Skoda Superb (2019 year). Instruction - part 13





Switching the ignition on/off

Fig. 255  Positions of the vehicle key in the ignition lock / starter button

Read and observe   and   on page 204 first.

Positions of the vehicle key in the ignition lock

» Fig. 255

 -

Ignition switched off, engine switched off
Ignition switched on
Starting engine

Switching on /off ignition in vehicles with starter button

Press the

» Fig. 255

 -  button, the ignition is turned on / off.

On vehicles with instruction transmission the pedal must not be depressed to

switch on / off the ignition, otherwise the engine will start.
On vehicles with automatic transmission, the brake pedal must not be de-

pressed to switch on / off the ignition, otherwise the engine will start.

Starting engine / Stopping

Read and observe   and   on page 204 first.

Before starting the engine

Switch on the parking brake.

For vehicles with instruction transmission, shift gear stick to neutral, depress

the clutch pedal and hold it there until the engine starts.

For vehicles with automatic transmission, place the selector lever in position

P or N and

»

depress the brake pedal until the engine starts.

1

2
3

Starting the engine

On vehicles with Ignition lock, turn the key to position

3

 and the engine

starts

» Fig. 255

 on page 205 . Release the key, the engine will start auto-

matically.

If the engine does not start within 10 seconds, turn the key to position

1

. Re-

peat the starting process after 30 seconds.

On vehicles with starter button, press the button briefly

» Fig. 255

 on

page 205 - , the motor will start automatically.

In vehicles with diesel engines, the glow plug warning lights

 up after the

ignition is switched on. The engine can be started after the indicator light goes

out.

Stopping the engine

Stopping the vehicle.

On vehicles with ignition lock, turn the key to position

1



» Fig. 255

 on

page 205 .

On vehicles with starter button, press the button

» Fig. 255

 on page 205 - ,

The engine and the ignition will be switched off simultaneously.

For vehicles with automatic transmission, the ignition key can only be removed

if the selector lever is in position P (this only applies to a few countries).
Do not switch the engine off immediately at the end of your journey after the

engine has been running for a prolonged period at high loads. Leave it to run at

an idling speed for about 1 minute. This prevents any possible accumulation of

heat when the engine is switched off.

Emergency shutdown of the engine in vehicles with starter button

The system is equipped with a protective device against accidental switching

off, the engine can only be shut off while driving in the event of an emergency.

Keep the knob pressed

» Fig. 255

 on page 205 -  or press it twice within 1

second.

After the emergency stop of the engine, the steering lock will remain un-

locked.

CAUTION

When the outdoor temperature is below -10 ° C, the selector lever when start-

ing must always be in P mode.

205

Starting-off and Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Note

The engine running noises may be louder at first for a short time after start-

ing the cold engine.

You should not switch on any major electrical components during the heating

period, otherwise the vehicle battery will be drained unnecessarily.

After switching off the ignition, the radiator fan may intermittently continue

to run for approx. 10 minutes (also continuously).

Problems with the engine start - vehicles with starter button

Fig. 256

Engine start - hold key on but-

ton

Read and observe   and   on page 204 first.

If no engine start is possible and the display of the instrument cluster shows a

message that the key could not be detected by the system or there is a sys-

tem fault, then try to start the engine as follows.

Push the starter button and then hold the key with the back of it on the but-

ton

» Fig. 256

.

If the engine does not start, the help of a specialist garage is required.

CAUTION

The key may not be detected by the system if the battery in the key is running

out of charge or the signal fails.

START-STOPsystem

Introduction

The START-STOPsystem (hereinafter referred to as the system) reduces

CO

2

emissions and harmful emissions, and saves fuel.

If the system determine that the engine is not needed when the vehicle stops

or is at a standstill (e.g. at the traffic lights), it turns off the engine and starts it

again when moving off.
The system function depends on many factors. Some of them are down to the

driver, while others are systemic and can neither be influenced nor identified.
For this reason, the system may react differently in situations which seem

identical from the driver's perspective.
The system is automatically activated every time the ignition is switched on

(even when it has previously been instructionly deactivated with the  button).

Note

If the engine has stopped due to the system, the ignition remains switched on.

Operation

Fig. 257

Display

Vehicles with instruction transmission

The engine is automatically switched off as soon as the vehicle comes to a

halt, the shift lever is moved into neutral and the clutch pedal is released.
The engine is automatically started as soon as the clutch pedal is depressed.

Vehicles with automatic transmission

The engine is automatically switched off as soon as the vehicle comes to a

halt and the brake pedal is operated.
The engine is automatically started as soon as the accelerator pedal is de-

pressed or the brake pedal is released (with deactivated Auto Hold function).

206

Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Requirements for the system to function correctly

The following conditions must be met for the system to function correctly.

The driver's door is closed.
The driver has fastened the seat belt.
The driving speed was higher than 4 km/h after the last stop.

