Renault Koleos (2018 year). Manual

1.2

1  Locks all the opening elements.
2  Unlocks all the opening elements.
3  Ignition and front door key.
4  Locking/unlocking the tailgate only.
Remote control with switchblade

key:

5 Locking/unlocking using the switch-

blade key. To release the insert from

its housing, press button 5, it comes

out automatically. Press button 5 and

guide the insert back into its housing.

KEY, RADIO FREQUENCY REMOTE CONTROL: general information

(1/2)

The key must not be used for any

function other than those described

in the handbook (removing the cap

from a bottle, etc.).

Advice
Avoid leaving the remote control in

hot, cold or humid areas.

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

1.3

KEY, RADIO FREQUENCY REMOTE CONTROL: general information

(2/2)

Radio frequency remote

control operating range

This varies according to the surround-

ings: take care not to lock or unlock the

doors by inadvertently pressing the but-

tons on the remote control.
Note: If a door or the boot is open or

not closed properly, the doors and boot

lock/unlock in quick succession.

Interference

Interference by factors in the immediate

vicinity (external installations or the use

of equipment operating on the same

frequency as the remote control) may

affect the operation of the remote con-

trol.

Replacement and additional keys

or remote controls.
You must only contact an approved

dealer:
– If you need to replace a key it will

be necessary to take the vehicle

and all of its keys to an approved

Dealer in order to initialise the

system.

– Depending on the vehicle, you

have the option of using up to

four remote controls.

Remote control unit failure
Make sure that the correct battery

type is being used, and that the

battery is in good condition and in-

serted correctly. These batteries

have a service life of approximately

two years.
Refer to Section 5: “Radio fre-

quency remote control: batteries”

for the battery changing procedure.

1.4

Locking/unlocking only the

boot

Press the button 3.

RADIO FREQUENCY REMOTE CONTROL UNIT: use

The remote control A can be used to

lock or unlock the doors and boot.

It is powered by a battery which must

be replaced (refer to the information on

“Radio frequency remote control: bat-

teries” in Section 5).

Locking the doors

Press locking button 1.

The side indicator lights and hazard

warning lights flash twice to indicate

that the doors have been locked.

If a door or the boot is open or not prop-

erly shut, they will lock and unlock in

quick succession and the hazard warn-

ing lights and indicator lights will not

flash.

Unlocking the doors

Pressing button 2 unlocks the doors

and tailgate.
The side indicator lights and hazard

warning lights flash once to indicate

that the doors have been unlocked.

Note:

With the engine running, the ignition

switched on and in accessories position

(refer to “Ignition switch: vehicles with a

key” in Section 2), the remote control

buttons will be inactive.

Driver’s responsibility when parking or stopping the vehicle

Never leave an animal, child or adult who is not self-sufficient alone on

your vehicle, even for a short time.

They may pose a risk to themselves or to others by starting the engine,

activating equipment such as the electric windows or locking the doors.

Also, in hot and/or sunny weather, please remember that the temperature inside

the passenger compartment increases very quickly.

RISK OF DEATH OR SERIOUS INJURY.

1.5

RENAULT CARD: general information

(1/2)

The RENAULT card is used

for:

– locking/unlocking the doors and boot

(see the following pages);

– switching on the vehicle lighting re-

motely (refer to the following pages);

– starting the engine; refer to the in-

formation on “Starting the engine” in

Section 2.

Battery life

Make sure that the correct battery type

is being used, and that the battery is in

good condition and inserted correctly.

Its service life is approximately two

years: replace it when the message

“Keycard battery low” appears on the

instrument panel (refer to the informa-

tion on the “RENAULT card: battery” in

section 5).

RENAULT card operating

range

This varies according to the surround-

ings. It is important to make sure when

handling the RENAULT card that you

do not lock or unlock the doors by inad-

vertently pressing the buttons.

When the battery is flat, you can

still lock/unlock and start your vehi-

cle. Please see the information on

“Locking and unlocking the doors”

in Chapter 1 and “Starting, stopping

the engine” in Chapter 2.

1  Unlocking the doors and tailgate.
2  Locking all doors and tailgate.
3  Unlocking/locking the boot.
4  Switching on the lighting remotely or

remote engine start-up depending

on the vehicle.

1.6

RENAULT CARD: general information

(2/2)

Advice
Avoid leaving the card in hot, cold or

humid areas.
Do not keep the RENAULT card in

a place where it could be bent or

damaged accidentally, such as in a

back pocket of a garment.

Replacement: need for an

additional RENAULT Card
If you lose your RENAULT card or

require another, you can obtain one

from an approved dealer.
If a RENAULT card is replaced, it

will be necessary to take the vehi-

cle and all of its RENAULT cards

to an approved dealer to initialise

the system.
You may use up to four RENAULT

cards per vehicle.

Distance lighting function

Depending on the vehicle, pressing

button 4 switches on the dipped beam

headlights and the interior lighting for

approximately 20 seconds. This can be

used, for example, to identify the vehi-

cle from a distance when parked in a

car park.

