PRACTICAL INFORMATION

159

FITTING ROOF BARS (SALOON)

When fi tting transverse roof bars, use

the four quick-fi t fi xings provided for this

purpose:
) lift the concealing fl aps,
) adjust the roof bar quick-fi t fi xings.

Maximum authorised weight on the

roof rack, for a loading height not

exceeding 40 cm (with the excep-

tion of bicycle carriers): 65 kg.
If the height exceeds 40 cm, adapt

the speed of the vehicle to the pro-

fi le of the road to avoid damaging

the roof bars and the fi xings on the

roof.
Be sure to refer to national legis-

lation in order to comply with the

regulations for transporting objects

which are longer than the vehicle.

FITTING ROOF BARS (SW)

Consult a PEUGEOT dealer or a quali-

fi ed workshop for the installation of lon-

gitudinal roof bars.
When fi tting transverse roof bars, en-

sure that they are positioned correctly

as shown by marks on the longitudinal

roof bars.
Use accessories recommended by

PEUGEOT and follow the accessory

manufacturer's fi tting instructions.
In order to place a load on the roof, your

vehicle must be fi tted with longitudinal

roof bars with transverse roof bars fi tted

on top of these.
The longitudinal roof bars cannot be re-

moved.

Maximum authorised weight on the

roof bars, for a loading height not

exceeding 40 cm (except bicycle

carriers): 75 kg.
If the height exceeds 40 cm, adapt the

speed of the vehicle to the condition

of the road, to avoid damaging the

roof bars and the fi xings on the roof.
Please refer to national legislation

to comply with the regulations re-

garding the transport of objects

which are longer than the vehicle.

Lashing the straps through the

ends of the longitudinal roof bars is

prohibited.

PRACTICAL INFORMATION

160

ACCESSORIES

A wide range of accessories and

genuine parts is available from the

PEUGEOT dealer network.
These accessories and parts have been

tested and approved for reliability and

safety.
They are all adapted to your vehicle and

benefi t from PEUGEOT's recommenda-

tion and warranty.

Conversion kits
You can obtain an "Enterprise" kit to

convert a trade vehicle to a private car

and vice-versa.

"Transport solutions":
boot liner, luggage net, cigarette lighter,

roof bars, bicycle carrier on roof bars,

ski carrier, roof box...
Tow bar, which mst be fi tted by PEUGEOT

dealer or a qualifi ed workshop.

"Comfort":
door defl ectors, side blinds and rear

blind, coat hanger fi xed to head restraint,

front centre armrest, under shelf storage,

front and rear parking sensors...

"Styling":
aluminium gear lever knob, spoiler, styl-

ing strips, alloy wheels, trims, chromed

mirror shells, body kit...

* To avoid any risk of jamming of the

pedals:
- ensure that the mat is positioned

and secured correctly,

never fi t one mat on top of another.

"Security":
anti-theft alarm, window engraving,

wheel security bolts, child seats and

booster cushions, breathalyzer, fi rst aid

kit, warning triangle, high visibility jack-

et, stolen vehicle tracking system, tem-

porary puncture repair kit, snow chains,

non-slip covers, front foglamps kit...

"Protection":
mats * , seat covers compatible with lat-

eral airbags, aluminium or PVC door

aperture fi nishers...

PRACTICAL INFORMATION

161

Installation of radio

communication transmitters
Before installing any after-market ra-

dio communication transmitter, you

can contact a PEUGEOT dealer for

the specifi cation of transmitters which

can be fi tted (frequency, maximum

power, aerial position, specifi c instal-

lation requirements), in line with the

Vehicle Electromagnetic Compatibility

Directive (2004/104/EC).

Depending on the legislation in

force in the country, it may be

compulsory to have a high vis-

ibility safety vest, warning triangle

and spare bulbs and fuses avail-

able in the vehicle.

The fi tting of electrical equipment

or accessories which are not rec-

ommended by PEUGEOT may

result in a failure of your vehicle's

electronic system and excessive

electrical consumption.
Please note this precaution. You

are advised to contact a PEUGEOT

representative to be shown the

range of recommended equipment

and accessories.

"Multimedia":
audio systems, satellite navigation

systems, hands-free kit, CD changer,

speakers, DVD player, connection kit

for MP3 or CD player, USB Box...

You can also obtain products for cleaning

and maintenance (exterior and interior),

topping up (screenwash...), and refi lls

(cartridge for the temporary puncture re-

pair kit...) by visiting a PEUGEOT dealer.

