Skoda Rapid Spaceback (2019 year). Instruction - part 9





Navigation

Introductory information

Navigation - function sequence

Applies to Infotainment Amundsen.

Route guidance is started as follows.

Find/enter a new destination or select one of the stored destinations.

Confirm the route calculation in the destination details or, if necessary, adjust

the route options.

Select the preferred route type, if this is requested by the Infotainment sys-

tem.

A route is calculated and route guidance starts.
The route guidance is provided by means of graphical driving recommenda-

tions and navigation announcements.
There is an option to add additional destinations during route guidance, or to

adapt the route.
If a traffic radio station is available, information concerning traffic delays is

evaluated by the Infotainment system and, if necessary, an alternative route is

offered.
If you deviate from the route, then a new route is calculated.

GPS satellite signal

Infotainment uses the GPS (Global Positioning System) satellite signal for

route guidance.
Outside the range of the GPS satellite signal (e.g. in dense vegetation, in tun-

nels, parking garages, etc.), the Infotainment system navigates only with re-

strictions, with the aid of vehicle sensors.
The Infotainment system offers the possibility off showing the following infor-

mation on the current geographical position of the vehicle and the satellite sig-

nal in the Position

» Fig. 162

 on page 142 split screen.

Geographical latitude
Geographical longitude

Elevation
Number of received/available satellites

If no GPS satellite signal is available, no values are displayed.

Navigation data

Navigation data source

The navigation data is stored on an Original SD Card.
In order to ensure the function of the navigation, the Original SD card, with the

navigation data, must be inserted in the respective slot in the external module

» page 93

.

If the original SD card is damaged or lost, a new original SD card can be pur-

chased from ŠKODA Original Accessories.
With a Non-original SD Card, navigation does not work.

Determining the version of the navigation data

In the main Navigation menu, tap the function surface  → Version information .

Updating the navigation data

We recommend that you update the navigation data on a regular basis.
The Infotainment can give incorrect driving recommendations if the road con-

dition or the traffic situation does not match the navigation data. This can lead

to route guidance being carried out using a different route or proposing a

change of direction in a one-way street. Therefore, observe the respective

traffic signs while driving, which always have priority over the driving recom-

mendations.
The information on updating the navigation data can be obtained from a

ŠKODA partner or on the following ŠKODA websites.

http://go.skoda.eu/updateportal

Importing/updating the POI categories online

When “Infotainment Online”

» page 13

 services are activated, it is possible to

download the POI categories created in the user profile on the “ŠKODA

Connect portal” websites.

In the main Navigation menu, tap the function surface  → Version information

→ Online update → Retrieve.

or: Press the



 button, then tap on function surface  →  .

140

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

A menu for the import/update of POI categories is displayed.

Select the desired list entries.

Tap on the function surface Retrieve and confirm the download process.

Main menu

Fig. 160

Navigation: Main menu

To display, press the



 button.

or: Press the



 button, then tap on function surface  .

Description of the function interfaces

A



» Fig. 160

Context-dependent:

Route guidance is deactivated - Search/enter a new destination

Route guidance is activated - The following menu is displayed:

Route details - Displays the route details

» page 154

Congestion ahead - Instruction adjusts traffic conditions

» page 157

Enter destination - Search / enter a new destination / stopover

» page 142

Stop route guidance - Stops route guidance

» page 154

The following menu is displayed:

Curr. current position - Store the current vehicle position as the flagged

destination

» page 146

Routes - Displays the list of saved routes

» page 155

Destinations - Display the list of stored destinations

» page 145

Last destinations - Display the list of recent destinations to which route

guidance was carried out

» page 145

Home address - Route guidance to your home address

» page 146

Search for POIs in categories

 and

Map display options

» page 149

Operation of Media/Radio playback

  

Display for the volume setting of the navigation announcements/repeti-

tion of the navigation announcement

» page 153

Navigation settings

» page 105

Map

Fig. 161

Map description

The following information and function surfaces can be displayed in the

map.

