INTERIOR TRIM MAINTENANCE (1/2)

A well-maintained vehicle will last

Glass instrument panel

Textiles (seats, door trim, etc)

longer. It is therefore recommended to

(e.g. instrument panel, clock, exterior

Vacuum-clean the textiles regularly.

maintain the interior of the vehicle regu-

temperature display etc.)

larly.

Use a soft cloth (or cotton wool).

Liquid stain

A stain should always be dealt with

If this does not clean them properly,

Use soapy water.

swiftly.

use a soft cloth (or cotton wool) slightly

Dab lightly (never rub) with a soft cloth,

moistened with soapy water and then

Whatever type of stain is on the trim,

rinse and remove the excess.

wipe clean with another soft damp cloth

use cold (or warm) soapy water with

or cotton wool.

natural soap.

Solid or pasty stain

Finally, carefully dry off with a soft dry

Detergents (washing-up liquid, pow-

cloth.

Carefully remove the excess solid or

dered products, alcohol-based prod-

pasty material immediately with a

ucts) should not be used.

Do not use products containing alco-

spatula (working from the edges to the

hol and/or spray fluids on the area.

Use a soft cloth.

centre to avoid spreading the stain).

Clean as for a liquid stain.

Rinse and wipe up excess water.

Seat belts

Special instructions for sweets or

These must be kept clean.

chewing gum

Multimedia screen

Use products selected by our Technical

Maintenance of the screen may depend

Department

(Approved outlets) or

Put an ice cube on the stain to solidify

on the type of multimedia equipment.

warm, soapy water and a sponge and

it, then proceed as for a solid stain.

Please refer to the multimedia instruc-

wipe with a dry cloth.

tions for further information.

Detergents or dyes must not be used

under any circumstances.

For further recommendations for

maintaining the interior, and/or for

any unsatisfactory results, please

see an authorised dealer.

4.18

CarManuals2.co

INTERIOR TRIM MAINTENANCE (2/2)

Removal/replacing removable

You should not:

equipment originally fitted in

Position objects such as deodorants,

the vehicle

scents etc. near air vents as this could

damage your dashboard trim.

If you need to remove equipment in

order to clean the passenger com-

partment (for example, mats), always

ensure that they are correctly refitted

and are the right way around (the driv-

er’s mat should be fitted on the driver’s

Using high-pressure

side, etc.) and fit them with the compo-

cleaning equipment or

nents supplied with the equipment (for

sprays inside the pas-

example, the driver mat should always

senger compartment:

be fixed using the pre-fitted mounting

components).

without careful use, this equipment

With the vehicle stationary, always

could impair the correct functioning

ensure that nothing will impede driving

of the electrical or electronic compo-

(anything obstructing the pedals, heel

nents in the vehicle, or have other

wedged by the mat etc.).

detrimental effects.

4.19

CarManuals2.co

Section 5: Practical advice

Puncture, Emergency spare wheel

5.2

Tyre inflation kit

5.5

Tools

5.8

Wheel trim

5.10

Changing a wheel

5.11

Tyres (tyre and wheel safety, use in winter)

5.13

Headlights (changing bulbs)

5.16

Rear lights and side lights (replacing bulbs)

5.18

Interior lighting: changing bulbs

5.25

Fuses

5.28

Battery

5.30

Card: battery

5.32

Radio frequency remote control: batteries

5.34

Accessories

5.36

Wipers (replacing blades)

5.37

Towing: breakdown

5.39

Operating faults

5.41

5.1

CarManuals2.co

PUNCTURE, EMERGENCY SPARE WHEEL (1/3)

In case of puncture

Depending on the vehicle, a tyre infla-

tion kit or emergency spare wheel is

provided (refer to the following pages).

Special note

The tyre pressure monitor function

does not check the emergency spare

wheel (the wheel replaced by the emer-

gency spare wheel disappears from the

instrument panel display) ➥ 2.32.

If the emergency spare wheel has been stored for several years, have it

checked by your Dealer to ensure that it is safe to use.

Vehicles fitted with an emergency spare wheel smaller than the

four other wheels:

- Never fit more than one emergency spare wheel to the same vehicle.

- As the punctured wheel is wider than the emergency spare wheel, the vehicle’s

ground clearance is reduced.

- Replace the emergency spare wheel as soon as possible with a wheel with the

If the vehicle is parked on

same dimensions as the original.

the hard shoulder, you must

- When this is fitted to the vehicle, which must only be a temporary measure, the

warn other road users of

driving speed must not exceed the speed indicated on the label on the wheel.

your vehicle’s presence

- Fitting an emergency spare wheel may alter the way the vehicle usually runs.

with a warning triangle or with other

Avoid sudden acceleration or deceleration and reduce your speed when cor-

devices as per the legislation apply-

nering.

ing to the country you are in.

- If you need to use snow chains, fit the emergency spare wheel to the rear axle

and check the tyre pressure.

5.2

CarManuals2.co

PUNCTURE, EMERGENCY SPARE WHEEL (2/3)

Emergency spare wheel 3

Vehicle not fitted with a

Vehicle fitted with a

subwoofer

This is located in the luggage compart-

ment.

To access it:

- open the boot;

- lift the luggage compartment

carpet 1 using tab 2 (or the handle,

Remove the subwoofer 7, refit it and

depending on the vehicle);

reconnect it in the same position

- unscrew the central mounting 6 loca-

again. Handle it carefully. If not, this

ted under the jack 4;

could impair the correct functioning

of the subwoofer.

- remove the tool kit 5;

– remove the emergency spare wheel.

- disconnect the power cable of the

subwoofer 7;

- remove the subwoofer;

It is not recommended to replace and reconnect the subwoofer if a tyre is punc-

– remove the emergency spare wheel.

tured: this may cause damage to the subwoofer.

