Renault Twizy (2018 year). Manual - part 4

2.8

ENVIRONMENT

Please make your own

contribution towards

protecting the environment

too.

– Worn parts replaced in the course of

routine vehicle maintenance (vehi-

cle battery, etc.) must be disposed of

through specialist bodies.

– At the end of the vehicle’s service

life, it should be sent to approved

centres to ensure that it is recycled.

– In all cases, comply with local legis-

lation.

Recycling

Your vehicle is 85% recyclable and

95% recoverable.
To achieve these objectives, many of

the vehicle components have been de-

signed to enable them to be recycled.

The materials and structures have

been carefully designed to allow these

components to be easily removed and

reprocessed by specialist companies.
In order to preserve raw material re-

sources, this vehicle incorporates nu-

merous parts made from recycled plas-

tics or renewable materials (vegetable

or animal-derived materials such as

cotton or wool).

Your vehicle has been designed with

respect for the environment in mind for

its entire service life: during production,

use and at the end of its life.

Manufacture

Your vehicle has been manufactured at

an industrial site which uses a progress

policy to reduce environmental impacts

on rivers and natural areas (reduc-

tion of water and energy consumption,

visual and noise pollution, atmospheric

emissions and waste water, sorting and

reusing waste).

2.9

CHARGE METER/ECO-CONSUMPTION

Eco-consumption (Éco ScorE)

This function shows the driver whether

their driving style is suitable for an opti-

mum vehicle range.

To display this function, press the end

of the windscreen wiper stalk as many

times as necessary.
The squares C indicate increased

range: the more squares there are, the

more range there is remaining for the

vehicle.

Éco ScorE is calculated using the aver-

age from the last 1.8 miles (3 kilome-

tres) travelled. After the traction battery

is charged, it is calculated based on the

last 93 miles (150 kilometres).

Power recovery B
When driving, if you lift your foot off the

accelerator pedal, the motor generates

electrical current during deceleration,

and this energy is used to recharge the

traction battery.

Charge meter

The charge meter gives the driver a

real-time view of the vehicle’s remain-

ing power.

Power consumption A
The traction battery supplies the elec-

trical energy required for the motor to

move the vehicle.

2.10

3.1

Section 3: Your comfort

Windscreen de-icing, demisting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2

Passenger compartment storage/fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3

3.2

WINDSCREEN DE-ICING, DEMISTING



De-icing or demisting

the windscreen

With the engine running, turn the end of

stalk 1. Warning light 2 lights up on the

instrument panel.
This function enables quick electric

deicing/demisting.

To exit this function
Turn the end of stalk 1. Warning light 2

goes out on the instrument panel.
Demisting automatically stops approxi-

mately 10 seconds after it is activated.

Recommendations
In the event of freezing, manu-

ally de-ice the windscreen using a

scraper rather than the de-icing/de-

misting function in order to reduce

your energy consumption.

3.3

Left-hand storage

compartment 1

To open, lift cover 2.

Right-hand storage

compartment 4

To open, lift cover 5.
To lock and unlock the storage com-

partment 4, insert the ignition key in

lock 6 and turn it.

PASSENGER COMPARTMENT STORAGE, FITTINGS

(1/4)

Accessories socket 3

Located in the storage compartment 1,

this is provided for connecting ac-

cessories approved by the Technical

Department with a maximum power of

65 watts (voltage of 12V).

Only connect accessories

with a maximum power of

65 watts.
Fire hazard.

Always leave the storage

compartment covers closed

when driving.
There is a risk of injury

when braking suddenly or in the

event of an accident.

3.4

PASSENGER COMPARTMENT STORAGE, FITTINGS

(2/4)

Ensure that no hard, heavy

or pointed objects are

placed in the “open” storage

compartments in such a

way that they may fall onto passen-

gers during sudden turning, braking

or in the event of an accident.

Rear storage space 10

To unlock the seat cushion B and the

seatback A, insert the ignition key in

lock 7 and turn it.

Unclip the seatback A, then slide it

back and pull towards you.

Move the seat cushion B in 8, then pull

upwards to unclip the base.

Push the seat cushion B and lift it

(movement C) to take it out from the

runners 9.
Note: when replacing, make sure you

lock the cushion and the seat back in

place.

The closure 7 enables the seat back

and cushion of the rear passenger

seat and the rear storage compart-

ment to be locked or unlocked.

