to remove the valve

cap. Place it on a clean surface.

●

Shake the tyre sealant bottle vigorously

●

Screw the tyre inflation hose

into the tyre sealant bottle. The bottle's seal will
break automatically.

●

Remove the filler cap

and

screw the open end of the tube into the tyre
valve.

●

With the bottle upside down, empty

all

of the

contents into the tyre.

●

Remove the bottle from the valve.

●

Replace the howitzer with the device

onto the tyre valve.

Inflating the tyre

●

Screw the tyre inflation tube of the compres-

sor

on the tyre valve.

●

Check that the air evacuation screw is

closed

●

Start the engine and leave it running.

●

Attach the connector

to the

vehicle’s 12 volt power outlet

page 179

●

Switch on the air compressor with ON/OFF

switch

●

Keep the air compressor running until it rea-

ches a pressure of 2.0-2.5 bar (29-36 psi/
200-250 kPa).

A maximum of 8 minutes

●

Disconnect the air compressor.

●

If it does not reach the pressure indicated,

unscrew the tyre inflator tube from the valve.

●

Move the vehicle 10m so that the sealant is

distributed throughout the tyre.

●

Screw the compressor tyre inflator into the

valve.

●

Repeat the inflation process.

●

If it still does not come up to pressure, the

tyre is too badly damaged. Stop and seek as-
sistance from authorised personnel.

●

Disconnect the air compressor. Unscrew the

tyre inflation tube from the tyre valve.

●

When the tyre pressure is between 2.5 and

2.0 bars, continue driving without exceeding
80 km/h (50 mph).

●

Attach the sticker

to the instru-

ment panel display, within the driver's field of
vision.

●

Check the pressure again after 10 minutes

page 300

WARNING

When inflating the wheel, the air compressor
and the inflator tube may become hot.

●

Protect hands and skin from hot parts.

●

Do not place the hot flexible inflator tube

or hot air compressor on flammable material.

●

Allow them to cool before storing the de-

vice.

●

If it is not possible to inflate the tyre to at

least 2.0 bars (29 psi / 200 kPa), the tyre is
too badly damaged. The sealant is not in a
good condition to seal the tyre. Do not con-
tinue driving. Seek specialist assistance.

300

Wheels and tyres

NOTICE

Switch off the air compressor after a maxi-
mum of 8 operational minutes to avoid over-
heating! Before switching on the air com-
pressor again, let it cool for several minutes.

Check after 10 minutes of driving

Screw in the inflator tube

again

and check the pressure on the gauge

1.3 bar (19 psi / 130 kPa) and lower:

●

Stop the vehicle!

The tyre cannot be sealed

sufficiently with the tyre mobility set.

●

You should obtain professional assistance

1.4 bar (20 psi/140 kPa) and higher:

●

Set the tyre pressure to the correct value

again.

●

Carefully resume your journey until you reach

the nearest specialised workshop without ex-
ceeding 80 km/h (50 mph).

●

Have the damaged tyre replaced.

WARNING

Driving with an unsealed tyre is dangerous
and can cause accidents and serious injury.

●

Do not continue driving if the tyre pressure

is 1.3 bar (19 psi / 130 kPa) and lower.

●

Seek specialist assistance.

Maintenance

301

Service

Maintenance

Service

Service work and the Digital Mainte-
nance Plan

Log of services performed (“Digital Mainte-
nance Plan”)

The SEAT dealership or a specialised workshop
records Service receipts in a central system.
Thanks to this comprehensive documentation
of the service history, it is possible to reproduce
the services performed any time. SEAT recom-
mends requesting a Service receipt after every
service carried out containing all the services
carried out on the system.
Whenever there is a new service the receipt is
replaced with a current one.

The Digital Maintenance Plan is not availa-
ble in some markets. In this case, your SEAT
dealer will inform you about the current
documentation of the work.

Service works

In the Digital Maintenance Plan, your SEAT au-
thorised service or specialised workshop docu-
ments the following information:

●

When each one of the services was carried

out.

●

Whether a specific repair has been sugges-

ted, e.g. changing the brake pads in the near
future.

●

If you have expressed a special request for

the maintenance. Your Service Advisor will write
the work order.

●

The components or fluids that were changed.

●

The date of the next service.

The Long Life Mobility Warranty is valid until the
next inspection. This information is documented
in all checks performed.
The type and the volume of the service may
vary from one vehicle to another. A specialised
workshop will be able to provide specific infor-
mation on the jobs for your vehicle.

WARNING

If the services are insufficient or not per-
formed and if the service intervals are not
observed, the vehicle may be immobilised in
traffic cause an accident and severe injuries.

●

Make sure that any repairs are carried out

by a SEAT authorised service or specialised
workshop.

NOTICE

SEAT cannot be held liable for any damage
to the vehicle due to insufficient work or of
lack of availability of spare parts.

Note

Regular services on the vehicle not only
maintain its value, but also its correct opera-
tion and road safety. For this reason, conduct
the services in accordance with SEAT guide-
lines.

Set Service or Flexible Service Inter-
vals

Services are classified as

oil change service

and

inspection

. The service interval display

on the instrument panel display serves as a re-
minder of the next service.
Depending on the features, the engine and the
conditions of use of the car, either the

Fixed

service

or the

Flexible service

will be applied

for an oil change service..

How to know which type of service needs to
his vehicle

Check the tables below:

302

Maintenance

Oil change service

PR No.

Type of
service

Service interval

QI1

Fixed

Every

5000 km

or after

QI2

Every

7500 km

or after

QI3

Every

10000 km

or after

QI4

Every

15000 km

or after

QI6

Flexible

According to the service in-
terval display.

The data are based on normal conditions of use.

Whatever happens first.

Inspection Service

According to the service interval display.

The data are based on normal conditions of use.

Particular characteristics of the Flexible
Service

Regarding the

Flexible Service

the oil change

service only has to be performed when the ve-
hicle needs it. To calculate when you have to
carry out this service, take into account the in-
dividual conditions of use and personal driving

style. A major component of the flexible service
the use of LongLife oil instead of conventional
engine oil.
Bear in mind the information about the specifi-
cations of the engine oil according to the VW
standard

page 275

If you do not want to the flexible service you
can select the fixed service. However, a fixed
service may affect service costs.

The Service

Advisor will gladly advise you.

At SEAT, the dates of the services are indicated
by the service intervals display:

●

on the instrument panel

page 29

●

in the infotainment system: menu

> Set-

tings > Service

;

> Vehicle sta-

tus > Service

page 35

The service interval display gives information
for service dates that involve an engine oil
change or an inspection. When the time for the
corresponding service comes, additional work
required, such as the change of brake fluid and
the spark plugs, can be carried out.

Information about the terms of use

The service intervals and groups are usually
based on

normal conditions of use

If, on the other hand, the vehicle is under

ad-

verse conditions of use

, some of the work

must be carried out before the next service pe-
riod or even between service intervals.

Conditions of use adverse include:

●

The use of fuel with a high sulphur content.

●

Frequent short trips.

●

Letting the engine idle for a long period of

time, as in the case of taxis.

●

Using the vehicle in areas with thick dust.

●

Frequent driving with a trailer (depending on

equipment).

●

Using the vehicle mostly in situations with a

lot of traffic and stops (e.g. in the city).

●

Using the vehicle mostly in winter.

This applies especially for the following
parts (depending on equipment):

●

Dust and pollen filter

●

Air Care allergen filter

●

Air filter

●

Toothed chain

●

Particulate filter

●

Engine oil

The Service Advisor of your specialised
workshop will gladly inform you

about the

need of performing service work between nor-
mal service intervals, always considering the
conditions of use of your vehicle.

Maintenance

303

Additional service offers

WARNING

If the services are insufficient or not per-
formed and if the service intervals are not
observed, the vehicle may be immobilised in
traffic and cause accidents and severe inju-
ries.

●

Have the services conducted at authorised

SEAT services or specialised workshops.

NOTICE

SEAT cannot be held liable for any damage
to the vehicle due to insufficient work or of
lack of availability of spare parts.

Service sets

Sets of services include all the

maintenance

works

needed to ensure the safety and the

smooth running of the vehicle (

depending on

the conditions of use and the features of the
vehicle

, such as the engine, gearbox, or oper-

ating fluids).
Maintenance services are divided into

inspec-

tion

and

review

services. Consult the details of

the jobs required for your vehicle at:

●

Your SEAT authorised service

●

Your specialised workshop

Due to technical reasons (continuous develop-
ment of components) the sets of services may
vary. Your SEAT authorised service or special-
ised workshop is always receiving updates in
time.

Additional service offers

Approved spare parts

Original SEAT Spare Parts have been con-
ceived for their vehicles and approved by SEAT,
with a special emphasis on safety. These parts
correspond exactly to the manufacturer's re-
quirements in terms of design, accuracy of the
measurements and materials. The original SEAT
Spare Parts have been conceived exclusively
for your vehicle. For this reason, we always rec-
ommend the use of Original SEAT Spare Parts.
SEAT cannot be held liable for the safety and
suitability of parts from other manufacturers.

Approved spare parts

Approved spare parts, following the manufac-
turer's requirements, are an additional service
to you, offering the possibility of replacing com-
plete sets, such as: light engine, gearboxes,
heads, control units, electrical components,
etc.
These parts are,

approved parts

, and are the

same as the factory parts, which are also ap-
proved spare parts.

Original accessories

We recommend you only use SEAT Original Ac-
cessories and SEAT approved accessories for
your vehicle. The reliability, safety and suitabil-
ity of these accessories have been inspected
specifically for this type of vehicle. SEAT cannot
be held liable for the safety and suitability of
parts from other manufacturers.

Service Mobility

As of the moment you purchase your SEAT ve-
hicle you will be able to enjoy the benefits and
coverage of Service Mobility.
For the first two years after the purchase, your
new SEAT vehicle is automatically covered by
Service Mobility at no additional cost.
If you wish to enjoy this service after this period,
you can extend SEAT Service Mobility as long
as you carry out the recommended Inspection
and Maintenance Services at a SEAT Author-
ised Service.
If your SEAT vehicle is immobilised due to a fault
or an accident, our assistance services will help
you keep moving.
Take into account that the SEAT Mobility Serv-
ice differs depending on the country in which
the vehicle was purchased. For further informa-
tion ask your SEAT dealership or the SEAT web-
site in your country.

304

Maintenance

Vehicle upkeep and clean-
ing

Basic observations

Regular and careful care helps to maintain the
value of your vehicle. In addition, it may be-
come a prerequisite to demand the warranty
in the event of corrosion damage and deficien-
cies in the paint coat of the bodywork.
Specialised workshops have the necessary
care products. Please follow the instructions for
application on the packaging.

WARNING

●

Cleaning products and other materials

used for car care can be damaging to your
health if misused.

●

Always keep care products in a safe place,

out of the reach of children. Danger of poi-
soning!

For the sake of the environment

●

When purchasing car care products, chose

products that are compatible with the envi-
ronment.

●

The waste from car-care products should

not be disposed of with ordinary household
waste.

Washing the vehicle

The longer you take to clean the tanks, e.g. re-
mains of insects, bird excrements, tree resin or
anti frost salt adhered to your vehicle, the more
damage it can cause to the surface. High tem-
peratures, for instance strong sunlight, further
intensify the damage.
Before washing the car, soften the dirt using
plenty of water.
To remove encrusted dirt such as insects, bird
droppings or tree resin, use a lot of water and a
microfibre cloth.
Have the underside of the vehicle washed after
the end of the anti frost salts in winter.

