529

7-2. Steps to take in an emergency

CAMRY_U

7

Wh
en tro

uble

 a

ris

es

If you have a set of jumper (or booster) cables and a second vehicle
with a 12-volt battery, you can jump start your vehicle by following the
steps below.

Vehicles with an alarm: Confirm
that the electronic key (vehicles
with a smart key system) or key
(vehicles  without  a  smart  key
system) is being carried.

When  connecting  the  jumper  (or
booster) cables, depending on the
situation,  the  alarm  may  activate
and doors locked. (

P. 84)

Open the hood. (

P. 430)

Vehicles  with  3.5  L  V6  (2GR-
FKS)  engine:  Remove  the
engine cover.

Make sure to pull the engine cover
straight up when removing it.

If the vehicle battery is discharged

The following procedures may be used to start the engine if the
vehicle’s battery is discharged.
You can also call your Toyota dealer or a qualified repair shop.

1

2

3

530

7-2. Steps to take in an emergency

CAMRY_U

Connect the jumper cables according to the following procedure:



2.5 L 4-cylinder (A25A-FKS) engine



3.5 L V6 (2GR-FKS) engine

Connect a positive jumper cable clamp to the positive (+) battery
terminal on your vehicle.
Connect the clamp on the other end of the positive cable to the
positive (+) battery terminal on the second vehicle.
Connect a negative cable clamp to the negative (-) battery termi-
nal on the second vehicle.
Connect  the  clamp  at  the  other  end  of  the  negative  cable  to  a
solid, stationary, unpainted metallic point away from the battery
and any moving parts, as shown in the illustration.

4

1

2

3

4

531

7-2. Steps to take in an emergency

CAMRY_U

7

Wh
en tro

uble

 a

ris

es

Start the engine of the second vehicle. Increase the engine speed
slightly  and  maintain  at  that  level  for  approximately  5  minutes  to
recharge the battery of your vehicle.
Vehicles with a smart key system: Open and close any of the doors
of your vehicle with the engine switch off.
Vehicles without a smart key system:
Maintain  the  engine  speed  of  the  second  vehicle  and  turn  the
engine switch to the “ON” position, then start the vehicle's engine.
Vehicles with a smart key system:
Maintain  the  engine  speed  of  the  second  vehicle  and  turn  the
engine  switch  to  IGNITION  ON  mode,  then  start  the  vehicle's
engine.
Once the vehicle’s engine has started, remove the jumper cables in
the exact reverse order from which they were connected.

Once  the  engine  starts,  have  the  vehicle  inspected  at  your  Toyota
dealer as soon as possible.

■

Starting the engine when the battery is discharged
The engine cannot be started by push-starting.

■

To prevent battery discharge

●

Turn off the headlights and the audio system while the engine is off.

●

Turn off any unnecessary electrical components when the vehicle is running
at a low speed for an extended period, such as in heavy traffic.

■

When the battery is removed or discharged

●

Information stored in the ECU is cleared. When the battery is depleted, have
the vehicle inspected at your Toyota dealer.

●

Some systems may require initialization. (→P. 575)

■

When removing the battery terminals
When the battery terminals are removed, the information stored in the ECU is
cleared. Before removing the battery terminals, contact your Toyota dealer.

■

Charging the battery
The  electricity  stored  in  the  battery  will  discharge  gradually  even  when  the
vehicle is not in use, due to natural discharge and the draining effects of cer-
tain electrical appliances. If the vehicle is left for a long time, the battery may
discharge,  and  the  engine  may  be  unable  to  start.  (The  battery  recharges
automatically during driving.)

5

6

7

8

532

7-2. Steps to take in an emergency

CAMRY_U

■

When recharging or replacing the battery (vehicles with a smart key sys-
tem)

●

In some cases, it may not be possible to unlock the doors using the smart
key system when the battery is discharged. Use the wireless remote control
or the mechanical key to lock or unlock the doors.

●

The engine may not start on the first attempt after the battery has recharged
but will start normally after the second attempt. This is not a malfunction.

●

The engine switch mode is memorized by the vehicle. When the battery is
reconnected, the system will return to the mode it was in before the battery
was discharged. Before disconnecting the battery, turn the engine switch off.
If you are unsure what mode the engine switch was in before the battery dis-
charged, be especially careful when reconnecting the battery.