Do not place an object or

pet on the storage space if

it has not first been secured

using a specific accessory

for the vehicle.
Risk of serious injury when braking

sharply or in an impact.

3.5

PASSENGER COMPARTMENT STORAGE, FITTINGS

(3/4)

Rear storage space

The rear seat can be transformed into a

storage space.
– To unlock the seat cushion B and the

seatback A, insert the ignition key in

lock 7 and turn it;

– unclip the seatback A, then slide it

downwards and pull towards you;

Ensure that no hard, heavy

or pointed objects are

placed in the “open” storage

compartments in such a

way that they may fall onto passen-

gers during sudden turning, braking

or in the event of an accident.

– move the seat cushion B in 8, then

pull it upwards to unclip the base;

– push the seat cushion B and lift it

(movement C) to take it out from the

runners 9;

– depending on the vehicle, insert the

blanking cover 11 into the seatbelt

housing. On vehicles fitted with it,

the blanking cover 11 is located on

the back of seatback A;

3.6

Driver’s responsibility
Never use the storage

space as a booster seat for

a person or pet. Otherwise,

this could place your child or pet in

danger, or endanger the driver, in

the event of hard braking or impact.
Risk of death or serious injury.

Driver’s responsibility
Do not place any objects

in the storage space if this

space is not secured using

the specific accessory for your ve-

hicle.
Please see an authorised dealer.
Risk of serious injury when braking

sharply or in heavy impacts.

PASSENGER COMPARTMENT STORAGE, FITTINGS

(4/4)

–  turn the seat B;
–  insert the seat B into the runners 9;
–  correctly position the seat B;
– clip the seatback A from top to

bottom;

– lock the seat cushion B and the seat-

back A using lock 7.

Maximum load allowed in the rear

storage space: 10 kg, evenly distrib-

uted.

4.1

Section 4: Maintenance

Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2

Brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2

windscreen washer reservoir . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.3

12 volt battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.4

Bodywork maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.6

Interior trim maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.8

4.2

Brake fluid level

The level control should be read with

the vehicle on level ground. This should

be checked frequently, and immedia-

tely if you notice even the slightest loss

in braking efficiency.

Accessing the brake fluid reservoir
Unclip the upper bar 2 of the bonnet

before moving your hand in 1.

Topping up
After any operation on the hydraulic cir-

cuit, a specialist must replace the fluid.

Only use fluids approved by our

Technical Department (and taken from

a sealed container).

Replacement intervals
Refer to the Maintenance Document for

your vehicle.

Consult your approved dealer at

once if you notice an abnormal or

repeated drop in any of the fluid

levels.

LEVELS

(1/2)

Level 3
It is normal for the level to drop as

the linings become worn, but it should

never drop below the MIN line.

If you wish to check the disc wear your-

self, you should obtain the document

explaining the checking procedure from

our network or from the manufacturer’s

website.

4.3

Windscreen washer reservoir

Topping up
Open flap 5.
Open cap 4 and fill until you see the

liquid. Then close the cap.

Liquid
Screen wash product (product with an-

tifreeze in winter).

LEVELS

(2/2)

Jet
Use a pointed tool to adjust the height

of the windscreen washer jets.

4.4

12V BATTERY

(1/2)

The secondary battery is a 12 V battery:

this supplies the energy required to op-

erate vehicle equipment (lights, wind-

screen wipers, audio system, etc) and

certain safety systems, such as ABS.

For your safety and the

proper operation of the

vehicle’s electrical equip-

ment (lights, windscreen

wipers, etc.), any work on the se-

condary 12V battery (removal, dis-

connection, etc.) must be carried

out by a specialist.

Risk of serious burns or electric

shocks.

Respect categorically the replace-

ment intervals (without exceeding

them) as stated in the maintenance

document.

The battery is a specific type.

Please ensure it is replaced with the

same type.

Contact an Authorised Dealer.

A 1

Label A
Observe the indications on the battery:

– 1 naked flames and smoking are for-

bidden;

– 2 eye protection required;

– 3 keep away from children;

– 4 explosive materials;

– 5 please consult the driver’s hand-

book;

– 6 corrosive materials.

4.5

12 VOLT BATTERY

(2/2)

Connecting a charger to the

accessories socket

Only use a charger that is compatible

with a nominal voltage of 14.4 volts

and a current limited to 5 amps.
With the ignition switched on, plug

the power supply into the accessories

socket 7 located in the storage com-

partment 8. Please consult an authori-

sed dealer.

