Skoda Karoq (2019 year). Instruction - part 3





The seat belt for the driver and front passenger needs to be replaced.

Seek help from a specialist garage.

WARNING

When a fault in the airbag system occurs, there is a risk of the system not

being triggered in the event of an accident. Therefore, this must be

checked immediately by a specialized garage.

Tyre pressure

Read and observe   on page 42 first.

Change of tyre pressure values

 illuminates - there was a pressure change in one of the tyres.

Immediately reduce speed and avoid sudden steering and braking manoeu-

vres.

Stop the vehicle, turn the ignition off and check the tyres and their inflation

pressures

» page 275

.

Correct the tyre pressure if necessary or replace the affected wheel

» page 279

 or use the repair kit

» page 283

.

Save the tyre pressure values in the system

» page 251

.

System fault

 flashes for approximately 1 minute and remains lit – there may be a fault in

the tyre pressure monitoring system.

Stop the vehicle, turn the ignition off and start the engine again.

If the warning light

 flashes after starting the engine again, there is a system

error.

It is possible to continue driving with due caution. Seek assistance from a

specialist garage immediately.

Disconnecting the vehicle battery

If the vehicle's battery has been disconnected and reconnected, the indicator

light

 comes on after switching on the ignition.

The warning light should go out after driving a short distance.
If, after a short drive, the indicator light does not go out, there is a system er-

ror.

It is possible to continue driving with due caution. Seek assistance from a

specialist garage immediately.

Other incidents

The illumination of the warning light

 can have the following reasons.

The vehicle is loaded on one side. Distribute the load evenly.

The wheels of one axle are loaded more heavily (e.g. when towing a trailer or

when driving uphill or downhill).

Snow chains are mounted.

A wheel has been changed.

CAUTION

Under certain circumstances (e.g. sporty style of driving, wintry or unpaved

roads) the warning light

 can be delayed or does not light up at all.

 Brake linings

Read and observe   on page 42 first.

 illuminates - the brake pads are worn.

It is possible to continue driving with due caution. Seek assistance from a

specialist garage immediately.

 Fuel reserve

Read and observe   on page 42 first.

 illuminates – the fuel level in the fuel tank is at the reserve level (approxi-

mately 6 litres).

Fill up with fuel

» page 263

.

Note

The text in the display goes out after refuelling and driving a short distance.



 Turn signal system

Read and observe   on page 42 first.

 flashes - the left turn signal is switched on.

 flashes – the right turn signal is turned on.

45

Instruments and warning lights

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If there is a fault in the turn signal system, the warning light flashes at twice its

normal rate (does not apply when towing).
When the hazard warning light system is switched on, this will cause all of the

turn signal lights as well as both warning lights to flash.

 Trailer turn signal lights

Read and observe   on page 42 first.

 flashes - the trailer turn signals are switched on.

If a trailer is hitched and the warning light

 is not flashing, one of the trailer

turn signal lights has failed.

Check the trailer bulbs.

 Fog lights

Read and observe   on page 42 first.

 illuminates - the fog lights are switched on.

 Speed regulating system/speed limiter

Read and observe   on page 42 first.

 illuminates - the vehicle speed is limited by the speed regulating system

and/or the adaptive cruise control or by the speed limiter.

 flashes - the speed set with the speed limiter has been exceeded.

 Brake pedal (automatic gearbox)

Read and observe   on page 42 first.

 lights up – apply the brake.

 Auto Hold function

Read and observe   on page 42 first.

 illuminates - the Auto Hold function is activated.

For more information about the Auto-Hold Function

» page 207

.

 Main beam

Read and observe   on page 42 first.

 illuminates - the main beam or headlight flasher is switched on.

 Automatic gearbox

Read and observe   on page 42 first.

Gearbox overheated



 illuminates

Message: Gearbox overheated. You can drive on.

Transmission overheated. You can drive on, exercising appropriate caution.



 illuminates

Message: Gearbox overheated. Stop! Log book!

 Do not continue to drive! Stop the vehicle and turn off the engine.

You can continue your journey as soon as the warning light disappears.

If the warning light does not go off,

 stop driving! Seek help from a special-

ist garage.

