Information on cooling system

After pressing the buttonthe indicator light on the button lights up, even if

not all the conditions for the cooling system have been met. The cooling sys-

tem starts to work as soon as the following conditions have been met

» page 91

.

If recirculated air mode is turned to position  when the blower is on, the

cooling system is switched on. The cooling system is switched off again by

turning the air distribution control out of the position  .
If recirculated air mode is outside position  when the recirculating air mode

is on, the cooling system is switched on.

Note

To ensure adequate thermal comfort, during operation of the instruction air condi-

tioning there could be an increase in the engine idle speed in some circumstan-

ces.

Climatronic (automatic air conditioning)

Fig. 123  Controls the Climatronic

Read and observe   on page 91 first.

Individual functions can be adjusted or switched on by turning the dial or

pressing the corresponding button

» Fig. 123

.

Setting temperature

 Reduce the temperature/

 Increase the temperature

Selected temperature
Degrees Celsius or Fahrenheit
Automatic operation of the air conditioning system is switched on
Intense air flow turned on to the windscreen

1

2
3
4
5

Direction of air flow
Recirculated air mode activated
Cooling system activated
Set blower speed
Set the fan speed (the set fan speed is indicated by the corresponding

number of segments in the display)

Turn to the left: Decrease speed / switch off Climatronic

Turn to the right: Increase speed

Interior temperature sensor

Switching the intensive airflow to the front windscreen on/off - when

this function is switched on, the warning light illuminates in the button

Switching automatic mode on

» page 93

Switching the airflow to the windows on and off
Switching the airflow to the upper body on and off
Switching the airflow to the footwell on and off
Switch recirculation on/off

» page 93

Switch the cooling system on/off

When this function is switched on, the corresponding icon appears in the dis-

play.

After the cooling system is switched off, only the ventilation function remains

active, whereby the lowest temperature that can be reached is the outside

temperature.

Set the temperature

In the range between 16 °C to 29° C, an automatic temperature control takes

place.
At a temperature setting below 16 ° C,  lights up in the temperature display,

the Climatronic functions with maximum cooling performance.
At a temperature setting over 29° C,  lights up in the temperature display, the

Climatronic functions with maximum heating output.

Switching between Celsius and Fahrenheit

Press the  and  buttons simultaneously and hold for about 2 s, the dis-

play shows the desired unit (position

3



» Fig. 123

).

6
7
8
9

10

11





92

Operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CAUTION

Do not cover the interior temperature sensor

11



» Fig. 123

 – the function of

the Climatronic could be affected.

Note

In order to ensure adequate thermal comfort, there may be an increase in en-

gine idle speed during operation of the Climatronic in some circumstances.

Climatronic - automatic operation

Read and observe   on page 91 first.

The automatic mode is used in order to maintain a constant temperature and

to demist the windows in the interior of the car.

To switch on press the  button. The display shows  (pos.

4



» Fig. 123

on page 92).

To turn off, press any button for the air distribution or change the blower

speed. The temperature contro lis continued.

Recirculated air mode

Read and observe   on page 91 first.

The recirculation mode prevents contaminated outside air getting into the in-

terior of the vehicle. In recirculated air mode air is sucked out of the interior of

the vehicle and then fed back into the interior.

To switch on/off, press the button.

Heater

If the air distribution control is set to position when the recirculation mode

is switched on, the recirculated-air mode is switched off automatically.

Individually controlled air conditioning

Recirculated air mode is switched on automatically if the following conditions

are met.

The blower is switched on.
The airflow adjuster is outside position .
The temperature controller is turned to the left.

If the air distribution control is set to position  when the recirculation mode

is switched on, the recirculated-air mode is automatically switched off.

Climatronic

If humidity increases in the vehicle, an automatic shutdown of air recirculation

can occur.

WARNING

The recirculation system cannot be switched on for a longer period of time,

because no fresh air is fed through from the outside. “Stale air” may result

in fatigue in the driver and occupants, reduce attention levels and also

cause the windows to mist up. As soon as windows mist up, turn on the re-

circulation system immediately - The is a risk of an accident!

