Skoda Rapid Spaceback (2019 year). Instruction - part 6





Left control dial for switching Infotainment on and off; volume adjustment
Control dial for calls and confirmations



 - Radio menu

» page 111



 - Media menu

» page 115



 - Telephone menu

» page 126



 - Voice control

» page 98



 - Navigation menu

» page 140



 - Target-oriented traffic information

» page 155



 - Vehicle system settings

» page 158



 Overview of Infotainment menu

» page 96

Touch screen

» page 93

Description – Infotainment Swing

Fig. 121  Infotainment Swing

Left control dial for switching Infotainment on and off; volume adjustment
Control dial for calls and confirmations



 - Radio menu

» page 111



 - Media menu

» page 115

Depending on equipment fitted:



 - Telephone menu

» page 126



 Muting



 - Infotainment settings

» page 107

1

2
3
4
5
6
7
8
9

1

2
3

4

Depending on equipment fitted:



 - Menu SmartLink (Press) / turn on / off the voice control function

SmartLink (hold)

» page 135



 - Sound settings

» page 107



 - Vehicle system settings

» page 158

Touch screen

» page 93

SD card slot

» page 118

Description – Infotainment Blues

Fig. 122  Infotainment Blues

Dial (hereinafter only symbol )
Display
SD card slot
Switches Infotainment on/off
Radio menu

» page 112

 / Select radio frequency range

Media menu

» page 116

 / Select audio source

Settings of the selected menu (Radio

» page 111

 /Media

» page 111

)

Infotainment settings

» page 110

- Sound settings

» page 110

Backward / forward movement / settings of the selected menu item

values

Function keys (each of the functions for these keys is described in the

relevant chapters)

5

6
7
8

1

2
3











 /

 -

92

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

External module

Applies to Infotainment Amundsen.

Fig. 123

External module: Infotainment

Amundsen

The external module is located in the storage compartment on the front pas-

senger side

» Fig. 123

.

SD1 card slot
SD2 card slot

Touch screen

The Infotainment can be operated by lightly touching the screen with your

fingers.
The brightness level of the screen can be set by

» page 101

 or

» page 107

.

To protect the screen, a suitable protective film for touch screens can be used.
The screen can be cleaned with a soft cloth and pure spirit if necessary.

1

2

Infotainment operation

Infotainment operation

Screen areas

Applies to Infotainment Columbus, Amundsen.

Fig. 124

Screen areas

Description of the display

» Fig. 124

Status line with time and outdoor temperature data and other information
Information and operation of the current menu
Function surfaces of the current menu

Operation principles

Applies to Infotainment Columbus, Amundsen.

Fig. 125

Screen display

Description of the display

» Fig. 125

Name of the current menu
Return to the higher-level menu

A
B
C

A
B

93

Infotainment operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Scroll symbol – you can move in the menu by moving your fingers up or

down on the scroll symbol
Menu item with “checkbox”

 - Function is switched on

 - Function is switched off

 Opens a sub-menu of the menu item with a “pop-up window”

Function surfaces

The screen areas which confirm a function or a menu are called “function sur-

faces”.

White text – the surface is active and thus selectable

Grey text – the surface is inactive and therefore not selectable

Green frame – currently selected surface

Selecting a menu/menu item/function

Drag your finger over the screen in the required direction.

By moving your finger over the scroll bar

By turning the dial .

Confirming a menu/menu item/function

By tapping on the function surface.

By pressing the dial .

Returning to higher-level menu

By tapping on the function surface .

By tapping on the screen outside of the “pop-up window”.

By pressing the corresponding button next to the screen (e.g. in the menu

Media, by pressing the



 button).

Selecting a menu item/function value

 - Selected menu item/function value

 - Deselected menu item/function value

Setting a value

By tapping on the function surface  or  the bottom of the screen.

By touching or moving your finger over the scale.

By turning the dial .

Note

Depending on the equipment, the Infotainment can also be operated by means

of the buttons on the multifunction steering wheel. Further information

» page 47

.

C

D

E

Operating principles and display areas

Applies to Infotainment Blues.

Fig. 126

Display

Description of the display

» Fig. 126

Total number of menu items for each setting
Position of the current menu item
Name of the current menu item
Go to previous menu item value
Go to next menu item value
Current menu item value

Setting a value

The desired value of the selected item will be set to one of the following ways.

By pressing button

 or

.

By turning the dial .

Exit setting

To exit setting, press one of the buttons

 -

.

If the device is not being operated, the display switches off after a few sec-

onds in the last selected mode of (Radio or Media).