Transmission problem



 illuminates

Message: Gearbox faulty. Stop the vehicle safely!



 illuminates

Message:

Gearbox in emergency mode. No reverse gear.

Error: gearbox. Speed is limited.

It is possible to continue driving with due caution. Seek assistance from a

specialist garage immediately.

 Rear seat belt warning light

Read and observe   on page 42 first.

 illuminates – a rear seat belt is not fastened.

 illuminates - a rear seat belt is fastened.

46

Operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

When the seat belt is fastened/unfastened, the particular light lights up briefly

and indicates the current belt status!

 Generator

Read and observe   on page 42 first.

 illuminates - the battery is not being charged while the engine is running.

CAUTION

If in addition to the light  the light  lights up while driving,

 stop driving -

There is a risk of engine damage! Switch off the engine and seek assistance

from a specialist garage.

 Coolant

Read and observe   on page 42 first.

Coolant level too low



 illuminates

Message: Please check the coolant level. Log book!

Stop the vehicle, switch off the engine and let it cool.

Check the coolant level

» page 270

.

If the coolant level is within the specified range and the warning light  lights

up again, then there may be a malfunction of the cooling fan.

Switch off the ignition.

Check the fuse for the radiator fan, replace if necessary.

If the coolant level and fan fuse are both OK but the warning lightlights up

again,

 stop driving!

Seek help from a specialist garage.

Coolant temperature too high



 illuminates

Message: Engine overheat. Stop! Observe log book.

Stop the vehicle, switch off the engine and let it cool.

Continue your journey only after the warning light  has disappeared.

 Engine oil pressure

Read and observe   on page 42 first.



 flashes - the engine oil pressure is too low.

Stop the vehicle, switch off the engine, and check the engine oil level.

Even if the oil level is correct,

 do not drive any further if the warning light

is flashing! Also do not leave the engine running at an idling speed.

Seek help from a specialist garage.

CAUTION

If it is not possible to top up with engine oil,

 stop driving - there is a risk of

engine damage! Switch off the engine and seek assistance from a specialist

garage.

 Engine oil level

Read and observe   on page 42 first.

Engine oil level too low



 illuminates

Message: Please add engine oil.

Stop the vehicle, switch off the engine, and check the engine oil level, top up

if necessary.

The warning light will go out if the bonnet is left open for more than 30 sec-

onds. If the engine oil is not replenished, the warning light will come on again

after driving about 100 km.

Engine oil level too high



 illuminates

Message: Please reduce oil level.

Stop the vehicle, switch off the engine, and check the engine oil level.

In the event of an oil level which is too high, you can drive on, exercising ap-

propriate caution. Seek assistance from a specialist garage immediately.

Fault on the engine oil level sensor



 illuminates

Message: Oil sensor: please visit workshop.

47

Instruments and warning lights

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Immediately drive to the nearest specialist garage with appropriate caution.

CAUTION

If it is not possible to top up with engine oil,

 stop driving - there is a risk of

engine damage! Switch off the engine and seek assistance from a specialist

garage.

 AdBlue

®

level II low (diesel engine)

Read and observe   on page 42 first.

 Illuminates - AdBlue

®

level too low.

Replenish Add AdBlue

®



» page 265

.

 AdBlue

®

 error (diesel engine)

Read and observe   on page 42 first.

 illuminates – there is a fault in the AdBlue

®

 system.

Seek help from a specialist garage.

 Lamp failure

Read and observe   on page 42 first.



 illuminates - one of the lamps is faulty.

A message will appear in the display about the affected lamp.

 Display when the light is switched off

Read and observe   on page 42 first.

Applies to vehicles with the digital instrument cluster.

 lit - no light is on.

Message: Please turn on the light.

 Particulate filter

Read and observe   on page 42 first.

The particulate filter separates and burns the soot particles from the exhaust.



 illuminates - the filter is clogged with soot.

To clean the filter, if allowed by the traffic conditions

»

, you should drive at a

speed between 50-120 km/h in the recommended gear.
If the filter is properly cleaned, the warning light  extinguishes.
If the indicator light  does not go out within 30 minutes, the filter was not

cleaned.

Immediately drive to the nearest specialist garage with appropriate caution.

