If you have a flat tire

● Stop the vehicle in a safe place on a hard, flat surface.
● Set the parking brake.
● Shift the shift lever to P.
● Stop the engine.
● Turn on the emergency flashers. (→P. 438)
● Press the height control mode select switch to set the height control

system to manual mode (if equipped) (

→P. 290)

Your vehicle is equipped with a spare tire. The flat tire can be
replaced with the spare tire.

For details about tires:

→P. 405

WARNING

■

If you have a flat tire
Do not continue driving with a flat tire.

Driving even a short distance with a flat tire can damage the tire and the
wheel beyond repair, which could result in an accident.

Before jacking up the vehicle

466

SEQUOIA_OM_USA_OM0C011U

Spare tire

Jack

Tool bag

Location of the spare tire, jack and tools

467

SEQUOIA_OM_USA_OM0C011U

WARNING

■

Using the tire jack
Improper use of the tire jack may cause the vehicle to suddenly fall off
the jack, leading to death or serious injury.

●

Do not use the tire jack for any purpose other than replacing tires or
installing and removing tire chains.

●

Only use the tire jack that comes with this vehicle for replacing a flat
tire.
Do not use it on other vehicles, and do not use other tire jacks for
replacing tires on this vehicle.

●

Always check that the tire jack is securely set to the jack point.

●

Do not put any part of your body under the vehicle while it is supported
by the jack.

●

Do not start or run the engine while your vehicle is supported by the
jack.

●

Do not raise the vehicle while someone is inside.

●

When raising the vehicle, do not put an object on or under the jack.

●

Do not raise the vehicle to a height greater than that required to
replace the tire.

●

Use a jack stand if it is necessary to get under the vehicle.

Take particular care when lowering the vehicle to ensure that no one
working on or near the vehicle may be injured.

■

Using the jack handle
Insert the square head securely until you hear a click to prevent the
extension parts from coming apart unexpectedly.

468

SEQUOIA_OM_USA_OM0C011U

Pull the deck board up.

Remove the cover and loosen
the strap.

Remove the tools.

Take out the jack.

For tightening

For loosening

Taking out the jack and tool bag

469

SEQUOIA_OM_USA_OM0C011U

Assemble the jack handle
extension as shown.

Remove the cover.

Insert the end of the jack han-
dle extension into the lowering
screw and turn it counterclock-
wise.

Lower the spare tire completely
to the ground.

Pull out the spare tire and
remove the holding bracket.

Taking out the spare tire

470

SEQUOIA_OM_USA_OM0C011U

Chock the tires.

Slightly loosen the wheel nuts
(one turn).

Assemble the jack handle
extension as shown.

Replacing a flat tire

Flat tire

Wheel chock positions

Front

Left-hand side

Behind the rear right-hand side tire

Right-hand side

Behind the rear left-hand side tire

Rear

Left-hand side

In front of the front right-hand side tire

Right-hand side

In front of the front left-hand side tire

471

SEQUOIA_OM_USA_OM0C011U

Position the jack at the jack
points as shown.

Front

Rear

Make sure the jack is positioned
on a level and solid place.

Raise the vehicle until the tire is
slightly raised off the ground.

Remove all the wheel nuts and
the tire.

When resting the tire on the
ground, place the tire so that the
wheel design faces up to avoid
scratching the wheel surface.

472

SEQUOIA_OM_USA_OM0C011U

WARNING

■

Replacing a flat tire

●

Observe the following precautions.
Failure to do so may result in serious injury:

• Lower the spare tire completely to the ground before removing it

from under the vehicle.

• Do not try to remove the wheel ornament by hand. Take due care in

handling the ornament to avoid unexpected personal injury.

• Do not attach a heavily damaged wheel ornament, as it may fly off

the wheel while the vehicle is moving.

• Do not touch the disc wheels or the area around the brakes immedi-

ately after the vehicle has been driven.
After the vehicle has been driven the disc wheels and the area
around the brakes will be extremely hot. Touching these areas with
hands, feet or other body parts while changing a tire, etc. may result
in burns.

●

Failure to follow these precautions could cause the wheel nuts to
loosen and the tire to fall off, resulting in death or serious injury.

• Have the wheel nuts tightened with a torque wrench as soon as pos-

sible after changing wheels.
Steel wheel: 154 ft·lbf (209 N·m, 21.3 kgf·m)
Aluminum wheel: 97 ft·lbf (131 N·m, 13.4 kgf·m)

• When installing a tire, only use wheel nuts that have been specifi-

cally designed for that wheel.

• If there are any cracks or deformations in the bolt screws, nut

threads or bolt holes of the wheel, have the vehicle inspected by
your Toyota dealer.

• When installing the wheel nuts, be sure to install them with the

tapered ends facing inward. (

→P. 420)

473

SEQUOIA_OM_USA_OM0C011U

Remove any dirt or foreign mat-
ter from the wheel contact sur-
face.

If foreign matter is on the wheel
contact surface, the wheel nuts
may loosen while the vehicle is in
motion, causing the tire to come
off.

Install the spare tire and loosely
tighten each wheel nut by hand
by approximately the same
amount.

Tighten the nuts until the tapered
portion comes into loose contact
with the disc wheel.

Installing the spare tire

Tapered portion

Disc wheel

474

SEQUOIA_OM_USA_OM0C011U

Lower the vehicle.

Firmly tighten each wheel nut
two or three times in the order
shown in the illustration.

Tightening torque

154 ft·lbf (209 N·m, 21.3 kgf·m)

: When used on aluminum wheel,

apply 97 ft·lbf (131 N·m, 13.4 kgf·m)

WARNING

■

Stowing the flat tire
Failure to follow steps listed under stowing the tire may result in damage
to the spare tire carrier and lose of the tire, which could result in death or
serious injury.