A
B
C
D

E
F

94

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Operating the menus

Applies to Infotainment Amundsen.

Fig. 127  Operating the menus

Operating the menus

» Fig. 127

Browsing the menu, list entries
Expand/reduce the menu window
Open / close the menu window
Close the menu window

Alphanumeric keyboard

Applies to Infotainment Columbus, Amundsen.

Fig. 128

Example of the keyboard display

The alphanumeric keyboard is used to enter letters, numbers and characters.

A
B
C

Description of the alphanumeric keyboard

» Fig. 128

Input line
Context-dependent:



 - Toggle upper case to lower case and vice versa



 - Switch to special characters



 - Switch to numbers

Context-dependent:



 - Switch to numbers



 - Switch to Latin letters



 - Switch to Cyrillic letters

- Display of visited entries (the number of visited entries is displayed in the

function surface)
Erase the entered characters
Hold to display the variants of the respective letters.

Switch between keyboards with specific characters of the selected

languages

» page 102

 or

» page 108

Space
Move the cursor within the input line to the left
Move the cursor within the input line to the right
Confirmation of the entered characters

Search

While entering characters, a search is made for corresponding entries.
The entry to be searched for (such as a telephone contact) must be entered

along with any special characters (diacritics).
By tapping on the function surface  a list of matching entries opens.

Switching Infotainment on/off

Applies to Infotainment Amundsen, Swing, Blues

To switch Infotainment on/off, press

.

Automatic switch-on of Infotainment

If Infotainment was not switched off with

 before the ignition was switched

off, it will automatically switch on when the ignition is switched on.

Automatic switch-off of Infotainment

If the vehicle key is pulled out of the ignition lock while Infotainment is switch-

ed on, Infotainment will switch off automatically.

A
B

C

  



95

Infotainment operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If the vehicle is fitted with the starter button, Infotainment will switch off au-

tomatically after the engine is switched off and the door is opened.
With the ignition off, Infotainment will automatically switch off after about 30

minutes.
Infotainment switches off automatically under certain circumstances. Infotain-

ment informs you of this via a text message on the Infotainment display.

Infotainment restart

If Infotainment stops responding (if it “freezes”), it can be restarted by press-

ing and holding

 for longer than 10 s (does not apply to Infotainment Blues).

Show time and date on the screen

Applies to Infotainment Columbus, Amundsen.

Standby mode

With the ignition on and infotainment off (Standbymode), it is possible to dis-

play the time and date on the Infotainment screen.
Applies to Infotainment Amundsen

To switch the time and date display on/off, press the



 button, then tap

the function surface  → Screen Show clock in standby mode.

The display mode can be changed by finger motion across the screen side-

ways.
Applies to Infotainment Swing

To switch the time and date display on/off, press the



 button, then tap

the function surface Screen → Show clock in standby mode.

"Screen off" mode

With the ignition on and functions Switch off screen (in 10 seconds) and Display clock

when screen is off

» page 101

 enabled, it is possible to display the time and date

when the Infotainment screen is switched off.
The display type depends on the display mode selected in standby mode (does

not apply to the Infotainment Swing).

Adjusting the volume

Every change in volume is displayed on the screen.

Applies to Infotainment Amundsen, Swing

To increase the volume, turn the controller

 clockwise.

To decrease the volume, turn the controller

 anticlockwise.

To mute, turn the controller

 anticlockwise to 0.

or: To activate/deactivate the mute setting, press the button



 (applies

to Infotainment Swing).

Applies to Infotainment Blues

To increase the volume, turn the control switch

1



» Fig. 122

 on page 92

clockwise.

To decrease the volume, turn the control switch

1

 anticlockwise.

To mute, turn the controller

1

 anticlockwise to 0.

The following symbol appears on the screen when the sound is muted .
If, at the time of muting, sound is being played from a source in the Media

menu, then the playback is stopped.

CAUTION

High volumes can cause sound resonance in the vehicle.

When changing or connecting an audio source, this may cause sudden

changes in volume. Reduce the volume before changing or connecting an au-

dio source.

Infotainment menus

Applies to Infotainment Amundsen.

Fig. 129

Overview of Infotainment me-

nus: Grid display

96

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Fig. 130

Overview of Infotainment me-

nus: List

To display the overview of Infotainment menus, press the



 button.

To set the display mode, press the button



, then tap the function surface

 → Screen → Menu:.

Select the Grid display

» Fig. 129

 or Horizont. Display

» Fig. 130

 option.

