VEHICLE SETTINGS CUSTOMISATION MENU (1/3)

Adjusting the settings

d) “Welcome”:

1

- External welcome;

Select a menu then the function to be

- Automatic fold-out of mirrors;

modified (the display depends on the

- Interior welcome;

vehicle equipment and country):

- Courtesy light auto mode.

a) “Driving”:

Depending on the function, select:

- Indicator volume;

- “ON” or “OFF” to activate or deacti-

- Free-wheel;

vate,

- ...

or

b) “Access”:

- a duration to adjust the time the lights

- Unlocking the driver’s door;

are switched on (e.g. for the “Follow-

– Lock doors during driving;

me-home lighting” function).

– Opening/closing in hands-free

Please refer to the multimedia instruc-

mode;

tions for further information.

- Remote locking/Approach unlock-

ing;

Depending on the vehicle equipment,

- Distance locking sound;

this function allows you to activate/de-

- Silent mode;

activate and adjust some of the vehi-

- Automatic locking;

cle’s functions.

c) “Wiping and lighting”:

- Follow-me-home lighting;

Vehicles fitted with a

- Wiping in reverse;

multimedia screen 1

- Automatic front wiping;

- Wiping after washing;

Accessing the settings menu

Refer to the multimedia instructions for

information on accessing the various

settings.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

1.89

CarManuals2.co

VEHICLE SETTINGS CUSTOMISATION MENU (2/3)

Adjusting the settings

d) “DRIVING ASSIST”:

2

- Lane departure warning sound

Navigate using the 4 or 5 control to

volume;

select the function to be modified and

- Lane departure warning sensitiv-

press 6 “OK” to confirm (display may

ity;

vary according to vehicle equipment

- Lane departure warning vibration;

and country):

- Lane keeping assist sensitivity;

a) “DASHBOARD”:

- Blind spot warning;

- Language;

- Active braking;

- Unit;

- Overspeed warning;

3

4

- Style;

- Distance warning.

- Colour.

e) “LIGHTING”:

b) “VEHICLE”:

- Courtesy light auto mode;

- Rear windscreen wiping in re-

- Automatic follow-me-home light-

6

verse gear;

5

ing;

- Automatic windscreen wiping;

- Follow-me-home lighting: XX sec-

Vehicles not fitted with a

- Front/rear drip wiping function;

onds.

multimedia screen

- Exterior welcome.

f)

“ACCESS”:

c) “PARKING ASSIST”:

- Lock doors during driving;

Accessing the settings menu on

- Beep volume.

- Opening/closing in hands-free

display 2

mode;

With the vehicle stationary, press

- Unlocking the driver’s door;

switch 3 as many times as required to

- Automatic re-locking;

reach the “Vehicle” tab. Press repeat-

- Silent locking;

edly on the 4 or 5 switch to access the

- Automatic opening/closing;

“Settings” menu, then confirm by press-

- Automatic deployment of door

ing 6 “OK”.

mirrors.

g) “RESET”.

=

function activated

<

function deactivated

1.90

CarManuals2.co

VEHICLE SETTINGS CUSTOMISATION MENU (3/3)

To exit the menu, press 4 or 5 to access

“BACK” and confirm by pressing 6

“OK”. It may be necessary to carry out

this operation more than once.

3

4

6

5

Once a line has been selected, press 6

“OK" to adjust the function.

If you select either “PARKING ASSIST”

then “VOLUME”, or “DASHBOARD”

then “LANGUAGE”, you will have to

make a further selection (sound volume

of the parking distance control or in-

strument panel language). In this case,

make your selection and confirm it by

pressing 6 “OK”, the selected value is

shown by a =

in front of the line.

The vehicle settings personalisation

menu cannot be used when driv-

ing. At a speed exceeding 12 mph

(20 km/h), the instrument panel dis-

play switches automatically back to

trip computer and warning system

mode.

1.91

CarManuals2.co

CLOCK AND EXTERIOR TEMPERATURE (1/2)

1

6

2

3

4

5

Vehicles fitted with a multimedia

Vehicles not fitted with a multimedia

Set the hour using the 3 or 4 control,

screen

screen

then wait for three seconds: the min-

utes will flash.

The time and exterior temperature are

Press the switch 2 as many times as re-

displayed on the multimedia screen 1.

quired to reach the “Vehicle” tab.

Set the minutes using the 3 or 4 control,

then wait for three seconds: the flash-

Refer to the multimedia instructions.

Repeatedly press control 3 or 4 to set

ing stops and the time setting is com-

the 6 clock.

plete.