Recharging the 12 volt

battery

It is difficult to access the 12 volt bat-

tery. It is therefore recommended that

you attach the vehicle plug to a power

source: energy is supplied to both the

12 volt battery and the traction battery

at the same time.

Please refer to the information on

“Electric vehicle: charging” in Section 1.

Do not forget to switch off the ignition

when replacing the traction battery.

Immobilising the vehicle for an

extended period of time
Before immobilisation, you should

make sure that:

– the ignition is switched off;

– the side lights and hazard warning

lights are switched off;

– the traction battery is fully charged.
After lengthy immobilisation, it is normal

to find the traction battery charge

level down. In this case, recharge it

(see “Electric vehicle: charging” in

Section 1).

Do not use booster cables

to start the vehicle.

Risk of serious injury.

Only connect accessories

with a maximum power of

65 watts. When several ac-

cessory sockets are used

at the same time, the total power of

the connected accessories must not

exceed 65 watts.

Fire hazard.

4.6

BODYWORK MAINTENANCE

(1/2)

A well-maintained vehicle will last

longer. It is therefore recommended to

maintain the exterior of the vehicle reg-

ularly.

Some parts may look different over time

(e.g.: bleaching, etc.)

Your vehicle has been treated with very

effective anti-corrosion products. It is

nevertheless subject to various outside

influences.

Corrosive agents in the atmosphere

–

atmospheric pollution (built-up and

industrial areas);

–

saline atmospheres (near the sea,

particularly in hot weather);

–

seasonal and damp weather condi-

tions (e.g. road salt in winter, water

from road cleaners, etc.).

Minor impacts

Abrasive action

Dust and sand in the air, mud, road grit

thrown up by other vehicles, etc.
You should take a number of minor pre-

cautions in order to safeguard your ve-

hicle against such risks.

You should

Wash your car frequently, with the

engine off, with cleaning products rec-

ommended by the manufacturer (never

use abrasive products). Rinse thor-

oughly beforehand with a jet:

–

spots of tree resin and industrial

grime;

–

mud in the wheel arches and under-

neath the body which forms damp

patches;

–

bird droppings, which cause a

chemical reaction with the paint that

rapidly discolours paintwork and

may even cause the paint to peel

off;

wash the vehicle immediately to

remove these marks since it is im-

possible to remove them by polish-

ing;

–

salt, particularly in the wheel arches

and underneath the body after driv-

ing in areas where the roads have

been gritted.

Remove any plant matter (resin, leaves,

etc.) from the vehicle regularly.

Respect local regulations about wash-

ing vehicles (e.g. do not wash your ve-

hicle on a public highway).
Observe the vehicle stopping distances

when driving on gravelled surfaces to

prevent paint damage.
Repair, or have repaired quickly, areas

where the paint has been damaged, to

prevent corrosion spreading.
Remember to visit the body shop pe-

riodically in order to maintain your

anti-corrosion warranty. Refer to the

Maintenance Document.
If it is necessary to clean mechani-

cal components, hinges, etc., spray

them with products approved by our

Technical Department to protect them

after they have been cleaned.

We have selected special products

to care for your vehicle and you can

obtain these from the manufactur-

er’s accessory outlets.

4.7

BODYWORK MAINTENANCE

(2/2)

Cleaning the roof

Use a soft cloth or cotton wool.

Soak it lightly with a protective agent

recommended by our Technical

Department.

Spread the protective agent carefully

in circular movements using a soft or a

cotton cloth.

What you should not do

Wash the vehicle in bright sunlight or

freezing temperatures.
Do not scrape off mud or dirt without

pre-wetting.
Allow dirt to accumulate on the exterior.
Allow rust to form following minor im-

pacts.
Do not use solvents not approved by

our Technical Department to remove

stains as this could damage the paint-

work.
Do not drive in snow or muddy condi-

tions without washing the vehicle, par-

ticularly under the wheel arches and

body.

Degrease or clean using

high-pressure cleaning

equipment or by spray-

ing on products not ap-

proved by our Technical

Department:

–

mechanical components (e.g.:

engine compartment);

–

underbody;

–

parts with hinges (e.g.: inside the

doors);

–

painted plastic external fittings (e.g.:

bumpers).

Doing this could give rise to corrosion

or operational faults.

Content .. 2 3 4 5 ..