5.3

CarManuals2.co

PUNCTURE, EMERGENCY SPARE WHEEL (3/3)

To refit the wheel carrier:

- use the wheelbrace 8 to screw fully

the nut clockwise (reverse move-

ment A);

– make sure you lock the wheel carrier

in place;

- refit the blanking cover, then the

cover 9.

Note: 4-door version vehicle, store the

punctured wheel in the boot.

Emergency spare wheel 11

under the vehicle, lift then push

(movement B) the handle 10 to lower

It is located under the vehicle.

the wheel carrier on the ground;

To get to it:

pull the wheel 11 towards you, a

– in the luggage compartment, lift the

plastic guide located under the

Make sure that the wheel

cover 9 from the luggage compart-

wheel makes it easy to move;

carrier is always locked,

ment carpet;

with or without the emer-

remove the plastic guide from the

gency spare wheel inside.

- remove blanking cover;

wheel before fitting it to the vehicle.

There is a risk of accidents.

- only use the wheel brace 8 (using

a different tool could damage the

mechanism) to unscrew fully the nut

When the emergency spare

anti-clockwise (movement A), and

wheel is located underneath

the wheel will lower to the ground;

the vehicle, it is vital to take

Do not touch the exhaust

the emergency spare wheel

system.

out before lifting the vehicle.

Risk of burns.

Risk of injury.

5.4

CarManuals2.co

TYRE PRESSURE KIT (1/3)

Do not attempt to use the

The kit is only approved for

inflation kit if the tyre has

inflating the tyres of the ve-

been damaged as a result

hicle originally equipped

of driving with a puncture.

with the kit.

You should therefore carefully check

It must never be used to inflate

the condition of the tyre sidewalls

the tyres of another vehicle, or any

before any operation.

other inflatable object (rubber ring,

rubber boat, etc.).

Driving with underinflated, flat or

punctured tyres can be dangerous

Avoid spillage on skin when han-

and may make the tyre impossible

dling the repair product bottle. If

to repair.

droplets do leak out, rinse them off

with plenty of water.

This repair is temporary

Keep the repair kit away from chil-

A tyre which has been punctured

dren.

should always be inspected (and re-

paired, where possible) as soon as

Do not dispose of the empty bottle

The kit repairs tyres when

possible by a specialist.

in the countryside. Return it to your

tread A has been dam-

approved dealer or to a recycling or-

aged by objects smaller

When taking a tyre which has been

ganisation.

than 4 mm. It cannot repair

repaired using this kit to be replaced,

all types of puncture, such as cuts

you must inform the specialist.

The bottle has a limited service

larger than 4 mm, or cuts in tyre

life which is indicated on its label.

When driving, vibration may be felt

sidewall B.

Check the expiry date.

due to the presence of the repair

Ensure also that the wheel rim is in

product injected into the tyre.

Contact an approved dealer to re-

good condition.

place the inflation tube and repair

product bottle.

Do not pull out the foreign body

causing the puncture if it is still in

the tyre.

5.5

CarManuals2.co

TYRE PRESSURE KIT (2/3)

Engine running, handbrake applied:

Note: While the container empties

(approx.

30 secs), the pressure

Connect the compressor hose 4 to

gauge 6 briefly shows pressure up to

the container inlet 9;

6 bar, then the pressure drops.

remove the cap from the container

inflation adapter 3;

Adjust the pressure: to increase

–

unscrew the valve cap on the rele-

it, continue inflation with the kit; to

vant wheel and screw on the contai-

reduce it, press button 8.

ner’s inflation adapter 3;

disconnect any accessories pre-

viously connected to the vehicle’s

accessories sockets;

the end piece 7 must be plugged in

to the vehicle accessories socket;

press the 5 switch to inflate the

tyre to the recommended pressure

➥ 4.13 ;

In the event of a puncture, use the kit

after a maximum of 15 minutes, stop

located in the luggage compartment

inflating and read the pressure (on

Before using the kit, park

or underneath the luggage compart-

pressure gauge 6).

the vehicle at a sufficient

ment floor (depending on the vehicle).

distance from traffic, switch

➥ 3.54.

on the hazard warning

Vehicle fitted with a tyre pressure

lights, apply the parking brake, ask

monitoring system

all passengers to leave the vehicle

In the event of under-inflation (punc-

and keep them away from traffic.

tures, under-inflation etc.), the 

warning light appears on the instrument

panel. ➥ 2.32.

If the vehicle is parked on the hard shoulder, you must warn other road

users of your vehicle’s presence with a warning triangle or with other de-

vices as per the legislation applying to the country you are in.

5.6

CarManuals2.co

TYRE PRESSURE KIT (3/3)

Once the tyre is correctly inflated,

Precautions when using the

remove the kit:

kit

Slowly unscrew the inflation

The kit should not be operated for more

adapter 3 to prevent any repair prod-

than 15 consecutive minutes.

uct from escaping and store the con-

tainer in plastic packaging to prevent

the product from leaking.

Affix the driving recommendation

label (located under the container) to

Nothing should be placed

the dashboard where the driver can

around the driver’s feet

see it.

as such objects may slide

- Put the kit away.

under the pedals during

–

At the end of this initial inflation op-

sudden braking manoeuvres and

eration, air will still escape from the

obstruct their use.

tyre. You must drive a short distance

in order to seal the hole.

If a minimum pressure of 1.8 bar is

Start immediately and drive at be-

not reached after 15 minutes, repair

tween

12 and 40 mph (20 and

is not possible; do not drive the ve-

Following repair with the kit,

60 km/h) in order to distribute the

hicle but contact an approved dealer.

do not travel further than

product evenly in the tyre and, after

120 miles (200 km). In addi-

driving for 2 miles (3 km), stop and

tion, reduce your speed and

check the pressure.

under no circumstances exceed

If the pressure is greater than 1.3 bar

48 mph (80 km/h). The sticker,

Please be aware that a

but less than the recommended

which you must affix in a prominent

poorly tightened or miss-

pressure, re-adjust it (refer to the

position on the dashboard, reminds

ing valve cap can make the

label affixed to the edge of the driv-

you of this.

tyres less airtight and may

er’s door), otherwise contact an ap-

Depending on the country or local

lead to pressure loss.

proved dealer: repair is not possible.

legislation, a tyre repaired with the

Always use valve caps identical to

inflation kit may need to be replaced.

those fitted originally and tighten

them fully.

