Skoda Rapid Spaceback (2019 year). Instruction - part 12

Headlights

The front of the vehicle may lift up when a trailer (accessory) is being towed

and the headlights may dazzle other road users. Set the range of the headlights

» page 59

.

Power supply of the trailer / accessory power system

In the electrical connection between the vehicle and trailer (accessory), the

trailer (accessories) is supplied with power from the vehicle (with ignition

switched on and off).
With the engine switched off, the vehicle battery is discharged by the connec-

ted consumers.
At low charge state of the vehicle battery, the power supply to the trailer (ac-

cessories) is interrupted.

WARNING

■

An improperly connected electrical installation of the trailer (accessories)

may result in an accident or serious injury from electrical shock.

■

Do not make any adjustments to the electrical installation of the vehicle

and the trailer (accessories) - risk of an accident or serious injury from elec-

trical shock.

WARNING (Continued)

■

After the electrical connection between the vehicle and trailer (accesso-

ry) the trailer / accessory lights should be checked for function.

■

Never use the securing eye to tow - risk of accident!

CAUTION

■

An improperly connected electrical installation of the trailer (accessories) can

lead to the inoperability of the vehicle electronics.

■

The total power consumption of all the connected consumers to the trailer

power supply must not exceed 350 watts, otherwise there is a risk of damage

to the electrical system of the vehicle.

Loading a trailer

Correct the tyre inflation pressure on the vehicle for “full load”

» page 206

.

Distribution of the cargo

Distribute the cargo in the trailer in such a way that heavy items are located as

close to the trailer axle as possible. Secure the load from slipping.
The distribution of the weight is very poor if your vehicle is unladen and the

trailer is laden. Drive with particular caution if you cannot avoid driving with

this combination.

WARNING

A sliding cargo can significantly adversely affect stability and driving safety

- there is a risk of accident!

Trailer load

The details given in the vehicle's technical documentation always take prece-

dence over the details in the Owner's Instruction.

The permissible trailer load must not be exceeded under any circumstances.

Permissible trailer load

Engine

Transmission

Permissible trailer load, braked (kg)

at gradients up to 12%.

Permissible trailer load, unbraked (kg)

1.0 l/70 kW TSI

MG

1000

580

DSG

1000

600

1.0 l/81 kW TSI

MG

1100

590

DSG

1100

610



188

Driving

Engine

Transmission

Permissible trailer load, braked (kg)

at gradients up to 12%.

Permissible trailer load, unbraked (kg)

1.4 l/92 kW TSI

DSG

1200

610

1.6 l/81 kW MPI

MG

1000

580

AG

1000

600

Towing a trailer

Driving speed

For safety reasons, do not drive faster than 100 km/h when hitching a trailer.
Immediately reduce your speed as soon as even the slightest swaying of the

trailer is detected. Never attempt to stop the trailer from “swaying” by accel-

erating.

Brakes

Apply the brakes in good time! If the trailer is fitted with a trailer brake, apply

the brakes gently at first, then brake firmly. This will avoid brake jolts resulting

from the trailer wheels locking.
On downhill sections shift down a gear in good time to also use the engine as a

brake.

WARNING

Always drive particularly carefully with the trailer.

CAUTION

With frequent towing, the vehicle is excessively loaded so this must also be

checked between service intervals.

Anti-theft alarm system

The alarm is triggered if, with a vehicle with activated anti-theft alarm (herein-

after only warning system), the electrical connection to the trailer (accessory)

is interrupted.
Always switch off the anti-theft alarm system before a trailer (accessory) is

coupled or uncoupled

» page 56

.

Conditions for including a trailer (accessory) in the anti-theft alarm system.

The vehicle is factory-fitted with an anti-theft alarm system and a towing

device.
The trailer (accessory) is electrically connected to the towing vehicle by

means of the trailer socket.
The electrical system of the vehicle and trailer (accessory) is functional.
The vehicle is locked and the anti-theft alarm system is activated.
The trailer (accessory) is not equipped with LED taillights.











189

Towing device and trailer

General Maintenance

Care and maintenance

Service work, adjustments and technical alterations



Introduction

The instructions and guidelines from ŠKODA AUTO must be observed when

using accessories or carrying out any modifications, repairs or technical altera-

tions to your vehicle.
Adhering to these instructions and guidelines helps ensure road safety and

helps keep your vehicle in a good technical condition.

WARNING

■

Adjustments, repairs and technical changes to the vehicle should only be

carried out by a specialist. Work carried out incorrectly (including work on

the electronic components and their software) can result in malfunctions -

there is a risk of accident and, potentially, increased wear on parts!

■

We recommend that you use only ŠKODA Original Accessories and ŠKO-

DA Original Parts which have been expressly approved for use on your ve-

hicle. Reliability, safety and suitability for your vehicle are guaranteed with

these.

