Subaru Crosstrek (2019 year). Manual

(201,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

Clear setting

1. Select “Clear All Settings” from the 2nd
menu on the setting screen. Refer to
“Setting screen” F3-54.

2. Select “Yes” or “No” by using the
control switches.

Initialize

You can initialize the items that have been
set to your preference.
1. Select “Initialize” from the 2nd menu on
the setting screen. Refer to “Setting
screen” F3-54.

2. Select “Yes” or “No” by using the
control switches.

How to get the source code
using the open source

Free/Open Source Software Information

This product contains Free/Open Source
Software (FOSS).
The license information and/or the source
code of such FOSS can be found at the
following URL.

http://www.globaldenso.com/en/open-
source/ivi/subaru/

Instruments and controls/Multi-function display (color LCD)

3-59

(202,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

Clock

For models with a SUBARU genuine
navigation and/or audio system, the clock
can be adjusted using either auto mode or
manual mode.
.

Auto mode: automatic clock adjustment

Manual mode: manual clock adjust-

ment

Setting the clock manually

Type A multi-function display (black
and white)

1. Turn the ignition switch to “ON”.

2. Press the

button.

3. Select “Settings”.

4. Select “Vehicle”.
5. Select “Clock adjustment” and then
select “Manual”.

6. Press the “+” button or the “−” button
beside the clock.

Setting 12-hour or 24-hour dis-
play

The clock can be set to 12-hour or 24-hour
display. Perform the following procedure to
switch the display format.
1. Turn the ignition switch in the “LOCK”/
“OFF” position.
2. Press and hold the “−” button located
near the clock display for approximately 5
seconds. The clock display will then start
to flash.
3. While the clock display is flashing,
press and hold the “+” button for approxi-
mately 2 seconds. The clock format will
then change.
4. The clock display will continue to flash
for approximately 3 seconds to indicate
that the clock display has been changed.

Instruments and controls/Clock

3-60

(203,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

Type B multi-function display (color
LCD)

NOTE

When the combination meter display
(color LCD) is displaying the menu
screen entering screen, the system will
not move to the selection screen even if
the “INFO” button is pressed and held.
Before adjusting the clock, be sure to
change the combination meter display
(color LCD) to a screen other than the
menu screen entering screen.

1. Turn the ignition switch to “ON”.

2. Press the

button.

3. Select “Settings”.
4. Select “Vehicle”.
5. Select “Clock adjustment” and then
select “Manual”.

“INFO” button

6. Press the “INFO” button on the steer-
ing wheel to display the guidance screen.

7. While displaying the guidance screen,
press and hold the “INFO” button on the
steering wheel. The screen goes to the
selection screen.

– CONTINUED –

Instruments and controls/Clock

3-61

(204,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

1)
2)

/SET

8. Pull the “

” or “

” switch to select the

item.

9. Select “Time/Date” and pull the

/SET

switch.

10. Select “Time/Date” and pull the

/SET

switch.

NOTE

If “Clock adjustment” is not in manual
mode, “Time/Date” cannot be selected.
Be sure to perform steps 2 through 5.

11. Pull the “

”, “

” switches to scroll

through to the items you can set.

(1) Use the

/ SET switch to choose

the item you would like to change.
(2) Pull the “

”, “

” switches to

adjust the items.

12. Select “Set” and pull the

/SET switch

to complete the clock setting.
Select “Go Back” to return to the previous
screen without saving settings.

NOTE

The Birthday/Anniversary and mainte-
nance reminder system function are
based on the time and date on the
multifunction display (color LCD).

Instruments and controls/Clock

3-62

(205,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

Setting the clock automati-
cally

1. Turn the ignition switch to “ON”.

2. Press the

button.

3. Select “Settings”.
4. Select “Vehicle”.
5. Select “Clock adjustment” and then
select “Auto”.
6. Press the

button again to complete

the setting.

Models with navigation system

The clock will be set automatically where a
GPS signal is available.

Models without navigation system

The clock will be set and adjusted auto-
matically when a smartphone is connected
via Bluetooth

for transferring phonebook

data.
1. Register the smartphone to the audio
system. For details, refer to “Bluetooth
SETTINGS” in the supplemental Owner’s
Manual for the audio/navigation system.
2. Transfer phonebook data to the sys-
tem. For details, refer to “Bluetooth SET-
TINGS” in the supplemental Owner’s
Manual for the audio/navigation system.
The clock will be adjusted automatically.

