Peugeot RCZ (2015 year). Manual - part 18

06

271

RCZ_en_Chap10c_RD45_ed01_2015

Receiving a call

An incoming call is announced by a ring and a superimposed
display in the vehicle's screen.

Select the YES tab on the display

using the buttons and confirm by

pressing OK.

Press this button to accept the call.

Making a call

From the Bluetooth telephone function Audio menu, select Manage
the telephone call then Call, Call list or Directory.

Press this button for more than two seconds for
access to your directory, then navigate with the
thumb wheel.
Or
To dial a number, use your telephone's keypad,
with the vehicle stationary.

BLUETOOTH

The system accesses the telephone's contacts directory, depending
on compatibility, and while the Bluetooth connection with it is
maintained.

With certain telephones connected by Bluetooth you can send a
contact to the directory of the audio system.
Contacts imported in this way are saved in a permanent directory
visible to all, whatever the telephone connected.
The menu for the directory is not accessible if it is empty.

06

272

RCZ_en_Chap10c_RD45_ed01_2015

Initiate the pairing between the telephone and
the vehicle. This pairing can be initiated from
the vehicle's telephone function menu or via the
telephone's keypad. Refer to the steps in "Pairing
a telephone" on the previous pages. During the
pairing phase, the vehicle must be stationary with
the key in the ignition.

Select the telephone to be connected from the telephone function
menu.
The audio system connects to a newly paired telephone automatically.

Bluetooth audio streaming*

Wireless transmission of music files on the telephone, played via

the audio equipment. The telephone must be able to manage the

appropriate Bluetooth profiles (Profiles A2DP / AVRCP).

* Depending on the compatibility of the telephone.
** In certain cases, playing of the Audio files must be initiated from

the keypad.

*** If the telephone supports the function.

Activate the streaming source by
pressing the SOURCE button**.
The tracks to be played can be
controlled as usual via the buttons on
the audio system control panel and
the steering mounted controls***.
The contextual information can be
displayed on the screen.

During a call, press this button for more than
2 seconds.
Confirm with OK to end the call.

Ending a call

BLUETOOTH

07

273

RCZ_en_Chap10c_RD45_ed01_2015

SCREEN MENU MAP(S)

activate / deactivate RdS

activate / deactivate REG mode

activate / deactivate radiotext

RAdIO

activate / deactivate Intro

Cd / MP3 Cd

activate / deactivate track repeat (the
entire current Cd for Cd, the entire
current folder for MP3 Cd)

activate / deactivate random play (the
entire current Cd for Cd, the entire
current folder for MP3 Cd)

activate / deactivate track repeat (of the
current folder / artist / genre / playlist)

USB

activate / deactivate random play (of the
current folder / artist / genre / playlist)

1

1

1

1

1

1

1

1

Screen C

Press the OK dial for access to short-cut menus according
to the display in the screen:

07

274

RCZ_en_Chap10c_RD45_ed01_2015

SCREEN MENU MAP(S)

Audio functions

Alternative frequencies (RDS)

activate / deactivate

FM waveband settings

Regional mode (REG)

activate / deactivate

Radio-text information (RDTxT)

activate / deactivate

1

2

3

4

3

4

3

4

Play modes

Album repeat (RPT)

activate / deactivate

Track random play (RDM)

activate / deactivate

2

3

4

3

4

Vehicle diagnostics

Alert log

1

2

Screen C

Pressing the MENU button displays:

07

275

RCZ_en_Chap10c_RD45_ed01_2015

SCREEN MENU MAP(S)

Bluetooth telephone

Connect/Disconnect an equipment

Consult the paired equipment

Bluetooth configuration

Telephone function

Audio Streaming function

Delete a paired equipment

Perform a Bluetooth search

Calls list

Call

Directory

Terminate the current call

Manage the telephone call

Activate secret mode

1

2

3

3

3

4

4

4

2

3

4

2

3

3

Video brightness adjustment

Display configuration

Define the vehicle settings*

Personalisation-Configuration

normal video

inverse video

brightness (- +) adjustment

Date and time adjustment

day/month/year adjustment

hour/minute adjustment

choice of 12 h / 24 h mode

Choice of units

l/100 km - mpg - km/l

°Celsius / °Fahrenheit

Choice of language

1

2

4

3

2

4

4

3

4

4

2

3

4

4

4

* The parameters vary according to vehicle.

