Section 2: Driving

(Advice on use relating to fuel economy and the environment)

Running in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2

Ignition switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3

Starting, stopping the engine: vehicle with key/remote control unit . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4

Starting, stopping the engine: vehicle with RENAULT card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5

Stop and Start function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.10

Special features of petrol versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.14

Special features of diesel versions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.15

Gear lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.16

Parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.17

Electronic parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.18

ECO driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.21

Maintenance and anti-pollution advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.26

Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.27

Tyre pressure loss warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.28

Driver correction devices/aids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.31

Transmission: 4-wheel drive (4WD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.35

Active emergency braking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.39

Lane departure warning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.50

Fatigue detection warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.53

Blind spot warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.55

Speeding alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.59

Speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.62

Cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.65

Adaptive cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.69

Parking sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.77

Reversing camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.82

Assisted parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.84

Automatic gearbox. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.90

2.2

RUNNING IN

Petrol version

For the first 600 miles (1,000 km), do

not exceed 78 mph (130 km/h) in the

highest gear, or 3,000 to 3,500 rpm.
You may only expect top performance

from your vehicle after approximately

1,800 miles (3,000 km).
Service intervals: refer to the

Maintenance Document for your vehi-

cle.

Diesel version

For the first 1,000 miles (1,500 km),

do not exceed 80 mph (130 km/h) in

the highest gear, or 2,500 rpm. After

completing this mileage you may drive

faster, although you may only expect

top performance after approximately

3,600 miles (6,000 km).
During the running in period, do not ac-

celerate hard while the engine is still

cold and do not let the engine over-rev.
Service intervals: refer to the

Maintenance Document for your vehi-

cle.

2.3

Ignition position 2.
The ignition is switched on:

Start position 3.
If the engine fails to start at the first

attempt, the key must be turned back

before the starter can be activated

again. Release the key as soon as the

engine starts.
Note: on diesel versions, several sec-

onds may pass between turning the

key and the engine starting to allow for

engine preheating.

Ignition switch

“Stop and steering lock” position 0.
To lock: remove the key and turn the

steering wheel until the steering column

locks.
To unlock: turn the key and the steering

wheel slightly.

IGNITION SWITCH: vehicle with key

2.4

STARTING, STOPPING THE ENGINE: vehicle with key

Starting the engine

Petrol versions

–

Activate the starter without ac-

celerating;

–

release the key as soon as the

engine starts.

Diesel versions

–

Turn the ignition key to the

“Ignition on” position 2, and hold

this position until the engine pre-

heating light goes off;

–

turn the key to starter position 3

without depressing the accel-

erator pedal;

–

release the key as soon as the

engine starts.

Special note: if starting the engine

when the outdoor temperature is very

low (below -10°C): hold down the clutch

pedal until the engine starts.

Never start your vehicle

while freewheeling on a

gradient. Risk of non-ac-

tivation of power-assisted

steering.
There is a risk of accidents.

Never switch off the igni-

tion before the vehicle has

stopped completely. Once

the engine has stopped, the

brake servo, power-assisted steer-

ing, etc. and the passive safety de-

vices such as air bags and preten-

sioners will no longer operate.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

Stopping the engine

With the engine idling, turn the key to

the “Stop” position 0.

2.5

STARTING, STOPPING THE ENGINE: vehicle with RENAULT CARD

(1/5)

The RENAULT card must be inserted in

detection zone 1.
To start:
– vehicles with an automatic gearbox,

place the lever in position P, depress

the brake pedal and press button 2;

– vehicles with a manual gearbox,

depress the brake or clutch pedal

and press the button 2. If a gear is

engaged, the vehicle may only be

started by depressing the clutch

pedal.

“Hands-free” starting with

the tailgate open

In this case, the RENAULT card should

not be located in the boot, to avoid any

risk of loss.

Special features
– If one of starting conditions is not ap-

plied, the message “Press brake +

START” or “Press clutch + START”

or “Select P” is displayed on the in-

strument panel;

– in some cases, it will be necessary to

move the steering wheel while press-

ing the start button 1 to assist in un-

locking the steering column. A mes-

sage on the instrument panel “Turn

steering wheel + START” warns of

this.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

2.6

STARTING, STOPPING THE ENGINE: vehicle with RENAULT CARD

(2/5)

Operating faults

In certain cases, the RENAULT “hands-

free” card may not work:
– when the RENAULT card battery is

drained, etc.;

– near to appliances operating on the

same frequency as the card (moni-

tor, mobile phone, video game, etc.);

– vehicle located in a high electromag-

netic radiation zone.

The message “Place card close START

and push” appears on the instrument

panel.

