Air conditioning

141

Auxiliary heating (additional heating)

Programming a departure/trip start

The activation of the parking ventilation for a
scheduled time is only valid for a single ventila-
tion process. The departure time must be for
each newly programmed ventilation process.
Before programming the departure time, you
must check that the date and time of the car
are correctly set.
When programming a departure time, the car
automatically calculates, depending on the en-
vironmental conditions, the necessary operat-
ing time of the parking ventilation.

NOTICE

Foods sensitive to heat or cold, medications
and other objects can be damaged by the
airflow.

●

Do not place any type of food, medicines

or other temperature sensitive items in front
of the ventilation slots.

Note

If parking ventilation works repeatedly for
long periods of time, the 12V battery charge
level will drop. It is advisable to take the vehi-
cle for a long drive to recharge the battery.

Troubleshooting

The cooling system cannot be switched on
or its operation is limited

If the air conditioning system cannot be
switched on, this may be caused by the follow-
ing:

●

The engine is not running.

●

The fan is switched off.

●

The air conditioner fuse has blown.

●

The outside temperature is lower than ap-

proximately 0°C (+32°F).

●

The air conditioner compressor has been

temporarily switched off because the engine
coolant temperature is too high.

●

Another fault in the vehicle. Have the air con-

ditioner checked by a specialised workshop.

Change the temperature unit (Climatronic)

The temperature display can be changed from
Celsius to Fahrenheit on the Infotainment sys-
tem screen using the function button

> Set-

tings > Units

Water or water vapour under the vehicle

If the humidity and temperature outside the ve-
hicle are high,

condensation

can drip off the

evaporator in the cooling system and form a
pool underneath the vehicle. This is normal and
does not indicate a leak!

When the outside humidity is high and the am-
bient temperature is low, condensation water
may evaporate when the stationary air condi-
tioning is operating. In this case, steam may
be released from underneath the vehicle. This
does not mean that the vehicle has any dam-
age.

Note

After starting the engine, any residual humid-
ity in the air conditioner could mist over the
windscreen. Switch on the defrost function
as soon as possible to clear the windscreen
of condensation.

Auxiliary heating (addi-
tional heating)

Introduction

The auxiliary heater runs on fuel from the vehi-
cle's tank and can be used while you are driving
and when the vehicle is stationary.
The auxiliary heating can be controlled through
the auxiliary heating menu in the Infotainment
system, through the SEAT CONNECT mobile
app, the MySEAT website or with the remote
control.
In winter, with the auxiliary heater switched on,
you can defog the windscreen and leave it free
of ice and snow (if it is a thin layer) before you
start driving.

CarManuals2.com

142

Air conditioning

If the outside temperature is very high, the vehi-
cle interior can be ventilated with the engine off
using the auxiliary heater.
The maximum operating period of the parking
ventilation is 60 min.

WARNING

The auxiliary heater exhaust fumes contain
carbon monoxide, an odourless and colour-
less toxic gas. Carbon monoxide can cause
people to lose consciousness. It can also
cause death.

●

Never switch on the auxiliary heater or

leave it running in enclosed spaces or areas
with no ventilation.

●

Never programme the auxiliary heater so

that it switches itself on and is running in an
enclosed space or an area with no ventila-
tion.

WARNING

The components of the auxiliary heater are
extremely hot and could cause a fire.

●

Always park your vehicle so that no part

of the exhaust system can come in contact
with easily flammable materials that might
be below the vehicle, such as dried grass.

NOTICE

Never place food, medicines or other tem-
perature-sensitive objects close to the air
vents. Food, medicines and other objects
sensitive to heat or cold may be damaged
or made unsuitable for use by the air coming
from the vents.

Switching the auxiliary heater on and
off

Connection

The independent heating can be connected in
the following ways:

●

Press the immediate on/off button in the App

or on the MySEAT website.

●

Press the immediate on/off button in the in-

fotainment system (while the vehicle is switched
off).

●

Press button on the remote control

›››

page 143

●

Automatically scheduling a departure time in

the auxiliary heater menu in the infotainment
system, or on the MySEAT App or website

›››

page 144

Disconnection

The independent heating can be switched off in
the following ways:

●

The supplementary heating function will be

turned off immediately using the on/off button
in the App or MySEAT website.

●

Press the immediate on/off icon in the info-

tainment system (while the vehicle is switched
off).

●

Press button on the remote control

›››

page 143

●

Automatically at the scheduled departure

time or after the programmed operating time
has elapsed .

●

Automatically when the control lamp (fuel

level indicator) lights up.

●

Automatically when the 12-volt battery

charge drops too low

›››

page 338

Things to note

Once switched off, the auxiliary heater will con-
tinue to operate for a short period of time in
order to burn the fuel remaining in the system
and also to expel the exhaust fumes.

CarManuals2.com

Air conditioning

143

Auxiliary heating (additional heating)

Radio-operated remote control

Fig. 114

Independent heating: radiofrequency

remote control key

›››

Fig. 114

Switch the auxiliary heater on
Switch the auxiliary heater off
Control lamp

If the buttons of the remote control are pressed
unnecessarily, it could switch on the auxiliary
heater involuntarily, even when it is out of range
or when the control lamp is flashing.
To switch on and off the independent heating,
the button must be pressed and held for ap-
proximately 1 second.

Control lamp on the remote control

When the buttons are pressed, the control lamp
on the remote control

provides the user with

different information:

It lights up for approx. 2 seconds

●

In green:

The auxiliary heater has been

switched on using the button.

●

In red:

The auxiliary heater has been

switched off using the button.

Flashes slowly for approx. 2 seconds

●

In green:

No on signal has been received. The

remote control is out of range. Move closer to
the vehicle.

●

In red:

No off signal has been received. The

remote control is out of range. Move closer to
the vehicle.

Flashes quickly approx. 2 seconds

●

In green:

The independent heating is blocked.

Possible causes: the fuel tank is almost empty,
the 12-volt battery charge is very low or there is
a fault.

It lights up for approx. 2 seconds

●

In orange (then in green or in red):

The re-

mote control battery is almost flat. However,
the on or off signal has been received.

●

In orange (then flashes green or red):

The

remote control battery is almost flat. No on or
off signal has been received.

Flashes for around 5 seconds

●

In orange:

The remote control battery is flat.

No on or off signal has been received.

Changing the battery of the radio-operated
remote control

When pressing the buttons, if the control lamp
of the remote

flashes for approx. 5 orange

or does not light up, the batteries must be re-
placed.
The battery is located beneath a cover on the
back of the remote control.

●

To open the cover, lift it slightly at the bottom

and slide it down.

●

Remove the old battery.

●

Insert the new battery. When doing so, take

into account the polarity and use batteries of
the same type

›››

●

Replace the battery cover by inserting the

tabs at the top and pressing the bottom.

Range

The receiver is inside the vehicle. The remote
control, when fitted with new batteries, has a
range of several hundred metres. Obstacles
between the remote control and the vehicle,
bad weather conditions and discharged batter-
ies can considerably reduce the range of the
remote control.

CarManuals2.com

144

Air conditioning

WARNING

Swallowing a battery with a 20 mm diameter
or any other button battery can cause seri-
ous and even fatal injuries within a very short
time.

●

Always keep the remote control, keyrings

with batteries, the spare batteries, button
batteries and all other batteries over 20 mm
out of reach of children.

●

If you suspect that someone may have

swallowed a battery, seek immediate medi-
cal attention.

NOTICE

●

The radio frequency remote control

contains electronic components. Therefore,
avoid getting it wet and exposing it to knocks
or direct sunlight.

●

The use of inappropriate batteries may

damage the radio frequency remote control.
For this reason, always replace the used bat-
tery with another of the same voltage, size
and specifications.

For the sake of the environment

●

Please dispose of your used batteries cor-

rectly and with respect for the environment.

●

The remote control battery may contain

perchlorate. Observe the legal provisions re-
garding disposal.

●

Care should be taken so as not to operate

the remote control unintentionally so as to
prevent the auxiliary heater being switched
on accidentally.

Programming the auxiliary heater

The activation of the parking ventilation for a
scheduled time is only valid for a single ventila-
tion process. The departure time must be for
each newly programmed ventilation process.
Before programming the departure time, you
must check that the date and time of the vehi-
cle are correctly set.
When programming a departure time, the vehi-
cle automatically calculates, depending on the
environmental conditions, the necessary oper-
ating time of the parking ventilation.

WARNING

Never programme the auxiliary heater so
that it switches itself on and is running in
an enclosed space or an area with no ven-
tilation. The auxiliary heater exhaust fumes
contain carbon monoxide, an odourless and
colourless toxic gas. Carbon monoxide can
cause people to lose consciousness. It can
also cause death.

Usage instructions

The auxiliary heater exhaust system located
below the vehicle must be kept clear of snow,
mud and other objects. The exhaust fumes
must be able to exit freely. The emissions gen-
erated by the auxiliary heater are removed via
an exhaust pipe fitted underneath the vehicle.
On heating the vehicle interior, depending on
the outside temperature, the warm air is first
directed at the windscreen and then to the rest
of the vehicle interior through the air vents. Di-
recting the vents – towards the windows for ex-
ample – can affect air distribution.

When the auxiliary heater is not switched on

●

The auxiliary heater requires about as much

power as the dipped beam headlights. If the
12-volt battery charge is too low, the auxiliary
heater switches off automatically and cannot
be switched on. This avoids problems when
starting the engine.

CarManuals2.com

Air conditioning

145

Stationary air conditioning

●

The heating must be activated every time you

want to set off. Similarly, the departure time
must reactivate each time.

●

The control lamp (fuel level indicator) lights

up.

Note

●

Noises will be heard while the auxiliary

heater is running.