WARNING

Always adjust the speed and driving style to the actual weather, road, ter-

rain and traffic conditions.

The particulate filter reaches very high temperatures - there is a fire haz-

ard and serious injury could be caused. Therefore, never stop the vehicle at

places where the underside of your vehicle can come into contact with

flammable materials, such as dry grass, undergrowth, leaves, spilled fuel or

the like.

CAUTION

As long as the warning light  illuminates, one must take into account an

increased fuel consumption and a power reduction of the engine.

As long as the indicator light  is lit, the START-STOPfunction is not availa-

ble.

Note

We encourage you to avoid constant short journeys. This supports the correct

function of the particulate filter.

 Windscreen washer fluid level

Read and observe   on page 42 first.



 illuminates - the windscreen washer fluid level is too low.

Top up the windscreen washer fluid

» page 269

.

 High-beam assistant

Read and observe   on page 42 first.

 illuminates - the high beam assistant is activated

» page 74

Light Assist.

48

Operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Display of a low temperature

Read and observe   on page 42 first.

 illuminates - the outside temperature is below +4 °C.

WARNING

Even at temperatures around +4 °C, black ice may still be on the road sur-

face! Do not only rely upon the information given on the outside tempera-

ture display that there is no ice on the road.

 Water in the fuel filter (diesel engine)

Read and observe   on page 42 first.

The fuel filter with water separator, filters out dirt and water from the fuel.
If too much water is present in the separator, the following information ap-

pears on the instrument cluster display.



 illuminates

Message: Water in fuel filter. Log book!

It is possible to continue driving with due caution. Seek assistance from a

specialist garage immediately.

Front Assist

Read and observe   on page 42 first.

 illuminates – the safe distance to the vehicle in front is below the mini-

mum.
Information on the Front Assist system

» page 240

.

 front Assist

Read and observe   on page 42 first.



 illuminates

Front Assist has recognised the risk of a collision or automatically triggered

an emergency braking manoeuvre

» page 240

.

An automatic deactivation of Front Assist took place when activating ESC

Sport

» page 215

 and when deactivating the ASR

» page 216

.

Front Assist is not available

» page 242

.

 Illuminates with the lettering 

 - Front Assist is deactivated

» page 242

.

 emergency call

Read and observe   on page 42 first.



 lights up – there is a fault in the emergency call system.

Seek help from a specialist garage.

 Economy mode

Read and observe   on page 42 first.

 illuminates - the vehicle is in economy mode due to the intervention of the

active cylinder management or due to the neutral position of the automatic

gearbox.

  Offroad mode

Read and observe   on page 42 first.

 illuminates - the Offroad mode is enabled.

 illuminates - the hill descent assistant is activated.

 flashes (stronger) – the hill descent assistant is engaged at the moment.

 Adaptive chassis (DCC)

Read and observe   on page 42 first.



 illuminates – there is a DCC fault.

49

Instruments and warning lights

-------------------------------------------------------------------------------------------------------------------------------------------------------------

It is possible to continue driving with due caution. Seek assistance from a

specialist garage immediately.

 Service

Read and observe   on page 42 first.

 illuminates – note regarding a due service appointment

» page 57

Display-

ing the distance and days until the next service interval.

Information system

Driver information system

Display in the instrument cluster

Fig. 38

Display overview

Depending on the vehicle's equipment, the information system uses the dis-

play in the instrument cluster to provide the following information

» Fig. 38

.

Time / symbols of the Infotainment voice control
Engaged gear / gear recommendation

Selector lever positions for the automatic gearbox

START STOP system indicator lights

Compass display

Detected traffic signs
Driving data (multifunction display)

Warning lights

Information messages

Door alarm

Eco tips

Service interval display
Outside temperature
Cruise control / speed limiter

Total distance travelled
Distance travelled by resetting the memory (trip)

Door, luggage compartment and bonnet alarm

When the door or luggage compartment / bonnet is open, a graphic warning

appears in the display.

1

2

3

4
5

6

50

Operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

An acoustic signal will also sound if you drive the vehicle above 6 km/h when a

door is open.