162

TECHNICAL DATA

* Not available on SW Outdoor.

MODELS:

ENGINES AND GEARBOXES

PETROL ENGINES

1.4 litre 75 hp *

1.4 litre VTi 95 hp

Cubic capacity (cc)

1 360

1 397

Bore x stroke (mm)

75 x 77

Maximum power: EU standard (kW)

Maximum power engine speed (rpm)

5 400

6 000

Maximum torque: EU standard (Nm)

118

136

Maximum torque engine speed (rpm)

3 300

4 000

Fuel

Unleaded

Catalytic converter

Yes

GEARBOXES

Manual

(5-speed)

Manual

(5-speed)

OIL CAPACITIES (in litres)

Engine (with fi lter replacement)

3.25

4.25

TECHNICAL DATA

163

MODELS:

ENGINES AND GEARBOXES

PETROL ENGINES

1.6 litre VTi 120 hp

1.6 litre THP 156 hp **

Cubic capacity (cc)

1 598

Bore x stroke (mm)

77 x 85.8

Maximum power: EU standard (kW)

115

Maximum power engine speed (rpm)

6 000

5 800

Maximum torque: EU standard (Nm)

160

240

Maximum torque engine speed (rpm)

4 250

1 400

Fuel

Unleaded

Catalytic converter

Yes

GEARBOXES

Manual

(5-speed)

Automatic

(4-speed)

Manual

(6-speed)

OIL CAPACITIES (in litres)

Engine (with fi lter replacement)

4.25

** Only on 5-door saloon.

164

TECHNICAL DATA

The GTW and towed load values indicated apply up to a maximum altitude of 1 000 metres; the towed load mentioned must

be reduced by 10 % for each additional 1 000 metres of altitude.

The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).

High ambient temperatures may result in a reduction in the performance of the vehicle in order to protect the engine; when

the ambient temperature is higher than 37 °C, limit the weight towed.

SALOON WEIGHTS AND TOWED LOADS (in kg)

Petrol engines

1.4 litre 75 hp

Gearboxes

Manual

- Kerb

weight

1 214 - 1 201 - 1 207/1 248

Gross vehicle weight (GVW)

1 617 - 1 601 - 1 582

Gross train weight (GTW)

2 397 - 2 421 - 2 412

Braked trailer (within GTW limit)

780 - 820 - 830

- Braked

trailer

** (with load transfer within

GTW limit)

950

- Unbraked

trailer

600 - 600 - 590

Recommended nose weight

38 - 38 - 46

** The weight of the braked trailer may be increased, within the GTW limit, on condition that the GVW of the towing vehicle is reduced

by the same amount; warning, towing using a lightly loaded towing vehicle may adversely affect its road holding performance.

TECHNICAL DATA

165

The GTW and towed load values indicated apply up to a maximum altitude of 1 000 metres; the towed load mentioned must

be reduced by 10% for each additional 1 000 metres of altitude.

The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).

High ambient temperatures may result in a reduction in the performance of the vehicle in order to protect the engine; when

the ambient temperature is higher than 37 °C, limit the weight towed.

** The weight of the braked trailer may be increased, within the GTW limit, on condition that the GVW of the towing vehicle is reduced

by the same amount; warning, towing using a lightly loaded towing vehicle may adversely affect its road holding performance.

SALOON WEIGHTS AND TOWED LOADS (in kg)

Petrol engines

1.4 litre VTi 95 hp

Gearboxes

Manual

- Kerb

weight

1 164 - 1 162

Gross vehicle weight (GVW)

1 643 - 1 626

Gross train weight (GTW)

2 583 - 2 566

Braked trailer (within GTW limit)

940

- Braked

trailer

** (with load transfer within

GTW limit)

1 150

- Unbraked

trailer

580

Recommended nose weight

166

TECHNICAL DATA

SALOON WEIGHTS AND TOWED LOADS (in kg)

Petrol engines

1.6 litre VTi 120 hp

1.6 litre THP 156 hp

Gearboxes

Manual

Automatic

Manual

- Kerb

weight

1 278 - 1 255

1 3279 - 1 270

1 3719

Gross vehicle weight (GVW)

1 671 - 1 655

1 711 - 1 696

1 714

Gross train weight (GTW)

2 631 - 2 615

2 671 - 2 516

2 644

Braked trailer (within GTW limit)

960

960 - 820

930

- Braked

trailer

** (with load transfer within

GTW limit)

1 150

1 150 - 950

1 150

- Unbraked

trailer

600

Recommended nose weight

The GTW and towed load values indicated apply up to a maximum altitude of 1 000 metres; the towed load mentioned must

be reduced by 10 % for each additional 1 000 metres of altitude.

