Skoda Fabia (2019 year). Instruction - part 9





If route guidance is taking place at this moment in Infotainment, then there

is the option to start the route guidance in the “Android Auto” application. And

vice versa, if route guidance is currently taking place in the “Android Auto”

application, then there is the possibility that this will be terminated by the

start of route guidance by the Infotainment system.

Main menu

Fig. 162

Android Auto: Main menu

Main menu

» Fig. 162

Navigation applications
Telephone applications
Overview of running applications, telephone calls, accepted text messag-

es, tasks in the working directory, weather or similar.
Music applications
Display of other available applications as well as the option of returning to

the main SmartLink menu
Switching on voice control (Google Voice)

Next to the function surface in area

A

, the symbol , Then, by tapping on this

function surface again, a list of new applications is displayed.

Apple CarPlay

Connection set-up / disconnection

Prerequisites for establishing a connection

The external device to be connected must support the “Apple CarPlay”

communication system.
The data connection of the external device to be connected must be ac-

tive.
The voice control (Siri) of the external device to be connected must be ac-

tive.

A list external of devices, supported regions and applications that the “Apple

CarPlay” connection supports can be found on the websites of Apple Inc..

Connection set-up

Switch on the ignition.

Switch on the Infotainment system.

Switch on the external device.

Connect the external device to the USB input using a cable

» page 74

.

Select the connection using “Apple CarPlay”

B



» Fig. 161

 on page 139.

Disconnection of the active connection

In the main menu “Apple CarPlay”, tap the function surface of the “ŠKODA”

application, the main menu SmartLink is displayed.

Tap the function surface  .

or: Disconnect the cable from the USB input. When reconnected, the exter-

nal device is automatically connected.

Function restriction of Infotainment

For the duration of the connection, the external device cannot be used as an

audio source in the Media menu.
By connecting the external device with “Apple CarPlay”, all currently connec-

ted Bluetooth

®

 devices will be disconnected.

For the duration of the connection, no Bluetooth devices can be connected to

the infotainment system.

140

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If route guidance is taking place at this moment using Infotainment, then this

is terminated by starting the route guidance in the “Apple CarPlay” application.

And vice versa, if route guidance is currently taking place in the “Apple

CarPlay” application, then this will be terminated by the start of route

guidance by the Infotainment system.

Note

Some phone features of the connected external device can be operated in the

display of the instrument cluster

» page 50

.

Main menu

Fig. 163

Apple CarPlay: Main menu

Main menu

» Fig. 163

List of available applications
More pages with applications
Depending on how long the function surface is pressed for:

Tap - Return to “Apple Carplay” main menu

Hold - Switch on voice control (Siri)

MirrorLink

®

Connection set-up / disconnection

Prerequisites for establishing a connection

The external device to be connected must support the communication

system “MirrorLink

®

”.

The external device to be connected must have at least one

“MirrorLink

®

”application installed.

Some applications require the data connection in the connected external

device to be switched on.

A
B

Connection set-up

Switch on the ignition.

Switch on the Infotainment system.

Switch on the external device.

Connect the external device to the USB input using a cable

» page 74

.

Select the connection using “MirrorLink

®

”

B



» Fig. 161

 on page 139.

Disconnection of the active connection

In the main menu of “MirrorLink

®

”, tap the function surface  The SmartLink

main menu is displayed.

Tap the functional surface  .

or: Disconnect the cable from the USB input. When reconnected, the exter-

nal device is automatically connected.

Function restriction of Infotainment

Applies to Infotainment Amundsen: If you wish to use the device to be con-

nected in the Telephone menu, the external device must be paired with and

connected to the Infotainment system before establishing the connec-

tion

» page 130

.

Applies to Infotainment Swing. By connecting the external device to all cur-

rently connected Bluetooth

®

 devices will be disconnected and the external de-

vice will automatically be connected as the main telephone. Depending on the

device to be connected, a connection confirmation may be required.
For the duration of the connection, the external device cannot be used as an

audio source in the Media menu.