High pressure cleaning equipment

When washing the vehicle with a high-pressure
cleaner, always follow the operating instruc-
tions for the equipment. This applies particu-
larly to the operating pressure and the distance
between the spraying water.
Do not point the jet directly towards the side
windows, doors or covers; the same applies for
the tyres, rubber hoses, damping material, sen-
sors or camera lenses. Keep a distance of at
least 40 cm.
Do not remove snow and ice with a high-pres-
sure cleaner.
Do not use a nozzle that sprays the water out in
a direct stream or one that has a rotating jet for
forcing off dirt.

The water temperature must not exceed 60°C.

Automatic car washes

Spray the vehicle before starting the car wash.
Make sure that the windows are closed and
the windscreen wipers are deactivated. Bear
in mind the instructions of the car wash tunnel
operator, especially if your vehicle has detach-
able parts.
Use of car washes without brushes if possible.

Washing by hand

Clean your vehicle from top to bottom with a
soft sponge or with a brush. Only use cleaning
products that do not contain solvents.

Polishing

Polishing is only necessary when the vehicle's
paintwork has lost its gloss and cannot be re-
stored with care products.
Do not polish matt painted surfaces! If the
paintwork is polished, the surface will be irrep-
arably damaged.

Washing vehicles with a matte paint by hand

To prevent damage to the vehicle when wash-
ing it, first remove the thicker dust and dirt.
To remove traces of insects, grease and finger-
prints, it is best to use a special cleaner for
matte paint.

Maintenance

305

Vehicle upkeep and cleaning

Neutral soap solution: maximum of two tablespoons in 1 l of water.

Apply the product with a microfibre cloth. To
avoid damaging the surface of the paint, do not
apply too much pressure.
Rinse with plenty of water. Then clean it with a
neutral cleaning product and a soft microfibre
cloth.
Rinse the vehicle again with plenty of water and
then leave it to dry. Remove traces of water
with a leather cloth.

WARNING

●

Only wash the vehicle with the ignition

switched off or according to the specifica-
tions of the car wash tunnel operator. Acci-
dent hazard!

●

When cleaning the underbody or the inside

of the wheel arches, protect yourself from
sharp or pointy metal parts. Risk of cut!

●

After cleaning the brakes could act more

slowly due to moisture or, in winter, the ice on
the brake discs and pads. Accident hazard!
In this case the brakes should be dried by
pressing the brake pedal several times.

WARNING

Incorrect use of high-pressure cleaning
equipment can cause damage. This can lead
to accidents and serious injuries.

●

Never direct the jet of the high-pressure

cleaning equipment directly at the orange
high-voltage cables, the high-voltage sys-
tem components or the 12-volt on-board net-
work.

NOTICE

●

Before washing the vehicle in an automatic

car wash, please make sure to retract the
exterior mirrors to prevent them from being
damaged. The electric folding exterior mir-
rors should only be folded/unfolded electri-
cally!

●

Do not wash the vehicle in direct sunlight.

Risk of damaging the paint job!

●

Do not use sponges, abrasive household

sponges or similar to clean insect remains.
Risk of damaging the surface!

●

Vehicle parts with matte paint:

–

Do not use polish or hard wax. Risk of

damaging the surface!

–

Never select washing programmes that

include the use of wax. This could damage
the appearance of matte paint.

–

Do not put stickers or magnets on parts

with matte paint, as removing them may
damage the paint.

For the sake of the environment

The car should only be washed in special
wash bays. These places are prepared to
prevent oily water from getting into the pub-
lic drains.

Cleaning the exterior

Below can be found some recommendations on
the cleaning and upkeep of individual vehicle
components.
Go to your specialised workshop if you have
special questions or parts that are not listed.
Take the general considerations into account

Take special care with...

page 307,

Windscreen wipers

●

Dirt:

Soft cloth with windscreen cleaner.

Headlights / Tail lights

●

Dirt:

Soft sponge with neutral soap solution

306

Maintenance

Neutral soap solution: maximum of two tablespoons in 1 l of water.

Sensors / Camera lenses

●

Dirt:

–

Sensors

: soft cloth with a solvent-free

cleaning product.

–

Camera lenses

: soft cloth with an alcohol-

free cleaning product.

●

Snow/ice:

Hand brush/Solvent-free antifreeze

spray

Wheels

●

Antifreeze salt:

Water.

●

Brake abrasion dust:

Special acid-free clean-

ing product.

End exhausts

●

Antifreeze salt:

Water, if a fine steel cleaning

product is required, or a non-abrasive and non-
corrosive cleaning product.

Covers / Trims

●

Dirt:

Neutral soap solution

, if a fine steel

cleaning product is required.

Paint

●

Paint flaws:

Check the paint's colour code at

an authorised service and restore with a touch-
up pencil.

●

Spilled fuel:

Immediately rinse with water.

●

Tank with environmental rust:

Apply rust re-

mover and then apply hard wax. Go you your
specialised workshop if you have any queries.

●

Corrosion:

Have your specialised workshop

take care of this.

●

Water does not form droplets on the clean

paint:

Maintain with hard wax (at least twice a

year).

●

No shine despite maintenance/unattractive

paint:

Treat with suitable wax and apply paint

preservative afterwards if the wax used does
not contain preservative ingredients.

●

Tanks, e.g. insect remains, bird droppings, tree

sap, road salt:

Immediately soak with water and

remove with a microfibre cloth.

●

Grease-based dirt, e.g. cosmetic products or

sunscreen:

Remove immediately with a neutral

soap solution

and a soft cloth.

Carbon fibre parts

●

Dirt:

Clean in the same way as painted parts

page 304

Decoration slides

●

Dirt:

Soft sponge with neutral soap solution

Interior cleaning

Take special care with...

page 307,

Windows

●

Dirt:

Apply windscreen cleaner and then dry

with a cloth.

Covers / Trims

●

Dirt:

Neutral soap solution

Plastic parts

●

Dirt:

Damp cloth.

●

Encrusted dirt:

Neutral soap solution

, if possi-

ble a solvent-free plastic cleaning product.

Displays/instrument panel

●

Dirt:

Soft cloth with a liquid crystal display

cleaner.

Control panels

●

Dirt:

Soft brush, then a soft cloth with a neu-

tral soap solution

Maintenance

307

Vehicle upkeep and cleaning

Neutral soap solution: maximum of two tablespoons in 1 l of water.

Seat belts

●

Dirt:

Neutral soap solution

, allowed to dry

before retracting.

Fabrics, artificial, Alcantara leather

●

Particles of dirt stuck to surfaces:

Vacuum

cleaner.

●

Water-based dirt, e.g. coffee, tea, blood etc.:

Absorbent cloth and neutral soap solution

●

Grease-based dirt, e.g. oil, make-up, etc.:

Ap-

ply a neutral soap solution

. Absorb the dis-

solved grease and paint particles drying with
an absorbent cloth, in case you must treat it
with water afterwards.

●

Special dirt, e.g. pens, nail polish, dispersion

paint, shoe polish, etc.:

Special stain remove:

dry with an absorbent cloth, if applicable, ap-
ply neutral soap solution afterwards

Natural leather

●

Recent dirt:

Cotton cloth with neutral soap

solution

●

Water-based dirt, e.g. coffee, tea, blood etc.:

–

Recent stains:

absorbent cloth.

–

Dry stains:

stain remover suitable for

leather.

●

Grease-based dirt, e.g. oil, make-up, etc.:

–

Recent stains:

absorbent cloth and suitable

stain remover for leather.

–

Dry stains:

grease solvent spray.

●

Special dirt, e.g. pens, nail polish, dispersion

paint, shoe cream etc.:

Stain remover suitable

for leather.

●

Care:

Apply preservative cream regularly to

protect from sunlight. Use a coloured preserva-
tive if required.

Carbon fibre parts

●

Dirt:

Clean as with plastic parts.

Take special care with...

Headlights/tail lights

●

Do not clean the headlights/tail lights with a

dry cloth or sponge.

●

Do not use cleaning products that contain

alcohol. Risk of cracks!

Wheels

●

Do not use for paint wax or other abrasive

products.

●

If the protective coating on the paint of the

rim has been damaged due to stone impacts,
scratches, etc., the damage should be repaired
immediately.

Camera lenses

●

Do not use hot or warm water to remove ice

or snow from the camera lenses. Risk of crack-
ing the lens!

●

To clean the camera lens, never use abra-

sive cleaning products or products with alcohol.
Risk of scratches and cracks!

Windows

●

Remove snow and ice from windows and ex-

terior mirrors with a plastic scraper only. To
avoid scratches, the scraper should only be
pushed in one direction and not moved to and
fro.

●

Never remove snow or ice from windows and

rearview mirrors with warm or hot water. Risk of
cracks on the windows!

●

To prevent damage to the heating of the rear

window, do not put stickers over the heating
elements.

Covers/trims

●

Do not use cleaning products or chrome

based cleaning agents.

Paint

●

The vehicle must be free from dirt and dust

before applying wax or care products. Risk of
scratches!

308

Maintenance

●

Do not apply wax or care products if the vehi-

cle is exposed to direct sunlight. Risk of damag-
ing the paint job!

●

The ambient rust deposits must not be re-

moved through friction. Risk of damaging the
paint job!

●

Remove cosmetic products and sunlight im-

mediately. Risk of damaging the paint job!

Displays/instrument panel

●

The displays, the instrument panel and the

trim around it must not be cleaned dry. Risk of
scratches!

●

Make sure that the instrument panel is

switched off and cooled down before cleaning.

●

Make sure that no liquid leaks between the

instrument panel and the trim. Risk of damage!

Control panels

●

Make sure that no liquid leaks into the control

panels. Risk of damage!

Seat belts

●

Do not remove the seat belts to clean them.

●

Seat belts and their components must never

be cleaned with chemical products, nor should
they be allowed to come into contact with cor-
rosive liquids, solvents or sharp objects. Risk of
damaging the fabric!

●

If you find any damage to the belt webbing,

belt fittings, the belt retractor or the buckle, ask
your specialised workshop to replace the belt
in question.

Fabrics/artificial leather/microfibre

●

Do not treat artificial leather/microfibre with

leather cleaning products, solvents, wax polish,
shoe cream, stain removers or similar products.

●

If the stain is very hard to remove, take the

vehicle to a specialised workshop to have it re-
moved there. This will prevent damage.

●

Do not use steam cleaners, brushes, hard

sponges, etc. to clean.

●

Do not turn on seat heating to dry the seats.

●

Sharp objects on clothing, such as zips, rivets

or belts can damage the surface.

●

Open Velcro, e.g. on clothes can damage the

seat upholstery. Make sure that Velcro fasten-
ers are closed.

Natural leather

●

Never use solvents, wax polish, shoe cream,

spot removers or similar products on leather.

●

Sharp objects on clothing, such as zips, rivets

or belts can damage the surface.

●

Do not use steam cleaners, brushes, hard

sponges, etc. to clean.

●

Do not turn on seat heating to dry the seats.

●

Avoid exposing leather to direct sunlight for

long periods, otherwise it may tend to lose
some of its colour. If the car is left for a pro-
longed period in the bright sun, it is best to
cover the leather.