System status

The system status is shown in the display when the vehicle comes to a halt

» Fig. 257

.

The engine is switched off automatically; when moving off, the ignition

process will be initiated automatically.
The engine is not switched off automatically.

When stopping, the engine will not switch off for the following reasons,

among others.

The engine temperature for the proper function of the system has not yet

been reached.

The charge state of the vehicle battery is too low.

The current consumption is too high.

High air conditioning or heating output (high blower speed, big difference

between the desired and actual interior temperature).

If the engine is shut down automatically and the system detects that the en-

gine is required, such as when the brake pedal is pressed repeatedly, then the

system automatically starts the engine.
More information about the current system status can be displayed in the In-

fotainment screen in menu



/  →  → display Vehicle status.

If there is a system fault, the following message will appear in the display of

the instrument cluster. Seek help from a specialist garage.

Note

If the driver's seat belt is removed for more than approx. 30 seconds or the

driver's door is opened during automatic stop mode, the engine will have to be

started instructionly.

No automatic engine shut-down takes place when a vehicle with automatic

transmission is moving at low speed (e.g. during a traffic jam) and remains sta-

tionary after pressing the brake pedal lightly. Automatic engine shut-down

takes place if you press the brake pedal down with more force.

For vehicles with automatic transmission there is no automatic engine shut-

down when the system detects a manoeuvring action due to a large steering

angle.

Instructionly disable / enable system

Fig. 258

Button for the START-STOP sys-

tem

To deactivate/activate, press the  button

» Fig. 258

.

When the system is deactivated, the symbol

 illuminates in the button.

If the system is deactivated, it will be reactivated automatically after the igni-

tion has been switched off and on.

Note

If the system is deactivated when the engine is turned off automatically, then

the automatic start process takes place.

207

Starting-off and Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Brakes and Parking

Introduction

The wear of the brake pads is dependent on the operating conditions and driv-

ing style. Under difficult conditions (e.g. urban, sporty driving style) the condi-

tion of the brakes should also be checked by a specialist garage between the

service intervals.
The performance of the brakes can be delayed if the brakes are damp, iced up

in winter or if covered in a layer of salt. The brakes are cleaned and dried by

applying the brakes several times

»

.

Corrosion on the brake discs and dirt on the brake pads occur if the vehicle

has been parked for a long period and if you do not make much use of the

braking system. The brakes are cleaned by applying the brakes several times

»

.

Before travelling a long distance with a steep gradient, reduce speed and

shift into the next lowest gear. As a result, the braking effect of the engine will

be used, reducing the load on the brakes. If you do have to brake, this should

be carried out at intervals.
Emergency braking display - when an emergency braking is performed, the

automatic flashing of the brake lights are used to alert the traffic behind.
New brake pads must first be “worn in” because these do not initially have the

best possible braking effect. Drive especially carefully for the first 200 km or

so.
A too low brake fluid level can cause faults in the braking system, the warn-

ing light

 illuminates in the instrument cluster

» page 40

 Brake system. If

the warning light does not illuminate and an extended stopping distance is re-

quired, then driving should be adapted according to the unknown cause of

fault and restricted braking effect - seek the assistance of a specialist garage

immediately.
The brake booster increases the pressure generated with the brake pedal. The

brake booster only operates when the engine is running.

WARNING

Greater physical effort is required for braking when the engine is switch-

ed off – risk of accident!

During the braking procedure on a vehicle with instruction transmission,

when the vehicle is in gear and at low revs, press the clutch pedal. Other-

wise, the functionality of the brake system may be impaired – risk of acci-

dent!

Do not press the brake pedal if braking is now required. This causes the

brakes to overheat and can also result in a longer braking distance and ex-

cessive wear - risk of accident!

Braking for the purpose of drying and cleaning the brake discs should be

carried out only if the traffic conditions permit. Do not place any other road

users in jeopardy.

Recommendations for new brake pads have to be observed.

When stopping and parking, the parking brake should always be on, oth-

erwise the vehicle could move off - there is the risk of an accident!

If a front spoiler, full wheel trim, etc. is mounted retrospectively, it must

be ensured that the air supply to the front wheel brakes is not reduced.

Otherwise, the functionality of the brake system may be impaired – risk of

accident!

Electric parking brake

Fig. 259

Parking brake button

208

Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Fig. 260  Parking brake operation

Read and observe   on page 208 first.

The electric parking brake (hereinafter referred as a parking brake) replaces

the handbrake. This secures the vehicle when stopping and parking against un-

wanted movement.
The parking brake can be used when the ignition is on or off.

Switching on

Pull the  button in the direction of arrow

1



» Fig. 260

 and hold until the

symbol in the button and warning light

 illuminating the instrument cluster.