Press and hold switch 5 “OK” until the

time display flashes.

1.92

CarManuals2.co

STEERING WHEEL, POWER-ASSISTED (1/2)

Activating the function

With the ignition on, press the 3 switch:

the switch warning light illuminates.

Deactivating the function

2

- Automatic:

The function switches off automatically

after the regulation phase of approxi-

mately 30 minutes. The 3 switch warn-

ing light remains on.

3

1

Note: if the function has switched off

automatically, press the switch 3 twice

to reactivate it.

If switch 3 is not pressed again, the

function will be reactivated the next

Adjusting the steering wheel

Steering wheel heating

time the ignition is switched on.

height and depth

(depending on vehicle)

- Manually:

Lower the lever 1 and position the

This function heats the steering

steering wheel in the required position.

wheel 2.

To deactivate the function during the

regulation phase, press the switch 3.

Then, raise the lever fully, beyond the

Operating principle

The 3 switch warning light goes out.

point of resistance to lock the steering

When the temperature is reached, the

wheel.

function regulates the temperature of

Make sure that the steering wheel is

the heated areas for approximately

correctly locked.

30 minutes and then switches off auto-

matically.

For safety reasons, only

adjust the steering wheel

when the vehicle is station-

ary.

1.94

CarManuals2.co

REAR VIEW MIRRORS (1/2)

Electrical folding mirrors

Special case

When the rear view mirror has been

The door mirrors will fold-out automati-

manually deployed or folded back, it is

cally when the vehicle is unlocked. The

possible to reset it to a usage position.

door mirrors fold in when the vehicle is

locked.

To do this, press the 3 switch. A me-

chanical tapping noise can be heard

Note: you can deactivate/activate the

from the door mirror.

door mirrors folding mechanism ➥ 1.89.

1

If a tapping noise cannot be heard,

You can force folding by pressing the 3

press once again on 3 switch until the

switch. In this situation, the door mirrors

tapping noise can be heard from the

will remain folded until the 3 button is

2

door mirror.

pressed again, regardless of automatic

folding.

3

Door mirrors

Adjustment

For safety reasons, carry

When you select the door mirror using

out any adjustments when

the 2 switch, the built-in warning light

the vehicle is not being

on the switch will appear. Then use

driven.

the 1 button to adjust it to the desired

position.

Heated door mirrors

Objects observed in the

Mirror de-icing is carried out at the

rear view mirror glass are

same time as rear screen de-icing.

actually closer than they

➥ 3.6 ➥ 3.12.

appear. For your safety,

take this into account in order to

correctly assess the distance before

any manoeuvre.

1.96

CarManuals2.co

REAR VIEW MIRRORS (2/2)

4

Interior rear view mirror

Its position can be adjusted.

For safety reasons, carry

Rear view mirror with lever 4

out any adjustments when

When driving at night, to avoid being

the vehicle is not being

dazzled by the headlights of the vehicle

driven.

behind, depress the little lever located

behind rear view mirror 4.

Rear view mirror without lever 4

Objects observed in the

rear view mirror glass are

The rear view mirror automatically dark-

actually closer than they

ens when you are being followed by a

appear. For your safety,

vehicle using main beam headlights or

take this into account in order to

in very bright lighting.

correctly assess the distance before

any manoeuvre.

1.97

CarManuals2.co

FRONT HEADRESTS

To raise the headrest

Raise it to its highest position (tilt the

seatback backwards if necessary).

A

Press button 2 and lift the headrest to

release it.

3

1

To refit the headrest

Check that the headrest rods are

clean 3.

2

Insert the headrest rods into the holes 1

(tilt the seatback backwards if neces-

sary). Lower the headrest until it locks

and press button 2 to adjust to the de-

sired height. Check that each rod 3 on

To raise the headrest

the seatback is securely locked.

Press the 2 button and pull the headrest

upwards to the height required. Check

that the bonnet is correctly locked.

To lower the headrest

Press button 2 and guide the headrest

down to the desired height. Check that

The headrest is important

the bonnet is correctly locked.

for safety. Ensure that it is in

place and in the correct po-

sition: the top of the head-

rest should be as close as possible

to the top of the head and there must

be a minimal distance between the

head and the headrest A.

1.98

CarManuals2.co

EXTERIOR LIGHTING AND SIGNALS (1/6)

Depending on the vehicle, the dipped

1

2

beam headlights come on automati-

cally after several sweeps of the wind-

1

screen wiper blades.