●

When the air humidity is high and the in-

side temperature low, condensation from the
heating and ventilating system may evapo-
rate when the auxiliary heater is switched
on. In this case, steam may be released from
underneath the vehicle. This does not mean
that there is a vehicle malfunction.

●

If the vehicle is tilted, e.g. if parked on a

slope, the operation of the auxiliary heater
may be restricted if the fuel tank level is low
(just above the reserve level).

●

If the auxiliary heater is used a number of

times for a long period of time, the 12-volt
battery will lose its charge. To recharge the
battery, the vehicle must be driven for a
number of kilometres from time to time. As
a guideline: the journey should last approxi-
mately as long as the heater was connected.

●

At temperatures below +5 °C (+41 °F), the

auxiliary heater may switch itself on auto-
matically when the engine is switched on.
The auxiliary heater is switched off again af-
ter a certain time.

Stationary air conditioning

Introduction

✓

Valid for: hybrid vehicles.

With the stationary air conditioning you can
cool, ventilate and heat the passenger com-
partment while the vehicle is parked. In winter,
you can also demist the windscreen and leave
it free of ice and snow (if the layer is thin).
The stationary air conditioning is powered
through a socket or the vehicle’s high voltage
battery. Stationary air conditioning can be pro-
grammed and controlled in the Infotainment
system, through the SEAT CONNECT mobile
App and on the MySEAT website.
You can find information about the app, its
availability and the necessary requirements for
its use, as well as compatible terminals, on the
Internet

›››

page 236

NOTICE

Note

Using the stationary air conditioning with-
out connecting the charging cable reduces
the vehicle’s range. At extreme exterior tem-
peratures, the heating or cooling power of
the stationary air conditioning may be insuf-
ficient to reach the desired temperature.

Operating the stationary air condi-
tioning

✓

Valid for: hybrid vehicles.

The stationary air conditioning only works if the
high voltage battery is sufficiently charged.
The stationary air conditioning can operate
when the charging connector is not plugged in
When the charging connector is not plugged in,
the stationary air conditioning operates with the
high-voltage battery.

●

Open the

Battery Manager

menu.

●

Select the

Settings

menu.

●

Turn on the

Enable High-Voltage Battery

Power

function if necessary.

Setting the desired temperature

●

Open the infotainment system’s

Battery

manager

menu.

●

Set the desired temperature using y

CarManuals2.com

146

Air conditioning

Switching on the stationary air conditioning

It can be switched on in the following ways:

●

Press the immediate on icon in the Infotain-

ment system (while the vehicle is switched off).
During immediate air conditioning, the vehicle
reaches the set temperature in a maximum of
30 minutes.

●

Press the immediate on/off button in the mo-

bile App or on the MySEAT website.

●

Automatically programming a departure time

in the mobile App, on the My SEAT website, or
in the

Battery Manager

menu of the Infotain-

ment system

›››

page 146

Switching off the stationary air conditioning

In can be switched off in the following ways:

●

Press the immediate on/off button in the mo-

bile App or on the MySEAT website.

●

Press the immediate on/off icon in the info-

tainment system (while the vehicle is switched
off). It is only possible to switch it off if the sta-
tionary air conditioning was switched on using
this button.

●

Press the air conditioning off button in the

Air

conditioning

menu of the infotainment system

(while the vehicle is off).

●

Automatically, a few minutes after the sched-

uled departure time.

●

Automatically if the charge level of the vehi-

cle's high-voltage battery drops excessively.

Note

●

Noises will be heard while the stationary

air conditioning is running, caused by its op-
eration.

●

When the outside humidity is high and the

inside temperature low, condensation from
the air conditioning system may evaporate
when the stationary air conditioning is run-
ning. In this case, steam may be released
from underneath the vehicle. This does not
mean that there is a vehicle malfunction.

Programming the stationary air con-
ditioning

✓

Valid for: hybrid vehicles.

The stationary air conditioning can be pro-
grammed in the Infotainment system for a
scheduled departure time. You can set the de-
sired temperature of the vehicle interior for the
vehicle’s planned departure time.
Based on the desired temperature, the vehicle
calculates the time that the stationary air con-
ditioning needs to be switched on to reach this
temperature by the departure time.

Air conditioning the vehicle for departure

●

Open the

Battery Manager

menu.

●

Set the scheduled departure time.

●

Turn on the

air conditioning

and

charging

functions as needed.

If the two

air conditioning

and

charging

func-

tions are on at the same time, the high-voltage
battery is charged first and then the vehicle is
air conditioned. The departure time can only
be enabled when one of the two functions has
been enabled.
If the charging connector is plugged in, the ve-
hicle starts cooling down around 30 minutes
before the scheduled departure time. If the ve-
hicle is not ready to drive at the scheduled de-
parture time, it will be cooled for a further 15
minutes.
If the charging connector is not plugged in, the
air conditioning operating time is reduced to 10
minutes. The operating time is extended by 5
minutes if the vehicle is not ready to drive.
The stationary air conditioning switches off au-
tomatically.

Extended stationary air conditioning

In the

Battery Manager

menu can be found

an option to add extended air conditioning.
This means if the vehicle is air conditioned (ei-
ther by being switched on immediately or due
to departure scheduling), the convenience con-
sumers, e.g. seat or rear window heating may
switch on automatically if considered neces-
sary by the Climatronic (in cold conditions).
If the air conditioning is switched on immedi-
ately, the electrical convenience consumers
are also activated.
Comfort consumers depend on features.

CarManuals2.com

Air conditioning

147

Stationary air conditioning

●

Open the

Battery Manager

menu.

●

Tap on the icons of the seats whose conven-

ience consumers should be switched on in ad-
dition to the stationary air conditioning. The
driver's seat icon always stays activated by de-
fault (the driver's seat icon includes the comfort
consumers of seat heating and steering wheel
heating).

●

To turn on the rear window heating before the

departure time, switch on the

Automatic rear

window heating

function.

The maximum waiting time for comfort consum-
ers is approximately 10 minutes before the de-
parture time.

Immediate activation of the rear window
heating

The rear window heating can be switched
on/off using the SEAT CONNECT mobile app
or the MySEAT website, regardless of whether
or not the stationary air conditioning is switched
on.

Air-conditioning the vehicle after unlocking
it

●

Open the infotainment system’s

Battery

manager

menu.

●

Press

Settings

●

Enable the

When unlocking the vehicle

function.

Checking the programming

When the ignition is switched off, the infotain-
ment system displays the next time that is ac-
tive and the set functions.

CarManuals2.com

148

Driving

Driving

Driving indications

Pedals

●

Ensure that you can always press the accel-

erator, brake and clutch pedals unimpaired to
the floor.

●

Ensure that the pedals can return unimpaired

to their initial positions.

●

Ensure that the floor mats are securely fas-

tened during the trip and do not obstruct the
pedals

›››

Only use floor mats which leave the pedals
clear and which are secured to prevent them
from slipping. You can obtain suitable floor mats
from a specialised dealership. Fasteners for
floor mats are fitted in the footwells.

Wear suitable footwear

Always wear shoes which support your feet
properly and give you a good feeling for the
pedals.

WARNING

●

Restricting pedal operation can lead to

critical situations while driving.

●

Never lay or fit floor mats or other floor

coverings over the original floor mats. This
would reduce the pedal area and could ob-
struct the pedals. Risk of accident.

●

Never place objects in the driver footwell.

An object could move into the pedal area
and impair pedal operation.

Selecting the optimal gear

Depending on the equipment on the instrument
panel screen, a recommendation is shown with
the gear that should be engaged to optimise
consumption.
On vehicles with

automatic transmission

, it is

only displayed when driving in Tiptronic mode

›››

page 166

No recommendation will appear if the optimal
gear is engaged. The current gear will be dis-
played.

Display

Meaning

Optimum gear.

4 5

Changing to a higher gear is rec-
ommended.

2 1

Changing to a lower gear is rec-
ommended.

Information regarding the “cleanliness” of
the particulate filter

When the exhaust system detects that the par-
ticulate filter is close to saturation, this system’s
self-cleaning function recommends the optimal
gear for that function

›››

page 311

WARNING

The gear change recommendation is an aux-
iliary function and in no case should be a
substitute for careful driving.

●

Responsibility for selecting the correct

gear, depending on the circumstances, rests
solely with the driver.

For the sake of the environment

Selecting the correct gear can help to save
fuel.

Note

The recommended gear display turns off
when you are no longer in tiptronic mode.

Economical and environmentally
friendly driving

Fuel consumption, environmental pollution and
wear to the engine, brakes and tyres all depend
largely on driving style. Consumption can be
reduced between 10-15% with an efficient driv-
ing type. The following section gives you some

CarManuals2.com

Driving

149

Driving indications

tips on lessening the impact on the environment
and reducing your operating costs at the same
time.

Active cylinder management (ACT®)

Depending on vehicle equipment, the active
cylinder management (ACT®) may deactivate
some of the engine cylinders if the driving sit-
uation does not require too much power. The
number of active cylinders can be seen on the
instrument panel display

›››

page 18

Foresight when driving

If you think ahead when driving, you will need
to brake less and thus accelerate less. Take ad-
vantage of the inertia of the vehicle whenever
possible, with a

gear engaged

. This takes ad-

vantage of the engine braking effect, reducing
wear on the brakes and tyres. Emissions and
fuel consumption will drop to zero.

Changing gear to save energy

An effective way of saving is to change

in ad-

vance

to a higher gear.

Manual gearbox:

change from first to second

gear as soon as possible. Choosing the cor-
rect gear saves fuel. Select the highest possi-
ble gear suitable for the driving situation (the
engine should continue to run with cyclical reg-
ularity).

Automatic transmission:

accelerate gradually

and without reaching the “kick-down” position.

Avoid driving at high speed

Avoid travelling at your vehicle’s top speed,
whenever possible. Fuel consumption, emission
of harmful gases and noise pollution multiply as
speed is increased. Driving at moderate speeds
will help to save fuel.

