321

5-1. Using the air conditioning system and defogger

5

In

te

rior fe

atures

SEQUOIA_OM_USA_OM0C011U

■

Fan speed setting

Turn the fan speed control dial.

Increases the fan speed

Decreases the fan speed

Press



to turn the fan off.

■

Change the airflow mode

Turn the air outlet selection dial.

The air outlets switch each time
either side of air outlet selection
dial is turned.

Air flows to the upper body.

Air flows to the upper body
and feet.

Air flows to the feet.

Air flows to the feet and the
windshield defogger oper-
ates.

322

5-1. Using the air conditioning system and defogger

SEQUOIA_OM_USA_OM0C011U

Press .

The air conditioning system begins to operate. Air outlets and fan speed
are automatically adjusted according to the temperature setting.

Adjust the temperature setting.

To stop the operation, press

.

■

Automatic mode indicator

If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.

■

Adjusting the temperature for driver and passenger seats sep-
arately (“SYNC” mode)

Perform the following procedures to turn on the “SYNC” mode:

● Press .

● Adjust the passenger’s side temperature setting.

The indicator comes on when the “SYNC” mode is on.
While in “SYNC” mode, the temperature of the rear air outlets is
set at the right-hand side temperature setting.

■

Switching between outside air and recirculated air modes

Press .

The mode switches between outside air mode (the indicator is off) and
recirculated air mode (the indicator is on) each time the button is
pressed.

Using automatic mode

Other functions

1

2

3

323

5-1. Using the air conditioning system and defogger

5

In

te

rior fe

atures

SEQUOIA_OM_USA_OM0C011U

■

Defogging the windshield

Defoggers are used to defog the windshield and front side win-
dows.

Press .

The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to the outside air mode if
the recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.

To return to the previous mode, press

 again when the windshield

is defogged.

■

Defogging the rear window and outside rear view mirrors (if
equipped)

Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.

Before operating the defoggers, make sure the back window is
completely closed. (

→P. 152)

Press

.

The defoggers will automatically turn off after their operation time. The
operation time varies depending on the ambient temperature and vehi-
cle speed.

■

Windshield wiper de-icer (if equipped)

This feature is used to prevent ice from building up on the wind-
shield and wiper blades.

Press .

The windshield wiper de-icer will automatically turn off after their opera-
tion time. The operation time varies depending on the ambient tempera-
ture and vehicle speed.

324

5-1. Using the air conditioning system and defogger

SEQUOIA_OM_USA_OM0C011U

■

Adjusting the temperature setting

Press .

Press

 to increase the temperature and

 to decrease

it.

The air conditioning system switches between individual and simultane-

ous modes each time

 is pressed.

■

Location of air outlets

The air outlets and air volume
changes according to the
selected airflow mode.

■

Adjusting the position of and opening and closing the air out-
lets

Changing the rear seat settings

Air outlets

1

2



Driver’s side



Front passenger’s side

Direct air flow to the left or right, up or down.

Turn the knob to open or close the vent.

325

5-1. Using the air conditioning system and defogger

5

In

te

rior fe

atures

SEQUOIA_OM_USA_OM0C011U

■

Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.

Therefore, the fan may stop for a while until warm or cool air is ready to flow

immediately after

 is pressed.

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high.

Turning

 on will dehumidify the air from the outlets and defog the wind-

shield effectively.

●

If you turn

 off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Outside/recirculated air mode

●

When driving on dusty roads, in tunnels, or in heavy traffic, set the outside/
recirculated air mode to the recirculated air mode. This is effective in pre-
venting outside air from entering the vehicle interior. During cooling opera-
tion, setting the recirculated air mode will also cool the vehicle interior
effectively.

●

Outside/recirculated air mode may automatically switch depending on the
temperature setting, outside temperature, pressure, engine coolant tem-
perature or inside temperature.

■

When the outside temperature exceeds 75 °F (24 °C) and the air condi-
tioning system is on

●

In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.

●

Recirculated air mode is selected as a default mode when the engine switch
is turned to the “ON” position.

●

It is possible to switch to outside air mode at any time by pressing



.

■

When the outside temperature falls to nearly 32 °F (0 °C)

The dehumidification function may not operate even when

 is pressed.

326

5-1. Using the air conditioning system and defogger

SEQUOIA_OM_USA_OM0C011U

■

When driving on dusty roads
Close all windows. If dust thrown up by the vehicle is still drawn into the vehi-
cle after closing the windows, it is recommended that the air intake mode be
set to outside air mode and the fan speed to any setting except off.

■

When the indicator light on

 flashes

Press



to turn off the cooling and dehumidification function and turn it on

again. There may be a problem in the air conditioning system if the indicator
light continues to flash. Turn the air conditioning system off and have it
inspected by your Toyota dealer.