Reset counter for distance travelled (trip)

The counter can be reset by tapping button

A



» Fig. 39

 on page 51 or Info-

tainment in the



/  →  → Instrument cluster menu.

Setting the time

Fig. 39

Button in the instrument cluster

The time can be set in Infotainment in the



 →  → time and date menu or

with the button in the instrument cluster.

Set the time using the button in the instrument cluster

Switch on the ignition.

Press and hold the button

A



» Fig. 39

until thetime is shown in the display.

Release the button

A

 and the system switches to the hour setting function.

Press the button

A

 again and set the hours.

Wait 4 seconds, the system switches to the minutes setting.

Press the button

A

 again and set the minutes.

Wait 4 seconds, the system switches to the initial setting.

Gear recommendation

Fig. 40

Information on the selected

gear / Gear recommendation

A suitable engaged gear or, where appropriate, a recommended gear is dis-

played, with the aim of conserving the life of the engine and increasing driving

efficiency.
Display

» Fig. 40

Optimal gear engaged
Gear recommendation (e.g.    means that it is advantageous to switch

from 3rd to 4th gear)

For vehicles with automatic transmission the recommended gear will be

shown provided the mode for manual switching (Tiptronic) is selected.

WARNING

The driver is always responsible for selecting the correct gear in different

driving situations, such as overtaking.

Vehicle condition

Fig. 41

Vehicle condition

Certain functions and conditions of individual vehicle systems are checked

continuously when the ignition is switched on. If there is a fault in the system,

the following message will appear in the display of the instrument cluster.
While the operational faults remain unrectified, the messages are always indi-

cated again. After the message is displayed for the first time, the warning

lights

 (danger) or

 (warning) continue to be displayed.

The vehicle condition can be displayed in Infotainment in the menu



/  →

 → Vehicle status.

In the screen, information regarding vehicle condition or function of the tyre

pressure monitor is displayed.

Using the function surfaces  select the menu item Vehicle status.

51

Information system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Function surfaces and screen display

» Fig. 41

A

Vehicle representation (the zones of the vehicle are shown in different

colours, corresponding to any warning messages that occur. The warn-

ing messages are displayed once you touch the “vehicle”)



No message/warning messages relating to vehicle status and the num-

ber (if there is only one message, one warning message text is dis-

played)

Display information about the status of the START-STOP system





Activation / deactivation of notes relating to START-STOP-Sys-

tem messages in another screen display

Operation of the information system

Operation using the control lever

Fig. 42

Buttons on the operating lever

Operating the multifunction display

Press (up or down) - select data / set values
Press - display / confirm indication

Operation of the display menus

Press (up or down) - move to the selected menu

Hold (up or down) - display main menu
Press - confirm selected menu item

A
B

A

B

Operation using the multifunctional steering wheel

Fig. 43  Buttons/dials on the multifunction steering wheel

Buttons/dials on the multifunction steering wheel

Switch on/off voice control
Turn - sets the volume

Press - sound on / off
Skip to next track/station
Switch to previous track/station
Display the assistance systems menu

Depending on equipment:

Operating a digital instrument cluster

» page 40

Show previous menu (if one has been selected) / display Telephone

menu

Operating the multifunction display

Turn - select data / set values

Press - display / confirm indication

Operation of the display menus

Hold - display main menu

Press - return to a previous level in the menu
Turn - move in the selected menu

Press - confirm selected menu item

A



B

B

52

Operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving data (Multifunction display)

Introduction

The driving data display is only possible with the ignition switched on.
The units can be adjusted in Infotainment in the menu



/  →  → Units.

The journey data can be set/reset in Infotainment in the menu



/  →  →

Instrument cluster.

Note

The setting of the information display is stored in the active user account per-

sonalisation

» page 57

.