Reduce idling time

In vehicles with the Start-Stop system idling is
automatically reduced. In vehicles without the
Start-Stop system it is worth switching off the
engine, for example, at level crossings and at
traffic lights that remain red for long periods of
time. When an engine has reached operating
temperature, and depending on the cylinder
capacity, keeping it switched off for a minimum
of about 5 seconds already saves more than
the amount of fuel necessary for restarting.
The engine takes a long time to warm up when
it is idling. Mechanical wear and pollutant emis-
sions are also especially high during this initial
warm-up phase. It is therefore best to drive
off immediately after starting the engine. Avoid
running the engine at high speed.

Regular maintenance

Regular servicing helps in saving fuel even be-
fore the engine is started. A well-serviced en-
gine gives you the benefit of

improved fuel

efficiency

as well as maximum reliability and

an enhanced resale value. A badly serviced en-
gine can consume up to 10% more fuel than
necessary.

Avoid short journeys

The engine and catalytic converter need to
reach their optimal

operating temperature

order to minimise fuel consumption and emis-
sions.
A cold engine consumes a disproportionate
amount of fuel. The engine reaches its work-
ing temperature after about four kilometres (2.5
miles), when fuel consumption will return to a
normal level.

Check tyre pressure

Always make sure the tyres are inflated to the
correct pressures

›››

page 348

to save fuel. If

the pressure is below half bar, fuel consumption
may increase by 5%. Due to the greater rolling
resistance, under-inflation also increases tyre
wear and impairs handling.
Do not use winter tyres all year round as they
increase fuel consumption by up to 10%.

Avoid carrying unnecessary loads

Given that every kilo of extra

weight

will in-

crease the fuel consumption, it is advisable
make sure that no unnecessary loads are being
transported.
Since the luggage rack increases the

aerody-

namic drag

of the vehicle, you should remove

it when not needed. At speeds of 100-120 km/h
(62-75 mph), this will save 12% of fuel.

CarManuals2.com

150

Driving

Save electrical energy

The engine drives the alternator, thereby gen-
erating electricity. This implies that any in-
crease in power consumption also increases
fuel consumption! For this reason, switch off any
unneeded electrical devices. Devices that use
a lot of electricity include the blower at a high
setting, the rear window heating or the seat
heating.

Plug-in hybrid drive:

brake early and evenly to

take advantage of energy recovery.

Note

●

If you have the Start-Stop system, it is rec-

ommended that it should not be disconnec-
ted.

●

It is recommended that you close the win-

dows when driving at more than 60 km/h
(37 mph).

●

Do not drive with your foot resting on the

clutch pedal, as the pressure can make the
plate slip. This causes wear and can damage
the clutch plate.

●

Do not ride the clutch on a hill, use the

brake. The fuel consumption will be lower
and you will prevent the clutch plate from
being damaged.

●

Use the engine brake on downhills by

changing to the gear that is best suited for
the gradient. Fuel consumption will be “zero”
and the brakes will not suffer.

Driving with a loaded vehicle

In order to achieve appropriate driving charac-
teristics when the vehicle is loaded, please note
the following:

●

Place all luggage securely

›››

page 280

●

Accelerate with particular care and precau-

tion.

●

Avoid sudden braking and manoeuvres.

●

Brake earlier than usual.

●

If applicable, please note the information

about the roof rack

›››

page 289

WARNING

Loads that move around could seriously
threaten the vehicle's stability and safety,
extend the braking distance during hard or
emergency braking and lead to serious acci-
dents and injuries.

●

Secure the load correctly to prevent it from

moving around.

●

Secure heavy objects with suitable lashing

straps or tie-down belts.

●

Ensure that the rear seat backrests are se-

curely engaged.

Driving with the rear lid open

Driving with the rear lid open is particularly
dangerous. Secure all objects and the open
rear lid correctly and take any necessary
measures.
Driving with the rear lid open increases the aer-
odynamic drag of the vehicle, along with fuel
consumption. It is therefore recommended that
you do not drive with the rear lid open.

WARNING

Driving with the rear lid unlocked or open can
cause serious injury.

●

Always drive with the rear lid closed.

●

Place all objects securely inside the lug-

gage compartment. Otherwise, loose ob-
jects could fall out of the luggage compart-
ment and injure road users driving behind.

●

Always drive carefully and with special

care and anticipation.

●

Avoid braking and sudden manoeuvres, as

the open rear lid could move uncontrollably.

●

When transporting objects that protrude

from the luggage compartment, mark them
accordingly to warn other road users. Please
bear in mind all legal provisions.

●

Never use the rear lid to support or secure

objects protruding from the luggage com-
partment.

CarManuals2.com

Driving

151

Driving indications

●

If a luggage rack is fitted on the rear lid, re-

move it and the load when you have to drive
with the rear lid open.

NOTICE

An open rear lid changes the height and, in
some cases, the length of the vehicle.

Note

Depending on the country, it may be forbid-
den to drive with the rear lid open. Please
observe the legal regulations of the country
in question.

Driving on flooded roads

To prevent damage to the vehicle driving on
flooded roads, take the following into account:

●

Water should

never

come above the lower

edge of the bodywork.

●

Drive at pedestrian speed.

●

Never stop the vehicle in the water, drive in

reverse or stop the engine.

●

Vehicles driving in the opposite direction form

waves that can raise the water level so high
that your vehicle will not be able to cross the
water safely.

WARNING

After driving through flooded zones, braking
effectiveness can decrease if the brake discs
or pads are damp

›››

page 173

Note

●

Driving through flooded areas may se-

verely damage vehicle components such as
the engine, drive train or electrical system.

●

Avoid driving through salt water (corrosion)

›››

page 366

●

Whenever driving through water, the

Start-Stop system must be switched off

›››

page 160

Running in

Please observe the instructions for running-in
new components.

Running-in the engine

A new engine must be driven through a
run-in period during its first 1500 kilometres
(1000 miles). During its first few hours of run-
ning, the internal friction in the engine is greater
than later on when all the moving parts have
bedded down.
How the vehicle is driven for the first 1500 km
(1000 miles) influences the future engine per-
formance. Throughout the life of the vehicle,
it should be driven at a moderate speed (es-

pecially when the engine is cold) this will re-
duce engine wear and increase its useful life.
Never drive at extremely low engine speeds.
Always engage a lower gear when the engine
works “irregularly”.

For the first 1000 km or

600 miles, please note:

●

Do not use full throttle.

●

Do not force the engine above two thirds of its

maximum speed.

●

Do not tow a trailer.

Between 1000 and 1500 kilometres (600 to
1000 miles)

gradually

increase power until

reaching the maximum speed and high engine
speeds.

Running in new tyres and brake pads

●

Replacement of wheel rims and new tyres

›››

page 347

●

Information about brakes

›››

page 173

For the sake of the environment

If the engine is run in gently, the life of the
engine will be increased and the engine oil
consumption reduced.

Four-wheel drive (4Drive)

On four-wheel drive models, the engine power
is distributed to all four wheels

CarManuals2.com

152

Driving

General notes

On four-wheel drive vehicles, the engine power
is distributed to all four wheels. The distribution
of power is controlled automatically according
to your driving style and the road conditions.
See also

›››

page 174

The four-wheel drive is specially designed to
complement the superior engine power. This
combination gives the vehicle exceptional han-
dling and performance capabilities, both on
normal roads and in more difficult conditions,
such as snow and ice. Even so (or perhaps es-
pecially for this reason), it is important to ob-
serve certain safety points

›››

Winter tyres

Thanks to four-wheel drive, your vehicle will
have plenty of traction in winter conditions,
even with the standard tyres. Nevertheless, we
still recommend that winter tyres or all-season
tyres be fitted on all four wheels to give even
better braking response.

Snow chains

On roads where snow chains are mandatory,
this also applies to cars with four-wheel drive

›››

page 351

Changing tyres

On vehicles with four-wheel drive, all four tyres
must have the same rolling circumference. Also
avoid using tyres with varying tread depths

›››

page 347

Off-roader?

Your SEAT vehicle is not an off-roader: in fact,
the ground clearance is not enough to be used
as such. Avoid consequently rough tracks and
uneven terrain.

WARNING

●

Even with four-wheel drive, you should al-

ways adjust your speed to suit the condi-
tions. Do not let the extra safety features
tempt you into taking any risks when driving.
Accident hazard!

●

The braking capability of your vehicle is

limited by the tyres' grip. It is therefore no dif-
ferent from a car without four-wheel drive. So
do not be tempted to drive too fast on firm or
slippery roads just because the vehicle still
has good acceleration in these conditions.
Accident hazard!

●

On wet roads bear in mind that the front

wheels may start to “aquaplane” and lose
contact with the road if the car is driven too
fast. If this should happen, there will be no
sudden increase in engine speed to warn the
driver, as occurs with a front-wheel drive car.

For this reason you should always choose
a driving speed suitable for the road condi-
tions. Accident hazard!

Trips abroad

The vehicle has been manufactured for a spe-
cific country and meets the approval regula-
tions in force in that country at the time it was
manufactured.
If you are going to use the vehicle abroad tem-
porarily or for a short period of time, please
observe the relevant instructions.
Some countries have special safety regulations
and provisions that the vehicle may not com-
ply with. Before travelling abroad, SEAT recom-
mends that you seek information from one of
your dealers about the legal provisions in force
in your destination country.
If you are going to sell the vehicle in another
country or use it there for a longer period of
time, please observe the legal regulations in
force in the country in question.
In some cases it may be necessary to install or
remove certain equipment at a later date, and
to deactivate certain functions. Sets and types
of services may also be affected. In particular,
this can occur if the vehicle is to be used in an-
other climatic region for a long period of time.
Due to the different frequency bands around
the world, the factory-fitted infotainment sys-
tem may not work in another country.

