Peugeot 2008 (2016 year). Manual

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Towards a recent destination

Select "Enter destination".

Select an address from
the list offered.

Press on Navigation to display the
primary page.

Press on the secondary page.

Select "Navigate to".

Towards a contact

Select "Enter destination".

Select "Contacts".

Press on Navigation to display the
primary page.

Press on the secondary page.

Select a destination from
the contacts in the list
offered.

Select "Navigate to".

Select the criteria then "Confirm" to
start navigation.

To be able to use navigation "towards
a contact in the directory", it is first
necessary to enter the address for your
contact.

Select the criteria then "Confirm" or
press "Show route on map" to start
navigation.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Towards GPS coordinates

Select "Enter destination".

Select "Address".

Enter the "Longitude:"
then the "Latitude:".

Select "Navigate to".

Select the criteria then "Confirm" or
press "Show route on map" to start
navigation.

Press on Navigation to display the
primary page.

Press on the secondary page.

Towards a point on the map

Select "Enter destination".

Select "On the map".

Press on Navigation to display the
primary page.

Press on the secondary page.

Zooming in on the map shows points with
information.

A long press on a point opens its content.

Towards points of interest (POI)

Points of Interest (POI) are listed in different
categories.

Press on Navigation to display the
primary page.

Press on the secondary page.

Select "Search for POI".

Select "All POIs",

"Motor",

"Dining/hotels".

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Risk areas / Danger zone
alert settings

Press on Navigation to display the
primary page.

Press on the secondary page.

Select "Settings".

Select "Alarm!" (Alert).

It is then possible to activate Risk areas alerts
then:
-

"Audible warning"

"Alert only when navigating"

"Alert only for overspeed"

"Display speed limits"

Timing: the choice of timing allows the
time before giving a Risk areas alert to be
defined.

Select "Confirm".

This series of alerts and displays is
only available if Risk areas have first
been downloaded and installed on the
system.

Traffic

Traffic information

Display of messages

Press on Navigation to display the
primary page.

Press on the secondary page.

Select "Traffic messages".

Choose filter settings for:

"On the route",

"Around",

"Near destination", filters to
fine-tune the list of messages.

Press again to remove the filter.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Select the message from
the list offered.

Select the magnifying glass to have
voice information.

Setting filters

Press on Navigation to display the
primary page.

Press on the secondary page.

Select "Settings".

Select "Traffic options".

Select:
- "Be advised of new messages",
- "Speak messages".
Then enter the filter radius.

Select "Confirm".

We recommend a filter radius of:
-

12 miles (20 km) in urban areas,

30 miles (50 km) on motorways.

TMC (Traffic Message Channel)
messages on GPS-Navigation contain
traffic information transmitted in real
time.

The TA (Traffic Announcement)
function gives priority to TA alert
messages. To operate, this function
needs good reception of a radio station
transmitting this type of message.
When a traffic report is transmitted,
the current audio source is interrupted
automatically to play the TA message.
Normal playback of the audio source
resumes at the end of the transmission
of the message.

Receiving TA messages

Press on Navigation to display the
primary page.

Press on the secondary page.

Select "Settings".

Select "Voice".

Activate / Deactivate "Traffic
(TA)".

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Level 1

Level 2

Comments

Radio Media

List

List of FM stations

Press on a radio station to select it.

Radio Media

Source

FM Radio

Select the change of source.

DAB Radio

AM Radio

USB

MirrorLink

CarPlay

iPod

Bluetooth

AUX

Radio Media

Save

Press on an empty location then on Save.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Level 1

Level 2

Level 3

Media

Photos

List of FM stations

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Level 1

Level 2

Level 3

Comments

Radio Media

Secondary page

Radio list

Save

Press a radio station to select it.

Update list

Update the list of stations received.

Frequency

Enter the desired radio frequency.

Confirm

Save the settings.

Radio Media

Secondary page

Photos

Home screen

Display the selected photo in the home page.

Rotate

Rotate the photo 90°.

Select all

Select all the photos in the list.
Press again to deselect.

Slideshow

Previous photo.

Display the photos in sequence, full-screen.
The system supports the following image formats:
.gif, .jpg, .bmp, .png.

Pause / Play.

Next photo.

Full screen

Display the selected photo full-screen.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Level 1

Level 2

Level 3

Media

Settings

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Level 1

Level 2

Level 3

Comments

Radio Media

Secondary page

Media list

Presentation of the last media used.

Radio Media

Secondary page

Settings

Media

Settings

Shuffle (all tracks)

Choose the play settings.

Shuffle (current
album)

Repeat

Aux. amplification

Radio

Settings

RDS options

Activate or deactivate the settings.

DAB/FM station tracking

Display Radio Text

Digital radio slideshow
display

Announcements

Settings

Traffic announcements (TA)

Activate or deactivate the settings.

News - Weather

Sport - Programmes info

Flash - Unforeseen
events

Confirm

Save the settings.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Press on Radio Media to display the
primary page.

