Nissan Rogue (2019 year). Manual - part 16

LHA4364

LHA4365

4-34

Monitor, climate, audio, phone and voice recognition systems

LHA4366

LHA4367

Monitor, climate, audio, phone and voice recognition systems

4-35

LHA4685

4-36

Monitor, climate, audio, phone and voice recognition systems

Front defroster button

Temperature control dial (driver’s
side) / ON-OFF button

MODE (manual air flow control)
button

Display screen

A/C (air conditioner) button

Temperature control dial (passen-
ger’s side)/DUAL (passenger’s side
temperature control) button

Rear window and outside

mirror (if so equipped) defroster
switch

Fresh air intake button

AUTO (automatic mode) button

10.

Fan speed control buttons

11.

Air recirculation button

WARNING

∙ The air conditioner cooling function

operates only when the engine is
running.

∙ Do not leave children or adults who

would normally require the assis-
tance of others alone in your vehicle.
Pets should also not be left alone.
They could accidentally injure them-
selves or others through inadvertent
operation of the vehicle. Also, on hot,
sunny days, temperatures in a closed
vehicle could quickly become high
enough to cause severe or possibly
fatal injuries to people or animals.

∙ Do not use the recirculation mode for

long periods as it may cause the inte-
rior air to become stale and the win-
dows to fog up.

LHA2875

HEATER AND AIR CONDITIONER
(automatic) (if so equipped)

Monitor, climate, audio, phone and voice recognition systems

4-37

NOTE:

∙ Odors from inside and outside the ve-

hicle can build up in the air condi-
tioner unit. Odor can enter the pas-
senger compartment through the
vents.

∙ When parking, set the heater and air

conditioner controls to turn off air re-
circulation to allow fresh air into the
passenger compartment. This should
help reduce odors inside the vehicle.

AUTOMATIC OPERATION

Cooling and/or dehumidified
heating (AUTO)

This mode may be used all year round as
the system automatically works to keep a
constant temperature. Air flow distribution,
air intake control and fan speed are also
controlled automatically.

1. Press the AUTO button on. The indica-

tor on the button will illuminate.

2. Turn the temperature control dial to

the left or right to set the desired tem-
perature.

∙ The temperature of the passenger

compartment will be maintained auto-
matically. Air flow distribution, air intake
control and fan speed are also con-
trolled automatically.

∙ A visible mist may be seen coming from

the vents in hot, humid conditions as
the air is cooled rapidly. This does not
indicate a malfunction.

3. You can individually set driver’s and

front passenger’s side temperature us-
ing each temperature control dial.
When the DUAL button is pressed or
passenger’s side temperature dial is
turned, the DUAL indicator will come
on. To turn off the passenger’s side
temperature control, press the DUAL
button.

Heating (A/C OFF)

The air conditioner does not activate. When
you need to heat only, use this mode.

1. Press the AUTO button.

2. Turn the temperature control dial to set

the desired temperature.

∙ The temperature of the passenger

compartment will be maintained auto-
matically. Air flow distribution and fan
speed are also controlled automatically.

∙ Do not set the temperature lower than

the outside air temperature. Otherwise,
the system may not work properly.

∙ Not recommended if windows fog up.

Dehumidified defrosting or
defogging

1. Press the

front defroster button

on. The indicator light on the button will
come on.

2. Turn the temperature control dial to set

the maximum temperature to aid in
defrosting or defogging.

∙ To quickly remove ice from the outside

of the windows, use the

fan speed

control button to set the fan speed to
maximum.

∙ As soon as possible after the wind-

shield is clean, press the AUTO button to
return to the automatic mode.

4-38

Monitor, climate, audio, phone and voice recognition systems

∙ When the

front defroster button is

pressed, the air conditioner will auto-
matically be turned on at outside tem-
peratures above 36°F (2°C). The air recir-
culate mode automatically turns off,
allowing outside air to be drawn into the
passenger compartment to further im-
prove

the

defogging

performance.

When the air recirculate mode auto-
matically turns off, the air fresh mode
will automatically turn on.

Remote Engine Start with
Intelligent Climate Control (if so
equipped)

Vehicles equipped with automatic climate
controls and Remote Engine Start function
may go into automatic heating or cooling
mode when Remote Engine Start is acti-
vated depending on outside and cabin
temperatures. During this period, the cli-
mate control display and buttons will be
inoperable until the ignition switch is
turned on. In Remote Engine Start defrost-
ing mode, the rear window defroster and
heated steering wheel (if so equipped) may
be activated automatically.