Overview of Infotainment menus

Radio menu

» page 111

Media menu

» page 115

“ŠKODA Connect” Online Services

» page 12

SmartLink menu

» page 135

With a connection established to an external device,  the actual connec-

tion is shown instead of a symbol

 Android Auto

» page 136

 Apple CarPlay

» page 137

 MirrorLink®

» page 137

Telephone menu

» page 126

Vehicle system settings

» page 158

Navigation menu

» page 140

 (Applies to Infotainment Amundsen)

List of traffic reports (TMC) (applies to Infotainment Amundsen)

» page 155

Media Command menu (Applies to Infotainment Amundsen)

» page 124

Images menu

» page 122

- Sound settings

» page 101

Infotainment settings

» page 101

Configuration wizard

Applies to Infotainment Columbus, Amundsen.

The configuration wizard is automatically displayed if there are at least two

non-selected menu items after turning on the Infotainment.

For instruction display in Infotainment Amundsen, press the



 button, then

tap on the function surface  → Configuration wizard.

For instruction display in Infotainment Swing, press the



 button, then tap

the function surface Configuration wizard.

The Configuration wizard allows you to set the following menu items in se-

quence.

Time and date format
Storing the radio station with the strongest reception signal at present
Pairing and connecting a telephone to the Infotainment system
Home address (applies to Infotainment Amundsen)
Setting “ŠKODA Connect” online services

The selected menu item is marked with the

 symbol.

Operating using an application in the external device

Applies to Infotainment Amundsen, Swing.

Some Infotainment functions can be operated using an application in the sup-

ported external device.
For the complete functionality of the application, data transmission from ex-

ternal devices must be activated and, if necessary, operation of the Infotain-

ment via the application must be approved.

Applies to Infotainment Amundsen

Activate data transfer in Infotainment. To do this, press the



 button and

then tap function surface  → Mobile device data transfer → Activate data transfer

for ŠKODA Apps.

Release Infotainment operation using the application. To do this, press the



 button and then tap function surface  Tap→ Mobile device data transfer →

Operation via apps: → Confirm/Allow .

Connect Infotainment to an external device via WLAN

» page 133

.

In the external device, launch an application for Infotainment operation (e.g.

ŠKODA Media Command).

97

Infotainment operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Applies to Infotainment Swing

Activate data transfer in Infotainment. Press the



 button and then tap on

the function surface Activate data transfer for ŠKODA apps.

Note

The description of Infotainment operation using ŠKODA Media Command is

part of the application.

Voice control

Introduction to the subject

Applies to Infotainment Amundsen.

The navigation, telephone, radio and media menus can be operated by voice

commands.
The voice control system can be used either by the driver or by the front pas-

senger.

Function requirements for voice control

Infotainment is switched on.
No telephone call is being made using a telephone connected to Infotain-

ment.
The parking aid is not active.

Requirements for optimum voice command recognition

The voice commands must only be issued when the

 symbol is displayed on

the Infotainment screen and the input tone has completely faded.

Speak at your normal volume without intonation and long pauses.

Avoid bad pronunciation.

Close the doors and windows in order to prevent environmental influences

from interfering with the function of the voice control.

You are advised to speak louder at higher speeds, so that the sound of your

voice is not drowned out by the increased ambient noise.

During voice control, limit additional noise in the vehicle, e.g. passengers talk-

ing at the same time.

WARNING

The emergency number should be dialled instructionly. Your voice commands

may not be recognised in such situations. The telephone connection may

not be established or the connection may take too much time to complete.

CAUTION

The messages are generated by Infotainment. Flawless clarity (e.g. road or

city name) cannot always be guaranteed.

For some Infotainment languages, voice control is not available. Infotainment

indicates this through a text message that is displayed on the screen after set-

ting the Infotainment language.

Note

During voice control, no navigation announcements and traffic announce-

ments are played.

Switching voice control on/off

Fig. 131

Voice control: Main menu

Switch on

Press the button  on the multifunction steering wheel or button



 on

the Infotainment system.

The main menu is displayed

» Fig. 131

.

Switch off

Press the button twice  on the multifunction steering wheel or button



on the Infotainment system.

or: Issue the voice command “End voice control”.

98

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Operation principle

Fig. 132

Example of screen display

The voice control main menu

» Fig. 131

 on page 98 contains basic voice com-

mands for the individual menus.
Other voice commands are displayed by tapping the respective function sur-

face, if required, by issuing the name of respective command (e.g. navigation).

The screen shows the following

» Fig. 132

.

Context-dependent:

 The system is waiting for a voice command

 The system recognises a voice command

 The system plays a message

 Voice command entry was stopped

Available list entries
Possible voice commands
Displaying other possible voice commands

Voice commands that can be issued are indicated in “quotation marks”.

