Toyota Matrix (2014 year). Manual

214

3-2. Using the audio system

MATRIX_U

NOTICE

■

CD player precautions

Failure to follow the precautions below may result in serious damage to the
CDs or the player itself.

●

Do not insert anything other than CDs into the CD slot.

●

Do not apply oil to the CD player.

●

Store CDs away from direct sunlight.

●

Never try to disassemble any part of the CD player.

215

3-2. Using the audio system

Inte
rior fea

tures

MATRIX_U

Playing MP3 and WMA discs

Type A

Type B

Volume

Random playback

Selecting a file

Repeat play

Playback

Power

Disc eject

Displays text message

Search playback

Selecting a folder

Selecting a file

Reverse

Fast-forward

Power

Volume

Search playback

Disc eject

Displays text message

Playback

Selecting a file
or displays
folder list

Repeat play

Random playback

Selecting a folder, fast-forwarding
and rewinding

Selecting a
file

216

3-2. Using the audio system

MATRIX_U

Loading and ejecting MP3 and WMA discs

→P. 208

Selecting MP3 and WMA discs (with a CD changer) (type A)

→P. 209

Selecting and scanning a folder

Type A

■

Selecting folders one at a time

Press “

∧” or “∨” on

to select the desired folder.

■

Scanning the first file of all the folders

Press and hold

until you hear a beep.

The first ten seconds of the first file in each folder will be played.

When the desired folder is reached, press

again.

■

Returning to the first folder

Press and hold “

∨” on

until you hear a beep.

STEP

217

3-2. Using the audio system

Inte
rior fea

tures

MATRIX_U

Type B

■

Selecting folders one at a time

Press

(

) or

(

) to select the desired folder.

■

Selecting a folder and file from a folder list

Press .

The folder list will be displayed.

Turn and press

to select a folder and a file.

To return to the previous display, press

(BACK).

■

Returning to the first folder

Press and hold

(

) until you hear a beep.

■

Scanning a folder

Press and hold

until you hear a beep.

The first 10 seconds of the first file in the each folder will be played.

When the desired folder is reached, press

again.

Selecting and scanning files

■

Selecting one file at a time

Turn

or press “

∧” or “∨” on

to select

the desired file.

■

Selecting the desired file by cueing the files in the folder
Press

When the desired file is reached, press

once

again.

STEP

218

3-2. Using the audio system

MATRIX_U

Fast-forwarding and reversing files

→P. 208

Repeat play

■

Repeating a file (type A)
Press

(RPT).

To cancel, press the button once more (without a CD changer), or twice
more (with a CD changer).

■

Repeating all of the files in a folder
Type A
Press and hold

(RPT) until you hear a beep.

To cancel, press the button again.

Type B
Pressing

(RPT) changes modes in the following order:

File repeat

→ Folder repeat* → Off

*: Available except when RDM (random playback) is selected

219

3-2. Using the audio system

Inte
rior fea

tures

MATRIX_U

Random playback

Type A

■

Playing files from a particular folder in random order
Press

(RAND).

To cancel, press the button once more (without a CD changer), or twice
more (with a CD changer).

■

Playing all of the files on a disc in random order
Press and hold

(RAND) until you hear a beep.

To cancel, press the button again.

Type B

Pressing

(RDM) changes modes in the following order:

Folder random

→ Disc random → Off

Switching the display

Type A

Press .

Each time

is pressed, the display changes in the following order:

Folder no./File no./Elapsed time

→ Folder name → File name → Album

title (MP3 only)

→ Track title → Artist name.

Type B

Press .

Track title, Artist name and Album title (MP3 only) are shown on the dis-
play.

To return to the previous display, press

(BACK).

220

3-2. Using the audio system

MATRIX_U

■

Display
→P. 211

■

Error messages

“CD CHECK”:This indicates a problem either in the CD or inside the player.

The CD may be dirty, damaged or inserted up-side down.