■

Do not use any products which have not been approved by ŠKODA AU-

TO, even though these may be products with a type approval or which have

been approved by a nationally recognised testing laboratory.

Vehicle operating under different weather conditions



Read and observe   on page 190 first.

If you would like to operate your vehicle in countries other than those with the

intended weather conditions, you should contact a ŠKODA partner. He or she

will advise you if certain precautions need to be taken to ensure the full func-

tioning of the vehicle or to prevent damage (e.g. coolant, changing the battery

or similar).

ŠKODA service partner



Read and observe   on page 190 first.

All ŠKODA service partners work according to the instructions and guidelines

from ŠKODA AUTO. All service and repair work is therefore carried out on

time and to the appropriate quality. Adhering to these guidelines and instruc-

tions helps ensure road safety and helps keep your vehicle in a good technical

condition.
We therefore advise you to have all modifications, repairs and technical altera-

tions to your vehicle carried out by a ŠKODA Service Partner.

ŠKODA Original parts



Read and observe   on page 190 first.

We recommend the use of ŠKODA Genuine Parts for your vehicle, as these

parts are approved by ŠKODA AUTO. These parts comply wholly with ŠKODA

AUTO regulations and are identical to the parts used in series production.
ŠKODA AUTO is able to warrant the safety, suitability, and long life of these

products.
ŠKODA Service Partners are liable for any defects of ŠKODA Genuine Parts for

a period of 2 years after sale in accordance with the materials defect liability,

unless agreed otherwise in the purchase agreement.

ŠKODA Original accessories



Read and observe   on page 190 first.

If you wish to fit accessories to your vehicle, you should remember the follow-

ing.
We recommend that you use ŠKODA Genuine Accessories in your vehicle.

ŠKODA AUTO has selected these accessories to ensure that they are reliable,

safe and suitable for your particular vehicle. Although we constantly monitor

the market, we are not able to assess or vouch the suitability of other products

for your vehicle, despite the fact that some products may have operational ap-

proval or may have been approved by a nationally recognised testing laborato-

ry.



190

General Maintenance

ŠKODA Service Partners are liable for any defects of ŠKODA Genuine Acces-

sories for a period of 2 years after installation or delivery in accordance with

the materials defect liability, unless agreed otherwise in the purchase agree-

ment or any other agreements.

Spoiler



Read and observe   on page 190 first.

WARNING

If your vehicle is equipped with a Genuine Accessories spoiler on the front

bumper in combination with the spoiler on the boot lid, the following in-

structions must be observed - otherwise there is a risk of accidents and se-

rious injuries!

■

The vehicle can only be equipped with a spoiler on the front bumper in

combination with the corresponding spoiler on the boot lid.

■

A Genuine Accessories spoiler cannot be fitted to the front bumper ei-

ther on its own (without a spoiler on the boot lid) or in combination with an

unsuitable spoiler on the boot lid.

■

We recommend that you consult the ŠKODA Service Partner for any re-

pairs to or replacement, addition or removal of spoilers.

■

Improperly conducted work on the spoilers of your vehicle may result in

malfunction.

Component protection



Read and observe   on page 190 first.

Some electronic vehicle components (such as the instrument cluster) are fac-

tory-equipped with component protection. This ensures the functional limita-

tion of these components in a non-legitimate installation in another vehicle

(e.g. after a theft) or operation outside the vehicle.

Airbags



Read and observe   on page 190 first.

WARNING

■

Modifications, repairs and technical alterations that have been carried out

unprofessionally can cause damage and operational faults, and can also se-

riously impair the effectiveness of the airbag system – risk of accident and

fatal injury!

■

A change to the vehicle's wheel suspension, including the use of non-ap-

proved wheels and tire combinations, can impair the functioning of the air-

bag system - risk of accident and fatal injury!

WARNING

■

No changes may be made to airbag system components, the front bump-

er and the bodywork.

■

Any work on the airbag system including the installation and removal of

system components due to other repair work (e.g. removal of the steering

wheel) must only be carried out by a specialist garage.

■

Do not manipulate individual parts of the airbag system, as this might re-

sult in the airbag being deployed.

■

If the airbag has been deployed, the airbag system must be replaced.

Cleaning and care



Introduction

Regular and thorough care helps to retain the value of your vehicle.
The instructions for use on the packaging must be observed when using care

products. We recommend that you use ŠKODA Original Accessories care

products.

WARNING

■

Vehicle care products may be harmful to your health if not used according

to the instructions.

■

Always keep the vehicle care products safe from people who are not

completely independent, e.g. children - danger of poisoning!



191

Care and maintenance

CAUTION

■

Do not use any insect sponges, rough kitchen sponges or similar cleaning

products – risk of damaging the paintwork surface.

■

Do not use aggressive cleaning agents or chemical solvents - danger of dam-

aging the surface to be cleaned.