3

Side lights

Dipped beam

š

k

headlights

Turn ring 2 until the symbol is

opposite mark 3.

Manual operation

This indicator light on the instrument

Turn ring 2 until the symbol is opposite

panel comes on.

mark 3. This indicator light on the in-

strument panel comes on.

Before driving at night,

check that the electrical

Daytime running lights

Automatic operation

equipment is operating cor-

function

(depending on the vehicle)

rectly and adjust the head-

The daytime running lights come on

light beams (if your vehicle is not

Turn ring 2 until the AUTO symbol is op-

automatically with no action on stalk 1

carrying its normal load).➥ 1.106. As

posite mark 3: with the engine running,

when the engine is started, and they go

a general precaution, check that

the dipped beam headlights switch on

off once the engine is switched off.

the lights are not obscured (by dirt,

or off automatically depending on the

mud, snow or objects being trans-

brightness of the light outside, without

ported).

any action on stalk 1.

1.99

CarManuals2.co

EXTERIOR LIGHTING AND SIGNALS (2/6)

During deactivation of the main beam

The main beam headlights come on au-

1

2

headlights, the dipped beam headlights

tomatically if:

return to their original position.

- exterior light is weak;

- no other vehicles or lighting are de-

tected;

Automatic main beam



- the vehicle speed is above approxi-

headlights

mately 25 mph (40 km/h).

Depending on the vehicle, this system

If any of the above conditions are not

switches the main beam headlights on

fulfilled, the system switches to dipped

and off automatically. It uses a camera

beam headlights.

3

located behind the interior rear-view

Note: make sure the windscreen is not

mirror to detect vehicles that are being

obscured (dirt, mud, snow, condensa-

followed and those coming in the oppo-

tion etc.).

site direction.

To activate automatic main beam

headlights:

Main beam headlights

á

turn the ring 2 until the AUTO symbol

With the engine running and

appears opposite the 3 mark and push

the dipped beam headlights lit, push

stalk 1. This indicator light on the instru-

the stalk 1. The 

warning light is

ment panel comes on.

The system may encounter difficul-

illuminated on the instrument panel.

To return to the dipped headlight posi-

ties under certain conditions, inclu-

tion, pull the stalk 1 towards you again.

ding:

- extreme weather conditions (rain,

snow, fog, etc.);

“Raise lights during driving”

- obstruction in front of the wind-

function

screen or camera;

When the main beam headlights are

- when a following or oncoming ve-

activated, the “Raise lights during driv-

hicle has weak or hidden lighting;

ing” function improves driver visibil-

- incorrect settings for the front

ity by automatically raising the dipped

headlights;

beam headlight and the main beam

- reflective systems;

headlights.

- ...

1.100

CarManuals2.co

EXTERIOR LIGHTING AND SIGNALS (3/6)

Operating faults

1

2

When the message “Check Automatic

Lighting” appears on the instrument

panel, the system is deactivated.

Consult an approved dealer.

3

Using the portable naviga-

tion system at night in the

windscreen area below the

Automatic main beam

camera may disturb the op-



headlights (continued)

eration of the “automatic main beam

headlights” system (risk of reflection

To deactivate automatic main beam

on the windscreen).

headlights:

- turn ring 2 to a position other than

AUTO;

or

- pull the stalk 1.

The “automatic main beam

headlights” system should

Warning light 

goes out on the in-

under no circumstances be

strument panel.

used to replace driver atten-

Note: the main beam headlights will be

tion and responsibility with regard

activated upon deactivation of the au-

to vehicle lighting and adapting to

tomatic main beam headlights function.

light, visibility and traffic conditions.

1.101

CarManuals2.co

EXTERIOR LIGHTING AND SIGNALS (4/6)

Lights-on reminder buzzer

Welcome and goodbye

2

If the lights are on after the engine is

function

switched off, a warning beep sounds

(depending on the vehicle)

when the driver’s door is opened to

Once the function is activated, the day-

warn you that the lights are still on (to

time running lights and the rear side

avoid battery discharge or other prob-

lights will light up automatically upon

lems).

detection of the card or when the vehi-

cle is unlocked.

Operating faults

They switch off automatically:

If the

“Check lighting” message ap-

- approximately one minute after light-

ing up;

- when starting the engine based on

the k

warning light flashes on the

the position of the lighting stalk;

instrument panel, this indicates a light-

ing fault.

or

Switching off the lights

Consult an authorised dealer.

- upon locking the vehicle.