Main menu

Fig. 164

MirrorLink®: Main menu

141

SmartLink+

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Main menu

» Fig. 164

Return to SmartLink main menu

» page 139

List of running applications
Display of the last running application in the connected external device
Settings of the SmartLink

» page 109

 menu or

» page 113

List of applications
More pages with applications
Applications cannot be operated while driving

Display of the function surfaces during the running application

Return to “MirrorLink

®

” main menu

Show function surfaces at the top/bottom (applies to Infotainment

Amundsen)

Move the functional surfaces in the desired corner of the screen

(applies to the infotainment Swing)

To show/hide the function surfaces, press the controller  (applies to Infotain-

ment Amundsen).

function problems

If problems occur with the “MirrorLink

®

”connection, then one of the following

messages may occur on the screen.

Fault: transfer - Disconnect and reconnect the external device

MirrorLink® audio is unavailable. - Disconnect and reconnect the external device

MirrorLink® availability on this mobile device is restricted. - it is not possible to use the

connected device during the journey or the device only has limited availabili-

ty (applies to Infotainment swing)

The mobile device is locked. Please unlock the mobile device to use MirrorLink® - “unlock”

the connected external device

Unable to start app or app not working. - Disconnect and reconnect the external

device

A
B

  

      

Application“ŠKODA OneApp”

Introductory information

Fig. 165

Information on the ŠKODA

OneApp application on the ŠKO-

DA websites

A mobile telephone connected to the Infotainment system allows you to edit

and evaluate journey data in the “ŠKODA One App” application.
After entering the following address into the web browser, the website is

opened with information on the ŠKODA mobile applications.
http://go.skoda.eu/service-app
The “ŠKODA OneApp” application is available in the App Store and Google

Play online shops.

“ŠKODA OneApp” application

Scan the QR code

» Fig. 165

 .

For the full functionality of the “ŠKODA One App” application, data transfer

from external devices must be activated.
Applies to Infotainment Amundsen

To activate data transfer from external devices, press the



 button, then

tap on function surface →  → Mobile device data transfer → Activate data transfer

for ŠKODA Apps.

Applies to Infotainment Swing

To activate data from external devices, press the



 button, then tap on

function surface → Activate data transfer for ŠKODA apps.

Note

Some functions of the application are not available in all countries or there is a

function restriction during the journey

» page 95

Mobile devices and applica-

tions.

142

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Connecting to the Infotainment system

The mobile telephone can be connected to the Infotainment system using the

SmartLink function or via WLAN.

Connection by SmartLink

Switch on the ignition.

Establish the connection via SmartLink (eg “MirrorLink

®

”)

» page 138

.

In the list of available applications, select the “ŠKODA One App” application.

Depending on the type of external device connected, some applications can be

started using voice activation, via the Infotainment or using the buttons on the

multi-function steering wheel.
Once connected, the contents of the application are displayed on the infotain-

ment screen.
A possible connection between the mobile telephone and the Infotainment

system via WLAN will be terminated after a connection is established using

SmartLink.

Connection via WLAN (applies to Infotainment Amundsen)

Switch on the ignition.

Establish the WLAN connection

» page 137

.

In the mobile telephone, start the “ŠKODA OneApp” application.

Disconnection

The connection can be disconnected in one of the following ways.

Switch off the ignition for longer than 5 seconds (for vehicles with a starter

button, switch off the engine and open the driver's door).

End the connection in the “ŠKODA OneApp” application.

Disconnect the mobile telephone from the USB port or terminate the WLAN

connection.

Navigation

Introductory information

Navigation - function sequence

Applies to Infotainment Amundsen.

Route guidance is started as follows.

Find/enter a new destination or select one of the stored destinations.

Confirm the route calculation in the destination details or, if necessary, adjust

the route options.

Select the preferred route type, if this is requested by the Infotainment sys-

tem.

A route is calculated and route guidance starts.
The route guidance is provided by means of graphical driving recommenda-

tions and navigation announcements.
There is an option to add additional destinations during route guidance, or to

adapt the route.
If a traffic radio station is available, information concerning traffic delays is

evaluated by the Infotainment system and, if necessary, an alternative route is

offered.
If you deviate from the route, then a new route is calculated.

