Renault Scenic (2018 year). Manual

2.48

The function is set to notify the

driver if:

– speed is between about 43.4 mph

(70 km/h) and 124 mph (200 km/h);

and

– the line indicators 4 are coloured

green or, depending on the vehicle,

the



warning light is white.

The function triggers an alert if a line

is crossed without the direction indica-

tor being activated.
The function alerts the driver:

– by using a beep or, depending on

the vehicle, a vibration of the steer-

ing wheel;

and

– the indicator of the line crossed

turns red or, depending on the vehi-

cle, the 5



warning light is dis-

played on the instrument panel.

Note: on bends, the function allows for

slightly cutting the bend.

Operation

When the function is activated, the in-

dicators 4 for the left and right lines, or

depending on the vehicle, the



warning light, are displayed in grey on

the instrument panel.

LANE DEPARTURE WARNING

(2/4)

Conditions in which the

function is not available

– Indicators activated or having been

activated approximately four sec-

onds prior to departing from the lane;

– very fast lane departure;

– driving continuously near a line;

– 4 seconds approximately after

changing lanes;

– tight bends;

– impaired visibility;

– ...
If the function is unavailable, the line in-

dicators 4 or, depending on the vehicle,

the



warning light are displayed

in grey on the instrument panel.

2.49

LANE DEPARTURE WARNING

(3/4)

– “sensitivity”: adjust the sensitivity

level for line detection. To do this,

select:

–

“Low”: line detected when cross-

ing;

–

“Average”: line detected on ap-

proach;

–

“high”: line detected nearby.

Vehicles fitted with the “Lane keep-

ing assist” function:
From the multifunction screen 2,

select “Vehicle”, “Driving assistance”,

“SETTINGS”.
– “VOLUME”: adjust the volume of the

warning;

– “Intensity”: adjust the level of steer-

ing wheel vibration;

– “SENSITIVITY”: adjust the sensitiv-

ity level for line detection. To do this,

select:

–

“Low”: line detected when cross-

ing;

–

“Average”: line detected on ap-

proach;

–

“high”: line detected nearby.

Adjustment

Vehicles not fitted with the “Lane

keeping assist” function
From the multifunction screen 2, select

“Vehicle”, “Driving assistance”, “Lane

departure warning setting”.
– “VOLUME”: adjust the volume of the

warning;

– “Intensity”: adjust the level of steer-

ing wheel vibration;

Operating faults

In the event of a malfunction, the left

and right line indicators or, depending

on the vehicle, the



warning light

disappear or stay grey on the instru-

ment panel. In some cases, they are

accompanied by the message “Lane
departure warning check” or the

warning light on the instrument panel.

Consult an approved dealer.

2.50

This function is an additional driving aid. This function is not under any circumstances intended to replace the due care

and attention of the driver, who should at all times be in control of the vehicle.

System servicing/repairs

– In the event of an impact, the camera alignment may be changed, and its operation may consequently be affected. Deactivate

the function, then consult an authorised dealer.

– Any work in the area where the camera is located (repairs, replacements, windscreen modifications etc.) must be carried

out by a qualified professional.

Only an authorised dealer is qualified to service the system.

In the event of system disturbance

Some conditions can disturb or damage the operation of the system, such as:

– windscreen obscured (by dirt, ice, snow, condensation etc.);

– a complex environment (tunnel etc.);

– poor weather conditions (snow, hail, black ice etc.);

– poor visibility (night, fog etc.);

– road markings which are worn, lacking in contrast or very widely spaced from one another (lines partially erased etc);

– being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);

– the road is narrow, winding or undulating (tight bends etc.);

– closely following a vehicle travelling in the same lane.
Risk of false alarms or absence of warnings

LANE DEPARTURE WARNING

(4/4)

2.51

LANE KEEPING ASSIST

(1/4)

Using information from the camera 1,

the function is triggered if a contin-

uous or broken line is crossed without

activating the direction indicator lights,

with corrective action on the steering

system of the vehicle.
A notification on the instrument panel

appears to warn you of this.

On equipped vehicles, some infor-

mation is given on the head-up dis-

play.

Note: make sure the windscreen is not

obscured (dirt, mud, snow, condensa-

tion etc.).

This function is an addi-

tional driving aid. This func-

tion is not under any circum-

stances intended to replace

the due care and attention of the

driver, who should at all times be

in control of the vehicle.

2.52

LANE KEEPING ASSIST

(2/4)

Activation/deactivation

From the multifunction screen 2: select

“Vehicle”, “Driving assistance”, “Lane

Keeping” then



to activate or

“OFF" to deactivate it.

