Renault Sandero (2012 year). Manual

4.4

ENG_UD18250_2

Niveau huile moteur : généralités (B90 - L90 Ph2 - F90 Ph2 - R90 Ph2 - Dacia)

ENG_NU_817-9_B90_Dacia_4

It is normal for an engine to use oil for

lubrication and cooling of moving parts

and it is sometimes necessary to top up

the level between oil changes.
However, contact your approved dealer

if more than 0.5 litres is being con-

sumed every 600 miles (1,000 km) after

the running in period.
Oil change frequency: check the oil

level from time to time and certainly

before any long journey to avoid the

risk of damaging your engine.
The vehicle must be parked on level

ground and the engine should have

been switched off for some time before-

hand to obtain an accurate reading.

Engine oil level: general information

ENGINE OIL LEVEL: general information

Reading the oil level

– Remove dipstick 1 and wipe with a

clean, lint-free cloth;

– push in the dipstick as far as it will

go;

– take out the dipstick again;
– read the level: it should never fall

below minimum mark B or exceed

maximum mark A.

Once the level has been read, push the

dipstick in as far as it will go.

Exceeding the maximum engine

oil level
The oil level should only be read with

the dipstick as explained above.
If the oil level exceeds the maximum

level,

do not start your vehicle and

contact an approved dealer.

Under no circumstances

must maximum fill level

A be exceeded: risk of

damage to the engine and

catalytic converter.

Consult your approved dealer at

once if you notice an abnormal or

repeated drop in any of the fluid

levels.

In order to prevent splashback, it is

recommended that a funnel be used

when topping up/filling with oil.

engine oil grade ....................................(up to the end of the DU)

levels:

engine oil .........................................................(current page)

4.5

ENG_UD19757_10

Niveau huile moteur : appoint / remplissage (B90 - L90 Ph2 - Dacia)

ENG_NU_817-9_B90_Dacia_4

Engine oil level: topping up/filling

ENGINE OIL LEVEL: topping up/filling

(1/2)

Topping up/filling

The vehicle must be parked on level

ground and the engine should be cold

(for instance, before the engine is

started up for the first time in the day).

Engine oil grade

Refer to the Maintenance Service

Booklet for your vehicle.

– Unscrew cap 2;

– top up the level (as a guide, the ca-

pacity between the minimum and

maximum reading on dipstick 1 is

between 1.5 and 2 litres, depending

on the engine);

– wait approximately 10 minutes to

allow the oil to flow into the engine;

– check the level using dipstick 1 (as

described above).

Once the level has been read, push the

dipstick in as far as it will go.

When working in the engine

compartment, ensure that

the windscreen wiper stalk

is in the park position.

Risk of injury.

1.4 – 1.6

Do not exceed the

MAX level and

do not forget to refit dipstick 1 and

cap 2.

filter

oil filter .............................................................(current page)

oil change ..............................................................(current page)

4.6

ENG_UD19757_10

Niveau huile moteur : appoint / remplissage (B90 - L90 Ph2 - Dacia)

ENG_NU_817-9_B90_Dacia_4

Engine oil change

ENGINE OIL LEVEL: topping up/filling

(2/2)

Oil change

Service interval: refer to the

Maintenance Service Booklet for your

vehicle.

Average capacities for oil change oil

filter included.

(for information)

1.2 16V engines: 4.00 litres

1.4 engines : 3.30 litres

1.6 engines : 3.30 litres

1.6 16V engines: 4.80 litres

1.5 dCi engines : 4.10 litres

Engine oil grade

Refer to the Maintenance Service

Booklet for your vehicle.

Filling: take care when

topping up the oil that

no oil drips onto engine

components - risk of fire.

Remember to refit the cap securely

as there is a risk of fire if oil splashes

onto hot engine components.

Engine oil change: if you

are changing the oil when

the engine is hot, be careful

not to scald yourself if the

oil overflows.

The engine may be hot

during operations in close

proximity. In addition, the

engine cooling fan may

come on at any moment.
Risk of injury.

Consult an approved dealer at once

if you notice an abnormal or re-

peated drop in any of the fluid levels.