WARNING

Do not use water-repellent coatings on the
windscreen. In bad visibility conditions such
as humid weather, darkness or when the sun
is in its lowest point, visibility may be impac-
ted. Accident hazard! Such coatings can also
cause the windscreen wiper blades to make
noise.

Note

●

Remains of insects can be removed much

more easily with previously treated paint.

●

Regular car care treatments can prevent

deposits of ambient rust.

Remove the vehicle from traffic

If you want to leave your vehicle stationary
for a long period of time, contact a qualified
workshop. They will gladly inform you about
the necessary measures, such as anti-corrosion
protection, Service and storage.
Also take into account the indications relat-
ing to the vehicle’s battery

Maintenance

309

Accessories, spare parts and repair work

Accessories, spare parts
and repair work

Introduction

Always ask your dealer or specialist retailer for
advice before purchasing accessories and re-
placement parts.
Your vehicle is designed to offer a high standard
of active and passive safety. For this reason, we
recommend that you ask a SEAT Official Serv-
ice for advice before fitting accessories or re-
placement parts. Your SEAT Official Service has
the latest information from the manufacturer
and can recommend accessories and replace-
ment parts which are suitable for your require-
ments. They can also answer any questions
you might have regarding official regulations.
We recommend only using

SEAT accessories

and

genuine SEAT parts

®. SEAT has tested

these parts and accessories for suitability, reli-
ability and safety. SEAT Official Services have
the necessary experience and facilities to en-
sure that the parts are installed correctly and
professionally.
Although SEAT continuously monitors the mar-
ket, it cannot judge whether products

not au-

thorised by SEAT

meet the vehicle’s reliability,

safety and suitability requirements. SEAT there-
fore accepts no liability for these products,
even if, in certain cases, they are authorised
by an officially recognised technical inspection
institute or official body.

Any

retro-fitted equipment

which has a di-

rect effect on the vehicle and/or the way it
is driven, such as a cruise control system

electronically-controlled suspension

, must

be approved for use in your vehicle and bear
the

mark (the European Union's authorisation

symbol).
If

any additional electrical devices

are fitted

which do not serve to control the vehicle itself
(for instance a refrigerator box, laptop or venti-
lator fan, etc.), they must bear the marking
(manufacturer conformity declaration in the Eu-
ropean Union).

WARNING

Accessories, for example telephone holders
or cup holders, should never be fitted on the
covers, or within the working range of the air-
bags. Otherwise, there is a danger of injury if
the airbag is triggered in an accident.

Technical modifications

Unauthorised modifications to the electronic
components, software, wiring or data transfer
in the vehicle may cause malfunctioning.
You will appreciate that your SEAT dealership
cannot be held liable for any damage caused
by modifications and/or work performed incor-
rectly.
For this reason we recommend asking official
SEAT service centres to do any necessary work
using

genuine SEAT

parts®.

WARNING

Incorrectly performed modifications or other
work on your vehicle can lead to malfunc-
tions and cause accidents.

Radio telephones and office equip-
ment

Radio transmitters (fixed installation)

Any retrofit installations of radio transmitters
in the vehicle require prior approval. SEAT gen-
erally authorises in-vehicle installations of ap-
proved types of radio transmitters provided
that:

●

The antenna is installed correctly.

●

The aerial is installed on the exterior of the

vehicle (and shielded cables are used together
with non-reflective aerial trimming).

●

The effective transmitting power does not ex-

ceed 10 Watts at the aerial base.
A SEAT Official Service and specialised work-
shop will be able to inform you about options
for installing and operating radio transmitters
with a higher transmitting power.

Mobile radio transmitters

Commercial mobile telephones or radio equip-
ment might interfere with the electronics of your
vehicle and cause malfunctions. This may be
due to:

310

Maintenance

●

No external aerial.

●

External aerial incorrectly installed.

●

Transmitting power more than 10 W.

You must, therefore, do not operate portable
mobile telephones or radio equipment

inside

the vehicle

without a properly installed external

aerial

Please note also that the maximum range of
the equipment can only be achieved with an

external

aerial.

Business equipment

Retrofit installation of business or private equip-
ment in the vehicle is permitted, provided the
equipment cannot interfere with the driver's im-
mediate control of the vehicle and that any
such equipment carries the mark. Any retro-
fit equipment that could influence the driver's
control of the vehicle must have a type appro-
val for your vehicle and must carry the

mark.

WARNING

Mobile telephones or radio equipment which
is operated inside the vehicle without a prop-
erly installed external aerial can create ex-
cessive magnetic fields that could cause a
health hazard.

Note

●

The posterior fitting of electric and elec-

tronic equipment in this vehicle affects its li-
cence and could lead to the withdrawal of
the vehicle registration document under cer-
tain circumstances.

●

Please use the mobile telephone/radio op-

erating instructions.

Information for the user

311

Vehicle antennas

Information for the user

Warranty

Fault-free operation warranty

SEAT Authorised Services ensure the perfect
condition of new vehicles. Check the purchase
agreement or complementary additional docu-
mentation provided by your Technical Service
to see the conditions and the terms of the war-
ranty. Consult further information in this regard
in your SEAT Official Service.

Information stored by the
control units

Storage of accident data (Event Data
Recorder)

Your vehicle has an event data recorder (EDR).
The EDR’s function is to record data in the event
of a mild or serious accident. These data are
used to support the analysis of how different
vehicle systems behaved.
The EDR records, over a reduced time range
(normally 10 seconds or less), dynamic driving
data and data from the restraint systems, such
as:

●

How different vehicle systems worked.

●

Whether the driver and the occupants were

wearing their seat belts.

●

How hard the acceleration or brake pedal

was pressed.

●

Vehicle speed.

●

GPS position.

These data will provide a better understanding
of the circumstances of the accident.
Data from the driving assist systems are also
recorded. This includes data such as whether
the systems were inactive or active and if such
action had an impact on the vehicle’s dynamic
behaviour, changing its path in the aforemen-
tioned situations, accelerating or decelerating
the vehicle.
Depending on vehicle equipment, this includes
data from systems such as:

●

the adaptive cruise control

●

the lane assist system

●

parking assistants

●

the emergency brake functions.

The EDR data are only recorded in specific ac-
cident situations. No data are recorded in nor-
mal driving conditions.
No audio or video data inside or around the
vehicle are recorded. Under no circumstances
are personal data such as name, age, or gen-
der recorded. Nevertheless, third parties (such
as criminal proceedings authorities) may relate

the contents of the EDR data to other data
sources and create a personal reference in the
context of an accident investigation.
In order to read the EDR data it is necessary
to access (if legally permitted to do so) the
vehicle's ODB (“On-Board-Diagnose”) interface
while the vehicle is switched on.
SEAT will not have access to EDR data unless
the owner (or, in “Leasing” cases, the lessee or
hirer) gives their consent. There may be excep-
tions to this, depending on legal or contractual
provisions.
Due to legal requirements in safety-related
products, SEAT may use the EDR data for field
research and in order to improve vehicle system
quality. Any data used for the purposes of re-
search will be treated anonymously (in other
words, no reference will be made to the vehicle,
their owner or the lessee/hirer).

Vehicle antennas

Infotainment system and antennas

The infotainment system's antennas are instal-
led on different locations on the vehicle:

●

On the roof.

●

On the windscreen, between the layers of

glass.

●

On the rear and side windows with a printed

antenna structure

312

Information for the user

NOTICE

The printed antenna structure on the rear
and side windows can be damaged by ob-
jects rubbing against it or by the use of
corrosive products, or products containing
acids.

●

Do not apply any stickers to the rear and

side window areas.

●

Never clean the antenna structure with

corrosive or acidic products.

Materials and recycling in-
formation

Environmental compatibility

Environmental protection is a top priority in the
design, choice of materials and manufacture of
your new SEAT.

Constructive measures to encourage recy-
cling

●

Joints and connections designed for easy

dismantling.

●

Modular construction to facilitate disman-

tling.

●

Increased use of single-grade materials.

●

Plastic parts and elastomers are marked in

accordance with ISO 1043, ISO 11469 and ISO
1629.

Choice of materials

●

Use of recycled materials.

●

Use of compatible plastics in the same part if

its components are not easily separated.

●

Use of recycled materials and/or materials

originating from renewable sources.

●

Reduction of volatile components, including

odour, in plastic materials.

●

Use of CFC-free coolants.

Ban on heavy metals, with the exceptions
dictated by law (Annex II of ELV Directive
2000/53/EC)

: cadmium, lead, mercury, hexa-

valent chromium.

Manufacturing methods

●

Reduction of the quantity of thinner in the

protective wax for cavities.

●

Use of plastic film as protection during vehi-

cle transport.

●

Use of solvent-free stickers.

●

Use of CFC-free coolants in cooling systems.

●

Recycling and energy recovery from residues

(RDF).

●

Improvement in the quality of waste water.

●

Use of systems for the recovery of residual

heat (thermal recovery, enthalpy wheels, etc.).

●

The use of water-soluble paints.

Recycling of electrical or electronic
devices

All electrical or electronic devices (EED) that
are not permanently fitted in the vehicle must
be marked with the following symbol:

This symbol indicates that EED must not be dis-
carded as home waste but through selective
waste collection.

Product recycling

Information for the user

313

Radioelectrical equipment

For the sake of the environment

The Triman logo and the Infotri symbol con-
tain important information for the classifica-
tion of the end consumer.

Italy. Environmental labelling

Legislative decree no. 116 (3 September 2020),
which transposes EU Directive 2018/851 on
waste, and EU Directive 2018/852 on packag-
ing and packaging waste, states that all pack-
aging must be properly labelled to facilitate
the collection, reuse, recovery and recycling of
packaging, and to give users correct informa-
tion about the final destination of the packag-
ing.
Information about the environmental labelling
of packaging present in the vehicle can be
accessed by scanning the following QR code,
which links to a website where the information
required by this regulation can be found:

Radioelectrical equipment

Simplified declaration of conformity

Your vehicle has different radioelectrical de-
vices. The manufacturers of these devices
declare that they comply with Directive
2014/53/EU when legally required.
The full text of the EU compliance declaration is
available online at the following address:

www.seat.com/generalinfo

United Kingdom

Your vehicle has different radioelectrical devi-
ces. The manufacturers of these devices de-
clare that they comply with the UK Radio
Equipment Regulations 2017 (SI 2017/1206) if
required by law.
The full text of the declaration of conformity
is available online at the following Internet ad-
dress:

www.seat.com/generalinfo

Ukraine

Your vehicle has different radioelectrical devi-
ces. The manufacturers of these devices de-
clare that they comply with Ukraine Decree
355/2017 (TR Radio Equipment) where legally
required.
The full text of the declaration of conformity
is available online at the following Internet ad-
dress:

www.seat.com/generalinfo

Addresses of the manufacturers

The address of the manufacturers of compo-
nents that, due to their size or nature, cannot
include a sticker are listed below, as long as it is
legally required:

Central control unit (BCM)

Robert Bosch GmbH/Braunschweig
Theodor-Heuss-Strasse 12
38122 - Braunschweig, Germany
Phone: 0049 53188890

Keyless Access System

HELLA GmbH & Co. KGaA/Hamm
Roemerstr. 66
59075 - Hamm, Germany
Phone: 0049 23817980