■

When replacing the battery

●

Use a battery that conforms to European regulations.

●

Use a battery with the same case size, equivalent or greater 20 hour rate
capacity (20HR), and equivalent or greater performance rating (CCA) as the
battery which is being replaced.

The  case  size,  20  hour  rate  capacity  (20HR)  and  performance  rating
(CCA) are specified on the label attached to the battery.

• If the sizes differ, the battery cannot be properly secured.
• If the 20 hour rate capacity is low, even if the time period where the vehi-

cle is not used is a short time, the battery may discharge and the engine
may not be able to start.

●

For details, consult your Toyota dealer.

Case size

20 hour rate

capacity (20HR)

Performance rating

(CCA)

Type A

LN2

60Ah

360A

Type B

LN2

60Ah

563A

Type C

LN3

70Ah

600A

533

7-2. Steps to take in an emergency

CAMRY_U

7

Wh
en tro

uble

 a

ris

es

WARNING

■

When removing the battery terminals
Always remove the negative (-) terminal first. If the positive (+) terminal con-
tacts  any  metal  in  the  surrounding  area  when  the  positive  (+)  terminal  is
removed, a spark may occur, leading to a fire in addition to electrical shocks
and death or serious injury.

■

Avoiding battery fires or explosions
Observe the following precautions to prevent accidentally igniting the flam-
mable gas that may be emitted from the battery:

●

Make sure each jumper cable is connected to the correct terminal and that
it is not unintentionally in contact with any other than the intended terminal.

●

Do not allow the other end of the jumper cable connected to the “+” termi-
nal to come into contact with any other parts or metal surfaces in the area,
such as brackets or unpainted metal.

●

Do not allow the + and - clamps of the jumper cables to come into contact
with each other.

●

Do  not smoke,  use matches, cigarette lighters  or  allow  open flame near
the battery.

■

Battery precautions
The  battery  contains  poisonous  and  corrosive  acidic  electrolyte,  while
related parts contain lead and lead compounds. Observe the following pre-
cautions when handling the battery:

●

When working with the battery, always wear safety glasses and take care
not to allow any battery fluids (acid) to come into contact with skin, clothing
or the vehicle body.

●

Do not lean over the battery.

●

In  the  event  that  battery  fluid  comes  into  contact  with  the  skin  or  eyes,
immediately wash the affected area with water and seek medical attention.
Place a wet sponge or cloth over the affected area until medical attention
can be received.

●

Always wash your hands after handling the battery support, terminals, and
other battery-related parts.

●

Do not allow children near the battery.

NOTICE

■

When handling jumper cables
When connecting the jumper cables, ensure that they do not become entan-
gled in the cooling fan or engine drive belt.

534

7-2. Steps to take in an emergency

CAMRY_U

Stop the vehicle in a safe place and turn off the air conditioning sys-
tem, and then stop the engine.
If you see steam:
Carefully lift the hood after the steam subsides.
If you do not see steam:
Carefully lift the hood.
After  the  engine  has  cooled
down  sufficiently,  inspect  the
hoses and radiator core (radia-
tor) for any leaks.

Radiator
Cooling fan

If a large amount of coolant leaks,
immediately  contact  your  Toyota
dealer.

If your vehicle overheats

The following may indicate that your vehicle is overheating.

● The  needle  of  the  engine  coolant  temperature  gauge  (P.  92)

enters the red zone or a loss of engine power is experienced. (For
example, the vehicle speed does not increase.)

● “Engine  Coolant Temp  High  Stop  in  a  Safe  Place  See  Owner’s

Manual” is shown on the multi-information display.

● Steam comes out from under the hood.

Correction procedures

1

2

3

1

2

535

7-2. Steps to take in an emergency

CAMRY_U

7

Wh
en tro

uble

 a

ris

es

The coolant level is satisfactory if it is between the “F” and “L” lines
on the reservoir.

Reservoir
“F” line
“L” line
Radiator cap

Add coolant if necessary.

Water can be used in an emergency if coolant is unavailable.