Note

Depending on the equipment, the voice control symbols

A



» Fig. 132

 are also

displayed on the display of the instrument cluster.

A

B
C

Voice commands

Enter

The voice commands must only be issued when the

 symbol is displayed

on the Infotainment screen and the input tone has completely faded. The in-

put tone can be switched on/off. To do this, press



 and then tap on  →

Voice control.
It is not necessary to wait for the end of message playback when Infotainment

is playing a message. The Infotainment message can be terminated by pressing

the button



 or button  on the multifunction steering wheel. Then a voice

command can be issued. Voice control is much faster as a result.

Stop

This allows more time to enter the voice command (e.g. in the list of retrieved

contacts).
The process for entering voice commands can be stopped by moving a finger

up/down across the screen or by turning the controller  .
When stopping, the symbol changes from

 to .

Restore

The procedure for entering voice commands can be restarted in one of the fol-

lowing ways.

By tapping on the function surface .

By pressing the button



 on the Infotainment.

By pressing the button  on the multifunction steering wheel.

Not recognising a voice command

If a voice command is not recognised by the Infotainment system three times

in succession, then voice control is stopped.

Correction of a voice command input

A voice command can be corrected, modified or re-entered by pressing the

button



 or the button  on the multifunction steering wheel. However,

this is only possible as long as the

 symbol is displayed on the screen.

You do not have to wait until the voice command is recognised by Infotain-

ment.

99

Infotainment operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Voice commands can be used during voice control

Voice command

Function

Back

Return to the previous menu

Help

Reproduce and display possible voice commands

Voice commands that can be used while browsing the list entries

Voice command

Function

Next page

Browse menu/list/directory

Previous page
First page
Last page

Additional Information

Navigation

To the destination, you are first required to issue the command“enter ad-

dress” and then follow Infotainment instructions.
It is not necessary to spell city and street names if the entered destination is

located in a country that has no voice control available for the language.

Online POI search

When “Infotainment Online”

» page 17

 services are activated, a POI search can

also be carried out online by issuing the voice command “Find online POI”.

Radio

In order for a radio station can be selected using voice command, the station

must be stored in the list of available stations

» page 113

 or in the preset list

» page 114

.

Updating the Infotainment software

Fig. 133

Available software updates on

the ŠKODA websites

The software update ensures optimum operation of Infotainment (e.g. com-

patibility with new telephones).
Information on Infotainment compatibility can be found on the following

ŠKODA Internet pages. This is done by scanning the QR code

» Fig. 133

 or en-

tering the following address into the web browser.

http://go.skoda.eu/updateportal

Applies to Infotainment Amundsen

To determine the software version, press the



 button then tap the func-

tion surface  → System information.

To start the software update, press the



 button, then tap the function

surface  → System information → Update software.

Applies to Infotainment Swing

To determine the software version, press the



 button, then tap the Sys-

tem information function surface.

To start the software update, press the



 button, then tap the System in-

formation → Update software function surface.

100

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infotainment settings - Amundsen

Infotainment system settings

Sound settings

Press the



 button, then tap on function surface  .

Volume - Volume settings

Radio announcements - Volume adjustment of traffic announcements (TP)

Navigation announcements - Volume setting for navigation announcements

Voice control - Volume setting for voice output

Maximum switch-on volume - Set the maximum volume when switching on In-

fotainment

Speed dependent Speed-dep. vol.adjust. - Increases the volume as speed increa-

ses

Bluetooth audio: - Volume setting of the device connected via Bluetooth

®

 au-

dio profile of the connected external device

Quiet - Low volume

Medium - Medium volume

Loud - High volume

Entertainment fading while parking - Lowers the audio volume (e.g. radio volume)

when the parking aid is activated

Entertainment fading (Navigation) - Lowers the audio volume (e.g. radio volume)

in the event of a navigation announcement

Bass - Mid - Treble - Setting the equalizer

Balance - Fader - Sets the balance between left and right, front and rear

ŠKODA Surround - Switch surround sound on/off (cannot be used in Radio

mode)

Virtual Subwoofer -Switch virtual subwoofer on/off (cannot be used in Radio

mode)

Touchscreen tone - Switch audible tone when touching the screen on/off

No navigation announcements during calls - Switches the navigation prompts on or

off during a telephone conversation

Display settings

Press the



 button, then tap on function surface  Tap→ Screen.