NOTE

Depending on the model of smart-
phone, the settings of the connected
smartphone may need to be changed.
(ex: For iOS or other models, notifica-
tion settings may need to be activated.)
For details, check the instructions on
connecting smartphones.

Regulatory information

The Bluetooth

word mark and logos are

registered trademarks owned by Bluetooth
SIG, Inc.

Light control switch

Precautions and tips

CAUTION

Use of any lights for a long period

of time while the engine is not
running can cause the battery to
discharge.

Before leaving the vehicle, make

sure that the lights are turned off.
If the vehicle is left unattended
for a long time with the lights
illuminated, the battery may be
discharged.

NOTE

Even if the key is removed from the

ignition switch, the lights can be illumi-
nated by operating the light control
switch from the “ ” (off) position to the
“

” or “

” position.

If the driver’s door is opened while

the lights are illuminated and the key is
removed from the ignition switch, the
chirp sound will inform the driver that
the lights are illuminated.

– CONTINUED –

Instruments and controls/Light control switch

3-63

(206,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

Headlights

To turn on the headlights, turn the knob on
the end of the turn signal lever.

“

” position:

Instrument panel illumination, headlights,
parking lights, front side marker lights, rear
side marker lights, tail lights and license
plate lights are on.
“

” position:

Instrument panel illumination, parking
lights, front side marker lights, rear side
marker lights, tail lights and license plate
lights are on.
“

” position (if equipped):

Auto on/off headlights

When the ignition switch is in the “ON”
position, the instrument panel illumination,
headlights, parking lights, front side mar-

ker lights, rear side marker lights, tail lights
and license plate lights are automatically
on or off depending on the level of the
ambient light.

NOTE

The sensitivity of the auto on/off head-
lights can be changed by a SUBARU
dealer. Consult your SUBARU dealer
for details. Also, for models with a
combination meter display (color
LCD), the setting can be changed using
the display. For details, refer to “Vehicle
Setting” F3-39.

Auto-on/off wiper-linked headlights

While the light control switch is in the
“AUTO” position, the headlights will auto-
matically turn on when the windshield
wipers operate several times. The head-
lights will automatically turn off when the
wipers stop.

NOTE

The ON/OFF setting of this function can
be changed by a SUBARU dealer.
Consult your SUBARU dealer for de-
tails.

“ ” position:
The headlights are all off.

Welcome lighting function (if
equipped)

The welcome lighting function turns on the
low beam headlight for smooth approach-
ing to or exiting from the vehicle at night or
in a dark place.

The function is activated while all of the
following conditions are met.
.

The light control switch is in the “AUTO”

position
.

It is dark enough to turn on the auto on/

off headlights

When approaching:
While the welcome lighting function is
activated, the low beam headlights will
automatically illuminate when unlocking
the doors and the rear gate by using the
remote keyless entry system.

The low beam headlights will remain
illuminated for 30 seconds

and then turn

off. However, if any of the following
operations is done, the low beam head-
lights will turn off.
.

The doors are locked.

The light control switch is turned to a

position other than “AUTO”.
.

The ignition switch is turned to the “ON”

position.

Instruments and controls/Light control switch

3-64

(207,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

When exiting:
While the welcome lighting function is
activated, the low beam headlights will
remain illuminated even when either of the
following operation is done.
.

The push-button ignition switch is

turned to the “OFF” status (models with
“keyless access with push-button start
system”)
.

The key is pulled out from the ignition

switch (models without “keyless access
with push-button start system”)

The low beam headlights will turn off under
any of the following conditions.
.

3 minutes have passed since the low

beam headlights were illuminated by the
welcome lighting function.
.

30 seconds have passed since the door

is opened and closed.

The light control switch is turned to a

position other than “AUTO”.
.

The locking procedure is performed

twice. When performing the unlocking
procedure after performing the locking
procedure, perform the locking procedure
twice again.

*1: The setting for the period of time in which the
low beam headlights remain on by the welcome
lighting function can be changed by a SUBARU
dealer. Contact your SUBARU dealer for de-

tails.