Note

We recommend that the vehicle is cleaned and maintained at a ŠKODA service

partner.

Car washing



Read and observe   and   on page 191 first.

The best way to protect your vehicle against harmful environmental influences

is frequent washing.
The longer insect residues, bird droppings, road salt and other aggressive de-

posits remain on the paintwork of your vehicle, the more detrimental their de-

structive effect can be. High temperatures, such as those caused by intensive

sun's rays, accentuate this caustic effect.
It is also essential to thoroughly clean the underside of the vehicle at the end

of the winter.

Washing by hand

Wash the vehicle from top to bottom, with a soft sponge or a wash mitt and

plenty of water, and, if necessary, with the appropriate detergents. Wash out

the sponge or washing glove thoroughly at short intervals.
For wheels, door sills and lower areas of the vehicle use a different sponge.
Give the vehicle a good rinse after washing it and dry it off using a chamois

leather.

Automatic Car Washes

The usual precautionary measures must be taken before washing the vehicle

(e.g. closing the windows and the tilt/slide roof etc.).
If your vehicle is fitted with any special attached parts (e.g. spoiler, roof rack

system, two-way radio aerial etc.) it is best to consult the operator of the car

wash system beforehand.

After an automatic wash with wax treatment, the wiper blades should be

cleaned with cleaning agents specially designed for the purpose, and then de-

greased.

Pressure Washers

When washing the vehicle with a high-pressure cleaner, the instructions for

use of the equipment must be observed. This particularly applies to instruc-

tions regarding the pressure and spraying distance from the vehicle surface.

WARNING

■

When washing your vehicle in the winter: Water and ice in the braking

system can affect the braking efficiency – risk of accident!

■

Take care when cleaning the underbody or the inside of the wheel wells -

there is a risk of injury from sharp metal parts!

CAUTION

■

Do not wash the vehicle in direct sunlight, do not exert pressure on the body

while washing. The temperature of the washing water should be no more than

60 °C max. - otherwise there is a risk of damaging the vehicle paint.

■

Before driving through a car wash fold in the exterior mirrors - risk of dam-

age.

■

For vehicles with roof antenna the antenna rod should be unscrewed before

driving through a car wash - there is a risk of damage.

CAUTION

Washing the vehicle with high-pressure cleaners

■

Do not wash the foils using pressure washers - there is a risk of damage.

■

Do not aim the water jet directly at the lock cylinders or the door or opening

joints when washing the vehicle in the winter – there is a risk of freezing.

■

During cleaning, always keep a sufficiently large spraying distance in particu-

lar from the parking sensors, the reversing camera lens, the external decorative

and protective plastic parts (e.g. roof racks, spoilers, protective strips) and oth-

er vehicle parts made of non-metallic materials, such as rubber hoses or insula-

tion materials – otherwise there is a risk of damage.

192

General Maintenance

Exterior car care



Read and observe   and   on page 191 first.

Vehicle compo-

nents

Circumstances

Remedy

Paint

Spilled fuel

Clear water, cloth, (clean as soon as

possible)

No water drop-

lets form on the

paint

Use hard wax preserve (at least twice a

year), apply wax to clean and dry body

Paint has gone

matt

Use polish, then wax (if the polish does

not contain any preservative ingredi-

ents)

Plastic parts

Soiling

Clear water, cloth / sponge, possibly

cleaners provided for this purpose

Chrome

and anodised

parts

Soiling

clear water, cloth, possibly cleaners

provided for this purpose, clean then

polish with a soft dry cloth

Films

Soiling

soft sponge and mild soap solution

a)

Windows

and external mir-

ror glass

Soiling

Wash with clean water and dry with a

wipe specifically for that purpose

Head / taillights

Soiling

soft sponge and mild soap solution

a)

Reversing camera

Soiling

Wash with clean water and dry with a

soft cloth

Snow/ice

Hand brush / de-icer

Door lock cylin-

ders

Snow/ice

De-icing fluid specifically for that pur-

pose

Wiper / wiper

blades

Soiling

Windscreen cleaner, sponge or cloth

Wheels

Soiling

Clear water, then apply appropriate

substance

a)

A mild soap solution consisting of 2 tablespoons of natural soap to 1 litre of lukewarm water.

The jack is maintenance-free. If necessary, the moving parts of the jack should

be lubricated with a suitable lubricant.

The towing device is maintenance-free. Coat the ball head of the towing de-

vice with a suitable grease whenever necessary.

Protection of cavities

All the cavities of your vehicle which are at risk from corrosion are protected

by a layer of long-lasting protective wax applied in the factory.
If any small amount of wax flow out of the cavities at high temperatures, these

must be removed with a plastic scraper and the stains cleaned using a petrole-

um cleaner.