Menu: Setting the Infotainment menu display

Horizont. Display - Horizontal display

» Fig. 130

 on page 97

Grid display - Grid display

» Fig. 129

 on page 96

Switch off screen (in 10 seconds) - Enable/disable the automatic power off func-

tion

Display clock when screen is off - Time and date display when the screen is

switched off

Brightness: - Adjusts the brightness of the screen

Touchscreen tone - Switch audible tone when touching the screen on/off

Animation when finger near screen - Switch the proximity sensors on/off (when

the function is on the bottom bar with function surfaces will be displayed e.g.

in the main Navigation menu when you move a finger towards the screen)

Show clock in standby mode - Time and date displayed on the screen when the

ignition is switched on and Infotainment is switched off

Time and date settings

Press the



 button, then tap on function surface  → Time and date.

Clock time source: Time source settings: manual/GPS (applies to Infotainment

Amundsen)

Time: - Time settings

Summer time - Switches summer time on/off

Automatic summer time - Switches the automatic switch to summer time on/off

Time zone: - Select the time zone

Time format: - Set the time format

Date: - Date settings

Date format: - Set the date format

Infotainment language settings

Press the



 button, then tap on function surface  → Language.

Select the Infotainment language.

In some languages, after selecting the function surface, Female or Male are dis-

played for the choice of Infotainment voice prompts.

Note

When a language is selected which does not support voice control, Infotain-

ment will indicate this with a message on the screen.

The messages are generated by Infotainment. Flawless clarity (e.g. road or

city name) cannot always be guaranteed.

101

Infotainment settings - Amundsen

-------------------------------------------------------------------------------------------------------------------------------------------------------------

More keypad languages settings

Press the



 button, then tap on function surface  → Additional keypad lan-

guages.

In this menu, a keyboard language set can be added to allow characters other

than those in the currently selected language to be entered.

Unit settings

Press the



 button, then tap on function surface  Tap on→ Units .

Distance: - Distance units

Speed: - Speed units

Temperature: - Temperature units

Volume: - Volume units

Fuel consumption: - Consumption units

Pressure: - Pressure units for tyre pressure

Settings for data transfer

Activated data transfer enables data transfer between the Infotainment sys-

tem and the external device or the operation of some Infotainment functions

using the applications of the external device (e.g. ŠKODA Media Command).

Press the



 button, then tap on function surface  → Mobile device data trans-

fer.

Activate data transfer for ŠKODA apps - Switch data transfer on and off

Use apps to operate: - Setting Infotainment operation via the applications of the

external device (applies to Infotainment Amundsen)

Deactivate - Deactivation of Infotainment operation via an external device

Confirm - Infotainment operation with required confirmation

Allow - Infotainment operation without required confirmation

Voice control settings

Press the



 button, then tap on function surface  → Voice control.

Example commands (Infotainment system) - Turn on/off display of the menu con-

taining voice commands in the Infotainment screen when voice control is ac-

tivated

Example commands (instrument cluster) - Turn on/off display of the menu contain-

ing basic voice commands when voice control is activated

Voice control session start tone - Activate/deactivate the audible signal when

turning on the voice control

Voice control session end tone - Activate/deactivate the audible signal when voice

control ends

Input tone in voice dialogue - Activate/deactivate the audible signal for the voice

input

End tone in voice dialogue - Activate/deactivate the audible signal for the voice

input

Safe removal of the external device

Press the



 button, then tap on function surface  Remove safely: and select

the external device to be removed.

Reset to factory settings

Press the



 button, then tap on function surface  → Factory settings.

In this menu, all or only selected settings can be restored.

Bluetooth

®

 settings

Press the



 button, then tap on function surface  → Bluetooth.

Bluetooth - Switch the Bluetooth

®

 function on/off

Visibility: Switch the visibility of the Bluetooth

®

 device for other Bluetooth

®

 de-

vices on/off

Name: - Changing the name of the Bluetooth

®

device

Paired devices - Display the list of paired Bluetooth

®

devices

Find devices - Search for available Bluetooth

®

 devices

Bluetooth audio (A2DP/AVRCP) - Activate/deactivate the ability to connect a

Bluetooth

®

 audio device (e.g. MP3 player, tablet etc...)

Wireless settings

Applies to Infotainment Amundsen.

Press the



 button, then tap on function surface  → WLAN.