276

RCZ_en_Chap10c_RD45_ed01_2015

FREQUENTLY ASKEd QUESTIONS

QUESTION

ANSWER

SOLUTION

There is a difference in

sound quality between

the different audio
sources (radio, CD...).

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,
which may result in audible differences when changing source (radio,
CD...).

Check that the audio settings (Volume, Bass,
Treble, Ambience, Loudness) are adapted to
the sources listened to. It is advisable to set
the AUDIO functions (Bass, Treble, Front-Rear
Balance, Left-Right Balance) to the middle
position, select the musical ambience "None" and
set the loudness correction to the "Active" position
in CD mode or to the "Inactive" position in radio
mode.

The CD is ejected
automatically or is not
played by the player.

The CD is inserted upside down, is unplayable, does not contain any
audio data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

-

Check that the CD is inserted in the player the
right way up.

-

Check the condition of the CD: the CD cannot
be played if it is too damaged.

-

Check the content in the case of a recorded
CD: consult the advice in the "Audio" section.

-  The audio equipment's CD player does not

play DVDs.

-  Due to their quality level, certain writeable

CDs will not be played by the audio system.

The message "USB
peripheral error" is
displayed on the screen.
The Bluetooth connection
is cut.

The battery of the peripheral may not be sufficiently charged.

Recharge the battery of the peripheral device.

The USB memory stick is not recognised.
The memory stick may be corrupt.

Reformat the memory stick.

277

RCZ_en_Chap10c_RD45_ed01_2015

FREQUENTLY ASKEd QUESTIONS

QUESTION

ANSWER

SOLUTION

I am unable to access my
voicemail.

Few telephones or service providers allow the use of this function.

The CD player sound is
poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable

conditions.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

Set the treble or bass level to 0, without selecting
an ambience.

The stored stations do
not function (no sound,
87.5 Mhz is displayed...).

An incorrect waveband is selected.

Press the BAND AST button to return to the
waveband (AM, FM1, FM2, FMAST) on which the
stations are stored.

The traffic announcement

(TA) is displayed. I do

not receive any traffic

information.

The radio station is not part of the regional traffic information network.

Tune to a radio station which broadcasts traffic

information.

The quality of reception

of the radio station
listened to gradually
deteriorates or the stored
stations do not function
(no sound, 87.5 Mhz is
displayed...).

The vehicle is too far from the transmitter used by the station listened
to or there is no transmitter in the geographical area through which the
vehicle is travelling.

Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...) block
reception, including in RDS mode.

This phenomenon is normal and does not indicate

a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going
through an automatic car wash or into an underground car park).

Have the aerial checked by a PEUGEOT dealer.

278

RCZ_en_Chap10c_RD45_ed01_2015

FREQUENTLY ASKEd QUESTIONS

QUESTION

ANSWER

SOLUTION

Sound cut-outs of 1 to
2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for another frequency

giving better reception of the station.

Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

With the engine off,

the audio equipment

switches off after a few
minutes of use.

When the engine is switched off, the audio equipment operating time

depends on the battery charge.
The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery
charge.

The message "the audio
system is overheated"
appears on the display.

In order to protect the installation if the surrounding temperature is too

high, the audio equipment switches to an automatic thermal protection

mode leading to a reduction of the volume or stopping of the playing of
the CD.

Switch the audio system off for a few minutes to
allow the system to cool.

ALPHABETICAL

 INDEX

ALPHABETICAL INDEX

279

RCZ_en_Chap11_Index-alpha_ed01-2015

ABS and EBFD systems.................... 89
Accessories ..................................... 190
Accessory socket, 12V ...................... 69
Access to rear seats .......................... 58
Active bonnet ..................................... 92
Adjusting headlamps ......................... 81
Adjusting the steering

wheel .............................................. 54

Advice on driving ..............................115
Airbags .............................................. 99
Airbags, front ........................... 100, 103
Airbags, lateral......................... 101, 103
Air conditioning .................................. 10
Air conditioning,

digital ........................................ 60, 61

Air filter ............................................ 148

Air flow ......................................... 59, 62
Air vents............................................. 59
Alarm ................................................. 41
Alert / warning log .............................. 34
Alloy wheels..................................... 189
Anti-lock braking system (ABS) ......... 89
Anti-pinch........................................... 44
Anti-theft ...........................................118
Arches, aluminium ........................... 188
Armrest, front ..................................... 70
Ashtray .............................................. 69
Assistance call ................... 88, 201, 202
Audible warning ................................. 88
Audio streaming