Information Overview

Overview of driving data (depending on the vehicle equipment).
Range - drive distance in km which can be covered with the existing tank ca-

pacity and with the same driving style. If you drive more efficiently this value

can increase.
AdBlue

®

 range - drive distance in km which can be covered with the existing

AdBlue

®

tank capacity and with the same driving style. If you drive more effi-

ciently this value can increase. When the system detects that AdBlue

®

 can be

refilled, an indication of the minimum and maximum AdBlue

®

 refilling quantity

appears.
Average fuel consumption - is calculated continuously since the last time the

memory was deleted. After erasing the memory, no data will appear for the

first 100 m driven.
Current fuel consumption - when the vehicle is stationary or slowly moving,

the fuel consumption is displayed in l/h (--,- km/l appears on models for some

countries).
Oil temperature - if the temperature is lower than 50 °C or if there is a fault in

the system for checking the oil temperature, the  symbols are displayed.
Warning when the preset speed is exceeded - allows the setting of a speed

limit where, if exceeded, an acoustic warning signal and a warning message ap-

pears on the display of the instrument cluster.

Dynamic Road Sign Display - traffic signs display

» page 248

Traffic sign rec-

ognition.
Current speed - digital speedometer.
Average speed - is calculated continuously since the last time the memory

was deleted. After erasing the memory, no data will appear for the first 300 m

driven.
Driving route - distance driven since the last time the memory was deleted.
Driving time - driving time since the last time the memory was deleted.
Conv. consumers - information about the total consumption of the comfort

consumers in l/h and a list of three consumers (e.g. air conditioning etc.), which

have the largest share of fuel consumption.

Infotainment display

Fig. 44

Driving data

In the Infotainment system, in menu



/  tap on function surface  →

Tap Journey data.

Screen display

» Fig. 44

Distance travelled
Driving time
Average speed
Average fuel consumption
Transit point rating (DriveGreenFunction)
Graphic fuel level display (if the estimated range is less than 300 km, the

vehicle starts to approach the symbol )
Approximate range

A
B
C
D

E
F

G

53

Information system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Use the function surfaces   to select one of the following presets.

Since start - Driving data for the individual trip

Long-term - Long-term driving data

Since refuel - Data since refuelling

Warning when exceeding the set speed

The system offers the possibility to set a speed limit beyond which an acoustic

warning signal will sound and the following warning message appears in the

display of the instrument cluster.

Adjust the speed limit while the vehicle is stationary

Select the menu item Warning at and confirm.

Set the desired speed limit is 5 km/h steps.

Confirm the set value, or wait several seconds; your settings will be saved

automatically.

Adjusting the speed limit while the vehicle is moving

Select the menu item Warning at and confirm.

Drive at the desired speed.

Confirm the current speed as the speed limit.

The set speed limit can be manually adjusted later if needed.

Reset the speed limit

Select the menu item Warning at and confirm.

By confirming the stored value, the speed limit is reset.

The speed limit set mode is stored even after the ignition is switched off and

on. After a gap between driving exceeding 2 hours, the pre-set speed limit is

deactivated.

Memory

Fig. 45

Memory display

The system saves the data in the three memories described below which are

displayed at the position

A

» Fig. 45

.

Since start

In the memory, driving data is saved for the time between switching on and

switching off the ignition. New data will also flow into the calculation of the

current driving information if the trip is continued within 2 hours after switch-

ing off the ignition.
If the trip is interrupted for more than 2 hours, the memory is automatically

erased.

Long-term

The memory gathers driving data from any number of individual journeys up to

a total of 99 hours and 59 minutes driving time or 9999 kilometres driven.
The indicator is automatically set back to zero if one of the indicated values is

exceeded.

Since refuel

The driving data is stored in the memory since the last fuel refuelling.
The memory is erased automatically the next time you fill up.

For the Storage choice, repeatedly confirm the selected indication and se-

lect the desired memory.

For Deleting the memory for the selected information, hold down the but-

ton confirming the specification.

The following driving data are stored.

Average fuel consumption

Distance travelled

Average speed

Driving time

Note

Disconnecting the vehicle battery will delete all memory data.

54

Operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Menus in the display of the instrument cluster

Introduction

The instrument cluster display is a user interface which, depending on the

equipment configuration, provides information about the Infotainment, the

multifunction display, the assistance systems etc.
The menus with details can be operated and displayed using the buttons on

the operating lever or the multifunction steering wheel

» page 52

.

Main menu items (depending on vehicle equipment)

Journey data

» page 53

Assist systems

» page 56

Navigation

» page 55

Audio

» page 55

Telephone

» page 55

;

Vehicle

» page 51

Lap timer

» page 56

Note

If warning messages are displayed, these messages must first be confirmed

to access the main menu.