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

●

To reduce potential odors from occurring:

• It is recommended that the air conditioning system be set to outside air

mode prior to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time

immediately after the air conditioning system is started in automatic
mode.

■

Air conditioning filter
→P. 422

327

5-1. Using the air conditioning system and defogger

5

In

te

rior fe

atures

SEQUOIA_OM_USA_OM0C011U

WARNING

■

To prevent the windshield from fogging up

●

Do not use

 during cool air operation in extremely humid weather.

The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mir-
ror defoggers are on.

●

Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on.

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is stopped.

●

Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.

328

5-1. Using the air conditioning system and defogger

SEQUOIA_OM_USA_OM0C011U

Rear air conditioning system

■

Change the fan speed setting

To change the fan speed, press

,



or .

Press



to turn the fan off.

■

Adjusting the temperature setting

To adjust the fan speed, press



to increase the fan speed and



to decrease the fan speed.

Airflow and outlets are automatically adjusted according to the
temperature setting.

329

5-1. Using the air conditioning system and defogger

5

In

te

rior fe

atures

SEQUOIA_OM_USA_OM0C011U

■

Change the airflow mode

To change the airflow mode,
press the button.
The indicator comes on.

Air flows to the upper body.

Air flows to the upper body
and feet.

Air flows to the feet.

Press .

The air conditioning system begins to operate. Air outlets and fan speed
are automatically adjusted according to the temperature setting.

Adjust the temperature setting.

To stop the operation, press

.

Using automatic mode

1

2

3

330

5-1. Using the air conditioning system and defogger

SEQUOIA_OM_USA_OM0C011U

■

Location of air outlets

The air outlets and air volume
changes according to the
selected airflow mode.

■

Adjusting the position of the roof side air outlets

Direct air flow to the left or right,
up or down.

Air outlets

331

5-1. Using the air conditioning system and defogger

5

In

te

rior fe

atures

SEQUOIA_OM_USA_OM0C011U

■

Button lock function
During the “SYNC” mode is on, the rear air conditioning system buttons will
be automatically locked. (

→P. 322)



appears on the display when the buttons are locked.

To unlock the buttons, choose the “SYNC” mode is off.

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is stopped.

332

5-1. Using the air conditioning system and defogger

SEQUOIA_OM_USA_OM0C011U

Seat heaters

∗

/seat ventilators

∗

∗

: If equipped

The seat heaters warm the seats and the seat ventilators main-
tain good airflow by blowing air through the seats.

WARNING

●

Care should be taken to prevent injury if anyone in the following categories
comes in contact with the seats when the heater is on:

• Babies, small children, the elderly, the sick and the physically chal-

lenged

• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

●

Observe the following precautions to prevent the minor burns or overheat-
ing

• Do not cover the seat with a blanket or cushion when using the seat

heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.

●

To prevent battery discharge, do not use the functions when the engine is
off.

333

5-1. Using the air conditioning system and defogger

5

In

te

rior fe

atures

SEQUOIA_OM_USA_OM0C011U

■

Front seats



Vehicles without ventilator

On

The indicator light comes on.

Adjusts the seat temperature

The further you move the dial
upward, the warmer the seat
becomes.

Off

Move the dial fully downward.
The indicator light turns off.



Vehicles with ventilator

Off

Set the dial to 0. The indicator
turns off.

Heats the seats

The indicator comes on. The
higher the number, the warmer
the seats become.

Blows air from the seats

The indicator comes on. The
higher the number, the stronger
the airflow becomes.

Seat heaters/ventilators

334

5-1. Using the air conditioning system and defogger

SEQUOIA_OM_USA_OM0C011U

■

Rear seat (vehicles with rear console box)

High heating temperature

The indicator (yellow) comes
on.
Press lightly on the opposite
side to turn off.

Low heating temperature

The indicator (green) comes
on.
Press lightly on the opposite
side to turn off.

■

The seat heaters/seat ventilators can be used when
The engine switch is in the “ON” position.

335

5-2. Using the interior lights

5

In

te

rior fe

atures

SEQUOIA_OM_USA_OM0C011U

Interior lights list

Outer foot lights (if equipped)

Interior light (

→P. 338)

Personal/interior lights (

→P. 337)

Engine switch light

Footwell lights

Door courtesy lights

Auxiliary lighting

336

5-2. Using the interior lights

SEQUOIA_OM_USA_OM0C011U

On

The personal/interior lights cannot
be individually turned off.

Door position

The personal/interior lights come
on when a door is opened. They
turn off when the doors are closed.

Off

The personal/interior lights and
interior light can be individually
turned on or off.

Personal/interior light main switch