Note: Pressing button 4 again switches

off the lighting.

Remote engine start-up

Refer to the information on the

“Starting, stopping the engine: vehicle

with RENAULT card” in section 2.

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

1.7

RENAULT CARD: usage

(1/4)

Do not store the RENAULT card

anywhere it may come into con-

tact with other electronic equipment

(computer, phone, etc.) as this could

hinder its operation.

There are two ways to unlock/lock the

vehicle:
– the “hands-free” function;
– RENAULT card buttons.

Using the card in hands-free

mode

It allows locking/unlocking without input

on the card RENAULT when within the

access zone 1.
Note: It is possible to deactivate the

hands-free system – please refer to

the information on the “Vehicle settings

customisation menu” in Section 1.

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

1.8

RENAULT CARD: usage

(2/4)

Locking using button 2
With the doors and boot closed, press

button 2 on one of the front door han-

dles. The vehicle will lock.
The hazard warning lights flash twice

to indicate that the vehicle is locked.

Special features relating to vehicle

locking
– When locking, if a door is open or in-

correctly closed, the vehicle will lock

and unlock in quick succession with-

out the hazard warning lights flash-

ing;

– after locking by pressing button 2,

you have to wait approximately 3

seconds to be able to unlock the ve-

hicle again.

Remote “Hands-free” locking
With the RENAULT card on you, and

doors and boot closed, move away

from the vehicle: it will lock automati-

cally as soon as you leave the access

zone.
Note: The distance at which the vehicle

locks depends on the surroundings.
To indicate that the doors have been

locked, the hazard warning lights

flash once and then light up for ap-

proximately four seconds, and a beep

sounds in confirmation.

“Hands-free” unlocking
With the RENAULT card in zone 1,

press the button 2 on the handle of one

of the two front doors or the button 3 on

the tailgate: the vehicle will unlock.
The hazard warning lights flash once

to indicate that the doors have been un-

locked.

1.9

RENAULT CARD: usage

(3/4)

Using the card as a remote

control

Unlocking with the card RENAULT

Press the button 4.

The hazard warning lights flash once

to indicate that the doors have been un-

locked.

Locking using the RENAULT card

With the doors and boot closed, press

button 5: the vehicle will lock.

The hazard warning lights flash twice

to indicate that the vehicle is locked.

NB: The maximum distance at which

the vehicle locks depends on the sur-

roundings.

Special features

If the a door or the boot is open or not

properly closed, the vehicle cannot be

locked. The vehicle will lock/unlock in

quick succession, but the hazard warn-

ing lights will not flash.

The card buttons are deactivated

when the engine is running.

If, while the engine is running, a door

is opened and closed, and the card is

no longer in the zone 6, the message

Keycard not detected indicates that

the card is not inside the vehicle. This

avoids you driving away after having

dropped off a passenger who has the

card, for example.
The warning disappears when the card

is detected again.

1.10

Locking/unlocking only the

boot

Press the button 7 to lock/unlock the

boot only.

RENAULT CARD: usage

(4/4)

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

1.11

LOCKING, UNLOCKING THE DOORS

(1/3)

If the remote control or,

depending on the vehicle, the

RENAULT card does not work

In some cases, the radio frequency

remote control or the RENAULT card

may not work:
– RENAULT card/radio frequency

remote control battery worn or run

flat, vehicle battery flat, etc.

– use of appliances operating on the

same frequency as the card (mobile

phone, etc.);

– vehicle located in a high electromag-

netic radiation zone.

Never leave your vehicle

with the key or RENAULT

card inside.

It is then possible:
– depending on the vehicle, use the

radio frequency remote control or

the emergency key integrated in the

card to unlock the front left-hand

door;

– to lock each of the doors manually;
– to use the interior door locking/un-

locking control (refer to the following

pages).

Vehicles with key/remote

control

Using the key
Insert the key 2 into the lock 1 and lock

or unlock the front left-hand door.

1.12

LOCKING, UNLOCKING THE DOORS

(2/3)

Using the integrated key
Insert the key 4 into the lock 1 and lock

or unlock the front left-hand door.
Once you are inside the vehicle, put the

key back in its casing in the RENAULT

card.

Vehicles with RENAULT card

Access key 4 integrated in the card
Slide the rear casing 3 downwards

while pressing on zone A.

1.13

LOCKING, UNLOCKING THE DOORS

(3/3)

Interior locking/unlocking

door control

Depending on the vehicle, each door

can be locked/unlocked by controlling

knob 5 from the inside.

The switch 6 controls the doors and the

boot simultaneously.
If a door or the tailgate is open or not

closed properly, the doors and tailgate

lock/unlock quickly.
If transporting an object with the tail-

gate open, you can still lock the doors:
with the engine stopped, press and hold

switch 6 for more than five seconds to

lock the other doors.
And then close the driver’s door while

pulling the outside handle after getting

out of the vehicle.