(Bluetooth) ............................ 244, 272

Audio systems ......................... 203, 259

Automatic illumination

of headlamps ............................ 76, 79

Automatic operation of hazard

warning lamps ................................. 87

Automatic rain sensitive

windscreen wipers .................... 83, 85

Auxiliary sockets ........ 71, 245, 267, 269

A/

A/

Battery .............................. 148, 165-167
Battery, charging .............................. 167
Battery, remote

control ....................................... 39, 40

Bluetooth

(hands-free) .......................... 226, 270

Bluetooth

(telephone) ............................ 226, 270

Bodywork ......................................... 188
Bonnet ............................................. 141
Boot ............................................. 33, 49
Boot lamp .......................................... 74
Brake discs ...................................... 149
Brake lamps............................. 172, 175
Brake pads ...................................... 149
Braking assistance system ................ 89

B/

Capacity, fuel tank ........................... 139
CD MP3 ................................... 241, 266
Central locking ............................. 38, 47
Changing a bulb ....................... 169-176
Changing a fuse ....................... 177-183
Changing a wheel ..................... 157-161
Changing a wiper blade ............. 86, 163
Changing the remote

control battery ................................. 39

Changing the time ................. 26, 33, 35
CHECK .............................................. 25
Checking levels ........................ 145-147
Checking the engine

oil level .................................... 21, 145

Checking tyre pressures

(using the kit) ................................ 156

Checks...................................... 142-149
Children ...................... 98, 100, 104-114
Child seats  ............... 104, 105, 109-114
Child seats, ISOFIx ..........................112
Cleaning (advice)............................. 188
Clock.................................................. 26
Closing the boot........................... 38, 49
Closing the doors......................... 38, 46
Colour screen, retractable ........... 34, 36
Connectors, audio ..... 71, 245, 267, 269
Coolant level .............................. 21, 147
Coolant temperature

indicator .......................................... 21

Cruise control .................................. 132
Customising stickers........................ 188
Cup holder ......................................... 67

C/

ALPHABETICAL INDEX

280

RCZ_en_Chap11_Index-alpha_ed01-2015

DAB (Digital Audio

Broadcasting) ........ 238, 239, 264, 265

Date (setting) ............................... 33, 35
Daytime running lamps ...... 78, 170, 171
Deactivating ESP ............................... 91
Deactivating the passenger

airbag ............................................ 100

Deadlocking ....................................... 38
Demisting-Defrosting ......................... 63
Dials and gauges ............................... 12
Diesel additive level ......................... 147
Diesel engine pre-heat

warning lamp .................................. 19

Dimensions ...................................... 197
Dipped beam ..................... 75, 170, 171
Dipstick ...................................... 21, 145
Directional lighting ............................. 82
Direction indicators .... 87, 170, 172, 175
Doors ................................................. 46
Doors emergency

control ............................................. 48

Door pockets ..................................... 67
Driving economically ......................... 10
Driving positions (storing) .................. 53
Dynamic stability

control (DSC) ............................ 17, 90

d/

Filling with fuel ......................... 139, 140
Fitting a wheel ................................. 159
Fittings, boot ...................................... 73
Flashing indicators............................. 87

F/

G/

Front seats................................... 50, 51
Fuel............................................ 10, 140
Fuel consumption .............................. 10

Fuel filler flap ................................... 139
Fuel gauge................................. 12, 139
Fuel tank .......................................... 139
Fusebox, dashboard ........................ 179
Fuses ............................................... 177

EBA (Emergency braking

assistance) ...................................... 89

E/

Eco-driving ........................................ 10
Economy mode................................ 164
Electric window controls .................... 44
Electronic brake force

distribution (EBFD) ......................... 89

Electronic engine immobiliser .....40, 118
Electronic stability control (ESC) ....... 90
Emergency braking system ............... 89
Emergency call .................. 88, 201, 202
Emergency warning lamps ................ 87
Energy economy mode.................... 164
Engine compartment ............... 142, 143
Engine compartment fusebox .......... 181
Engine,

Diesel .............. 19, 140, 143, 144, 195

Engine oil level indicator ............ 21, 145
Engine, petrol .................. 140, 142, 192
Engines.................................... 192, 195
Environment ...........................10, 40, 60,

63, 125, 147, 165

Equipment settings ...................... 30, 34
ESC/ASR ........................................... 90