314

Information for the user

Roof antenna

ASK Industries S.p.A
Via dell'Industria n.12/14/16
60037 Monte San Vito (AN), Italy
Phone: +3907174521
Website: www.askgroup.it

Mitsumi Electronics Europe GmbH
Siemensstrasse 32
63225 Langen, Germany
Phone: +49 (0) 6103913-0
Website: www.minebeamitsumi.co.jp

Molex CVS Hildesheim GmbH
Daimlerring 31
31135 Hildesheim, Germany
Phone: +49 3377 3160
Website: www.molex.com

Antenna amplifiers

ASK Industries S.p.A
Via dell'Industria n.12/14/16
60037 Monte San Vito (AN), Italy
Phone: +3907174521
Website: www.askgroup.it

Hirschmann Car Communication GmbH
Stuttgarter Strasse 45-51
72654 Neckartenzlingen, Germany
Phone: +49 7127 140
Website: www.te.com

KATHREIN Automotive GmbH
Römerring 1

31137 Hildesheim, Germany
Phone: +498,031,184-0
Website: www.kathrein.com

Molex CVS Hildesheim GmbH
Daimlerring 31
31135 Hildesheim, Germany
Phone: +49 3377 3160
Website: www.molex.com

Navigation antenna

Hirschmann Car Communication GmbH
Stuttgarter Strasse 45-51
72654 Neckartenzlingen, Germany
Phone: +49 7127 140
Website: www.te.com

KATHREIN Automotive GmbH
Römerring 1
31137 Hildesheim, Germany
Phone: +498,031,184-0
Website: www.kathrein.com

Connectivity Box

Molex CVS Dabendorf GmbH
Märkische Strasse 72
15806 Zossen OT Dabendorf, Germany
Phone:+49 3377 3160
Website: www.molex.com

Basic infotainment system

Panasonic Automotive Systems Czech
U Panasonicu 266
530 06, Pardubice, Czech Republic

Optional infotainment system

LG Electronics Mlawa SP
LG Electronics 7
06 500, Mlawa

Remote control key

Digades GmbH Digitales Und Ana/Zittau
Äußere Weberstr. 20
02763 - Zittau, Germany
Phone: 0049 358357750

Instrument panel

Analogue SE38x/SE316

Visteon Electronics Germany GmbH
Visteonstr. 4-10
50170 Kerpen, Germany

Analogue all other models

Continental Automotive Spain, S.A.
Crta. de Rubí a Ullastrell, nº 12-30
08191 Rubí (Barcelona - Spain)

Information for the user

315

Radioelectrical equipment

The commissioning or authorisation of radioelectrical technology may be restricted in some European countries, forbidden or only allowed with additional
requirements.

FPK (digital)

Continental Automotive GmbH
VDO-Strasse 1,
64832 Babenhausen, Germany

Panasonic Automotive Systems Europe GmbH
Robert Bosch Str. 27-29
63225 Langen, Germany

Panasonic Automotive Systems Czech, s.r.o.
U Panasonicu 266
530 06, Pardubice, Czech Republic

Front radar sensors

MRR for SE38X

Robert Bosch GmbH
Markwiesenstrasse, 46
72770 Reutlingen (Kusterdingen) Germany

MRR for Tarraco, Ateca, Ibiza, Arona

Automotive Distance Control Systems GmbH
Peter-Dornier-Strasse, 10
88131, Lindau, Germany

Rear radar sensors

Hella GmbH & Co. KGaA
Rixbecker Straße 75
59552 Lippstadt (Germany)

Online Connectivity Unit

LG ELECTRONICS INC.
10, Magokjungang 10-ro,
Gangseo-gu, Seoul, Republic of Korea

Radio equipment, frequency band,
maximum transmitting power

Below can be found details of the radio equip-
ment

that can be fitted to all SEAT models.

Unless otherwise stated, the data are valid for
all models (variations are indicated in footnotes
to the tables):

Frequency band

Max. station
power

Key with radio-operated remote control
(vehicle)

433.05-434.78 MHz

10 mW (ERP)

433.05-434.79 MHz

10 mW

868.0-868.6 MHz

25 mW

434.42 MHz

32 µW

Radio-operated remote control (auxiliary
heater)

868.7-869.2 MHz (869.0 MHz)

25 mW

868.0-868.6 MHz (868.3 MHz)

3.1 mW

Valid for: Leon, Ateca, Tarraco

Valid for: Alhambra

Transmitter-Receiver (auxiliary heater)

868.7-869.2 MHz (869.0 MHz)

23.5 mW

868.0-868.6 MHz (868.3 MHz)

23.5 mW

Valid for: Leon, Ateca, Tarraco

Valid for: Alhambra

Bluetooth

2402-2480 MHz

6 dBm

2400-2483.5 MHz

10 dBm

316

Information for the user

Connection to the vehicle’s external an-
tenna

GSM 900: 880-915 MHz

33 dBm

GSM 1800: 1710-1785 MHz

30 dBm

WCDMA FDD I: 1920-1980 MHz

24 dBm

WCDMA FDD lll: 1710-1785 MHz

21 dBm

WCDMA FDD VIII: 880-915 MHz

21 dBm

LTE FDD1: 1920-1980 MHz

23 dBm

LTE FDD3: 1710-1785 MHz

23 dBm

LTE FDD7: 2500-2570 MHz

23 dBm

LTE FDD8: 880-915 MHz

23 dBm

LTE FFD20: 832-862 MHz

23 dBm

✓

Valid for: Tarraco, Leon

Connection to the vehicle’s external an-
tenna

GSM 900: 880-915 MHz

33 dBm

GSM 1800: 1710-1785 MHz

30 dBm

WCDMA FDD I: 1920-1980 MHz

24 dBm

✓

Valid for: Alhambra

Wireless hotspot

2400-2483.5 MHz

10 dBm

✓

Valid for: Leon, Ateca, Tarraco

Keyless Access

434.42 MHz

32 µW

✓

Valid for: Ibiza, Arona, Leon, Ateca, Tarraco

Radar sensors for front assist systems

76 GHz-77 GHz

28.2 dBm

35.0 dBm

Valid for: Leon, Alhambra

Valid for: Ibiza, Arona, Ateca, Tarraco

Radar sensors for rear assist systems

24050-24250 MHz

20 dBm

✓

Valid for: Ibiza, Arona, Leon, Ateca, Tarraco

Wireless charging function

110-120 kHz

5 W

✓

Valid for: Ibiza, Arona, Leon, Ateca, Tarraco

Instrument cluster

125 kHz

40 dBµA/m

Online Connectivity Unit

EGSM900: 880-915 MHz

33 dBm

DCS1800: 1710-1785 MHz

31 dBm

UMTS FDD 1: 1920-1980 MHz

24 dBm

UMTS FDD 3: 1710-1785 MHz

24 dBm

UMTS FDD 8: 880-915 MHz

24 dBm

E-UTRA FDD 1: 1920-1980 MHz

23.5 dBm

E-UTRA FDD 3: 1710-1785 MHz

23.0 dBm

E-UTRA FDD 7: 2500-2570 MHz

23.5 dBm

E-UTRA FDD 8: 880-915 MHz

23.0 dBm

E-UTRA FDD 20: 832-862 MHz

23.5 dBm

E-UTRA FDD 28: 703-748 MHz

23.0 dBm

✓

Valid for: Ibiza, Arona, Leon, Ateca, Tarraco

Additional information for countries
outside the European Union

Mexico

Your vehicle has different radioelectrical de-
vices. The manufacturers of these devices
declare that they comply with Directive
RLVCOAR15-0008 when legally required. The
full text of the declaration of conformity is avail-
able online at the following Internet address:
https://www.seat.mx/servicio/mi-seat/manual-
del-propietario.html

Information for the user

317

Radioelectrical equipment

Certificate: RLVHERS17-0286. RS4 Hella
KGaA Hueck & Co. short-range radar
IFT:RLVHERS17-0286. The operation of this
equipment is subject to the following two con-
ditions: (1) this equipment or device may not
cause harmful interference, and (2) this equip-
ment or device must accept any interference,
including interference that may cause unde-
sired operation.

United Kingdom

The following applies to importers in the UK
market:
Volkswagen Group United Kingdom Ltd.
Yeomans Drive, Blakelands
Milton Keynes, MK 14 5AN
United Kingdom

Turkey

Telsiz Ekipmanları Yönetmeliği (2014/53/AB)

Aracınızda çeşitli telsiz ekipmanları bulunmak-
tadır.
Telsiz Ekipmanlari Yönetmeliği (2014/53/AB)
açısından Türkiye pazarı için radyo ekipmanı
ithalatçısı (bu bilgi sadece resmi temsilcimiz
olan Doğuş Otomotiv Servis ve Ticaret A.Ş.’nin
ithal ettiği ürünler için geçerlidir):
Doğuş Otomotiv Servis ve Ticaret A.Ş.
Şekerpınar Mahallesi, Anadolu Caddesi, No: 22
ve 45
41420 Çayırova/Kocaeli

Ukraine

мпортер

ТОВ

Порше

Укра

на

просп

Павла

Тичини

, 1

оф

„

“, 4-

поверх

02152

Ки

Укра

на

Importer:

Porsche Ukraine LLC
Pavla Tychyny ave. 1V, Office “B”, 4th floor
02152 Kyiv, Ukraine.

318

Technical data

Technical data

Indications about the tech-
nical data

Vehicle identification data

The values indicated in the technical data may
differ depending on optional equipment or ver-
sion of the model, as well as in the case of spe-
cial vehicles and equipment for certain coun-
tries.
The information in the official vehicle documen-
tation takes precedence at all times.

Abbreviations used in the Technical Specifi-
cations section

Kilowatt, engine power measure-
ment.

Horsepower (not currently used),
engine power measurement unit.

rpm, 1/min

Revolutions per minute – engine
speed.

Newton metres, unit of engine tor-
que.

Cetane number, indication of the
diesel combustion power.

RON

Research octane number, indication
of the knock resistance of petrol.

Vehicle ID number

The vehicle ID number can be found in the fol-
lowing places:

●

One the vehicle's data label.

●

In front, under the windscreen.

●

To the right in the engine compartment.

Type plate

The type plate is located on the vehicle’s right
hand door frame. Vehicles for certain export
countries do not have a type plate.

Performance

The values apply only to optimal road and
weather conditions.
The vehicle’s performance has been calculated
without any equipment that would affect it, e.g.
accessories.

Fuel consumption

Approved consumption values are derived from
measurements performed or supervised by
certified EU laboratories, according to the legis-
lation in force at the time (for more information,
see the Publications Office of the European
Union on the EUR-Lex website: © European Un-
ion, http://eur-lex.europa.eu/) and apply to the
specified vehicle characteristics.

The values relating to fuel consumption and
CO

emissions can be found in the documenta-

tion provided to the purchaser of the vehicle at
the time of purchase.
Fuel consumption and CO

emissions depend

on the equipment/features of each individual
vehicle, as well as on the driving style, road
conditions, traffic conditions, environmental
conditions, load or number of passengers.

Tank level

Petrol engines

40 l, 7 l reserve

Natural gas en-
gine

approx. 13.8 kg

Additional petrol tank: 9 l, of

which approx 7.6 l is a reserve

The capacity depends on the efficacy and char-

acteristics of the natural gas pumps. The capacity
indicated is based on a minimum loading pressure
of 200 bar.