You can access menu “Driving as-

sistance” directly from button 3



Operation

When the function is activated, the cor-

rection indicators 4 for the left and right

lines are displayed in grey on the instru-

ment panel.
The function is set to react if:
– speed is between about 43.4 mph

(70 km/h) and 99.2 mph (160 km/h);

and

– the correction indicators 4 are green.
The function reacts if the vehicle ap-

proaches or crosses a line without ac-

tivation of the indicator lights. In these

cases:

– the function triggers corrective action

on the vehicle’s steering system and

trajectory;

– the indicator 4 on the same side as

the crossed side line turns orange on

the instrument panel.

Note: on bends, the function allows for

slightly cutting the bend.

The function is deactivated by de-

fault every time the engine is started.

You can retake control of the ve-

hicle at any time by operating the

steering wheel.

When Lane Keeping Assist is activated,

the “Lane Departure Warning” function

is automatically activated (please refer

to the information on “Lane Departure

Warning” in Section 2).

2.53

– only one line is detected;

– very fast lane departure;

– driving continuously near a line;

– impaired visibility;

– 4 seconds approximately after

changing lanes;

– during tight bends;

– the lane width is too narrow;

– ...
When the function is unavailable, the

correction indicators are displayed in

grey on the instrument panel.

LANE KEEPING ASSIST

(3/4)

Adjustment

From the multifunction screen 2,

select “Vehicle”, “Driving assistance”,

“SETTINGS”:

“SENSITIVITY”: adjust the sensitiv-

ity level for line detection. To do this,

select:

–

“Low”: line detected when cross-

ing;

–

“Average”: line detected on ap-

proach;

–

“high”: line detected nearby.

Operating faults

In the event of a malfunction, the left-

hand and right-hand correction indica-

tors disappear or remain grey on the in-

strument panel.

In some cases, they are accompanied

by the message “Check Lane Keeping”
or the

warning light on the in-

strument panel.

Consult an approved dealer.

Special case
When the function is set to react or it

reacts and cannot detect any further

action from the driver on the steering

wheel:

– the message “Keep control” appears

on the instrument panel;

– the right-hand and left-hand correc-

tion indicators turn orange;

– a beep sounds.
If the driver does not take action, the

system may switch off the warnings

above and make the function unavail-

able until the next action of the driver on

the steering wheel.

Conditions in which the

function is not available

– Correction indicators activated or

having been activated approximately

four seconds prior to crossing the

line;

– the driver’s hands are not on the

steering wheel;

2.54

This function is an additional driving aid. This function is not under any circumstances intended to replace the due care

and attention of the driver, who should at all times be in control of the vehicle.

System servicing/repairs

– In the event of an impact, the camera alignment may be changed, and its operation may consequently be affected. Deactivate

the function and consult an authorised dealer.

– Any work in the area where the camera is located (repairs, replacements, windscreen modifications etc.) must be carried

out by a qualified professional.

Only an authorised dealer is qualified to service the system.

In the event of system disturbance

Some conditions can disturb or damage the operation of the system, such as:

– windscreen obscured (by dirt, ice, snow, condensation etc.);

– a complex environment (tunnel etc.);

– poor weather conditions (snow, hail, black ice etc.);

– poor visibility (night, fog etc.);

– road markings which are worn, lacking in contrast or very widely spaced from one another (lines partially erased etc);

– being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);

– the road is narrow, winding or undulating (tight bends etc.);

– closely following a vehicle travelling in the same lane.
In this case, the “Lane Keeping Assist” may react incorrectly or not at all.

Risk of unwanted, incorrect correction or no correction of trajectory.
Deactivating the function

You must disable the function if:

– the area of the camera has been damaged (on the windscreen side or the interior rear-view mirror side);

– the road is slippery (snow, black ice, aquaplaning, gravel etc.) ;

– poor visibility (night, fog etc.);

– the windscreen is cracked or distorted (do not carry out windscreen repairs in this area; have it changed by an Authorised

Dealer);

– the vehicle is towing a trailer or a caravan;

– the vehicle is entering an area with several surface markings (an area with road works etc.).

LANE KEEPING ASSIST

(4/4)

2.55

BLIND SPOT WARNING

(1/4)

This system alerts the driver to other

vehicles in the detection zone A.
The system is activated when the vehi-

cle’s speed is between approximately

30 km/h (19 mph) and 140 km/h (87

mph).
This function uses sensors 1 installed in

the front and rear bumper of both sides.

Special feature

Make sure that the sensors are not ob-

scured (by dirt, mud, snow, etc.).

