SsangYong Rexton. Service manual - part 153

SSANGYONG  REXTON XDi(RHD)

2-10  POSITION OF CONNECTORS AND GROUNDS

2) W/H MAIN

POSITION OF CONNECTORS AND GROUNDS  2-11

SSANGYONG  REXTON XDi(RHD)

SSANGYONG  REXTON XDi(RHD)

2-12  POSITION OF CONNECTORS AND GROUNDS

POSITION OF CONNECTORS AND GROUNDS  2-13

SSANGYONG  REXTON XDi(RHD)

3) W/H FLOOR(LH)