Weights

The kerb weight values apply to the vehicle
as ready to drive with a driver (75 kg), oper-
ating fluids and, if applicable, tools and the
spare wheel. The kerb weight increases with
optional equipment and retrofitting of accesso-
ries, which reduces the possible payload ac-
cordingly.

320

Technical data

Engine specifications

Petrol engines

1.0 TSI Start-Stop

Power output in kW (hp) at 1/min

70 (95)/5,000-5,500

81 (110)/5,500

85 (115)/5,000-5,500

Maximum torque (Nm at 1/min)

175/1,600-3,500

200/2,000-3,000

200/2,000-3,500

No. of cylinders/displacement (cm

)

3/999

Fuel

Super 95 / Normal 91 (with a slight power loss) ROZ

Gearbox

manual

DSG

Top speed (km/h)

182 (V)

190 (V)

190 (VI)

Acceleration from 0-100 km/h (s)

11.5

10.6

10.8

10.0

Maximum authorised weight (kg)

1,710

1,730

1,750

1,740

Varies depending on the features.

Petrol engines

1.5 TSI Start-Stop

1.6 MPI

Power output in kW (hp) at 1/min

110 (150)/5,000-6,000

81 (110)/5,800

Maximum torque (Nm at 1/min)

250/1,500-3,500

152/3,850-4,100

No. of cylinders/displacement (cm

)

4/1,498

4/1,598

Fuel

Super 95 / Normal 91 (with a slight power loss) ROZ

Gearbox

DSG

manual

automatic

Top speed (km/h)

210 (V)

180 (IV)

Acceleration from 0-100 km/h (s)

8.4

11.2

11.6

Maximum authorised weight (kg)

1,770

1,690

1,730

Varies depending on the features.

Technical data

323

Indications about the technical data

ARONA

Front projection (mm)

809

Rear projection (mm)

779

Wheelbase (mm)

2,566

Length (mm)

4,154

Front

track (mm)

1,513

Back

track (mm)

1,495

Width (mm)

1,780

Height at kerb weight (mm)

1,537

Ground clearance between the axles (mm)

173

Front projection angle limited by the bumper

maximum 18.1°

Rear projection angle limited by the bumper

maximum 28.1°

Turning radius (m)

10.6

This data will change depending on the type of wheel rim.

Dimension to the roof bars.

Index

325

Index

Numbers and Symbols

12-volt battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279

assisted start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  253
charge level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  282
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  280
control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  282
disconnect and connect . . . . . . . . . . . . . . . . . . .  280
electrolyte level . . . . . . . . . . . . . . . . . . . . . . . . . . . .  280
energy management . . . . . . . . . . . . . . . . . . . . . . .  282
replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  280

ACC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  142
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  309
Activating SEAT CONNECT . . . . . . . . . . . . . . . . . . . .  182
Adapting the playback volume . . . . . . . . . . . . . . .  200
Adaptive Cruise Control . . . . . . . . . . . . . . . . . . . . . .  142

control and warning lamp . . . . . . . . . . . . . . . . . .  147
malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  147
operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  143
special driving situations . . . . . . . . . . . . . . . . . . . .  145
status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  143
System limitations . . . . . . . . . . . . . . . . . . . . . . . . . .  146

Adjust

front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  84
headrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  85
lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  93
seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  38
time and date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  28

Adjusting the seat belt . . . . . . . . . . . . . . . . . . . . . . . . . 44

Air conditioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

air recirculation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  106
controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  104
manual air conditioning . . . . . . . . . . . . . . . . . . . .  105
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  107

Air recirculation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Airbag system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  47
control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  48
deactivation of the front airbag . . . . . . . . . . . . . .  49
description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  46
front airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  49
how it works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  47

Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

activating and deactivating . . . . . . . . . . . . . . . . .  49
description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  46
for the head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  51
front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  49
side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  50

Android Auto™

disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  190
establish connection . . . . . . . . . . . . . . . . . . . . . . .  190
menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  190
requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  190
special characteristics . . . . . . . . . . . . . . . . . . . . .  190

Anti-lock brake system . . . . . . . . . . . . . . . . . . . . . . . .  131
Anti-puncture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  297
Anti-puncture kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  297

check after 10 minutes . . . . . . . . . . . . . . . . . . . . .  300
components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  298
inflating the tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . .  299
sealing the tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . .  299

Anti-puncture set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297
Anti-theft alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

interior monitoring and anti-tow system . . . . . . 75
trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233

Anti-theft alarm system . . . . . . . . . . . . . . . . . . . . . . . . 74
Anti-trap function

windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Antifreeze . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270
Apple CarPlay

disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  189
establish connection . . . . . . . . . . . . . . . . . . . . . . .  189
menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  189
requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  189
special characteristics . . . . . . . . . . . . . . . . . . . . .  189

Applications (apps) . . . . . . . . . . . . . . . . . . . . . . . . . . .  188
Approved spare parts . . . . . . . . . . . . . . . . . . . . . . . .  303
Aspects to think about before starting the vehicle
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  37
Assistance systems

adaptive cruise control . . . . . . . . . . . . . . . . . . . . .  142
connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  135
cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  139
driver alert system . . . . . . . . . . . . . . . . . . . . . . . . . . .  24
driving assist (Travel Assist) . . . . . . . . . . . . . . . . .  153
emergency braking (Front Assist) . . . . . . . . . . .  147
front camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  137
front radar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  136
general notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  135
lane departure warning (Side Assist) . . . . . . . .  155
parking aid Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  162
rear camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  139
rear parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  165
rear radar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  137
road signs detection system . . . . . . . . . . . . . . . . .  25
safety advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  135
speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  141
switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  135
system limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  135
tyre pressure monitor indicator . . . . . . . . . . . . .  296

326

Index

tyre pressure monitoring . . . . . . . . . . . . . . . . . . . . 297
ultrasound sensors . . . . . . . . . . . . . . . . . . . . . . . . . 138

Assisted start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253
Audible warning

lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
unbuckled seat belt . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Audio warning signals

warning and control lamps . . . . . . . . . . . . . . . . . . . 11

Auto Lock (central locking) . . . . . . . . . . . . . . . . . . . . .  71
Auto Unlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  71
Automatic car wash . . . . . . . . . . . . . . . . . . . . . . . . . .  304
Automatic dipped beam headlight control . . . . .  88
Automatic gearbox

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  121
downhill assistant . . . . . . . . . . . . . . . . . . . . . . . . . . .  127
driving tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  123
ignition key extraction lock . . . . . . . . . . . . . . . . . .  113
selector lever positions . . . . . . . . . . . . . . . . . . . . . .  121
steering wheel with shift paddles . . . . . . . . . . .  123
tiptronic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  123

Average fuel consumption . . . . . . . . . . . . . . . . . . . . . 16

Backrest of the rear seat

folding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
raise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Bag hooks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  179
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  67
Before starting the vehicle . . . . . . . . . . . . . . . . . . . . .  37
Belt force limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  45
Belt tightening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  45
Bicycle carrier

fitting onto the coverable tow hook . . . . . . . . . 237
max. load rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237

Blown bulbs

change a bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262

Bonnet

opening and closing . . . . . . . . . . . . . . . . . . . . . . . 269

Brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  273
brake servo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  130
braking assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . .  131
new brake pads . . . . . . . . . . . . . . . . . . . . . . . . . . . .  130

Braking assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Braking system

warning lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Brands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Camera

cleaning the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 27

Capacities

natural gas tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245

Catalytic converter . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Central locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

anti-theft alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  74
auto-locking due to involuntary opening . . . . .  71
central locking switch . . . . . . . . . . . . . . . . . . . . . . . .  72
emergency lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  77
Keyless Access system . . . . . . . . . . . . . . . . . . . . . .  68
remote control key . . . . . . . . . . . . . . . . . . . . . . . . . . .  72

Change a bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262

tail light bulb in the bodywork . . . . . . . . . . . . . . 264

Change the wiper blades . . . . . . . . . . . . . . . . . . . . . 251
Changing a wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . 290

raise the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . .  294
subsequent work . . . . . . . . . . . . . . . . . . . . . . . . . . .  295
wheel nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  293

Changing parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 309
Changing the battery

of the vehicle key . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Check lists

requirements for Android Auto™ . . . . . . . . . . . . .  190
requirements for Apple CarPlay . . . . . . . . . . . .  189
requirements for MirrorLink® . . . . . . . . . . . . . . . .  191

Child lock

electric windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Child seats

attachment systems . . . . . . . . . . . . . . . . . . . . . . . . .  55
group classification . . . . . . . . . . . . . . . . . . . . . . . . . .  53
i-Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  56
ISOFIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  56
safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . .  54
securing with the seat belt . . . . . . . . . . . . . . . . . .  60
Top Tether system . . . . . . . . . . . . . . . . . . . . . . . . . . . .  59

Cleaning

high pressure cleaning equipment . . . . . . . . .  304
special care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  307
vehicle exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  305
vehicle interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  306
washing the vehicle . . . . . . . . . . . . . . . . . . . . . . . .  304

Clocks

set the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Closing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269
windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Clutch (lamp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Coming Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Connectivity

WLAN access point . . . . . . . . . . . . . . . . . . . . . . . . . 186

Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Control and warning lamps

12-volt battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  282
ACC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  147
adaptive cruise control . . . . . . . . . . . . . . . . . . . . .  143
air conditioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  107
airbag system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  48

Index

327

airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  49
anti-lock brake system ABS . . . . . . . . . . . . . . . . .  133
automatic gearbox . . . . . . . . . . . . . . . . . . . . . . . . . .  121
braking system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  131
cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  140
cruise control (GRA) . . . . . . . . . . . . . . . . . . . . . . . .  139
electromechanical steering . . . . . . . . . . . . . . . . .  128
emissions control . . . . . . . . . . . . . . . . . . . . . . . . . . .  249
engine coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  19
engine management . . . . . . . . . . . . . . . . . . . . . . .  249
engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  278
ESC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  133
ESC in Sport mode . . . . . . . . . . . . . . . . . . . . . . . . .  133
ESC off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  133
fuel reserve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  17
Lane Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  152
lane departure warning (Side Assist) . . . . . . . .  157
lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  88
particulate filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  249
press on the brake . . . . . . . . . . . . . . . . . . . . . . . . . .  142
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  17, 244
seat belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  41
speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  142
Start-Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  118
steering column . . . . . . . . . . . . . . . . . . . . . . . . . . . .  128
TCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  133
tyre pressure monitor system . . . . . . . . . . . . . . .  297

Control lamps

overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Controls on the steering wheel . . . . . . . . . . . . . . . . 82
Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Cooling system

check the coolant . . . . . . . . . . . . . . . . . . . . . . . . . . 271
refilling coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 271

Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Cornering light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Correct position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
passenger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Cruise control system . . . . . . . . . . . . . . . . . . . . . . . . . 139

control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Current documentation attached . . . . . . . . . . . . . 193