GPS satellite signal

Infotainment uses the GPS (Global Positioning System) satellite signal for

route guidance.
Outside the range of the GPS satellite signal (e.g. in dense vegetation, in tun-

nels, parking garages, etc.), the Infotainment system navigates only with re-

strictions, with the aid of vehicle sensors.
The Infotainment system offers the possibility off showing the following infor-

mation on the current geographical position of the vehicle and the satellite sig-

nal in the Position

» Fig. 168

 on page 145 split screen.

Geographical latitude
Geographical longitude

143

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Elevation
Number of received/available satellites

If no GPS satellite signal is available, no values are displayed.

Navigation data

Navigation data source

The navigation data is stored on an Original SD Card.
In order to ensure the function of the navigation, the Original SD card, with the

navigation data, must be inserted in the respective slot in the external module

» page 97

.

If the original SD card is damaged or lost, a new original SD card can be pur-

chased from ŠKODA Original Accessories.
With a Non-original SD Card, navigation does not work.

Determining the version of the navigation data

In the main Navigation menu, tap the function surface  → Version information .

Updating the navigation data

We recommend that you update the navigation data on a regular basis.
The Infotainment can give incorrect driving recommendations if the road con-

dition or the traffic situation does not match the navigation data. This can lead

to route guidance being carried out using a different route or proposing a

change of direction in a one-way street. Therefore, observe the respective

traffic signs while driving, which always have priority over the driving recom-

mendations.
The information on updating the navigation data can be obtained from a

ŠKODA partner or on the following ŠKODA websites.

http://go.skoda.eu/updateportal

Importing/updating the POI categories online

When “Infotainment Online”

» page 13

 services are activated, it is possible to

download the POI categories created in the user profile on the “ŠKODA

Connect portal” websites.

In the Navigation main menu, tap on function surface  → Version information →

Online update → Retrieve.

or: Press the



 button, then tap on function surface  →  .

A menu for the import/update of POI categories is displayed.

Select the desired list entries.

Tap on the function surface Retrieve and confirm the download process.

Main menu

Fig. 166

Navigation: Main menu

To display, press the



 button.

or: Press the



 button, then tap on function surface  .

Description of the function interfaces

A



» Fig. 166

Context-dependent:

Route guidance is deactivated - Search/enter a new destination

Route guidance is activated - The following menu is displayed:

Route details - Displays the route details

» page 157

Congestion ahead - Instruction adjusts traffic conditions

» page 160

Enter destination - Search / enter a new destination / stopover

» page 145

Stop route guidance - Stops route guidance

» page 157

The following menu is displayed:

Curr. current position - Store the current vehicle position as the flagged

destination

» page 149

Routes - Displays the list of saved routes

» page 158

Destinations - Display the list of stored destinations

» page 149

Last destinations - Display the list of recent destinations to which route

guidance was carried out

» page 149

Home address - Route guidance to your home address

» page 150

Search for POIs in categories

 and

Map display options

» page 152

Operation of Media/Radio playback

  

144

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Display for the volume setting of the navigation announcements/repeti-

tion of the navigation announcement

» page 156

Navigation settings

» page 109

Map

Fig. 167

Map description

The following information and function surfaces can be displayed in the

map.

» Fig. 167

Vehicle position
Route
Function interfaces for card use

» page 152

Function surface of the POI
Function surface for the POI list
Function surface for displaying a traffic incident

» page 160

Information on the maximum permitted speed
Destination position
Intermediate destination position
Destination position Home address
Favourite position

Information in the status line

Street name/street number of the current vehicle position
Distance to destination
Route to the stopover
Estimated travelling time to the destination
Estimated travelling time to the stopover
Estimated time of arrival at destination/stopover

A
B
C
D

E
F

G

Split screen

Fig. 168

Split screen

To activate/deactivate, go to the main Navigation menu and tap on the func-

tion surface  → Split screen.

To select content of the split screen

A



» Fig. 168

, tap on the function sur-

face  Tap and select one of the following menus, depending on the context.