Automatic shut-off

The parking brake switches off automatically when starting, as long as the

driver's door is closed and the driver has fastened the seat belt.
Should the vehicle start to roll away backwards when starting on an uphill

slope, step on the accelerator or switch on the parking brake.
Turning off the parking brake can be prevented if, before starting, the  but-

ton is pulled and held in the direction of arrow

1



» Fig. 260

. The parking brake

turns off after releasing the button.

Instruction shut-down

With the ignition switched on, press the brake pedal and at the same time

push the  button in the direction of arrow

2



» Fig. 260

.

With the engine running, press either the brake or accelerator pedal and

press the  button in the direction of arrow

2

.

The

 symbol in the button and the warning light

 in the instrument cluster

go out.

Emergency braking function

If, while driving, a fault occurs in the brake system, the parking brake can be

used as an emergency brake

»

.

Pull the  button in the direction of arrow

1

 and

» Fig. 260

 hold (you hear

an audible signal), the vehicle starts to brake strongly.

The braking process is interrupted when the key is released or the accelerator

pedal is actuated.

WARNING

The emergency brake is to be used only in an emergency when the vehi-

cle cannot be stopped with the brake pedal.

Do not place any objects in the recessed grip for the finger in front of the

parking brake key - the parking brake button could be blocked!

Note

If the vehicle battery is discharged, it is not possible to release the parking

brake. First connect the vehicle first to a power source, such as the battery of

another vehicle

» page 288

Jump-starting and then turn off the parking brake.

Noise when switching on and off the parking brake is normal and therefore

harmless.

Auto Hold function

Fig. 261

The Auto-Hold function button

Read and observe   on page 208 first.

The Auto Hold function (hereinafter referred to only as system) prevents the

vehicle from rolling unintentionally when stopped. It is, for example, not neces-

sary to secure the vehicle with the brake pedal or parking brake at traffic

lights.

209

Starting-off and Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

For the activation, deactivation and correct functioning of the system, the

following basic conditions are required.

The driver's door is closed.
The engine is running (or has been switched off automatically by the

START-STOP system).
On vehicles with automatic transmission the selector lever is not in mode

N (in this mode, the system is not available).

Stopping and starting

When stopping the system prevents the vehicle from rolling away. The warn-

ing light

 illuminates in the instrument cluster. The brake pedal can be re-

leased.
The vehicle's brakes are released at the moment of stating off. The warning

light

 in the instrument cluster goes out.

Should the vehicle start to roll away backwards when starting on an uphill

slope, step on the accelerator or switch on the parking brake.
If the vehicle is secured by the system and the driver's door is opened or the

ignition is turned off, the vehicle is secured by the parking brake to prevent un-

wanted movement.
In this case, the indicator light turns off

 in the instrument cluster and the

warning light

 illuminates.

Activation/deactivation

The system is activated/deactivated by means of the 

» Fig. 261

 button.

When the system is activated, the symbol  illuminates.
After switching off and switching on the ignition, the system remains either

activated or deactivated depending on the last setting.

WARNING

The increased stopping and starting comfort brought by the system must

not tempt you to take any safety risks.

The system is not able to stop the vehicle under all circumstances, such

as on icy or otherwise slippery ground, or on gradients.

When stopping and parking always make sure that the vehicle is correctly

secured

» page 210

Parking.

CAUTION

In some washing systems it is necessary that the vehicle can roll freely. There-

fore, the system must be deactivated before driving through a car wash.

Note

The system is able to secure the vehicle for about 10 minutes, after which the

vehicle will be automatically secured by the parking brake.

Parking

Read and observe   on page 208 first.

When stopping and parking, look for a place with a suitable surface

»

 .

Only carry out the activities while parking in the specified order.

Bring the vehicle to a stop and depress the brake pedal.

The parking brake switch.

On vehicles with automatic transmission place the selector lever in the P

position.

Switch off the engine.

For vehicles with instruction transmission, select 1st gear or reverse gear R.

Release the brake pedal.

If the parking brake is turned on while on a steep slope, the following message

may be displayed in the instrument cluster. Search for a car park with less of

an inclination.

WARNING

The exhaust system components can become very hot. Therefore, never

stop the vehicle at places where the underside of your vehicle can come in-

to contact with flammable materials such as dry grass, undergrowth,

leaves, spilled fuel or such like. - Risk of fire and serious injury can occur!

When leaving the vehicle, never leave people who could, for example, lock

the vehicle or release the brake, unattended in the vehicle - risk of accident

and injury!

210

Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Instruction gear changing and pedals

Introduction

CAUTION

When stopping on a slope, never try to hold the vehicle using the accelerator

pedal – this may lead to gear damage.

Instruction gear changing

Fig. 262

The shift pattern

Read and observe   on page 211 first.

The gearshift pattern for the individual gear positions is shown on the gear lev-

er

» Fig. 262

.

The gear shift indicator should be observed when changing gear

» page 49

.

Always depress the clutch pedal all the way down. This prevents uneven wear

on the clutch.

Engage reverse gear

Stop the vehicle.