» Fig. 161

Vehicle position
Route
Function interfaces for card use

» page 149

Function surface of the POI
Function surface for the POI list
Function surface for displaying a traffic incident

» page 156

Information on the maximum permitted speed
Destination position
Intermediate destination position
Destination position Home address
Favourite position

Information in the status line

Street name/street number of the current vehicle position
Distance to destination
Route to the stopover
Estimated travelling time to the destination
Estimated travelling time to the stopover
Estimated time of arrival at destination/stopover

A
B
C
D

E
F

G

141

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Split screen

Fig. 162

Split screen

To activate/deactivate, go to the main Navigation menu and tap on the func-

tion surface  → Split screen.

To select content of the split screen

A



» Fig. 162

, tap on the function sur-

face  Tap and select one of the following menus, depending on the context.

Audio - Operation of Radio/Mediaplayback

Compass - Displays the current vehicle location in relation to the compass di-

rections

Most frequent routes - Display the three most frequent routes (if guidance not

being carried out)

» page 153

Manoeuvre - Display graphical driving recommendations (if route guidance is

enabled)

» page 153

Position - Displays the geographical coordinates of the current vehicle loca-

tion

Search for destination and enter

Selecting the type of destination search/destination entry

Fig. 163

Selecting the type of destina-

tion search/destination entry

Route guidance is disabled - From the navigation main menu, the function

surface  →  .

 Route guidance is enabled - From the main menu navigation, tap on the

function surface  → Enter destination →  .

Function surfaces

» Fig. 163

Search for a destination or POI (point of interest) by name

» page 142

Destination entry by address

» page 143

Online POI search

» page 142

Search for a point along the route (only works with active route guidance)

» page 142

Destination input via the map point or using the GPS coordinates

» page 144

Search for destination/POI

Fig. 164

Menu for the destination search

Fig. 165  List of destinations visited: in the navigation data / online

The feature allows a full text search of locations or points of interest (POI) by

entering keywords.

A
B
C
D

E

142

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Show menu

Route guidance is disabled - From the navigation main menu, the function

surface  →  .

 Route guidance is enabled - From the main menu navigation, tap on the

function surface  → Tap Enter destination

Then tap the function surface of one of the menu items for the destination

search

A

C

 or

D



» Fig. 163

 on page 142.

Function surfaces

» Fig. 164

 and

» Fig. 165

Input line
Depending on the search mode, the following symbols are displayed

 - Display the map as well as the list of the destinations listed in the navi-

gation database

 - Display the map as well as the list of online destinations

 - Select the destination search/destination entry

» page 142

List of last destinations (if no character is entered) / List of visited destina-

tions
Keypad
Status of online services

Find destination

Enter the POI name or the POI category (POI) and, if required, the place and

street name or house number/postal code.

A list of the destinations found is displayed in area

D



» Fig. 164

.

Select the desired destination and the destination details will be displayed.

or: Tap the

B



» Fig. 164

 function surface.

A map with the following symbols and a list of the destinations found is dis-

played.

Destinations found in the navigation data

» Fig. 165

 - .

Destinations found online

» Fig. 165

 - .

Select the desired destination and the destination details will be displayed.

A
B

C
D

E
F

Enter destination using the address

Fig. 166  Enter destination using the address: Main menu / List of visited

destinations

Show menu

Route guidance is disabled - From the navigation main menu, the function

surface  .

 Route guidance is enabled - From the main menu navigation, tap on the

function surface  → Tap Enter destination

Then tap the function surface  →

B



» page 142

Enter dest.

Enter the destination address and then confirm

» Fig. 166

 - .

Tap the function surface  to see the destination details.

Relevant names (e.g. place/street names) are offered in the entry line during

entry, depending on the context. The location of the proposed destination can

be displayed by tapping the function surface Map.
Depending on the number of places visited, a map with a list of visited places

can be displayed automatically

» Fig. 166

 - .

The map with the list of visited locations can be accessed instructionly by tapping

the function surface  .

143

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Entering a destination via the map point and using GPS coordinates

Fig. 167  Enter destination: via the map point / using the GPS coordi-

nates

Show menu

Route guidance is disabled - From the navigation main menu, the function

surface  .