Select "Save".

If necessary, select the change of
source.

Press on Radio Media to display the
primary page.

Select the change of source.

"AM Radio".

By automatic frequency search

Select "FM Radio".

"AM Radio".

Press on the secondary page.

Select a preset radio station
in the list.

Select "FM Radio".

Select a radio station from
the list offered.

Select "Update list" to refresh the
list.

Select "List" in the primary page.

Press on Radio Media to display the
primary page.

Radio

Changing a radio frequency

Selecting a station

THEN

Radio reception may be affected by
the use of electrical equipment not
approved by PEUGEOT, such as a USB
charger connected to the 12 V socket.
The exterior environment (hills,
buildings, tunnel, car park, below
ground, etc.) may prevent reception,
even in RDS station tracking mode.
This phenomenon is normal in the
propagation of radio waves and is in no
way indicative of a fault with the audio
system.

Select "Radio list" in the secondary
page.

Press 3 or 4 to move the cursor for an
automatic search down or up for a radio
frequency.

To select a preset radio station.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Select a radio station or frequency (refer to the
corresponding section).

Press on Radio Media to display the
primary page.

Press on the secondary page.

Select "Settings".

Select "Radio".

Activate/deactivate "RDS
options".

Press on Radio Media to display the
primary page.

Press on the secondary page.

Press on "Save" (preset).

Select a number in the list to preset the
previously chosen radio station.
A long press on a number saves (presets)
the station.

Press on Frequency.

Enter the frequency in full (e.g.
92.10 MHz) using the keypad then
"Confirm".

Changing radio station
Pressing the name of the current radio station
brings up a list.
To change radio station press the name of the
desired station.

Press on Radio Media to display the
primary page.

Select "Save" (preset).

Presetting a station

Activating / Deactivating RDS

THEN

A press on this button presets all of
the stations one after the other.

Recalling preset stations

RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the entire country as
radio stations do not cover 100% of
the territory. This explains the loss of
reception of the station during a journey.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Display of options:
if active but not available, the display will be greyed out,
if active and available, the display will be in white.

Display of "Radiotext" for
the current station.

Select the audio source.
Display the "DAB" band.

Display of the name of the
current station.

Short-cut: access to the choice of audio
source and the list of stations (or titles,
depending on the source).

Select the radio station.

Any thumbnail broadcast by
the station.

Preset stations,
buttons 1 to 15.
Short press: select the
preset radio station.
Long press: preset a radio
station.

Next "Multiplex".
Next radio station.

Secondary page.

Display the name and
number of the "multiplex"
service being used.

Previous "Multiplex".
Previous radio station.

DAB (Digital Audio Broadcasting) radio

If the "DAB" radio station being listened to is not
available on "FM", the "DAB FM" option is greyed out.

Journaline

is a text-based information service designed for digital radio systems.

It provides text-based information structured around topics and sub-topics.
This service is available from the "LIST OF DAB STATIONS" page.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Select change of source.

Press on Radio Media to display the
primary page.

Select "DAB Radio".

Select "List" in the primary page.

Select the radio station from the list offered.

Press on Radio Media to display the
primary page.

Press on the secondary page.

Select "Settings".

Select "Radio".

Select "Digital/FM auto
tracking" then "Confirm".

DAB / FM auto tracking

Digital radio

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
"DAB/FM station tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station
(if there is one).

If "DAB/FM station tracking" is
activated, there is a difference of a few
seconds when the system switches to
"FM" analogue radio with sometimes a
variation in volume.
When the digital signal is restored,
the system automatically changes
back to "DAB".

Digital radio provides higher quality
reception and also the graphical display
of current information on the radio
station being listened to. Select "List" in
the primary page.
The range of multiplexes available is
displayed in alphabetical order.

If the "DAB" station being listened to
is not available on "FM" ("DAB/FM"
option greyed out), or "DAB/FM station
tracking" is not activated, the sound
will cut out while the digital signal is
too weak.

or
Select "Radio list" in the secondary
page.

Audio and Telematics

2008-additif_en_Chap12b_SMEGplus_ed01-2016

Media

USB port

Selecting the source

The steering mounted SRC (source)
button can be used to go to the next
media source, available if the source
is active.

Select the change of source.

Press on Radio Media to display the
primary page.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or on connection of a
USB memory stick. The lists are memorised: if
they are not modified, the subsequent loading
time will be shorter.

Insert the USB memory stick into the USB port
or connect the USB device to the USB port
using a suitable cable (not supplied).

Auxiliary socket (AUX)

Connect the portable device (MP3 player, etc.)
to the auxiliary Jack socket using an audio
cable (not supplied).

This source is only available if the "Auxiliary
socket" option has been activated in the
"Media" settings.

First adjust the volume of your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

Choose the source.

To protect the system, do not use a
USB hub.

CD player

Insert the CD in the player.

Press on OK to confirm the selection.

Peugeot 2008 (2016 year). Manual - part 26