The clutch pedal is fully depressed.

Switch the gear lever to N.

Push the shift lever downwards fully to the left and then forward into

R

» Fig. 262

.

The reversing lights will come on once reverse gear is engaged, provided the

ignition is on.

WARNING

Never engage reverse gear when driving – risk of accident!

CAUTION

If not in the process of changing gear, do not leave your hand on the gear shift

lever while driving. The pressure from the hand can cause the gear shift mech-

anism to wear excessively.

Pedals

Read and observe   on page 211 first.

The operation of the pedals must not be hindered under any circumstances!
In the driver's footwell, only a footmat (supplied by the factory or from the

ŠKODA Original Accessories) which is secured on the respective attachment

points should be used.

WARNING

No objects should be located in the driver's footwell, otherwise the pedal

operation could be disabled - risk of accident!

Automatic transmission

Introduction

The automatic transmission performs an automatic gear change irrespective

of the engine load, the operation of the accelerator, the vehicle speed and the

selected driving mode.
The modes of the automatic transmission can be adjusted by the driver by

means of the selector lever.

WARNING

Do not use the throttle if the forwards mode has been set using the se-

lector lever prior to starting up - risk of accident!

Never move the selector lever to mode R or P when driving – risk of acci-

dent!

211

Starting-off and Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING (Continued)

If the vehicle stalls, with engine running, in the DSR or Tiptronic mode,

then the vehicle must be prevented from rolling away using the brake ped-

al, or using the Auto Hold function. Even when the engine is idling, the pow-

er transmission is never interrupted - the vehicle creeps.

When leaving the vehicle, the selector lever must always be set to P .

Otherwise, the vehicle could start to move - risk of accident.

CAUTION

If you want to move the selector lever from position N to position D / S

whilst driving, the engine must be running at idling speed.

When stopping on a slope, never try to hold the vehicle using the accelerator

pedal – this may lead to gear damage.

Select selector lever position

Fig. 263

Selector lever settings / display

Read and observe   and   on page 211 first.

Move the selector lever to change to the following positions

» Fig. 263

. In

some positions you have to push the locking button

» page 212

Selector lever

lock.
When the ignition is switched on, the gearbox mode and the currently selected

gear are indicated in the display

» Fig. 263

.

Park - the position can be set only when the vehicle is at a standstill.

The drive wheels are mechanically locked.
Reverse gear - the position can be set only when the vehicle is at a stand-

still and the engine is at idling speed.
Neutral (idle position) - the power transmission to the drive wheels is in-

terrupted.

P

R

N

Forward mode / sports programme - the gear change takes place in the

position S at higher engine speeds than in mode D
(Sprung position) - choice between positions D and S

If the Sport driving mode is selected with the engine running

» page 244

Se-

lect the driving mode (Driving Mode Selection) , the transmission is automati-

cally set in the S mode.

E – Economical driving mode

If the driving mode Eco or Individual (engine - Eco)

» page 244

 is selected and

the selection lever is in the setting D/S, the transmission is automatically set to

mode E. This mode cannot be selected with the selector lever.
The forwards mode is switched up or down automatically in mode E at lower

engine speeds than in mode D.

Selector lever lock

Fig. 264

Shift lock button

Read and observe   and   on page 211 first.

The selector lever is locked in mode P and N to prevent that the forward driv-

ing is selected accidentally, thereby setting the vehicle in motion.
The selector lever is locked only when the vehicle is stationary and at speeds

up to 5 km/h.
The selector lever lock is indicated by the illumination of the warning

 light.

Release the gear selector lever from P mode or N

Press the brake pedal and, at the same time, push the lock button in the di-

rection of arrow

1



» Fig. 264

.

To move the selector lever from mode N to D / S only the brake pedal is press-

ed.

D/S

212

Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The selector lever is not locked when quickly moving across the position N

(e.g. from R to D/S). This, for example, helps to rock out a vehicle that is stuck,

e.g. in a bank of snow. The selector lever lock will engage if the lever is in posi-

tion N for more than approx. 2 seconds without the brake pedal being de-

pressed.
If it is not possible to release the gear selector from mode P in the usual man-

ner, then this can be emergency unlocked

» page 294

.

Note

If you want to switch the selector lever from mode P to mode D/S or vice ver-

sa, move the selector lever quickly. This prevents that you accidentally select

mode R or N.

Manual shifting of gears (Tiptronic)

Fig. 265  Selector lever/multi function steering wheel

Read and observe   and   on page 211 first.

Tiptronic mode makes it possible to manually shift gears with the selector lev-

er or multifunction steering wheel.

Switching to manual shifting using the selector lever

Push the gear selector from position D/S towards the right, or left in a right-

hand drive vehicle. The current gear is maintained.

Switching to manual shifting by using the rocker switches under the

multifunction steering wheel

To change gear, pull one of the rocker switches

-

/

+

 briefly towards the

steering wheel

» Fig. 265

.