E/

F/

Gearbox, automatic ........... 10, 122, 149
Gearbox, manual ............... 10, 121, 149
Gear lever, automatic gearbox ........ 122
Gear lever, manual gearbox ............ 121
Gear shift indicator .......................... 126
Glove box .......................................... 68
G.P.S. .............................................. 209
Guide-me-home........................... 79, 80

H/

Halogen headlamps......................... 169
Hands-free kit .......................... 226, 270
Hazard warning lamps ....................... 87
Headlamp adjustment........................ 81
Headlamps, directional .............. 82, 170
Headlamp wash ................................. 84
Headlamp wash reservoir ................ 147
Head rests, rear ................................. 58

ALPHABETICAL

 INDEX

ALPHABETICAL INDEX

281

RCZ_en_Chap11_Index-alpha_ed01-2015

Keeping children

safe .......................... 98, 100, 104-114

Key in ignition warning......................118
Key with remote control ........... 37-40, 118

K/

Navigation........................................ 209
Number plate lamps ........................ 176

N/

Labels, identification ........................ 199
Lamps, front............................. 169, 188
Lamps, rear ..................... 172, 175, 188
Lamps, warning and indicator....... 14-20
LED daytime running lamps .............. 78

Level, brake fluid ............................. 146
Level, headlamp wash ............... 84, 147

Level, power steering fluid ............... 146
Levels and checks .................... 142-149
Lighting bulbs (replacement) .... 169-176
Lighting control stalk .......................... 75
Lighting dimmer ................................. 26
Lighting, guide-me home ............. 79, 80
Lighting, interior ........................... 64, 65
Lighting on reminder .......................... 77
Loading .............................................. 10
Load reduction mode ....................... 164
Locating your vehicle ......................... 39
Locking from the inside...................... 47
Locking the boot ................................ 49
Low fuel level ............................. 16, 139

L/

Main beam ......................... 75, 170, 171
Maintenance ...................................... 10
Maintenance (advice) ...................... 188
Map reading lamps ............................ 64

Markings, identification .................... 199
Mat..................................................... 72
Menu, main ...................................... 262
Mirror, rear view ................................. 57
Mirrors, door ................................ 55, 56
Motorway function

(direction indicators) ....................... 87

Mountings for ISOFIx seats ............. 111
MP3 CD ................................... 241, 266
Music media players ................ 240, 265

M/

Heated seats ..................................... 52
Heating .............................................. 61
Height and reach adjustment,

steering wheel ................................. 54

Hill start assist ................................. 120
Horn ................................................... 88

H/

jACK socket .............. 71, 245, 267, 269

j/

Identification plates .......................... 199
Ignition ..............................................118
Indicators, direction ........................... 87

Inflating accessories

(using the kit) ................................ 156

Inflating tyres ............................. 10, 199
Inputs for audio

system .................... 71, 245, 267, 269

Instrument panel

lighting ............................................ 26

Instrument panels ........................ 12, 25
Instrument panel

screen ..................................... 12, 126

Intelligent Traction

Control ............................................ 90

Interior finish .................................... 188

Interior fittings .................................... 67
Interior lamp....................................... 64
Interior mood lighting ......................... 65
ISOFIx ....................................... 111-113
ISOFIx mountings ............................ 111

I/

Oil filter ............................................ 148
Oil level ...................................... 21, 145
Opening the bonnet ......................... 141
Opening the boot ......................... 37, 49
Opening the doors ................. 37, 46, 48

Opening the fuel filler flap ................ 139
Opening the retractable screen ......... 36
Operation indicator lamps............. 14-20

O/

ALPHABETICAL INDEX

282

RCZ_en_Chap11_Index-alpha_ed01-2015

Seats, rear ......................................... 58
Serial number,

vehicle ........................................... 199

Service indicator ................................ 23
Service warning lamp ........................ 16
Servicing ............................................ 10
Setting the clock .................... 26, 33, 35
Short-cut menus .............................. 208
Sidelamps ............. 75, 78, 170-172, 175
Side repeater ................................... 171
Snow chains .................................... 162
Spare wheel............................. 127, 160
Speed limiter.................................... 129
Speedometer ..................................... 12
Spoiler, active .................................... 93
Starting the engine ...........................116
Starting using another battery ......... 166
Steering mounted controls,

audio ..................................... 206, 261

Stickers, customising ....................... 188
Storage .................................. 67, 70, 73
Storing driving

positions .......................................... 53

Stowing rings ..................................... 73
Sun visor............................................ 68
Switching off the engine ...................116
Synchronising the remote

control ............................................. 39

Synthesiser, voice............................ 220
System, navigation .......................... 209