 Route guidance is enabled - From the main menu navigation, tap on the

function surface  → Tap Enter destination

Then tap the function surface  →

E



» Fig. 163

 on page 142.

Enter destination via map point

By sliding the screen move the desired destination into the cross-hair

» Fig. 167

 - .

Tap the function surface  to see the destination details.

Entering the destination using coordinates

Tap in the values of the GPS coordinates one at a time and adjust

» Fig. 167

 -

,

Tap the function surface  to see the destination details.

If information is available about the point entered in the navigation data, then

these will be displayed instead of the GPS coordinates (e.g. address

A

» Fig. 167

).

Entering a destination via the map point

Fig. 168

Menu after tapping the map

point

Tap on the map to display the symbol  and a menu with the following menu

items (depending on the context)

» Fig. 168

.

Display the destination details

» page 151

Display the POI details/display the list of POIs (function surface) )
Start route guidance to the selected point
Paste the selected point into the current route guidance as the next des-

tination
Start route guidance to the favourite
Start route guidance to the home address
Destination search in the vicinity of the selected point

» page 142

Define the starting point for demo mode (if it is turned on)

» page 152

Find petrol station, restaurant or car park

Fig. 169  List of petrol stations visited: in the navigation data / online

A
B

C

144

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Fig. 170  List of car parks visited: in the navigation data / online

The Infotainment allows you to find petrol stations, restaurants or car parks

quickly in the navigation data as well as online.

In the main Navigation menu, tap the function surface  .

Tap the function surface of the desired category.

or: Press the



 button, and then tap on function surface  →  or  .

Find destination in the navigation data

Depending on the context below, a list of POIs from the selected category is

displayed.

No route guidance is taking place - The nearest destinations in a radius of

200 km from the current vehicle position are displayed.

Route guidance is taking place - Destinations on the route or near the route

are displayed.

Find destination online

When “Infotainment Online”

» page 13

 services are activated, a list of POIs

from the selected category in a radius around the current vehicle position is

displayed, regardless of whether or not route guidance is taking place.
After searching for a destination, you can switch between the list of destina-

tions found in the navigation data and the list of destinations found online by

tapping one of the following function surfaces at position

A



» Fig. 169

 or

» Fig. 170

.

Displays the list of destinations found in the navigation data.
Displays the list of destinations found online.

Note

With the  → Fuel options → Select preferred fuel station function activated, the pre-

ferred fuel stations are displayed in the first three positions during the fuel sta-

tion search.

Saved destinations

Last destinations

List of last destinations

In the main Navigation menu, tap the function surface  → Last destinations.

Details of the last destination

In the main Navigation menu, press the



 button.

If route guide is not taking place, the details of the last destination to which

route guidance was carried out are displayed. If route guidance is taking

place, the details of the final destination are displayed.

Last destinations in the destination/POI search menu

In the destination search menu, a short list of last destinations is shown in the

area

D



» page 142

.

Function surfaces in the list of last destinations

- Destination search by name (the function surface is displayed when

there are more than 5 entries available)
- Display the details of the selected destination

» page 151

Destination memory

Fig. 171  Select list of stored destinations/categories of stored destina-

tions

Find

145

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

List of stored destinations

In the main Navigation menu, tap the function surface  → Destinations.

Tap on function surface

A



» Fig. 171

 and select one of the following catego-

ries of saved destinations

B



» Fig. 171

.

All saved destinations

 - Flagged destination (vehicle position at the time of storage)

 - Stored destination (instructionly saved destination/destination impor-

ted in vCard format)

 - Favourite (destination with additional favourite property)

Favourites (the favourite location is shown on the map by the

 symbol).

Telephone contact addresses of the connected telephone.
Online destinations created in the user profile on the “ŠKODA Connect

Portal” website or in the “ŠKODA Connect” application

» page 148

Function surfaces in the list of stored destinations

- Destination search by name (the function surface is displayed if there

are several entries on the next page of the list)
- Display the destination details

» page 151

Store target

In the main Navigation menu, tap the function surface  → Last destinations.

Tap the functional surface  Tap on the desired destination, the destination

details are displayed.