5.7

CarManuals2.co

TOOLS (2/2)

Towing hitch 9

➥ 5.39

Wheelbrace 10

Locks or unlocks the wheel bolts and

tow eye 9.

Do not leave the tools un-

secured inside the vehicle

as they may come loose

under braking. After use,

The presence of the tools depends on

Hubcap tool 7

check that all the tools are correctly

the vehicle.

This tool is used to remove the wheel

clipped into the tool kit, then posi-

trims.

tion it correctly in its housing: risk of

injury.

Jack 5

If wheel bolts are supplied in the

On vehicles equipped with a tool kit,

Screw guide 8

tool kit, only use these bolts for the

push towards the front of the vehicle

For tightening/loosening wheel bolts on

emergency spare wheel: refer to the

the 4 clip on the tool kit and remove the

vehicles fitted with alloy wheels

label affixed to the emergency spare

jack.

wheel.

Fold the jack correctly before refitting it

The jack is designed for wheel

in its housing (ensure that the wheel-

changing purposes only. Under no

brace 6 is correctly positioned).

circumstances should it be used for

carrying out repairs underneath the

vehicle or to gain access to the un-

derside of the vehicle.

5.9

CarManuals2.co

HUBCAP

Remove using the hubcap tool 1 (lo-

cated in the tool kit) by connecting the

hook in the recess provided next to the

valve 2 (to attach the metal clip).

To refit it, align it with valve 2. Push the

retaining hooks in fully, starting with

side A near the valve, followed by B

and C, finishing at D opposite the valve.

Note: if you are using anti-theft bolts

Do not leave the tools un-

➥ 5.11.

secured inside the vehicle

as they may come loose

under braking. After use,

check that all the tools are correctly

clipped into the tool kit, then posi-

tion it correctly in its housing: risk of

injury.

5.10

CarManuals2.co

CHANGING A WHEEL (1/2)

Vehicles equipped with a jack

and wheelbrace

If necessary, remove the wheel trim.

Use the wheelbrace 2 to slacken off the

wheel bolts. Position it so as to be able

to push from above.

Place the jack 3 horizontally; the jack

head must be lined up with the sill clos-

est to the wheel concerned, as shown

by an arrow 1.

Crank up the jack by hand at first to

align the base plate (which should be

inclined further inwards than the jack

When the emergency spare

head).

wheel is located underneath

Switch on the hazard warn-

the vehicle, it is vital to take

Turn the wheelbrace until the wheel lifts

ing lights.

the emergency spare wheel

off the ground.

out before lifting the vehicle.

Keep the vehicle away from

traffic and on a level surface

Risk of injury.

where it will not slip.

Apply the parking brake and engage

a gear (first or reverse, or P for auto-

If the vehicle is parked on

matic transmissions).

the hard shoulder, you must

Ask all the passengers to leave the

warn other road users of

vehicle and keep them away from

your vehicle’s presence

traffic.

with a warning triangle or with other

devices as per the legislation apply-

ing to the country you are in.

5.11

CarManuals2.co

CHANGING A WHEEL (2/2)

Undo the bolts and take off the wheel.

Vehicle fitted with a tyre pressure

monitoring system

Fit the emergency spare wheel onto

the hub and rotate it until the mounting

In the event of under-inflation (punc-

holes in the wheel coincide with those

tures, under-inflation etc.), the 

of the hub.

warning light appears on the instrument

If bolts are supplied with the emergency

panel. ➥ 2.32.

spare wheel, only use these bolts for

the emergency spare wheel. Tighten

the bolts, checking that the wheel is

correctly positioned on its hub and un-

screw the jack.

With the wheel on the ground, tighten

the bolts fully and have the tightness of

the bolts checked and the emergency

spare wheel pressure checked as soon

as possible.

Note: 4-door version vehicle, when the

Anti-theft bolt

emergency spare wheel is located un-

derneath the vehicle, place the punc-

If you use anti-theft bolts, fit these

tured wheel in the boot.

nearest the valve (wheel embel-

lisher may not be able to fit).

If you have a puncture, re-

place the wheel as soon as

possible.

A tyre which has been punc-

tured should always be inspected

(and repaired, where possible) by a

specialist.

5.12

CarManuals2.co

TYRES (1/3)

The tyres are the only contact between

When the tread has worn down to the

the vehicle and the road, so it is essen-

wear warning strips, these strips will

tial to keep them in good condition.

become visible 2: it is then necessary

to replace your tyres because the tread

You must make sure that your tyres

rubber is now only 1.6 mm deep at

con- form to local road traffic regula-

most, resulting in poor road holding

tions.

on wet roads.

An overloaded vehicle, long journeys

by motorway, particularly in very hot

weather, or continual driving on poorly

surfaced minor roads will lead to more

rapid tyre wear and affect safety.

Maintaining the tyres

The tyres must be in good condition

and the tread form must have sufficient

depth; tyres approved by our Technical

Department have tread wear indica-

tors 1 which are indicators moulded

into the tread at several points.

Incidents which occur when

driving, such as striking the

kerb, may damage the tyres

and wheel rims, and could

also lead to misalignment of the

front or rear axle geometry. In this

case, have the condition of these

checked by an approved dealer.

