Toyota C-HR (2018 year). Manual - part 11

161

4-1. Before driving

Drivin

Dinghy towing

Your vehicle is not designed to be dinghy towed (with 4 wheels
on the ground) behind a motor home.

NOTICE

■

To avoid serious damage to your vehicle
Do not tow your vehicle with all four wheels on the ground.

162

4-2. Driving procedures

Engine (ignition) switch (vehicles without a

smart key system)

Check that the parking brake is set.
Check that the shift lever is in P.
Firmly depress the brake pedal.
Turn the engine switch to the “START” position to start the engine.

“LOCK”

The steering wheel is locked and
the key can be removed. The key
can be removed only when the
shift lever is in P.

“ACC”

Some electrical components such
as the power outlet can be used.

“ON”

All electrical components can be used.

“START”

For starting the engine.

Starting the engine

Changing the engine switch positions

1
2
3
4

163

4-2. Driving procedures

Drivin

■

Turning the key from “ACC” to “LOCK”

Shift the shift lever to P. (

→P. 171)

■

If the engine does not start
The engine immobilizer system may not have been deactivated. (

→P. 74)

Contact your Toyota dealer.

■

When the steering lock cannot be released

■

Key reminder function
A buzzer sounds if the driver’s door is opened while the engine switch is in
the “LOCK” or “ACC” position to remind you to remove the key.

Push in the key and turn it to the
“LOCK” position.

When starting the engine, the engine
switch may seem stuck in the “LOCK”
position. To free it, turn the key while turn-
ing the steering wheel slightly left and
right.

164

4-2. Driving procedures

WARNING

■

When starting the engine
Always start the engine while sitting in the driver’s seat. Do not depress the
accelerator pedal while starting the engine under any circumstances.
Doing so may cause an accident resulting in death or serious injury.

■

Caution when driving
Do not turn the engine switch to the “LOCK” position while driving. If, in an
emergency, you must turn the engine off while the vehicle is moving, turn
the engine switch only to the “ACC” position to stop the engine. An accident
may result if the engine is stopped while driving. (

→P. 397)

NOTICE

■

To prevent battery discharge
Do not leave the engine switch in the “ACC” or “ON” position for long peri-
ods of time without the engine running.

■

When starting the engine

●

Do not crank the engine for more than 30 seconds at a time. This may
overheat the starter and wiring system.

●

Do not race a cold engine.

●

If the engine becomes difficult to start or stalls frequently, have your vehi-
cle checked by your Toyota dealer immediately.

165

4-2. Driving procedures

Drivin

Engine (ignition) switch (vehicles with a

smart key system)

Check that the parking brake is set.
Check that the shift lever is in P.
Firmly depress the brake pedal.

and message will be displayed on the multi-information display.

If it is not displayed, the engine cannot be started.

Press the engine switch shortly
and firmly.

When operating the engine switch,
one short, firm press is enough. It
is not necessary to press and hold
the switch.
The engine will crank until it starts
or for up to 30 seconds, whichever
is less.
Continue depressing the brake
pedal until the engine is completely
started.
The engine can be started from
any engine switch mode.

Performing the following operations when carrying the elec-
tronic key on your person starts the engine or changes engine
switch modes.

Starting the engine

1
2
3

166

4-2. Driving procedures

Stop the vehicle.
Set the parking brake (

→P. 178), and shift the shift lever to P.

If the parking brake is in automatic mode, the parking brake is set automat-
ically when shifting the shift lever to P. (

→P. 177)

Press the engine switch.
Release the brake pedal and check that “ACCESSORY” on the
multi-information display is off.

Modes can be changed by pressing the engine switch with brake
pedal released. (The mode changes each time the switch is pressed.)

Off

The emergency flashers can be
used.
The multi-information display will
not be displayed.

ACCESSORY mode

Some electrical components such
as the audio system can be used.
“ACCESSORY” will be displayed
on the multi-information display.

IGNITION ON mode

All electrical components can be
used.
“IGNITION ON” will be displayed on the multi-information display.

: If the shift lever is in a position other than P when turning off the engine,

the engine switch will be turned to ACCESSORY mode, not to off.

Stopping the engine

Changing engine switch modes

1
2

3
4

IGNITION ON

ACCESSORY

167

4-2. Driving procedures

Drivin

If the engine is stopped with the shift lever in a position other than P,
the engine switch will not be turned off but instead be turned to
ACCESSORY mode. Perform the following procedure to turn the
switch off:

Check that the parking brake is set.
Shift the shift lever to P.
Check that “ACCESSORY” and “Turn power OFF.” are displayed
on the multi-information display and then press the engine switch
once.
Check that “ACCESSORY” and “Turn power OFF.” on the multi-
information display are off.