Tap on the function surface Store .

Rename the destination if necessary and confirm storage.

Save “flagged destination” (current vehicle position)

In the main Navigation menu, tap the function surface  → Store → Store cur-

rent position.

By tapping again on function surface Rename, you can rename the flagged

destination and store it as a destination in the destination memory.

Storing the next flagged destination will overwrite the last flagged destination.

To maintain the existing flagged destination, it must be stored in the Infotain-

ment memory.

Save destination as a favourite/cancel

It is not possible to store a contact address, a vCard or a target image as a fa-

vourite.

In the main Navigation menu, tap the function surface  → Destinations.

Tap the functional surface  and select the desired list of destinations.

Find

Show the destination details by tapping on the function surface  at the de-

sired destination.

Tap the function surface Edit.

Tap the function surface Favourite.

Delete the destination

In the main Navigation menu, tap the function surface  → Destinations.

Tap the functional surface  and select the desired list of destinations.

Show the destination details by tapping on the function surface  at the de-

sired destination.

Tap the function surface Edit.

Tap the function surface Delete and confirm the deletion.

Home address

Define home address

When your home address is not entered, proceed as follows.

In the main Navigation menu, tap the function surface  → Home address.

Define the home address using the current vehicle position or by entering

the address.

Change home address

In the main Navigation menu, tap the function surface  → Manage memory →

Define home address.

Tap the function surface Edit.

Edit the home address or set one up using the current vehicle position or by

entering the address.

Delete home address

In the main Navigation menu, tap the function surface  → Manage memory →

Delete user data → Home address.

Tap the function surface Delete and confirm the deletion.

146

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Import custom destinations

Introduction to the subject

Fig. 172

MyDestination application on

the ŠKODA websites

Fig. 173

ŠKODA Connect websites

Your own destinations can be created using the ŠKODAapplication

“MyDestination”, in the user profile on the website “ŠKODA Connect Portal” or

in the application “ŠKODA Connect”
Scan the QR code

» Fig. 172

 or enter the following address in your web brows-

er to display more information on the “MyDestination” application.

http://go.skoda.eu/my-destination

For the “ŠKODA Connect Portal” refer to the website of “ŠKODA Connect”.

You can open this by scanning the QR code

» Fig. 173

 or entering the following

address in your web browser.

http://go.skoda.eu/connectivity

Destinations in vCard format

In the Infotainment memory, you can import a custom destination in vCard

format (*.vcf) from an SD card or a USB source.

Import

Insert the SD card into the external module or connect a USB source with

the file of the custom destination.

In the main Navigation menu, tap the function surface  → Manage memory →

Import destinations (SD/USB).

Select the source and confirm the import.

Route guidance

In the main Navigation menu, tap the function surface  → Destinations →  →

 .

Find and select the desired imported destination.

Delete custom destination

In the main Navigation menu, tap the function surface  → Destinations →  →

 .

Tap the functional surface  Tap on the desired own destination.

In the destination details, tap the function surface Edit → Delete and confirm

the deletion process.

POI categories created in the “MyDestination” application

Import/update

Insert the SD card into the external module or connect a USB source with

the POI categories.

In the main Navigation menu, tap the function surface  → Manage memory

Update "My POIs" (SD/USB) Tap.

If the same custom POI category name already exists in the Infotainment

memory, then it will be overwritten during the import.

Show POIs in the map

In the main Navigation menu, tap the function surface  → Map → Select cate-

gories for POIs → My points of interest (Personal POI).

Select the imported POI category.

Guidance to the POI

In the map, tap on the traffic obstruction symbol.

Details of the selected destination will be displayed

» page 151

.

Clear all own POI categories

In the main Navigation menu, tap the function surface  → Manage memory →

Delete "My POIs".

Tap the function surface Delete and confirm the deletion.

147

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

POI categories created in the user profile in the “ŠKODA Connect

Portal”

Your own POI categories created in the user profile on the website “ŠKODA

Connect Portal” can be imported into the Infotainment memory.
The requirement for importing a POI category is that “Infotainment Online”

» page 13

 services are activated.