CAUTION

We recommend not smoking in the vehicle when the recirculating air opera-

tion is switched on. The smoke sucked from the interior is deposited on the

evaporator of the air conditioner. This produces a permanent odour when the

air conditioning system is operating which can only be eliminated through con-

siderable effort and expense (replacement of compressor).

Air outlet vents

Fig. 124  Air outlet vents

Read and observe   on page 91 first.

The direction of airflow can be adjusted using the air outlet vents 34

» Fig. 124

, the outlets can be opened and closed individually.

93

Heating and ventilation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The airflow direction is set by moving the adjustment element

A



» Fig. 124

 in

the desired direction.

Opening

Turn the regulator

B

 upwards

» Fig. 124

.

Turn the regulator

B

 to the right.

Closing

Turn the regulator

B

 downwards

» Fig. 124

.

Turn the regulator

B

 to the left.

Depending on the setting for air distribution, the air will flow from the follow-

ing air vents.

Set the direction of the air

outlet

Air outlet vents

» Fig. 124



124

1245

34

45

CAUTION

Do not cover the air vents - the air distribution could be compromised.

94

Operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infotainment

Introductory information

Important information

Introduction to the subject

WARNING

Only use Infotainment in such a way that you have control of the vehicle

in every traffic situation (e.g. do not write text messages while driving, do

not link or connect the telephone, do not work with the contact list, do not

enter any destinations, do not connect WLAN or SmartLink etc.) – Other-

wise there is a risk of an accident!

Always route the connection cable of the external device such that is

does not restrict you when driving.

WARNING

Adjust the volume to ensure that acoustic signals from outside the vehi-

cle, e.g. the police, ambulances and fire engines, can be heard at all times.

High volumes can cause hearing damage.

CAUTION

In some countries, some Infotainment functions can no longer be selected

when the vehicle is running faster than a certain speed. This is not a malfunc-

tion, but complies with the national legal regulations.

Mobile devices and applications

Applies to Infotainment Columbus, Amundsen.

Fig. 125

QR code with reference to web

pages for checking the compati-

bility of devices

The availability of some of the functions described in this Owner's Instruction

depends on the type of device to be connected and the applications instal-

led in it.

Compatibility

On the ŠKODA pages, check to see if Infotainment is compatible with the se-

lected mobile devices. This verification is carried out by reading the QR code

» Fig. 125

 or after typing the following address into the web browser.

http://go.skoda.eu/compatibility

Applications

Applications can be installed in external devices (e.g. mobile, tablet) making it

possible to display additional information on the Infotainment screen or to op-

erate Infotainment.
Due to the variety of applications as well as their ongoing development, the

available applications may not work in all external devices. ŠKODA AUTO can

accept no liability for their proper function.
The range of available applications and their functionality is dependent on the

Infotainment model, vehicle and region.

Infotainment overview

Description – Infotainment Amundsen

Fig. 126  Infotainment Amundsen

95

Introductory information

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Left control dial for switching Infotainment on and off; volume adjustment
Control dial for calls and confirmations



 - Radio menu

» page 115



 - Media menu

» page 119



 - Telephone menu

» page 129



 - Voice control



 - Navigation menu

» page 143



 - Target-oriented traffic information

» page 159



 - Vehicle system settings

» page 161



 - Overview of Infotainment menus

Touch screen

» page 97

Description – Infotainment Swing

Fig. 127  Infotainment Swing

Left control dial for switching Infotainment on and off; volume adjustment
Control dial for calls and confirmations



 - Radio menu

» page 115



 - Media menu

» page 119

Depending on equipment fitted:



 - Telephone menu

» page 129



 Muting



 - Infotainment settings

1

2
3
4
5
6
7
8
9

1

2
3

4

Depending on equipment fitted:



 - Menu SmartLink (Press) / turn on / off the voice control function

SmartLink (hold)

» page 138



 - Sound settings

» page 111



 - Vehicle system settings

» page 161

Touch screen

» page 97

SD card slot

Description – Infotainment Blues

Fig. 128  Infotainment Blues

Dial (hereinafter only symbol )
Display
SD card slot
Switches Infotainment on/off
Radio menu

» page 115

 / Select radio frequency range

Media menu

» page 119

 / Select audio source

Settings of the selected menu (Radio

» page 114

 /Media

» page 114

)

Infotainment settings

» page 114

- Sound settings

» page 114

Backward / forward movement / settings of the selected menu item

values

Function keys (each of the functions for these keys is described in the

relevant chapters)

5

6
7
8

1

2
3











 /

 -

96

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

External module

Applies to Infotainment Amundsen.