S/

Radio ............................... 235, 236, 263
Rear foglamp ..................... 77, 172, 175
Rear screen (demisting) .................... 63
Recharging the battery .................... 167
Reduction of electrical load ............. 164
Regeneration of the particle

filter ............................................... 148

Reinitialising the electric windows ..... 44
Reinitialising the remote control ........ 39

R/

Remote control ............................. 37-40
Removing a wheel ........................... 158
Removing the mat ............................. 72
Repair kit, puncture ......................... 150
Replacing bulbs ........................ 169-176
Replacing fuses ........................ 177-183

Replacing the air filter ...................... 148

Replacing the oil filter ...................... 148
Replacing the passenger

compartment filter ......................... 148

Replacing wiper blades ............. 86, 163
Resetting the service indicator .......... 24
Resetting the trip recorder ................. 25
Rev counter ....................................... 12
Reversing lamps ...................... 172, 175
Risk areas (update) ......................... 214
Routine checks ......................... 142-149
Running out of fuel (Diesel) ............. 144

R/

Paint colour code ............................. 199
Paintwork, matt ................................ 189
Parking brake ...........................119, 149
Parking sensors, front...................... 136
Parking sensors, rear ...................... 135

Particle filter ............................. 147, 148

Passenger compartment filter.......... 148
PEUGEOT Connect Assistance ...... 202
PEUGEOT Connect Navigation

(RT6) ....................................... 34, 203

PEUGEOT Connect SOS ................ 202
PEUGEOT Connect Sound

(RD5) ...................................... 30, 259

Player, CD MP3 ....................... 241, 266
Port, USB................... 71, 245, 267, 269
Preheater, Diesel ............................... 19
Priming the fuel system ................... 144
Protecting

children .................... 98, 100, 104-114

Puncture .......................................... 150

P/

Screen, colour and mapping.... 207, 248
Screen menu map ................... 248, 273
Screen, monochrome ...................... 262
Screen, multifunction

(with audio equipment) ....... 30, 34, 36

Screenwash fluid level ............... 84, 147
Screenwash, front.............................. 84
Screen-wash reservoir..................... 147
Seat adjustment........................... 50, 51
Seat belts............................... 17, 96, 98
Seats, electric .............................. 51, 53

S/

ALPHABETICAL

 INDEX

ALPHABETICAL INDEX

283

RCZ_en_Chap11_Index-alpha_ed01-2015

Warning lamps .............................. 14-20
Washing (advice) ............................. 188
Weights .................................... 193, 196
Welcome lighting ......................... 65, 66
Window controls ................................ 44
Wiper control stalk ....................... 83, 85
Wipers ......................................... 83, 85

W/

Vanity mirror ...................................... 68

Vehicle configuration ................... 30, 34
Vehicle diagnosis ............................... 30

Vehicle identification ........................ 199
Ventilation .............................. 59, 60, 62

V/

Table of weights ....................... 192, 195
Tables of engines..................... 193, 196
Tables of fuses................................. 177
Tank, fuel ......................................... 139
Technical data........................... 192-199
Telephone ................................ 226, 270
Temperature control for heated

seats ............................................... 52

Temperature, coolant ......................... 21
Temporary puncture

repair kit ........................................ 150

Third brake lamp...................... 172, 176

TMC (Traffic info) ............................. 223
Tools ........................................ 157, 160
Total distance

recorder .......................................... 25

Towbar ............................................. 186
Towed loads............................. 193, 196
Towing another

vehicle ........................................... 184

Traction control (ASR) ................. 17, 90

Traffic information (TA) .... 224, 237, 264

Traffic information (TMC) ......... 223, 224
Trajectory control

systems ........................................... 90

Trip computer .............................. 27, 29
Trip distance recorder ........................ 25
Tyre pressures ................................. 199
Tyres .................................................. 10

Tyre under-inflation

detection ....................................... 127

T/

Under floor storage ............................ 74

Under-inflation (detection) ............... 127
Unlocking ........................................... 37
Unlocking from the inside .................. 47
Unlocking the boot ....................... 37, 49
Update risk areas ............................ 214
Updating the time .................. 26, 33, 35
USB (PEUGEOT Connect) ....71, 245, 267

U/

X/

xenon headlamps............................ 170