Accessories function

(switching on the ignition)
Once you have gained access to your

vehicle, you may use some of its func-

tions (radio, navigation, wipers, etc.).
To use the other functions, with the

RENAULT card in the passenger com-

partment, press button 2 without press-

ing the pedals.

Depress the brake or clutch pedal, then

place the RENAULT 3 card (logo side)

in contact with the start button 2 for

around 2 seconds. Press the 2 button

to start the vehicle. The message goes

out.

Never leave your vehicle

with the RENAULT card in

the reader or in the pas-

senger compartment while

there is a child (or an animal) in the

vehicle, even for a short while.
They may pose a risk to themselves

or to others by starting the engine.
Risk of serious injury.

Never switch off the igni-

tion before the vehicle has

stopped completely. Once

the engine has stopped, the

brake servo, power-assisted steer-

ing, etc. and the passive safety de-

vices such as air bags and preten-

sioners will no longer operate.

2.7

STARTING, STOPPING THE ENGINE: vehicle with RENAULT CARD

(3/5)

If the RENAULT card is no longer in the

passenger compartment or if the card

battery is low when you try to switch

the engine off, the message “No key-

card Press and hold” appears on the in-

strument panel: press the button 2 for

longer than two seconds. If the card is

no longer in the passenger compart-

ment, make sure you can retrieve it

before pressing and holding the button.

Without the RENAULT card, you will

not be able to restart the vehicle.
With the engine switched off, any ac-

cessories being used (radio, etc.) will

continue to function for approximately

10 minutes.
When the driver’s door is opened, the

accessories stop working.

Conditions for stopping the

engine

The vehicle must stationary, with the

lever positioned in N or P for vehicles

with an automatic transmission.
With the RENAULT card in the vehicle,

press the 2 button: the engine will stop.

The steering column is locked when the

driver’s door is opened or the vehicle

is locked.

When you leave your vehi-

cle, especially if you have

your RENAULT card with

you, check that the engine

is completely switched off.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

Never switch off the igni-

tion before the vehicle has

stopped completely. Once

the engine has stopped, the

brake servo, power-assisted steer-

ing, etc. and the passive safety de-

vices such as air bags and preten-

sioners will no longer operate.

2.8

STARTING, STOPPING THE ENGINE: vehicle with RENAULT CARD

(4/5)

This function also allows to program the

engine to start, in order to heat or ven-

tilate the passenger compartment up to

24 hours before using the vehicle.
The level of heat comfort (temperature,

defrost) set up before the setting the

program.
Depending on the country, the engine

will be running during 5 or 10 minutes.
Once the engine started, it will be pos-

sible to add additional 5 or 10 minutes

by pressing again the remote start

button 3.

Remote engine start-up

Activation
If the vehicle is equipped with it, press

the unlocking button 4 briefly, in a dura-

tion lower than 5 seconds, then press

the remote start button 3 twice for about

3 seconds each time. If there is a prob-

lem, consult an approved Dealer as

soon as possible.

Operation
This function allows to remote starting

of the engine.
To do this, press the locking button 5,

followed by the remote start button 3

for about 3 seconds. Flashers turn on

about 3 seconds.

Depending on the vehicle, the configu-

ration and the programming are done

using the multimedia display 6. Refer

to the multimedia instructions for your

vehicle.
The range for the remote engine start-

up varies according to the surround-

ings:
– Obstacles closed to buildings (ships)

, walls or the other vehicles, etc;

– Vehicle in an area with strong elec-

tromagnetic radiations;

– The key or Renault card of battery

low.

2.9

Do not use the engine

remote start-up function or

its programming when:
– the vehicle is in a garage

or in a confined space.

Risk of poisoning or suffoca-

tion by exhaust gas emissions.

– the vehicle is covered with a pro-

tective cover.

Fire hazard.
– the bonnet is open or before it

opens.

Risk of burns or serious injury.
Depending on the country, the

use of the remote starting

function or its programming

can be prohibited by the legis

lation and/or the regulations in

force.

Before using this function, check

the legislation and/or the regu-

lations for the country in force.

The remote engine start-up operates:

– the lever is in neutral for vehicles

with a manual or sequential gearbox;

– the lever is in position P for vehicles

with an automatic gearbox;

– the ignition is off and no key is in-

serted into the ignition switch;

– the bonnet is closed;

– all of the opening elements (doors

and luggage compartment) are

closed and locked when you leave

the vehicle;

– in very cold weather conditions, the

remote engine start-up by program-

ming may not operate;

– If the vehicle is equipped with an au-

tomatic transmission, after the stop

of the engine or an attempt failed the

remote engine start-up, wait 10 sec-

onds to make a new attempt.