To cancel manual shift, pull the rocker switch

+

 towards the steering wheel

for more than 1 s.

If you do not pull one of the rocker switches

-

/

+

 for a certain time, manual

shifting of the gears is deactivated automatically.

Changing gear

To shift up, tap the selector lever forwards

+

 or pull the rocker switch

+

briefly towards the steering wheel

» Fig. 265

.

To shift down, tap the selector lever backwards

-

 or pull the rocker switch

-

 briefly towards the steering wheel

» Fig. 265

.

The currently selected gear is marked with the letter M in the instrument clus-

ter display.

The gear shift indicator should be observed when changing gear

» page 49

.

When accelerating, the gearbox automatically shifts up into the higher gear

just before the maximum permissible engine speed is reached. If a lower gear

is selected, the gearbox does not shift down until there is no risk of the engine

over revving.

Note

It may be beneficial, for example, when travelling downhill, to use manual shift-

ing of gears. Shifting to a lower gear reduces the load on the brakes and hence

the wear of the brakes.

Start and run

Read and observe   and   on page 211 first.

Starting and temporarily pausing

Firmly depress and hold the brake pedal.

Start the engine.

Press the locking button and move the selector lever to the desired position

» page 212

.

Release the brake pedal and accelerate.

The selector lever position N does not have to be selected if stopping for a

short time, such as at cross roads. However, you must apply the brake pedal in

order to prevent the vehicle from rolling away.

Accelerate to maximum speed during the journey (kickdown function)

The kickdown function is applied when the accelerator pedal is pressed down

in the forward mode.
The gear change is adjusted accordingly to reach the maximum acceleration.

213

Starting-off and Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

When approaching maximum speed (launch control function)

The launch control function is available in mode S or Tiptronic.

Disable the TCS

» page 217

Braking and stabilisation systems.

START STOP deactivate

» page 207

Manually disable / enable system.

Fully depress and hold the brake pedal with your left foot.

Fully depress the accelerator pedal with your right foot.

Release the brake pedal - the vehicle is running at maximum acceleration.

Driving in neutral (“coasting”)

When releasing the accelerator pedal, the vehicle moves without the braking

effect of the engine.
Operating conditions

The selector lever is in the D/S position.

Driving mode Eco or Individual (Drive: - Eco) is selected

» page 244

Select

the driving mode (Driving Mode Selection).

The vehicle speed is 20-130 km/h.

No trailer or other accessory is connected to the trailer socket.

The gear is selected again automatically, when you depress the accelerator or

brake pedal or pull one of the rocker switches

-

/

+

 towards the steering

wheel

» page 213

Manual shifting of gears (Tiptronic).

WARNING

Rapid acceleration, particularly on slippery roads, can lead to loss of control

of the vehicle – risk of accident!

Running in the engine and economical driving

Running in the engine

During the first 1,500 km, the driving manner determines the quality of the

running in process on a new engine.
During the first 1,000 km, the engine should not be charged with more than

3/4 of the maximum permitted engine revs and without the trailer.
In the area of 1,000 to 1,500 kilometres, the engine load can be increased up

to the maximum permitted engine speed.

Tips for economical driving

The fuel consumption depends on the driving style, road condition, weather

conditions and the like.
For an economical driving style, the following instructions must be observed.

Avoid unnecessary acceleration and braking.

Observe the recommended gear

» page 49

.

Avoid full throttle and high speeds.

Reduce idling.

Avoid short distances.

Ensure the correct tyre inflation pressure is maintained

» page 277

.

Avoid unnecessary ballast.

Remove the roof rack when it is not needed.

Only switch on electrical consumers (e.g. seat heating) for as long as they are

needed. In the infotainment system, in menu



/  →  → Fuel consumption:,

it is possible to display up to three consumers that are currently making up

the largest share of fuel consumption.

Before switching on, ventilate the cooling system briefly and do not use the

cooling system with open windows.

Do not leave windows open at high speed.

DriveGreen function

Fig. 266

Display in Infotainment screen

The DriveGreen function (hereinafter referred to as DriveGreen) evaluates the

driving efficiency based on the information respecting the driving style.
DriveGreen can be displayed in the infotainment screen in menu



/  → 

→ DriveGreen.

214

Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

A

 driving liquid display

With the driving is fluid, the display is located in the middle (near the green

dot). When accelerating, the display moves down, and upwards when braking.

B

“Green leaf”

The greener the leaf, the more economic the driving style. With less economi-

cal driving, the leaf is presented without any green colouring or it can be com-

pletely hidden.

C

 bar graph

The higher the green bars, the more economical the driving style. Each bar

shows the driving efficiency in 5-second steps, the current bar is on the left.

D

 scoring (0 - 100)

The higher the indicated value, the more economical the driving style. When

you tap the function surface

D

, a detailed assessment showing the driving ef-

ficiency during the last 30 minutes is displayed.
If the trip lasts less than 30 minutes from the start, then the overview will add

the assessment from the previous journey (the bars are shown in dark green).

