11-20

Press the [4INT] button repeatedly to select the intro play mode.

-        INT: Play the intro of all the songs in the current folder in order for about 10 seconds (applies

only to MP3/WMA disc)

- INT: Play the intro of all the song in the disc in order for about 10 seconds

- OFF: Deactivates playing intro

2.

To change play mode

▶

Press the [2RPT] button repeatedly to select the repeat mode.

-        RPT: Repeat all the songs in the current folder in order (applies only to MP3/WMA disc)

- RPT: Repeat the playing song consecutively

- OFF: Deactivates repeat mode

1.

Search for song and play it

▶

When [MENU] button is pressed after turning the [TUNE] dial to select the song number or name to

play, the system begins playing the song.

1.

MP3[WMA] song information view

▶

If you press the [INF] button briefly and repeatedly when a song is playing, other information

(artist/album/genre/play time) for the song is displayed for 3 seconds.

If you press and hold the [INF] button when a song is playing, the data table for the song is displayed

for 5 seconds.

1.

2.

To set scroll function

▶

When pressing the [SET] button, "Setup List" is displayed.

Turn the [TUNE] dial to select the desired "Scroll On/Off" and press the [ENTER] button to select ON

or OFF.

1.

2.

Press the [5RDM] button repeatedly to select the random play mode.

-        RDM: Play all the songs in the current folder in random order

(applies only to MP3/WMA disc)

- RDM: Play all the song in the disc in random order

- OFF: Deactivates random play mode

3.

8. MP3 [WMA]/CD PLAYER

11-21

8910-05

To register Bluetooth device

▶

Press the [Call] button for more than 3 seconds.

- "PAIRING" is displayed and followed by "KEY 00xx" to indicate stand-by mode.

1.

To set Bluetooth mode

▶

When pressing the [SET] button, "Setup List" is displayed.

- The setting screen is displayed for 5 seconds.

1.

Making phone call using recent call list

▶

When you [Call] button for more than 3 seconds, the system displays "REDIAL" and makes a phone

call to the recent calling party.

1.

Activate the Bluetooth device to register to carry out Bluetooth setting/device search and connect it to

the audio system.

- If the searched device selection item is displayed, carry out selecting/connecting

  "SSANGYONG".

- If the device search fails for 60 seconds, "NO device paired" is displayed. If this is the case,

  carry out steps 1~2 above again.

2.

Enter the pairing key, "00xx", displayed on the audio system screen to the *pin code input item

of the Bluetooth device to connect and register it.

- When the registration is completed normally, the audio system screen displays "BT CONNECT"

  and displays cellular phone model name or "BT MOBILE" together with the Bluetooth icon.

- The Bluetooth device can be registered just once. Although several devices can be

  registered, you can select only 1 device to connect the system. If the registered Bluetooth

  device is set to connect to other device, disable the previous connection under Connect

  Bluetooth device and select "Car audio" or  "Audio device" to connect the device to the system.

3.

Check whether the Bluetooth connection is completed.

4.

Turn the [TUNE] dial to select a desired "Bluetooth Setup" and press the [ENTER] button.

2.

Turn the [TUNE] dial to select a desired Bluetooth setup item and press the [ENTER] button.
- Turn the dial to select one of the followings: Pair Device ↔ Select Device ↔ Delete Device
  ↔ Priority Device.

  For "Pair Device", see the steps 2~4 in "To register Bluetooth device".

3.

Turn the [TUNE] dial to select the device list and press the [ENTER] button.

- Select Device: Select the connected device.

- Delete Device: Delete the registered device.

- Priority Device: Set the connection priority for Bluetooth devices.

4.

9. BLUETOOTH

11-22

Answering an incoming call

▶

When the call is incoming, the bell rings and "CALL IN" and sender's telephone number are

displayed.

-

Hang-up call

▶

To hang-up the call, press the [END] button.

- The call is ended and system returns to the previous screen.

- However, the connection between the audio system and the phone remains "connected".

1.

To make a call, press the [Call] button.

- "BT TEL" is displayed during a call and you can converse through the microphone and

  speaker connected to this system. If you don't want to receive a call, press the [End] button

  to reject it.

- After "CALL REJECT" is displayed, the system returns to the previous screen.

1.

To adjust volume

▶

Turn the [VOL] dial to adjust the volume.

- The adjustable range is between BT VOL 06 to 32.

1.

Mute function

▶

Press the [MUTE] button on the audio remote control to activate the mute function.

- "MIC MUTE" is displayed and the other party can't hear your voice.

- Press the [MUTE] button again to resume your conversation.

1.

Private mode

▶

When you press the [Call] button during hands-free call, "PRIVATE" is displayed and hands-free call

is changed to cellular phone call. When you press the [Call] button during cellular phone call, "BT

TEL" is displayed and cellular phone call is changed to hands-free call.

- This function may not be available on some phone models.

1.

You can change to private call using a cellular phone during hands-free call. (The other party's voice

is coming through only the cellular phone, not speaker.)

-

To disconnect

▶

Press and hold the [End] button to disconnect the connection with Bluetooth device and press and

hold it once again to turn off the Bluetooth function.

- At this time, "BT DISCONNECT" is displayed and the Bluetooth icon disappears.

1.

Playing music stored in cellular phone

▶

Press the [MEDIA] button repeatedly to select "BT AUDIO".

After playing the music using a music-playback function in the cellular phone, turn the [VOL] dial to

adjust the volume.

To exit the function, press the [End] button or press the [BAND/AS], [MEDIA] or CD button to select

other function.

1.

2.

3.

11-23

8910-05

* Connect iPod to USB terminal

- Playing music file in USB memory
- Playing external audio device
  through AUX jack
- Supports iPod function

To playback USB/iPod

▶

Press and hold the power button to turn the audio off.

Insert the linking cable of the USB or iPod in which MP3/WMA file to play is stored to the USB

terminal.

Press the [MEDIA] button repeatedly to select the USB or iPod function.

- "USB" or "I-POD" is displayed and the music files which has been played previously are

  played automatically.

1.

2.

3.

To use AUX jack

▶

Turn off the external device's power supply and connect its sound output to the [AUX] jack.

Press the [MEDIA] button repeatedly and select the [AUX IN] function.

Turn the [VOL] dial to adjust the sound volume.

1.

2.

3.

10. EXTERNAL DEVICE (USB/AUX & I-POD)

Layout with USB/iPod

▶

USB 2.0 cable
