Renault Scenic (2018 year). Manual

3.1

Section 3: Your comfort

Multi-Sense . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2

Air Vents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4

Manual air conditioning/heating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.6

Automatic climate control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.9

Air conditioning: information and advice on use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.19

Outside air quality and deodorisation function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.21

Multimedia equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.22

Electric windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.24

Fixed glass roof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.26

Interior lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.27

Sun visor/blinds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.29

Passenger compartment storage/fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.30

Accessories socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.38

Ashtray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.38

Cigarette lighter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.38

Rear headrests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.39

Rear seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.40

Luggage compartment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.46

Rear parcel shelf . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.47

Luggage cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.48

Luggage compartment storage space and fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.49

Transporting objects in the luggage compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.51

Transporting objects: towbar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.52

Luggage net. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.53

Roof bars . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.56

3.2

MULTI-SENSE

(1/2)

The Multi-Sense system enables once

of five modes to be selected which, de-

pending on the vehicle, affect the drive,

the light environment, the comfort and

the engine noise:

– modes Comfort , Neutral, Eco and

Sport are preset and associated with

customisable light environments and

engine noise;

– mode Perso is fully customisable.
The drive modes affect the:

– power-assisted steering;

– engine and gearbox responsiveness;

– heating level.
They also affect the:

– passenger compartment and instru-

ment panel lighting;

– instrument panel and multifunction

screen information;

– engine noise;

– massage seat.
After each start-up, the vehicle uses the

mode set at the time the engine was

last switched off.

Mode Comfort

This mode favours smooth steering.

The interior environment is softened.

Mode Neutral

Default mode, mode Neutral selects the

vehicle factory settings.

Mode Eco

Mode Eco is geared towards saving

energy and the environment. The

steering is smooth, engine and gearbox

management enable fuel consumption

to be lowered. Air conditioning is man-

aged to be used only when necessary.
Please refer to the information on

“Driving advice, Eco-driving” in

Section 2.

Multi-Sense

Sport

Eco

Neutral

Comfort

Perso

In all modes, it is possible to change

the colour of the ambient lighting as

well as the format of the information

displayed on the instrument panel

and multifunction display.
You can also reset to the default set-

tings.

3.3

MULTI-SENSE

(2/2)

Sport mode

This mode enables an increased re-

sponsiveness from the engine and the

gearbox. The steering is firmer.

Mode Perso

This mode enables you to manually

configure the drive, light environment

and, depending on the vehicle, the

comfort and engine noise.

Stopping the engine in Sport

mode, or Perso mode with engine

setting in Sport mode.
When you restart the vehicle, a mes-

sage asks you if you wish to keep

the engine setting in Sportmode.

Accessing the menu

You can access Multi-Sense, depend-

ing on the vehicle:

– from the multifunction screen 1.

Select menu “Vehicle” then “Multi-

Sense”;

– using switch 2;

– using button Eco 3 which automati-

cally launches Eco mode and opens

the “Multi-Sense” menu on the multi-

function screen 1 for a few seconds.

3.5

AIR VENTS: air outlets

(2/2)

To remove bad odours from your ve-

hicles, only use the systems designed

for this purpose. Consult an approved

Dealer.

Front seats

Direction
Up/down: lower or raise tabs 8.

Air flow
Turn control knob 9.

To fully close, turn beyond the point of

resistance.

Do not add anything to the

vehicle’s ventilation circuit

(for example, to remove

bad odours).

There is a risk of damage or of

fire.

2nd row rear seats

Output/direction
Move the cursor 10:
– downwards to decrease the air flow

and direct it downwards;

– upwards to increase the air flow and

direct it upwards;

– to the right or left.

3.6

The controls

1 Air temperature adjustment/”Clear

View” function

2 De-icing/demisting of the rear screen

and, depending on the vehicle, the

door mirrors.

3 Air conditioning.
4 Air recirculation.
5 Adjusting air distribution in the pas-

senger compartment.