E

 the average fuel consumption from the start

When you tap the

E

 function surface, a detailed overview of the average fuel

consumption during the last 30 minutes is shown.
If the trip lasts less than 30 minutes from the start, then the overview will add

the overview of the average fuel consumption from the previous journey (the

bars are shown in dark green).

F

 symbols

The display may show the following four symbols, which give information on

the current driving style.

Economical driving style
The current speed has a negative effect on fuel consumption.
Travelling is not fluid, this is to avoid unnecessary acceleration and braking
Recommended gear

Tips for economical driving

Tap on the

B

 leave to display tips for economical driving.

Note

Resetting the single-trip memory “Since start” also resets the average con-

sumption

E

 and the driving assessment

D

 as well as diagram

C

.



Radiator shutters

The radiator shutters located in front of the radiator (hereinafter: shutter) help

to reduce CO

2

 emissions as well as harmful emissions and to save fuel.

If the system detects that it is possible to reduce the amount of air flowing to

the radiator, it closes the blinds. As a result, the air resistance of the vehicle is

reduced.
If a driving speed of 150 km/h is reached due to a function impairment of the

shutters, a message regarding the function impairment of the shutters is

shown in the instrument cluster display.
After this message has been displayed, the maximum speed of the vehicle is

automatically limited to 170 km/h. The manner of driving should therefore be

adapted to this limitation.
If this message appears in the winter, the cause may be ice or snow caught up

in the blinds. After the ice or snow has thawed, the blinds are functional again.
If the impairment not due to ice or snow, then assistance from a specialist

should be sought.

Avoiding damage to your vehicle

Driving Tips

Only drive on such roads and in such terrain that match the vehicle parameters

» page 304

Technical data as well as your driving skills.

The driver is always responsible for deciding whether the vehicle can handle

travelling in the given terrain.

WARNING

Adjust the speed and driving style to the current visibility, weather, road

and traffic conditions. Too high a speed or an erroneous manoeuvre may

cause serious injury and damage to the vehicle.

Combustible objects such as dry leaves or twigs caught under the base of

the vehicle could ignite on hot vehicle parts - risk of fire!

215

Starting-off and Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CAUTION

Pay attention to the ground clearance of the vehicle! When driving over ob-

jects which are larger than the ground clearance, the vehicle can get damaged.

Any objects that get trapped under the vehicle floor must be removed as

soon as possible. These items can cause damage to the vehicle (e.g. on parts of

the fuel system or the brake system).

Driving through water

Fig. 267

Maximum permissible water lev-

el when driving through water

The following must be observed to avoid damage to the vehicle when driving

through bodies of water (e.g. flooded roads).

Therefore determine the depth of the water before driving through bodies of

water. The water level must not reach above the lower edge of the lower

brace

» Fig. 267

.

Drive at a maximum speed of walking pace, otherwise a shaft may form in

front of the vehicle which could enable water to enter the vehicle system

(e.g. in the air induction system of the engine).

Never stop in the water, do not reverse and do not switch the engine off.

CAUTION

Water entering the vehicle systems (e.g. the air induction system of the en-

gine) can cause serious damage to the vehicle!

Oncoming vehicles can generate water waves which can exceed the permis-

sible water level for your vehicle.

Do not drive through salt water, as the salt can cause corrosion. An vehicle

coming into contact with salt water is to be thoroughly rinsed with fresh wa-

ter.

Assist systems

General information

Introduction

WARNING

The assistance systems only serve to support the driver and do not re-

lieve the driver of the responsibility for driving the vehicle.

The increased safety provision, as well as the increased occupant protec-

tion provided by the assistance systems must not tempt you to take risks -

risk of accident!

Adjust the speed and driving style to the current visibility, weather, road

and traffic conditions.

The assistance systems have physical and system-related limitations. For

this reason, the driver may experience some undesired or delayed system

responses in certain situations. You should therefore always be alert and

ready to intervene!

Only enable, disable or set the assistance systems when you have the car

fully under control, in every traffic situation - risk of accident!

Radar sensor

Fig. 268

Installation location of the radar

sensor

Read and observe   on page 216 first.

The radar sensor (hereinafter referred to only sensor) uses electromagnetic

waves to capture the traffic situation ahead of the vehicle. The radar is located

under a cover

» Fig. 268

.

The sensor is part of the ACC

» page 236

 and Front Assist

» page 242

systems.

216

Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The sensor function may be impaired in the event of one of the following sit-

uations arising.

The sensor cover is soiled (e.g. with mud, snow and the like).

The area in front of and around the sensor cover is obscured (e.g. by labels,

auxiliary headlights and the like(.

When visibility is poor (e.g. fog, heavy rain, thick snowfall).