Audio - Operation of Radio/Mediaplayback

Compass - Displays the current vehicle location in relation to the compass di-

rections

Most frequent routes - Display the three most frequent routes (if guidance not

being carried out)

» page 157

Manoeuvre - Display graphical driving recommendations (if route guidance is

enabled)

» page 156

Position - Displays the geographical coordinates of the current vehicle loca-

tion

Search for destination and enter

Selecting the type of destination search/destination entry

Fig. 169

Selecting the type of destina-

tion search/destination entry

145

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Route guidance is disabled - From the navigation main menu, the function

surface  →  .

 Route guidance is enabled - From the main menu navigation, tap on the

function surface  → Enter destination →  .

Function surfaces

» Fig. 169

Search for a destination or POI (point of interest) by name

» page 146

Destination entry by address

» page 147

Online POI search

» page 146

Search for a point along the route (only works with active route guidance)

» page 146

Destination input via the map point or using the GPS coordinates

» page 147

Search for destination/POI

Fig. 170

Menu for the destination search

Fig. 171  List of destinations visited: in the navigation data / online

The feature allows a full text search of locations or points of interest (POI) by

entering keywords.

A
B
C
D

E

Show menu

Route guidance is disabled - From the navigation main menu, the function

surface  →  .

 Route guidance is enabled - From the main menu navigation, tap on the

function surface  → Tap Enter destination

Then tap the function surface of one of the menu items for the destination

search

A

C

 or

D



» Fig. 169

 on page 145.

Function surfaces

» Fig. 170

 and

» Fig. 171

Input line
Depending on the search mode, the following symbols are displayed

 - Display the map as well as the list of the destinations listed in the navi-

gation database

 - Display the map as well as the list of online destinations

 - Select the destination search/destination entry

» page 145

List of last destinations (if no character is entered) / List of visited destina-

tions
Keypad
Status of online services

Find destination

Enter the POI name or the POI category (POI) and, if required, the place and

street name or house number/postal code.

A list of the destinations found is displayed in area

D



» Fig. 170

.

Select the desired destination and the destination details will be displayed.

or: Tap the

B



» Fig. 170

 function surface.

A map with the following symbols and a list of the destinations found is dis-

played.

Destinations found in the navigation data

» Fig. 171

 - .

Destinations found online

» Fig. 171

 - .

Select the desired destination and the destination details will be displayed.

A
B

C
D

E
F

146

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Enter destination using the address

Fig. 172  Enter destination using the address: Main menu / List of visited

destinations

Show menu

Route guidance is disabled - From the navigation main menu, the function

surface  .

 Route guidance is enabled - From the main menu navigation, tap on the

function surface  → Tap Enter destination

Then tap the function surface  →

B



» page 145

.

Enter dest.

Enter the destination address and then confirm

» Fig. 172

 - .

Tap the function surface  to see the destination details.

Relevant names (e.g. place/street names) are offered in the entry line during

entry, depending on the context. The location of the proposed destination can

be displayed by tapping the function surface Map.
Depending on the number of places visited, a map with a list of visited places

can be displayed automatically

» Fig. 172

 - .

The map with the list of visited locations can be accessed manually by tapping

the function surface  .

Entering a destination via the map point and using GPS coordinates

Fig. 173  Enter destination: via the map point / using the GPS coordi-

nates

Show menu

Route guidance is disabled - From the navigation main menu, the function

surface  .

 Route guidance is enabled - From the main menu navigation, tap on the

function surface  → Tap Enter destination

Then tap the function surface  →

E



» Fig. 169

 on page 145.

Enter destination via map point

By sliding the screen move the desired destination into the cross-hair

» Fig. 173

 - .

Tap the function surface  to see the destination details.

Entering the destination using coordinates

Tap in the values of the GPS coordinates one at a time and adjust

» Fig. 173

 -

,

Tap the function surface  to see the destination details.

If information is available about the point entered in the navigation data, then

these will be displayed instead of the GPS coordinates (e.g. address

A

» Fig. 173

).

