Suzuki SX4 (2010 year). Instruction - part 17

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Specifications: 1, 2, 5, 6, 7, 10, 11

SPECIFICATIONS

ITEM: Light

WATTAGE

BULB No.

Headlight

12V 65/55W

HB5

Front fog light

12V 55W

H11

Front turn signal light

12V 21W

WY21W

Rear turn signal light

12V 21W

WY21W

Position light

12V 5W

168

Brake/tail light

12V 21/5W

W21/5W

License plate light

12V 5W

W5W

Reversing light

12V 21W

W21W

Dome light

12V 10W

Luggage compartment light

12V 5W

Spot light

12V 8W

High mount stop light

SX4

12V 5W

W5W

SX4 SEDAN

12V18W

W16W

Side marker light

12V 5W

168

12-3

80J23-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Specifications: 1, 2, 5, 6, 7, 10, 11

SPECIFICATIONS

ITEM: Wheel

Tire size, front and rear

SX4

P195/65R15, P205/60R16, P205/50R17

SX4 SEDAN

P195/65R15, P205/50R17

Tire pressure

For the specified tire pressure, see the Tire Information Label located

on the driver’s door lock pillar.

ITEM: Steering

Toe

IN 1.0 ± 1.0 mm (0.0393 ± 0.0393 in.)

Camber angle

P195/65R15, P205/60R16

-0° 10’ ± 1°

P205/50R17

-0° 17’ ± 1°

Caster angle

P195/65R15, P205/60R16

3° 40’ ± 2°

P205/50R17

3° 46’ ± 2°

ITEM: Capacities

Coolant (including reserve tank)

M/T

7.1 L (15.0 US pt)

CVT

7.0 L (14.8 US pt)

Fuel tank

2WD

50 L (13.2 US gal)

i-AWD

45 L (11.9 US gal)

Engine oil (replaced with filter)

4.5 L (4.7 quarts)

Transaxle oil

Instruction transaxle: 2.5 L (5.3 US pt)

CVT: 9.44 L (19.9 US pt) (when overhauling)

Rear differential oil

0.8 L (1.7 US pt)

Transfer gear box oil

0.6 L (1.2 US pt)

12-4

80J23-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INDEX

Brake Assist System

3-21

INDEX

Brake Fluid

7-21

Symbols

Brake Pedal

3-8, 7-22

“CRUISE” Indicator Light

2-66

Brake System Warning Light

2-61

“ESP OFF” Indicator Light

2-63, 3-25

Brakes

7-21

“ESP” (Electronic Stability Program) Warning Light

2-63

Braking

3-20

“ESP” Warning Light

3-25

Break-In

4-1

“SET” Indicator Light

2-66

Bulb Replacement

7-40

Accelerator Pedal

3-8

Catalytic Converter

4-1

Accessory Socket

5-47

Changing Engine Oil and Filter

7-12

Adding Coolant

7-15

Changing Wheels

8-4

Adjusting Seat Position

2-21

Charging Light

2-64

Adjusting Seatbacks

2-22

Child Lock System (rear doors)

2-3

AIR BAG Light

2-65

Child Restraint Systems

2-36

Air Cleaner

7-16

Cigarette Lighter and Ashtray

5-47

Air Conditioning System

7-50

Clock

2-75

All Seat Belts

2-31

Clutch Pedal

3-8, 7-19

Anti-Lock Brake System (ABS)

3-21

Compact Spare Tire

7-31

Anti-Lock Brake System (ABS) Warning Light

2-62

Continuously Variable Transaxle (CVT)

3-11

Anti-Lock Braking System (ABS)

3-24

Continuously Variable Transaxle (CVT) Fluid

7-20

Armrest

5-51

Coolant Level Check

7-15

Assist Grips

5-48

Coolant Replacement

7-16

Audio Systems

5-15

Corrosion Prevention

9-1

Automatic Heating and Air Conditioning System

Cruise Control

3-18

(Climate Control)

5-9

Cup Holder and Storage Area

5-49

Automatic Locking Retractor (ALR)