The lights will go out automatically

when the engine is switched off, the

driver’s door is opened or the vehicle

Activating/deactivating the

is locked. In this case, the next time

function

the engine is started the lights will be

To activate or deactivate the external

switched back on according to the posi-

welcome function, please see the multi-

tion of the ring 2.

media instructions.

Note: if the fog lights are lit, the lights

Select “ON” or “OFF”.

are not switched off automatically.

1.102

CarManuals2.co

EXTERIOR LIGHTING AND SIGNALS (5/6)

With the engine lights switched off,

2

the 2 ring in AUTO, pull the lever 1 to-

1

wards you: the side lights and dipped

beam headlights will switch on for ap-

proximately 30 seconds along with the

š

and k

warning lights on the

instrument panel.

To increase this duration, you may pull

the stalk up to four times (total time re-

stricted to approximately two minutes).

On the instrument panel, the message

“lighting on _ _ _” followed by the re-

maining time will appear as confirma-

tion. You can then lock your vehicle.

To switch off the lights before they go

“See-me-home lighting”

out automatically, turn ring 2 to any po-

function

sition, then return it to position AUTO.

This function enables you to briefly

switch on the side lights and dipped

beam headlights (e.g. to provide light

when opening a gate).

1.103

CarManuals2.co

EXTERIOR LIGHTING AND SIGNALS (6/6)

Rear fog lights

Cornering lights

1

2



(depending on vehicle)

Turn centre ring 4 on the stalk

3

until the symbol faces mark 3, then re-

When driving in forward gear, with

4

lease it.

the vehicle speed below approxi-

mately 25 mph (40 km/h), whenever

Operation of the fog lights depends on

the dipped beam headlights are on:

the exterior lighting selected, and an in-

under certain conditions (the steering

dicator light will light up on the instru-

wheel at an angle, the indicator lights

ment panel.

on etc.), when turning a corner one of

Do not forget to switch off the fog lights

the front fog lights will switch on to light

when they are no longer needed, to

the inside of the bend.

avoid inconveniencing other road

When reverse gear is engaged and

users.

the dipped beam headlights are on the

two front fog lights illuminate automati-

Switching off the lights

cally.

Front fog lights

Turn the centre ring 4 again until mark 3

Note: when shifting from reverse gear

g

Turn centre ring

4

on

the

is opposite the symbol for the fog lights

into forward gear (for example during a

stalk 1 until the symbol faces mark 3,

that you wish to switch off. The corre-

parking manoeuvre), the two fog lights

then release it.

sponding indicator light on the instru-

are activated until the vehicle exceeds

ment panel goes out.

approximately 6 mph (10 km/h).

Operation of the fog lights depends on

the exterior lighting position selected,

The front and rear fog lights switch off

and an indicator light will light up on the

when the exterior lights are switched

instrument panel.

off.

When driving in fog or snow, or when transporting objects which are higher than the roof, the headlights do not come on au-

tomatically.

Switching on the fog lights remains the responsibility of the driver: the indicator lights on the instrument panel inform you

whether the fog lights are lit (indicator light on) or not (indicator light not on).

1.104

CarManuals2.co

AUDIBLE AND VISUAL SIGNALS

Direction indicators

Move the stalk 1 in the same direc-

tion as you want to move the steering

wheel.

One-touch mode

1

Briefly shift the stalk

1 upwards or

A

downwards, not exceeding the point

of resistance, then release it: the stalk

will return to its original position and the

direction indicator light concerned will

2

flash three times.

Horn

Hazard warning lights

é

Press the steering wheel boss A to ac-

Pressing switch 2 illuminates

tivate the horn.

all four direction indicators and the

side-mounted indicator lights simulta-

neously.

Headlight flasher

It must only be used in an emergency to

Pull stalk 1 towards you then release it

warn drivers of other vehicles that you

to flash the headlights.

have had to stop in an area where stop-

ping is prohibited or unexpected, or that

you are obliged to drive under special

conditions.

1.105

CarManuals2.co

HEADLIGHT BEAM ADJUSTMENT

Examples of positions for

adjusting

control A according to the load

A

Driver alone or with front passenger

0

All seats occupied

2

Switch A is used to adjust the height of

Driver with passengers and luggage

the headlight beams according to the

(or load) reaching the maximum

3

load.

permissible all-up weight

With the dipped beam headlights lit,

press or lift switch A as many times

as is necessary to select the required

Driver without passengers and luggage

position on the instrument panel. The

(or load) reaching the maximum

4

position selected is displayed on the

permissible all-up weight

instrument panel for approximately

30 seconds.