Sensor for the auto on/off head-
lights (if equipped)

The sensor is on the instrument panel as
shown in the illustration.

CAUTION

If any object is placed on or near the
sensor, the sensor may not detect
the level of the ambient light cor-
rectly and the auto on/off headlights
may not operate properly.

High/low beam change
(dimmer)

High beam

Low beam

When the headlights are on high beam, the
high beam indicator light “

” on the

combination meter is also on.

– CONTINUED –

Instruments and controls/Light control switch

3-65

(208,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

Headlight flasher

CAUTION

Do not hold the lever in the flashing
position for more than just a few
seconds.

To flash the headlights, pull the lever
toward you and then release it. The high
beam will stay on for as long as you hold
the lever.

When the headlights are on high beam, the
high beam indicator light “

” on the

combination meter also illuminates.

High beam assist function (if
equipped)

NOTE

The high beam assist function uti-

lizes the stereo camera installed at the
position of the front map lights.
.

For details on how to handle the

stereo camera, refer to the Owner’s
Manual supplement for the EyeSight
system.

The high beam assist function automati-
cally changes the headlight from high
beam to low beam (or vice versa).

When all of the following conditions are
met, the headlight will change to high
beam.
.

When the vehicle speed increases to or

above 20 mph (32 km/h).
.

There is no preceding or oncoming

vehicle.
.

The forward area of the vehicle is dark.

The road does not have a sharp curve.

When any of the following conditions is
met, the headlight will change to low beam.
.

When the vehicle speed decreases to

or below 10 mph (16 km/h).
.

When the forward area of the vehicle is

bright.
.

When there is a preceding or oncoming

vehicle.
.

When the EyeSight system is malfunc-

tioning or is temporarily stopped.

NOTE

The factory setting (default setting) for
this function is set as “operational”.
This setting can be changed to OFF
(non-operation) at SUBARU dealers.
For more details, contact a SUBARU
dealer.

How to use the high beam assist
function

The high beam assist function will be
activated when all the following conditions
are met.
.

The light control switch is in the “AUTO”

position and the low beam headlights are
on automatically.
.

The turn signal lever is pushed forward.

Instruments and controls/Light control switch

3-66

(209,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

High beam assist indicator

When the high beam assist function is
activated, the high beam assist indicator
light on the combination meter will illumi-
nate.

NOTE

If the high beam assist function is
malfunctioning or is temporarily
stopped, the headlight will be fixed at
low beam.

How to temporarily lower the sensi-
tivity of the high beam assist func-
tion

The sensitivity of the high beam assist
function can be lowered by performing the
following operations.
1. Before turning the ignition switch to the
“ON” position, set the light control switch to
the “AUTO” position and push the signal
lever forward (high beam position).
2. Turn the ignition switch to the “ON”
position and within approximately 15 sec-
onds, press the “

/ ” (following distance

setting) switch more than 10 times con-
secutively.

When the sensitivity of the high beam
assist function is lowered, the EyeSight
temporary stop indicator (White) “

” on

the combination meter will illuminate.

NOTE

The sensitivity of the high beam

assist function cannot be lowered in
the following conditions.

– Cruise control or Adaptive Cruise
Control is in operation
– The EyeSight warning indicator
(yellow) is illuminated

The sensitivity of the high beam

assist function returns to normal level

the next time the ignition switch is
turned to the “LOCK”/“OFF” position
and the engine is restarted.

How to change the headlight mode
manually

Change to the low beam:
When you return the turn signal lever to the
center position, the high beam assist
function will turn off and the high beam
assist indicator light will turn off.

Change to the high beam:
When you turn the light control switch to
the “

” position, the headlight mode will

be changed to the high beam.
At this time, the high beam assist function
will turn off, the high beam assist indicator
will turn off and the high beam indicator
light will turn on.

NOTE

After manually changing the head-

light mode to the high beam, if you turn
on the high beam assist function,
return the light control switch to the
“AUTO” position.
.

When manually changing the head-

light mode to the high beam, if you turn
the light control switch to the “

”

position, the instrument panel illumina-
tion, parking lights, front side marker
lights, rear side marker lights, tail lights

– CONTINUED –

Instruments and controls/Light control switch

3-67

(210,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

and license plate lights will be on.