If a sensor is obscured, the message

“Blind spot clean sensor” will appear on

the instrument panel. Clean the sen-

sors.

This function is an addi-

tional aid which indicates

other vehicles in the blind

spot area.

It can never in any case be a sub-

stitute for care nor for the driver’s

responsibility while in charge of his

vehicle.
The driver should always be ready

for sudden incidents while driv-

ing: always ensure that there are

no small, narrow moving obstacles

(such as a child, animal, pushchair,

bicycle, stone, post etc.) in the blind

spot when manoeuvring.

2.56

Activation/deactivation

Vehicles fitted with a navigation

system
On the multifunction screen 2, select

the “vehicle” menu, “Driving assist-

ance”, and “Blind spot alert”, and then

choose “ON” or “OFF”.

You can access menu “Driving as-

sistance” directly from button 3



Vehicles not fitted with a navigation

system
– With the vehicle at a standstill, press

and hold the switch 4 OK to access

the settings menu;

– repeatedly press the control 5 up or

down until you reach the “Driving as-

sistance” menu. Press the switch 4

OK;

BLIND SPOT WARNING

(2/4)

– repeatedly press the control 5 up or

down until you reach the Blind spot

alert menu, then press the switch 4

OK .

– press the 4 OK switch again to acti-

vate or deactivate the function.

When the engine is started, the system

remembers its position when the igni-

tion was last switched off.

2.57

BLIND SPOT WARNING

(3/4)

Operation

This function gives a warning:
– when the vehicle speed is between

approximately 19 mph (30 km/h) and

87 mph (140 km/h);

– when another vehicle is in the blind

spot area and travelling in the same

direction as your vehicle.

If your vehicle is overtaking another ve-

hicle, the indicator 6 will be activated

only if that vehicle remains in the blind

spot for more than one second.

Indicator 6

An indicator light 6 is located on each

door mirror 7.
Note: clean the door mirrors 7 regularly

so that the indicators 6 can be seen.

Display B

The function is activated and has not

detected any vehicles.

Display C

First warning: the indicator 6 means

that a vehicle has been detected in the

blind spot.

Display D

When the direction indicator is acti-

vated, the indicator light 6 flashes when

a vehicle is detected in the blind spot on

the side towards which you are about to

steer. If you cancel the direction indica-

tor, the function will return to the initial

warning (display C).

The system’s detection range oper-

ates according to a standard lane

width. If you are driving in narrow

traffic lanes, it may detect vehicles

in other lanes.

2.58

Operating faults

If the system detects a fault, the mes-

sage “Check blind spot alert” is dis-

played on the instrument panel. Consult

an approved dealer.
Note: when the engine is started, the

indicator light 6, display B, flashes

three times. It is normal.

– The system’s detection

range operates according

to a standard lane width. If

you are driving in wide traf-

fic lanes, the system might not

be able to detect a vehicle in the

blind spot.

– The system might be disrupted

momentarily if it is exposed to

strong electromagnetic waves

(as beneath high-tension power

lines) or to very poor weather

conditions (heavy rain, snow

etc.). Remain aware of driving

conditions.

There is a risk of accidents.

BLIND SPOT WARNING

(4/4)

Because sensors have

been installed in the bump-

ers, any work (repairs, re-

placements, touching up of

paintwork) must be carried out by a

qualified professional.

Conditions for non-function

–  If the object is not moving;
–  if traffic is heavy;
–  the road is winding;
–  if front and rear sensors both detect

an object at the same time (e.g.

when passing an articulated lorry).

– ...

2.59

SAFE DISTANCE ALERT

(1/3)

Activating/deactivating the

function

From the multifunction screen 2, select

menu “Vehicle”, “Driving assistance”,

“Distance warning” then choose “ON”

or “OFF”.

Using the information from the radar-

camera 1, this function informs the

driver of the time interval between him

and the vehicle in front so that a safe

stopping distance between the two ve-

hicles can be maintained.
Note: make sure the windscreen is not

obscured (dirt, mud, snow, condensa-

tion etc.).
The function is activated when the ve-

hicle speed is between about 18.6 and

124 mph (30 and 200 km/h).
When the engine is started, the func-

tion maintains the same status that was

active when the engine was last stop-

ped.

You can access menu “Driving as-

sistance” directly from button 3



This function is an addi-

tional driving aid. This func-

tion is not under any cir-

cumstances intended to

replace the due care and attention

of the driver, who should at all times

be in control of the vehicle.

2.60

SAFE DISTANCE ALERT

(2/3)

The measurement is dis-

played for information only:

the system performs no

action on the vehicle.