■

Auto power off function
If the vehicle is left in ACCESSORY mode for more than 20 minutes or IGNI-
TION ON mode (the engine is not running) for more than an hour with the
shift lever in P, the engine switch will automatically turn off.
However, this function cannot entirely prevent battery discharge. Do not leave
the vehicle with the engine switch in ACCESSORY or IGNITION ON mode for
long periods of time when the engine is not running.

■

Electronic key battery depletion
→P. 102

■

Conditions affecting operation
→P. 121

■

Notes for the entry function
→P. 122

■

If the engine does not start

●

The engine immobilizer system may not have been deactivated. (

→P. 74)

Contact your Toyota dealer.

●

Check that the shift lever is securely set in P. The engine may not start if the
shift lever is displaced out of P.
“Shift to P Position to Start.” will be displayed on the multi-information dis-
play.

When stopping the engine with the shift lever in a position other
than P

1
2
3

168

4-2. Driving procedures

■

Steering lock
After turning the engine switch off and opening and closing the doors, the
steering wheel will be locked due to the steering lock function. Operating the
engine switch again automatically cancels the steering lock.

■

When the steering lock cannot be released

■

Steering lock motor overheating prevention
To prevent the steering lock motor from overheating, the motor may be sus-
pended if the engine is turned on and off repeatedly in a short period of time.
In this case, refrain from operating the engine. After about 10 seconds, the
steering lock motor will resume functioning.

■

When the “Entry & Start System Malfunction. See Owner’s Manual.” is
displayed on the multi-information display
The system may be malfunctioning. Have the vehicle inspected by your
Toyota dealer immediately.

■

If the electronic key battery is depleted
→P. 373

■

Operation of the engine switch

●

If the switch is not pressed shortly and firmly, the engine switch mode may
not change or the engine may not start.

●

If attempting to restart the engine immediately after turning the engine
switch off, the engine may not start in some cases. After turning the engine
switch off, please wait a few seconds before restarting the engine.

■

If the smart key system has been deactivated in a customized setting
→P. 436

“Push ENGINE Switch while Turning The
Steering Wheel in Either Direction.” will be
displayed on the multi-information display.
Check that the shift lever is set in P. Press
the engine switch while turning the steer-
ing wheel left and right.

169

4-2. Driving procedures

Drivin

WARNING

■

Caution while driving
If engine failure occurs while the vehicle is moving, do not lock or open the
doors until the vehicle reaches a safe and complete stop. Activation of the
steering lock in this circumstance may lead to an accident, resulting in
death or serious injury.

■

Stopping the engine in an emergency

●

If you want to stop the engine in an emergency while driving the vehicle,
press and hold the engine switch for more than 2 seconds, or press it
briefly 3 times or more in succession. (

→P. 397)

However, do not touch the engine switch while driving except in an emer-
gency. Turning the engine off while driving will not cause loss of steering or
braking control, but the power assist to these systems will be lost. This will
make it more difficult to steer and brake, so you should pull over and stop
the vehicle as soon as it is safe to do so.

●

If the engine switch is operated while the vehicle is running, a warning
message will be shown on the multi-information display and a buzzer
sounds.

●

When restarting the engine after it was turned off while driving, shift the
shift lever to N and press the engine switch.

170

4-2. Driving procedures

NOTICE

■

To prevent battery discharge

●

Do not leave the engine switch in ACCESSORY or IGNITION ON mode
for long periods of time without the engine running.

●

If “ACCESSORY” or “IGNITION ON” is displayed on the multi-information
display, the engine switch is not off. When exiting the vehicle, always
check that the engine switch is off.

●

Do not stop the engine when the shift lever is in a position other than P. If
the engine is stopped in another shift lever position, the engine switch will
not be turned off but instead be turned to ACCESSORY mode. If the vehi-
cle is left in ACCESSORY mode, battery discharge may occur.

■

When starting the engine

●

Do not race a cold engine.

●

If the engine becomes difficult to start or stalls frequently, have your vehi-
cle checked by your Toyota dealer immediately.

■

Symptoms indicating a malfunction with the engine switch
If the engine switch seems to be operating somewhat differently than usual,
such as the switch sticking slightly, there may be a malfunction. Contact
your Toyota dealer immediately.

171

4-2. Driving procedures

Drivin

Continuously variable transmission

Vehicles without a smart key system:
While the engine switch is in the “ON” position, depress the
brake pedal and while pressing the button move the shift lever.