Note: depending on the vehicle, at

each engine start-up the selected po-

sition may be displayed on the instru-

The table below gives some examples. In all cases, adjust control A accord-

ment panel for approximately 30 sec-

ing to the vehicle load so that the road can be seen and other drivers are not

onds.

dazzled.

1.106

CarManuals2.co

WINDSCREEN WASH, WIPE (1/5)

2

A

1

1

B

C

D

E

Vehicle fitted with intermittent

Special note

windscreen wipers

When driving the vehicle, the wiping

speed slows down whenever the ve-

A single sweep

hicle stops. For example, fast wiping

A short push will trigger one sweep

speed will slow to normal wiping speed.

of the wipers.

As soon as the vehicle moves off,

B stop

wiping will return to the speed originally

C intermittent wiping

selected.

The wipers will pause for several

If stalk 1 is operated, it overrides and

seconds between sweeps. It is

cancels the automatic function.

possible to change the time be-

tween sweeps by turning ring 2.

D slow continuous wiping

E fast continuous wiping

1.107

CarManuals2.co

WINDSCREEN WASH, WIPE (2/5)

When activating automatic wiping

or when increasing sensitivity, one

sweep of the blades is performed.

A

1

F

Note:

1

2

- the rain sensor is only intended as a

B

driving aid. In the event of reduced

visibility, the driver should manually

C

activate the wipers. In foggy weather

or during snowfalls, wiping is not au-

D

tomatically triggered and remains

E

G

under the driver’s control;

- in the event of temperatures below

zero, automatic wiping is not acti-

vated when the vehicle is started. It

is automatically activated as soon as

Vehicle fitted with front

C

automatic wiper function

the vehicle exceeds a certain speed

When this position is selected, the

windscreen wiper rain sensor

(approximately 5 mph (8 km/h));

system detects water on the wind-

The rain sensor is located on the winds-

screen and triggers the wipers at a

- do not activate automatic wiping in

creen, in front of the interior rear-view

suitable wiping speed. It is possi-

dry weather;

mirror.

ble to change the triggering thresh-

- fully de-ice the windscreen before

old and the time sweeps by turning

A single sweep

activating automatic wiping.

ring 2:

A short push will trigger one sweep

- F: minimum sensitivity

of the wipers.

- G: maximum sensitivity

B stop

The higher the sensitivity, the

quicker the wipers will react and

the faster the wipe.

1.108

CarManuals2.co

WINDSCREEN WASH, WIPE (3/5)

Operating faults

Special note

In the event of a malfunction of the au-

When driving the vehicle, the wiping

tomatic wiping, the wiper is set to inter-

speed slows down whenever the vehi-

A

mittent wiping. Contact an authorised

cle stops. For example, fast wiping

1

dealer.

speed will slow to normal wiping speed.

As soon as the vehicle moves off,

The operation of the rain sensor can be

B

wiping will return to the speed originally

disturbed in the event of:

selected.

- damaged windscreen wipers; a

C

If stalk 1 is operated, it overrides and

film of water or traces left by a

cancels the automatic function.

blade in the sensor’s detection

D

zone may increase the response

E

Precautions

time of the automatic wiper, or in-

crease the wiping frequency;

- In the event of ice, check whether the

- a windscreen with any chip or

blades are stuck to the windscreen

crack level with the sensor, or a

before operating the wiping mecha-

windscreen covered in dust, dirt,

nism. If you activate the wipers while

D

slow continuous wiping

insects, ice, the use of washing

the blades are stuck down with ice,

wax and water-repellent chemi-

E

fast continuous wiping

you may risk damaging both the

cals; the windscreen wiper will

blade and the wiper motor.

be less sensitive or may even not

- Do not activate the wipers on a dry

react at all.

screen. This will lead to premature

wear or damage to the blades.

1.109

CarManuals2.co

WINDSCREEN WASH, WIPE (4/5)

Specific front wiper position

(service position)

This position enables the blades to be

A

lifted to remove them from the winds-

1

creen.

B

It may be useful to:

- to clean the blades;

C

- to release the blades from the winds-

creen in winter;

D

- replace the blades ➥ 5.33.

E

With the ignition on or the engine run-

ning, lift the 1 stalk twice to position A

(single sweep). The blades stop slightly

away from the bonnet.

To return the blades to low position,

with the ignition on, ensure that the

wipers have folded down onto the wind-

screen, then move the stalk 1 to posi-

tion A (single sweep).