Underbody

The underside of your vehicle is already permanently protected by the factory

against chemical and mechanical influences.
We recommend having the protective coating checked — preferably before

the beginning of winter and at the end of winter.

Product life of the films

Environmental influences (e.g. sunlight, humidity, air pollution, rockfall) affect

the life of the films. Films will age and become brittle – this is entirely normal;

this is not a fault.
Sunlight may also affect the strength of the film colour.
When transporting a load on the roof rack (e.g. roof box or similar), there is an

increased risk of film damage (e.g. of chipping from the secured load).

CAUTION

■

Vehicle paint

■

Repair damaged areas as soon as possible.

■

Matt-painted parts should not be treated with polishes or hard waxes.

■

Do not polish in a dusty environment - risk of paint scratches.

■

Do not apply any paint care products to door seals or window guides.

■

Plastic parts

■

Do not use paint polish.

■

Chromed and anodised parts

■

Do not polish in a dusty environment - risk of surface scratches.

■

Films

The following instructions must be observed, otherwise there is a risk of film

damage.

■

Do not use dirty cloths or sponges for cleaning.

■

Do not use a scraper or other means to remove ice and snow.



193

Care and maintenance

■

Do not polish the films

■

Do not use a high pressure cleaner on the films.

■

Rubber seals

■

Do not treat the door seals and window guides deal with anything - the

protective varnish coating could be damaged.

■

Windows and door mirrors

■

Do not clean the insides of the windows/mirrors with sharp objects - risk of

damage to the filaments or the antenna.

■

Do not use a cloth which has been used to polish the body - this could dirty

the window and impair visibility.

■

Head / taillights

■

Do not wipe head/taillights dry, do not use any sharp objects - risk of dam-

age to the protective coating and cracks forming on the headlight glass cov-

ers.

■

Reversing camera

The following instructions must be observed, otherwise there is a risk of

camera damage.

■

Do not remove snow / ice with warm / hot water.

■

To wash, never use a pressure washer or steam jet.

■

For cleaning, do not use abrasive cleaners.

■

Door lock cylinders

■

Make sure that as little water as possible gets into the locking cylinder

when washing the vehicle - there is a risk of freezing the lock cylinder!

■

Wheels

■

Heavy soiling of the wheels can affect the balance of the wheels - the re-

sult can be a vibration, which can cause premature wear of the steering.

Removing snow and ice from the windscreens

Fig. 228

Installation location of the ice

scraper, removing the scraper



Read and observe   and   on page 191 first.

Use a plastic ice scraper for removing snow and ice from the windows and

mirrors. This can be on the inside of the fuel filler flap.

›

Open the fuel filler flap and slide the scraper in the direction of arrow

» Fig. 228

.

CAUTION

■

Move the scraper in one direction only, otherwise there is a risk of damage to

the glass surface.

■

Do not remove snow / ice on the surface that is soiled (e.g. pea gravel, sand,

road salt) - there is a risk of damaging the surface.

■

Remove snow / ice carefully, otherwise there is a risk of damaging the labels

that have been fitted by the factory.

Caring for the interior



Read and observe   and   on page 191 first.

Vehicle compo-

nents

Circumstances

Remedy

Natural leather /

Faux leather /

Alcantara

®

 /

Suede /

Fabric

Dust, surface

soiling

Vacuum cleaner

Soiling (fresh)

Water, slightly damp cotton / wool

cloth, if necessary, mild soap solution

a)

,

then wipe off with a soft cloth

Stubborn stains Cleaning fluid specifically for this task

Care (natural

leather)

Treat the leather periodically with a

leather protecting fluid / use a care

cream with light blocker and impregna-

tion after each cleaning

Care (Alcantara

®

suede / fabric)

Remove stubborn hair using a “cleaning

glove”

Remove pills from materials with a

brush

Plastic parts

Soiling

Water, slightly damp cloth or sponge, if

necessary cleaners specifically for this

purpose



194

General Maintenance

Vehicle compo-

nents

Circumstances

Remedy

Windows

Soiling

Wash with clean water and dry with a

wipe specifically for that purpose

Covers on electri-

cally heated seats Soiling

Cleaners specifically for this purpose

Seat belts

»

Soiling

soft cloth and mild soap solution

a)

a)

A mild soap solution consisting of 2 tablespoons of natural soap to 1 litre of lukewarm water.

WARNING

■

Never clean the seat belts chemically as chemical cleaning products could

destroy the fabric.

■

Air fresheners and scents can be hazardous to heath when the tempera-

ture inside the vehicle is high.

CAUTION

■

Natural leather / Faux leather / Alcantara

®

 suede / material

■

Avoid standing for lengthy periods in bright sunlight, and protect the mate-

rials by covering to prevent them from fading.

■

Remove fresh stains (e.g. from pens, lipstick, shoe polish and similar) as

soon as possible.