102

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WLAN - List of available hotspots of external devices

WLAN - Switch Infotainment WLAN on/off

WPS quick connection (WPS button) - Establish a secure connection to the hot-

spot of the external device using WPS (applies to Infotainment Amundsen)

Manual settings - Parameter settings for searching and connecting to the hot-

spot of the external device

Network name - Enter the Hotspot name

Network key - Access passkey setting

Security level: Security setting (WPA2 always set)

Connect - Establish a connection

Find - Search / Restore the list of available hotspots

Mobile hotspot - Infotainment hotspot setting (the symbol  displayed with

the number of connected external devices)

Mobile hotspot - Switch the Infotainment hotspot on/off

WPS quick connection (WPS button) - Establish a secure connection to the Info-

tainment hotspot via WPS (applies to Amundsen)

Hotspot (WLAN) settings - Parameter settings for connection to the Infotain-

ment hotspot

Security level: Security setting (WPA2 always set)

Network key - Input of the access password

SSID: ... - Name of the infotainment Hotspots

Do not send network name (SSID) -Turn Infotainment hotspot visibility on/off

Store - Storage of the parameters set for the Infotainment hotspot

Network settings

Applies to infotainment Amundsen with the connected Carstick device.

Press the



 button, then tap on function surface  → Network.

Network settings - Sets the data connection from the associated telephone

service provider (APN settings)

Access point name: ... - Setting of the access point name

User name: ... - Setting of the user name

Password: ... - Password setting

Authentication: Sets the check type

Normal - Without verification

Safe - Verification required

Reset Access Point (APN) - Delete the parameters for the network setting

Store - Saves the parameters for the network setting

Network provider: ... - Selection of the network provider (the menu item is visi-

ble when the SIM card is inserted in the CarStick device)

Data roaming - Enable/disable the use of data roaming connection

Current connection details - Display of information on data downloaded (tap the

function surface Reset to delete the data information)

Data connection: - Usage settings for the data connection (Internet connection)

of the SIM card inserted in the CarStick device

Off - Use of the data connection is not possible

Ask - Use of the data connection is only possible after it has been confirmed

On - Use of the data connection is possible at any time

ŠKODA Connect Online Services settings

Press the



 button, then tap on function surface  → ŠKODA Connect (Online

Services).

Services Management - Information on licensing of the respective online serv-

ices and the option to switch them on/off

registration - Enter the registration PIN code for online services (in the user

profile on the website ŠKODA Connect Portal receive)

System information

Press the



 button, then tap on function surface  → System information.

The information available will be displayed, for example regarding the Infotain-

ment hardware and software, the Bluetooth

®

 software version, the navigation

database version, etc.

To Update the Infotainment software, Bluetooth

®

 software version, etc., tap

on the function surface Update software.

To Update the POI categories created in the user profile on the ŠKODA

Connect Portal website, tap on the function surface Online update.

The information on available software updates is obtained from a ŠKODA part-

ner or from the following ŠKODA Internet pages.

http://go.skoda.eu/updateportal

103

Infotainment settings - Amundsen

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Radio menu settings

Settings for all broadcasting ranges

In the main Radio menu, tap the function surface  .

Sound - sound settings

Scan - Automatic playback of short portions of all available stations in the

current frequency range

Arrow buttons: - Setting the function of the function surfaces  

Preset list - Change between stations stored under the preset buttons

Station list - Change between all available stations of the selected broadcast-

ing range

Traffic program (TP) - Switches TP traffic program on/off

Delete presets - Deletes the preset buttons

Station logos - Manual management of station logos

Radio text - Switches the radio text display (FM and DAB) on and off

Advanced settings - Other settings that are different depending on the selected

broadcasting range (FM and DAB)

Advanced settings (FM)

Select the FM band in the Radio main menu and tap on the function surface

 → Advanced settings.

Autostore station logos- Automatic storage of the station logos

Region for station logo: - Setting the region for station logo

Automatic frequency control (AF) - Activate/deactivate the search for alternative

frequencies of the station currently being played

Radio Data System (RDS) - enable/disable RDS function (receiving additional in-

formation from the station)

RDS Regional: Switch on/off automatic tracking of related regional stations

Fixed - Maintains the selected regional station continuously. When the sig-

nal is lost, another station must be set manually.

Automatic - Auto-selects the station with the best reception at the moment.

If you lose reception in the given the region, Infotainment will automatically

set another available region.

Advanced settings (DAB)

In the Radio main menu, select the DAB range and tap on the function sur-

face  → Advanced settings.

Autostore station logos- Automatic storage of the station logos

DAB traffic announcements - Switch DAB traffic announcements on/off

Other DAB messages - Switch other announcements on/off (e.g., warnings, re-

gional weather, sports reports, financial news)

DAB - DAB station tracking - Activate/deactivate automatic DAB station tracking

on another frequency or in other station groups

Automatic DAB - FM switching - Activate/deactivate auto-switching from DAB to

the FM broadcasting range if the DAB signal is lost

Automatic change from DAB to FM

In the event of bad DAB reception, the device tries to find an FM station.
The station name is followed by () while the station is being received on the

FM band. When the corresponding DAB station is received again, the system

automatically switches from FM to DAB.
If a DAB station is also not available in the FM band due to poor reception, In-

fotainment will be switched to mute.

