Renault Kangoo Z.E. (2018 year). Manual

1.18

Radio frequency remote

control operating range

This varies according to the surroun-

dings: take care not to lock or unlock

the doors by inadvertently pressing the

buttons on the remote control.

Interference

Interference by factors in the imme-

diate vicinity (external installations or

the use of equipment operating on the

same frequency as the remote control)

may affect the operation of the remote

control.
Note: if a door is not opened within

approximately 2 seconds of the door

being unlocked by remote control, the

doors will lock again automatically.

KEY, RADIO FREQUENCY REMOTE CONTROL: general information

(2/2)

For replacement, or if you

require an additional remote

control.

You must only contact an approved

Dealer.

– To replace a remote control, the

vehicle must be taken to an ap-

proved Dealer as both the vehi-

cle and the remote control are

needed to initialise the system.

– Depending on the vehicle, you

have the option of using up to

four remote controls.

Remote control unit failure
Make sure that the correct battery

type is being used, and that the bat-

tery is in good condition and inser-

ted correctly. These batteries have

a service life of approximately two

years.

To learn how to change the battery,

please refer to the information on

the “Key, radio frequency remote

control: Batteries” in Section 5.

1.19

KEY, RADIO FREQUENCY REMOTE CONTROL: Use

(1/2)

The doors are locked and unlocked

using the remote control unit.
It is powered by a battery which must

be replaced (refer to the information on

the “Key, radio frequency remote con-

trol: batteries” in Section 5).

Locking the doors

Remote control A or B
Press locking button 1.
The hazard warning lights and side in-

dicator lights flash twice to indicate

that the doors have locked.
If a door or the tailgate is open or not

properly shut, the doors and tailgate

lock then quickly unlock and the hazard

warning lights and side indicator lights

do not flash.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone in your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors, for example.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

1.20

Unlocking the doors

Remote control A or B
Press unlocking button 2.
Pressing the button briefly unlocks all

the doors.
A short press on button 3 locks/unlocks

the tailgate and, depending on the vehi-

cle, the sliding side doors.
The hazard warning lights and side in-

dicator lights flash once to indicate that

the doors have unlocked.

RADIO FREQUENCY REMOTE CONTROL, KEY: use

(2/2)

The key must not be used for any

function other than those described

in the handbook (removing the cap

from a bottle, etc.).

Note: unlocking the opening elements

will unlock the vehicle charging cord.

1.21

DEADLOCKING

Never use deadlocking if

someone is still inside the

vehicle.

If fitted to the vehicle, this allows the

doors to be locked and prevents them

from being opened with the interior

handles (for example, by breaking the

window and then trying to open the

doors from the inside).

To activate deadlocking

Press button 1 twice in quick succes-

sion.

The side indicator lights and hazard

warning lights flash five times to indi-

cate that the doors have locked.

To deactivate deadlocking

Unlock the vehicle using button 2.

The hazard warning lights and side in-

dicator lights flash once to indicate that

the doors have unlocked.

Special feature

For vehicles equipped with deadlock-

ing, when the vehicle is charging, every

time one of the doors is unlocked,

opened or closed, check that charging

is still in progress.
If not, the charging process needs to

be restarted (connecting the cord, pro-

gramming, etc.). Refer to the paragraph

“Electric vehicle: charging” in section 1.

1.22

Opening from the outside

Unlock the door and pull handle 1. For

information on unlocking the doors,

refer to the information on the “Key,

radio frequency remote control: use” in

Section 1.

Opening from the inside

Pull handle 2.

OPENING AND CLOSING THE DOORS

(1/4)

Child safety

(depending on vehicle)
At the rear, to prevent the side door

from being opened from the inside,

move lever 3 using the end of the ve-

hicle key.
From the inside, check that the door is

correctly locked.

Lights-on reminder buzzer

A warning beep sounds when the driv-

er’s door is opened to warn you that the

lights are still on (to prevent discharge

of the 12 volt battery).

This warning indicates that a door is

open or not properly closed.

1.23

OPENING AND CLOSING THE DOORS

(2/4)

Closing from the inside
Pull handle 5 towards the front of the

vehicle until the door is completely

closed.

Sliding side door

Opening from the outside
Unlock the door and pull handle 4, then

slide the door towards the rear of the

vehicle until it locks in position. For

information on unlocking the doors,

refer to the information on the “Key,

radio frequency remote control: use” in

Section 1.

Opening from the inside
Pull handle 6 and use handle 5 to slide

the door towards the rear of the vehicle

until it locks in position.