The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).

High ambient temperatures may result in a reduction in the performance of the vehicle in order to protect the engine; when

the ambient temperature is higher than 37 °C, limit the weight towed.

** The weight of the braked trailer may be increased, within the GTW limit, on condition that the GVW of the towing vehicle is reduced

by the same amount; warning, towing using a lightly loaded towing vehicle may adversely affect its road holding performance.

TECHNICAL DATA

167

SW WEIGHTS AND TOWED LOADS (in kg)

Petrol engines

1.4 litre 75 hp

1.4 litre VTi 95 hp

Gearboxes

Manual

- Kerb

weight

1 259

1 273

Gross vehicle weight (GVW)

1 643

1 694

Gross train weight (GTW)

2 423

2 594

Braked trailer (within GTW limit)

780

900

- Braked

trailer

** (with load transfer within

GTW limit)

1 045

1 150

- Unbraked

trailer

600

Recommended nose weight

The GTW and towed load values indicated apply up to a maximum altitude of 1 000 metres; the towed load mentioned must

be reduced by 10 % for each additional 1 000 metres of altitude.

The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).

High ambient temperatures may result in a reduction in the performance of the vehicle in order to protect the engine; when

the ambient temperature is higher than 37 °C, limit the weight towed.

** The weight of the braked trailer may be increased, within the GTW limit, on condition that the GVW of the towing vehicle is reduced

by the same amount; warning, towing using a lightly loaded towing vehicle may adversely affect its road holding performance.

168

TECHNICAL DATA

SW WEIGHTS AND TOWED LOADS (in kg)

Petrol engines

1.6 litre VTi 120 hp

Gearboxes

Manual

Automatic

- Kerb

weight

1 279

Gross vehicle weight (GVW)

1 707

1 731

Gross train weight (GTW)

2 607

2 681

Braked trailer (within GTW limit)

900

950

- Braked

trailer

** (with load transfer within

GTW limit)

1 150

- Unbraked

trailer

600

Recommended nose weight

The GTW and towed load values indicated apply up to a maximum altitude of 1 000 metres; the towed load mentioned must

be reduced by 10 % for each additional 1 000 metres of altitude.

The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).

High ambient temperatures may result in a reduction in the performance of the vehicle in order to protect the engine; when

the ambient temperature is higher than 37 °C, limit the weight towed.

** The weight of the braked trailer may be increased, within the GTW limit, on condition that the GVW of the towing vehicle is reduced

by the same amount; warning, towing using a lightly loaded towing vehicle may adversely affect its road holding performance.

TECHNICAL DATA

169

SW OUTDOOR WEIGHTS AND TOWED LOADS (in kg)

Petrol engines

1.4 litre VTi 95 hp

1.6 litre VTi 120 hp

Gearboxes

Manual

Automatic

- Kerb

weight

1 362

1 323

1 378

Gross vehicle weight (GVW)

1 712

1 722

1 747

Gross train weight (GTW)

2 612

2 572

2 697

Braked trailer (within GTW limit)

900

850

950

- Braked

trailer

** (with load transfer within

GTW limit)

1 150

1 110

1 150

- Unbraked

trailer

600

Recommended nose weight

The GTW and towed load values indicated apply up to a maximum altitude of 1 000 metres; the towed load mentioned must

be reduced by 10 % for each additional 1 000 metres of altitude.

The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).

High ambient temperatures may result in a reduction in the performance of the vehicle in order to protect the engine; when

the ambient temperature is higher than 37 °C, limit the weight towed.

** The weight of the braked trailer may be increased, within the GTW limit, on condition that the GVW of the towing vehicle is reduced

by the same amount; warning, towing using a lightly loaded towing vehicle may adversely affect its road holding performance.

170

TECHNICAL DATA

MODELS:

ENGINES AND GEARBOXES

DIESEL ENGINES

1.4 litre HDi 70 hp

PEF *

1.6 litre HDi 90 hp

PEF 98g *

1.6 litre HDi 92 hp

PEF

1.6 litre HDi

112 hp PEF

Cubic capacity (cc)

1 398

1 560

Bore x stroke (mm)

73.7 x 82

75 x 88.3

Maximum power: EU standard (kW)

Maximum power engine speed (rpm)

4 000

Maximum torque: EU standard (Nm)

160

215

230

270

Maximum torque engine speed (rpm)

2 000

1 750

Fuel

Diesel

Catalytic converter

Yes

Particle emission fi lter

Yes

GEARBOXES

Manual

(5-speed)

Manual

(5-speed)

Manual

(5-speed)

Manual

(6-speed)

OIL CAPACITIES (in litres)

Engine (with fi lter replacement)

3.75

3.25

* Not available on SW and SW Outdoor.