If one of the conditions is not respected,

flashers will turn on during approxi-

mately 3 seconds.
Note: In some rare case, the engine

can be stopped just after engine start

by remote engine start-up. In this case,

remote engine start-up is available and

driver can try to use again.
If the engine is stopped continuously,

consult an approved Dealer as soon as

possible.

STARTING, STOPPING THE ENGINE: vehicle with RENAULT CARD

(5/5)

Special feature of vehicles

equipped with the “wake up every

2 hours” function
It is imperative to drive at least 10

minutes between each use of the

function. If you use this function,

there are risk of degradation of the

engine oil.
Refer to the multimedia instructions

for your vehicle.

2.10

For manual gearboxes:
– the gearbox is in neutral;
and
– the clutch pedal is released. If the

warning light



blinks, this

means that the clutch pedal is not

sufficiently released;

and
– the vehicle speed is less than ap-

proximately 7 mph (3 km/h).

For all vehicles:

Warning light



on the instrument

panel appears when the engine is on

standby.
The vehicle equipment remains opera-

tional while the engine is stopped.

STOP AND START FUNCTION

(1/4)

This system enables a reduced fuel

consumption and lower greenhouse

gas emissions.
The system is activated automatically

when the vehicle is started.
While driving, the system stops the

engine (standby) when the vehicle is

at a standstill (traffic jam, traffic lights,

etc).

Conditions for engine

standby

The vehicle has set off from where it

was parked;
For automatic gearboxes:
– the gearbox is in position D, M or N;
and
– the brake pedal is pressed (suffi-

ciently hard);

and
– the accelerator pedal is not pressed;
and
– the speed is zero for around

1 second.

The engine remains on standby if posi-

tion P is selected, or if position N is se-

lected with the parking brake engaged

and the brake pedal released.

If the engine is put in

standby, the electronic par-

king brake (depending on

the vehicle) is not applied

automatically.

Engine on standby - braking

assistance is no longer ope-

rational.

If the engine stalls while the system

is in operation, the clutch pedal is

pressed slightly and then the engine

will start it again.

Keep your vehicle station-

ary when the engine is

on standby (shown by the

warning light



on the

instrument panel).

The ignition must be

switched off before leaving

the vehicle (please see

section on “Starting, stop-

ping the engine”).

2.11

Conditions for coming out of

the engine standby

For automatic gearboxes:
– the brake pedal is released, position

D or M engaged or,

– the brake pedal is released, position

N engaged and the parking brake

off, or

– the brake pedal is pressed again,

with position P engaged or position

N engaged with the parking brake

applied, or

–  position R is engaged or,
–  the accelerator pedal is pressed or,
–  in manual mode, the gear lever is

moved towards + or -.

For manual gearboxes:
– the gearbox is in neutral and the

clutch pedal is slightly depressed

To fill up with fuel, the engine must

be stopped (and not on standby):

always stop the engine (please see

“Starting, stopping the engine”).

STOP AND START FUNCTION

(2/4)

Preventing the standby of the

engine

In certain situations, such as a cross-

roads for instance, it is possible (with

the system activated) to keep the

engine running so as to be ready to

move off quickly.
Automatic gearbox:
Keep the vehicle stationary with pres-

sing the brake pedal slightly.
Manual gearbox:
Keep the clutch pedal pressed right

down.

Special note: depending on the vehi-

cle, if you switch off the ignition when

the engine is on standby, the warning

light

is displayed for a few sec-

onds on the instrument panel.

2.12

STOP AND START FUNCTION

(3/4)

Conditions for preventing the

standby of the engine

Certain conditions prevent the system

from using the engine standby function,

including when:
for vehicles equipped with a

RENAULT  card:
–  the driver’s door is not closed;
–  the driver’s seatbelt is not fastened;

for all vehicles:
–  reverse gear is engaged;
–  the bonnet is not locked;
–  the outdoor temperature is too low or

too high;

– the battery is not sufficiently char-

ged;

– if available, “4WD Lock” mode is

activated (please see the section

“Transmission: 4-wheel drive (4WD)”

in Section 2);

– the difference between the vehicle

interior temperature and the auto-

matic climate control instruction is

too high;

– parking distance control is in opera-

tion;

– for vehicles with automatic gear-

boxes, the gradient is steeper than

approximately 12%;

– the “Clear View” function is activa-

ted (please see “Automatic Climate

Control” in Section 3);

– the engine temperature is too low or

high;

– the emission control system is being

regenerated;

– ...

Warning light



is displayed on the

instrument panel. This notifies you that

engine standby is not available.