■

Ensure that no part of the leather is soaked through during cleaning and

that no water gets into the seams - risk of damaging the leather!

■

Do not clean the roof panelling with a brush – risk of damage to the surface

of the panelling.

■

Do not use solvents, floor wax, shoe cream, stain remover or similar agents

on Alcantara

®

 suede seat upholstery.

■

Some clothing fabrics (e.g. dark denim) do not have sufficient colour fast-

ness - this could lead to clearly visible discolouration on the upholstery. This

is not a defect in the fabric.

■

Sharp objects on garments (e.g. zips, rivets, sharp- edged belts) can dam-

age the upholstery fabrics in the vehicle. Such damage will not be recognised

as a justified complaint.

■

Plastic parts

■

Do not attach scents or air fresheners to the dashboard – risk of damage to

the dashboard.

■

Windows

■

Do not attach any stickers to the filaments or glass antenna - there is risk

of damage.

■

Covers on electrically heated seats

■

Do not clean either with water or with other liquids - risk of damage to the

heating system.

■

Do not dry by switching on the heating.

■

Seat belts

■

After cleaning the belts, allow them to dry before retracting them.

Note

During use, the leather and Alcantara

®

 and suede materials may show minor

changes (e.g. folds, discolouration).

195

Care and maintenance

Inspecting and replenishing

Fuel



Introduction

Fig. 229  Label with prescribed fuel / graphic designation of fuel types

The correct fuel for your vehicle is specified on the inside of the fuel filler flap

» Fig. 229

.

The fuel tank has a capacity of about 55 litres, including a reserve of approx.

7 litres.
Graphic name of the fuel types

» Fig. 229

Unleaded petrol
Diesel
CNG (compressed natural gas)
Percentage of organic

WARNING

The fuel and fuel vapours are explosive - it can be fatal!

A
B
C
D

CAUTION

■

Never drive until the fuel tank is completely empty! Irregular supply of fuel

can cause misfiring, which can result in damage to parts of the engine and the

exhaust system.

■

Immediately remove any fuel that has spilled onto the vehicle's paintwork –

risk of paint damage.

■

If you would like to operate your vehicle in countries other than those with

the intended weather conditions, please contact a ŠKODA partner. They will

tell you whether the fuel specified by the manufacturer is offered in that coun-

try and/or whether the manufacturer will sanction operating the vehicle with

another fuel.

Petrol Refuelling

Fig. 230  Open fuel filler flap / unscrew tank cap / place the tank cap on

the fuel filler flap



Read and observe   and   on page 196 first.

Perform the refuelling under the following conditions.

The vehicle is unlocked.
The ignition is switched off.

›

Press the fuel filler flap in direction of arrow

1

 and fold in the direction of

arrow

2



» Fig. 230

.

›

Unscrew the tank cap in the direction of arrow

3

.

›

Remove the tank cap and place on top of the fuel filler flap in direction of ar-

row

4

.

›

Insert the pump nozzle into the fuel filler tube as far as it will go.

The fuel tank is full as soon as the pump nozzle switches off for the first time.

Do not continue refuelling.







196

General Maintenance

›

Remove the pump nozzle from the fuel filler neck and put it back in the

pump.

›

Place the filler cap onto the fuel filler neck and turn it in the opposite direc-

tion to the arrow until it securely engages

3

.

›

Close the fuel filler flap until it clicks into place.

Unleaded petrol



Read and observe   and   on page 196 first.

The correct fuel for the vehicle is specified on the inside of the fuel filler flap

» Fig. 229

 on page 196.

The vehicle can only be operated with unleaded petrol containing maximum

10% bioethanol (E10).
Unleaded petrol must correspond to the European Standard EN 228 (in Ger-

many DIN 51626-1 or E10 for unleaded petrol with octane number 95 and 91

or DIN 51626-2 or E5 for unleaded petrol with octane number 95 and 98).

Specified petrol 95 / min. 92 and 93 RON/ROZ

We recommend using petrol 95 RON.
Optionally, the petrol 92 or 93 RON can be used (slight power loss, a slightly

increased fuel consumption).
In an emergency, petrol 91 RON can be used (slight power loss, slightly in-

creased fuel consumption)

»

.

Specified petrol is unleaded, min. 95 RON / ROZ

Use min. 95 ROZ petrol.
In an emergency, 91, 92 or 93 ROZ petrol can be used (slight loss of power,

slightly increased fuel consumption)

»

.

Prescribed petrol 98/(95) RON / ROZ

We recommend using petrol 98 RON.
Optionally, petrol 95 ROZ can be used (slight power loss, a slightly increased

fuel consumption).
In an emergency, 91, 92 or 93 ROZ petrol can be used (slight loss of power,

slightly increased fuel consumption)

»

.

CAUTION

The following instructions must be observed, otherwise there is a risk of dam-

age to the engine and to the exhaust system.