CarManuals2.com

Driving

153

Starting and stopping the engine

With petrol vehicles, it should be ensured that
lead-free petrol is available throughout the
journey. Seek information about service station
networks selling unleaded fuel.

SEAT importers and distributors will provide in-
formation about the technical preparation that
your vehicle requires and also about necessary
maintenance and repair possibilities.

NOTICE

SEAT does not accept liability for any dam-
age to the vehicle due to the use of a lower
quality fuel, an inadequate service or the
non-availability of genuine spare parts.

Starting and stopping the
engine

Switching the ignition on/off

Fig. 115

In the lower part of the centre console:

start button.

The engine can be started with a start button
(Press & Drive). For this there must be a valid
key inside the passenger compartment.
Opening the driver's door

when exiting the ve-

hicle

activates the electronic lock on the steer-

ing column if the ignition is disabled.

Switching the ignition on/off

If you only want to switch on the ignition (with-
out starting the engine), briefly press the start
button once

without pressing

the brake pedal

or the clutch pedal

›››

page 154

The starter button text

flashes

like a heartbeat when the system is preset for
switching the ignition on and off.

Automatic ignition disconnection

When the vehicle detects that there is no driver
once the engine has stopped, after a certain
time the ignition is switched off automatically.
If at that time the dipped beam headlights are
on, the side lights will stay on for approx. 30
minutes. The side lights can be turned off by
blocking the vehicle

Automatic deactivation of the ignition on ve-
hicles with the Start-Stop system

The ignition is switched off automatically when
the vehicle is stopped and the automatic en-
gine shutdown is active, if:

●

The driver's seat belt is not fastened,

●

the driver does not step on any pedal,

●

the driver door is opened.

After automatically turning off the ignition, if the
dipped beam is on, the side light remains
on for approx. 30 minutes (if the battery has
enough charge). If the driver locks the vehicle
or manually turns off the light, the side light
goes out.

CarManuals2.com

154

Driving

Switching off the ignition when leaving the
vehicle, with hybrid drive

When the ignition is not switched off in E-MODE
operating mode, a certain amount of time af-
ter the journey is complete it switches off auto-
matically to prevent draining the 12-volt vehicle
battery.

Function “My Beat”

For vehicles with a convenience key there is the
“My Beat” function. This feature provides an ad-
ditional indication of the vehicle ignition system.
When entering the vehicle, the start button

›››

Fig. 115

flashes to draw attention to it.

When the ignition is on/off, the engine start but-
ton flashes.
With the ignition is switched off, the start button
goes off after a few seconds.
With the engine running, the start button light
stays on, indicating that the engine is running.
The time elapsed between the moment the
user starts the engine with the start button and
the lighting changes from flashing to fixed will
depend on specific engine size characteristics.
When the start button is used to stop the en-
gine, the button starts flashing again.
In vehicles

with the Start-Stop system

, the

“My Beat” function also offers additional infor-
mation:

●

When the engine stops during the Stop

phase, the light of the start button stays on,
as the Start-Stop system remains active even
though the engine is off.

●

When the engine cannot be started again

with the Start-Stop system

›››

page 160

and

needs to be started manually, the start button
flashes to indicate this situation.

WARNING

When switching on the ignition, do not press
the brake or clutch pedal, otherwise the en-
gine could start immediately.

WARNING

If vehicle keys are used negligently or with-
out due care, this may cause accidents and
serious injury.

●

Never leave any key inside the vehicle

when you leave it. Otherwise, a child or un-
authorised person could lock the vehicle,
start the engine or connect the ignition and
operate any of the electrical equipment.

Note

●

Before leaving the vehicle, always discon-

nect the ignition and, if appropriate, take into
account the instructions on the screen of the
dash panel.

●

If the vehicle is stationary for a long time

with the engine off and the ignition on, the
vehicle battery might be discharged and it
might not be possible to start the engine.

●

In vehicles with diesel engines, wait until

the warning light goes off before starting
the engine.

●

If during the STOP phase you press the

button, the ignition is switched

off and the push-button flashes.

●

If the following indication appears on the

instrument cluster display:

“Start-Stop

system deactivated: Start the en-
gine manually”

; the button

will flash.

Starting the engine

●

Vehicles with manual transmission:

put the

gear lever in neutral, press the clutch pedal and
keep it pressed in this position until the engine
starts.

●

Vehicles with automatic transmission:

press

the brake pedal and keep it pressed in this posi-
tion until the engine starts.

CarManuals2.com

Driving

155

Starting and stopping the engine

●

Press the start button without pressing the

accelerator. There must be a valid key in the
vehicle for the engine to start. After starting the
engine, the lighting of the

button

remains fixed indicating that the engine is run-
ning.

●

Once the engine starts, release the start but-

ton.

●

If the engine does not start, stop and wait

for around 1 minute to try again. If necessary,
perform an emergency start

›››

page 157

Diesel engines can take a few seconds longer
than usual to start on cold days. During pre-
heating, the warning lamp remains lit. To
avoid unnecessary discharging of the battery,
do not use any other major electrical equip-
ment while the glow plugs are pre-heating.
The preheating time depends on the coolant
and exterior temperatures. With the engine at
operating temperature, or at outside tempera-
tures above +8°C, the warning lamp will light
up for about one second. This means that you
can start the engine almost immediately.

Starting a diesel engine after having run out
of fuel

If the fuel tank of a diesel vehicle was run until
completely empty, after refuelling it can last
longer than normal to start the engine, even
up to a minute. This is because the fuel system
must eliminate air first.

WARNING

Do not keep the engine running in confined
spaces, as there is a risk of poisoning.

●

The exhaust gases contain carbon monox-

ide, an odourless and colourless poisonous
gas that can cause loss of consciousness
and death.

WARNING

Do not get out of the vehicle with the en-
gine running, especially if a gear is engaged.
The vehicle could then suddenly move or
something strange could happen that would
cause damage, fire or serious injury.

WARNING

Never use cold start sprays, they could ex-
plode or cause the engine to run at high revs.
Doing this risks injury.

NOTICE

●

The starter motor or the engine may be

damaged if you try to restart the engine im-
mediately after switching it off.

●

When the engine is cold, you should avoid

high engine speeds, driving at full throttle
and over-loading the engine, as this could
cause engine damage.

For the sake of the environment

Do not warm-up the engine by running the
engine with the vehicle stationary. Start off
immediately, driving gently. This helps the
engine reach operating temperature faster
and reduces emissions.

Note

Electrical components with a high power
consumption are switched off temporarily
when the engine starts.

●

When starting with a cold engine, noise

levels may briefly increase. This is quite nor-
mal, and no cause for concern.

●

In vehicles with a natural gas engine

(CNG), by default, the engine starts with gas,
with the exception of the following cases:

–

Coolant temperature below -15°C.

–

After refuelling CNG.

●

When the outside temperature is below

+5 °C (+41 °F), if the engine is diesel, some
smoke may appear under the vehicle when
the fuel-operated auxiliary heater is on.

Turning off the engine

●

Bring the vehicle to a full stop

›››

●

Vehicles with manual transmission:

fully de-

press the clutch.

●

Vehicles with automatic transmission:

Switch

on the parking lock by pressing button

CarManuals2.com

156

Driving

●

Apply the electronic parking brake.

●

Briefly press the start button.

Car wash function (hybrid vehicles)

When the ignition is turned off with gear

ac-

tivated, the vehicle can roll for the next 30 mi-
nutes. After that time, if the vehicle is stopped
the parking lock

activates automatically. The

corresponding warning message is displayed
on the instrument cluster display one minute
before this happens.

WARNING

Never switch off the engine while the vehicle
is moving. This could cause loss of control of
the vehicle, accidents and serious injury.

●

The airbags and belt tensioners do not

work when the ignition is switched off.

●

The brake servo does not work with the

engine off. Therefore, you need to press the
break pedal harder to brake the vehicle.

●

Power steering does not work when the en-

gine is not running. You need more strength
to steer when the engine is switched off.

●

If the ignition is switched off, the steering

column could be locked, making it impossi-
ble to control the vehicle.

WARNING

Always take the key with you when you leave
the vehicle. This is particularly important if
there are children in the vehicle, as they
might otherwise be able to start the engine
or use power-operated equipment (e.g. the
electric windows), which could cause inju-
ries.

NOTICE

●

If the vehicle is stopped and the Start-Stop

system switches off the engine, the ignition
remains switched on. Make sure that the ig-
nition is switched off before leaving the vehi-
cle, otherwise the battery could discharge.

●

If the engine has been driven at high speed

for a prolonged period of time, it may over-
heat when switched off. To avoid damage,
allow the engine to run for approximately two
minutes in neutral before switching it off.

Note

After the engine is switched off the radiator
fan may run on for up to 10 minutes, even
if the ignition is switched off. It is also pos-
sible that the fan turns itself on once more
if the coolant temperature increases due to
the heat accumulated in the engine com-
partment or due to its prolonged exposure to
solar radiation.

Electronic immobilizer

The electronic immobiliser helps to prevent the
engine from being started with an unauthorised
key and, consequently, the vehicle being put in
motion.
The vehicle key has an integrated chip which
automatically deactivates the electronic immo-
biliser if there is a valid key inside the passenger
compartment.
The electronic immobiliser is automatically ac-
tivated when there is no longer a valid key in-
side the vehicle.
For this reason, the engine can only be started
with a properly coded Original SEAT key. This
type of keys can be purchased from a SEAT
dealer.

NOTICE

A perfect operation of the vehicle is ensured
if genuine SEAT keys are used.

CarManuals2.com

Driving

157

Driving with electric drive

Emergency starting function

Fig. 116

On the centre console: emergency

start.

If no valid key is detected inside the vehicle,
an emergency start-up will be required. The rel-
evant message will appear in the dash panel
display. This may happen when, for example,
the vehicle key battery is very low.