Fig. 129

External module: Infotainment

Amundsen

The external module is located in the storage compartment on the front pas-

senger side

» Fig. 129

.

Only the SD1 card slot

A

 is visible.

Touch screen

The Infotainment can be operated by lightly touching the screen with your

fingers.
The brightness level of the screen can be set by

» page 105

 or

» page 111

.

To protect the screen, a suitable protective film for touch screens can be used.
The screen can be cleaned with a soft cloth and pure spirit if necessary.

Infotainment operation

Infotainment operation

Screen areas

Applies to Infotainment Columbus, Amundsen.

Fig. 130

Screen areas

Description of the display

» Fig. 130

Status line with time and outdoor temperature data and other information
Information and operation of the current menu
Function surfaces of the current menu

Operation principles

Applies to Infotainment Columbus, Amundsen.

Fig. 131

Screen display

Description of the display

» Fig. 131

Name of the current menu
Return to the higher-level menu

A
B
C

A
B

97

Infotainment operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Scroll symbol – moving in the menu is possible by moving fingers up or

down on the scroll symbol
Menu item with “checkbox”

 - Function is switched on

 - Function is switched off

 Opens a sub-menu of the menu item with a “pop-up window”

Function surfaces

The screen areas which confirm a function or a menu are called “function sur-

faces”.

White text – the surface is active and thus selectable

Grey text – the surface is inactive and therefore not selectable

Green frame – currently selected surface

Selecting a menu/menu item/function

Drag your finger over the screen in the required direction.

By moving your finger over the scroll bar

By turning the dial .

Confirming a menu/menu item/function

By tapping on the function surface.

By pressing the dial .

Returning to higher-level menu

By tapping on the function surface .

By tapping on the screen outside of the “pop-up window”.

By pressing the corresponding button next to the screen (e.g. in the menu

Media, by pressing the



 button).

Selecting a menu item/function value

 - Selected menu item/function value

 - Deselected menu item/function value

Setting a value

By tapping on the function surface  or  the bottom of the screen.

By touching or moving your finger over the scale.

By turning the dial .

Note

Depending on the equipment, the Infotainment can also be operated by means

of the buttons on the multifunction steering wheel. Further information

» page 47

.

C

D

E

Operating principles and display areas

Applies to Infotainment Blues.

Fig. 132

Display

Description of the display

» Fig. 132

Total number of menu items for each setting
Position of the current menu item
Name of the current menu item
Go to previous menu item value
Go to next menu item value
Current menu item value

Setting a value

The desired value of the selected item will be set to one of the following ways.

By pressing button

 or

.

By turning the dial .

Exit setting

To exit setting, press one of the buttons

 -

.

If the device is not being operated, the display switches off after a few sec-

onds in the last selected mode of (Radio or Media).

A
B
C
D

E
F

98

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Operating the menus

Applies to Infotainment Amundsen.

Fig. 133  Operating the menus

Operating the menus

» Fig. 133

Browsing the menu, list entries
Expand/reduce the menu window
Open / close the menu window
Close the menu window

Alphanumeric keyboard

Applies to Infotainment Columbus, Amundsen.

Fig. 134

Example of the keyboard display

The alphanumeric keyboard is used to enter letters, numbers and characters.

A
B
C

Description of the alphanumeric keyboard

» Fig. 134

Input line
Context-dependent:



 - Toggle upper case to lower case and vice versa



 - Switch to special characters



 - Switch to numbers

Context-dependent:



 - Switch to numbers



 - Switch to Latin letters



 - Switch to Cyrillic letters

- Display of visited entries (the number of visited entries is displayed in the

function surface)
Erase the entered characters
Hold to display the variants of the respective letters.