475

SEQUOIA_OM_USA_OM0C011U

Remove the center wheel ornament by pushing from the reverse
side.

Lay down the tire with the valve
stem facing up and install the
holding bracket, inserting the
claw into the wheel lug nut hole.
Turn the jack handle extension
clockwise to take up slack in
the chain.

Then, check to ensure the claw
is in the wheel lug nut hole and
the holding bracket is centered
in the wheel hub.

Claw

Holding bracket

While raising, secure the tire,
taking care that the tire goes
straight up without catching on
any surrounding part to prevent
it from flying forward during a
collision or sudden braking.

Tightening torque:

34.7 ft·lbf (46.6 N·m, 4.8 kgf·m)

Stowing the flat/spare tire, jack and tools

incorrect

correct

476

SEQUOIA_OM_USA_OM0C011U

Confirm that the tire is not loose
after tightening:

Push and pull the tire

Try rotating

Visually check to ensure the tire
is not hung on surrounding parts.
If looseness or misassembly
exists, repeat step

and step

Repeat step

any time the tire is lowered or disturbed.

Stow the tools and jack securely.

■

The temporary spare tire

●

Use the temporary spare tire temporarily, and only in an emergency.

●

Make sure to check the tire inflation pressure of the temporary spare
tire. (

→P. 501)

■

After completing the tire change
The tire pressure warning system must be reset. (

→P. 407)

■

When using the spare tire
As the spare tire is not equipped with a tire pressure warning valve and
transmitter, low inflation pressure of the spare tire will not be indicated by
the tire pressure warning system. Also, if you replace the spare tire after
the tire pressure warning light comes on, the light remains on.

■

If you have a flat rear tire on a road covered with snow or ice
Install the temporary spare tire on one of the front wheels of the vehicle.
Perform the following steps and fit tire chains to the rear tires:

Replace a front tire with the temporary spare tire.

Replace the flat rear tire with the tire removed from the front of the vehi-
cle.

Fit tire chains to the rear tires.

477

SEQUOIA_OM_USA_OM0C011U

WARNING

■

When using the temporary spare tire

●

Remember that your temporary spare tire is specifically designed for
use with your vehicle. Do not use your temporary spare tire on another
vehicle.

●

Do not use two temporary spare tires simultaneously.

●

Replace the temporary spare tire with a standard tire as soon as possi-
ble.

●

Avoid sudden acceleration, deceleration and braking, as well as sharp
cornering.

■

Speed limit when using the temporary spare tire
Do not drive at speeds in excess of 50 mph (80 km/h) when a temporary
spare tire is installed on the vehicle.

The temporary spare tire is not designed for driving at high speeds. Fail-
ing to observe this precaution may lead to an accident causing death or
serious injury.

■

When the temporary spare tire is attached
The vehicle speed may not be correctly detected, and the following sys-
tems may not operate correctly:

Also, not only can the following system not be utilized fully, it may actu-
ally negatively effect the drive-train components:

• 4WD system (if equipped)

■

After using the tools and jack
Before driving, make sure all the tools and jack are securely in place in
their storage location to reduce the possibility of personal injury during a
collision or sudden braking.

• ABS & Brake assist
• VSC
• TRAC
• AUTO LSD
• Automatic High Beam
• PCS (Pre-Collision System)
• LDA (Lane Departure Alert)

• Dynamic radar cruise control
• BSM (Blind Spot Monitor)
• Intuitive parking assist-sensor

(if equipped)

• Rear view monitor system
• Navigation system (if equipped)

478

SEQUOIA_OM_USA_OM0C011U

NOTICE

■

Do not drive the vehicle with a flat tire
Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the
wheel beyond repair.

■

Driving with tire chains and the temporary spare tire
Do not fit tire chains to the temporary spare tire.
Tire chains may damage the vehicle body and adversely affect driving
performance.

■

When stowing the flat tire
Ensure that there is no object caught between the tire and the vehicle
underbody.

■

When assembling the jack handle extension
Insert the square head securely until you hear a click. Otherwise the
extension may come off and it may damage the paint or vehicle body.

■

When replacing the tires
When removing or fitting the wheels, tires or the tire pressure warning
valve and transmitter, contact your Toyota dealer as the tire pressure
warning valve and transmitter may be damaged if not handled correctly.

■

To avoid damage to the tire pressure warning valves and transmit-
ters
When a tire is repaired with liquid sealants, the tire pressure warning
valve and transmitter may not operate properly. If a liquid sealant is
used, contact your Toyota dealer or other qualified service shop as soon
as possible. Make sure to replace the tire pressure warning valve and
transmitter when replacing the tire. (

→P. 406)

479

SEQUOIA_OM_USA_OM0C011U

If the engine will not start

One of the following may be the cause of the problem:
● There may not be sufficient fuel in the vehicle’s tank.

Refuel the vehicle.

Flex-fuel vehicles: The type of fuel may be different. When refuel-
ing, add the same type of fuel, if available.

After adding a different type of fuel, the engine may run roughly and
driving performance may be reduced for a while when the engine is
first started. In this case, wait until the engine runs normally.

● The engine may be flooded.

Try to restart the engine again following correct starting procedures.
(

→P. 198)

● There may be a malfunction in the engine immobilizer system.

(

→P. 74)

One of the following may be the cause of the problem:
● The battery may be discharged. (→P. 481)
● The battery terminal connections may be loose or corroded.

If the engine will not start even though correct starting proce-
dures are being followed (

→P. 198), consider each of the follow-

ing points:

The engine will not start even though the starter motor operates
normally.

The starter motor turns over slowly, the interior lights and head-
lights are dim, or the horn does not sound or sounds at a low
volume.

480