Resetting the alert after an oil

change

(depending on the vehicle)
If you change the oil yourself, you will

need to reset the oil change warning.

To do this, after switching on the igni-

tion, for ten seconds you must:

– Depress the accelerator pedal fully,

– with your foot on the accelerator, de-

press the brake pedal three times in

succession.

Reinitialisation is complete when the

indicator light goes out. If this is

not the case, repeat the operation.
Special case: if you change the oil

before the oil change interval exceeded

warning is displayed, it will also be nec-

essary to reset the display. In this case,
the

warning light comes on for

approximately 5 seconds to confirm the

reset.

Never run the engine in an

enclosed space as exhaust

gases are poisonous.

maintenance:

mechanical ......................................(up to the end of the DU)

brake fluid ..............................................................(current page)

levels ....................................................(up to the end of the DU)

tanks and reservoirs

brake fluid ........................................................(current page)

4.7

ENG_UD19766_9

Niveaux / Filtres (B90 - L90 Ph2 - Dacia)

ENG_NU_817-9_B90_Dacia_4

Levels:

Brake fluid

LEVELS

(1/3)

Brake fluid level

This should be checked frequently,

and immediately if you notice even the

slightest loss in braking efficiency.
The level should be read with the engine

switched off and on level ground.

Level
It is normal for the level to drop as the

brake shoes become worn, but it must

never drop lower than the “

MINI" warn-

ing line shown on brake fluid reser-

voir 1.
If you wish to check the disc and drum

wear yourself, you should obtain the

document explaining the checking pro-

cedure from the manufacturer’s net-

work or web site.

Consult your approved dealer at

once if you notice an abnormal or

repeated drop in any of the fluid

levels.

The engine may be hot

during operations in close

proximity. In addition, the

engine cooling fan may

come on at any moment.
Risk of burns.

Topping up
After any operation on the hydraulic cir-

cuit, a specialist must replace the fluid.
Only use fluids approved by the

Technical Department and which have

been taken from a sealed container.

Replacement intervals
Refer to the Maintenance Service

Booklet for your vehicle.

engine coolant .......................................................(current page)

tanks and reservoirs

coolant .............................................................(current page)

tanks and reservoirs:

windscreen washer ..........................................(current page)

4.8

ENG_UD19766_9

Niveaux / Filtres (B90 - L90 Ph2 - Dacia)

ENG_NU_817-9_B90_Dacia_4

Engine coolant

Windscreen washer reservoir

Coolant

With the engine switched off and on

level ground, the level

when cold must

be between the “

MINI" and “MAXI"

marks on reservoir 2.
Top this level up

when cold before it

reaches the “

MINI" mark.

No operations should be

carried out on the cooling

circuit when the engine is

hot.

Risk of burns.

Checking intervals
Check the coolant level regularly

(very severe damage is likely to be

caused to the engine if it runs out of

coolant).
If the level needs to be topped up, only

use products approved by our Technical

Department which ensure:
– protection against freezing;
– anti-corrosion protection of the cool-

ing system.

Replacement intervals
Refer to the Maintenance Service

Booklet for your vehicle.

Consult an approved dealer at once

if you notice an abnormal or re-

peated drop in any of the fluid levels.

LEVELS

(2/3)

The engine may be hot

during operations in close

proximity. In addition, the

engine cooling fan may

come on at any moment.
Risk of burns.

Windscreen washer reservoir

Filling: Remove cap 3, fill until you can

see the fluid, then refit the cap.
This reservoir supplies the front and

rear screen washers.
Liquid: Special windscreen washer

fluid (anti-freeze product in winter).
Jets: to adjust the angle of the jets

pivot the little ball using a pin.
Use products approved by the Technical

Department.

power-assisted steering.........................................(current page)

windscreen washer ................................................(current page)

power-assisted steering pump...............................(current page)

4.9

ENG_UD19766_9

Niveaux / Filtres (B90 - L90 Ph2 - Dacia)

ENG_NU_817-9_B90_Dacia_4

Power-assisted steering fluid reservoir

LEVELS

(3/3)

Power-assisted steering fluid

reservoir 4 or 5

Level: for a correct level when cold,

with the engine switched off and on

level ground, it must be visible between

the “MINI"

and “MAXI" marks on reser-

voir 4 or 5.
For maintenance operations on the

power-assisted steering, contact an ap-

proved dealer.