Switch between keyboards with specific characters of the selected

languages

» page 105

 or

» page 111

Space
Move the cursor within the input line to the left
Move the cursor within the input line to the right
Confirmation of the entered number

Search

While entering characters, a search is made for corresponding entries.
The entry to be searched for (such as a telephone contact) must be entered

along with any special characters (diacritics).
By tapping on the function surface  a list of matching entries opens.

Switching Infotainment on/off

Applies to Infotainment Amundsen, Swing, Blues

To switch on/off Infotainment, press

.

Automatic switch-on of Infotainment

If Infotainment was not switched off with

 before the ignition was switched

off, it will automatically switch on when the ignition is switched on.

Automatic switch-off of Infotainment

If the vehicle key is pulled out of the ignition lock while Infotainment is switch-

ed on, Infotainment will switch off automatically.

A
B

C

  



99

Infotainment operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If the vehicle is fitted with the starter button, Infotainment will switch off au-

tomatically after the engine is switched off and the door is opened.
With the ignition off, Infotainment will automatically switch off after about 30

minutes.
Infotainment switches off automatically under certain circumstances. Infotain-

ment informs you of this via a text message on the Infotainment display.

Infotainment restart

If Infotainment stops responding (if it “freezes”), it can be restarted by press-

ing and holding

 for longer than 10 s (does not apply to Infotainment Blues).

Show time and date on the screen

Applies to Infotainment Columbus, Amundsen.

Standby mode

With the ignition on and infotainment off (Standbymode), it is possible to dis-

play the time and date on the Infotainment screen.
Applies to Infotainment Amundsen

To switch the time and date display on/off, press the



 button, then tap

the function surface  → Screen Show clock in standby mode.

The display mode can be changed by finger motion across the screen side-

ways.
Applies to Infotainment Swing

To switch the time and date display on/off, press the



 button, then tap

the function surface Screen → Show clock in standby mode.

"Screen off" mode

With the ignition on and functions Switch off screen (in 10 seconds) and Display clock

when screen is off

» page 105

 enabled, it is possible to display the time and date

when the Infotainment screen is switched off.
The display type depends on the display mode selected in standby mode (does

not apply to the Infotainment Swing).

Adjusting the volume

Every change in volume is displayed on the screen.

Applies to Infotainment Amundsen, Swing

To increase the volume, turn the controller

 clockwise.

To decrease the volume, turn the controller

 anticlockwise.

To mute, turn the controller

 anticlockwise to 0.

or: To activate/deactivate the mute setting, press the button



 (applies

to Infotainment Swing).

Applies to Infotainment Blues

To increase the volume, turn the control switch

1



» Fig. 128

 on page 96

clockwise.

To decrease the volume, turn the control switch

1

 anticlockwise.

To mute, turn the controller

1

 anticlockwise to 0.

The following symbol appears on the screen when the sound is muted .
If, at the time of muting, sound is being played from a source in the Media

menu, then the playback is stopped.

CAUTION

High volumes can cause sound resonance in the vehicle.

When changing or connecting an audio source, this may cause sudden

changes in volume. Reduce the volume before changing or connecting an au-

dio source.

Infotainment menus

Applies to Infotainment Amundsen.

Fig. 135

Overview of Infotainment me-

nus: Grid display

100

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Fig. 136

Overview of Infotainment me-

nus: List

To display the overview of Infotainment menus, press the



 button.

To set the display mode, press the button



, then tap the function surface

 → Screen → Menu:.

Select the Grid

» Fig. 135

 or Horizont. Display

» Fig. 136

 option.