This function is not designed for use

in urban conditions or for a dynamic

driving style (sudden cornering, ac-

celeration, braking, etc.), but rather

for stable driving conditions.

The function does not interact with

the braking system.

The windscreen must remain clean

to ensure the correct operation of

the system.

– C (orange): the time interval falls

between around 1 and 2 seconds (in-

sufficient distance between the two

vehicles);

– D (red): the time interval is less than

or equal to around one second (very

insufficient distance between the two

vehicles).

If the interval between the two vehicles

is less than around 0.5 seconds, noti-

fication 4, display D, will flash on the

instrument panel. Under certain condi-

tions, the time interval may not be dis-

played:

– while cornering;

– when changing lane;

– if the vehicle in front is sufficiently far

or outside the range of the sensor.

This function is essential if adaptive

cruise control is activated.

On equipped vehicles, some infor-

mation is given on the head-up dis-

play.

Operation

Upon activating the function, indicator 4

notifies the driver of the distance sepa-

rating them from the vehicle in front.
–  A (grey): function not operational;
–  A (green): no vehicle detected;
–  B (green): the time interval is greater

than or equal to around two seconds

(distance between the two vehicles

adapted to your speed);

2.61

This function is an additional driving aid. This function is not under any circumstances intended to replace the due care

and attention of the driver, who should at all times be in control of the vehicle.

System servicing/repairs

– In the event of an impact, the radar-camera alignment may be changed, and its operation may consequently be affected.

Deactivate the function and consult an authorised dealer.

– Any work in the area where the radar-camera is located (repairs, replacements, windscreen modifications etc.) must be car-

ried out by a qualified professional.

Only an authorised dealer is qualified to service the system.

In the event of system disturbance
Some conditions can disturb or damage the operation of the system, such as:

– a complex environment (tunnel etc.);

– poor weather conditions (snow, hail, black ice etc.);

– poor visibility (night, fog etc.);

– poor contrast between the vehicle preceding it and the surrounding area (e.g. white vehicle in a snowy area etc.);

– being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);

– the road is narrow, winding and undulating (tight bends etc.)
Risk of erroneous false alarms.

SAFE DISTANCE ALERT

(3/3)

2.62

FATIGUE DETECTION WARNING

(1/2)

The fatigue detection warning is a func-

tion which is useful on monotonous

roads (motorways, high-speed roads

etc.).
It analyses driver behaviour and takes

account of events to inform you of any

risk of fatigue, such as:

– steering wheel movement;

– driver actions on other devices (indi-

cators, windscreen washer, etc.);

– time spent driving without stopping;

– ...

This function is an addi-

tional driving aid in case of

risk of fatigue. The function

does not take the place of

the driver.

Under no circumstances should this

function replace the driver’s care or

responsibility whilst driving.

Activation/deactivation

Vehicles fitted with a navigation

system
From the multimedia screen1: select

“Vehicle”, “Driving assistance”, “Fatigue

detection warn.” then choose “ON” or

“OFF”.

You can access menu “Driving as-

sistance” directly from button 2



When the engine is started, the

system remembers its position

when the ignition was last switched

off.

2.63

– repeatedly press the control 4 up or

down until you reach the “Fatigue de-

tection warn.” menu, then press the

switch 3 OK.

– press the 3 OK switch again to acti-

vate or deactivate the function.

Operation

The function is set to notify the

driver if:

– the vehicle speed is greater than ap-

proximately 37.2 mph (60 km/h);

and

– Approximately 15 minutes have

passed since the deletion of the pre-

vious warning.

The function triggers an alert if the

system detects repeated signs of fa-

tigue in the driver at the steering wheel.
When a risk of fatigue is detected,

the message “Fatigue warning have a

break” is displayed on the instrument

panel accompanied by a beep.
Press switch 3 OK to delete the warn-

ing.
It is advisable to stop as soon as pos-

sible for a break.

FATIGUE DETECTION WARNING

(2/2)

Note:
– if the warning is not deleted by press-

ing switch 3 OK, the beep repeats;

– the function may interpret certain

driving styles as a sign of tiredness

(sporty driving, incorrect driving, etc.)

or driving along a road which is in

poor condition.

Operating faults

If the system detects a fault, the mes-

sage “Check fatigue warning” is dis-

played on the instrument panel. Consult

an approved dealer.

Vehicles not fitted with a navigation

system
– With the vehicle at a standstill, press

and hold the switch 3 OK to access

the settings menu;

– repeatedly press the control 4 up or

down until you reach the “Driving as-

sistance” menu. Press the switch 3

OK;

Renault Scenic (2018 year). Manual - part 11