Consult an approved dealer at once

if you notice an abnormal or re-

peated drop in any of the fluid levels.

The engine may be hot

when carrying out opera-

tions in close proximity. In

addition, the engine cooling

fan can come on at any moment.
Risk of injury.

If you feel any variation in the ef-

fectiveness of the power-assisted

steering, consult an approved

dealer.

filter

air filter .............................................................(current page)

filter

diesel filter ........................................................(current page)

filter ........................................................................(current page)

filter

passenger compartment filter ..........................(current page)

4.10

ENG_UD20151_3

Filtres (B90 - U90 - L90 Ph2 - F90 Ph2 - R90 Ph2 - H79 - Dacia)

ENG_NU_817-9_B90_Dacia_4

Filters

FILTERS

The replacement of filter elements (air

filter, passenger compartment filter,

diesel filter, etc.) is scheduled in the

maintenance operations for your vehi-

cle.
Replacement intervals for filter el-

ements: refer to the Maintenance

Service Booklet for your vehicle.

Passenger compartment filter

If your vehicle is not originally fitted with

a passenger compartment filter, it is

possible to have one retrofitted.
Contact an approved dealer.

The engine may be hot

when carrying out opera-

tions in close proximity. In

addition, the engine cooling

fan can come on at any moment.
Risk of injury.

Air filter

If fitted to the vehicle, clogging sensor 1

allows you to see the condition of the

air filter.
Replacement of the filter is scheduled

in the maintenance operations: refer

to your vehicle’s Maintenance Service

Booklet for your vehicle.
However, it must be checked regularly,

especially if you drive in dusty environ-

ments.

If clogging level indicator 2 reaches

100%, consult an approved dealer as

soon as possible to have the filter re-

placed.

Resetting the air filter clogging

sensor
Once the air filter has been replaced,

turn button 3 on the clogging sensor

fully (movement A).

tyre pressures .......................................(up to the end of the DU)

tyres ......................................................(up to the end of the DU)

tyre pressure.........................................(up to the end of the DU)

4.11

ENG_UD19741_9

Pressions de gonflage des pneumatiques à froid (B90 - U90 - L90 Ph2 - F90 Ph2 - R90 Ph2 - Dacia)

ENG_NU_817-9_B90_Dacia_4

Tyre pressures

TyRE PRESSURE

The tyre pressure is indicated on

label A affixed to the edge of the driv-

er’s door. Open the door to read it.
B: dimension of the tyres fitted to the

vehicle.

C: tyre pressures for the front wheels

(non-motorway).

D: tyre pressures for the rear wheels

(non-motorway).

E: tyre pressures for the front wheels

(motorway).

F: tyre pressures for the rear wheels

(motorway).

G: tyre pressure for front wheels, rec-

ommended for optimising fuel con-

sumption.
H: tyre pressure for rear wheels, rec-

ommended for optimising fuel con-

sumption.

Tyre safety and use of snow

chains
Refer to the information on “Tyres”

in Section 5 for details of the main-

tenance conditions and, depending

on the vehicle version, the use of

chains.
Special note
For vehicles used fully laden

(maximum permissible all-up

weight)

and towing a trailer. The

maximum speed must be limited

60 mph (100 km/h) and the tyre

pressure increased by

0.2 bar.

Refer to the information on “Weights”

in Section 6.

When they need to be replaced, only tyres of the same make, size, type

and profile should be used.
Tyres fitted to the vehicle should either be identical to those fitted

originally or conform to those recommended by your approved

dealer.

battery...................................................(up to the end of the DU)

capacity of mechanical components......................(current page)

maintenance:

mechanical .......................................................(current page)

4.12

ENG_UD18253_10

Batterie (B90 - U90 - L90 Ph2 - F90 Ph2 - R90 Ph2 - Dacia)

ENG_NU_817-9_B90_Dacia_4

Battery

BATTERy

Depending on the vehicle, the battery

may be a low maintenance version.