2-30

Average fuel consumption

2-72

Daily Inspection Checklist

3-1

Daytime Running Light (D.R.L.) Indicator Light

2-68

Basic Operations

5-18

Daytime Running Light (D.R.L.) System

2-76

Battery

7-35

Door Locks

2-1

13-1

80J23-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INDEX

Drive Belt

7-11

FUSES AND PROTECTED CIRCUITS

11-1

Driver’s Seat Belt Reminder Light

2-64

Fuses in the Engine Compartment

7-36

Driving on Hills

4-3

Fuses under the Dash Board

7-38

Driving on Slippery Roads

4-4

Driving range

2-72

Gasoline Containing MTBE

1-1

Gasoline/Ethanol blends

1-1

Electronic Stability Program (ESP^®)

3-23

Gasoline/Methanol blends

1-1

Emergency Locking Retractor (ELR)

2-30

Gear Oil

7-18

Emission Compliance Label (for U.S.A.)

10-2

Gear Oil Level Check

7-19

Engine Block Heater

3-9

Gear Oil Replacement

7-19

Engine Coolant

7-14

GLOSSARY OF TIRE TERMINOLOGY

7-32

Engine Hood

5-44

Glove Box

5-49

Engine Oil and Filter

7-11

Engine Serial Number

10-1

Hazard Warning Switch

2-78

Exhaust Gas Warning

3-1

Head Restraints

2-22, 2-24

Headlight Aiming

7-39

Floor Mats

5-51

Heated Rear Window and Heated Outside Rearview

Fluid Level Check

7-20

Mirrors Switch

2-81

Folding Rear Seats

2-26

Heating and Air Conditioning System

5-1

Frame Hooks

5-56

Heating System

5-2

Front Air Bags

2-49

High Beam Indicator Light

2-67

Front Fog Light Switch

2-77

Highway Driving

4-3

Front Seat Back Pocket

5-50

Horn

2-81

Front Seat Heater

2-23

How the ABS Works

3-23

Front Seats

2-21

Fuel Filler Cap

5-43

Identification Numbers

10-1

Fuel Gauge

2-69

If the Engine is Flooded

8-7

Fuel Pump Labeling

1-1

If the Engine Overheats

8-7

Fuel Recommendation

1-1

If the Starter Does Not Operate

8-6

Full Wheel Cover

8-4

If You Cannot Shift CVT Gearshift Lever Out of

Fuses

7-36

“P” (PARK)

3-15

13-2

80J23-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INDEX

If Your Vehicle Gets Stuck

4-4

Lights “On” reminder

2-76

Ignition Key Reminder

2-1

Listening to a CD

5-22

Ignition Switch

3-2

Listening to a CD from an External CD Changer

Illumination control setting

2-74

(Option)

5-34

Illumination Indicator Light

2-67

Listening to a XM Satellite Radio (Option)

5-31

Improving Fuel Economy

4-2

Listening to Audio for AUX (Option)

5-33

Information display

2-70

Listening to the Radio

5-20

Inside Rearview Mirror

2-19

Low Fuel Warning Light

2-66

Installation of Child Restraint with Top Strap

2-44

Low Tire Pressure Warning Light

2-60, 3-26

Installation with Lap-Shoulder Seat Belts

Luggage Compartment Board

5-53

(child restraint with no top strap)