Importing POI categories

In the main Navigation menu, tap the function surface  → Version information →

Online update.

or: Press the



 button, then tap on function surface  →  .

A menu for importing/updating the navigation data and POI categories is dis-

played.

Tap the function surface POIs → Retrieve.

If new POI categories are available, their quantity and file size is displayed by

the Infotainment system.

Tap the function surface Start to start route guidance.

To complete the import, tap the function surface Next and confirm the im-

port.

Show POIs in the map

In the main Navigation menu, tap the function surface  → Map → Select cate-

gories for POIs → My points of interest (Personal POI).

Select the imported POI category.

Route guidance to a destination in the imported POI category

In the map, tap on the traffic obstruction symbol.

There are details of the selected target appears

» page 151

,

Clear all own POI categories

In the main Navigation menu, tap the function surface  → Manage memory →

Delete "My POIs".

Tap the function surface Delete and confirm the deletion.

Destinations created in the user profile in the “ŠKODA Connect

Portal”

The destinations you have created in the user profile on the website “ŠKODA

Connect Portal” or in the application “ŠKODA Connect” can be imported to the

Infotainment memory.
The requirement for importing the destinations is that “Infotainment Online”

» page 13

 services are activated.

importing destinations

In the main Navigation menu, tap the function surface  → Destinations →  →

 .

or: Press the



 button, then tap on function surface  →  .

Tap on the function surface Update.

If new destinations are available, then confirm the import.

If the user profile on the website “ŠKODA Connect Portal” or in the application

“ŠKODA Connect” creates an object and sent to the Infotainment, after

switching on the ignition in the Infotainment screen displays a message re-

garding a new destination with the option to import this displayed.

Route guidance to an online destination

In the main Navigation menu, tap the function surface  → Destinations →  →

 .

In the list of online destinations, find and select the desired destination.

Deleting online destinations

To delete all online destinations go to the main Navigation menu and tap the

function surface  → Manage memory → Delete user data → Online destinations.

To delete one online destination, go to the main Navigation menu and tap on

function surface  → Destinations →  →  →  → Edit → Delete.

148

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Image with GPS coordinates

Fig. 174

Image with GPS coordinates

Infotainment enables guidance to the GPS coordinate data stored in the im-

age.

Press the



 button then tap the function surface Images.

Select the connected source and open the image with GPS coordinates.

Tap the function surface 

» Fig. 174

 Surface in the image, a menu opens with

the option to start route guidance.

The image can be obtained from an external device in which GPS coordinates

are stored during the imaging process. This can be created and imported in

the“MyDestination” application

» Fig. 172

 on page 147.

Map

Map display options

Fig. 175

Map display options

In the main Navigation menu, tap the function surface  .

The following function surfaces are displayed

» Fig. 175

.

2D - Two-dimensional map display
3D - Three-dimensional map display
Display of the route from the current vehicle location to the destination
Display of the position of the destination or the next stopover on the map

(depending on the setting for menu item  → Advanced settings → Status line:)
Automatic map display in day or night mode (depending on the currently

active vehicle lighting)
Daytime map display
Night-time map display
Switch the split screen display on/off

» page 142

Switching on/ off of the selected POI categories display

» page 144

Enter-

ing a destination via the map point

If the map scale of the 2D Map or 3D Map is greater than 10 km, then the map

is automatically displayed as 2D and aligned in the direction of north. If the

scale is increased beyond this value, then the map is switched back to the orig-

inal representation.

Map scale

Fig. 176  Function surfaces for changing the map scale

It is possible to change the map scale manually or to activate the automatic

scale change.

Tap the function surface

A



» Fig. 176

.

In area

B



» Fig. 176

, function surfaces for changing the map scale are dis-

played.

A

B
C
D
E

149

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Types of manual scale change

Touch the screen with two fingers and pull them apart or close them togeth-

er.

Press the control knob  .

Activating automatic scale change

If the automatic scale is active, the map scale will change automatically de-

pending on the type of roads travelled (motorway - smaller map scale / town -

larger map scale) and the manoeuvre to be carried out.