When shifting the shift lever between P and D, make sure that the
vehicle is completely stopped.

Vehicles with a smart key system:
While the engine switch is in IGNITION ON mode, depress the
brake pedal and while pressing the button move the shift lever.

When shifting the shift lever between P and D, make sure that the
vehicle is completely stopped.

Shifting the shift lever

172

4-2. Driving procedures

: To improve fuel efficiency and reduce noises, set the shift lever in D for

normal driving.

: Selecting gear step using the M position achieves suitable engine braking

forces by operating the shift lever.

→P. 251

To enter 7-speed sport sequential shiftmatic mode, shift the shift lever
to M position. Gear steps can then be selected by operating the shift
lever, allowing you to drive in the gear step of your choosing.

Upshifting
Downshifting

The gear changes once every time
the shift lever is operated.
The selected gear step, from M1 to
M7, will be displayed in the meter.

However, even when in the M position, the gear steps will be auto-
matically changed if the engine speed is too high, or too low.

Shift position purpose

Shift position

Objective or function

Parking the vehicle/starting the engine

Reversing

Neutral

Normal driving

7-speed sport sequential shiftmatic mode driving

(

→P. 172)

Selecting a driving mode

Changing gear steps in the M position

173

4-2. Driving procedures

Drivin

■

Gear step functions

●

You can choose from 7 levels of engine braking force.

●

A lower gear step will provide greater engine braking force than a higher
gear step, and the engine speed will also increase.

■

If the 7-speed sport sequential shiftmatic mode indicator does not come
on even after shifting the shift lever to M
This may indicate a malfunction in the continuously variable transmission
system. Have the vehicle inspected by your Toyota dealer immediately.
(In this situation, the transmission will operate in the same manner as when
the shift lever is in D.)

■

When the vehicle comes to a stop with the shift lever in the M position

●

The transmission will automatically downshift to M1 once the vehicle is
stopped.

●

After a stop, the vehicle will start off in M1.

●

When the vehicle is stopped, the transmission is set at M1.

■

When driving with dynamic radar cruise control with full-speed range
activated
Even when performing the following actions with the intent of enabling engine
braking, engine braking will not activate because cruise control will not be
canceled.

●

When switching the driving mode to sport mode while driving in D position.
(

→P. 251)

■

Downshifting restrictions warning buzzer
To help ensure safety and driving performance, downshifting operation may
sometimes be restricted. In some circumstances, downshifting may not be
possible even when the shift lever is operated. (A buzzer will sound twice.)

■

Shift lock system
The shift lock system is a system to prevent accidental operation of the shift
lever in starting.
The shift lever can be shifted from P only when the engine switch is in the
“ON” position (vehicles without a smart key system) or IGNITION ON mode
(vehicles with a smart key system), and the brake pedal is being depressed.

174

4-2. Driving procedures

■

If the shift lever cannot be shifted from P
First, check whether the brake pedal is being depressed.
If the shift lever cannot be shifted with your foot on the brake pedal while
pressing the button on the shift knob, there may be a problem with the shift
lock system. Have the vehicle inspected by your Toyota dealer immediately.
The following steps may be used as an emergency measure to ensure that
the shift lever can be shifted.
Releasing the shift lock:

Set the parking brake.
Turn the engine switch to the “LOCK” position (vehicles without a smart key
system) or off (vehicles with a smart key system).
Depress the brake pedal.

■

G AI-SHIFT
G AI-SHIFT automatically selects a suitable gear for sporty driving according
to driver’s input and driving conditions. G AI-SHIFT operates automatically
when the shift lever is in D and sport mode is selected for the driving mode.
(Selecting normal mode or shifting the shift lever to the M position cancels
this function.)

Remove the cover.
Remove the cover using flathead
screwdriver. To prevent damage to the
cover, tip the screwdriver with a rag.

Press the shift lock override button
while pressing the button on the shift
knob.
The shift lever can be shifted while the
button is pressed.

175

4-2. Driving procedures

Drivin

WARNING

■

When driving on slippery road surfaces
Be careful of downshifting and sudden acceleration, as this could result in
the vehicle skidding to the side or spinning.

■

To prevent an accident when releasing the shift lock
Before pressing the shift lock override button, make sure to set the parking
brake and depress the brake pedal.
If the accelerator pedal is accidentally depressed instead of the brake pedal
when the shift lock override button is pressed and the shift lever is shifted
out of P, the vehicle may suddenly start, possibly leading to an accident
resulting in death or serious injury.