Dangers of not using the seat belt . . . . . . . . . . . . .  42
Data label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  318
Data transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  181
Deactivating SEAT CONNECT services . . . . . . .  184
Deactivation of the front airbag . . . . . . . . . . . . . . .  49
Disposal

seat belt tensioners . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Door cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  76
Door handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  76
Door lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  76
Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  76

child lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Downhill assistance function . . . . . . . . . . . . . . . . . .  127
downhill assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  127
Drawers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  178
Drink holder

bottle holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  178
front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  178
in the rear central armrest . . . . . . . . . . . . . . . . . .  178

Drive Profiles

see Drive profile selection . . . . . . . . . . . . . . . . . . 128

Driver alert system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Driving

driving on flooded roads . . . . . . . . . . . . . . . . . . . .  112
economical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  109
loaded vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  111

safe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  37
trips abroad . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  93, 113
with the luggage compartment open . . . . . . . .  111
with trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  236

Driving Assist (Travel Assist)

see Travel Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

Driving data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  22
Driving data indicator . . . . . . . . . . . . . . . . . . . . . . . . . .  22
Driving mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  129
Driving on flooded roads . . . . . . . . . . . . . . . . . . . . . .  112
Driving profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  129
Driving with a loaded vehicle . . . . . . . . . . . . . . . . . .  111
Driving with the luggage compartment open . .  111
DSG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  121
Duplicate keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  66
Dust and pollen filter . . . . . . . . . . . . . . . . . . . . . . . . . .  102
Dynamic headlight range control . . . . . . . . . . . . . .  93

e-Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
E10

see Ethanol (fuel) . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

Eco-driving notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  28
Electric devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  179
Electric windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  79
Electrolyte . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  280
Electronic differential lock . . . . . . . . . . . . . . . . . . . . .  131
Electronic immobilizer . . . . . . . . . . . . . . . . . . . . . . . . .  117
Electronic Stability Control (ESC) . . . . . . . . . . . . .  131
Emergencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  63

anti-puncture kit . . . . . . . . . . . . . . . . . . . . . . . . . . . .  297
changing a wheel . . . . . . . . . . . . . . . . . . . . . . . . . .  290
changing the battery . . . . . . . . . . . . . . . . . . . . . .  280
emergency vehicle towing . . . . . . . . . . . . . . . . .  255
hazard warning lights . . . . . . . . . . . . . . . . . . . . . . . .  62
jump leads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  253

328

Index

replace a blown fuse . . . . . . . . . . . . . . . . . . . . . . . 260
vehicle tool kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251

Emergency braking assist system . . . . . . . . . . . . . 136

activating and deactivating . . . . . . . . . . . . . . . .  150
status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  148
system limitations . . . . . . . . . . . . . . . . . . . . . . . . . .  149
temporarily deactivating . . . . . . . . . . . . . . . . . . .  150
warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  148

Emergency braking warning . . . . . . . . . . . . . . . . . . .  62
Emergency call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  63
Emergency call service . . . . . . . . . . . . . . . . . . . . . . . .  63
Emergency locking of the front passenger door 77
Emergency opening

driver's door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Emergency operation

front passenger door . . . . . . . . . . . . . . . . . . . . . . . . 77

Emissions control system

catalytic converter . . . . . . . . . . . . . . . . . . . . . . . . .  248
control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  249
particulate filter . . . . . . . . . . . . . . . . . . . . . . . . . . . .  249

Energy management . . . . . . . . . . . . . . . . . . . . . . . . . 282
Engine

noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  115
preheating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  113
running in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  112
Start-Stop system . . . . . . . . . . . . . . . . . . . . . . . . . . .  118
starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  113

Engine and ignition

emergency start . . . . . . . . . . . . . . . . . . . . . . . . . . . .  117
preheat the engine . . . . . . . . . . . . . . . . . . . . . . . . . .  115
starting the engine . . . . . . . . . . . . . . . . . . . . . . . . . .  115
starting the engine with Press & Drive . . . . . . .  115
switching off the engine . . . . . . . . . . . . . . . . . . . . .  116

Engine compartment

battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  279
engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  277
opening and closing . . . . . . . . . . . . . . . . . . . . . . .  269
safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . .  267

Engine coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270

check the level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  271
exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  21
specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  270
temperature indicator . . . . . . . . . . . . . . . . . . . . . . . . .  19
warning lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  19

Engine failure

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

Engine management . . . . . . . . . . . . . . . . . . . . . . . . . 248

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

Engine oil

change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  275, 278
check the oil level . . . . . . . . . . . . . . . . . . . . . . . . . .  277
consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  277
dipstick . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  277
inspection service . . . . . . . . . . . . . . . . . . . . . . . . . .  275
maintenance frequencies . . . . . . . . . . . . . . . . . .  275
refill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  277
specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  275

Engine oil pressure

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278

Engine specifications . . . . . . . . . . . . . . . . . . . . . . . . . 320
Environment

ecological driving . . . . . . . . . . . . . . . . . . . . . . . . . .  109
environmental compatibility . . . . . . . . . . . . . . . .  312
recycling of electrical appliances . . . . . . . . . .  312
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  244

Environmental tip

refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244

ESC

connecting and disconnecting . . . . . . . . . . . . . .  133
electronic stability control (ESC) . . . . . . . . . . . .  131
Sport mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  133

Ethanol (fuel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  247
Event Data Recorder . . . . . . . . . . . . . . . . . . . . . . . . . .  311
Exhaust gases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  248
Exiting a parking space

with the parking assist system . . . . . . . . . . . . . . . 172

Exterior lighting

change a bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262

Exterior mirrors

driving with a trailer . . . . . . . . . . . . . . . . . . . . . . . . .  232
fold manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  100
folding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  100
heated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  100
settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  100

External antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 309
External audio sources

adapting the playback volume . . . . . . . . . . . . 200

Fabrics: clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  306
Factors that have a negative influence on safe
driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  37
Fastening rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  228
Filling capacities

window washer water . . . . . . . . . . . . . . . . . . . . . . 274

Filling the tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  244
Fire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  63
Frequency bands . . . . . . . . . . . . . . . . . . . . . . . . . . . .  206
Front bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  267
Front camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  137

Index

329

Front compartment

brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  273
coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  270, 271
windscreen washer reservoir . . . . . . . . . . . . . . .  274

Front passenger front airbag

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Fuel

ethanol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  247
fuel gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  17
identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  246
natural gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  247
petrol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  246
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  244
saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  109

Fuel consumption

inertia disconnection . . . . . . . . . . . . . . . . . . . . . . . 109
why does consumption increase? . . . . . . . . . . 249

Fuel gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Fuel tank cap

opening and closing . . . . . . . . . . . . . . . . . . . . . . . 244

Fuel tank flap

opening and closing . . . . . . . . . . . . . . . . . . . . . . . 244

Full Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187

applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  188
settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  189
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  189

Full-LED headlights . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259

colour coded . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  260
fuse box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  259, 260
preparations for replacing fuses . . . . . . . . . . .  260
recognise blown fuses . . . . . . . . . . . . . . . . . . . . .  260
replace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  260

Gear change

manual gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Gear indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  109
Gear-change recommendation . . . . . . . . . . . . . .  109
Glove compartment . . . . . . . . . . . . . . . . . . . . . . . . . .  177

Handbrake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  160
Hangers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  179
Hazard warning lights . . . . . . . . . . . . . . . . . . . . . . . . . .  62
Head-on collisions and the laws of physics . . . .  42
Headlight range control . . . . . . . . . . . . . . . . . . . . . . .  93
Headlights

trips abroad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Headrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
removing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  102
Heating and fresh air . . . . . . . . . . . . . . . . . . . . . . . . .  105
Hill driving assistant . . . . . . . . . . . . . . . . . . . . . . . . . . .  127

i-Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  56
Identification of fuels . . . . . . . . . . . . . . . . . . . . . . . . .  246
Ignition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  113
Ignition key extraction lock . . . . . . . . . . . . . . . . . . . .  113
Ignition lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  113
Inertia mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  125
Infotainment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  193

adapt menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  199
Android Auto™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  190
Apple CarPlay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  189
assistants and vehicle settings . . . . . . . . . . . . . .  36

before first use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  193
clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  201
connecting and disconnecting . . . . . . . . . . . . .  199
customise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  199
customised menus . . . . . . . . . . . . . . . . . . . . . . . . . .  199
drop-down menu . . . . . . . . . . . . . . . . . . . . . . . . . . .  199
executing functions . . . . . . . . . . . . . . . . . . . . . . . . .  199
function buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  33
help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  31
initial configuration . . . . . . . . . . . . . . . . . . . . . . . . . .  34
Internet access . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  187
Media mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  209
MirrorLink® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  191
navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  212
operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  199
overview and controls . . . . . . . . . . . . . . . . . .  196, 197
Radio mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  205
safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . .  193
share a WLAN connection . . . . . . . . . . . . . . . . . .  186
sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  200
system settings . . . . . . . . . . . . . . . . . . . . . . . . . . . .  200
technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  201
telephone interface . . . . . . . . . . . . . . . . . . . . . . . . .  219
tutorial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  31
vehicle information . . . . . . . . . . . . . . . . . . . . . . . . . .  35
Wi-Fi Protected Setup (WPS) . . . . . . . . . . . . . . . .  187
WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  186

Infotainment system

see Infotainment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  275, 301
Inspection reminder . . . . . . . . . . . . . . . . . . . . . . . . . . .  29
Inspection service . . . . . . . . . . . . . . . . . . . . . . . . . . . .  275
Instrument panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  13

Basic digital . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  14
digital (SEAT Digital Cockpit) . . . . . . . . . . . . . . . .  16
service intervals display . . . . . . . . . . . . . . . . . . . . .  29

330

Index

status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  20
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  11
time and date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  28
use with the multifunction steering wheel . . . . .  31
warning and control lamps . . . . . . . . . . . . . . . . . . .  11
warning and information messages . . . . . . . . . .  23

Instrument panel display . . . . . . . . . . . . . . . . 14, 16, 20
Instrument panel lighting . . . . . . . . . . . . . . . . . . . . . . 94
Interior mirror

anti-dazzle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Interior monitoring and the anti-tow system

activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

ISOFIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
ISOFIX system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251

position points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 294

Jump leads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253
Jump start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253
jump leads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

Key switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Keyless Access

Press & Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  114
starting the engine . . . . . . . . . . . . . . . . . . . . . . . . . .  115
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  70
unlocking and locking the vehicle . . . . . . . . . . .  68

Keys

changing the battery . . . . . . . . . . . . . . . . . . . . . . . .  67
remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  66
spare key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  66
synchronise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  68

unlock and lock . . . . . . . . . . . . . . . . . . . . . . . . . . 72, 76
vehicle key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Lane Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

control and warning lamp . . . . . . . . . . . . . . . . . . 152
control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152

Lane Assist system . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Lane departure warning (Side Assist)

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  157
driving situations . . . . . . . . . . . . . . . . . . . . . . . . . . . .  158
how it works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  155
indication on the exterior mirror . . . . . . . . . . . . .  157
lane change Plus . . . . . . . . . . . . . . . . . . . . . . . . . . .  157
system limitations . . . . . . . . . . . . . . . . . . . . . . . . . . .  156