The display language can also be set in Infotainment

» page 136

Setting the

Infotainment language and

» page 143

Setting the Infotainment language.

Navigation menu item

The following information is displayed in the Navigation menu item.

Driving recommendations

Compass

Last destinations

Navigation map (applies to digital instrument cluster)

audio menu item

E.g. the following information is displayed in the Audio menu item.

Radio

Currently playing station (name/frequency).

The selected frequency range (e.g. FM) optionally with the number of the

station button (e.g. FM3), if the station is stored in the memory list.

List of available stations (if more than 5 stations can be received).

TP traffic announcements.

Media

Name of the track being played, if necessary, further information regarding

title (e.g. artist, album name), if this information is stored as a so called ID3

tag on the audio source.

Telephone menu item

The call list with the following symbols is displayed in the Telephone menu item.

Incoming call
Outgoing call
Missed call

Symbols in the display

Telephone battery charge (this function is only supported by some mobile

phones)

Signal strength (this function is only supported by some mobile phones)

A telephone connected to the Infotainment system
Missed calls (if there are several missed calls, the number of calls is shown

next to the symbol)
Switch-off microphone

Apple CarPlay

An external device connected to the Infotainment system via Apple CarPlay

can be operated via the multifunction steering wheel as well as via menus in

the instrument cluster display.
The following symbols are displayed in the Telephone menu option.

Answer the incoming call
Reject incoming call / end call
Activate / deactivate microphone (applies for the infotainment Swing)



55

Information system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Assist systems menu item

The following systems are activated/deactivated in the Assist systems menu

item.

Lane Assist

ACC (vehicle with speed limiter)

Cruise control system (vehicle with speed limiter)

Speed limiter

Front Assist

Assist system for blind spot monitoring

Rear Traffic Alert

menu item Laptimer (Stopwatch)

The Lap timer function offers the possibility of calculating the lap time, for ex-

ample when driving on a race course. The measured time is shown in the dis-

play.
The following functions are available.

Start time - start the timing manually or continue the interrupted measure-

ment

Since start - Start the timer automatically upon start-up

Statistics - Evaluate and reset the measured times

Time measurement

To start the measurement manually, choose the menu item Lap timer - start .

To start the measurement automatically, choose the menu item Lap timer -

Since Start . Timing will begin automatically when starting up.

To start the measurement of the next lap during time measurement, choose

the menu item new lap.

During timing, information about the fastest and the last lap time are also

shown in the display.

Measure split time

During the timing, select the menu item Split time. The split time data is dis-

played for 5 seconds in the display.

Stop measurement

During the timing, press the menu item Stop.

The time measurement is stopped, the following functions are now available.

Continue - Continue measurement of the current lap time

New lap - Start measurement of the next lap time.

Abort lap - Cancel the timer (the current lap time is not stored)

Hang up - End timing (the current lap time is stored)

Evaluate recorded times

Select the menu item Lap timer - Statistics.

The following information is displayed.

Fastest: - The fastest lap

Slowest: - The slowest lap

Average: - The average lap time

Overall time: - The total of all the lap times

Reset measured times

Select the menu item Lap timer - Statistics - Reset.

WARNING

Concentrate fully at all times on your driving! As the driver, you are fully

responsible for the operation of your vehicle.

Only use the Lap timer when you are in any traffic situation where you have

full control over the vehicle.

Note

If the measured times are not reset, then these are stored even after turning

off the ignition.

Service intervals

Introduction

Compliance with the service intervals is of crucial importance for the serv-

ice life and value retention of the vehicle. Never exceed the service date.
The specialist garage will inform you about the type of service interval, the op-

tion to change it, and the service scope.
The service interval display in the display of the instrument cluster will notify

you when a service is due.

56

Operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Proof of service

A specialist garage will confirm the corresponding service record in the service

information system called Digital Service Plan.
We recommend that you always print out the respective service record.

Note

The customer is responsible for covering the cost of all services including

changing or replenishing the oil, even during the warranty period, unless stated

otherwise in the ŠKODA AUTO warranty terms or other binding agreements.