Overview of Infotainment menus

Radio menu

» page 115

Media menu

» page 119

“ŠKODA Connect” Online Services

» page 12

SmartLink menu

» page 138

With a connection established to an external device,  the actual connec-

tion is shown instead of a symbol

 Android Auto

» page 139

 Apple CarPlay

» page 140

 MirrorLink®

» page 141

Telephone menu

» page 129

Vehicle system settings

» page 161

Navigation menu

» page 143

 (Applies to Infotainment Amundsen)

List of traffic reports (TMC) (applies to Infotainment Amundsen)

» page 159

Media Command menu (Applies to Infotainment Amundsen)

» page 127

Images menu

» page 126

- Sound settings

» page 105

Infotainment settings

» page 105

Configuration wizard

Applies to Infotainment Columbus, Amundsen.

The configuration wizard is automatically displayed if there are at least two

non-selected menu items after turning on the Infotainment.

For manual display in Infotainment Amundsen, press the



 button, then

tap on the function surface  → Configuration wizard.

For manual display in Infotainment Swing, press the



 button, then tap

the function surface Configuration wizard.

The Configuration wizard allows you to set the following menu items in se-

quence.

Time and date format
Storing the radio station with the strongest reception signal at present
Pairing and connecting a telephone to the Infotainment system
Home address (applies to Infotainment Amundsen)
Setting “ŠKODA Connect” online services

The selected menu item is marked with the

 symbol.

Operating using an application in the external device

Applies to Infotainment Amundsen, Swing.

Some Infotainment functions can be operated using an application in the sup-

ported external device.
For the complete functionality of the application, data transmission from ex-

ternal devices must be activated and, if necessary, operation of the Infotain-

ment via the application must be approved.

Applies to Infotainment Amundsen

Activate data transfer in Infotainment. To do this, press the



 button and

then tap function surface  → Mobile device data transfer → Activate data transfer

for ŠKODA Apps.

Release Infotainment operation using the application. To do this, press the



 button and then tap function surface  Tap→ Mobile device data transfer →

Operation via apps: → Confirm/Allow .

Connect Infotainment to an external device via WLAN

» page 137

.

In the external device, launch an application for Infotainment operation (e.g.

ŠKODA Media Command).

101

Infotainment operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Applies to Infotainment Swing

Activate data transfer in Infotainment. Press the



 button and then tap on

the function surface Activate data transfer for ŠKODA apps.

Note

The description of Infotainment operation using ŠKODA Media Command is

part of the application.

Voice control

Introduction to the subject

Applies to Infotainment Amundsen.

The navigation, telephone, radio and media menus can be operated by voice

commands.
The voice control system can be used either by the driver or by the front pas-

senger.

Function requirements for voice control

Infotainment is switched on.
No telephone call is being made using a telephone connected to Infotain-

ment.
The parking aid is not active.

Requirements for optimum voice command recognition

The voice commands must only be issued when the

 symbol is displayed on

the Infotainment screen and the input tone has completely faded.

Speak at your normal volume without intonation and long pauses.

Avoid bad pronunciation.

Close the doors and windows in order to prevent environmental influences

from interfering with the function of the voice control.

You are advised to speak louder at higher speeds, so that the sound of your

voice is not drowned out by the increased ambient noise.

During voice control, limit additional noise in the vehicle, e.g. passengers talk-

ing at the same time.

WARNING

The emergency number should be dialled manually. Your voice commands

may not be recognised in such situations. The telephone connection may

not be established or the connection may take too much time to complete.

CAUTION

The messages are generated by Infotainment. Flawless clarity (e.g. road or

city name) cannot always be guaranteed.

For some Infotainment languages, voice control is not available. Infotainment

indicates this through a text message that is displayed on the screen after set-

ting the Infotainment language.

Note

During voice control, no navigation announcements and traffic announce-

ments are played.

Switching voice control on/off

Fig. 137

Voice control: Main menu

Switch on

Press the button  on the multifunction steering wheel or button



 on

the Infotainment system.

The main menu is displayed

» Fig. 137

.

Switch off

Press the button twice  on the multifunction steering wheel or button



on the Infotainment system.

or: Issue the voice command “End voice control”.

102

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Operation principle

Fig. 138

Example of screen display

The voice control main menu

» Fig. 137

 on page 102 contains basic voice com-

mands for the individual menus.
Other voice commands are displayed by tapping the respective function sur-

face, if required, by issuing the name of respective command (e.g. navigation).