Tips for the high beam assist sys-
tem

The high beam assist function recog-

nizes the conditions surrounding the ve-
hicle based on the brightness of illumina-
tion ahead of your vehicle, etc. Therefore,
the headlight mode may switch in some
situations that do not match to the driver’s
sense.
.

A bicycle or cargo cycle may not be

detected.
.

Under the following situations, the

brightness of ambient illumination may
not be detected correctly and the high
beam assist function may not work prop-
erly. As a result, the glare of the high beam
may disturb the oncoming vehicle or
vehicle ahead. Also, the low beam mode
may continue although there are no
oncoming vehicles and vehicles ahead.
In the such cases, change the headlight
mode manually.

– In bad weather (fog, snow, sand
storm, heavy rain, etc.).
– When the windshield glass is dirty or
fogged.
– When the windshield is cracked or
damaged.
– When the stereo camera is de-
formed or the stereo camera lenses

are dirty.
– If there are lights similar to the
headlights or the tail lights in the
surrounding area.
– When an oncoming vehicle or ve-
hicle ahead is driven without its head-
lights and tail lights on.
– If the headlights of an oncoming
vehicle or the tail lights of a vehicle
ahead are dirty or discolored, or if the
light beams are not aimed correctly.
– When a rapid change of brightness
continues while driving.
– When driving on a road with many
ups and downs or uneven surfaces.
– When driving on a road with many
curves.
– When there are some objects that
reflect light strongly, such as a road
sign or a mirror in vehicle ahead.
– When the rear part of the vehicle
ahead, such as a container, reflects
light strongly.
– When the headlights of your vehicle
are damaged or dirty.
– When your vehicle is tilted, such as
in case the vehicle has a flat tire or is
being towed.
– Immediately after the engine has
started.

In the following conditions, the head-

light mode will not be automatically chan-

ged from the high beam to the low beam.

– When your vehicle passes an on-
coming vehicle suddenly in a blind
curve.
– When another vehicle passes in
front of your vehicle.
– When an oncoming vehicle or ve-
hicle ahead comes in and out of view
because of continuous curves, median
strips, roadside trees, etc.

If the stereo camera detects the light of

the front fog lights of an oncoming vehicle,
the headlight mode may change from the
high beam to the low beam automatically.
.

The headlight mode may change from

the high beam to the low beam, or the low
beam mode may continue, when affected
by a street light, traffic signal, illumination
of an advertisement board, or a reflective
object such as a road sign and signboard.
.

The timing of the change of headlight

mode may differ due to the following
factors.

– Color or brightness of the headlights
of an oncoming vehicle or the tail lights
of a vehicle ahead.
– The headlights of the oncoming
vehicle or the tail lights of the vehicle
ahead are covered with mud, snow,
etc.
– Movement and direction of an on-
coming vehicle or a vehicle ahead.

Instruments and controls/Light control switch

3-68

(211,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

– When the headlights of an oncom-
ing vehicle or the tail lights of a vehicle
ahead illuminate on only one side.
– When the oncoming vehicle or
vehicle ahead is a motorcycle.
– Conditions of a road (slope, curve,
road surface, etc.).
– Number of passengers and weight
of loaded cargo.
– Limitation of the detection ability of
the stereo camera.

Daytime running light system

WARNING

When the daytime running lights are
illuminated, the tail lights do not
illuminate. When it becomes dark
outside, turn the light switch to the
“

” position to illuminate the head-

lights and tail lights. This will im-
prove visibility and allow other dri-
vers to see your vehicle more easily.

The daytime running lights will automati-
cally illuminate when the following condi-
tions are fulfilled.
.

The engine is running.

The parking brake is fully released.

The light control switch is in the “AUTO”

(if equipped), “

” or off position.

For CVT models, the select lever is in a

position other than the “P” position.

NOTE

When the light switch is in the “

”

position, the instrument panel illumina-
tion, front side marker lights, tail lights
and license plate lights are also illumi-
nated.