Displaying the distance and days until the next service interval

Fig. 46

Button in the instrument cluster

The details regarding the remaining kilometres or days until the next scheduled

service can be displayed in Infotainment in the menu



/  →  → Events or

with the button in the instrument cluster.

Use the key to display

Switch on the ignition.

Press and hold the button

A



» Fig. 46

 until theService menu item is shown in

the display.

Release the button

A

.

In the display, the symbol  appears for 4 seconds along with the following

message for the kilometres or days to the next service appointment.

Service messages

Before the next service date has been reached, the symbol  as well as a

message about the mileage or days until the next service event appears in the

display after the ignition is switched on.

Once the service interval is reached, the symbol  appears in the display after

the ignition is switched on, together with the message.

Reset service interval display

Have the display reset by a specialist garage.

We recommend that you do not reset the service interval display yourself. In-

correctly setting the service interval display can cause problems to the vehicle.

Variable service interval

For vehicles with variable service intervals, after resetting the oil change serv-

ice display in a specialist garage, the values of the new service interval are dis-

played, which are based on the previous operating conditions of the vehicle.
These values are then continuously matched according to the actual operating

conditions of the vehicle.

Personalization

Introduction

Thanks to the personalisation, more drivers have the opportunity to use a vehi-

cle with individually set system functions by means of a user account which is

assigned to the respective vehicle key.

WARNING

Make all adjustments when the vehicle is stationary - otherwise there is the

risk of accident!

57

Information system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Operating principle

Fig. 47

Switch to a different user account

Read and observe   on page 57 first.

After unlocking the vehicle and opening the driver's door, all the personalised

functions are adjusted according to the user account that is assigned to the

key which was used to unlock the vehicle.
Any change to the set personalised functions is automatically stored in the ac-

tive user account.
As part of the personalisation, three default user accounts as well as a

Guestaccount are provided.

Switch to a different user account

You can switch to a different user account in the instrument cluster display

» Fig. 47

 within 10 seconds after turning on the ignition.

An account can be changed at a later time in Infotainment in the menu



/ 

→  →Vehicle status →  (if the Tyre Pressure Monitoring System is displayed first of

all, then use the arrow  or  switch to Vehicle status).
If an account is selected in which not all of the points required by the system

are set, a configuration wizard can be automatically displayed on the Infotain-

ment screen

» page 131

.

Electrically adjustable driver's seat (referred to only as seat in the

following)

The seated position adjustment is carried out in the following cases.

After unlocking the vehicle and opening the driver's door (in this case: before

the vehicle was locked, an account with a certain seat setting was selected.

After vehicle unlocking, an account is activated to which a different seat set-

ting is assigned).

After switching to a different user account and at a speed less than 5 km/h.

The seat adjustment can be terminated as follows.

By tapping on the function surface Cancel on the Infotainment screen.

By pressing any key on the seat

» page 84

.

Note

Vehicles with the personalisation function are provided with three vehicle

keys.

Overview of some personalized functions

Read and observe   on page 57 first.

Setting the electrically adjustable driver's seat.

Exterior mirror adjustment.

Driving mode - setting the individual mode

Assistance systems - Lane Assist, parking aid (Park Pilot).

Light - ambient lighting, convenience turn signal, COMING HOME / LEAVING

HOME.

Climatronic - temperature in each individual area, fan speed, recirculation

mode.

Infotainment settings - brightness level of the screen, keyboard arrange-

ment.

Radio - sound settings, station sorting.

Media - shuffle / repeat title, selected video format.

Voice control - acoustic signals.

Navigation - home address, alternative routes, recommended route, reminder

of the lack of fuel.

Note

The scope of the personalisation functions is dependent on the type of Info-

tainment package.

Setting the personalization

Read and observe   on page 57 first.

In the Infotainment system, in menu



/  tap on function surface  → Per-

sonalisation.

The following menu items are displayed.

58

Operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Personalisation

Active - activate/deactivate the personalisation

Select a user account

A list of user accounts with the option to manage user accounts and to switch

to another account.