5.13

CarManuals2.co

TYRES (2/3)

Tyre pressures

The pressures should be checked cold:

Vehicle fitted with a tyre pressure

ignore higher pressures which may be

monitoring system

Adhere to the tyre pressures (including

reached in hot weather or following a

the emergency spare wheel). The tyre

In the event of under-inflation (punc-

high speed journey.

pressures should be checked at least

tures, under-inflation etc.), the 

once a month and additionally before

If the tyre pressures cannot be checked

warning light appears on the instrument

any long journey (refer to the label af-

when the tyres are cold, increase the

panel. ➥ 2.32.

fixed to the edge of the driver’s door).

pressures from 0.2 to 0.3 bar (or 3 PSI).

Never deflate a hot tyre.

Emergency spare wheel

Special note

➥ 5.2, ➥ 5.11.

Depending on the vehicle, there may

be an adapter which needs to be posi-

tioned on the valve before air is added.

Changing wheels around

Incorrect tyre pressures

This practice is not recommended.

lead to abnormal tyre wear

and unusually hot running.

These are factors which

may seriously affect safety and lead

to:

- poor road holding,

- risk of bursting or tread separa-

tion.

Please be aware that a

The pressure depends on the load

poorly tightened or miss-

and the speed of use. Adjust the

ing valve cap can make the

pressure according to the condi-

tyres less airtight and lead

tions of use (refer to the label affixed

to pressure loss.

to the edge of the driver’s door).

Always use valve caps identical to

those fitted originally and tighten

them fully.

5.14

CarManuals2.co

TYRES (3/3)

Fitting new tyres

Use in winter

Studded tyres

Snow or Winter tyres

This type of equipment may only be

used for a limited period and as laid

We would recommend that these be

down by local legislation. It is neces-

fitted to all four wheels to ensure that

For your safety, please re-

sary to observe the speed specified by

your vehicle retains maximum adhe-

spect the speed limit.

current legislation.

sion. Warning: These tyres sometimes

These tyres must, at a minimum, be

When they need to be re-

have a specific direction of rotation and

fitted to the two front wheels.

placed, only tyres of the

a maximum speed index which may be

same make, size, type and profile

lower than the maximum speed of your

Chains

should be used on a single axle.

vehicle.

For safety reasons, fitting snow

They must: either have a load ca-

chains to the rear axle is strictly for-

pacity and a speed capacity at

bidden.

least equal to the original tyres,

Chains cannot be fitted to tyres which

or correspond to those recom-

are larger than those originally fitted to

mended by your authorised

Snow chains may only be

the vehicle.

dealer.

fitted to tyres of the same

size as those originally

Failure to heed these instructions

fitted to your vehicle.

could endanger your safety and

affect your vehicle’s roadworthi-

ness.

Risk of loss of control of the ve-

17” wheels and larger

hicle.

cannot be fitted with

Changing a wheel

chains.

As the tyre pressure moni-

tor may take several min-

If you wish to use special

utes to correctly determine

equipment, please consult an au-

the positions of the wheels and the

thorised dealer.

pressure values after driving, check

the tyre pressures following any op-

eration.

In all cases, we would recommend that you contact an authorised dealer who will

be able to advise you on the choice of equipment which is most suitable for your

vehicle.

5.15

CarManuals2.co

FRONT HEADLIGHTS: replacing the bulbs (1/2)

Front fog lights 4

Please see an authorised dealer.

Any operation on (or modi-

fication to) the electrical

Additional lights

system must be performed

If you wish to fit fog lights to your ve-

by an approved dealer

hicle, please see an authorised dealer.

since an incorrect connection might

damage the electrical equipment

(harness, components and in par-

ticular the alternator). In addition,

your Dealer has all the parts re-

quired for fitting these units.

Vehicles with LED headlights

The bulbs are under pres-

Daytime running lights/side lights/

sure and can break when

direction indicators 1

replaced.

Please see an authorised dealer.

Risk of injury.

Main beam headlights 2

Please note when work-

Please see an authorised dealer.

ing close to the engine that

it may be hot. In addition,

Dipped beam headlights 3

the engine cooling fan may

Please see an authorised dealer.

start at any moment. The 

warning light in the engine compart-

ment reminds you of this.

Risk of injury.

5.16

CarManuals2.co

FRONT HEADLIGHTS: replacing the bulbs (2/2)

Vehicles with Halogen

Halogen main beam headlight 5

Front fog lights 8

- Access the bulb holder via the un-

headlights

To change the bulb:

derneath of the vehicle;

- open the bonnet;

Daytime running lights/side lights/

- unclip the access flap 9;

- remove cover A;

direction indicators 7

- turn the bulb holder a quarter turn;

- pull the bulb holder 10;

Please see an authorised dealer.

- remove the bulb.

Type of bulb: H16.

Halogen dipped beam headlight 6

Type of bulbs 5 and 6: H7.

Once the bulb has been replaced,

To change the bulb:

It is essential to use anti-U.V. 55W

check that it is properly secured.

- open the bonnet;

bulbs so as not to damage the plastic

- remove cover B;

on the headlights.

- Turn the bulb holder a quarter

Do not touch the bulb glass. Hold it

turn 11;

by its base.

– remove the bulb.

To comply with local legislation, or

When the bulb has been changed,

as a precaution, you can obtain an

make sure you refit the cover correctly.

emergency kit containing a set of

spare bulbs and fuses from an ap-

proved dealer.

5.17

CarManuals2.co

REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (1/7)

Rear fog lights 6 or 7

The front bumper needs to be removed;

consult an authorised dealer.

Bulb type: P21W.

5-door version

Direction indicators 4

Consult an approved dealer.

Brake/side lights 1

Consult an approved dealer

High level brake light 5

Consult an approved dealer.

Side lights 2

Consult an approved dealer.

Reversing light 3

Consult an approved dealer.

The bulbs are under pres-

sure and can break when

replaced.

Risk of injury.