Steering Responsive Head-
light (SRH) (if equipped)

The target area of illumination when SRH
is activated

The target area of illumination when SRH
is not activated

SRH is a function that automatically moves
the headlight beam to the left or right in
accordance with the steering angle and
vehicle speed. This function helps to
improve the visibility at night by illuminat-
ing the road ahead at corners and inter-
sections.

– CONTINUED –

Instruments and controls/Steering Responsive Headlight (SRH)

3-69

(212,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

You can turn the SRH function on or off by
pressing the SRH OFF switch.

SRH OFF indicator

The SRH OFF indicator on the combina-
tion meter turns off when SRH is turned on.
The SRH OFF indicator on the combina-

tion meter illuminates when SRH is turned
off.

If SRH is malfunctioning, the SRH OFF
indicator on the combination meter flashes
when the ignition switch is in the “ON”
position. It indicates that SRH has been
deactivated. Contact a SUBARU dealer for
an inspection.

NOTE

If you turn the ignition switch to the

“OFF” position with SRH turned off and
then start the engine again, SRH will
automatically turn on.
.

When you turn the ignition switch to

the “ON” position, the SRH OFF indi-
cator will illuminate and turn off after
several seconds.
.

SRH only activates when the vehicle

is traveling forward at the speed of
approximately 5 mph (8 km/h) or more.
.

SRH may not activate when the shift

lever (MT models) is selected in 1st
gear.

Headlight beam leveler
(models with LED headlights)

The LED headlights produce more light
than conventional halogen headlights.
When the vehicle is carrying a heavy load
and the headlight beams are angled
upwards, the driver of an oncoming vehicle
may experience glare.
To prevent this, the automatic headlight
beam leveler adjusts the headlights to the
optimum height automatically depending
on the load the vehicle is carrying.

Instruments and controls/Headlight beam leveler (models with LED headlights)

3-70

(213,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

Fog light switch (if equipped)

Headlight switch

Fog light switch

The front fog lights will turn on when the
fog light switch is placed in the “

” position

while the headlights are in the following
condition.
.

while the headlight switch is in the “

”

position
.

for models with the auto on/off head-

lights, while the headlight switch is in the
“AUTO” position and the low beam head-
lights turn on automatically

To turn off the front fog lights, turn the
switch back down to the “ ” position.

The indicator light on the combination
meter will illuminate when the front fog
lights are illuminated.

Steering responsive fog
lights system (if equipped)

The steering responsive fog lights system
automatically turns the front fog light on
and off based on the steering angle and
vehicle speed when entering a curve or
driving on curved roads. The system is
intended to help prevent accidents by
enabling better visibility of curves ahead
and early recognition of any disabled
vehicles or other obstacles.

The front fog light on the inside of a curve
will turn on if all of the following conditions
are met.

The light control switch is in the “

”

position, or the light control switch is in the
“AUTO” position and the low beam head-
lights are turned on automatically
.

The fog light switch is in the “ ” position

The low beam mode is selected

The select lever is in the “D” position or

the manual mode is selected.
.

The steering response fog lights sys-

tem has not been deactivated
.

The operating conditions such as the

steering angle and vehicle speed are met

The front fog lights on both sides will turn
on as usual if all of the following conditions
are met.
.

The light control switch is in either of the

following conditions.

– in the “

” position

– in the “AUTO” position and the low
beam headlights turn on automatically

The fog light switch is in the “

”

position
.

The low beam mode is selected

– CONTINUED –

Instruments and controls/Fog light switch

3-71

(214,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

Steering responsive fog lights OFF
switch

Steering responsive fog lights OFF switch

Press this switch to deactivate the steering
responsive fog lights system. Press the
switch again to activate the system.

Steering responsive fog lights OFF
indicator

Steering responsive fog lights OFF indi-
cator

This indicator appears when the steering
responsive fog lights system is deacti-
vated. This indicator disappears when the
system is activated.

Turn signal lever

Right turn

Lane change right signal

Lane change left signal

Left turn

If the lever does not return after cornering,
return the lever to the neutral position by
hand.

To signal a lane change, push the turn
signal lever up or down slightly and hold it
during the lane change. The lever will
return automatically to the neutral position
when you release it.

Instruments and controls/Turn signal lever

3-72

(215,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

One-touch lane changer

To flash the turn signal and turn signal
indicator light three times, push the turn
signal lever up or down slightly and
immediately release it.