Low maintenance battery

A label on the battery will indicate if the

battery is the low maintenance type.

As the battery is

specific

to the vehicle (presence of

a ventilation pipe to expel

corrosive and explosive

gases), make sure that it is replaced

with a battery that enables this pipe

to be connected. Consult an ap-

proved Dealer.

Battery requiring

maintenance

Checking intervals:

Every six months, open cover 1.

Remove the caps and check the level.

Liquid

Distilled or demineralised water to

1.5 cm above the plates. Never add

electrolyte or other products.

Replacing the battery

As this operation is complex, we advise

you to contact an approved dealer.

Handle the battery with

care as it contains sulphu-

ric acid, which must not

come into contact with eyes

or skin. If it does, wash the affected

area with plenty of water and see a

doctor if necessary.
Ensure that naked flames, red hot

objects and sparks do not come into

contact with the battery as there is a

risk of explosion.

Label A

Observe the indications on the battery:

– 2 Naked flames and smoking forbid-

den;

– 3 Eye protection required;

– 4 Keep away from children;

– 5 Explosive materials;

– 6 Refer to the handbook;

– 7 Corrosive materials.

The engine may be hot

during operations in close

proximity. In addition, the

engine cooling fan may

start at any moment.
Risk of injury.

A 2

bodywork (maintenance) ......................(up to the end of the DU)

maintenance:

bodywork ........................................(up to the end of the DU)

washing ................................................(up to the end of the DU)

paintwork

maintenance ....................................................(current page)

4.13

ENG_UD20155_5

Entretien de la carrosserie (B90 - U90 - L90 Ph2 - F90 Ph2 - R90 Ph2 - Dacia)

ENG_NU_817-9_B90_Dacia_4

Bodywork maintenance

BODyWORK MAINTENANCE

(1/3)

A well-maintained vehicle will have a

longer service life. It is therefore ad-

visable to maintain the vehicle exterior

regularly.

Protection against the effects

of corrosive agents

Although your vehicle has been treated

with very effective anti-corrosion prod-

ucts, it nevertheless remains subject to

the effects of:
– corrosives in the atmosphere

– atmospheric pollution (urban and

industrial areas);

– saline atmosphere (near the sea,

particularly in hot weather);

– seasonal and damp climatic con-

ditions, (e.g.: road salt in winter,

water from road cleaners, etc.).

– abrasives

Wind-borne dust and sand, mud,

road grit thrown up by other vehi-

cles, etc.

– minor impacts

You should take a minimum number of

precautions in order to safeguard your

vehicle against such risks and not to

lose the benefit of your vehicle’s anti-

corrosion protection.

you should not:

– Degrease or clean mechanical com-

ponents, underneath the body, parts

with hinges (eg. fuel filler cap, inside

the fuel flap) and painted plastic ex-

ternal fittings (eg. bumpers) using

high-pressure cleaning equipment

or by spraying on products not ap-

proved by our Technical Department.

If adequate precautions are not

taken, this could cause corrosion or

lead to operational faults.

– Aim a high pressure water jet directly

onto damaged parts of the vehicle

(eg. painted bumpers, lights, etc.).

Wash these parts carefully by hand.

– Wash the vehicle in bright sunlight or

freezing temperatures.

– Use hard brushes to clean alloy

wheels. These can scratch or

damage the wheel’s protective coat-

ing.

– Scrape off mud or dirt without

prewetting.

– Allow dirt to accumulate.
– Allow rust to form following minor im-

pacts.

– Use solvents not approved by the

Technical Department to remove

stains as this could damage the

paintwork.

– Drive when the vehicle is muddy or

covered in snow (the wheel arches,

underneath the body, radiator, etc.

must always be free from mud or

snow).

It is forbidden to wash the engine compartment using a high-pressure

water jet: this risks damaging the electrical/electronic components in the

engine compartment.

A label affixed in the engine compartment reminds you of this.