●

Immediately after pushing the start button,

place the key in the drink holder of the centre
console

›››

Fig. 116

, as close as possible to the

Kessy

logo.

●

The ignition connects and the engine starts

automatically.

Indications for the driver on the in-
strument cluster screen

Depress the clutch

●

This indication is displayed on vehicles with

a manual gearbox when the driver does not
depress the clutch pedal when starting the en-
gine. The engine can only be started if the
clutch pedal is depressed.

Press the brake

●

This message appears on vehicles with an

automatic gearbox if the driver tries to start the
engine without having the brake pedal pressed.

Press the brake to engage a gear

●

This indication is displayed when starting or

stopping the engine if the automatic transmis-
sion selector lever is in position

and the

brake pedal is not depressed. The engine can
only be started and stopped in these positions.

Engage position P; the vehicle can
move; doors can only be locked in
position P.

●

For safety reasons, this driver message ap-

pears and an audible warning sounds if the
parking lock button

is not pressed after

switching off the engine. Press button

other-

wise the vehicle could move.

Ignition is switched on

●

This driver message is displayed and a buz-

zer is sounded when the driver door is opened
with the ignition switched on.

Driving with electric drive

Switching on the hybrid drive system

✓

Valid for: hybrid vehicles

Switching on the hybrid drive activates the ve-
hicle's propulsion system. When the vehicle’s
drive system is switched on, the electric drive
is activated. The combustion engine starts au-
tomatically when the charge level of the high-
voltage battery is not sufficient to run with the
electric drive, or if high drive power is required.
To access driving with the electric drive in the
infotainment system:

●

> Battery manager.

Requirements for switching on the drive sys-
tem

The drive system can be switched on when the
following conditions are met:

●

The high voltage battery has a sufficient

charge level.

●

There is no charging cable plugged in.

●

The temperature of the high-voltage battery

is within the operating range.

●

There is a valid remote control key in the vehi-

cle.

CarManuals2.com

158

Driving

Switching on the drive system

●

Press the ignition and start button once. The

ignition must be switched on.

●

Press the brake pedal and keep it pressed.

●

Set the gear selector switch to position

activate the parking lock

●

Press the ignition and start button until in-

dicator lamp

lights up on the instrument

cluster. Do not press the accelerator. Release
the ignition and start button when the indicator
lamp

lights up on the instrument cluster.

The mark on the power display changes from

●

If the indicator lamp

does not light up,

cancel and repeat the operation.

●

If the vehicle has been locked with the remote

control key, the ignition and start button is de-
activated. If you are inside the vehicle and have
to start the engine, first unlock the vehicle or
perform an emergency start

›››

page 157

Note

A click is heard when the drive system is
turned on. This is completely normal and
does not mean there is a problem.

Detecting the drive system

With the electric drive, the motor makes no
noticeable noise when the drive system is
switched on or while driving. Therefore, you
cannot defect that the vehicle's drive system

is on by engine noise. Instead, the following
characteristics show that the vehicle is ready
to drive:

●

The indication

›››

page 23

is displayed on

the power gauge of the instrument cluster.

●

The display light on the instrument cluster is

on, regardless of whether the vehicle’s exterior
lighting is on.

●

The indicator lamp

is on in the instrument

cluster display.

●

An audio signal is heard.

Switching on the drive system in very low
outside temperatures

If the outside temperature is very low (approxi-
mately -27°C (-16°F) or lower), the high-voltage
battery may freeze and stop working. In this
case it's not possible to switch on the drive sys-
tem.
As soon as the temperature of the high-voltage
has increase enough, the drive system can be
switched on again.
To ensure that the drive system can be
switched on, even in very low outside tempera-
tures, SEAT recommends parking the vehicle in
a place protected from the cold.

Behaviour when moving off or stopping

The combustion engine only runs if necessary.
When the vehicle is stationary, the combustion
engine is normally switched off and the vehi-

cle’s electrical systems are powered by the
high-voltage battery. The rev counter on the
instrument cluster remains at

›››

page 23

The combustion engine switches off in certain
driving conditions. This is normal and aims to
save fuel. In general, the power steering and
brake assist systems remain on. In isolated ca-
ses the system may require the combustion en-
gine to carry on running even when the vehicle
is stationary.
In traffic jams the combustion engine may start
up while the vehicle is stationary to recharge
the high voltage battery for subsequent

driving

off

and

stopping

phases.

Vehicle sound

✓

Valid for: hybrid vehicles

The electric drive makes much less noise than
a combustion engine. In the versions for some
countries, artificial vehicle sound is generated
to allow the vehicle to be heard better from
the outside. At higher speeds, when the noise
produced by the tyres and the wind increases,
the vehicle's sound automatically fades out.

WARNING

During electric driving, the auditory percep-
tion of the vehicle by other road users may
be much lower. This is especially true in traf-
fic-restricted areas and when manoeuvring
or reversing. Accident hazard!

CarManuals2.com

Driving

159

Operating mode selection

The displayed symbol varies depending on the active operating mode and the charge level of the high-voltage battery.

Troubleshooting

✓

Valid for: hybrid vehicles

Drive: Fault! Stop the vehicle safely

The warning lamp lights up red.
There is a fault in the vehicle’s drive system.
The vehicle's drive system is no longer availa-
ble. Park the vehicle in a safe place as soon as
possible. Seek professional assistance.

Drive: Fault! The electric drive is not

working properly. Visit a workshop

The warning lamp lights up yellow.
There is a fault in the vehicle’s drive system.
Drive slowly to a specialised workshop to have
the fault repaired.

Drive: Warning! Power is limited. Check

the manual

The warning lamp lights up yellow.
Performance limited. The high-voltage battery
may not be sufficiently charged or may have
reached its operating temperature limit, for ex-
ample in very cold outside temperatures.

Vehicle sound: Fault! Pedestrians can-

not hear the vehicle. Visit a workshop

The warning lamp lights up yellow.

There is a vehicle sound fault. Drive with utmost
care, as other road users may not be able to
hear the electric vehicle. Go immediately to a
specialised workshop to have the fault repaired.

Operating mode selection

✓

Valid for: hybrid vehicles

The vehicle has different operating modes so
that it can always be optimally adjusted to ev-
ery situation while driving. Once the drive sys-
tem has been turned on, and provided that all
of the operating conditions required for this pur-
pose have been met, the

E-MODE

operating

mode is always activated in the first instance
for electric driving.

Operating mode selection

●

Switch on the drive system.

●

Access the

Battery manager

menu of the

infotainment system

> Battery manager

›››

page 82

●

Press the

E-Mode

Hybrid

function button

in the infotainment system. Further information
about the operating mode can be found in .

E-MODE (driving in electric mode)

In the E-MODE electric driving mode, the vehi-
cle basically drives in electric only mode. To
the extent possible, the vehicle's combustion
engine is not used.
All of the following conditions must be met for
E-MODE to be activated:

●

The high voltage battery has a sufficient

charge level.

●

The vehicle speed is lower than 130 km/h (80

mph).

●

The high voltage battery temperature is

above -10°C.
If, while driving in E-MODE mode, the necessary
conditions are no longer met, the combustion
engine starts and electric driving is suspended.
In this case, the indicator lights up on the
instrument cluster display.
The combustion engine starts when a kick-
down occurs in E-MODE. However, E-MODE re-
mains activated.

Hybrid (use the battery's charge)

This is the operating mode that allows you to
save most fuel.
The operating mode control unit tries to make
the most of the battery charge. For this pur-
pose, with active directions the navigation data
are also accessed.

CarManuals2.com

160

Driving

In this operating mode, the electric motor and
the combustion engine share the work of driv-
ing the vehicle.
In hybrid operating mode, the power from
the battery charge is used optimally. If route
guidance is activated, the vehicle may autono-
mously recharge the high-voltage battery using
the combustion engine.

Manual control of the battery charge

Manual control of the battery charge is only
possible in

Hybrid

operating mode. The option

selected by the user is only valid until the igni-
tion is switched off or the vehicle is switched to
Hybrid mode or E-MODE.
Press the function button and use the sym-
bols ,

and to control the battery charge:

Pressing this symbol selects a higher the-
oretical charge level. The vehicle tries to
reach that new theoretical high-voltage
battery charge level while driving. The vehi-
cle is powered by the combustion engine. If
the combustion engine has “excess” power,
it is used to charge the high-voltage bat-
tery.
This option increases fuel consumption.
SEAT therefore recommends using the
charging socket to charge the high-voltage
battery, whenever possible

›››

page 76

The high-voltage battery charge level is
kept at around the current level while driv-
ing. If you accelerate harder or increase
the vehicle speed, the combustion engine
starts up. When permitted by the driver’s
demand for acceleration and the vehicle
speed, the vehicle switches back to electric
mode.
Pressing this symbol selects a lower theo-
retical charge level. The vehicle only uses
the battery's charge when it is above the
selected theoretical charge level. The rest
is kept until the end of the journey.

The

Intelligent Hybrid

App allows the user

to save electrical energy until reaching home
(charging point) with just “one click”. If this op-
tion is not selected, the maximum amount of
electrical energy will be consumed until the se-
lected destination is reached. If the user has
no active route, the function will offer the acti-
vation of a predictive route and BMA mode from
the widget itself with just one click.

Show the active operating mode

The operating mode active at any given time is
displayed on the instrument cluster display, e.g.

WARNING

Switching to a different operating mode
while driving can distract you from traffic
conditions and cause accidents.

Note

Information about the operating mode that
is currently active is displayed on the instru-
ment cluster display, along with the charge
level of the high-voltage battery.

Troubleshooting

✓

Valid for: hybrid vehicles

E-MODE operating mode is not availa-

ble

The indicator lamp lights up in white.
The E-MODE operating mode (driving in
electric mode) cannot be used temporarily be-
cause one or more conditions are not met.