Recommendations con-

cerning the sliding side

door
The following precautions

must be taken when opening and

closing the doors or any other open-

ing element:
– Check that the door will not come

into contact with any person,

animal or object.

– Only use the handles on the

inside and outside of the door to

operate it.

– Take care when opening and

closing the door.

– Take particular care when the ve-

hicle is parked on a slope: open

the door with care until it is fully

open and latches into its locking

position.

– Before moving off, always ensure

that the sliding door is properly

closed.

– Do not use the lower support as a

step.

As a safety measure, the sliding

side door located on the fuel filler

flap side locks when the flap is

opened. For more information, refer

to the information on the “Central

door locking/unlocking” in Section 1.

1.24

Opening the doors to the maximum

position
For each door, pull handle 8 to release

the door check strap. Open the door as

far as possible.

Closing manually from the outside
First close the small door and then

close the large door.
Position each door so that it is almost

closed and then slam shut.

Rear hinged doors

Opening from the outside
Unlock the door and pull handle 7. For

information on unlocking the doors,

refer to the information on the “Key,

radio frequency remote control: use” in

Section 1.

OPENING AND CLOSING THE DOORS

(3/4)

If the vehicle is parked

on the hard shoulder with

the tailgate open, the rear

lights may be obscured.

You should make other road-users

aware of your vehicle by using a

warning triangle or other equipment

specified by the road traffic regula-

tions of the country concerned.

Do not leave the hinged

rear doors open in case of

strong winds. Risk of injury.

1.25

Rear hinged doors

(continued)

Opening from the inside

(depending on vehicle)
Pull handle 10 and open the door. Pull

lever 9 to open the small door.

Closing from the inside
First close the small door and then

close the large door.
Position each door so that it is almost

closed and then slam shut.

OPENING AND CLOSING THE DOORS

(4/4)

Driver’s responsibility when parking or stopping the vehicle
Never leave an animal, child or adult who is not self-sufficient alone on

your vehicle, even for a short time.

They may pose a risk to themselves or to others by starting the engine, activating

equipment such as the electric windows or by locking the doors.
Also, in hot and/or sunny weather, please remember that the temperature inside

the passenger compartment increases very quickly.
RISK OF DEATH OR SERIOUS INJURY.

1.26

Locking the opening

elements without the remote

control

With the engine and ignition off, the

sliding side doors closed and a front

door open, press switch 1 for more than

five seconds.

Make sure you have your key with you

before you leave your vehicle.

When the door is closed, all the doors

and tailgate will be locked.

Unlocking from outside the vehicle will

only be possible with the key for the

driver’s door.

Doors and tailgate status

indicator light

With the ignition on, the warning light

integrated in switch 1 informs you of the

locking status of the opening elements:

– indicator light on, the doors and tail-

gate are locked;

– indicator light off, at least one door is

unlocked.

When you lock the doors, the indicator

light remains lit and then goes out.

Control for locking and

unlocking from the inside

This enables all the doors to be locked

simultaneously.

Lock or unlock the doors by pressing

switch 1.

If a door or the tailgate is open or not

closed properly, the doors and tailgate

lock/unlock quickly.

CENTRAL DOOR LOCKING, UNLOCKING

(1/2)

Never leave your vehicle

with the key inside the ve-

hicle.

If you decide to keep the

doors locked when you

are driving, remember that

it may be more difficult for

those assisting you to gain access

to the passenger compartment in

the event of an emergency.

Unlocking the opening elements by

pressing the switch 1 releases the

vehicle charging cord.

1.27

CENTRAL DOOR LOCKING, UNLOCKING

(2/2)

Manual control

Using the key

Lock or unlock the driver’s door by in-

serting the key 3 fully into lock 2, and

turning the key.

For more information on the remote

controls, refer to the information on the

“Key, radio frequency remote control:

use” in Section 1.

Locking the doors manually

Turn screw 4 with the door open (using

the end of the key) and close the door.

This means that the doors are then

locked from the outside.

The doors may then only be opened

from inside the vehicle or with the key

for the front doors.

Sliding side door (fuel filler cap

side)
To prevent the door striking the fuel

filler nozzle, a mechanical system locks

it when the fuel filler flap is open.
When the fuel tank has been filled, re-

place the cap in its housing and close

the flap. The door can now be used.

1.28

You must first decide if you want to

activate this function.

To activate

With the engine running, press and

hold button 1 for approximately 5 sec-

onds, until you hear a beep. The indica-

tor light built into the control comes on

when the doors are locked.

To deactivate

With the engine running, press and

hold button 1 for approximately 5 sec-

onds, until you hear a beep.