The screen shows the following

» Fig. 138

.

Context-dependent:

 The system is waiting for a voice command

 The system recognises a voice command

 The system plays a message

 Voice command entry was stopped

Available list entries
Possible voice commands
Displaying other possible voice commands

Voice commands that can be issued are indicated in “quotation marks”.

Note

Depending on the equipment, the voice control symbols

A



» Fig. 138

 are also

displayed on the display of the instrument cluster.

A

B
C

Voice commands

Enter

The voice commands must only be issued when the

 symbol is displayed

on the Infotainment screen and the input tone has completely faded. The in-

put tone can be switched on/off. To do this, press the



 button and then tap

function surface  → Voice control.
It is not necessary to wait for the end of message playback when Infotainment

is playing a message. The Infotainment message can be terminated by pressing

the button



 or button  on the multifunction steering wheel. Then a voice

command can be issued. Voice control is much faster as a result.

Stop

This allows more time to enter the voice command (e.g. in the list of retrieved

contacts).
The process for entering voice commands can be stopped by moving a finger

up/down across the screen or by turning the controller  .
When stopping, the symbol changes from

 to .

Restore

The procedure for entering voice commands can be restarted in one of the fol-

lowing ways.

By tapping on the function surface .

By pressing the button



 on the Infotainment.

By pressing the button  on the multifunction steering wheel.

Not recognising a voice command

If a voice command is not recognised by the Infotainment system three times

in succession, then voice control is stopped.

Correction of a voice command input

A voice command can be corrected, modified or re-entered by pressing the

button



 or the button  on the multifunction steering wheel. However,

this is only possible as long as the

 symbol is displayed on the screen.

You do not have to wait until the voice command is recognised by Infotain-

ment.

103

Infotainment operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Voice commands can be used during voice control

Voice command

Function

Back

Return to the previous menu

Help

Reproduce and display possible voice commands

Voice commands that can be used while browsing the list entries

Voice command

Function

Next page

Browse menu/list/directory

Previous page
First page
Last page

Additional information

Navigation

To the destination, you are first required to issue the command“enter ad-

dress” and then follow Infotainment instructions.
It is not necessary to spell city and street names if the entered destination is

located in a country that has no voice control available for the language.

Online POI search

When “Infotainment Online”

» page 17

 services are activated, a POI search can

also be carried out online by issuing the voice command “Find online POI”.

Radio

In order for a radio station to be selected using voice command, the station

must be stored in the list of available stations

» page 117

 or in the preset list

» page 117

.

Updating the Infotainment software

Fig. 139

Available software updates on

the ŠKODA websites

The software update ensures optimum operation of Infotainment (e.g. com-

patibility with new telephones).
Information on Infotainment compatibility can be found on the following

ŠKODA Internet pages. This is done by scanning the QR code

» Fig. 139

 or en-

tering the following address into the web browser.

http://go.skoda.eu/updateportal

Applies to Infotainment Amundsen

To determine the software version, press the



 button then tap the func-

tion surface  → System information.

To start the software update, press the



 button, then tap the function

surface  → System information → Update software.

Applies to Infotainment Swing

To determine the software version, press the



 button, then tap the Sys-

tem information function surface.

To start the software update, press the



 button, then tap the System in-

formation → Update software function surface.

104

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infotainment settings - Amundsen

Infotainment system settings

Sound settings

Press the



 button, then tap on function surface  .