“NO MUSIC” (type A): This indicates that MP3/WMA files are not included in

the CD.

“WAIT” or “PLEASE WAIT” (type A): Operation has stopped due to a high

temperature inside the player. Wait for
a while and then press

. Contact

your Toyota dealer if the CD still cannot
be played.

“ERROR” (type B): This indicates a problem either in the CD or inside the

player.

“NO

SUPPORT”

(type

B):This indicates that MP3/WMA files are not

included in the CD.

■

Discs that can be used
→P. 212

■

CD player protection feature
→P. 212

■

If CDs are left inside the CD player or in the ejected position for
extended periods
→P. 212

■

Lens cleaners
→P. 212

221

3-2. Using the audio system

Inte
rior fea

tures

MATRIX_U

■

MP3 and WMA files

MP3 (MPEG Audio LAYER3) is a standard audio compression format.

Files can be compressed to approximately 1/10 of their original size by using
MP3 compression.

WMA (Windows Media Audio) is a Microsoft audio compression format.

This format compresses audio data to a size smaller than that of the MP3
format.

There is a limit to the MP3 and WMA file standards that can be used and to
the media/formats on which the files are recorded.

●

MP3 file compatibility

• Compatible standards

MP3 (MPEG1 LAYER3, MPEG2 LSF LAYER3)

• Compatible sampling frequencies

MPEG1 LAYER3: 32, 44.1, 48 (kHz)
MPEG2 LSF LAYER3: 16, 22.05, 24 (kHz)

• Compatible bit rates (compatible with VBR)

MPEG1 LAYER3: 64, 80, 96, 112, 128, 160, 192, 224, 256, 320 (kbps)
MPEG2 LSF LAYER3: 64, 80, 96, 112, 128, 144, 160 (kbps)

• Compatible channel modes: stereo, joint stereo, dual channel and

monaural

●

WMA file compatibility

• Compatible standards

WMA Ver. 7, 8, 9

• Compatible sampling frequencies

32, 44.1, 48 (kHz)

• Compatible bit rates (only compatible with 2-channel playback)

Ver. 7, 8: CBR 48, 64, 80, 96, 128, 160, 192 (kbps)
Ver. 9: CBR 48, 64, 80, 96, 128, 160, 192, 256, 320 (kbps)

222

3-2. Using the audio system

MATRIX_U

●

Compatible media

Media that can be used for MP3 and WMA playback are CD-Rs and CD-
RWs.

Playback in some instances may not be possible, depending on the status
of the CD-R or CD-RW. Playback may not be possible or the audio may
jump if the disc is scratched or marked with fingerprints.

●

Compatible disc formats

The following disc formats can be used.

• Disc formats: CD-ROM Mode 1 and Mode 2

CD-ROM XA Mode 2, Form 1 and Form 2

• File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet)

MP3 and WMA files written in any format other than those listed above
may not play correctly, and their file names and folder names may not
be displayed correctly.

Items related to standards and limitations are as follows.

• Maximum directory hierarchy: 8 levels
• Maximum length of folder names/file names: 32 characters
• Maximum number of folders: 192 (including the root)
• Maximum number of files per disc: 255

●

File names

The only files that can be recognized as MP3/WMA and played are those
with the extension .mp3 or .wma.

●

Multi-sessions

As the audio system is compatible with multi-sessions, it is possible to play
discs that contain MP3 and WMA files. However, only the first session can
be played.

223

3-2. Using the audio system

Inte
rior fea

tures

MATRIX_U

●

ID3 and WMA tags

ID3 tags can be added to MP3 files, making it possible to record the track
title, artist name, etc.

The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags.
(The number of characters is based on ID3 Ver. 1.0 and 1.1.)

WMA tags can be added to WMA files, making it possible to record the
track title and artist name in the same way as with ID3 tags.