In exceptional cases, the sensor may be covered in the area beneath the cov-

er, e.g. due to snow.

If the sensor cover or the sensor is dirty or covered, a message to that effect

from the ACC system

» page 241

Malfunctions or Front Assist

» page 244

Mal-

functions system appears in the instrument cluster display.

WARNING

If you suspect that the sensor is damaged, deactivate the ACC system

and Front Assist system

» page 239

» page 243

. Have the sensor checked by

a specialist garage.

A collision or damage in the front or lower area of the vehicle could affect

the sensor function - there is risk of accident! Have the sensor checked by

a specialist garage.

Do not cover the area in front of and around the sensor cover. This can

lead to impaired function of the sensor - risk of accident!

CAUTION

Remove snow with a brush and ice with a solvent-free de-icer from the sensor

cover.

Braking and stabilisation systems

Introduction

The brake and stabilization systems are automatically activated each time the

ignition is switched on, unless otherwise indicated.
The error display is in Chapter

» page 39

Warning lights.

WARNING

The general information relating to the use of assistance systems must be

observed

» page 216,

   in section Introduction.

Stability Control (ESC)

Read and observe   on page 217 first.

ESC improves vehicle stability in critical driving situations (e.g. if the vehicle

starts to skid) by the braking the individual wheels to maintain the direction.
During an ECS intervention, the warning light

 flashes in the instrument clus-

ter.

ESC Sport

Fig. 269

ESC Sport / ASR system button

Read and observe   on page 217 first.

ESC Sport allows for a sportier driving style. With ESC Sport switched on, in

the event of light oversteer or understeer of the vehicle, no ESC interventions

take place and the ASR is so limited that the drive wheels can spin.

Activation

Press and hold down the 

» Fig. 269

 button.

or: In the infotainment system, in menu



/  tap on function surface  →

ESC system: → ESC Sport.

With activation the warning light

 lights up in the instrument cluster and an

appropriate message is displayed in the instrument cluster.

Deactivation

Press the 

» Fig. 269

 button.

or: In the infotainment system, in menu



/  tap on function surface  →

ESC system: → Activated.

With deactivation the warning light

extinguishes in the instrument cluster

and an appropriate message is displayed in the instrument cluster.

217

Assist systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Anti-lock brake system (ABS)

Read and observe   on page 217 first.

ABS prevents the wheels locking when braking. Thus helping the driver to

maintain control of the vehicle.
An ABS intervention can be noticed through pulsating movements of the

brake pedal and distinct noises.
When the ABS system is active, do not brake periodically or reduce the pres-

sure on the brake pedal.

Engine drag torque control (MSR)

Read and observe   on page 217 first.

The MSR prevents the blocking tendency of the drive wheels when shifting

down or with an abrupt deceleration (e.g. on icy or otherwise slippery road

surfaces).
If the drive wheels lock, the engine speed is automatically increased. This re-

duces the braking effect of the engine, and the wheels can rotate freely again.

Traction control (ASR)

Read and observe   on page 217 first.

The ASR prevents spinning of the drive wheels. TCS reduces the drive power

transmitted to the wheels in the case of slipping wheels. Thus, for example,

driving on road surfaces with low grip is made easier.
During a TCS intervention, the indicator light

 flashes in the instrument clus-

ter.

Deactivation

Press the 

» Fig. 269

 on page 217 button.

or: In the infotainment system, in menu



/  tap on function surface  →

ESC system: → ASR off.

With deactivation the warning light lights up in the instrument cluster

 and

an appropriate message is displayed in the instrument cluster.

Activation

Press the 

» Fig. 269

 on page 217 button.

or: In the infotainment system, in menu



/  tap on function surface  →

ESC system: → Activated.

With activation the warning light

 is extinguished and an appropriate mes-

sage is displayed in the instrument cluster.

The TCS should normally always be enabled. The system should be deactivated

only in the following situations, for example.

When driving with snow chains.

When driving in deep snow or on a very loose surface.

When it is necessary to “rock” a car free when it has become stuck.

Electronic Differential Lock (EDL and XDS)

Read and observe   on page 217 first.

EDL prevents the turning of the respective wheel of the driven axle. EDL

brakes the spinning wheel, if necessary, and transmits the driving force to the

other driving wheel. Driving becomes easier on road surfaces with different

traction under each wheel of the driven axle.
EDL switches off automatically to avoid excessive heat generation on the

brake of the wheel being braked. Once the brakes have cooled down, there is

an automatic re-activation of EDL.
XDS+ is an extension to the electronic differential lock (EDL). The XDS+ re-

sponds to the release of pressure on the wheels during fast cornering by

means of a braking intervention on the wheel on the inside of the corner on

the driven axle. By decelerating the individual wheels, this prevents the vehicle

from over-steering or understeering. This has a positive effect on the driving

stability and steerability of the vehicle.

Active steering assist (DSR)

Read and observe   on page 217 first.