Before switching on the ignition,

In the event of obstacles on the

place the wipers on the windscreen.

windscreen (dirt, snow, ice etc.),

Otherwise, there may a risk of damage

clean the windscreen (including the

to the bonnet or the wipers when they

central area located behind the inte-

are switched on.

rior rear view mirror) before starting

Before

carrying

out any

the wipers (risk of motor overheat-

action involving the wind-

ing).

screen (washing the vehi-

If an object is preventing a blade

cle, de-icing, cleaning the

from moving, it may stop functio-

windscreen etc.) return the 1 stalk

ning. Remove the obstacle and

to position B (stop).

reactivate the wiper using the wiper

Risk of injury and/or damage.

stalk.

1.110

CarManuals2.co

WINDSCREEN WASH, WIPE (5/5)

Note:

In temperatures below zero, the washer

1

liquid risks freezing to the windscreen,

thereby reducing visibility. Heat the

windscreen using the demister control

before cleaning.

Efficiency of a wiper blade

Check the condition of the wiper

blades. How long they last depends

on you:

- it must remain clean: clean the

blade and the screen regularly

with soapy water;

- do not use it when the screen is

dry;

Windscreen washer

- free it from the screen when it has

With the ignition on, pull stalk 1 then

not been used for a long time.

release.

In all cases, replace it as soon as

A longer pull will trigger, in addition to

it begins to lose efficiency: approxi-

the windscreen washer, two sweeps

mately once a year. ➥ 5.33.

of the wipers followed, a few seconds

later, by a third.

Precaution for using the

On vehicles fitted with a multimedia

wipers

screen, you can choose to activate or

disable the third sweep of the blades.

- In freezing or snowy weather

➥ 1.89.

conditions, clear the screen

When working in the engine

before starting the wipers (risk of

compartment, ensure that

motor overheating);

the windscreen wiper stalk

- ensure that no objects are ob-

is in position B (park).

structing the travel of the blade.

Risk of injury.

1.111

CarManuals2.co

REAR SCREEN WASHER, WIPER (1/2)

To stop the operation, pivot ring 3 again.

Note

3

2

When washing using a roller type car

wash, return the ring 3 on the stalk 1

1

to the stop position to deactivate auto-

matic wiping.

Follow usage recommendations.

Efficiency of a wiper blade

Check the condition of the wiper

blades. How long they last depends

on you:

- it must remain clean: clean the

blade and the screen regularly

with soapy water;

- do not use it when the screen is

dry;

Rear screen wiper

- free it from the screen when it has

Y

With the ignition on, rotate the

not been used for a long time.

ring 3 on the lever 1 until the symbol is

In all cases, replace it as soon as

opposite the reference point 2.

it begins to lose efficiency: approxi-

- stopping

mately once a year. ➥ 5.33.

Do not use the wiper arm to open or

- intermittent wiping

close the tailgate.

The wipers will pause for several

Precaution for using the

seconds between sweeps. Wiping

wipers

frequency varies with vehicle

speed;

Before any action involving

- In freezing or snowy weather

conditions, clear the screen

the rear screen (washing

– slow continuous wiping

before starting the wipers (risk of

the vehicle, de-icing, clean-

motor overheating);

ing, etc.) return stalk 1 to

- ensure that no objects are ob-

the stop position.

structing the travel of the blade.

Risk of injury and/or damage.

1.112

CarManuals2.co

REAR SCREEN WASHER, WIPER (2/2)

Activation/deactivation of the rear

In the event of obstacles present on the

screen wiper

rear window (dirt, snow, etc.), the wiper

will try to sweep away all the obstacles.

Engaging reverse gear triggers inter-

If an obstacle prevents the blade from

mittent wiping (if the front wipers are in

moving, it can be stopped. Remove the

1

operation). If your vehicle is equipped

obstacle, wait for around 30 seconds

with a vehicle settings customisation

and reactivate the wiper using the wiper

menu, you can opt to activate or deacti-

stalk.

vate this function. ➥ 1.89.

For vehicles not fitted with a settings

Precautions

customisation menu, you can have this

- In the event of ice, check that the

function deactivated by an authorised

blades are not stuck to the wind-

dealer.

screen before operating the wipers.

If you activate the wiper while the

blade is blocked by ice, you risk dam-

aging both the blade and the wiping

motor.

Rear screen wash/wipe

p

- Do not operate the wipers on a dry

With the ignition on, push and

screen. This will lead to the prema-

hold stalk 1, then release.

ture wear or damage to the blades.