Leaving Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  92
Legal provisions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  183
Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  201
Lift the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  294
Light Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  91
Lights

audible warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . .  89
AUTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  88
change a bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  262
coming home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  92
control and warning lamps . . . . . . . . . . . . . . . . . .  88
control lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  94
controlling the lights . . . . . . . . . . . . . . . . . . . . . . . . .  88
cornering light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  89
daytime running lights . . . . . . . . . . . . . . . . . . . . . . .  89
dipped beam headlights . . . . . . . . . . . . . . . . . . . .  88
fog light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  90
headlight range control . . . . . . . . . . . . . . . . . . . . .  93
instrument lighting . . . . . . . . . . . . . . . . . . . . . . . . . . .  94
interior lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  94
leaving home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  92

main beam assist . . . . . . . . . . . . . . . . . . . . . . . . . . . .  91
main beam headlight lever . . . . . . . . . . . . . . . . . .  90
main beam headlights . . . . . . . . . . . . . . . . . . . . . . .  88
reading lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  94
side lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  88
switching on and off . . . . . . . . . . . . . . . . . . . . . . . . .  88
turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  90

Loading the luggage compartment

fastening rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  228
general advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  225
luggage compartment . . . . . . . . . . . . . . . . . . . . .  225
positioning the load . . . . . . . . . . . . . . . . . . . . . . . .  225
positioning the luggage . . . . . . . . . . . . . . . . . . . .  225
roof carrier system . . . . . . . . . . . . . . . . . . . . . . . . .  230
trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  235

Lock and unlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

in the locking cylinder . . . . . . . . . . . . . . . . . . . . . . . 76
with the central locking switch. . . . . . . . . . . . . . . . 72

Luggage compartment . . . . . . . . . . . . . . . . . . . 78, 225

emergency unlocking . . . . . . . . . . . . . . . . . . . . . . . .  79
enlarge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  84
luggage compartment lighting . . . . . . . . . . . . . .  94
removing and fitting the shelf . . . . . . . . . . . . . . .  226
store the rear shelf. . . . . . . . . . . . . . . . . . . . . . . . . .  226
variable luggage compartment floor . . . . . . .  227

Luggage compartment floor . . . . . . . . . . . . . . . . . . 227
Lumbar support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Main beam assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  91
Main beam headlight lever . . . . . . . . . . . . . . . . . . . .  90
Maintenance frequencies . . . . . . . . . . . . . . . . . . . . .  275
Malfunction

adaptive cruise control . . . . . . . . . . . . . . . . . . . . .  147
clutch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  125
towing device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  233

Index

331

Manual gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  120
Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  109
Media Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  209

equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210

Microfiber: clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 306
MirrorLink®

disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  191
establish connection . . . . . . . . . . . . . . . . . . . . . . . .  191
menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  191
requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  191
settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  189
special characteristics . . . . . . . . . . . . . . . . . . . . . .  191

Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

adjusting the exterior mirrors . . . . . . . . . . . . . . . 100
anti-dazzle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Mobile phones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 309
Mobility Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 303
Multimedia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192, 205

favourites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  210
play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  210
select source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  210

Natural gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

fuel gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  19
fuel tank cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  245
LNG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  245
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  245, 247
special characteristics . . . . . . . . . . . . . . . . . . . . .  245

Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212, 215

decrease the navigation map . . . . . . . . . . . . . . .  213
edit route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  217
enter an address for a guide destination . . . .  215
favourite destinations . . . . . . . . . . . . . . . . . . . . . . .  216
frequent destinations . . . . . . . . . . . . . . . . . . . . . . .  216

function: entering destination . . . . . . . . . . . . . . .  215
functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  214
increase the navigation map . . . . . . . . . . . . . . . .  213
last destinations . . . . . . . . . . . . . . . . . . . . . . . . . . . .  216
learn usage pattern . . . . . . . . . . . . . . . . . . . . . . . . .  218
limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  212
navigation announcements . . . . . . . . . . . . . . . . .  212
operating the navigation map . . . . . . . . . . . . . .  213
route details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  217
save destination . . . . . . . . . . . . . . . . . . . . . . . . . . . .  216
saved data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  213
saved destinations . . . . . . . . . . . . . . . . . . . . . . . . . .  216
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  214
traffic reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  217
updating navigation data . . . . . . . . . . . . . . . . . . .  215
use contact details . . . . . . . . . . . . . . . . . . . . . . . . .  216

Noise

brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  130
refuelling natural gas . . . . . . . . . . . . . . . . . . . . . . .  245
tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  284

Number of seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Octane (petrol) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 246
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 16

partial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
total . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Oil change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  278
On-board toolkit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  251
One-touch signalling function . . . . . . . . . . . . . . . . .  90
Online services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  181
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  70

bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  269
tank cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  244, 245
windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  79

Opening and closing . . . . . . . . . . . . . . . . . . . . . . . . . . 70

bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  269
by remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . .  72
doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  76
in the locking cylinder . . . . . . . . . . . . . . . . . . . . . . .  76
rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  78
tank cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  244, 245
windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  79
with the central locking switch. . . . . . . . . . . . . . . .  72

Operation in winter

salt on the roads . . . . . . . . . . . . . . . . . . . . . . . . . . . .  98
snow chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  289
tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  289

Original accessories . . . . . . . . . . . . . . . . . . . . . . . . . 303
Overview

of warning and control lamps . . . . . . . . . . . . . . . . .  11
overview (left hand drive) . . . . . . . . . . . . . . . . . . . . .  9
overview (right hand drive) . . . . . . . . . . . . . . . . . . .  10
view of the vehicle from inside . . . . . . . . . . . . . . . .  8
view of the vehicle from the front . . . . . . . . . . . . . .  6
view of the vehicle from the rear . . . . . . . . . . . . . . .  7

Ownership accreditation . . . . . . . . . . . . . . . . . . . . . 183

Painting the vehicle

care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 305

Park assist

fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  162
operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  164
parking aid plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  162
rear parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  165
see the Parking assist system . . . . . . . . . . . . . . .  167
sensors and camera: clean . . . . . . . . . . . . . . . .  305
surroundings warning . . . . . . . . . . . . . . . . . . . . . . .  162
visual indication . . . . . . . . . . . . . . . . . . . . . . . . . . . .  165

332

Index

Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

automatic gearbox . . . . . . . . . . . . . . . . . . . . . . . . . 123
with the parking assist system . . . . . . . . . . . . . . . 171

Parking assist system . . . . . . . . . . . . . . . . . . . . . . . . . 167

angle parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  171
description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  168
leaving a parking space (only when parallel
parked) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  172
parallel parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  171
parking conditions . . . . . . . . . . . . . . . . . . . . . . . . . .  171
stop early . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  169

Parking systems

automatic brake operation . . . . . . . . . . . . . . . . .  160
reverse assist (Rear View Camera) . . . . . . . . . .  173
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  161

Partial odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  28
Particulate filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  249
Pedals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  39, 109
Petrol

additives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  246
particulate filter . . . . . . . . . . . . . . . . . . . . . . . . . . . .  249
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  246

Places with risk of explosion . . . . . . . . . . . . . . . . . .  220
Places with special regulations . . . . . . . . . . . . . . .  220
Power sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  179

trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233

Preheat the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Preheating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Press & Drive

start button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
starting the engine . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

Radar sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205

equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  206
frequency bands . . . . . . . . . . . . . . . . . . . . . . . . . . .  206
preset buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  206
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  206
Traffic information (TP) . . . . . . . . . . . . . . . . . . . . .  207
tune station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  206
type of reception . . . . . . . . . . . . . . . . . . . . . . . . . . .  206

Radio mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  205
Radio screen: clean . . . . . . . . . . . . . . . . . . . . . . . . . .  306
Radio telephones . . . . . . . . . . . . . . . . . . . . . . . . . . . .  309
Rain and light sensor . . . . . . . . . . . . . . . . . . . . . . . . . . .  97
Rain sensor

function control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Raise the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  294
RCTA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  175
Rear camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  139
Rear cross traffic alert (RCTA) . . . . . . . . . . . . . . . . .  175
Rear fog light

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78, 79
Rear mounting

towing device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

Rear parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

visual indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166

Rear radar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  137
Rear Traffic Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  175
Rear View Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  173
Rear window wiper . . . . . . . . . . . . . . . . . . . . . . . . . . . .  96
Refuelling

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  17
fuel gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  17
gas tank indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . .  19
natural gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  245

opening the fuel tank flap. . . . . . . . . . . . . . . . . . . 244
safety warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244

Releasing the seat belt . . . . . . . . . . . . . . . . . . . . . . . . 43
Remote control key

unlock and lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Repair work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  309
Requirements for Apple CarPlay . . . . . . . . . . . . . .  189
Reverse assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  173
Reverse assist (Rear View) . . . . . . . . . . . . . . . . . . . .  173

parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
shown on the display . . . . . . . . . . . . . . . . . . . . . . . 174

Reverse assist system . . . . . . . . . . . . . . . . . . . . . . . . . 173
Revolution counter . . . . . . . . . . . . . . . . . . . . . . . 14, 16, 17
Road signs

shown on the display . . . . . . . . . . . . . . . . . . . . . . . . 26

Road signs detection system . . . . . . . . . . . . . . . . . . 26

how it works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  25
limited operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  27
shown on the display . . . . . . . . . . . . . . . . . . . . . . . .  26
speed warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  26
windscreen damage . . . . . . . . . . . . . . . . . . . . . . . . .  27

Roof carrier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228

fix the crossbars . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229

Roof carrier system . . . . . . . . . . . . . . . . . . . . . . . . . . . 228
Roof rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 228
Rotation direction

tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 295

Running in

new brake pads . . . . . . . . . . . . . . . . . . . . . . . . . . . .  130
new engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  112
new tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  284

Safe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73, 117
Safe driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Index

333

Safe security system . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Safety

child safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  52
child seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  52
safe driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  37

Safety equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

head-protection airbags . . . . . . . . . . . . . . . . . . . . .  51
seat belt tensioners . . . . . . . . . . . . . . . . . . . . . . . . . .  45
side airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  50
using child seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  54
using seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  41

Save fuel

inertia mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Screen

clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Seat belt tensioners . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Seat belts

adjusting the seat belt . . . . . . . . . . . . . . . . . . . . . . .  44
adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  43
automatic retractor, tensioner and belt force
limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  45
control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  41
maintenance and disposal of seat belt
tensioners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  45
protective function . . . . . . . . . . . . . . . . . . . . . . . . . .  40
purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  46
safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . .  41
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  41
unfastened . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  42

SEAT CONNECT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181

activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
deactivate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184
legal provisions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

SEAT Digital Cockpit . . . . . . . . . . . . . . . . . . . . . . . . . . .  16
SEAT Drive Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  128
SEAT Drive Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . .  128

selecting a profile . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Seat heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
SEAT Ident . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
Seats

adjusting the headrests . . . . . . . . . . . . . . . . . . . . . .  85
backrest of the rear seat . . . . . . . . . . . . . . . . . . . .  84
fitting the headrest . . . . . . . . . . . . . . . . . . . . . . . . . .  86
heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  106
incorrect positions . . . . . . . . . . . . . . . . . . . . . . . . . . .  39
manual adjustment . . . . . . . . . . . . . . . . . . . . . . . . . .  84
number of seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  39
removing the headrest . . . . . . . . . . . . . . . . . . . . . .  86

Selection of driving profile

characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Selector lever (automatic gearbox)

positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Selling the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
Service