147

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Entering a destination via the map point

Fig. 174

Menu after tapping the map

point

Tap on the map to display the symbol  and a menu with the following menu

items (depending on the context)

» Fig. 174

.

Display the destination details

» page 155

Display the POI details/display the list of POIs (function surface) )
Start route guidance to the selected point
Paste the selected point into the current route guidance as the next des-

tination
Start route guidance to the favourite
Start route guidance to the home address
Destination search in the vicinity of the selected point

» page 146

Define the starting point for demo mode (if it is turned on)

» page 156

Find petrol station, restaurant or car park

Fig. 175  List of petrol stations visited: in the navigation data / online

A
B

C

Fig. 176  List of car parks visited: in the navigation data / online

The Infotainment allows you to find petrol stations, restaurants or car parks

quickly in the navigation data as well as online.

In the Navigation main menu, tap on function surface  .

Tap the function surface of the desired category.

or: Press the



 button, and then tap on function surface  →  or  .

Find destination in the navigation data

Depending on the context below, a list of POIs from the selected category is

displayed.

No route guidance is taking place - The nearest destinations in a radius of

200 km from the current vehicle position are displayed.

Route guidance is taking place - Destinations on the route or near the route

are displayed.

Find destination online

When “Infotainment Online”

» page 13

 services are activated, a list of POIs

from the selected category in a radius around the current vehicle position is

displayed, regardless of whether or not route guidance is taking place.
After searching for a destination, you can switch between the list of destina-

tions found in the navigation data and the list of destinations found online by

tapping one of the following function surfaces at position

A



» Fig. 175

 or

» Fig. 176

.

Displays the list of destinations found in the navigation data.
Displays the list of destinations found online.

148

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Note

With the  → Fuel options → Select preferred fuel station function activated, the pre-

ferred fuel stations are displayed in the first three positions during the fuel sta-

tion search.

Saved destinations

Last destinations

List of last destinations

In the main Navigation menu, tap the function surface  → Last destinations.

Details of the last destination

In the main Navigation menu, press the



 button.

If route guide is not taking place, the details of the last destination to which

route guidance was carried out are displayed. If route guidance is taking

place, the details of the final destination are displayed.

Last destinations in the destination/POI search menu

In the destination search menu, a short list of recent destinations is shown in

area

D

» page 146

.

Function surfaces in the list of last destinations

- Destination search by name (the function surface is displayed when

there are more than 5 entries available)
- Display the details of the selected destination

» page 155

Destination memory

Fig. 177  Select list of stored destinations/categories of stored destina-

tions

Search

List of stored destinations

In the main Navigation menu, tap the function surface  → Destinations.

Tap on function surface

A



» Fig. 177

 and select one of the following catego-

ries of saved destinations

B



» Fig. 177

.

All saved destinations

 - Flagged destination (vehicle position at the time of storage)

 - Stored destination (manually saved destination/destination impor-

ted in vCard format)

 - Favourite (destination with additional favourite property)

Favourites (the favourite location is shown on the map by the

 symbol).

Telephone contact addresses of the connected telephone.
Online destinations created in the user profile on the “ŠKODA Connect

Portal” website or in the “ŠKODA Connect” application

» page 152

Function surfaces in the list of stored destinations

- Destination search by name (the function surface is displayed if there

are several entries on the next page of the list)
- Display the destination details

» page 155

Store target

In the main Navigation menu, tap the function surface  → Last destinations.

Tap the functional surface  Tap on the desired destination, the destination

details are displayed.

Tap on the function surface Store .

Rename the destination if necessary and confirm storage.

Save “flagged destination” (current vehicle position)

In the main Navigation menu, tap the function surface  → Store → Store cur-

rent position.

By tapping again on function surface Rename, you can rename the flagged

destination and store it as a destination in the destination memory.

Storing the next flagged destination will overwrite the last flagged destination.

To maintain the existing flagged destination, it must be stored in the Infotain-

ment memory.

Save destination as a favourite/cancel

It is not possible to store a contact address, a vCard or a target image as a fa-

vourite.

In the main Navigation menu, tap the function surface  → Destinations.