6 Adjusting the ventilation fan speed.
7 Adjusting the ventilation speed and

stopping the system.

MANUAL AIR CONDITIONING

(1/3)

Switching air conditioning on

or off

The air conditioning is switched on (in-

dicator light on) or off (indicator light off)

using the control 3.

The air conditioning system is used

for:
– lowering the temperature inside the

passenger compartment;

– eliminating condensation more

quickly.

Indicators

The following indicators are displayed

on the multimedia screen A:
8 Air temperature.
9 Active mode.
10 Fan speed.
11 Distribution of air in the passenger

compartment.

9 10 11

3.7

MANUAL AIR CONDITIONING

(2/3)

Distribution of air in the

passenger compartment

There are five air distribution options.

Turn control 5 to choose the distribution

option.
The air distribution is displayed on the

multimedia screen.

The air flow is directed to the

windscreen and the front side

window demisting vents.

The air flow is distributed be-

tween all the air vents, the

front side window demisting vents, the

windscreen demisting vents and the

footwells.

The air flow is directed mainly

towards the footwells.

The air flow is directed towards

the dashboard air vents, the

front footwells and, depending on the

vehicle, the second row footwells.

All the air flow is directed to the

dashboard vents.

Adjusting the air temperature

Turn control 1 to obtain the desired

temperature. The more bars are dis-

played on the multimedia screen, the

higher the temperature.
When the air conditioning system is

used for long periods, it may begin to

feel cold. To increase the temperature,

turn control 1 to the right.

Rear screen de-icing/

demisting

With the engine running, press the

control 2. The operating tell-tale comes

on.
This function permits rapid demisting/

de-icing of the rear screen and de-icing

of the door mirrors (on equipped vehi-

cles).
To exit this function, press the con-

trol 2 again.

Demisting automatically stops.

3.8

Clear View function

Press the control 1: the integrated indi-

cator light in the button comes on.

This function quickly demists and de-

ices the windscreen, the rear screen,

the front side windows, and the exte-

rior rear view mirrors (depending on the

vehicle). The air conditioning and rear

screen de-icing functions must be ac-

tivated.

MANUAL AIR CONDITIONING

(3/3)

Varying the ventilation speed

You can adjust the fan speed by press-

ing the controls 6 or 7 to increase or

reduce the fan speed.

The system is deactivated (OFF): the

ventilation speed is zero (vehicle sta-

tionary). You can, however, still feel

a slight flow of air when the vehicle is

moving.

Stopping the system

To switch off the system, press the

control 7 several times until the mes-

sage “OFF” appears on the multimedia

screen.
You may, however, feel a slight flow of

air when the vehicle is moving.

Prolonged use of air recirculation can lead to condensation forming on the side windows and windscreen, and discomfort due

to the use of non-renewed air in the passenger compartment. We therefore advise you to return to normal mode (external air)

as soon as the air recirculation function is no longer required, by pressing the control 4 again.

Switching the air

recirculation on

Press the control 4: the integrated in-

dicator light in the button comes on.

Under these conditions, air is taken

from the passenger compartment and

is recirculated, with no air being taken

from outside the vehicle. Air recircula-

tion operates as follows:

– isolating the vehicle from the exter-

nal atmosphere (driving in polluted

areas, etc.);

– lowering the passenger compart-

ment temperature as quickly as pos-

sible.

3.9

AUTOMATIC CLIMATE CONTROL: Controls A

(1/5)

6 5 4 3

Controls A

Press zone 14 to access the multifunc-

tion screen controls 1. The presence of

the controls detailed below will depend

on the vehicle model.
2 and 7 Left and right temperature indi-

cation adjustment.

3 De-icing/demisting of the rear screen

and, depending on the vehicle, the

door mirrors.

4, 8, 9 and 10 automatic modes
5 Air recirculation.
6 “Clear View” function.

11 and 18 Ventilation speeds.
12 Passenger compartment air distri-

bution.

13 Right and left temperature display.
14 Zone displaying air conditioning set-

tings.