4.14

ENG_UD20155_5

Entretien de la carrosserie (B90 - U90 - L90 Ph2 - F90 Ph2 - R90 Ph2 - Dacia)

ENG_NU_817-9_B90_Dacia_4

BODyWORK MAINTENANCE

(2/3)

you should

–

Respect local regulations about

washing vehicles (e.g. do not wash

your vehicle on a public highway).

– Always follow the recommenda-

tions supplied with the high-pressure

cleaning equipment (jet distance and

pressure).

– Before using a roller type car wash,

put the windscreen wiper stalk in

Park position (refer information

on the “Windscreen wash/wipe” in

Section 1), check that the external

accessories, additional lights, and

mirrors are securely fitted and that

the wiper blades and radio aerial are

taped down.
Remove the radio aerial mast if your

vehicle is fitted with this equipment.
Remember to remove the tape and

refit the antenna after washing.

– Wash your vehicle frequently with

the

engine off, using shampoo ap-

proved by our Technical Department

(never use abrasive products) and

rinse thoroughly using a warm or

cold water jet (never hot):

– spots of tree resin and industrial

grime;

– the layer of dust or mud and any

insects;

–

bird droppings, which contain

chemicals that rapidly

discolour

paintwork and may even cause

the paint to peel off;

Wash the vehicle

immediately to

remove these marks since it is im-

possible to remove them by pol-

ishing;

–

salt deposited in the wheel arches

and underneath the body after

driving in areas where the roads

are chemically treated;

–

mud in the wheel arches and un-

derneath the body which form

damp patches.

– Clean mud and sand from the

wheels, in particular the inside of the

wheels and the brakes, as this can:

– reduce the braking efficiency and

damage the components of the

braking system;

– cause vibrations in the bodywork

and steering column.

We have selected special products

to care for your vehicle and you can

obtain these from approved dealer

accessory outlets.

4.15

ENG_UD20155_5

Entretien de la carrosserie (B90 - U90 - L90 Ph2 - F90 Ph2 - R90 Ph2 - Dacia)

ENG_NU_817-9_B90_Dacia_4

BODyWORK MAINTENANCE

(3/3)

– After cleaning your vehicle, check

the brakes while driving at low speed

to ensure that the braking efficiency

has not been reduced by the water.

If it has, depress the brake pedal

gently while driving to dry the brakes.

–

Check the drain holes at the bottom

of the doors to make sure they are

not blocked.

–

Inspect the wheels regularly to check

for any traces of impacts or corro-

sion. These can damage the tyre or

cause it to lose pressure.

–

Keep well away from the vehicle in

front when driving on gravelled sur-

faces to prevent paint damage.

–

Repair or have repaired quickly

patches where the paint has been

damaged to prevent corrosion

spreading.

–

Remember to visit the body shop pe-

riodically in order to maintain your

anticorrosion warranty. Refer to the

Maintenance Service Booklet.

– Spray mechanical components,

hinges, etc. with products approved

by the Technical Department to

protect them after they have been

cleaned.

maintenance:

interior trim ......................................(up to the end of the DU)

interior trim

maintenance ...................................(up to the end of the DU)

4.16

ENG_UD22288_6

Entretien des garnitures intérieures (B90 - U90 - L90 Ph2 - F90 Ph2 - R90 Ph2 - H79 - Dacia)

ENG_NU_817-9_B90_Dacia_4

Glass instrument panel

(e.g.: instrument panel, clock, exterior

temperature display, radio display).
Use a soft or cotton cloth. If this does

not clean them properly, use a soft cloth

(or cotton wool) slightly moistened with

soapy water and then wipe clean with

another damp soft or cotton cloth.
Finally, dry off

carefully with a soft dry

cloth.
Cleaning products containing alco-

hol must not be used under any cir-

cumstances.

Seat belts

These must be kept clean. Use products

selected by our Technical Department

or warm, soapy water and a sponge

and wipe with a dry cloth.
Detergents or dyes must not be used

under any circumstances.

Interior trim maintenance

INTERIOR TRIM MAINTENANCE

(1/2)

A well-maintained vehicle will have a

longer service life. It is therefore ad-

visable to maintain the vehicle interior

regularly.
Stains should always be dealt with

quickly. Whatever type of stain is on

the trim, use

soapy water (if possible,

warm water) containing:
Do not use detergents (washing up

liquid, powdered products, alcohol-

based products, etc.).
Use a soft cloth.
Rinse and soak up the excess.