To activate the automatic scale change, go to the main Navigation menu and

tap on function surface  →  .

Tap the functional surface  is highlighted in green.
The automatic scale is only active as long as the map is centred on the vehicle

position (the function surface  is hidden).

To deactivate the automatic scale change, go to the main Navigation menu

and tap on function surface  →  .

Tap the functional surface  is highlighted in white.
The function is also deactivated when the map is moved or the map scale is

changed manually.

Map view in reduced scale

In the main Navigation menu, tap on function surface

A

 →  .

The map scale is reduced for a few seconds and then restored.

Changing map orientation

Fig. 177

Changing the map orientation

You can change the map orientation under the following conditions.

The map is in the 2D display.
The map is centred (the function surface  is hidden).
The map scale is max. 10 km.

To change the map orientation, go to the main Navigation menu and tap on

function surface 

A



» Fig. 177

.

The map is oriented to the north

The symbol  the vehicle position rotates, the map and the Polar Star Symbol

 do not rotate.

With a larger map scale than 10 km, the map is automatically oriented towards

north.

Map oriented to the direction of travel

The map and the Polar Star symbol  rotate, the vehicle position symbol 

does not rotate.

Map centring

Fig. 178

Map centring

The moved map can be centred in the vehicle, destination or route position.

To centre the map, tap on function surface 

A



» Fig. 178

.

POIs display

The Infotainment system offers the possibility of displaying POI symbols on

the map on the Infotainment screen.

To activate/deactivate the display, go to the main Navigation menu and tap

on the function surface  → POIs.

To select the POIs to be displayed, go to the main Navigation menu and tap

on the function surface  → Map → Select categories for POIs and select the de-

sired categories (max. 10).

150

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Road sign display

The Infotainment system offers the option of displaying the traffic signs stor-

ed in the navigation data or detected by the front camera during guidance on

the Infotainment screen

G



» Fig. 161

 on page 141.

To activate/deactivate the road sign display, go to the main Navigation

menu and tap on the function surface  → Map → Show road signs.

For some vehicles it is possible to set an alert when exceeding the permitted

speed limited by a road sign.

Press the



 button, then tap on function surface  → Driver assistance →

Speed warning:.

When towing a trailer, we recommend that you activate recognition of road

signs relevant to trailers.

Press the



 button, then tap on function surface  → Driver assistance → Show

road signs relevant to trailers.

Route guidance

Introduction to the subject

route is created by starting route guidance to a destination. Additional stop-

overs can be added to the route.
Route guidance takes place as follows

Through graphical driving instructions on the Infotainment screen and in the

display of the instrument cluster.

Through navigation announcements.

The Infotainment system tries to allow for continued guidance even if the nav-

igation data is incomplete or there is no data at all for the given area.
The route is recalculated each time you ignore driving recommendations or

change the route.

CAUTION

The navigation announcements provided may vary from the actual situations,

e.g. due to out-of-date navigation data.

Destination details

Fig. 179  Details of the: in the navigation data / destination searched for

online

The following menu items and information are displayed in the destination de-

tails

» Fig. 179

.

Area with function surfaces
Detailed destination information
Destination position in the map
Detailed destination information (if available)
Status of online services

Display the destination details

The destination details can be displayed in one of the following ways.

While entering a destination.

By tapping on the function surface  in the destination list.

Press the



 button in the main Navigation menu to display the details of

the last destination.

Function surfaces

Using the function surfaces in area

A

, the following functions can be per-

formed, depending on the context.

Start/stop route guidance.

Searching for a nearby destination

» page 142

.

Set route options.

Store destination.

A
B
C
D

E

151

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Edit destination (the destination can be deleted, renamed or saved as a fa-

vourite).

Dial the POI phone number (if the Infotainment system is connected to a

phone

» page 127

Pairing and connecting).

Route calculation and starting route guidance

Fig. 180

Alternative routes

Routes are calculated based on the set route options. The route options can be

set:  → Route options.

Alternative routes

With selection of alternative routes turned on, the following menu is displayed

after calculation of a new route

» Fig. 180

.