Locking the opening

elements without the

RENAULT card or the key

For example, in the event of a dis-

charged battery or the RENAULT card

or key temporarily not working, etc.
With the engine switched off and

a door or tailgate open, press and

hold the switch 6 for more than five sec-

onds.

When the door is closed, all the doors

and the tailgate will be locked.

Unlocking the vehicle from the outside

is only possible with the RENAULT card

in the vehicle’s access zone or using

the key.

Door and tailgate status

indicator

With the ignition on, the warning

light 6 informs you of the locking status

of the opening elements:

– indicator light on, the doors and tail-

gate are locked;

– indicator light off, the doors and tail-

gate are unlocked.

When you lock the doors from the out-

side, the indicator light remains lit for a

moment, and then goes out.

Driver’s responsibility
If you decide to keep the

doors locked when you are

driving, remember that it

may be more difficult for those as-

sisting you to gain access to the

passenger compartment in the

event of an emergency.

1.14

Opening from the inside

If the vehicle is equipped with the knob

3, pull the handle 4 with the door un-

locked.
If the vehicle is not equipped with the

knob 3, pull the handle 4.

Lights-on reminder buzzer

If you have switched off the ignition

and left the lights switched on, a re-

minder buzzer will sound when a door

is opened and if the light stalk is not in

position AUTO.

Opening the doors from the

outside

With the doors unlocked, pull handle 1.

Special feature on vehicles

equipped with a RENAULT card
With the doors locked, press button 2

on handle 1 of one of the two front

doors and pull towards you.

OPENING AND CLOSING THE DOORS

(1/2)

As a safety precaution,

the doors should only be

opened or closed when the

vehicle is stationary.

Door/tailgate open buzzer

At a standstill, the warning light 5 lights

up on the instrument panel alongside

the warning light 6

indicating the

opening elements (door, boot) are open

or incorrectly closed.
Once the vehicle reaches a speed of

approximately 12 mph (20 km/h), a

warning light indicates the opening

element(s) (door, boot) open of im-

properly closed, alongside the mes-

sage “Boot open” or “Door open” and a

beep will sound for around 40 seconds

or until the opening element is closed.

1.15

Vehicle with manual door locking
To make it impossible for the rear doors

to be opened from the inside, move

lever 7 on each door and check from

the inside that the doors are securely

locked.

OPENING AND CLOSING THE DOORS

(2/2)

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

1.16

Operating faults

If you experience an operating fault (no

automatic locking, the indicator light in-

corporated in switch 1 does not light up

when trying to lock the doors and tail-

gate, etc.), make sure that locking has

not been deactivated by mistake and

check that the doors and tailgate are

properly closed. If they are correctly

locked and the fault is still present, con-

tact an authorised dealer.

Operating principle

After the vehicle is started, the system

automatically locks the doors when you

are driving at approximately 6 mph

(10 km/h) and over.
The door can be unlocked:
– by pressing the central door unlock-

ing switch 1.

– at a standstill, by opening a front

door from inside the vehicle.

Note: if a door is opened or closed, it

will automatically lock again when the

vehicle reaches a speed of 6 mph

(10 km/h).

AUTOMATIC LOCKING WHEN DRIVING

Driver’s responsibility
If you decide to keep the

doors locked when you are

driving, remember that it

may be more difficult for those as-

sisting you to gain access to the

passenger compartment in the

event of an emergency.

Activating/deactivating the

function

To switch it on: with the vehicle at a

standstill and the engine running, press

the switch 1 until a beep sounds.
To deactivate: with the vehicle at a

standstill and the engine running, press

the switch 1 until two beeps sound.
Depending on the vehicle, you can also

deactivate/activate the function from

the menu on the multifunction screen 2

(refer to the information on the “Vehicle

settings customisation menu” section 1,

“Auto door locking while driving” func-

tion).

1.17

EMERGENCY CALL (1/2)

A call is always made as follows:
– the call is set up with the emergency

services;

– data related to the event is sent out;
– voice communication with the emer-

gency services;

– if necessary, emergency assistance

is called.

Emergency call has two modes:
– automatic mode;
– manual mode;

1 Phone network availability light: on if

network available (green light), off if

network not available;

2 Automatic mode warning light;
3 SOS switch;
4 Microphone;
5 Speaker.

If the vehicle is equipped with it, the

emergency call is a system that allows

the emergency services to be called

automatically or manually in the event

of an accident or illness, in order to

reduce the time they take to arrive on

the scene.
If you use the emergency call func-

tion to report an accident which you

have witnessed, this implies stopping

where traffic conditions allow to allow

the emergency services to locate your

vehicle and therefore the location of the

reported accident.

Use emergency call only in

the event of an emergency

if you are involved in or wit-

ness an accident or if you

feel ill.

In the event of an accident,

it is recommended that you

stay close to the vehicle so

that you can respond to the

call centre if necessary.

Renault Koleos (2018 year). Manual - part 1