■

When petrol with a lower than the prescribed octane is used, only continue

driving at mid-range engine speeds and with minimal strain on the engine. Re-

fuel using petrol of the prescribed octane number as soon as possible.

■

Lower than 91 octane petrol should not be used, even in an emergency!

■

If a fuel other than unleaded fuel which complies to the above mentioned

standards (e.g. leaded petrol) is put in the tank by mistake, do not start the en-

gine or switch on the ignition.

CAUTION

Petrol additives (additives)

■

The unleaded petrol in accordance with the prescribed standards meets all

the conditions for a smooth running engine. We therefore do not recommend

mixing fuel additives into the petrol - risk of engine damage or damage to the

exhaust system.

■

The following additives may not be used - risk of engine damage or dam-

age to the exhaust system!

■

Additives with metal components (metallic additives), in particular with

manganese and iron content.

■

Fuels with metallic content (e.g. LRP - lead replacement petrol).

Note

■

Unleaded petrol that has a higher octane number than that required by the

engine can be used without limitations.

■

The use of petrol with an octane rating higher than 95 ROZ does not result in

either a noticeable increase in power nor lower fuel consumption in vehicles

for which unleaded petrol 95/min 92 or 93 ROZ is specified.

■

On vehicles using the prescribed petrol of min. 95 ROZ, the use of petrol

with a higher octane number than 95 ROZ can lead to an increase in power and

reduction in fuel consumption.

197

Inspecting and replenishing

Engine compartment



Introduction

WARNING

Never cover the engine with additional insulation material (e.g. with a cov-

er) – risk of fire!

WARNING

When working in the engine compartment, the following instructions must

be observed - otherwise risk of injury or fire. The engine compartment of

your car is a hazardous area!

WARNING

Instructions before beginning work in the engine compartment

■

Stop the engine and remove the ignition key, on vehicles with the KESSY

system, open the driver's door.

■

Firmly apply the handbrake.

■

For vehicles with manual transmission the lever into the neutral position.

For vehicles with automatic transmission, place the selector lever in the P

position.

■

Allow the engine to cool.

■

Never open the bonnet if you can see steam or coolant flowing out of the

engine compartment – risk of scalding! Wait until the steam or coolant has

stopped escaping.

WARNING

Information for working in the engine compartment

■

Keep everyone away from the engine compartment.

■

Do not touch any hot engine parts – risk of burns!

■

Never touch the radiator fan. The radiator fan may still turn suddenly

about 10 minutes after switching off the ignition!

■

Do not smoke in the vicinity of the engine and avoid the use of open

flames or sparks.

■

Do not leave any items (e.g. cloths or tools) in the engine compartment.

This presents a fire hazard and the risk of engine damage.

■

Read and observe the information and warning instructions on the fluid

containers.

WARNING

Information for working in the engine compartment with the engine run-

ning

■

If it is necessary to work on the engine with the engine running, beware

of rotating engine parts and electrical plants - they can be fatal!

■

Never touch the electric wiring on the ignition system.

■

Avoid short circuits in the electrical system, particularly on the vehicle's

battery.

CAUTION

Only refill using fluids with the proper specification - risk of damage to the ve-

hicle!

Note

■

Fluids with the proper specifications can be purchased from the ŠKODA

Original Accessories or from the ŠKODA Genuine Parts ranges.

■

We recommend you have the operating fluids replaced by a specialist ga-

rage.

198

General Maintenance

Opening and closing the bonnet

Fig. 231  Opening the bonnet



Read and observe   and   on page 198 first.

Open flap

›

Ensure that the windscreen wipers are not raised away from the windscreen

- risk of damage to the bonnet.

›

Open the front door and pull the release lever below the dash panel in the

direction of arrow

1



» Fig. 231

.

›

Press the release lever in the direction of arrow

2

 and the bonnet will be un-

locked.

›

Raise the bonnet in the direction of the arrow

3

.

›

Remove the lid prop in the direction of arrow

4

 from the holder.

›

Secure the open flap inserting the end of the post into the opening in the di-

rection of arrow

5

.

Close the flap

›

Lift the bonnet.

›

Decouple the bonnet support and press into the holder designed to hold it.

›

Drop down the bonnet lid from a height of about 20 cm applying light pres-

sure until it clicks safely into place.

WARNING

■

Never drive with the bonnet lid not properly closed - risk of accident!

■

Make sure that when closing the bonnet, no body parts are crushed -

there is danger of injury!

CAUTION

When closing the bonnet “do not press down” - there is a risk of damaging the

bonnet.

Engine compartment overview

Fig. 232  Arrangement (example) in the engine compartment



Read and observe   and   on page 198 first.