TECHNICAL DATA

171

SALOON WEIGHTS AND TOWED LOADS (in kg)

Diesel engines

1.4 litre HDi

70 hp PEF

1.6 litre HDi

90 hp PEF 98g

1.6 litre HDi

92 hp PEF

1.6 litre HDi

112 hp PEF

Gearboxes

Manual

- Kerb

weight

1 259 - 1 246 -

1 245/1 279

1 278 - 1 265

1 277 - 1 264 -

1 214/1 317

1 280 - 1 265 -

1 296/1 339

Gross vehicle weight (GVW)

1 665 - 1 642 -

1 620

1 664 - 1 643

1 718/1 703 -

1 649

1 737 - 1 726 -

1 671

Gross train weight (GTW)

2 265 - 2 242 -

2 220

1 664 - 1643

2 673/2 688 -

2 669

2 717 - 2 706 -

2 691

Braked trailer (within GTW limit)

600

970

980 - 980 - 1 020

- Braked

trailer

** (with load transfer within

GTW limit)

850 - 850

1 150

1 150 - 1 150

- Unbraked

trailer

600

Recommended nose weight

The GTW and towed load values indicated apply up to a maximum altitude of 1 000 metres; the towed load mentioned must

be reduced by 10 % for each additional 1 000 metres of altitude.

The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).

High ambient temperatures may result in a reduction in the performance of the vehicle in order to protect the engine; when

the ambient temperature is higher than 37 °C, limit the weight towed.

** The weight of the braked trailer may be increased, within the GTW limit, on condition that the GVW of the towing vehicle is reduced

by the same amount; warning, towing using a lightly loaded towing vehicle may adversely affect its roadholding performance.

172

TECHNICAL DATA

The GTW and towed load values indicated apply up to a maximum altitude of 1 000 metres; the towed load mentioned must

be reduced by 10 % for each additional 1 000 metres of altitude.

The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).

High ambient temperatures may result in a reduction in the performance of the vehicle in order to protect the engine; when

the ambient temperature is higher than 37 °C, limit the weight towed.

** The weight of the braked trailer may be increased, within the GTW limit, on condition that the GVW of the towing vehicle is reduced

by the same amount; warning, towing using a lightly loaded towing vehicle may adversely affect its roadholding performance.

SW WEIGHTS AND TOWED LOADS (in kg)

Diesel engines

1.6 litre HDi 92 hp PEF

1.6 litre HDi 112 hp PEF

Gearboxes

Manual

- Kerb

weight

1 275

1 280

Gross vehicle weight (GVW)

1 743

1 759

Gross train weight (GTW)

2 693

2 709

Braked trailer (within GTW limit)

950

- Braked

trailer

** (with load transfer within

GTW limit)

1 150

- Unbraked

trailer

600

Recommended nose weight

TECHNICAL DATA

173

The GTW and towed load values indicated apply up to a maximum altitude of 1 000 metres; the towed load mentioned must

be reduced by 10 % for each additional 1 000 metres of altitude.

The speed of a towing vehicle must not exceed 60 mph (100 km/h) (comply with the legislation in force in your country).

High ambient temperatures may result in a reduction in the performance of the vehicle in order to protect the engine; when

the ambient temperature is higher than 37 °C, limit the weight towed.

** The weight of the braked trailer may be increased, within the GTW limit, on condition that the GVW of the towing vehicle is reduced

by the same amount; warning, towing using a lightly loaded towing vehicle may adversely affect its roadholding performance.

SW OUTDOOR WEIGHTS AND TOWED LOADS (in kg)

Diesel engines

1.6 litre HDi 92 hp PEF

1.6 litre HDi 112 hp PEF

Gearboxes

Manual

- Kerb

weight

1 383

1 393

Gross vehicle weight (GVW)

1 769

1 775

Gross train weight (GTW)

2 719

2 725

Braked trailer (within GTW limit)

950

- Braked

trailer

** (with load transfer within

GTW limit)

1 150

- Unbraked

trailer

600

Recommended nose weight

Peugeot 207 (2011 year). Manual - part 11