5.18

CarManuals2.co

REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (3/7)

Rear fog lights 6 or 7

The front bumper needs to be removed;

consult an authorised dealer.

Bulb type: P21W.

Estate version

Direction indicators 4

Consult an approved dealer.

Brake/side lights 1

Consult an approved dealer

High level brake light 5

Consult an approved dealer.

Side lights 2

Consult an approved dealer.

Reversing light 3

Consult an approved dealer.

The bulbs are under pres-

sure and can break when

replaced.

Risk of injury.

5.20

CarManuals2.co

REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (5/7)

4-door version

Access to the bulb holders 6 and 7

Brake light 1

Open the boot, remove the cover 4 to

Turn bulb holder 6 a quarter of a turn

Side light 3

access the screw 5 and undo it.

and take out the bulb.

Consult an approved dealer.

Remove the rear lights unit.

Bulb type: P21W.

Refit the bulb holder and push the unit

Direction indicator light 2

in fully until it locks in place.

Turn bulb holder 7 a quarter of a turn

Check that the light is properly locked

and take out the bulb.

in position.

Bulb type: PY21W.

Tighten the screw 5 and reposition the

cover 4.

5.22

CarManuals2.co

REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (6/7)

Reversing light

Turn bulb holder 9 a quarter of a turn

High level brake light 10

and take out the bulb.

From the boot, unclip the cover on the

Consult an approved dealer.

interior trim of the boot lid 8 using a

Bulb type: W16W.

screwdriver or similar tool.

Refitting

Rear fog lights 11

To refit, proceed in the reverse order,

The front bumper needs to be removed;

taking care not to damage the wiring.

consult an authorised dealer.

Bulb type: P21W.

The bulbs are under pres-

sure and can break when

replaced.

Risk of injury.

5.23

CarManuals2.co

REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (7/7)

Number plate lights with

LED number plate lights 13

Side repeaters 14 and

conventional bulbs 12

(depending on vehicle)

welcome lighting 15

(depending on vehicle)

Consult an approved dealer

The wing mirror needs to be removed;

- Unclip the light 12 using a tool such

consult an authorised dealer.

as a flat-blade screwdriver;

- remove the light cover to gain access

to the bulb.

Bulb type: W5W.

The bulbs are under pres-

sure and can break when

replaced.

Risk of injury.

5.24

CarManuals2.co

INTERIOR LIGHTING: changing bulbs (2/3)

Glove box light 3

Luggage compartment light 4

(four-door version)

Please consult an authorised dealer.

Unclip the light by pressing the tab with

a flat-blade screwdriver or similar.

Disconnect the light.

Remove the bonnet 5

Access the bulb.

Bulb type: W5W.

The bulbs are under pressure and can break when replaced.

Risk of injury.

5.26

CarManuals2.co

FUSES (1/2)

Use the fuse allocation label on the

back of flap A to identify the fuses.

Certain fuses should only be replaced

by a qualified professional. These fuses

are not listed on the label.

Only change the fuses represented on

the label.

Fuse box

Tweezers 1

If any electrical component does not

Remove the fuse using tweezers 1, lo-

work, check the condition of the fuses.

cated at the back of flap A.

Unclip the access flap A.

To remove the fuse from the tweezers,

Check the fuse in question

slide the fuse to the side.

and replace it, if neces-

It is not advisable to use the free fuse

sary, by a fuse of the same

locations.

rating.

If a fuse is fitted where the rating is

too high, it may cause the electrical

circuit to overheat (risk of fire) in the

event of an item of equipment using

In accordance with local legislation

an excessive amount of current.

or as a precautionary measure:

obtain an emergency kit containing

a set of spare bulbs and fuses from

an approved Dealer.

5.28

CarManuals2.co

FUSES (2/2)

Allocation of fuses

(the presence of certain fuses depends on the vehicle equipment level)

Symbol

Allocation

Windscreen washer

Multimedia accessories socket, multimedia

screen

Front and rear second row accessories socket

Horn

Towbar socket



Heated rear view mirrors

Brake lights, passenger compartment central unit

Passenger compartment centre unit, rear wiper,



rear fog light

Direction indicator lights, hazard warning lights,

high level brake lights

Luggage compartment/Third row accessories

socket



Electric window (not one-touch)

5.29

CarManuals2.co

BATTERY: troubleshooting (1/2)

To avoid all risk of sparks:

Connecting a battery charger

Ensure that any consumers (cour-

The battery charger must be com-

Before carrying out any

tesy lights, etc.) are switched off

patible with a battery with nominal

action in the engine com-

before disconnecting or reconnect-

voltage of 12 volts.

partment, you must switch

ing the battery;

Do not disconnect the battery when the

off the ignition.

➥ 2.4

when charging, stop the charger

engine is running. Follow the instruc-

➥ 2.5.

before connecting or disconnecting

tions given by the manufacturer of

the battery;

the battery charger you are using.

to avoid creating a short circuit be-

Handle the battery with care

tween the terminals, do not place

as it contains sulphuric acid,

metal objects on the battery;

which must not come into

contact with eyes or skin. If

always wait at least one minute after

it does, wash the affected area with

the engine has been switched off

plenty of cold water. If necessary,

before disconnecting a battery;

consult a doctor.

make sure that you reconnect the

Keep naked flames, red hot objects

battery terminals after refitting.

and sparks away from the battery

components as there is a risk of

explosion.

Special procedures may be

Please note when working close to

required to charge some

the engine that it may be hot. The

batteries. Contact your au-

engine cooling fan may also start at

thorised dealer.

Avoid all risk of sparks which may

any moment. The 

label in the

cause an immediate explosion, and

engine compartment reminds you of

charge the battery in a well venti-

this.

lated area.

Risk of injury.

Risk of serious injury.