Coolant expansion reservoir

201

Engine oil dipstick

200

Engine oil filler opening

200

Brake fluid reservoir

202

Vehicle battery

203

Windscreen washer fluid reservoir

200

A
B
C
D

E
F

199

Inspecting and replenishing

Windscreen washer fluid

Fig. 233

Windscreen washer fluid reser-

voir



Read and observe   and   on page 198 first.

The windscreen washer fluid reservoir

A

 is located in the engine compart-

ment

» Fig. 233

.

The contents of the container is 3.5 litres, for vehicles with a headlamp clean-

ing system 5.4 litres (for some countries, both versions have container vol-

umes of 5.4 litres).
Use a suitable windscreen washer fluid for the current or expected weather

conditions. We recommend that you use windscreen washer fluid from

ŠKODA Original Accessories.

CAUTION

■

Only use liquids that do not attack polycarbonates - otherwise there is a risk

of damage to the headlights.

■

Do not remove the filter from the windscreen washer fluid reservoir when

replenishing it with liquid otherwise the liquid transportation system can be-

come contaminated, which can cause the windscreen washer system to mal-

function.

Engine oil

Specification

To find out which type of engine oil you can use for your vehicle, contact a

specialist garage.

If this oil is not available, other oils can also be refilled. To prevent engine dam-

age, a maximum of 0.5 l of engine oil with the following specifications may be

used until the next oil change: VW 504 00, VW 502 00, VW 508 00, ACEA

A3/ACEA B4 or API SN, (API SM).

Check and refill

Fig. 234  Dipstick variants

The engine uses up some oil, depending on driving style and operating condi-

tions (up to 0.5 l / 1 000 km). Consumption may be slightly higher than this

during the first 5 000 km.
Have the oil change carried out by a specialist garage during the inspection.
Check and refill oil under the following conditions.

The vehicle is standing on a horizontal surface.
The engine operating temperature is reached.
The engine is turned off.

Checking the level

›

Wait a few minutes until the engine oil flows back into the oil trough.

›

Pull the dipstick out and wipe with a clean cloth.

›

Push the dipstick back to the stop and then pull it out again.

›

Read the oil level and push the dipstick back in.

The oil level must lie in range

A



» Fig. 234

. If the oil level is below range

A

, oil

must be added.

Refilling

›

Unscrew the cap of the engine oil filler opening

C



» Fig. 232

 on page 199.

›

Add oil of the correct specification in increments of 0.5 litres

» page 200

.

›

Check the oil level.









200

General Maintenance

›

Screw the lid of the engine oil filler closed carefully.

WARNING

The following instructions must be followed at all times when working on

the engine compartment

» page 198

.

CAUTION

■

The oil level must never fall outside range

A



» Fig. 234

 – otherwise there is a

risk of damaging the engine and the exhaust system.

■

If a top up with oil is not possible or the oil level is above range

A

,



 do not

continue driving! Switch off the engine and seek assistance from a specialist

garage.

■

Do not add any additives to the engine oil - risk of engine damage.

Note

■

Too low engine oil level is shown in the instrument cluster by the warning

light illuminating and also indicated by the message

» page 43

. Nevertheless,

we recommend checking the oil level on a regular basis using the dipstick.

■

We recommend that you use oils from ŠKODA Original Accessories.

Coolant



Introduction

The coolant helps to keep the engine temperature down, and consists of water

and coolant additive (with additives that protect the cooling system against

corrosion and prevent furring).
The proportion of coolant additive in the coolant must be 40 to 60 %.
The correct mix of water and coolant additive should be checked and if neces-

sary corrected by a specialist garage.

WARNING

■

The following instructions must be followed at all times when working on

the engine compartment

» page 198

.

■

Never open the end cover of the coolant expansion reservoir while the

engine is still warm. The cooling system is pressurised - risk of scalding or

injury from splashes of coolant!

WARNING (Continued)

■

To protect against the coolant splashing, cover the cap with a cloth when

opening.

■

Coolant and coolant fumes are harmful - avoid contact with the coolant.

If the coolant comes into contact with the eye or skin, wash the affected

area with plenty of water for several minutes, and where appropriate seek

medical help.

CAUTION

Do not cover the radiator and install any parts (e.g auxiliary lights.) in front of

the air intakes - risk of the engine overheating.

Checking and refilling

Fig. 235

Coolant expansion reservoir



Read and observe   and   on page 201 first.

Check and refill coolant under the following conditions.

The vehicle is on a horizontal surface.
The engine is not warm (if the engine is warm the result of the check may

be wrong).
The engine is turned off.

Check the coolant level – The coolant level must lie between the marks

A

and

B



» Fig. 235

. If the coolant level is below the mark

B

, top up with cool-

ant.

Refilling

The reservoir must always contain a small amount of coolant

»

.

›

Place a cloth over the cap of the coolant expansion tank and unscrew the cap

carefully.









201

Inspecting and replenishing

›

Always top up using coolant of the correct specification.

›

Turn the cap until it clicks into place.

