(Customizable features:

P. 543, 544 )

If the smart key system has been deactivated in a customized setting

Locking and unlocking the doors:
Use the wireless remote control or mechanical key. (

P. 111, 503)

Starting the engine and changing engine switch modes:

P. 503

Stopping the engine:

P. 229

WARNING

Caution regarding interference with electronic devices

People with implantable cardiac pacemakers, cardiac resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should keep
away from the smart key system antennas. (

P. 143)

The radio waves may affect the operation of such devices. If necessary,
the entry function can be disabled. Ask your Toyota dealer for details, such
as the frequency of radio waves and timing of the emitted radio waves.
Then, consult your doctor to see if you should disable the entry function.

Users  of  any  electrical  medical  device  other  than  implantable  cardiac
pacemakers,  cardiac  resynchronization  therapy-pacemakers  or  implant-
able  cardioverter  defibrillators  should  consult  the  manufacturer  of  the
device  for  information  about  its  operation  under  the  influence  of  radio
waves.  Radio  waves  could  have  unexpected  effects  on  the  operation  of
such medical devices.

Ask your Toyota dealer for details for disabling the entry function.

149

SIENNA_OM_OM08025U_(U)

Front seats



Manual seat

Seat position adjustment lever
Seatback angle adjustment lever
Vertical height adjustment lever (driver’s side only)
Lumbar support adjustment switch (driver’s side only)*

: If equipped



Power seat

Seat position adjustment switch
Seatback angle adjustment switch
Seat cushion (front) angle adjustment switch (driver’s side only)
Vertical height adjustment switch (driver’s side only)
Lumbar support adjustment switch (driver’s side only)

Adjustment procedure

150

SIENNA_OM_OM08025U_(U)

When  the  occupant’s  lower  back
presses  against  the  seatback
during  a  rear-end  collision,  the
head  restraint  moves  slightly  for-
ward  and  upward  to  help  reduce
the  risk  of  whiplash  on  the  seat
occupant.

Active head restraints
Even small forces applied to the seatback may cause the head restraint to
move. When a locked head restraint is pushed up forcibly, the head restraint
inner structure may appear. This does not indicate a problem.

Active head restraints

ITN13N065

During
rear-end
collision

Inner structure

SIENNA_OM_OM08025U_(U)

151

WARNING

When adjusting the seat position

Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.

Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.

Make sure to leave enough space around the feet so they do not get stuck.

Seat adjustment

Be careful that the seat does not hit passengers or luggage.

To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is reclined too far, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.

Manual seat: After adjusting the seat, make sure that the seat is locked in
position.

152

SIENNA_OM_OM08025U_(U)

Rear seats

Second seat



Tip-up seat (7-passenger models)

Seat position adjustment
lever
Seatback angle adjustment
lever



Tip-up seat (8-passenger models)

Seat position adjustment
lever
Seatback angle adjustment
lever

Adjustment procedure

SIENNA_OM_OM08025U_(U)

153



Ottoman seat

Seat  position  adjustment
lever
Seatback  angle  adjustment
lever
Ottoman  angle  adjustment
lever



AUTO ACCESS SEAT

Refer to “AUTO ACCESS SEAT OWNER’S MANUAL”.

Third seats



Manual seat

Seatback angle adjustment
strap

154

SIENNA_OM_OM08025U_(U)



Power seat

Seatback angle adjustment
switch

Getting in the vehicle



Tip-up seats

Pull the seatback angle adjust-
ment lever and fold down the
seatback. The cushion will tip
up. The seat can slide forward.
Move the seat to the frontmost
position.



Ottoman seats

Pull the seatback angle adjust-
ment lever and fold down the
seatback. The seat can slide
forward.
Move the seat to the frontmost
position.

Moving a second seat for third seat access

SIENNA_OM_OM08025U_(U)

155

Getting out of the vehicle



Tip-up seats

Pull the strap and fold down the
seatback. The cushion will tip
up. The seat can slide forward.
Move the seat to the frontmost
position.

Make sure that no passenger is
seated on the second seat
before pulling the strap.



Ottoman seats

Pull the strap and fold down the
seatback. The seat can slide
forward.
Move the seat to the frontmost
position.

Make sure that no passenger is
seated on the second seat
before pulling the strap.

After passengers have entered/exited the vehicle
Lift up the seatback and slide the seat backward until it locks.

156

SIENNA_OM_OM08025U_(U)

Removing the second outside seats (Tip-up seats)

Pull the armrests up.
Pull the seatback adjustment
lever and fold down the seat-
back. The cushion will tip up.

Slide the seat forward to a lock position.
Pull the release lever under
the cushion and simultane-
ously lift the seat to remove.

Removing the second seats (Ottoman seats)

Pull the armrests up.
Pull the seatback adjustment
lever and fold down the seat-
back.

Slide the seat to a forward lock position.
Pull the release lever behind
the  seatback  straight  back,
then  up.  While  moving  the
lever  up,  simultaneously  lift
the seat to remove.

Removing the second seats

SIENNA_OM_OM08025U_(U)

157

Removing the second center seat (if equipped)

Pull the lock release strap
and fold down the second
center seatback.

Make sure that the head
restraint is in the lowest position.

Pull the lock release strap
under the seat to remove the
seat.
Retract the cushion leg.

Stow  the seat in  the storage
box  of  the  luggage  room
(cushion side first).
Engage the stow latch buckle
to  hold  the  seat  and  tighten
the latch strap.

158

SIENNA_OM_OM08025U_(U)