Volume - Volume settings

Radio announcements - Volume adjustment of traffic announcements (TP)

Navigation announcements - Volume setting for navigation announcements

Voice control - Volume setting for voice output

Maximum switch-on volume - Set the maximum volume when switching on In-

fotainment

Speed dependent Volume adjustment - Increases the volume as speed increases

Bluetooth audio: - Volume setting of the device connected via Bluetooth

®

 au-

dio profile of the connected external device

Quiet - Low volume

Medium - Medium volume

Loud - High volume

Entertainment fading while parking - Lowers the audio volume (e.g. radio volume)

when the parking aid is activated

Entertainment fading (Navigation) - Lowers the audio volume (e.g. radio volume)

in the event of a navigation announcement

Bass - Mid - Treble - Setting the equalizer

Balance - Fader - Sets the balance between left and right, front and rear

ŠKODA Surround - Switch surround sound on/off (cannot be used in Radio

mode)

Virtual Subwoofer -Switch virtual subwoofer on/off (cannot be used in Radio

mode)

Touchscreen tone - Switch audible tone when touching the screen on/off

No navigation announcements during calls - Switches the navigation prompts on or

off during a telephone conversation

Display settings

Press the



 button, then tap on function surface  Tap→ Screen.

Menu: Setting the Infotainment menu display

Horizont. Display - Horizontal display

» Fig. 136

 on page 101

Grid display - Grid display

» Fig. 135

 on page 100

Switch off screen (in 10 seconds) - Enable/disable the automatic power off func-

tion

Display clock when screen is off - Time and date display when the screen is

switched off

Brightness: - Adjusts the brightness of the screen

Touchscreen tone - Switch on/off audible tone when touching the screen

Show clock in standby mode - Time and date displayed on the screen when the

ignition is switched on and Infotainment is switched off

Time and date settings

Press the



 button, then tap on function surface  → Time and date.

Clock time source: Time source settings: manual/GPS (applies to Infotainment

Amundsen)

Time: - Time settings

Summer (DST) - Switches summer time on/off

Automatic summer time - Switches the automatic switch to summer time on/off

Time zone: - Select the time zone

Time format: - Set the time format

Date: - Date settings

Date format: - Set the date format

Infotainment language settings

Press the



 button, then tap on function surface  → Language.

Select the Infotainment language.

In some languages, after selecting the function surface, Female or Male are dis-

played for the choice of Infotainment voice prompts.

Note

When a language is selected which does not support voice control, Infotain-

ment will indicate this with a message on the screen.

The messages are generated by Infotainment. Flawless clarity (e.g. road or

city name) cannot always be guaranteed.

More keypad languages settings

Press the



 button, then tap on function surface  → Additional keypad lan-

guages.

105

Infotainment settings - Amundsen

-------------------------------------------------------------------------------------------------------------------------------------------------------------

In this menu, a keyboard language set can be added to allow characters other

than those in the currently selected language to be entered.

Unit settings

Press the



 button, then tap on function surface  Tap on→ Units .

Distance: - Distance units

Speed: - Speed units

Temperature: - Temperature units

Volume: - Volume units

Fuel consumption: - Consumption units

Pressure: - Pressure units for tyre pressure

Settings for data transfer

Activated data transfer enables data transfer between the Infotainment sys-

tem and the external device or the operation of some Infotainment functions

using the applications of the external device (e.g. ŠKODA Media Command).

Press the



 button, then tap on function surface  → Mobile device data trans-

fer.

Activate data transfer for ŠKODA apps - Switch data transfer on and off

Use apps to operate: - Setting Infotainment operation via the applications of the

external device (applies to Infotainment Amundsen)

Deactivate - Deactivation of Infotainment operation via an external device

Confirm - Infotainment operation with required confirmation

Allow - Infotainment operation without required confirmation

Voice control settings

Press the



 button, then tap on function surface  → Voice control.

Example commands (infotainment syst.) - Switch menu display with language com-

mands in the Infotainment screen when activating voice control

Example commands (instrument cluster) - Turn on/off display of the menu contain-

ing voice commands when voice control is activated

Voice control session start tone - Activate/deactivate the audible signal when

turning on the voice control

Voice control session end tone - Activate/deactivate the audible signal when voice

control ends

Input tone in voice dialogue - Activate/deactivate the audible signal for the voice

input

End tone in voice dialogue - Activate/deactivate the audible signal for the voice

input

Safe removal of the external device

Press the



 button, then tap on function surface  Remove safely: and select

the external device to be removed.

Reset to factory settings

Press the



 button, then tap on function surface  → Factory settings.