The specification for the coolant is shown in the coolant expansion reservoir

» Fig. 235

.

If the specified coolant is not available, then refilling only with distilled or dem-

ineralised water, and get a specialist garage to correct the water-coolant addi-

tive mix as soon as possible.

CAUTION

■

If the expansion tank is empty, do not top up with coolant. The system could

aerate - risk of engine damage!



 Do not drive the vehicle! Switch off the en-

gine and seek assistance from a specialist garage.

■

Do not fill the coolant above the mark

A



» Fig. 235

. The coolant could, when

heated, be expelled from the cooling system - risk of damage to the engine

parts.

■

If it is not possible to add coolant,



 do not continue driving! Switch off the

engine and seek assistance from a specialist garage.

■

A coolant additive which does not correspond to the correct specification

can reduce the anti-corrosion effect of the cooling system - risk of damage to

the cooling system and the engine.

■

If non-distilled (non-demineralised) water has been used to top up, the cool-

ant should be replaced by a specialist garage - risk of engine damage.

■

A loss of coolant indicates leaks in the cooling system - risk of engine dam-

age. Top up with coolant and then seek assistance from a specialist garage.

Note

A coolant level which is too low is indicated in the instrument cluster by the

warning light  and a corresponding message

» page 43

. We still recommend

inspecting the coolant level directly at the reservoir from time to time.

Brake fluid

Fig. 236

Brake fluid reservoir

Check the brake fluid under the following conditions.

The vehicle is on a horizontal surface.
The engine is turned off.

Checking the brake fluid level – The brake fluid level must lie between the

markings “MIN” and “MAX”

» Fig. 236

.

Specification - the brake fluid must comply with the standard VW 501 14 (this

standard meets the requirements of FMVSS 116 DOT4).
The brake fluid change is carried out during the inspection.

WARNING

■

If the date of the brake fluid change is exceeded, steam bubbles could

form in the brake system during heavy braking. This can impair the efficien-

cy of the brakes – risk of accident!

■

The following instructions must be followed at all times when working on

the engine compartment

» page 198

.

■

If the fluid level drops significantly within a short time or if it drops below

the “MIN”

» Fig. 236

 mark, this may be an indication of a leak in the brake

system.



 Do not continue driving - There is a risk of accident! Seek help

from a specialist garage.

Note

A brake fluid level which is too low is indicated in the instrument cluster by the

warning light



 and a corresponding message

» page 38

. We still recommend

inspecting the brake fluid level in the reservoir from time to time.





202

General Maintenance

Vehicle battery



Introduction

The vehicle battery represents a power source for the motor to start and for

the supply of electrical consumers in the car.
Depending on the engine, the vehicle battery is either in the engine compart-

ment or the luggage compartment.

Automatic consumer shutdown - Discharge protection of the vehicle

battery

The on-board power supply system tries to prevent the vehicle battery from

discharging in the following ways when it is subject to heavy loading.

▶

By increasing the engine idle speed.

▶

Through the power limitation of certain consumers.

▶

By switching off some consumers (e.g. heated seats) for as long as necessa-

ry.

Warning symbols on the vehicle battery

Symbol

Meaning



Always wear eye protection!



Battery acid is severely caustic. Always wear gloves and eye pro-

tection!



Keep fire, sparks, open flames and lit cigarettes well clear of the

vehicle battery!



When charging the vehicle battery, a highly explosive gas mixture

is produced!



Keep children away from the vehicle battery!

WARNING

Battery acid is highly corrosive - it can cause injury, chemical burns or poi-

soning! Corrosive vapours in the air irritate and damage the respiratory

tract and the eyes. The following guidelines must be observed.

■

Always wear protective gloves, eye and skin protection when handling

the vehicle battery.

WARNING (Continued)

■

If your eyes or skin come into contact with the electrolytic fluid, immedi-

ately wash the affected area for a few minutes long with a lot of water.

Seek medical assistance without delay.

■

Keep the vehicle battery away from people who are not completely inde-

pendent (e.g. children).

■

Do not tilt the battery otherwise battery electrolyte may flow out of the

battery vent openings.

WARNING

Working on the car battery may cause explosion, fire, injury or chemical

burn! The following guidelines must be observed.

■

Do not smoke, use open flames or light or transmitting devices.

■

A discharged vehicle battery may freeze slightly. Never charge up a fro-

zen or thawed vehicle battery. Replace a frozen vehicle battery.

■

Never use a damaged vehicle battery.

■

Do not connect the battery terminals, bridging the two poles will cause a

short circuit.

CAUTION

Ensure that battery acid does not come into contact with the bodywork – risk

of damage to the paintwork.

Note

■

We recommend having all work on the vehicle battery carried out by a spe-

cialist garage.

■

You should replace batteries older than 5 years.

203

Inspecting and replenishing