Media menu settings

In the main Media menu, tap function surface  .

Sound - Sound settings

Mix/repeat including subfolders - Activate/deactivate the title display including

subfolders

Bluetooth - Settings for the Bluetooth

®

 function

WLAN - WLAN settings (applies to Infotainment Amundsen)

Remove safely: - Safe removal of the external device

Traffic program (TP) - Switches the traffic program on/off

Image menu settings

In the main Images menu, tap on function surface  .

Image view: - Image view settings

Full - Display the maximum image size while retaining the aspect ratio

Automatic - Full screen display

Display time: - Set the display time for the slideshow

Repeat slideshow - Switching the slideshow repeat on/off

104

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Telephone menu settings

In the main Telephone menu, tap the function surface  .

Hands-free telephone - Switching a call to the phone/back to Infotainment (the

menu item is displayed during a call)

Select mobile phone - Search for available telephones/list of paired tele-

phones/select telephone

Bluetooth - Bluetooth

®

 settings

» page 102

User profile - User profile settings

Manage favourites - Set the function surfaces for your favourite contacts

Mailbox number: - Enter the mailbox phone number

Sort by: - Arrangement of telephone contact list

Surname - Sort by contact name

Forename - Sort by contact's first name

Import contacts: - Import telephone contacts

Select ring tone - Select the ring tone (depending on the connected tele-

phone)

Reminder: Remember your mobile - Turn on/off the warning mode before forget-

ting the phone in the vehicle (if the phone was connected to the device)

Show pictures for contacts - Activate/deactivate the display of the images as-

signed to the contacts

Conference call - Activate/deactivate conference calls

Network - Set the telephone service provider network of the SIM card inser-

ted in the CarStick device (applies to Infotainment Amundsen)

» page 103

SmartLink+ menu settings

In the main SmartLink menu, tap on function surface  .

Activate data transfer for ŠKODA apps- Activate/deactivate data transfer for

ŠKODA applications

MirrorLink® - Settings of the system MirrorLink

®

Allow MirrorLink® notification to be shown - Turn the display of Mirror link

®

 appli-

cation messages on the Infotainment screen on/off

Navigation menu settings

Route options

In the main Navigation menu, tap the function surface  → Route options.

Suggest 3 alternative routes - Switch the menu for alternative routes on/off (eco-

nomical, fast, short)

Route: - Setting the preferred route

Most frequent routes - Show/hide the menu of the most frequent routes in the

split screen

Dynamic route - Switch on/off dynamic route recalculation due to TMC traffic

reports or online traffic reports

 Avoid motorways - Activate/deactivate the non-use of motorways in the

route calculation

 Avoid ferries and motorail trains - Activate/deactivate the non-use of ferries

and motorail trains in the route calculation

 Avoid toll roads - Activate/deactivate the use of toll roads for route calcula-

tion

 Avoid tunnels - Switch on/off use of tunnels for route calculation

 Avoid routes requiring toll stickers - Activate/deactivate the use of routes re-

quiring toll stickers on/off for route calculation

Show available toll stickers - Selection of countries for which a valid toll sticker

is required (routes requiring toll stickers are used for route calculation)

 Include trailer - Turn on / off the setting to take a trailer into account for

route calculation

» page 152

Map

In the main Navigation menu, tap the function surface  → Map.

Show road signs - Switch the display of traffic signs on/off

Lane guidance - Activate/deactivate the display of lane guidance

Show favourites - Activate/deactivate the display of favourites

Show POIs - Activate/deactivate the display of POIs

Select categories for POIs - Select the categories of displayed POIs

Show brand logos for POIs - Activate/deactivate the company logos available

for the POIs shown

Traffic flow settings - Setting for the display of a traffic obstruction received

from online traffic

Display free-moving traffic - Activate/deactivate the display of routes with

free-moving traffic

Display congestion - Activate/deactivate the display of routes with heavy traf-

fic

Display traffic events (symbols on map) - Activate/deactivate the display of

routes with a traffic incident

105

Infotainment settings - Amundsen

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Manage memory

In the main Navigation menu, tap the function surface  → Manage memory.