NOTE

T h e o p e r a t i o n a l / n o n - o p e r a t i o n a l
setting of the one-touch lane changer
can be changed by a SUBARU dealer.
Contact the nearest SUBARU dealer for
details. For models with the combina-
tion meter display (color LCD), the
setting can also be changed by operat-
ing the combination meter display
(color LCD). For details, refer to “Vehi-
cle Setting” F3-39.

Wiper and washer

WARNING

In freezing weather, do not use the
windshield washer until the wind-
shield is sufficiently warmed by the
defroster.

Otherwise the washer fluid can
freeze on the windshield, blocking
your view.

CAUTION

Do not operate the washer con-

tinuously for more than 10 sec-
onds, or when the washer fluid
tank is empty. This may cause
overheating of the washer motor.
Check the washer fluid level fre-
quently, such as at fuel stops.

Do not operate the wipers when

the windshield or rear window is
dry. This may scratch the glass,
damage the blade rubbers and
might cause the wiper motor to
fail. Before operating the wiper
on a dry windshield or rear win-
dow, always use the windshield
washer.

In freezing weather, be sure that

the blade rubbers are not frozen
to the windshield or rear window
before switching on the wipers.
Attempting to operate the wiper
with the blades frozen to the
window glass could cause not
only the blade rubbers to be
damaged but also might cause
the wiper motor to fail. If the blade
rubbers are frozen to the window
glass, be sure to operate the
defroster, windshield wiper dei-
cer (if equipped) or rear window
defogger before turning on the
wiper.

If the wipers stop during opera-

tion because of ice or some other
obstruction on the window, this
might cause the wiper motor to
fail even if the wiper switch is
t u r n e d o f f . I f t h i s o c c u r s ,
promptly stop the vehicle in a
safe place, turn the ignition
switch to the “LOCK”/“OFF” po-
sition and clean the window glass
to allow proper wiper operation.

Use clean water if windshield

washer fluid is unavailable. In
areas where water freezes in
winter, use SUBARU Windshield
Washer Fluid or the equivalent.

– CONTINUED –

Instruments and controls/Wiper and washer

3-73

(216,1)

北米Model "A1340BE-A" EDITED: 2018/ 4/ 2

Refer to “Windshield washer
fluid” F11-29.

Do not clean the blade rubbers

with gasoline or a solvent, such
as paint thinner or benzine. This
will cause deterioration of the
blade rubbers.

NOTE

The windshield wiper motor is pro-

tected against overloads by a circuit
breaker. If the motor operates continu-
ously under an unusually heavy load,
the circuit breaker may trip to stop the
motor temporarily. If this happens, park
your vehicle in a safe place, turn off the
wiper switch, and wait for approxi-
mately 10 minutes. The circuit breaker
will reset itself, and the wipers will
again operate normally.
.

Clean your blade rubbers and win-

dow glass periodically with a washer
solution to prevent streaking, and to
remove accumulations of road salt or
road film. Operate the windshield
washer for at least 1 second so that
washer solution will be sprinkled all
over the windshield or rear window.
.

Grease, wax, insects or other mate-

rial on the windshield or the blade
rubbers results in jerky wiper operation

and streaking on the glass. If you
cannot remove those streaks after
operating the washer or if the wiper
operation is jerky, clean the outer sur-
face of the windshield or rear window
and the blade rubbers using a sponge
or soft cloth with a neutral detergent or
mild-abrasive cleaner. After cleaning,
rinse the window glass and blade
rubbers with clean water. The glass is
clean if no beads form on the glass
when you rinse with water.
.

If you cannot eliminate the streaking

even after following this procedure,
replace the blade rubbers with new
ones. For replacement instructions,
refer to “Replacement of wiper blades”
F11-30.

Windshield wiper and washer
switches

The wiper operates only when the ignition
switch is in the “ON” or “ACC” position.

Operating the wiper lever

: Mist operation (for a single wipe)

: Off

: Intermittent operation

: Low speed operation

: High speed operation

For a single wipe of the wipers, push the
lever up. The wipers operate until you
release the lever.

Instruments and controls/Wiper and washer

3-74

Subaru Crosstrek (2019 year). Manual - part 13