Fabrics (seats, door trim,

etc.)

Dust fabrics

regularly.

Liquid stains
Use soapy water.
Dab lightly (never rub) with a soft cloth,

rinse and remove the excess.

Solid or thick stains
Remove any excess solid or thick ma-

terial

immediately and carefully using

a spatula (from the edge inwards to

avoid spreading the stain).

Clean using the procedure for a liquid

stain.

Special instructions for sweets or

chewing gum
Put an ice cube on the stain to solidify

it, then proceed as for a solid stain.

For advice on interior maintenance

and/or on unsatisfactory results,

contact an approved dealer.

4.17

ENG_UD22288_6

Entretien des garnitures intérieures (B90 - U90 - L90 Ph2 - F90 Ph2 - R90 Ph2 - H79 - Dacia)

ENG_NU_817-9_B90_Dacia_4

Removing/refitting factory

fitted removable equipment

in the vehicle

If you need to remove equipment to

clean the passenger compartment (e.g.

mats), always make you refit it properly

and on the correct side (driver’s side

mats must be fitted on the driver’s side,

etc.), using retaining components sup-

plied with the equipment (e.g. the driv-

er’s side mat must always be secured

using prefitted retaining devices).
In all cases, with the vehicle stationary,

ensure that nothing can hinder driving

(obstacle underneath the pedals, heel

trapped by the mat, etc.).

What you should not do

You are strongly advised not to place

items such as air fresheners, perfume

etc. near the air vents as these could

damage the dashboard fittings.

INTERIOR TRIM MAINTENANCE

(2/2)

You are strongly recom-

mended not to use high-

pressure or spray cleaning

equipment inside the pas-

senger compartment: this equip-

ment could impair the correct func-

tioning of the electrical or electronic

components in the vehicle, or have

other detrimental effects.

5.1

ENG_UD25175_11

Sommaire 5 (B90 - Dacia)

ENG_NU_817-9_B90_Dacia_5

Section 5: Practical advice

Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.2

Puncture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.3

Tyre inflation kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.4

Wheel trims/Wheels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.7

Changing a wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.9

Tyres (tyre and wheel safety, use in winter) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.11

Changing bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.14

Front lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.14

Fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.15

Rear lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.16

Indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.18

Interior lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.19

Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.22

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.25

Radio frequency remote control: battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.27

Wiper blades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.28

Towing: breakdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.29

Towing: equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.31

Fitting a radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.32

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.33

Operating faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.34

towing hitch...........................................(up to the end of the DU)

practical advice .....................................(up to the end of the DU)

jack .......................................................(up to the end of the DU)

lifting the vehicle

changing a wheel ............................(up to the end of the DU)

wheelbrace ...........................................(up to the end of the DU)

5.2

ENG_UD22588_6

Outils (B90 - Dacia)

ENG_NU_817-9_B90_Dacia_5

Accessing the tools

The tools are stored in the luggage

compartment.
The presence of the tools depends on

the vehicle.

Towing hitch 1

Refer to the information on “Towing:

breakdown” in Section 5.

Tools

TOOLS

Wheelbrace 2

(depending on the vehicle)
This is used to tighten/loosen the wheel

bolts and, depending on the vehicle, to

access the emergency spare wheel.

Jack 3

To use the jack, undo bolt 5.

When refitting, fold the jack before plac-

ing it in its housing. Tighten the nut to

secure the jack.

Hubcap tool 4

This tool is used to remove the wheel

trims.

Do not leave the tools unsecured inside the vehicle as they may come

loose under braking. After use, make sure the tools are correctly posi-

tioned in their housings: risk of injury.

If wheel bolts are supplied in the tool kit, only use these bolts for the

emergency spare wheel: refer to the label affixed to the emergency spare wheel.

The jack is designed for wheel changing purposes only. Under no circumstances

should it be used for carrying out repairs underneath the vehicle or to gain access

to the underside of the vehicle.

Renault Sandero (2012 year). Manual - part 7