Sort contacts: - Setting the configuration of the phone book

By surname - Sorting by the contact surname

By Forename - Sorting by the contact first name

Define home address - Enter the home address

Delete "My POIs" - Delete your own POI categories (Personal POI)

Update "My POIs" (SD/USB) - Import/update your own POI categories (Personal

POI)

Retrieve "My POIs" (online) - Online import/update of your own POI categories

created in the user profile on the ŠKODA Connect Portal website

Import destinations (SD/USB) - Import destinations in vCard format

Delete user data - Delete user data (by tapping function surface Delete and con-

firming the deletion)

Last destinations - Delete the last destinations

Dest. memory - Delete the stored destinations

Online destinations - Delete the stored online destinations

Routes - Delete saved routes

My points of interest (Personal POI) - Delete the custom POIs

Entered cities - Delete the history of places already entered via the address

Home address - Delete the stored home address

Flagged destination - Delete the flagged destination

Most frequent routes - Delete the most travelled routes

Navigation announcements

In the main Navigation menu, tap the function surface  → Navigation announce-

ments.

Volume - Volume control of the navigation announcements

Entertainment fading (Navigation) - Adjust the fading of the audio volume (e.g. ra-

dio volume) when navigation announcements are being made

No navigation announcements during calls - Activate/deactivate non-playback of

navigation announcements during a telephone call

Note:“My POIs” - Activate/deactivate an audible indication when approaching a

custom POI (if supported by the imported custom POI)

Speed limits

In the main Navigation menu, tap the function surface  → Speed limits.

The maximum speed limits for the current country are displayed.
When the function is switched on Note:National border crossed

» page 106

Ad-

vanced settings, display the country-specific speed limits when crossing inter-

national borders.

Fuel options

In the main Navigation menu, tap the function surface  → Fuel options.

Select preferred fuel station - Select your preferred fuel station brand (the selec-

ted station brand will be displayed in the first three positions of the list)

Fuel warning – Activate/deactivate the display of a warning message with the

option to search for the nearest petrol station when the fuel level reaches

the reserve area

Version information

In the main Navigation menu, tap the function surface  → Version information .

A list of countries is displayed that exist for the navigation data, together with

the date of the last update.
The navigation data can be updated by tapping on the Update function surface

(SD/USB) or Online update.

The information on updating the navigation data can be obtained from a

ŠKODA partner or on the following ŠKODA websites.

http://go.skoda.eu/updateportal

Advanced settings

In the main Navigation menu, tap the function surface  → Advanced settings.

Time display: - Select the time display in the status line

 - Estimated arrival time at destination

 Estimated travelling time to the destination

Status line: - Selection of the destination type, for which the status line, the

route and travel time are displayed (this also determines which destination

type is displayed on the map after selecting  →  is displayed on the map)

 - Route destination

 - Next waypoint

Note:National border crossed - Switching the display of information on country-

specific speed limits when crossing a national border on/off

106

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Demo mode - Activate/deactivate guidance in demo mode

Define demo mode starting point - Specify the start point of the route guidance

in demo mode by entering the address or the current vehicle position

Infotainment settings – Swing

Infotainment system settings

Sound settings

Press the



 or



 button, then tap the function surface Sound.

Volume - Volume settings

Maximum switch-on volume - Set the maximum volume when switching on In-

fotainment

Announcements - Adjustment of traffic announcements volume (TP)

Speed-dep. vol.adjust. - Volume increases as speed increases

Entertainment fading - Lowers the audio volume (e.g. radio volume) with acti-

vated parking aid

Entertainment fading (Navigation) - Reduction of audio volume (e.g. radio vol-

ume) for navigation announcements originating from the SmartLink appli-

cation

Bluetooth audio: - Volume setting of the device connected via Bluetooth

®

 au-

dio profile

Balance - Fader - Sets the balance between left and right, front and rear

Bass - Mid - Treble - Setting the equalizer

Touchscreen tone - Activates/deactivates the acoustic tone when touching the

screen

ŠKODA Surround - Switch surround sound on/off (cannot be used in Radio

mode)

Virtual Subwoofer -Switch virtual subwoofer on/off (cannot be used in Radio

mode)

Display settings

Press the



 button, then tap the function surface Screen.

Switch off screen (in 10 seconds) - Enable/disable the automatic power off func-

tion

Display clock when screen is off - Time and date display when the screen is

switched off

Brightness: - Adjusts the brightness of the screen

Touchscreen tone - Switch audible tone when touching the screen on/off

Show clock in standby mode - Time and date displayed on the screen when the

ignition is switched on and Infotainment is switched off

107

Infotainment settings – Swing

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     4      5      6      7     ..