Digital Maintenance plan . . . . . . . . . . . . . . . . . . . .  301
inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  301
proof of Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 301
service sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  303
service works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  301
terms of use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  302

Service interval display . . . . . . . . . . . . . . . . . . . . . . . . 28
Service intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Service Menu

service interval display . . . . . . . . . . . . . . . . . . . . . . 28
vehicle identification number . . . . . . . . . . . . . . . . 28

Service Mobility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 303
Set of vehicle keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Shift paddles (automatic transmission) . . . . . . . .  123
Snow chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  289
Sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  200
Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  309
Spare wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  291
Special characteristics

Android Auto™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  190
Apple CarPlay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  189
MirrorLink® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  191
tow start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  255
towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  255
trailer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  236

Speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  142
indication on display . . . . . . . . . . . . . . . . . . . . . . . .  141
operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  141

Speed symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  284
Stabilisation of the towing vehicle and trailer
combination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  237
Start button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  114
Start the engine by towing . . . . . . . . . . . . . . . . . . .  256

special characteristics . . . . . . . . . . . . . . . . . . . . . 255

Start-Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Start-Stop system

disconnect and connect manually . . . . . . . . . .  119
driver indications . . . . . . . . . . . . . . . . . . . . . . . . . . .  120
how it works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  118
lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  118
stopping and starting the engine . . . . . . . . . . . .  118
the engine does not turn off . . . . . . . . . . . . . . . . .  118
the engine starts by itself . . . . . . . . . . . . . . . . . . . .  118

Starting up the engine . . . . . . . . . . . . . . . . . . . . . . . . . 113
Status display

adaptive cruise control . . . . . . . . . . . . . . . . . . . . .  143
doors, front bonnet and rear lid open . . . . . . . . .  21
Eco-driving notes . . . . . . . . . . . . . . . . . . . . . . . . . . . .  28

adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

334

Index

Emergency brake assistance system (Front
Assist) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  148
instrument panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .  20
odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  21
outside temperature . . . . . . . . . . . . . . . . . . . . . . . . .  21
road signs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  26
SEAT Drive Profile . . . . . . . . . . . . . . . . . . . . . . . . . . .  128
selector lever positions . . . . . . . . . . . . . . . . . . . . . .  121
service intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  29
speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  141
speed warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  21
time and date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  28
Travel Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  153
tyre pressure monitoring . . . . . . . . . . . . . . . . . . .  296
warning and information messages . . . . . . . . . .  23

Steering

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  128
electromechanical steering . . . . . . . . . . . . . . . . .  127
steering assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  128

Steering assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Steering wheel

adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  83
controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  82
shift paddles (automatic transmission) . . . . . .  123

Storage compartment . . . . . . . . . . . . . . . . . . . . . . . . 177

drawers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  178
glove compartment . . . . . . . . . . . . . . . . . . . . . . . . .  177
on-board documentation . . . . . . . . . . . . . . . . . . .  177
other object holders . . . . . . . . . . . . . . . . . . . . . . . .  179

Storage compartment accessories

see Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

Storage of accident data . . . . . . . . . . . . . . . . . . . . . . 311
Storing objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225

fastening rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  228
loading the trailer . . . . . . . . . . . . . . . . . . . . . . . . . .  235
positioning the load . . . . . . . . . . . . . . . . . . . . . . . .  225

positioning the luggage . . . . . . . . . . . . . . . . . . . .  225
roof carrier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  228
roof carrier system . . . . . . . . . . . . . . . . . . . .  228, 230
trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  230
trailer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  236

Sun blind . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Sun protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Switching off

telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220

Symbols

see Warning and control lamps . . . . . . . . . . . . . . . 11

System settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200

Tail lights on the bodywork

remove the tail light . . . . . . . . . . . . . . . . . . . . . . . . 264

Technical data

engine specifications . . . . . . . . . . . . . . . . . . . . . .  320
vehicle dimensions . . . . . . . . . . . . . . . . . . . . . . . . .  322
vertical load on the tow hitch . . . . . . . . . . . . . . .  230
weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  318

Technical modifications . . . . . . . . . . . . . . . . . . . . . . 309
Telephone

connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  220
contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  223
favourites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  223
pairing a mobile phone . . . . . . . . . . . . . . . . . . . . .  220
phone book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  223
send messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  222
speed dial buttons . . . . . . . . . . . . . . . . . . . . . . . . . .  223
switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  220
to call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  222

Telephone interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  219
places with risk of explosion . . . . . . . . . . . . . . . .  220
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  219

Time

Tiptronic (automatic transmission) . . . . . . . . . . . .  123
Top Tether . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  59
Top Tether System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  59
Torque

wheel nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 295

Touch screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196, 197
Tow cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232, 233
Towable loads

loading the trailer . . . . . . . . . . . . . . . . . . . . . . . . . . 235

Towing device

fitting a bicycle carrier . . . . . . . . . . . . . . . . . . . . .  237
fitting later . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  239
malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  233

Towing the vehicle

emergency towing . . . . . . . . . . . . . . . . . . . . . . . . .  257
front towline anchorage . . . . . . . . . . . . . . . . . . . .  257
prior steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  257
rear towline anchorage . . . . . . . . . . . . . . . . . . . .  258
special characteristics . . . . . . . . . . . . . . . . . . . . .  255
tow bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  255
tow cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  255
towing prohibited . . . . . . . . . . . . . . . . . . . . . . . . . . .  256

Traction control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  131
Traffic information . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  217
Traffic information (TP) . . . . . . . . . . . . . . . . . . . . . . .  207
Traffic programme

see TP (traffic information) . . . . . . . . . . . . . . . . . 207

Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

adjusting the headlights . . . . . . . . . . . . . . . . . . . .  236
anti-theft alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . .  233
connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  233
exterior mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  232
hitching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  233
LED tail lights . . . . . . . . . . . . . . . . . . . . . . . . . .  232, 233

Index

335

loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  235
malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  233
power socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  233
retrofitting a towing bracket . . . . . . . . . . . . . . . .  239
stabilisation of the towing vehicle and trailer
combination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  237
tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  232, 233
technical requirements . . . . . . . . . . . . . . . . . . . . .  232
tow cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  232, 233
towable loads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  235
trailer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  236
vertical load on the tow hitch . . . . . . . . . .  230, 235

Trailer mode

see Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

Transportation of children . . . . . . . . . . . . . . . . . . . . . . 52
Travel Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

connecting and disconnecting . . . . . . . . . . . . .  154
problems and solutions . . . . . . . . . . . . . . . . . . . . .  155
status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  153

Trips abroad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

headlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Troubleshooting

DSG gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  125
Start-Stop system . . . . . . . . . . . . . . . . . . . . . . . . . .  120
Travel Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  155

Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  90
Turning off the lights . . . . . . . . . . . . . . . . . . . . . . . . . . .  88
Turning on the lights . . . . . . . . . . . . . . . . . . . . . . . . . . .  88
Turning the ignition on and off . . . . . . . . . . . . . . . . .  113
Tyre pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  286
Tyre pressure monitor system . . . . . . . . . . . . . . . . .  297
Tyre pressure monitor systems

tyre pressure monitor indicator . . . . . . . . . . . . . 296

Tyre profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  288
Tyre repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  297
Tyre repair kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  297

Tyre tread depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  288
Tyre wear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  288
Tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  284

accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  284
change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  290
directional tread pattern . . . . . . . . . . . . . .  284, 295
for winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  289
foreign objects inserted . . . . . . . . . . . . . . . . . . . .  284
new tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  285
snow chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  289
speed symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  284
tread wear indicators . . . . . . . . . . . . . . . . . . . . . .  288
tyre pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  286
useful life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  286

Ultrasound sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Unlock and lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

by remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . .  72
doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  76
with the central locking switch. . . . . . . . . . . . . . . .  72

USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
USB port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Vanity mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Variable luggage compartment floor . . . . . . . . . 227
Vehicle

data label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  318
engine specifications . . . . . . . . . . . . . . . . . . . . . .  320
identification data . . . . . . . . . . . . . . . . . . . . . . . . . .  318
interior view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  8
lending or selling . . . . . . . . . . . . . . . . . . . . . . . . . . .  183
overview (left hand drive) . . . . . . . . . . . . . . . . . . . . .  9
overview (right hand drive) . . . . . . . . . . . . . . . . . . .  10

raise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  294
unlocking and locking (Keyless Access) . . . . .  68
vehicle ID number . . . . . . . . . . . . . . . . . . . . . . . . . .  318
view from behind . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  7
view from the front . . . . . . . . . . . . . . . . . . . . . . . . . . . .  6

Vehicle care

wiper blade service position . . . . . . . . . . . . . . . . 251

Vehicle conservation . . . . . . . . . . . . . . . . . . . . . . . . .  304
Vehicle conservation products . . . . . . . . . . . . . . .  304
Vehicle dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . .  322
Vehicle information . . . . . . . . . . . . . . . . . . . . . . . . . . . .  35
Vehicle location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  183
Vehicle seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  39
Vehicle settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  36
Vehicle tool kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  251
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  102
Vertical load on the tow hitch . . . . . . . . . . . . . . . . .  230

loading the trailer . . . . . . . . . . . . . . . . . . . . . . . . . . 235

Voice control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203

Android Auto™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  190
end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  204
Siri™ (Apple CarPlay™) . . . . . . . . . . . . . . . . . . . . .  189
start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  204
wake word: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  203

Volume

set for external audio sources . . . . . . . . . . . . . . 200

Warning lamps

overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Warning triangle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 311
Washing the vehicle

cleaning the exterior . . . . . . . . . . . . . . . . . . . . . . . 305
high pressure cleaning equipment . . . . . . . . . 304

336

Index

interior cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 306
special care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307

Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  318
Wheel balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  286
Wheel central trim . . . . . . . . . . . . . . . . . . . . . . . . . . . .  292
Wheel nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  288

anti-theft device . . . . . . . . . . . . . . . . . . . . . . . . . . .  293
caps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  292
loosen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  293
torque . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  295

Wheel spanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251
Wheels

change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  290
changing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  288
new wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  285
removing and attaching . . . . . . . . . . . . . . . . . . . .  295
snow chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  289
spare wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  291
wheel central trim . . . . . . . . . . . . . . . . . . . . . . . . . .  292
wheel nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  288

Window controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Window washer

window washer lever . . . . . . . . . . . . . . . . . . . . . . . . 96

Window washer system . . . . . . . . . . . . . . . . . . . . . . . 274
Window washer water

check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  274
filling quantities . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  274
refill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  274

Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

anti-trap function . . . . . . . . . . . . . . . . . . . . . . . . . . . .  81
automatic opening/closing . . . . . . . . . . . . . . . . . .  80
automatic operation . . . . . . . . . . . . . . . . . . . . . . . .  80

Windscreen washer . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Windscreen wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
lift the blade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251

rain and light sensor . . . . . . . . . . . . . . . . . . . . . . . . .  97
reposition the blade . . . . . . . . . . . . . . . . . . . . . . . .  251
service position . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  251
special characteristics . . . . . . . . . . . . . . . . . . . . . .  96

Winter conditions

trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230

Winter tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 289
Wiper and rear window wiper blades

cleaning the vehicle . . . . . . . . . . . . . . . . . . .  252, 305
replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  252
service position . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  251

WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186