Deactivate the Stop and

Start function when perfor-

ming any operations in the

engine compartment.

Special cases for vehicles

with a RENAULT card

With the engine on standby (traffic jam,

traffic lights, etc.), if the driver unfas-

tens the seat belt and opens the driv-

er’s door, or gets out of the seat, the

ignition is switched off.
The assisted parking brake is applied

automatically.
To restart and reactivate the Stop and

Start system, start the engine (please

refer to “Starting, stopping the engine”

in Section 2).

Special cases of vehicles

with a key

With the engine on standby (traffic

jam, traffic lights, etc.), if you get out of

the vehicle, a beep warns you that the

engine is on standby and has not been

stopped.

After engine standby, even

driver takes off the vehicle,

it could be restarted. Please

check the safety before you

leave.

2.13

STOP AND START FUNCTION

(4/4)

Special feature of the automatic

engine re-start
Under certain conditions, the engine

can restart on its own in order to gua-

rantee your safety and comfort.
This can occur especially when:
– the outdoor temperature is too low or

too high;

– the “Clear View” function is activa-

ted (please see “Automatic Climate

Control” in Section 3);

– the battery is not sufficiently char-

ged;

– the vehicle speed is above 3 mph

(5 km/h) (downhill slope, etc.);

– repeated pressing on the brake

pedal or braking system require-

ment;

– ...

Deactivating, activating the

function

Press switch 1 to deactivate the func-

tion. The message “Stop & Start deac-

tivated” will appear on the instrument

panel and the integrated warning light 2

on the switch will light up.

Pressing again will reactivate the

system. The message “Stop & Start ac-

tivated” will appear on the instrument

panel and the integrated warning light 2

on switch 1 will go out.

Note: With the engine on standby,

press switch 1 to automatically re-

start the engine.

The system is automatically reactivated

each time the vehicle is started (see

“Stop and Start function” in Section 2).

Operating faults

When the message “Check Stop &

Start” appears on the instrument panel

and the integrated warning light 2 lights

up on the switch 1, the system is deac-

tivated.

Please consult an authorised dealer.

Before getting out of the

vehicle, you must switch

off the ignition (please see

section on “Starting, stop-

ping the engine” in section 2).

Special feature of vehicles with

a key: for some of these condi-

tions the automatic restarting of the

engine is inhibited if a front door is

open.

2.14

SPECIAL FEATURES OF PETROL VERSIONS

The following operating conditions:
– driving for long periods when the low

fuel level warning light is lit;

– using leaded petrol;
– using fuel or lubrication additives

which are not approved.

Or operating faults such as:
– faulty ignition system, running out of

fuel or disconnected spark plugs re-

sulting in the engine misfiring or cut-

ting out when driving;

– loss of power,
as they may cause the catalytic con-

verter to overheat and thus reduce its

efficiency, or damage it irreparably

and cause heat damage to the vehi-

cle.

If you notice any of the above operating

faults, have the necessary repairs car-

ried out as soon as possible by an ap-

proved Dealer.
These faults may be avoided by regu-

larly taking your vehicle to an approved

Dealer at the intervals specified in the

Maintenance document.

Starting problems

To avoid damaging the catalytic con-

verter, do not keep trying to start the

engine (using the start button, or by

pushing or towing the vehicle) without

having identified and corrected the

starting fault.
If the fault cannot be identified, do not

keep trying to start the engine, but con-

tact an approved Dealer.

Do not park the vehicle or

run the engine in locations

where combustible sub-

stances or materials such as

grass or leaves can come into con-

tact with the hot exhaust system.

2.15

SPECIAL FEATURES OF DIESEL VERSIONS

Diesel engine speed

Diesel engines are fitted with injection

equipment which prevents the engine

speed being exceeded irrespective of

the gear selected.
If the message “Check antipollution

system” is displayed along with warn-

ing lights

and

, consult an

authorised dealer immediately.
When driving, depending on the fuel

grade used, it is possible that white

smoke may be emitted.
This is due to the exhaust particle filter

being cleaned automatically, and does

not affect the way the vehicle runs.

Running out of fuel

If the tank has been completely

drained, the system must be reprimed

after the tank is refilled: see information

on the “fuel tank” in section 1 before re-

starting the engine.

Do not park the vehicle or

run the engine in locations

where combustible sub-

stances or materials such

as grass or leaves can come into

contact with the hot exhaust system.

Precautions to be taken in

winter

To avoid any faults in icy weather:
– ensure that the battery is always fully

charged,

– always keep the diesel tank rela-

tively full to avoid water vapour con-

densing in it and accumulating at the

bottom of the tank.

Content .. 5 6 7 8 ..