5.30

CarManuals2.co

BATTERY: troubleshooting (2/2)

Starting the vehicle using the

battery from another vehicle

If you have to use the battery from an-

other vehicle to start, obtain suitable

jump leads (with a large cross section)

from an approved dealer or, if you al-

ready have jump leads, ensure that

they are in perfect condition.

The two batteries must have an iden-

tical nominal voltage of 12 volts. The

battery supplying the current should

have a capacity (amp-hours, Ah) which

is at least the same as that of the dis-

charged battery.

Ensure that there is no risk of contact

Connect the positive cable A to sup-

With the engine running, disconnect

between the two vehicles (risk of short

port

(+) located under the box

cables A and B in the reverse order

circuiting when the positive terminals

cover 1, then to terminal 5 (+) of the

(2 - 4 - 5 - 3).

are connected) and that the discharged

battery supplying the current.

battery is properly connected. Switch

off your vehicle ignition.

Connect the negative cable B to termi-

nal 4 (-) of the battery supplying the

Lift the red cover on box 1 located

current then to the metal cable 2 (-)

behind the battery.

of the discharged battery.

Check that there is no con-

Start the engine of the vehicle supply-

tact between leads A and B

ing the current and run it at a moderate

and that the positive lead A

speed.

is not touching any metal

parts on the vehicle supplying the

If your vehicle’s engine does not start

current.

immediately, switch off the ignition and

Risk of injury and/or damage to the

wait a few seconds before repeating

vehicle.

the operation.

5.31

CarManuals2.co

CARD: battery (1/2)

The batteries are available from ap-

proved Dealers, and their service

life approximately two years. Check

that there is no dye on the battery:

risk of an incorrect electrical con-

tact.

Replacing the battery

When refitting, proceed in the reverse

order, then press one of the buttons on

If they need to be replaced,

When the message “Keycard Battery

be sure to use the same

the card four times, close to the vehicle:

Low” appears on the instrument panel,

or equivalent type of bat-

the message will disappear.

replace the battery in the card:

tery (consult an Approved

Check that the cover is clipped shut.

- slide the rear casing 1 downwards

Dealer).

while pressing on zone A;

Note: Do not touch the electronic circuit

or contacts on the card when replacing

- remove the battery cover 2;

the battery.

- remove the battery by pressing on

one side and lifting the other;

When replacing:

- replace it according to the direc-

- make sure that the batter-

tion and template shown inside the

ies are correctly inserted.

cover.

There is a risk of explo-

sion.

- if the flap does not close cor-

rectly, do not use and keep out of

reach of children.

5.32

CarManuals2.co

CARD: battery (2/2)

Operating faults

If the battery is too weak to ensure cor-

rect operation, you will still be able to

start and lock/unlock the vehicle

➥ 1.14.

Precautions relating

to batteries:

- keep (new or used) batter-

ies out of reach of children;

- not to swallow the batteries.

Risk of chemical burns which

may led to death.

- if ingested or inserted into any

part of the body, consult a doctor

as soon as possible.

Do not throw away your used bat-

teries; give them to an organisation

responsible for collecting and recy-

cling batteries.

5.33

CarManuals2.co

RADIO FREQUENCY REMOTE CONTROL: batteries (1/2)

Replacing the battery

Note: It is not advisable to touch the

electronic circuit in the key cover when

Open the case at slot 1 using a flat-

replacing the battery.

blade screwdriver or similar, and re-

place the battery 2, observing the po-

When refitting, ensure that the cover is

larity shown on the back of the cover.

correctly clipped on and the screw tight-

ened.

If they need to be replaced,

The batteries are available from ap-

be sure to use the same

proved Dealers, and their service

or equivalent type of bat-

life approximately two years.

tery (consult an Approved

Check that there is no dye on the

Dealer).

battery: risk of an incorrect electri-

cal contact.

5.34

CarManuals2.co

RADIO FREQUENCY REMOTE CONTROL: batteries (2/2)

Operating faults

If the battery is too weak to ensure cor-

rect operation, you will still be able to

start and lock/unlock the vehicle

➥ 1.14.

Precautions relating

Do not throw away your used bat-

to batteries:

teries; give them to an organisation

responsible for collecting and recy-

- keep (new or used) bat-

cling batteries.

teries out of reach of children;

- not to swallow the batteries.

Risk of chemical burns which

When replacing:

may cause death;

- make sure that the batter-

- if ingested or inserted into any

ies are correctly inserted.

part of the body, consult a doctor

Risk of explosion.

as soon as possible.

- if the flap does not close cor-

rectly, do not use and keep out of

reach of children.

5.35

CarManuals2.co

ACCESSORIES

Electrical and electronic accessories

Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, po-

sition of the aerial, etc.), make sure it is compatible with your vehicle. You can get advice from an authorised dealer.

Before connecting an accessory to a socket, please ensure that you do not exceed the maximum power authorised for

the socket ➥ 3.26 ➥ 3.40. Fire hazard.

No work may be carried out on the vehicle’s electrical or radio circuits, except by authorised dealers: an incorrectly connected

system may result in damage being caused to the electrical equipment and/or the components connected to it.

If the vehicle is fitted with any aftermarket electrical equipment, make sure that the installation is correctly protected by a fuse.

Establish the rating and position of this fuse.

Using the diagnostic socket

The use of electronic accessories on the diagnostic socket may cause serious disturbance to the vehicle’s electronic systems.

For your safety we recommend that you use only electronic accessories approved by the manufacturer, consult an Approved

Dealer. Serious accident risk.

Fitting aftermarket accessories

If you wish to install accessories on the vehicle: please contact an authorised dealer. Also, to ensure the correct operation of

your vehicle, and to avoid any risk to your safety, we recommend that you use only accessories specifically designed for your

vehicle, which are the only accessories for which the manufacturer will provide a warranty.

If you are using an anti-theft device, only attach it to the brake pedal.