●

The conditions must be met to use the E-

MODE operating mode.

Start-Stop system

Description and operation

Not valid for PHEV hybrid vehicles

CarManuals2.com

Driving

161

Start-Stop system

Only in vehicles with Keyless Access.

In the mHEV version (semi-hybrid), above 20 km/h.

The Start-Stop system helps you to save fuel
and reduce CO

emissions.

In Start-Stop mode, the engine will automati-
cally switch off when the vehicle stops or is
stopping. The ignition remains switched on. The
engine automatically switches back on when
required.
In this scenario, the light of the
button remains lit.

When the ignition is switched on, the Start-Stop
function is automatically activated.

Control lamps

The Start-Stop system is available, the
automatic engine shutdown is active.
The Start-Stop system is not available or
has been disconnected.

Stopping and starting the engine

Vehicles with a manual gearbox:

●

When the vehicle is stopped, put it into neu-

tral and release the clutch pedal. The engine
will stop. The warning lamp will light up on

the display. The engine may be stopped before
the vehicle comes to a standstill (approximately
7 km/h).

●

When you depress the clutch pedal, the en-

gine will start again. The indicator lamp goes
out.

Vehicles with an automatic gearbox:

●

Brake until the vehicle has come to a stand-

still, and keep your foot on the brake pedal or
activate the Auto Hold system so that the vehi-
cle remains braked. The engine will stop. The
warning lamp will appear on the display.
The engine may stop before the car stops com-
pletely (approximately 7 or 2 km/h depending
on the vehicle's gearbox

●

When you take your foot off the brake pedal

the engine will start up again. The indicator
lamp goes out. With the Auto Hold system, the
engine will not start if you remove your foot
from the brake pedal. The car starts when you
press the accelerator pedal.

Basic requirements for the start/stop mode

●

The driver door must be closed.

●

The driver's seat belt must be fastened.

●

The bonnet must be closed.

●

The engine has reached operating tempera-

ture.

●

The reverse gear must not be engaged.

●

The vehicle must not be on a very steep

slope.

The engine does not turn off for various rea-
sons

Before stopping the vehicle, the system verifies
whether certain conditions are met. The engine

does not

switch off, in the following situations

for example:

●

The engine has not yet reached the required

temperature for the Start-Stop mode.

●

The temperature selected on the climate

control has not been reached.

●

The interior temperature is very high/low.

●

De-icing function button activated.

●

Park assist is switched on.

●

The battery is very low.

●

The steering wheel is overly turned or is being

turned.

●

If there is a danger of misting.

●

After engaging reverse gear.

●

In case of a very steep gradient.

●

In a traffic jam after stopping for the fifth time,

the engine will not stop any more.

●

With ESC disabled.

●

After emergency braking or loss of adhesion.

CarManuals2.com

162

Driving

Except for the MHEV version.

●

With a trailer attached.

●

While the particle filter is regenerating.

is displayed on the instrument cluster

screen; it is also displayed in the driver informa-
tion system,

The engine starts by itself

When stopped, the normal system mode may
be interrupted in the following situations. The
engine restarts without the driver's intervention.

●

The interior temperature differs from the tem-

perature selected on the climate control.

●

Defrost function button activated

●

The brake is pressed several times in a row.

●

The battery is not charged enough.

●

High electricity consumption.

●

The vehicle rolls forward or backward with

the engine off.

●

ESC deactivated.

●

The accelerator pedal (automatic transmis-

sion), or the clutch (manual transmission) is
pressed.

●

The steering wheel is turned slightly

●

When the air conditioning is activated.

Additional information related to the auto-
matic gearbox

The engine stops when the selector lever is in

and

, as well as in Tiptronic mode. When the

parking lock button

is activated, the engine

will also remain off when you remove your foot
from the brake.
In order to start the engine up again the ac-
celerator must be pressed, or another gear en-
gaged or the brake released.
If the selector lever is placed in

while stopped,

the engine will start up again.

Additional information about vehicles with
Adaptive Cruise Control (ACC)

In vehicles with ACC function, the engine will
start up again in certain operating conditions if
the radar sensor detects that the vehicle ahead
drives off again.

WARNING

●

Never switch the engine off until the vehi-

cle is stationary. The operation of the brake
and steering will not be fully guaranteed.
More force will be needed to turn the steer-
ing wheel or to brake. You could suffer an
accident and even serious injuries.

●

To avoid injury, make sure that the Start-

Stop system is switched off when working in
the engine compartment

›››

page 162

NOTICE

The Start-Stop system must always be
switched off when driving through flooded
areas

›››

page 151

Note

●

In vehicles with an automatic gearbox,

you can control whether the engine should
switch off or not by reducing or increasing
the brake force applied. While the vehicle re-
mains stopped, the engine will not stop if the
brake pedal is slightly pressed, in traffic jams
with frequent stopping and starting for exam-
ple. As soon as strong pressure is applied to
the brake pedal, the engine will stop.

●

When stopped, the brake pedal must be

kept pressed to ensure that the vehicle does
not move.

●

If the engine “stalls” with a manual gear-

box, it can be directly started up again by
immediately pressing the clutch pedal.

●

If the lever is placed in position D, N or S

after engaging reverse gear, 10 km/h (6 mph)
in a forwards direction must be reached for
the system to be in a condition to stop the
engine.

Manually connecting and discon-
necting the Start-Stop system

Not valid for PHEV hybrid vehicles

CarManuals2.com

Driving

163

Manual gearbox

Fig. 117

On the infotainment system display:

Start-Stop system on. View in the main menu.

View with the Infotainment system off.

If you do not wish to use the system, you can
switch it off manually:

●

In the infotainment system select

> As-

sistants > Smart Assistants

When the symbol appears in orange

›››

Fig. 117

the system is on and will stop and

start. When the symbol appears in white the
system is off.

Note

The system switches on every time the en-
gine is turned off voluntarily.

Troubleshooting

Not valid for PHEV hybrid vehicles

Indications for the driver on the instrument
cluster screen

Start-Stop system deactivated.
Start the engine manually

●

This indication shows that the Start-Stop sys-

tem

cannot

restart the engine.

This happens for 2 reasons: if the driver's door
has been opened or if the driver has unbuckled
the seat belt.

Start-Stop system: Fault! Function
not available

●

There is a fault in the Start-Stop system. Take

the vehicle to a workshop to have the fault re-
paired.

Manual gearbox

Changing gears

Fig. 118

Diagram of a 6-speed manual

gearbox.

Gear positions are indicated on the gear lever

›››

Fig. 118

●

Depress the clutch and keep your foot as far

as it will go.

●

Move the gear lever to the desired position.

●

Release the clutch.

Engaging reverse gear

Only engage reverse gear when the vehicle is
stopped.

CarManuals2.com

164

Driving

●

Depress the clutch and keep your foot as far

as it will go.

●

With the gear lever in neutral, push it down,

move it all the way to the left and then forwards
to select reverse gear

›››

Fig. 118

●

Release the clutch.

Changing to lower gears

When driving, you should always change down
through the gears progressively, i.e. to the gear
immediately below when engine RPM is not
tool high

›››

. Skipping one or several gears

when changing down through the gears at high
speed or high RPM can cause damage to the
clutch and gearbox, even if the clutch is de-
pressed

›››

WARNING

If the engine is running, the vehicle starts
moving as soon as a gear is engaged and the
clutch pedal is released. This also happens if
the electronic parking brake is switched on.

●

Never engage reverse gear while the vehi-

cle is in motion.

WARNING

Changing down through the gears incor-
rectly by selecting a gear that is too low
can lead to loss of control of the vehicle and
cause accidents and serious injuries.

NOTICE

Engaging a gear that is too low when driving
at high speed or at high engine RPM can
cause considerable damage to the clutch
and gearbox. This can happen even if the
clutch pedal is kept depressed and the gear
is not engaged.

NOTICE

Consider the following to avoid damage and
premature wear:

●

Do not rest your hand on the gear lever

while driving. The pressure exerted by the
hand is transmitted to the gearbox forks.

●

Do not rest your foot on the clutch pedal;

even if the pressure seems insignificant, it
can cause premature wear of the clutch disc.
Use the footrest when not changing gears.

●

Make sure the vehicle is completely stop-

ped before engaging reverse gear.

●

When changing gears, always fully de-

press the clutch.

●

Do not “ride” the clutch with the engine

running when the vehicle is stopped on an
uphill slope.

DSG automatic transmis-
sion

Introduction

Your vehicle is equipped with an electronically
controlled manual gearbox. Torque between
the engine and the gearbox is transmitted via
two independent clutches. They replace the
torque converter found on conventional auto-
matic gearboxes and allow for smooth, uninter-
rupted acceleration of the vehicle.
The

Tiptronic

system allows the driver to

change gears

manually

›››

page 166,

Chang-

ing gear in Tiptronic mode

Gear selector positions

Fig. 119

On the centre console: selector lever.

CarManuals2.com

Driving

165

DSG automatic transmission

The gear selector position is shown by the
corresponding sign lighting up. The engaged
gear is also displayed on the screen in manual
shift positions

and

(when the

Eco

›››

page 171

engine setting is selected in the

Individual

profile).

- Parking lock

When the

button is pressed, the drive wheels

are locked. Only press

when the vehicle is

stationary

›››

To press the

button you must press the brake

pedal simultaneously.

– Reverse gear

Reverse gear must be engaged only when the
vehicle is stationary and the engine is idling

›››

To engage reverse gear

, you must press the

brake pedal simultaneously. The reverse lights
switch on when the reverse gear

is selected

and the ignition is on.