 Calculate the most economical route with shortest travelling time and

distance travelled – the route is highlighted green

 Calculate the fastest route to the destination, even if a detour is neces-

sary - the route is highlighted in red

 Calculate the shortest route to the destination, even if a longer travel-

ling time is required - the route is highlighted in orange

It is possible to select an already calculated alternative route before calculation

of the remaining routes is completed.
Selecting the type of route will start the route guidance.
If no route selection is made within 30 s of calculation of all routes, route guid-

ance will start automatically according to the preferred route type.

A

B

C

Route calculation for trailer towing

When driving with a trailer or any other accessory connected to the trailer

socket, we recommend that you switch on trailer recognition, if necessary, to

set the maximum speed for towing a trailer.

To calculate the route when driving with a trailer, go to the main Navigation

menu and tap the function surface  → Route options →  .

To set the maximum speed of the trailer, press the



 button, then tap on

function surface  → Driver assistance → Trailer recognition → Maximum speed for

trailer.

Demo mode

Demo mode provides a driving simulation to the entered destination. The func-

tion allows you to travel through the calculated route “virtually”.
When Demo mode is turned on, a menu for route guidance in Demo mode or

in normal mode is displayed before route guidance starts.

To activate/deactivate, go to the main Navigation menu and tap on the func-

tion surface  → Advanced settings → Demo mode.

When Demo mode is activated, the route starting point can be defined.

In the main Navigation menu, tap the function surface  Tap→ Advanced set-

tings → Define demo mode starting point.

Define the starting point by entering the address or the current vehicle posi-

tion.

The demo mode starting point can also be set provided demo mode is turned

on by tapping on the desired map location and selecting the menu item Start

Demo Mode

» page 144

Entering a destination via the map point.

152

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Graphical driving recommendations

Fig. 181  Driving recommendations/driving recommendation detail

The display of the graphical driving recommendations is carried out in the split

screen Manoeuvre as well as the display of the instrument cluster.
In the Manoeuvre split screen, the following driving recommendations are dis-

played

» Fig. 181

.

Street name/street number of the current vehicle position
Driving recommendations with street names/road numbers, the route and

the travel time to the manoeuvre location
Driving recommendation details (displayed near the manoeuvre)
Lane guidance

In the Manoeuvre split screen, the Infotainment system also draws your atten-

tion to traffic obstructions received via TMC, as well as to motorways, car

parks, petrol stations or restaurants.

Speed limits

With the  → Advanced settings → Note:National border crossed , display the

country-specific speed limits when crossing international borders.
These speed limits can be displayed by tapping on function surface  → Top

speed in the main menu navigation.

Navigation announcements

The Infotainment system issues navigation announcements during route guid-

ance.

A
B

C
D

The navigation announcements are generated by the Infotainment system.

Flawless clarity of the message (e.g., road or city name) cannot always be guar-

anteed.
The last navigation announcement can be repeated in the main Navigation

menu by tapping on the function surface  →  .
The timing of the navigation announcement is dependent on the type of road

and on the driving speed.
The type of navigation announcements can be set:  → Navigation announcements.

Note

Route guidance on the most frequently travelled route takes place without

navigation announcements.

Most frequent routes

The most frequently travelled routes are automatically saved by Infotainment.

Of these, up to 3 routes can be offered, which best match the current time,

day of the week as well as the vehicle position.
Route guidance to one of the routes used most frequently can be started pro-

vided route guidance is not currently active.

To display the menu with the most frequently travelled routes, go to the split

screen and tap on the function surface Most frequent routes → Show on map.

Select the desired route.

The selected route is then calculated and route guidance starts.

The menu display in the split screen can be activated/deactivated in the main

Navigation menu by tapping the function surface  → Route options → Most fre-

quent routes switched on/off.
The stored most frequent routes can be deleted in the main Navigation menu

by tapping the function surface  → Manage memory → Delete user data → Most fre-

quent routes deleted.

Note

Route guidance on the most frequently travelled route takes place without

navigation announcements.

153

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Finish route guidance

Route guidance can be finished in one of the following ways.

The final destination is reached.