Tap the functional surface  and select the desired list of destinations.

Search

149

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Show the destination details by tapping on the function surface  at the de-

sired destination.

Tap the function surface Edit.

Tap the function surface Favourite.

Delete the destination

In the main Navigation menu, tap the function surface  → Destinations.

Tap the functional surface  and select the desired list of destinations.

Show the destination details by tapping on the function surface  at the de-

sired destination.

Tap the function surface Edit.

Tap the function surface Delete and confirm the deletion.

Home address

Define home address

When your home address is not entered, proceed as follows.

In the main Navigation menu, tap the function surface  → Home address.

Define the home address using the current vehicle position or by entering

the address.

Change home address

In the main Navigation menu, tap the function surface  → Manage memory →

Define home address.

Tap the function surface Edit.

Edit the home address or set one up using the current vehicle position or by

entering the address.

Delete home address

In the main Navigation menu, tap the function surface  → Manage memory →

Delete user data → Home address.

Tap the function surface Delete and confirm the deletion.

Import custom destinations

Introduction to the subject

Fig. 178

MyDestination application on

the ŠKODA websites

Fig. 179

ŠKODA Connect websites

Your own destinations can be created using the ŠKODAapplication

“MyDestination”, in the user profile on the website “ŠKODA Connect Portal” or

in the application “ŠKODA Connect”
Scan the QR code

» Fig. 178

 or enter the following address in your web brows-

er to display more information on the “MyDestination” application.

http://go.skoda.eu/my-destination

For the “ŠKODA Connect Portal” refer to the website of “ŠKODA Connect”.

You can open this by scanning the QR code

» Fig. 179

 or entering the following

address in your web browser.

http://go.skoda.eu/connectivity

Destinations in vCard format

In the Infotainment memory, you can import a custom destination in vCard

format (*.vcf) from an SD card or a USB source.

150

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Import

Insert the SD card into the external module or connect a USB source with

the file of the custom destination.

In the main Navigation menu, tap the function surface  → Manage memory →

Import destinations (SD/USB).

Select the source and confirm the import.

Route guidance

In the main Navigation menu, tap the function surface  → Destinations →  →

 .

Find and select the desired imported destination.

Delete custom destination

In the main Navigation menu, tap the function surface  → Destinations →  →

 .

Tap the functional surface  Tap on the desired own destination.

In the destination details, tap the function surface Edit → Delete and confirm

the deletion process.

POI categories created in the “MyDestination” application

Import/update

Insert the SD card into the external module or connect a USB source with

the POI categories.

In the main Navigation menu, tap the function surface  → Manage memory

Update "My POIs" (SD/USB) Tap.

If the same custom POI category name already exists in the Infotainment

memory, then it will be overwritten during the import.

Show POIs in the map

In the main Navigation menu, tap the function surface  → Map → Select cate-

gories for POIs → My points of interest (Personal POI).

Select the imported POI category.

Guidance to the POI

In the map, tap on the traffic obstruction symbol.

There are details of the selected target appears

» page 155

,

Clear all own POI categories

In the Navigation main menu, tap on function surface  → Manage memory →

Delete "My POIs".

Tap the function surface Delete and confirm the deletion.

POI categories created in the user profile in the “ŠKODA Connect

Portal”

Your own POI categories created in the user profile on the website “ŠKODA

Connect Portal” can be imported into the Infotainment memory.
The requirement for importing a POI category is that “Infotainment Online”

» page 13

 services are activated.

Importing POI categories

In the main Navigation menu, tap the function surface  → Version information →

Online update.

or: Press the



 button, then tap on function surface  →  .

A menu for importing/updating the navigation data and POI categories is dis-

played.

Tap the function surface POIs → Retrieve.

If new POI categories are available, their quantity and file size is displayed by

the Infotainment system.

Tap the function surface Start to start route guidance.

To complete the import, tap the function surface Next and confirm the im-

port.

Show POIs in the map

In the main Navigation menu, tap the function surface  → Map → Select cate-

gories for POIs → My points of interest (Personal POI).

