IDI-25

Tachometer

INSTRUMENTATION/DRIVER INFO

6. Tachometer

A: SPECIFICATION

Since the meter case assembly cannot be disas-
sembled, do not remove or inspect the tachometer
alone. (Do not remove the cover on the back sur-
face.)

IDI-26

Fuel Gauge

INSTRUMENTATION/DRIVER INFO

7. Fuel Gauge

A: SPECIFICATION

Since the meter case assembly cannot be disas-
sembled, do not remove or inspect the fuel gauge
alone. (Do not remove the cover on the back sur-
face.)

IDI-27

Engine Coolant Temperature Gauge

INSTRUMENTATION/DRIVER INFO

8. Engine Coolant Temperature

Gauge

A: SPECIFICATION

Since the meter case assembly cannot be disas-
sembled, do not remove or inspect the engine cool-
ant temperature gauge alone. (Do not remove the
cover on the back surface.)

IDI-28

Clock

INSTRUMENTATION/DRIVER INFO

9. Clock

A: REMOVAL

1) Disconnect the ground cable from the battery.
2) Remove the center air vent grille. <Ref. to AC-
47, REMOVAL, Air Vent Grille.>
3) Loosen the screws, and remove clock (B) from
center air vent grille (A).

B: INSTALLATION

Install in the reverse order of removal.

IDI00103

(A)

(B)