Holding the stalk for longer will trigger

(in addition to the windscreen washer)

two sweeps of the wipers followed,

a few seconds later, by a third (drip

wiping function).

When the stalk is released, it returns to

the rear wipe position.

1.113

CarManuals2.co

FUEL TANK (1/5)

Fuel grade

Use a high-grade fuel that complies

with the legislation in force in each

country and which must comply with

1

the specifications given on the label on

1

the cover 1. ➥ 6.6.

3

A

2

Fuel types that conform to European

standards with which the engines of

vehicles sold in Europe are compat-

ible: refer to the table ➥ 6.6.

Useable tank capacity:

- Approximately

9.24

gallons

(42 litres) for petrol versions;

Do not mix even small

- Approximately

8.58

gallons

amounts of petrol

(un-

Filler cap: this is specific.

(39 litres) for diesel versions.

leaded or E85) with diesel.

With the vehicle unlocked, to open

If you have to replace it,

Do not use ethanol-based

cover 1, press area A then release. The

make sure it is identical to

fuel if your vehicle is not compatible

cover 1 opens slightly.

the original cap. Contact an

with this fuel.

Use the cap holder 2 on the flap 1

approved Dealer.

Do not add reagent to the fuel - oth-

during filling to hold the cap 3 in place.

Never place the cap near a source

erwise you risk damaging the engine

For details on filling the fuel tank, refer

of heat or flame.

➥ 0.8. If you wish to add an additive

to the information on “Filling up with

Do not wash the filler area with a

to the fuel, use a product approved

fuel”.

high-pressure washer.

by our Technical Department.

To close it, press on the fuel filler flap by

Consult an approved dealer.

hand, as far as it will go.

1.114

CarManuals2.co

FUEL TANK (2/5)

Filling with fuel

If it is not possible to add at least

1.10 gallons (5 litres) of fuel due to the

With the ignition off, insert the nozzle

fuel level in the tank, drive the vehicle

and insert it fully before turning it on to

until the tank has capacity.

fill the fuel tank (risk of splashing). Keep

1

the nozzle in this position throughout

Petrol versions

the entire filling operation.

Using leaded petrol will damage the

When the pump cuts out automatically

antipollution system and may lead to a

at the end of the filling procedure, a

loss of warranty.

maximum of two further filling attempts

To ensure that the tank is not filled

may be made, as there must be suffi-

with leaded petrol, the fuel tank filler

cient space in the fuel tank to allow for

neck consists of a restrictor fitted with

expansion. Make sure that no water

a safety system which only allows

enters the fuel tank during filling. The

a nozzle for unleaded petrol to be

cover 1 and its surround must remain

used (at the pump).

clean.

Diesel version

Special case

It is essential to use diesel fuel that

conforms with the information given on

When the vehicle has been stopped for

the label inside cover 1.

around three months, you must add

fuel to prevent damage to the fuel

Petrol version

pump. To do this, with the ignition off,

It is essential to use unleaded petrol.

top-up at least 1.10 gallons (5 litres)

The octane rating (RON) must comply

then start the engine to operate the

To fill up with fuel, the engine

with the information given on the label

pump and renew the fuel in the circuit.

must be stopped (and not

on the cover 1. ➥ 6.6.

only on standby in the case

of vehicles equipped with

the STOP and START function): you

must switch off the ignition ➥ 2.4,

➥ 2.6.

Fire hazard.

After filling, check that the cap and

cover are closed.

1.115

CarManuals2.co

FUEL TANK (3/5)

Vehicles with card

No modifications what-

With the card in the passenger com-

soever are permitted on

4

partment, press the start button 4 with-

any part of the fuel supply

out pressing any of the pedals. Wait a

system

(electronic units,

few minutes before starting.

wiring, fuel circuit, injectors, pro-

This will enable the fuel circuit to be

tective covers, etc.) as this may be

primed. If the engine does not start,

dangerous (unless undertaken by

repeat the procedure.

qualified Network personnel).

If the engine does not start after several

attempts, please contact an authorised

dealer.

Running out of fuel on diesel

Persistent fuel odour

versions

If you notice a persistent

Vehicles with key/remote control

fuel odour you should:

- Set the ignition key to “On” position

- stop the vehicle as soon as traf-

M ➥ 2.3 and wait a few minutes

fic conditions allow and switch off

before starting to enable the fuel cir-

the ignition;

cuit to be primed;

- switch on the hazard warning

- turn the key to position D. If the

lights and ask your passengers to

engine does not start, repeat the pro-

leave the vehicle and stay clear

cedure;

of the traffic;

- if the engine does not start after sev-

- contact an approved Dealer.

eral attempts, please contact an au-

thorised dealer.