Select the imported POI category.

Route guidance to a destination in the imported POI category

In the map, tap on the traffic obstruction symbol.

There are details of the selected target appears

» page 155

,

Clear all own POI categories

In the Navigation main menu, tap on function surface  → Manage memory →

Delete "My POIs".

Tap the function surface Delete and confirm the deletion.

151

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Destinations created in the user profile in the “ŠKODA Connect

Portal”

The destinations you have created in the user profile on the website “ŠKODA

Connect Portal” or in the application “ŠKODA Connect” can be imported to the

Infotainment memory.
The requirement for importing the destinations is that “Infotainment Online”

» page 13

 services are activated.

importing destinations

In the main Navigation menu, tap the function surface  → Destinations →  →

 .

or: Press the



 button, then tap on function surface  →  .

Tap on the function surface Update.

If new destinations are available, then confirm the import.

If the user profile on the website “ŠKODA Connect Portal” or in the application

“ŠKODA Connect” creates an object and sent to the Infotainment, after

switching on the ignition in the Infotainment screen displays a message re-

garding a new destination with the option to import this displayed.

Guidance to an online destination

In the Navigation main menu, tap on function surface  → Destinations →  →

 .

In the list of online destinations, find and select the desired destination.

Deleting online destinations

To delete all online destinations go to the main Navigation menu and tap the

function surface  → Manage memory → Delete user data → Online destinations.

To delete one online destination, go to the main Navigation menu and tap on

function surface  → Destinations →  →  →  → Edit → Delete.

Image with GPS coordinates

Fig. 180

Image with GPS coordinates

Infotainment enables guidance to the GPS coordinate data stored in the im-

age.

Press the



 button then tap the function surface Images.

Select the connected source and open the image with GPS coordinates.

Tap the function surface 

» Fig. 180

 Surface in the image, a menu opens

with the option to start route guidance.

The image can be obtained from an external device in which GPS coordinates

are stored during the imaging process. This could be created in the

“MyDestination” application and imported

» Fig. 178

 on page 150.

Map

Map display options

Fig. 181

Map display options

In the main Navigation menu, tap the function surface  .

152

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The following function surfaces are displayed

» Fig. 181

.

2D - Two-dimensional map display
3D - Three-dimensional map display
Display of the route from the current vehicle location to the destination
Display of the position of the destination or the next stopover on the map

(depending on the setting for menu item  → Advanced settings → Status line:)
Automatic map display in day or night mode (depending on the currently

active vehicle lighting)
Daytime map display
Night-time map display
Switch the split screen display on/off

» page 145

Switching on/ off of the selected POI categories display

» page 148

Enter-

ing a destination via the map point

If the map scale of the 2D Map or 3D Map is greater than 10 km, then the map

is automatically displayed as 2D and aligned in the direction of north. If the

scale is increased beyond this value, then the map is switched back to the orig-

inal representation.

Map scale

Fig. 182  Function surfaces for changing the map scale

It is possible to change the map scale manually or to activate the automatic

scale change.

Tap the function surface

A



» Fig. 182

.

In area

B



» Fig. 182

, function surfaces for changing the map scale are dis-

played.

A

B
C
D
E

Types of manual scale change

Touch the screen with two fingers and pull them apart or close them togeth-

er.

Press the control knob  .

Activating automatic scale change

If the automatic scale is active, the map scale will change automatically de-

pending on the type of roads travelled (motorway - smaller map scale / town -

larger map scale) and the manoeuvre to be carried out.

To activate the automatic scale change, go to the main Navigation menu and

tap on function surface  →  .

Tap the functional surface  is highlighted in green.
The automatic scale is only active as long as the map is centred on the vehicle

position (the function surface  is hidden).

To deactivate the automatic scale change, go to the main Navigation menu

and tap on function surface  →  .

Tap the functional surface  is highlighted in white.
The function is also deactivated when the map is moved or the map scale is

changed manually.

Map view in reduced scale

In the main Navigation menu, tap on function surface

A

 →  .

The map scale is reduced for a few seconds and then restored.