In the main Navigation menu by tapping the function surface  → Stop route

guidance.

By turning off the ignition for longer than 120 minutes.

Abort route guidance

If the ignition is switched off and on again, then route guidance is continued in

one of the following ways, depending on the stop time.

Within 15 minutes - route guidance continues, taking the calculated route in-

to account.

From 15 minutes to 120 minutes - after confirming the message on the Info-

tainment screen, the route guidance continues, taking the calculated route

into account.

After 120 min - route guidance is cancelled.

Route

Route details

Fig. 182  Route details: a route destination / several route destinations

During route guidance, the Route details (information about the current route)

can be displayed.

In the main Navigation menu, tap the function surface  → Route details.

One route destination

In the route details, the following information is displayed at the destination

» Fig. 182

 - .

Area with function surfaces
Destination information

Estimated time of arrival at destination/remaining driving time to desti-

nation
Remaining distance to the destination
Chosen route type (economic, fastest, shortest)
Current vehicle position (address/GPS coordinates)

You can adjust the display of the arrival time or the remaining driving time as

follows.

In the main Navigation menu, tap the function surface  → Advanced settings →

Time display:.

Several route destinations

In the route details, the following information is displayed at the respective

destinations

» Fig. 182

 - .

Area with function surfaces
Stopover (with sequential number)
Final destination
Estimated time of arrival at destination/stopover
Driving distance to destination/stopover
Change positions of the destinations with each other
Delete the destination
Continuation of the route guidance from the selected target (previous

stopovers are skipped)
Display the destination details

» page 151

Insert destination into the route

In the area

A

, tap on the function surface Enter destination and enter a new

destination.

or: Tap on the area

A

 the function surface destinations and select an object in

the list of stored destinations.

Each additional destination is added to the list as the first subsequent destina-

tion route.

A
B



C
D

A

154

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Change positions of destinations with each other

Press and hold the relevant function surface  and move the destination to

the desired position.

For destinations already reached on the route, the note Destination reached is dis-

played below the destination name. It is no longer possible to change the posi-

tion of these destinations with each other.

Store route

In area

A

, tap the function surface Save.

Save the edited route as a new route or replace the existing saved route.

Einstellungen des Menüs Medien bzw.

» page 155

.

Stop route guidance

In area

A

, tap the function surface Stop.

Route list

In the route list, it is possible to create, import, save or delete routes or start

navigation.

New route

In the main Navigation menu, tap the function surface  → Routes → New route.

Insert a route destination in one of the following ways.

Tap on the function surface Enter destination and enter a new destination.

or: Tap on the function surface Destinations and select a destination from the

list of saved destinations.

To save the created route, tap the function surface Store.

To start route guidance, tap the function surface Start.

Route import

A prerequisite for importing the route is that “Infotainment Online”

» page 13

services are activated.
A route that has been created in the user profile on the “ŠKODA Connect

Portal” website and sent to the Infotainment system can be imported into the

Infotainment memory even before switching on the ignition .
If the route was created when the ignition was switched on and sent to Info-

tainment, Infotainment is not imported until after switching off (for at least 15

minutes) and after switching the ignition back on again.

Switch on the ignition. When a new route is available, a message regarding

the option to import this route appears in the Infotainment screen automati-

cally.

If the user opts not to import the route immediately, the route can be impor-

ted manually later, as follows.

In the main Navigation menu, tap the function surface  → Routes Tap to

check if a new route is available.

or: Press the



 button, then tap on function surface  →  .

Tap the function surface Import routes.

If a new route is available, a message will be displayed by the Infotainment sys-

tem.

Tap the function surface Retrieve to start route guidance.

After being successfully imported, the route is displayed in the list of saved

routes.

Managing saved routes

In the main Navigation menu, tap the function surface  → routes .

Choose the desired route, and then select one of the following functions.

- delete the stored route

- Edit the route

» page 154

Route details

- Calculate route and start route guidance

» page 152

Route calculation

and starting route guidance

Traffic reports

List of traffic reports

Fig. 183

List of traffic reports

Delete
Edit
Start

155

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     7      8      9      10     ..