 - Account management with the following options:

Rename user account - rename the user account (not applicable to the Guest

account)

Copy settings to another account - copy the settings of an active user account

to another user account

Reset user account - reset the selected user account to factory settings

Settings

Key assignment: - options for assigning the vehicle key to the user account:

Manual - detected vehicle key must be assigned to the active user account

manually

Automatic - detected vehicle key automatically assigned to a different ac-

count of the active user account

Assign vehicle key to current user account - manual assignment of the detected ve-

hicle key to the active user account - follow the instructions on the Infotain-

ment screen

Reset all - reset the personalisation and the user accounts to factory settings

Unlocking and opening

Unlocking and locking

Introduction

The vehicle is equipped with a central locking system which makes it possible

to unlock / lock all the doors, the fuel filler flap and boot lid simultaneously.
The door unlocking can be adjusted individually

» page 62

.

The unlocking of the vehicle is displayed by the turn signal lights flashing

twice.
If you unlock the vehicle and do not open a door or the boot lid within the next

45 seconds, the vehicle will lock again automatically.
The locking of the vehicle is displayed by the turn signal lights flashing once.
If the driver's door has been opened, the vehicle cannot be locked.
If the doors or the boot lid remain open after the vehicle has been locked, the

turn signal lights do not flash until they have been closed.

WARNING

Never leave the key in the vehicle when you exit the vehicle. Unauthorized

persons (e.g. children) could lock the car, turn on the ignition or start the

engine - there is a danger of injury and accidents!

When leaving the vehicle, never leave people who are not completely in-

dependent, such as children, unattended in the vehicle. These individuals

might not be able to leave the vehicle on their own or to help themselves.

Can be fatal at very high or very low temperatures!

CAUTION

Each key contains electronic components; therefore it must be protected

against moisture and severe shocks.

Keep the keyway clean. Impurities (textile fibres, dust etc.) have a negative

effect on the functionality of the locking cylinder and ignition lock.

59

Unlocking and opening

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlocking/locking with the remote control key

Fig. 48

Key with pop-out key bit

Read and observe   and   on page 59 first.

Description of the key

» Fig. 48

Unlock button
Lock button
Depending on equipment fitted:

Unlock/unlatch the boot lid (vehicles fitted with manual folding opera-

tion)

Open/close/ the boot lid Stop movement of the boot lid (vehicles with

electric folding operation)

Locking button for folding the key bit in/out
Warning light for the battery charge - if the warning light does not flash

when a button on the key is pressed, the battery is discharged.

Unlock/unlatch the boot lid (vehicles fitted with manual folding operation)

By pressing the button , the lid is unlocked.
By holding the button , the lid is unlocked and unlatched (partially open).
If the lid is unlocked or unlatched using the  button, then the lid is automati-

cally locked after closing. The period after which the lid is locked can be set

» page 65

.

CAUTION

The remote control may be affected by signal superposition of transmitters

that are in the vicinity of the vehicle.

The range of the remote control key is about 30 m. The battery must be re-

placed if the central locking only reacts to the remote control at a distance of

less than approximately 3 m away

» page 288

.

A
B

Locking / unlocking - KESSY

Fig. 49  Vehicle unlocking / vehicle locking

Read and observe   and   on page 59 first.

The KESSY system (Keyless Entry Start Exit System) enables unlocking and

locking of the vehicle without actively using the remote control key.

Grip the door handle to unlock the vehicle

» Fig. 49

 - .

Touch the sensor on the door handle with your finger to lock

» Fig. 49

 - 

the vehicle.

When unlocking/locking the vehicle, the key must be at a maximum distance

of approximately 1.5 m from the front door handle.

Information on locking

On vehicles fitted with automatic gearbox, the selector lever must be moved

into the position P before unlocking.
After locking the vehicle, it is not possible to unlock within the next 2 seconds

by touching the door handle. This can be used to check whether the vehicle is

locked.

Protection against inadvertently locking the key in the vehicle

If one of the doors is closed after the vehicle has been locked and the key with

which the vehicle was locked remains in the passenger compartment, the vehi-

cle will be automatically unlocked. After automatically unlocking, the turn sig-

nal lights will flash four times. If no door is opened within 45 seconds, the vehi-

cle is automatically locked again.

60

Operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     1      2      3      4      ..