In critical situations, the DSR provides the driver with a steering recommenda-

tion in order to stabilise the vehicle. DSR is activated, for example, on the right

and left vehicle side when braking sharply on different road surfaces.

218

Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Brake Assist (HBA)

Read and observe   on page 217 first.

The HBA increases the braking effect and helps to reduce the braking dis-

tance.
The HBA is activated by very quick operation of the brake pedal. In order to

achieve the shortest possible braking distance, the brake pedal must be ap-

plied firmly until the vehicle has come to a standstill.
The HBA function is automatically deactivated when the brake pedal is re-

leased.

Hill Start Assist

Read and observe   on page 217 first.

When driving on slopes, Hill Start Assist (hereinafter referred to simply as the

system) allows you to move your foot from the brake pedal to the accelerator

pedal without the vehicle rolling downhill on its own.
The vehicle is braked by the system for about 2 seconds after releasing the

brake pedal.
The system is active as of a 5% slope, if the driver door is closed. The system is

only ever active on slopes when starting off in forward or reverse.

Multicollision brake (MCB)

Read and observe   on page 217 first.

MCB helps to decrease speed after a collision by means of automatic braking

interventions and to stabilise the vehicle. This reduces the risk of a subsequent

crash due to uncontrolled vehicle movement.
The automatic brake interventions can take place only if the following condi-

tions are met.

There was a front, side and rear-end collision of a certain severity.
The impact speed was greater than approx. 10 km/h.
The brakes, the ESL and other required electrical systems remain function-

al after impact.
The accelerator pedal is not actuated.

Trailer stabilisation system (TSA)

Read and observe   on page 217 first.

The TSA helps the combination stable in situations where the trailer sways and

then the whole trailer combination.
TSA brakes the individual wheels of the towing vehicle in order to damp the

rocking motion of the entire vehicle combination.
The following conditions are required for the correct TSA function.

The trailer was shipped from the factory or purchased from the ŠKODA

genuine accessories.
The trailer is electrically connected to the towing vehicle via the trailer

socket.
The parking aid is activated.
The speed is greater than 60 km/h.

Further information

» page 254

Towing device and trailer.

Parking aid (ParkPilot)

Introduction

The parking aid (hereinafter referred to as system) uses acoustic signals or the

Infotainment screen when manoeuvring around obstacles in the vicinity of the

vehicle.

WARNING

The general information relating to the use of assistance systems must be

observed

» page 216,

   in section Introduction.

Moving persons or objects may not be recognized by the system sensors.

Under certain circumstances, surfaces of certain objects and types of

clothing cannot reflect the system signals. There is a danger that such ob-

jects or people may not be recognised by the system sensors.

External noise sources may affect the signals of the system sensors.

There is a danger that obstacles may not be detected by the system sen-

sors.

Before reversing, make sure that there are is not any small obstacle, such

as a rock, thin post etc., in front of or behind your vehicle. Such obstacles

may not be recognised by the system sensors.

219

Assist systems

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CAUTION

Keep the system sensors

» Fig. 270

 on page 220 clean, snow-and ice-free

and do not cover with any objects of any kind, otherwise the system function-

ing may be impaired.

Under adverse weather conditions (heavy rain, water vapour, very low or high

temperatures, etc.), the system function may be limited - “incorrect recogni-

tion of obstacle”.

Accessories fitted to the vehicle rear, such as bicycle carriers, can impair the

system function.

Settings in Infotainment

Read and observe   and   on page 219 first.

In the infotainment system, in menu



/  tap on function surface  → Park-

ing and manoeuvring.

ParkPilot - Settings for the parking aid

Activate automatically - Activate/deactivate the compact parking aid display

(when driving forward)

Front volume - Adjust the volume of the beeps for obstacle detection in front

Front tone setting - Setting the pitch of the beeps for obstacle detection in

front

Rear volume - Set the volume level of the beeps for the rear obstacle detec-

tion

Rear tone setting - Setting the pitch of the beeps for the rear obstacle detec-

tion

Entertainment fading while parking – Lowers the audio volume (e.g. radio vol-

ume) with activated parking aid

Manoeuvre braking - Activation / deactivation of the automatic emergency

braking

Operation

Fig. 270  Installation location of the sensors on the left side of the vehi-

cle: front/rear

Fig. 271

Sampled areas and range of the

sensors

Read and observe   and   on page 219 first.

The system uses ultrasound waves to calculate the distance between the

bumper and an obstacle. The ultrasonic sensors are, depending on vehicle

equipment,, located in the back or in the front bumper

» Fig. 270

.

Depending on the equipment, the following system versions are possible

» Fig. 271

.

Variant 1: warns of obstacles in areas

C

D

.

Variant 2: warns of obstacles in areas

A

B

C

D

.

Variant 3: warns of obstacles in the areas

A

B

C

D

E

.

220

Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     11      12      13      14     ..