In this menu, all or only selected settings can be restored.

Bluetooth

®

 settings

Press the



 button, then tap on function surface  → Bluetooth.

Bluetooth - Switch the Bluetooth

®

 function on/off

Visibility: Switch the visibility of the Bluetooth

®

 device for other Bluetooth

®

 de-

vices on/off

Name: - Changing the name of the Bluetooth

®

device

Paired devices - Display the list of paired Bluetooth

®

devices

Find devices - Search for available Bluetooth

®

 devices

Bluetooth audio (A2DP/AVRCP) - Activate/deactivate the ability to connect a

Bluetooth

®

 audio device (e.g. MP3 player, tablet etc...)

Wireless settings

Applies to Infotainment Amundsen.

Press the



 button, then tap on function surface  → WLAN.

WLAN - List of available hotspots of external devices

WLAN - Switch Infotainment WLAN on/off

WPS quick connection (WPS button) - Establish a secure connection to the hot-

spot of the external device using WPS (applies to Infotainment Amundsen)

Manual settings - Parameter settings for searching and connecting to the hot-

spot of the external device

Network name - Enter the Hotspot name

Network key - Access passkey setting

106

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Security level: Security setting (WPA2 always set)

Connect - Establish a connection

Find - Search / Restore the list of available hotspots

Mobile hotspot - Infotainment hotspot setting (the symbol  displayed with

the number of connected external devices)

Mobile hotspot - Switch the Infotainment hotspot on/off

WPS quick connection (WPS button) - Establish a secure connection to the Info-

tainment hotspot via WPS (applies to Amundsen)

Hotspot (WLAN) settings - Parameter settings for connection to the Infotain-

ment hotspot

Security level: Security setting (WPA2 always set)

Network key - Input of the access password

SSID: ... - Name of the infotainment Hotspots

Do not send network name (SSID) -Turn Infotainment hotspot visibility on/off

Store - Storage of the parameters set for the Infotainment hotspot

Network settings

Applies to infotainment Amundsen with the connected Carstick device.

Press the



 button, then tap on function surface  → Network.

Network settings - Sets the data connection from the associated telephone

service provider (APN settings)

Access point name: ... - Setting of the access point name

User name: ... - Setting of the user name

Password: ... - Password setting

Authentication: Sets the check type

Normal - Without verification

Safe - Verification required

Reset Access Point (APN) - Delete the parameters for the network setting

Store - Saves the parameters for the network setting

Network provider: ... - Selection of the network provider (the menu item is visi-

ble when the SIM card is inserted in the CarStick device)

Data roaming - Enable/disable the use of data roaming connection

Current connection details - Display of information on data downloaded (tap the

function surface Reset to delete the data information)

Data connection: - Usage settings for the data connection (Internet connection)

of the SIM card inserted in the CarStick device

Off - Use of the data connection is not possible

Ask - Use of the data connection is only possible after it has been confirmed

On - Use of the data connection is possible at any time

ŠKODA Connect Online Services settings

Press the



 button, then tap on function surface  → ŠKODA Connect (Online

Services).

Services Management - Information on licensing of the respective online serv-

ices and the option to switch them on/off

registration - Enter the registration PIN code for online services (in the user

profile on the website ŠKODA Connect Portal receive)

System information

Press the



 button, then tap on function surface  → System information.

The information available will be displayed, for example regarding the Infotain-

ment hardware and software, the Bluetooth

®

 software version, the navigation

database version, etc.

To Update the Infotainment software, Bluetooth

®

 software version, etc., tap

on the function surface Update software.

To Update the POI categories created in the user profile on the ŠKODA

Connect Portal website, tap on the function surface Online update.

The information on available software updates is obtained from a ŠKODA part-

ner or from the following ŠKODA Internet pages.

http://go.skoda.eu/updateportal

Radio menu settings

Settings for all broadcasting ranges

In the main Radio menu, tap the function surface  .

Sound - sound settings

Scan - Automatic playback of short portions of all available stations in the

current frequency range

107

Infotainment settings - Amundsen

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     4      5      6      7     ..