Obstructions to the driver

On the driver’s side, only use mats suitable for the vehicle, attached with the pre-fitted components, and check the fitting reg-

ularly. Do not lay one mat on top of another. There is a risk of wedging the pedals.

5.36

CarManuals2.co

WIPER BLADES: REPLACEMENT (1/2)

Replacing windscreen wiper

- In frosty weather, make

blades 1

sure that the wiper blades

are not stuck by ice

(to

With the ignition on and engine

avoid the risk of the motor

switched off, lower the windscreen

overheating).

wiper stalk completely: they stop

slightly away from the bonnet.

- Check the condition of the wiper

Lift wiper arm 3, pull tab 2

(move-

Check the condition of the wiper

blades.

ment A) and push the blade upwards.

blades. You are responsible for their

Replace the wiper blades as soon

service life:

as they begin to lose efficiency

To refit

- clean the blades, windscreen and

(approximately once a year).

Slide the blade along the arm until it

rear screen regularly with soapy

clips on. Make sure that the blade is

water;

Whilst changing the blade, take care

correctly locked in position. Return the

- do not use them when the wind-

not to drop the arm onto the window

windscreen wiper stalk to the park po-

screen or rear screen are dry;

after it has been removed as this

sition.

- free them from the windscreen or

may break the window.

rear screen when they have not

been used for a long time.

5.37

CarManuals2.co

WIPER BLADES: REPLACEMENT (2/2)

To refit

To refit the wiper blade, proceed in re-

verse order to removal. Make sure that

the blade is correctly locked in position.

Rear screen wiper blade 4

Stalk in stop position (deactivated):

- Lift wiper arm 6;

- pivot blade 4 until some resistance is

met (movement C);

- depending on the vehicle, press

tab 5, then remove the blade by pull-

ing it (movement B).

Before changing the rear

wiper blade, make sure the

stalk is in the stop position

(deactivated).

Risk of injury.

5.38

CarManuals2.co

TOWING: breakdown recovery (1/2)

Before towing, put the gearbox in neu-

The speed specified by current legis-

tral, unlock the steering column and re-

lation for towing must always be ob-

lease the parking brake.

served. If you are driving the towing

For vehicles fitted with an automatic

vehicle, do not exceed the permissible

gearbox, if it is not possible to put the

towing weight for your vehicle. ➥ 6.12.

gear lever into position N, please con-

sult an authorised dealer.

Towing a vehicle with an

Steering column unlocking

automatic gearbox

Insert the key into the ignition or press

Transport the vehicle on a trailer or tow

the engine start button for two sec-

it with the front wheels off the ground.

onds with the card on you (depending

In exceptional circumstances, you

on the vehicle).

may tow it with all four wheels on the

Reposition the lever to neutral (posi-

ground, only in a forward gear, with the

tion N for vehicles fitted with an auto-

gear in neutral position N over a maxi-

matic gearbox).

mum distance of 50 miles and not ex-

The column is unlocked, the acces-

If the lever is stuck in P, even though

ceeding a speed of 15 mph (25 km/h).

sory functions are supplied: the vehi-

you are depressing the brake pedal, the

cle lights can be used (indicators, brake

lever can be released manually.

lights etc.). At night the vehicle must

To do this, unclip the base of the lever,

have its lights on.

then insert a tool (with a hard rod to it)

Depending on the vehicle, once you

into the slot 1 and press the button 2

have finished towing, press the engine

at the same time in order to unlock the

start button twice (risk of running down

lever.

the battery).

Contact an authorised dealer as soon

as possible.

Do not remove the key

from the ignition switch, or

leave the card in the vehi-

cle during towing (depend-

ing on the vehicle).

When the engine is

Risk of the steering column lock-

stopped, steering and brak-

ing.

ing assistance are no longer

provided.

5.39

CarManuals2.co

TOWING: breakdown recovery (2/2)

Use only the 5 towing eye ➥ 5.8.

Ensure that the towing eye

is bolted correctly.

Risk of losing the towed

object.

Only use the front 3 and rear 6 towing

Access to towing points

- Use a rigid towing bar.

points

Front towing point 3

If a rope or cable is used

(never use the drive shafts or any other

Press zone A and keep depressed

(where the law allows this),

part of the vehicle)

while pulling zone B to open flap 4.

the vehicle being towed

These towing points may only be used

must be able to brake.

Rear towing point 6

for towing: never use them for lifting the

Press zone C and keep depressed

A vehicle must not be towed if it is

vehicle directly or indirectly.

while pulling zone D to open flap 7.

not fit to be driven.

Screw in the tow eye 5 by hand as far

Avoid accelerating or braking

as possible.

suddenly when towing, as this

may result in damage being

caused to the vehicle.

When towing a vehicle, it is ad-

visable not to exceed 30 mph

Do not leave the tools unse-

(50 km/h).

cured inside the vehicle as

they may come loose under

braking.

5.40

CarManuals2.co

OPERATING FAULTS (1/8)

The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact

an approved Dealer as soon as possible.

Using the card

POSSIBLE CAUSES

WHAT TO DO

The card does not lock or unlock the

Card battery is flat.

Replace the battery or have it replaced.

doors.

You will still be able to lock/unlock and start

your vehicle. ➥ 1.14 and ➥ 2.4 or ➥ 2.5.

Use of appliances operating on the

Stop using the devices or use the key pro-

same frequency as the card (mobile

vided. ➥ 1.14.

phone, etc.).

Vehicle located in a high electromag-

Use the key that is built into the card

netic radiation zone. Vehicle battery

➥ 1.14.

flat.

The vehicle is started.

With the engine running, the card’s locking/

unlocking device is blocked. Turn off the ig-

nition.

The message “Place the card near

The card battery is flat or the card is

Check the card battery status or place the

the START button” appears on the in-

out of synch.

card in the placement area ➥ 2.5 provided

strument panel.

for this purpose, then press the “START”

button.