2-38

Luggage Compartment Cover

5-52

Installation with the LATCH System

2-40

Luggage Compartment Light

5-46

Instantaneous Fuel Consumption

2-70

Instrument Cluster

2-59

Maintenance Recommended under Severe Driving

intelligent All Wheel Drive (i-AWD) AUTO Indicator

Conditions

7-7

Light

2-67

Maintenance Schedule

7-2

intelligent All Wheel Drive (i-AWD) LOCK Indicator

Malfunction Indicator Light

2-65

Light

2-68

Instruction Heating and Air Conditioning System

5-5

Interior Light Switch

5-45

Instruction Transaxle

3-10

Mirrors

2-19

Jacking Instructions

8-2

Jump Starting Instructions

8-5

Odometer

2-74

Oil Level Check

7-11

Keyless Entry System Transmitter

2-13

Oil Pressure Light

2-64

Keyless Start System Indicator Light

2-66

On-Board Vehicle Computers and Event Data

Keyless Start System Remote Controller

2-6

Recorders

10-3

Keys

2-1

Open Door Warning Light

2-66

Outside Rearview Mirrors

2-20

Lap-Shoulder Belt

2-30

Lighting Control Lever

2-75

Parking Brake Lever

3-6, 7-23

Lighting Operation

2-76

Pedals

3-7

13-3

80J23-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INDEX

Periodic Maintenance Schedule

7-3

Side Door Locks

2-1

Power Door Locking System

2-2

SLIP Indicator Light

2-62, 3-25

Power Mirror Control

2-20

Snow Tires

7-32

Power Steering

7-24

Spark Plugs

7-16

Power Steering Fluid

7-24

SPECIFICATIONS

12-1

Power Window Controls

2-17

Specified Fluid

7-20

Power-Assisted Brakes

3-21

Specified Gear Oil

7-18

Specified Oil

7-11

Radio Antenna

5-15

Speedometer

2-68

Rear Seats

2-24

Spot Light

5-47

Rear Window Wiper/Washer Switch

2-80

Stability Control System

3-24

Refill with Oil and Check for Leaks

7-14

Starting the Engine

3-8

Refilling

7-12

Steering Wheel

7-23

Remote Audio Controls

5-37

Sun Visor

5-45

Replace the Oil Filter

7-13

Supplemental Restraint System (air bags)

2-47

Replacing Tires and/or Wheels

3-29

Reporting Safety Defects

10-4

Tachometer

2-69

Roof Rails or Roof Rack Anchors

5-55

Tailgate

2-3

Temperature Gauge

2-70

Safety Certification Label

10-2

Theft Deterrent Light

2-17

Seat Adjustment

2-21

Thermometer

2-73

Seat Belt Extender

2-45

Tilt Steering Lock Lever

2-81

Seat Belt Hanger

2-34

Tire Chains

4-5

Seat Belt Inspection

2-35

Tire Changing Tool

8-1

Seat Belt Pretensioner System

2-46

Tire Inflation Pressure

7-26

Seat Belt Reminder

2-32

Tire Inspection

7-28

Seat Belts and Child Restraint Systems

2-28

Tire Pressure Monitoring System (TPMS)

3-26

Selection of Coolant

7-14

Tire Rotation

7-30

Shopping Hook

5-51

Tire Sidewall Labeling

7-24

Shoulder Anchor Height Adjuster

2-34

Tire Size

7-25

Side Air Bags and Side Curtain Air Bags

2-50

Tires

7-24

13-4

80J23-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------

INDEX

Towing a Disabled Vehicle

8-6

Windshield Wiper and Washer Lever

2-78

Towing Your Vehicle (recreational towing)

6-2

Windshield Wipers

2-79

Traction Control System

3-24

Wiper Blades

7-46

Trailer Towing

6-2

Transaxle selector position indicator

2-73

Trip meter

2-72

Troubleshooting

5-41

Trunk Lid

2-4

Trunk Light

5-46

Turn Signal Control Lever

2-77

Turn Signal Indicators

2-67

Turn Signal Operation

2-77

Uniform Tire Quality Grading

7-29

Using the 2WD/i-AWD (intelligent All Wheel Drive)

Switch

3-16

Using the Transaxle

3-10

Vehicle Cleaning

9-3

Vehicle Identification Number

10-1

Vehicle Loading

6-1, 7-33

Vehicle With Keyless Start System

3-4

Vehicle Without Keyless Start System

3-3

Warning and Indicator Lights

2-60

Warranties

10-2

Washing

9-4

Waxing

9-5

Windows

2-17

Windshield Washer

2-79

Windshield Washer Fluid

7-50

13-5

80J23-03E

-------------------------------------------------------------------------------------------------------------------------------------------------------------