15 “DUAL” function.
16 “Automatic recirculation” function.
17 Air conditioning.
19 Stopping the system.

Automatic mode

The automatic climate control system

guarantees comfort in the passen-

ger compartment and good visibility

(except in the event of extreme condi-

tions), while optimising consumption.

The system controls the ventilation

speed, air distribution, air recirculation,

and starting and stopping the air condi-

tioning and air temperature.
This mode consists of a choice of three

programmes:
NORMAL : allows the selected comfort

level to be best attained, depending on

the exterior conditions. Press button 4

or key 9.
SOFT: reaches the desired comfort

level more gently and silently. Press

button 8.
FAST: increases the flow of air in the

passenger compartment. This mode

is recommended in particular to opti-

mise comfort in the rear seats. Press

button 10.

Some buttons have a warning light

indicating their operative state.

Climate

3.10

Varying the ventilation speed

In automatic mode, the system uses

the most suitable amount of air to reach

and maintain the desired comfort level.
You can still adjust the ventilation speed

by pressing buttons 11 or 18 or by slid-

ing your finger in zone 20.

Temperature adjustment

There are two types of settings:

– uniform passenger compartment

setting;

– DUAL function setting to independ-

ently adjust the left and right sides.

Uniform passenger compartment

setting

Use control 7.

DUAL function setting

Press button 15 to activate. Use con-

trol 7 to adjust the left side and control 2

for the right side.

The displayed temperature values

show a comfort level.
When starting the engine, increas-

ing or decreasing the value dis-

played will not allow the com-

fort level to be reached any more

quickly. The system will always op-

timise the temperature increase or

decrease (the ventilation system

does not start instantly at maximum

speed: it gradually increases). This

may take several minutes.
Generally speaking, unless there is

a particular reason not to, the dash-

board air vents should remain open.

Note: the air conditioning configura-

tion depends on the mode selected in

the “Multi-Sense” menu (please refer

to the information on “Multi-Sense” in

Section 3).

AUTOMATIC CLIMATE CONTROL: Controls A

(2/5)

Climate

3.11

Press button 6 – the integrated indica-

tor light comes on.
Press button 3 to stop the heated rear

screen operating, and the integrated in-

dicator goes out.
To adjust the ventilation speed: press

buttons 11 or 18 or slide your finger in

zone 20.

Clear View function

This function quickly demists and de-

ices the windscreen, the rear screen,

the front side windows, and the door

mirrors (depending on the vehicle). It

imposes automatic operation of the

air conditioning and rear screen de-ic-

ing and, depending on the vehicle, the

windscreen electric de-icer.

To exit this function, press either:
– button 4;
– again button 6;
– on button 8, 9 or 10.

AUTOMATIC CLIMATE CONTROL: Controls A

(3/5)

Climate

3.12

Switching air conditioning on

or off

In automatic mode, the system switches

the air conditioning system on or off,

depending on the climate conditions.
Press button 17 to:
– activate the air conditioning (a warn-

ing light in zone 14 comes on);

– deactivate the air conditioning (the

warning light in zone 14 goes out).

Stopping the system

Press button 19 to activate or deacti-

vate the system (the operating warn-

ing light on button 19 notifies you of the

system status).

It is preferable to use one of the automatic programmes NORMAL, SOFT or

FAST.
In automatic mode (4 warning light is lit), all air conditioning functions are control-

led by the system.
You can still change the selection made by the system. In this case, the indicator

light for button 4 goes out.
To return to automatic mode, press one of the programmes NORMAL 9, SOFT 8

or FAST10 or the button 4.

Rear screen de-icing/

demisting

Press button 3 – the integrated indica-

tor light comes on. This function en-

ables rapid demisting or de-icing of the

rear screen and de-icing of the door

mirrors (on equipped vehicles).
To exit this function, press button 3

again. Demisting automatically stops.

AUTOMATIC CLIMATE CONTROL: Controls A

(4/5)

Climate

3.13

Automatic usage
Press button 16 (a warning light comes

on in zone 14).