If you decide to keep the

doors locked when you

are driving, remember that

it may be more difficult for

those assisting you to gain access

to the passenger compartment in

the event of an emergency.

AUTOMATIC LOCKING WHEN DRIVING (RAID)

Operating principle

When the engine is started, the system

automatically locks the doors when the

vehicle reaches a speed of approxi-

mately 4 mph (7 km/h).

Operating faults

If you notice an operating fault (auto-

matic locking impossible), first check

that all doors are correctly locked. If

they are correctly locked and the fault

is still present, contact an approved

Dealer.
Also make sure that locking has not

been inadvertently deactivated.
If necessary, refer to the activation pro-

cedure.

1.29

FRONT HEADRESTS

(1/3)

To refit the headrest
First, check that the headrest rods are

clean and correctly aligned.
Pull the tab 2 forwards.
Insert the headrest rods in the holes,

with the notches facing forwards (tilt the

seat backwards if necessary).
Guide the headrest down to the desired

height.

Headrest A

To raise the headrest
Pull it upwards to the required height.

To lower the headrest
Pull the tab 2 forwards, gently lift the

headrest to unlock it and guide it down

to the required height.

To remove the headrest
Raise it to its highest position. Press

button 1 and lift the headrest to release

it.

The headrest is an impor-

tant safety component:

ensure that it is in place

and in the correct position.

The distance between your head

and the headrest should be as small

as possible. The top of your head

should be in line with the top of the

headrest.

1.30

To remove the headrest
Raise it to its highest position. Press

button 4 and lift the headrest to release

it.

Note: when the headrest is removed,

take care not to change the positions

of the rods.

To refit the headrest
If the setting of the rods has been al-

tered, pull them fully upwards. Take

care to ensure they are clean and cor-

rectly aligned and, if there are any prob-

lems, check that the notches are facing

forwards.

Insert the headrest rods into the holes

(tilt the seatback backwards if neces-

sary).

Lower the headrest until it locks, press

button 3 and lower the headrest as far

as possible.

FRONT HEADRESTS

(2/3)

Headrest B

To raise the headrest
Pull it upwards to the required height.

To lower the headrest
Press button 3 and guide the headrest

down to the desired height.

The headrest is an impor-

tant safety component:

ensure that it is in place

and in the correct position.

The distance between your head

and the headrest should be as small

as possible. The top of your head

should be in line with the top of the

headrest.

1.31

FRONT HEADRESTS

(3/3)

Headrest C

To raise the headrest
Pull it upwards to the required height.

To lower the headrest
Press tab 5 and guide the headrest

down to the desired height.

To remove the headrest
Raise it to its highest position. Press

tabs 5 and 6 then lift the headrest to re-

lease it.
Note: when the headrest is removed,

take care not to change the positions

of the rods.

To refit the headrest
Press tab 5.
Insert the headrest rods in the holes

with the notches facing forward, and

guide the headrest down to the re-

quired height.

The headrest is an impor-

tant safety component:

ensure that it is in place

and in the correct position.

The distance between your head

and the headrest should be as small

as possible. The top of your head

should be in line with the top of the

headrest.

1.32

FRONT SEATS

(1/2)

Heated seats

Ignition switch to a position other than

the “Stop and steering lock” position

St, press switch 5, an indicator light will

come on.

To tilt the seatback

Depending on the seat, lower or lift

lever 2 and tilt the seatback until it

reaches the required position.

To move forwards or

backwards

Depending on the seat, lift bar 1 or

handle 4 to release it. Release the

handle at the desired position and

make sure that it is locked.

Adjusting the height of the

driver’s seat

Move lever 3 as many times as neces-

sary:
– upwards to raise the seat,
– downwards to lower the seat.

For safety reasons, carry out any adjustments when the vehicle is not

being driven.
We would advise you not to recline the seatbacks too far to ensure that

the effectiveness of the seat belts is not reduced.

Make sure that the seatbacks are correctly locked in place.

Nothing should be placed on the floor (area in front of driver) as such objects may

slide under the pedal during braking manoeuvres, thus obstructing its use.

1.33

FRONT SEATS

(2/2)

Front seats

Operating faults

(depending on vehicle)
If the sliding side door does not work,

lower handle 6, hold it while the seat-

back tilts and slide the seat forwards.
To place the seat into the comfort posi-

tion, slide it rearwards.

Adjust the seat and make sure that it is

correctly locked.

To avoid all risk of injury,

ensure that nobody is in

the proximity of the moving

parts. When moving the

seat, make sure that nothing inter-

feres with the moving parts and their

locking.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

Renault Kangoo Z.E. (2018 year). Manual - part 2