5.41

CarManuals2.co

OPERATING FAULTS (2/8)

The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact

an approved Dealer as soon as possible.

Using the card

POSSIBLE CAUSES

WHAT TO DO

Desynchronisation of the card.

Unlock the driver’s door by inserting the

key integrated in the card into the door lock

➥ 1.14 then place the card in the placement

area ➥ 2.5 and press the “START” button

to synchronise the card.

5.42

CarManuals2.co

OPERATING FAULTS (3/8)

The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact

an approved dealer as soon as possible.

Using the remote control

POSSIBLE CAUSES

ACTION REQUIRED

The remote control does not lock or The remote control battery is flat.

Use the emergency key.

unlock the doors.

Use of appliances operating on the same

Stop using the devices or use the key.

frequency as the remote control (mobile

phone, etc.).

Vehicle located in a high electromagnetic

Replace the battery or have it replaced.

radiation zone.

You will still be able to lock, unlock, and

Discharged battery.

start your vehicle. ➥ 1.14 and ➥ 2.4 or

➥ 2.5.

The vehicle is started.

With the engine running, the key’s locking/

unlocking device is blocked. Turn off the

ignition.

Desynchronisation of the remote control.

Unlock the driver’s door using the key in

the door lock, then start the engine to syn-

chronise the remote control.

5.43

CarManuals2.co

OPERATING FAULTS (4/8)

The starter is activated

POSSIBLE CAUSES

WHAT TO DO

The instrument panel indicator lights are

Battery terminals not tight,

Retighten or reconnect the terminals, or clean them if

weak or fail to light up and the starter

battery terminals discon-

they are oxidised.

does not turn.

nected or oxidised.

Discharged battery or not Connect another battery to the faulty battery. ➥ 5.30 or

operational.

replace the battery if necessary.

Do not push the vehicle if the steering column is

locked.

Faulty circuit.

Consult an approved dealer.

The engine will not start.

Starting conditions are not

➥ 2.4 or ➥ 2.5.

fulfilled.

The card does not work.

➥ 2.4 or ➥ 2.5.

With the vehicle stationary, engine

Petrol version, this is not

The engine’s idle speed should decrease after about

cold, the engine’s idle speed is high.

necessarily a fault. This may

one minute. Otherwise, this may be caused by an-

be caused by the increase in

other fault. Call an approved Dealer.

the engine temperature.

The engine cannot be switched off.

Card not detected.

➥ 2.4 or ➥ 2.5.

Electronic fault.

Press the starter button quickly five times.

The steering column remains locked.

Steering wheel locked.

Move the steering wheel whilst pressing the engine

start button (or, depending on the vehicle, operating

the ignition key) ➥ 2.4.

Faulty circuit.

Consult an approved dealer.

5.44

CarManuals2.co

OPERATING FAULTS (5/8)

On the road

POSSIBLE CAUSES

WHAT TO DO

Vibrations.

Tyres not inflated to correct pres-

Check the tyre pressures: if this is not the

sures, incorrectly balanced or dam-

problem, have them checked by an ap-

aged.

proved Dealer.

White smoke from the exhaust.

In the diesel version, this is necessar-

➥ 2.14.

ily a fault. Smoke may be caused by

particle filter regeneration.

Smoke under the bonnet.

Short-circuit or cooling system leak.

Stop, switch off the ignition, stand away

from the vehicle and contact an approved

dealer.

The oil pressure warning light comes

on:

while cornering or braking;

The level is too low.

Top up the engine oil ➥ 4.5.

is slow to go out or remains lit up

Loss of oil pressure.

Stop the vehicle and contact an approved

under acceleration.

Dealer.

5.45

CarManuals2.co

OPERATING FAULTS (6/8)

On the road

POSSIBLE CAUSES

WHAT TO DO

Steering becomes heavy.

Assistance overheating.

Drive carefully at reduced speed, be aware

of the level of force in the steering wheel

Fault with the electric assistance

needed to turn the wheels. Consult an ap-

motor.

proved dealer

Fault in the assistance system.

The engine is overheating. The cool-

Engine cooling fan not working.

Stop the vehicle, switch off the engine and

ant temperature indicator is in the

contact an approved dealer.

warning zone and warning light

comes on.

Coolant leaks.

Check the coolant reservoir: it should con-

tain fluid. If there is no coolant, consult an

approved dealer as soon as possible.

Coolant boiling in the coolant reser-

Mechanical fault: damaged cylinder

Stop the engine.

voir.

head gasket.

Contact an approved dealer.

Radiator: If there is a significant lack of coolant, remember that it must never be topped up using cold coolant while

the engine is very warm. After any procedure on the vehicle which has involved even partial draining of the cooling

system, it must be refilled with a new mixture prepared in the correct proportions. Reminder: only products approved

by our Technical Department may be used for this purpose.

5.46

CarManuals2.co

OPERATING FAULTS (7/8)

Electrical equipment

POSSIBLE CAUSES

WHAT TO DO

The wipers do not work.

Wiper blades stuck.

Free the blades before using the wipers.

Faulty electrical circuit.

Consult an approved dealer.

Fuse damaged.

Replace the fuse or have it replaced

➥ 5.28.

The wiper does not stop.

Faulty electrical controls.

Consult an approved dealer.

Direction indicators flashing more

Blown bulb.

➥ 5.16 or ➥ 5.18.

quickly.

The direction indicators do not work.

Faulty electrical circuit or control.

Consult an approved dealer.

Fuse damaged.

Replace the fuse or have it replaced

➥ 5.28.

The lights do not come on or go off.

Faulty electrical circuit or control.

Consult an approved dealer.

Fuse damaged.

Replace the fuse or have it replaced

➥ 5.28.

5.47

CarManuals2.co

Renault Megane (2023 year). Manual in english - page 8