– Neutral

In this position, the gear is in neutral.
Press the brake pedal to move the lever from

D/S

when the vehicle is stationary or at

speeds below 3 km/h (2 mph)

›››

– Permanent forward drive position

The

D/S

position enables the gears to be op-

erated in normal mode (

) or sport mode (

To select Sport mode

, move the lever back-

wards. Pushing the lever again will select nor-
mal mode

. The selected driving mode is dis-

played on the instrument panel screen.
In

normal mode

(

), the gearbox selects the

best gear ratio. This depends on the engine
load, the road speed and the dynamic gear
control programme (DCP).

Sport mode

(

) should be selected for a sporty

driving style. This setting makes use of the en-
gine's maximum power output. When acceler-
ating the gear shifts will be noticeable.
Under certain circumstances (e.g. on mountain
roads) it can be advantageous to switch tip-
tronic mode

›››

page 166

, to adapt the gears

to suit the road conditions.

WARNING

●

Take care not to press the accelerator

pedal when the vehicle is stopped. The vehi-
cle could start moving immediately (in some
cases even if the parking brake is engaged)
resulting in the risk of an accident.

●

Never move the lever to position R when

driving. Failure to follow this instruction could
result in an accident or failure.

●

With lever in any position, the foot brake

must be depressed whenever the engine
is running. This is because an automatic
gearbox still transmits power even at idling
speed.

●

While you are selecting a gear and the ve-

hicle is stopped with the engine running, do
not accelerate. Failure to follow this instruc-
tion could result in an accident.

●

As a driver you should never leave your ve-

hicle if the engine is running and a gear is
engaged. Switch on the electronic parking
brake and select the parking lock (P).

Note

●

If the lever is moved accidentally to N

when driving, release the accelerator and
let the engine speed drop to idling before
selecting gear range D or S again.

●

If the power supply is interrupted while the

P parking lock is active, it will not be possible
to move the lever. If this should happen the
manual release can be used. In this case, you
should seek professional assistance.

CarManuals2.com

166

Driving

Note

●

If a gear has been selected, the vehicle

does not move forwards or back. Proceed to
the next mode:

–

When the vehicle does not move in

the required direction, the system may not
have the gear range correctly engaged.
Press the brake pedal and engage the gear
range again.

–

If the vehicle still does not move in the re-

quired direction, there is a system malfunc-
tion. Seek specialist assistance and have
the system checked.

Changing gear in Tiptronic mode

Fig. 120

Steering wheel: automatic gearbox

levers

Tiptronic gives the driver the option to change
gears manually.

When you change to the Tiptronic programme,
the vehicle remains in the currently selected
gear. This is possible as long as the system is
not changing gear automatically due to a traf-
fic situation.

Using Tiptronic with the steering wheel pad-
dles

The gear shift paddles can be used when the
selector lever is in the

D/S

position.

●

Press the

gear shift paddle to change up

a gear

›››

Fig. 120

●

Press the

–

gear shift paddle to change

down a gear.

●

To exit the Tiptronic mode, pull the right-hand

gear shirt paddle towards the steering wheel
for approximately 1 second.
To keep Tiptronic mode permanently switched
on, move the selector lever to the

position.

If the selector lever is in position

and the

gear shift paddles are not operated for some
time, the Tiptronic mode will automatically be
switched off.

NOTICE

●

When accelerating, if a higher gear is

not selected, it will automatically change
shortly before reaching the maximum per-
mitted RPM.

●

Also, if a lower gear is selected, the system

will not change until it detects that the en-
gine will not reach its maximum RPM.

Driving with an automatic gearbox

The gearbox changes gear ratios automati-
cally as the vehicle moves.
The engine can only be started with the lever in
the

position and the

button must be lit up

(the parking lock remains active).

Driving down hills

Under certain circumstances it may be advan-
tageous to use the Tiptronic mode to select the
gear manually according to driving conditions

›››

Stop/Park

To park on flat ground, just press the

›››

Fig. 119

button. On slopes the parking brake

should first be applied and then press the

button.
If the driver door is opened and the

button

has not been activated, the vehicle could move.
The following warning is displayed on the in-
strument panel:

Gear change: selec-

tor lever in the drive position!.

Additionally, a buzzer will sound.

Stopping on a downhill

Always

apply the brake pedal firmly to prevent

the vehicle from moving; if necessary, apply the
electronic parking brake

›››

CarManuals2.com

Driving

167

DSG automatic transmission

Do not

accelerate while a range of gears is en-

gaged to prevent the car from rolling downhill

›››

Starting off uphill with the Auto Hold function

●

Once you have engaged a gear, take your

foot off the brake pedal and gently press the
accelerator.

Starting off uphill without the Auto Hold
function

●

Pull on the electronic parking brake button.

●

Once you have engaged a gear, gently press

the accelerator and pull on the electronic park-
ing brake button.

WARNING

Observe the safety warnings

●

Never allow the brake to rub and do not use

the brake pedal too often or for long periods,
as the brakes can overheat. This reduces
the braking power, increases the braking dis-
tance or even causes a brake system fault.

●

If you have to stop on a hill, keep the vehi-

cle’s brakes applied with the brake pedal or
parking brake.

NOTICE

●

If you stop the vehicle on a gradient, do not

attempt to stop it from rolling by depressing
the accelerator when a gear has been selec-
ted. This could cause overheating and dam-
age the automatic gearbox.

●

If you allow the vehicle to roll with the lever

in position N and the engine off, the auto-
matic gearbox will be damaged due to a lack
of lubrication.

●

In certain driving situations or traffic condi-

tions, the gears could overheat and be dam-
aged! If the warning lamp lights up, stop
the vehicle as soon as you can and wait for
the gearbox to cool

›››

page 169

●

If the gearbox operates with the backup

programme, take the vehicle to a specialised
workshop and have the fault repaired with-
out delay.

Kick-down

The kick-down device provides maximum ac-
celeration when the gear selector lever is in the
positions

or in Tiptronic mode.

When the accelerator pedal is pressed right
down, the automatic gearbox will shift down
to a lower gear, depending on road speed
and engine speed. This takes advantage of the
maximum acceleration of the vehicle

›››

The upshift to the next higher gear is delayed
until the engine reaches maximum rpm.

WARNING

Please note that if the road surface is slip-
pery or wet, the kickdown feature could
cause the driving wheels to spin, which could
result in skidding.

Launch-control program

The Launch-control programme enables maxi-
mum acceleration from a standstill.

Condition:

the engine must have reached oper-

ating temperature and the steering wheel must
not be turned.
The engine speed for Launch-control is differ-
ent for petrol and diesel engines.
To use the Launch-control you must discon-
nect the traction control (TCS) or activate the
ESC Sport mode, using the Infotainment system
menu: press the function button

> Assis-

tants > ESC menu

. The warning lamp will

remain on.

●

Press the brake pedal with your left foot and

hold it down for at least one second.

●

Set the selector lever to position

or Tip-

tronic, or select the

Sport

driving profile from

the Drive Profile.

CarManuals2.com

168

Driving

●

With your right foot, press the accelerator

down to the full throttle or kick-down posi-
tion. The engine speed will stabilise at about

3,200

rpm (petrol engine) or about

2,000

rpm

(diesel engine).

●

Take your left foot off the brake pedal. The

vehicle starts with maximum acceleration.

WARNING

●

Always adapt your driving style to the

traffic conditions.

●

Only use the Launch control programme

when road and traffic conditions permit, and
make sure your manner of driving and accel-
erating the vehicle does not inconvenience
or endanger other road users.

●

Make sure that the ESC remains switched

on. Please note that when the TCS and ESC
are deactivated, the wheels may start to
spin, causing the vehicle to lose grip. Acci-
dent hazard!

●

After moving off, you should activate the

TCS or deactivate the ESC “sport” mode
again using the Infotainment system: func-
tion button

> Assistants

Note

●

Dynamic driving or using a launch-control

program may considerably raise the temper-
ature of the catalytic converter or gearbox.
In this case, the program may be out of serv-
ice for a few minutes. The program may be
used again once the cooling phase is com-
plete.

●

Accelerating with the Launch control pro-

gramme places a heavy load on all parts of
the vehicle. This can result in increased wear
and tear.

Inertia mode

The inertia mode allows you to travel certain
distances without using the accelerator, which
saves fuel. Plan ahead and use the inertia
mode to let the vehicle roll.

Activation of the inertia mode

Condition: lever in position

, slopes of

less than 12% and speeds between 20 and
130 km/h (12 and 80 mph).

●

Gently take your foot off the accelerator.

The indication will be shown on the instrument
panel , the engaged gear and current con-
sumption will disappear and the word

Inertia

will appear.

The gears will automatically disengage and the
vehicle will roll freely, without the effect of the
engine brake. While the vehicle rolls, the engine
runs at idling speed.

Stopping inertia mode

●

Press the brake or the accelerator pedal.

To take advantage of the engine's inertia mode,
simply remove your foot from the accelerator.
Applying both the

inertia mode

(= prolonged

section with less energy) and

inertia discon-

nection

(= shorter section without the need for

fuel) facilitates improved fuel consumption and
emission balance.
If the vehicle has

SEAT Drive Profile

›››

page 171

, the inertia mode can be acti-

vated in

Normal

Eco

and

Individual

modes.

Eco

mode, it is activated whenever the op-

erating conditions are met, regardless of the
smoothness with which the foot is removed
from the accelerator.

WARNING

●

If the inertia mode has been switched on,

take into account, when approaching an ob-
stacle, that the vehicle will not decelerate in
the usual manner: risk of accident!

●

When using inertia mode while travelling

down hills, the vehicle can increase speed:
risk of accident!

●

If other users drive your vehicle, warn them

about inertia mode.

CarManuals2.com

Driving

169

Driving on slopes

NOTICE

The operation of the inertia mode in combi-
nation with hybrid engines (MHEV and PHEV)
can cause the combustion engine to switch
off.

