PREPARATION  –  DRIVE SHAFT

PP–31

PP

PREPARATION

PREPARATION

DRIVE SHAFT

SST

09240-00020

Wire Gauge Set

09520-01010

Drive Shaft Remover Attachment

09520-24010

Differential Side Gear Shaft
Puller

(09520-32040)

Shocker Set

09521-24010

Rear Axle Shaft Puller

09527-10011

Rear Axle Shaft Bearing Remover

09628-62011

Boll Joint Puller

09950-00020

Bearing Remover

PP–32

PREPARATION  –  DRIVE SHAFT

PP

RECOMMENDED TOOLS

09040-00011

Hexagon Wrench Set

(09043-20050)

Socket Hexagon Wrench 5

09905-00012

Snap Ring No.1 Expander

PREPARATION  –  DRIVE SHAFT

PP–33

PP

EQUIPMENT

Torque wrench

PP–34

PREPARATION  –  DRIVE SHAFT

PP

LUBRICANT

Item

Capacity

Front drive shaft outboard joint grease

260 to 270 g (9.2 to 9.5 oz.)

Front drive shaft inboard joint grease

231 to 241 g (8.1 to 8.5 oz.)