4

1

2

3

4



2.5  L  4-cylinder  (A25A-FKS)
engine



3.5 L V6 (2GR-FKS) engine

5



2.5  L  4-cylinder  (A25A-FKS)
engine



3.5 L V6 (2GR-FKS) engine

536

7-2. Steps to take in an emergency

CAMRY_U

Start the engine and turn the air conditioning system on to check
that the radiator cooling fan operates and to check for coolant leaks
from the radiator or hoses.

The fan operates when the air conditioning system is turned on immedi-
ately after a cold start. Confirm that the fan is operating by checking the fan
sound and air flow. If it is difficult to check these, turn the air conditioning
system on and off repeatedly. (The fan may not operate in freezing tem-
peratures.)

If the fan is not operating:
Stop the engine immediately and contact your Toyota dealer.
If the fan is operating:
Have the vehicle inspected at the nearest Toyota dealer.

WARNING

■

To  prevent  an  accident  or  injury  when  inspecting  under  the  hood  of
your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.

●

If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The engine compartment may be very hot.

●

Keep hands and clothing (especially a tie, a scarf or a muffler) away from
the fan and belts. Failure to do so may cause the hands or clothing to be
caught, resulting in serious injury.

●

Do  not  loosen  the  radiator  cap  and  the  coolant  reservoir  cap  while  the
engine and radiator are hot.
High temperature steam or coolant could spray out.

NOTICE

■

When adding engine coolant
Wait until the engine has cooled down before adding engine coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot engine too
quickly can cause damage to the engine.

■

To prevent damage to the cooling system
Observe the following precautions:

●

Avoid contaminating the coolant with foreign matter (such as sand or dust
etc.).

●

Do not use any coolant additives.

6

7

537

7-2. Steps to take in an emergency

CAMRY_U

7

Wh
en tro

uble

 a

ris

es

Stop the engine. Set the parking brake and shift the shift lever to P.
Remove the mud, snow or sand from around the front wheels.
Place wood, stones or some other material under the front wheels
to help provide traction.
Restart the engine.
Shift the shift lever to D or R and release the parking brake. Then,
while exercising caution, depress the accelerator pedal.

If the vehicle becomes stuck

Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:

1

2

3

4

5

538

7-2. Steps to take in an emergency

CAMRY_U

■

When it is difficult to free the vehicle

Press

 to turn off TRAC.

WARNING

■

When attempting to free a stuck vehicle
If you choose to push the vehicle back and forth to free it, make sure the
surrounding area is clear to avoid striking other vehicles, objects or people.
The vehicle may also lunge forward or lunge back suddenly as it becomes
free. Use extreme caution.

■

When shifting the shift lever
Be careful not to shift the shift lever with the accelerator pedal depressed.
This  may  lead  to  unexpected  rapid  acceleration  of  the  vehicle  that  may
cause an accident resulting in death or serious injury.

NOTICE

■

To avoid damaging the transmission and other components

●

Avoid  spinning  the  front  wheels  and  depressing  the  accelerator  pedal
more than necessary.

●

If  the  vehicle  remains  stuck even  after  these procedures  are  performed,
the vehicle may require towing to be freed.

539

8

Vehicle specifications

CAMRY_U

8-1. Specifications

Maintenance data

(fuel, oil level, etc.).......... 540

Fuel information ................ 551
Tire information ................. 554

8-2.  Customization

Customizable features ...... 567

8-3.  Items to initialize

Items to initialize ............... 575

540

CAMRY_U

8-1. Specifications

*

1

: Unladen vehicles

*

2

: For L, LE or XLE grade models

*

3

: For SE or XSE grade models

*

4

: 205/65R16 tires

*

5

: 215/55R17 tires

*

6

: 235/45R18 and 235/40R19 tires

Maintenance data (fuel, oil level, etc.)

Dimensions and weights

Overall length

192.1 in. (4880 mm)

*

2

192.7 in. (4895 mm)

*

3

Overall width

72.4 in. (1840 mm)

Overall height

*

1

56.9 in. (1445 mm)

Wheelbase

111.2 in. (2825 mm)

Tread

Front

63.0 in. (1600 mm)

*

4

62.6 in. (1590 mm)

*

5

62.2 in. (1580 mm)

*

6

Rear

63.2 in. (1605 mm)

*

4

62.8 in. (1595 mm)

*

5

62.6 in. (1590 mm)

*

6

Vehicle capacity weight
(occupants + luggage)

925 lb. (420 kg)

541

8-1. Specifications

8

Vehi

cl

e specificatio

ns

CAMRY_U

■

Vehicle identification number
The  vehicle  identification  number  (VIN)  is  the  legal  identifier  for
your  vehicle.  This  is  the  primary  identification  number  for  your
Toyota. It is used in registering the ownership of your vehicle.
This number is stamped on the
top left of the instrument panel.