NOTICE

The inertia mode will be automatically dis-
connected on gradients steeper than 15%.

Troubleshooting

The engine does not start

The indicator lamp lights up green.
The brake is not depressed, e.g. when trying to
change the gear selector lever.

●

To select a gear range, press the brake

pedal.

Indications on the instrument cluster display:

Clutch

Clutch overheated! Please stop!

●

The clutch has overheated and could be

damaged. Stop and wait for the gearbox to
cool with the engine idling and press the

parking lock button. When the warning lamp
and the driver message turn off, go to a speci-

alised workshop to get the fault repaired. If they
do not turn off, do not continue driving. Seek
specialist assistance.

Faults in the gearbox

Gearbox: Fault! Stop the vehi-

cle and place the lever in the P

●

There is a fault in the gearbox. Stop the vehi-

cle in a safe place and do not continue driving.
Seek specialist assistance.

Gearbox: System fault! You may

continue driving

●

Have the fault corrected by a specialised

workshop without delay.

Gearbox: System fault! You can

continue driving with restrictions.
Reverse gear disabled

●

Take the vehicle to a specialised workshop

and have the fault repaired.

Gearbox: System fault! You can

continue driving in D until switch-
ing off the engine

●

Park the vehicle in a safe place. Seek special-

ist assistance.

Gearbox: too hot. Adapt your

driving accordingly

●

Continue driving at moderate speeds. When

the warning lamp switches off, you can con-
tinue driving in a normal manner.

Gearbox: press the brake and

engage a gear again

●

If the warning was caused by the temperature

of the gearbox, this driver message will be dis-
played when the gearbox has cooled again.

Back-up programme

If all the gear positions are shown over a light
background on the instrument cluster, there is
a system fault and the automatic gearbox will
operate with the backup programme. It is still
possible to drive the vehicle, however, at low
speeds and within a selected range of gears.

Driving in reverse gear may not be possible

Parking lock manual release mechanism

If, in the event of a power failure (e.g. the 12-volt
vehicle battery is drained), the vehicle must be
towed and the parking lock can be released
manually. In this case, you should seek profes-
sional assistance.

Driving on slopes

downhill assistant

Downhill speed control is activated when the
gear lever is in the

D/S

position and the brake is

applied. An appropriate lower gear is engaged.

CarManuals2.com

170

Driving

The assistant attempts to maintain the speed
at which the vehicle was travelling when the
brake was applied, within logical limits. It may
be necessary to correct the speed by pressing
the brake.
The assistant can only change down as far as
3rd gear. It is possible that on very steep slopes
you may have to switch to tiptronic mode and
thus manually change down to 2nd or 1st gear
to take advantage of engine braking and take
the load off the brake system.
Downhill speed control is deactivated as soon
as the road levels out again or you press the
accelerator pedal.
On vehicles with a cruise control system

›››

page 182

, downhill speed control is activa-

ted when you set a cruising speed.

WARNING

The downhill speed control cannot defy the
laws of physics. Therefore, speed cannot be
maintained constant in all situations. Always
be prepared to use the brakes!

Steering

Information relating to different vehi-
cle processes.

To make the vehicle more difficult to steal, al-
ways lock the steering before leaving the it.

Steering

On vehicles with electromechanical steering,
the power steering automatically adjusts ac-
cording to the driving speed, the steering wheel
torque and the orientation of the wheels. The
power steering only works when the engine is
running.
If the power steering does not work properly or
does not work at all, you will have to use much
more strength than usual to turn the steering
wheel.

Progressive steering

Depending on the vehicle’s features, it may or
may not incorporate a progressive steering sys-
tem.
In

city traffic

you do not need to turn so much

on parking, manoeuvring or in very tight turns.
On

roads or motorway

, progressive steering

transmits, for example, in bends, a sportier,
more direct and noticeably more dynamic driv-
ing sensation.

Steering assist

This help assists the driver in critical situations. It
recommends turning the steering wheel to per-
form a corrective manoeuvre (counter-steer-
ing), turning slightly to avoid skidding

›››

WARNING

Steering assist helps the driver in critical sit-
uations. The driver is the person who has to
control the vehicle's steering at all times.

Troubleshooting

Steering fault

The warning lamp lights up red.
There is a fault in the power steering.

●

Stop driving!

Seek specialist assistance.

●

Do not allow the vehicle to be towed on its

own wheels.

Steering fault

The control lamp lights up or flashes yellow.
The steering is stiffer or reacts more sensitively
than usual.
The control lamp

lights up and remains lit

●

Restart the engine and drive slowly for a short

distance. Contact a specialist workshop if the
control lamp remains on.

●

OR:

the 12-volt battery was disconnected

and reconnected. Drive slowly for a short dis-
tance.
The control lamp

flashes

●

Turn the steering wheel slightly from one side

to the other.

●

Turn off the ignition and turn it on again.

CarManuals2.com

Driving

171

SEAT Drive Profiles

●

Consider the warnings shown on the instru-

ment cluster display.

●

If the control lamp continues flashing after

the ignition has been switched on, do not con-
tinue driving. Seek specialist assistance.

SEAT Drive Profiles

Introduction

The driver can use the drive profiles to adapt
various features of the vehicle's systems to
the current driving situation, the desired driving
comfort and an economical driving style. Some
of the systems that can be adapted are the
suspension, steering, engine and air condition-
ing.
Depending on the vehicle’s equipment, various
drive profiles can be selected. The degree of in-
fluence of the vehicle's systems on the different
drive profiles depends on the vehicle’s equip-
ment.

Engine

Depending on the profile selected, the engine
responds more quickly or smoothly to the ac-
celerator being pressed. When the

Eco

profile is

selected, the Start-stop function is activated.
In vehicles with automatic transmission, the
gear change timing is changed to put the
changes at higher or lower revolutions. The

Eco

profile activates the Inertia function, thereby re-

ducing consumption. The rest of the driving pro-
files will activate the inertia use function when
the gear selector lever is not in the

position,

depending on how the accelerator pedal is re-
leased

›››

page 168

. When the vehicle is turned

on again, the function is activated by default to
reduce consumption.
With manual transmission, the

ECO

profile

changes the gear change recommendations to
facilitate more efficient driving.

Adaptive chassis control (DCC)

The DCC continuously adapts the damping of
the suspension system to the characteristics
of the road surface and the driving situation
(speed, acceleration and steering wheel angle)
according to the selected driving profile. The
vehicle's dynamic behaviour is also adapted to
improve grip on curves and turning capacity.
Within the

Individual

profile you can also ad-

just the DCC level in a customised manner. In
the event of a fault in the DCC, the following
message is displayed on the instrument cluster
display>

Fault: damping adjustment

Four-wheel drive (4Drive)

Modify the transmission to adjust the vehicle’s
traction capacity to the road surface. The ac-
celeration capacity from a standstill will also be
modified.

Steering

The operation of the power steering is modified
and adapted to the selected profile to offer the
best behaviour for each situation.

Air conditioning

Climatronic can operate in

Eco

mode, espe-

cially restricting fuel consumption.

Adaptive Cruise Control (ACC)

Depending on the driving profile, the perform-
ance of the ACC to allow adaptation to a
speed that is more sporty or fuel consumption-
friendly.

PreCrash system

The PreCrash system adapts according to the
selected configuration

›››

page 52

The

Sport

driving profile has specific settings to

adapt to driving characteristics.

Selecting a driving profile

The drive profile can be selected when the igni-
tion is switched on and the vehicle is stationary
or moving

›››

CarManuals2.com

172

Driving

Selecting a driving profile

●

Press the

> Drive Profile

function button.

●

OR:

Press the function button

> Vehicle

settings > SEAT Drive Profile

, available pro-

files will be displayed.

●

OR:

Press the function button , swipe your

finger horizontally across the screen to

SEAT

Drive Profile

. Press to change the driving

profile or double press on the icon to show the
available profiles.

●

OR:

With the Infotainment System turned off,

by pressing on the

SEAT Drive Profile

icon, the

available driving profiles will be displayed.

Displaying the drive profile information

●

To display more information on the selected

drive profile, press

Information

in the info-

tainment system.

Kick-down

The kick-down feature allows maximum accel-
eration

›››

page 166

If the

Eco

profile has been selected in the SEAT

Drive Profile, and the accelerator is pressed
beyond a hard point, the engine power is auto-
matically controlled to give your vehicle maxi-
mum acceleration.

WARNING

Adjusting the driving profile while driving can
distract attention from traffic and cause ac-
cidents.

●

Always drive as carefully and responsibly

as possible.

Characteristics of driving profiles

The icon of the selected profile is displayed
at all times in the upper central part of the in-
strument panel and on the Infotainment System
screen when it is turned off.

Driving pro-
file

Characteristics

Places the vehicle in a low state
of consumption, facilitating a
fuel-saving driving style that is re-
spectful to the environment.

Comfort

It permits more relaxed and com-
fortable driving, for example for
long motorway journeys.

Normal

Offers a balanced driving experi-
ence, suitable for everyday use.

Sport

Provides a complete dynamic
performance in the vehicle, ena-
bling the user a more sporty driv-
ing style.

Driving pro-
file

Characteristics

Individual

It allows you to personalise the
configuration. The functions that
can be adjusted depend on the
equipment fitted in the vehicle.

Only for models fitted with adaptive chassis con-

trol (DCC).

WARNING

Your speed and driving style must always
be adjusted to visibility, weather, and traffic
conditions.

Note

●

Regardless of the driving profile selected

when the ignition is switched off, all systems
will start up Normal mode. To select a differ-
ent driving profile, use the infotainment sys-
tem display.

●

Your speed and driving style must always

be adjusted to visibility, weather, and traffic
conditions.

●

Use of the Eco profile is not recommended

when driving with a trailer.

CarManuals2.com

Seat Leon (2023 year). Manual in english - page 5
