SsangYong Korando II (1996-2006 year). Service manual - part 400

SUPPLEMENTAL RESTRAINTS SYSTEM 8B-13

SSANGYONG MY2002

Yes

System OK

Go to “Diag-

nostic System

Check”

Go to Step 4

Value

Step

Action

1. Clear SRS DTCs.
2. Turn the ignition OFF for at least 30 seconds.
3. Observe the airbag indicator as the ignition is turned

ON.

Does the airbag indicator turn on for 4.5 seconds and turn
off?
1. Turn the ignition to LOCK and remove the key.
2. Disconnect the SDM connector.
3. Replace the SDM.
4. Connect SDM connector and ensure that all compo-

nents are properly mounted.

Is the repair complete?

SSANGYONG MY2002

8B-14 SUPPLEMENTAL RESTRAINTS SYSTEM

Yes

Go to Step 3

System OK

Go to “SDM

Integrity

Check”

Go to Step 6

Go to Step 2

Go to Step 4

Value

9 v

9 - 16 v

Step

Action

Check the SDM connector to verify that it is properly
connected to the SDM.
Is the SDM connector properly connected?
Connect the SDM connector.
Is the repair complete?
1. Turn the ignition OFF.
2. Disconnect the SDM connector.
3. Turn the ignition ON.
4. Check the voltage at SDM connector terminal 5.
Is the ignition voltage greater than the specified value?
1. Turn the ignition ON.
2. Check the voltage supply to the airbag fuse F31.
Is the voltage within the specified value?

Circuit Description

The airbag indicator will stay on if the sensing and
diagnostic module (SDM) connector is not securely
attached to the SDM. There is a shorting bar in SDM
connector which completes the circuit between the
indicator lamp circuit and ground. The shorting bar is
disengaged when the connector is properly attached.
When the ignition switch is first turned to ON, ignition
voltage applied to the instrument use for the indicator

AIRBAG WARNING LAMP STAYS ON WITH IGNITION SWITCH ON

lamp and also to the airbag fuse for input terminal 5. If
ignition voltage is outside the range of 9 to 16 volts,
the airbag indicator will come on and stay on and
DTC47 will set.

Test Description

The numbers below refer to steps on the diagnostic
table.

8. See the caution below.

KAA8B090

Airbag Warning Lamp Stays on with Ignition Switch ON

or pretensioners are not disconnected, do not begin
s e r v i c e u n t i l o n e m i n u t e h a s p a s s e d a f t e r
disconnecting power to the SDM. Otherwise, injury
could result.

SUPPLEMENTAL RESTRAINTS SYSTEM 8B-15

SSANGYONG MY2002

Yes

System OK

Go to Step 8

System OK

Go to Step 9

System OK

Go to Step 7

Go to Step 10

Value

Step

Action

Repair the power supply to the airbag fuse.
Is the repair complete?
Check the airbag fuse.
Is the fuse in good condition?
Replace the airbag fuse F31.
Is the repair complete?
1. Turn the ignition to LOCK and remove the key.
2. Disconnect the SDM connector.
3. Check for open circuit between terminal 5 of the SDM

and the airbag fuse F31.

Is there an open circuit?
Repair the open circuit between the SDM and airbag fuse
F31.
Is the repair complete?
Repair the short to ground circuit between the airbag
indicator lamp and terminal 1 of the SDM.
Is the repair complete?

SSANGYONG MY2002

8B-16 SUPPLEMENTAL RESTRAINTS SYSTEM

Yes

Go to Step 2

Go to specific

DTC chart.

Go to “SRS

Diagnostic

System
Check”

Go to Step 2

Value

Step

Action

Perform the SRS Diagnostic System Check.
Is the SRS Diagnostic System Check complete?
Check for any DTCs that is not internal fault.
Is there any DTCs that set except internal DTC?
1. Disable the supplemental restraint system (SRS) in

this section.

2. Replace SDM.
3. Enable the SRS.
4. Make sure all the components are properly mounted.
Is the repair complete?

Circuit Description

When the ignition switch is turned to ON, the sensing
and diagnostic module (SDM) will perform tests to
diagnose critical malfunctions within SDM itself. Internal
fault DTC will set when any of the malfunctions detected
by SDM itself. Refer to “Diagnostic Trouble Code
Table” in this section.

DIAGNOSTIC TROUBLE CODES (DTCS) - INTERNAL FAULT

Action Taken

The SDM will turn on the airbag indicator and set
diagnostic trouble code.

The SDM will shutdown its function partially or totally.

Diagnostic Trouble Code (DTC) - Internal Fault

Caution: The sensing and diagnosis module (SDM)
can maintain sufficient voltage to deploy the airbags
and pretensioners for 0.15 seconds after the ignition
is OFF and the fuse has been removed. If the airbags
or pretensioners are not disconnected, do not begin
s e r v i c e u n t i l o n e m i n u t e h a s p a s s e d a f t e r
disconnecting power to the SDM. Otherwise, injury
could result.

Caution: During service procedure, be very careful
when handling the SDM. Never strike or jar the
SDM. Never power the supplemental restraints
system (SRS) when the SDM is not rigidly attached
to the vehicle. Also SDM mounting nuts must be
carefully tightened to ensure proper operation of
the SRS. The SDM could be activated if it is powered
when it is not rigidly attached to the vehicle,
resulting in unexpected deployment and possible
injury.