This number is also on the Cer-
tification Label.

On  some  models,  this  number
is also stamped under the right-
hand front seat.

Vehicle identification

542

8-1. Specifications

CAMRY_U

■

Engine number
The engine number is stamped on the engine block as shown.



2.5  L  4-cylinder  (A25A-FKS)
engine



3.5 L V6 (2GR-FKS) engine

Engine

Model

A25A-FKS

2GR-FKS

Type

4-cylinder in line,
4-cycle, gasoline

6-cylinder V type,
4-cycle, gasoline

Bore and stroke

3.44

 4.07 in.

(87.5

 103.4 mm)

3.70

 3.27 in.

(94.0

 83.0 mm)

Displacement

151.8 cu. in. (2487 cm

3

)

210.9 cu. in. (3456 cm

3

)

Valve clearance

Automatic adjustment

Drive belt tension

Automatic adjustment

Fuel

Fuel type

Unleaded gasoline only

Octane rating

87 (Research Octane Number 91) or higher

Fuel tank capacity
(Reference)



For L grade models

14.5 gal. (55 L, 12.0 Imp. gal.)



Except for L grade models

16.0 gal. (60.6 L, 13.3 Imp. gal.)

543

8-1. Specifications

8

Vehi

cl

e specificatio

ns

CAMRY_U

■

Oil capacity (Drain and refill [Reference

*

])

*

: The engine oil capacity is a reference quantity to be used when changing

the engine oil. Warm up and turn off the engine, wait more than 5 minutes,
and check the oil level on the dipstick.

■

Engine oil selection



2.5 L 4-cylinder (A25A-FKS) engine

“Toyota  Genuine  Motor  Oil”  is  used  in  your  Toyota  vehicle.  Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat-
isfy the following grade and viscosity.
Oil grade: API SN/RC multigrade engine oil
Recommended viscosity: SAE 0W-16

SAE  0W-16  is  the  best  choice  for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-16 is not available, SAE
0W-20  oil  may  be  used.  However,
it  must  be  replaced  with SAE 0W-
16 at the next oil change.

Oil viscosity (0W-16 is explained here as an example):

• The 0W in 0W-16 indicates the characteristic of the oil which allows cold

startability. Oils with a lower value before the W allow for easier starting of
the engine in cold weather.

• The 16 in 0W-16 indicates the viscosity characteristic of the oil when the

oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme load conditions.

Lubrication system

With filter

Without filter

2.5

L

4-cylinder

(A25A-FKS) engine

4.8 qt.
(4.5 L, 4.0 Imp. qt.)

4.4 qt.
(4.2 L, 3.7 Imp. qt.)

3.5  L  V6  (2GR-FKS)
engine

5.7 qt.
(5.4 L, 4.8 Imp. qt.)

5.6 qt.
(5.3 L, 4.7 Imp. qt.)

Outside temperature

544

8-1. Specifications

CAMRY_U

How to read oil container label:
API  registered  marks  is  added
to  some  oil  containers  to  help
you  select  the  oil  you  should
use.



3.5 L V6 (2GR-FKS) engine

“Toyota  Genuine  Motor  Oil”  is  used  in  your  Toyota  vehicle.  Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat-
isfy the following grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20

SAE  0W-20  is  the  best  choice  for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-20 is not available, SAE
5W-20  oil  may  be  used.  However,
it  must  be  replaced  with SAE 0W-
20 at the next oil change.

Oil viscosity (0W-20 is explained here as an example):

• The 0W in 0W-20 indicates the characteristic of the oil which allows cold

startability. Oils with a lower value before the W allow for easier starting of
the engine in cold weather.

• The 20 in 0W-20 indicates the viscosity characteristic of the oil when the

oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme load conditions.

Outside temperature