1.116

CarManuals2.co

FUEL TANK (4/5)

Useable capacity of the LPG tank: ap-

5

5

proximately 7.04 gallons (32 litres).

Filling up with LPG

Apply the parking brake, stop the

engine, switch off the ignition and

switch off the lights.

Always respect the safety instructions

5

given at filling stations.

Depending on the country, before refill-

ing you must screw the filling adapter 5

onto the LPG filler end piece.

It is always advisable to completely fill

the tank.

When the pump stops delivering LPG,

Filling stations without self-

or when the pump flow reduces signif-

service

icantly, the maximum LPG level has

been reached.

If the service station personnel carry

IMPORTANT: LPG filling

At this point, do not attempt to carry on

out the LPG filling procedure, you must

adapter 5

filling.

give them the adapter 5.

Depending on the country, the use

of a specific adapter is required for

LPG filling.

The filling adapter 5 is provided in

a pouch in the glove box. It may or

may not be present in the vehicle,

depending in which country the ve-

hicle was sold.

Before driving the vehicle to another

country, it is essential to consult an

If you exceed the LPG tank capacity when topping-up, please go to an

approved dealer to find out the type

accredited garage or an authorised dealer to check the automatic filler

of adapter to use if necessary.

device.

1.117

CarManuals2.co

FUEL TANK (5/5)

Depending on the type of station, it may

be necessary to perform press and hold

6

the station button before filling will start.

When the pump stops supplying LPG,

or when the pump flow reduces sig-

nificantly, the maximum tank level has

been reached.

The filling will stop as soon as you re-

lease the button. Release the stop

lever (a small amount of gas may be re-

leased), lift the pistol and place it on the

7

distributor.

Replace the cap 6 to avoid any water

or foreign bodies from entering the

system.

Filling stations with self-

service

We recommend that you wear gloves

when handling the LPG pistol.

Open the tank flap of your vehicle and

unscrew the cap 6 from the end piece

of the LPG filler 7.

Carefully follow the instructions shown

on LPG distributors. These explain how

to fill up properly.

1.118

CarManuals2.co

REAGENT TANK (1/4)

Please ensure that you comply with the

legislation of your country. It is impor-

tant to remember that failure to respect

regulations in force could lead to legal

action being taken against the vehicle

1

To fill up with reagent, the engine

owner.

A

must be stopped

(and not on

standby in the case of vehicles

equipped with the STOP and Start

Operating principle

function). You must switch off the ig-

The reagent is intended for diesel en-

nition ➥ 2.4 ➥ 2.6.

gines fitted with the SCR (selective cat-

alytic reduction) system.

Using a reagent reduces the quantity of

nitrogen oxides in exhaust gases.

If the

“XXX MILES (XXX

Reagent consumption in real time de-

KM) failure Top up AdBlue”

pends on vehicle usage conditions, the

warning message appears,

equipment fitted, and driving style.

Filling

fill the reagent tank and

refer to the filling instructions.

Useable capacity of the tank: 2.42

Reagent quality

gal (11 litres) approximately.

Risk of immobilisation of the ve-

Use only reagents which conform

hicle.

With the ignition switched off, open the

to standard ISO 22241 and in accor-

cover A, then unscrew the cap 1.

dance with the mark on the tank filler

cap.

Note: ammonium hydroxide vapour

may escape from the cap opening

Fuel filler cap: this is a

when the tank temperature is high.

specific type.

If you have to replace it,

make sure it is identical

to the original cap. Contact an ap-

proved Dealer. Do not wash the filler

area with a high pressure washer.

The reagent must not come into contact with eyes or skin. If it does, wash

the affected area with plenty of cold water. If necessary, consult a doctor.

1.119

CarManuals2.co

IGNITION SWITCH: vehicle with key

“Ignition” position ON 2

The ignition is switched on: Any acces-

sories (radio etc.) can be used.

“Start” position START 3

If the engine fails to start at the first

attempt, the key must be turned back

before the starter can be activated

again. Release the key as soon as the

engine starts.

Note: on diesel versions, several sec-

onds may pass between turning the

key and the engine starting to allow for

engine preheating.

Ignition switch

Off position LOCK 0 (steering lock

applied)

To lock: remove the key and turn the

steering wheel until the steering column

locks.

To unlock: turn the key and the steering

wheel slightly.

2.3

CarManuals2.co

Content      ..     1      2      3      4      ..