●

MP3 and WMA playback

When a disc containing MP3 or WMA files is inserted, all files on the disc
are first checked. Once the file check is finished, the first MP3 or WMA file
is played. To make the file check finish more quickly, we recommend you
do not write in any files other than MP3 or WMA files or create any unnec-
essary folders.

If the discs contain a mixture of music data and MP3 or WMA format data,
only music data can be played.

●

Extensions

If the file extensions .mp3 and .wma are used for files other than MP3 and
WMA files, they will be mistakenly recognized and played as MP3 and
WMA files. This may result in large amounts of interference and damage
to the speakers.

●

Playback

• To play MP3 files with steady sound quality, we recommend a fixed bit

rate of 128 kbps and a sampling frequency of 44.1 kHz.

• CD-R or CD-RW playback may not be possible in some instances,

depending on the characteristics of the disc.

• There is a wide variety of freeware and other encoding software for

MP3 and WMA files on the market, and depending on the status of the
encoding and the file format, poor sound quality or noise at the start of
playback may result. In some cases, playback may not be possible at
all.

• When files other than MP3 or WMA files are recorded on a disc, it may

take more time to recognize the disc. In some cases, playback may not
be possible at all.

• Microsoft, Windows, and Windows Media are the registered trade-

marks of Microsoft Corporation in the U.S. and other countries.

225

3-2. Using the audio system

Inte
rior fea

tures

MATRIX_U

Operating an iPod

∗

: If equipped

Connecting an iPod enables you to enjoy music from the vehicle
speakers.

■

Connecting an iPod

Open the cover and connect
an iPod using an iPod cable.

Turn on the power of the iPod if
it is not turned on.

Press .

STEP

226

3-2. Using the audio system

MATRIX_U

■

Control panel

iPod menu
mode

Volume

Power

Selecting an iPod
menu/song or
displays song list

Shuffle playback

Repeat play

Playback

Displays text message

Selecting a
track

Reverse

Fast-forward

Adjusting sound quality and volume balance

227

3-2. Using the audio system

Inte
rior fea

tures

MATRIX_U

Selecting a play mode

Press

(MENU) to select iPod menu mode.

Turning

clockwise changes the play mode in the fol-

lowing order:

“Playlists”

→“Artists”→“Albums”→“Songs”→“Podcasts”→“Genres”

→“Composers”→“Audiobooks”

Press

to select the desired play mode.

■

Play mode list

Play mode

First

selection

Second

selection

Third

selection

Fourth

selection

“Playlists”

Playlists
select

Songs
select

“Artists”

Artists select

Albums
select

Songs
select

“Albums”

Albums
select

Songs
select

“Songs”

Songs select

“Podcasts”

Podcasts
select

Episodes
select

“Genres”

Genre select

Artists select

Albums
select

Songs
select

“Composers”

Composers
select

Albums
select

Songs
select

“Audiobooks”

Audiobooks
select

Chapters
select

STEP

228

3-2. Using the audio system

MATRIX_U

■

Selecting a list

Turn

to display the first selection list.

Press

to select the desired item.

Pressing the knob changes to the second selection list.
Repeat the same procedure to select the desired item.

To return to the previous selection list, press

(BACK).

Selecting songs

Turn

or press “

∧” or “∨” on

to select the desired song.

Selecting a song from the song list

Press .

The song list will be displayed.

Turn

to select a song.

Press

to play the song.

To return to the previous display, press

(BACK).

STEP

229

3-2. Using the audio system

Inte
rior fea

tures

MATRIX_U

Fast-forwarding and reversing songs

To fast-forward or reverse, press

(

) or

(

Shuffle playback

Pressing

(RDM) changes modes in the following order:

Track shuffle

→ Album shuffle → Off

Repeat play

Press

(RPT)

To cancel, press

(RPT) again.

Switching the display

Press .

To return to the previous display, press

(BACK).

Adjusting sound quality and volume balance

Press

to enter iPod menu mode.

Press

to change sound modes. (

→P. 242)

STEP

Toyota Matrix (2014 year). Manual - part 14