Manual use
Press button 5 to force air recirculation.
Prolonged use of this position may lead

to odours, caused by non-renewal of

air, and the formation of condensation

on the windows.
We advise you to return to automatic

mode as soon as air recirculation is no

longer needed, by pressing key 16 or

button 5 again.
To exit this function, press key 16 or

button 5 again.

Adjusting the distribution

of air in the passenger

compartment

Press buttons 12 to select the desired

distribution (a warning light is displayed

in zone 14):

The air flow is mainly directed

to the demisting vents for the

windscreen and the side windows.

The air flow is mainly directed

to the dashboard air vents.

The air flow is directed mainly

towards the footwells.

The demisting/de-icing will still take

priority over the air recirculation.

Air recirculation

This function is managed automatically

but you can also activate it manually.

Note:
– during recirculation, air is taken from

the passenger compartment and

is recycled, with no air being taken

from outside the vehicle;

– air recirculation allows the exter-

nal atmosphere to be cut off (when

driving in polluted areas, etc.) and

to cool the passenger compartment

temperature more quickly.

AUTOMATIC CLIMATE CONTROL: Controls A

(5/5)

Climate

3.14

AUTOMATIC CLIMATE CONTROL: Controls B and C

(1/5)

Indicators

The following indicators are displayed

on the screen 3:
1 Active mode, ventilation speed and

air distribution in the passenger com-

partment (temporary display after

pressing the associated controls).

2 Outside air temperature.
4 Air temperature, left and right.

Automatic mode

The automatic climate control system

guarantees comfort in the passen-

ger compartment and good visibility

(except in the event of extreme condi-

tions), while optimising consumption.

The system controls the ventilation

speed, air distribution, air recirculation,

and starting and stopping the air condi-

tioning and air temperature.
This mode consists of a choice of three

programmes:
AUTO: allows the selected comfort

level to be best attained, depending

on the exterior conditions. Press the

button 15.
SOFT: reaches the desired comfort

level more gently and silently. Press the

button 14.
FAST: increases the flow of air in the

passenger compartment. This mode is

recommended in particular to optimise

comfort in the rear seats. Press the

button 16.

Some buttons have a warning light

indicating their operative state.

13 14 15

Controls B and C

5 and 11 Left and right temperature in-

dication adjustment.

6 De-icing/demisting of the rear screen

and, depending on the vehicle, the

door mirrors.

7 Passenger compartment air distribu-

tion.

8 “Automatic recirculation” function.

9 Air recirculation.

10 “Clear View” function.

12 and 18 Ventilation speeds.

13 “DUAL" function.

14, 15, and 16 Automatic modes.

17 Air conditioning.

18 5

13 14 15

18 5

3.15

Varying the ventilation speed

In automatic mode, the system uses

the most suitable amount of air to reach

and maintain the desired comfort level.
You can still adjust the ventilation

speed by pressing buttons 12 or 18 or,

depending on the vehicle, by sliding

your finger in zone 19.

Temperature adjustment

There are two types of settings:

– uniform passenger compartment

setting;

– “DUAL” function setting to independ-

ently adjust the left and right sides.

Uniform passenger compartment

setting

Use control 11.

“DUAL” function setting

Press button 13 to activate. Use con-

trol 11 to adjust the left side and con-

trol 5 for the right side.

The displayed temperature values

show a comfort level.
When starting the engine, increas-

ing or decreasing the value dis-

played will not allow the com-

fort level to be reached any more

quickly. The system will always op-

timise the temperature increase or

decrease (the ventilation system

does not start instantly at maximum

speed: it gradually increases). This

may take several minutes.
Generally speaking, unless there is

a particular reason not to, the dash-

board air vents should remain open.

Note: the air conditioning configura-

tion depends on the mode selected in

the “Multi-Sense” menu (please refer

to the information on “Multi-Sense” in

Section 3).

18 5

AUTOMATIC CLIMATE CONTROL: Controls B and C

(2/5)

Renault Scenic (2018 year). Manual - part 14