Changing map orientation

Fig. 183

Changing the map orientation

You can change the map orientation under the following conditions.

153

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The map is in the 2D display.
The map is centred (the function surface  is hidden).
The map scale is max. 10 km.

To change the map orientation, go to the main Navigation menu and tap on

function surface 

A



» Fig. 183

.

The map is oriented to the north

The symbol  the vehicle position rotates, the map and the Polar Star Symbol

 do not rotate.

With a larger map scale than 10 km, the map is automatically oriented towards

north.

Map oriented to the direction of travel

The map and the Polar Star symbol  rotate, the vehicle position symbol 

does not rotate.

Map centring

Fig. 184

Map centring

The moved map can be centred in the vehicle, destination or route position.

To centre the map, tap on function surface 

A



» Fig. 184

.

POIs display

The Infotainment system offers the possibility of displaying POI symbols on

the map on the Infotainment screen.

To activate/deactivate the display, go to the main Navigation menu and tap

on the function surface  → POIs.

To select the POIs to be displayed, go to the main Navigation menu and tap

on the function surface  → Map → Select categories for POIs and select the de-

sired categories (max. 10).

Road sign display

The Infotainment system offers the option of displaying the traffic signs stor-

ed in the navigation data or detected by the front camera during guidance on

the Infotainment screen

G



» Fig. 167

 on page 145.

To activate/deactivate the road sign display, go to the main Navigation

menu and tap on the function surface  → Map → Show road signs.

For some vehicles it is possible to set an alert when exceeding the permitted

speed limited by a road sign.

Press the



 button, then tap on function surface  → Driver assistance →

Speed warning:.

When towing a trailer, we recommend that you activate recognition of road

signs relevant to trailers.

Press the



 button, then tap on function surface  → Driver assistance → Show

road signs relevant to trailers.

Route guidance

Introduction to the subject

route is created by starting route guidance to a destination. Additional stop-

overs can be added to the route.
Route guidance takes place as follows

Through graphical driving instructions on the Infotainment screen and in the

display of the instrument cluster.

Through navigation announcements.

The Infotainment system tries to allow for continued guidance even if the nav-

igation data is incomplete or there is no data at all for the given area.
The route is recalculated each time you ignore driving recommendations or

change the route.

CAUTION

The navigation announcements provided may vary from the actual situations,

e.g. due to out-of-date navigation data.

154

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Destination details

Fig. 185  Details of the: in the navigation data / destination searched for

online

The following menu items and information are displayed in the destination de-

tails

» Fig. 185

.

Area with function surfaces
Detailed destination information
Destination position in the map
Detailed destination information (if available)
Status of online services

Display the destination details

The destination details can be displayed in one of the following ways.

While entering a destination.

By tapping on the function surface  in the destination list.

Press the



 button in the main Navigation menu to display the details of

the last destination.

Function surfaces

Using the function surfaces in area

A

, the following functions can be per-

formed, depending on the context.

Start/stop route guidance.

Searching for a nearby destination

» page 146

.

Set route options.

Store destination.

A
B
C
D

E

Edit destination (the destination can be deleted, renamed or saved as a fa-

vourite).

Dial the POI phone number (if the Infotainment system is connected to a

phone

» page 130

Pairing and connecting).

Route calculation and starting route guidance

Fig. 186

Alternative routes

Routes are calculated based on the set route options. The route options can be

set:  → Route options.

Alternative routes

With selection of alternative routes turned on, the following menu is displayed

after calculation of a new route

» Fig. 186

.

 Calculate the most economical route with shortest travelling time and

distance travelled – the route is highlighted green

 Calculate the fastest route to the destination, even if a detour is neces-

sary - the route is highlighted in red

 Calculate the shortest route to the destination, even if a longer travel-

ling time is required - the route is highlighted in orange

It is possible to select an already calculated alternative route before calculation

of the remaining routes is completed.
Selecting the type of route will start the route guidance.
If no route selection is made within 30 s of calculation of all routes, route guid-

ance will start automatically according to the preferred route type.

A

B

C

155

Navigation

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     7      8      9      10     ..