Voice Recognition logic (if so
equipped)

When the climate control system is on, the
fan speed may be automatically lowered
so that commands are more easily recog-
nized. Fan speed can be adjusted using
the

fan speed control buttons, if de-

sired.

MANUAL OPERATION

Fan speed control

Press the

fan speed control buttons

to manually control the fan speed.
Press the AUTO button to return to auto-
matic control of the fan speed.

Temperature control dial

The temperature control dial allows you to
adjust the temperature of the outlet air. To
lower the temperature, turn the dial to the
left. To increase the temperature, turn the
dial to the right. Temperature can be ad-
justed on the driver’s and passenger’s side.

Air recirculation

Press the

air recirculation button to

recirculate interior air inside the vehicle.
The indicator light on the

button will

come on.
The air recirculation cannot be activated
when the air conditioner is in the
front defrosting mode.
When the outside temperature exceeds 70°F
(21°C), the air conditioning system may de-
fault to air recirculation mode automatically
to reduce overall power consumption. To exit
air recirculation mode, select the fresh air
intake button to enter fresh air mode.

Fresh air intake

Press the

fresh air intake button to

draw outside air into the passenger com-
partment.

Automatic intake air control

In the AUTO mode, the intake air will be
controlled automatically. When the outside
temperature exceeds 70°F (21°C), the air
conditioning system may default to air re-
circulation mode automatically to reduce
overall power consumption. To exit air re-
circulation mode, select the fresh air intake
button to enter fresh air mode.

Monitor, climate, audio, phone and voice recognition systems

4-39

To manually control the intake air, press
the

air

recirculation

button

fresh air intake button. To return to

the

automatic

control

mode

the

fresh air indicator is illuminated,

press and hold the

fresh air intake

button for about 2 seconds. The fresh air
indicator and air recirculation indicator
lights will flash twice, and then the intake air
will be controlled automatically. To return
to

the

automatic

control

mode

the

air recirculation icon is illumi-

nated, press and hold the

air recircu-

lation

button

for

about

seconds.

The

air

recirculation

indicator

and

fresh air intake indicator lights

will flash twice and the intake air will be
controlled automatically.

A/C (air conditioner) button

Start the engine, press the

fan speed

control buttons to the desired position and
press the

button to turn on the air

conditioner. To turn off the air conditioner,
press the

button again.

The air conditioner cooling function op-
erates only when the engine is running.

Air flow control

Pressing the MODE button manually con-
trols air flow and selects the air outlet:

— Air flows mainly from center

and side vents.

— Air flows mainly from center

and side vents and foot outlets.

— Air flows mainly from foot out-

lets and partly from defroster.

— Air flows mainly from defroster

and foot outlets.

To turn system off

Press the ON-OFF button.

Rear window and outside mirror
(if so equipped) defroster switch

For additional information, refer to “Rear
window and outside mirror (if so equipped)
defroster switch” in the “Instruments and
controls” section of this manual.

OPERATING TIPS

The sunload sensor, located on the top and
center of the instrument panel, helps the
system maintain a constant temperature.
Do not put anything on or around this sen-
sor.

LHA2949

4-40

Monitor, climate, audio, phone and voice recognition systems

∙ When the climate system is in auto-

matic operation and the engine coolant
temperature and outside air tempera-
ture are low, the air flow outlet may de-
fault to defroster mode for a maximum
of 2 minutes 30 seconds. This is not a
malfunction. After the engine coolant
temperature warms up, the air flow out-
let will return to foot mode and opera-
tion will continue normally.

∙ When the outside and interior cabin

temperatures are moderate to high, the
intake setting may default to turn off air
recirculation to allow fresh air into the
passenger compartment. You may no-
tice air flow from the foot mode, bi-level
mode, or side demist vent outlets for a
maximum of 15 seconds. This may oc-
cur when previous climate setting was
system off. This is not a malfunction.
After the initial warm air is expelled, the
intake will return to automatic control,
air flow outlet will return to previous set-
tings, and operation will continue nor-
mally. To exit, press any climate control
button.

∙ Keep the moonroof (if so equipped)

closed while the air conditioner is in op-
eration.

∙ If you feel that the air flow mode you

have selected and the outlets the air is
coming out do not match, select
the

mode.

∙ When you change the air flow mode,

you may feel air flow from the feet vents
for just a moment. This is not a mal-
function.

The air conditioner system in your NISSAN
vehicle is charged with a refrigerant de-
signed with the environment in mind.
This refrigerant does not harm the
earth’s ozone layer.

Special charging equipment and lubricant
is required when servicing your NISSAN air
conditioner. Using improper refrigerants or
lubricants will cause severe damage to
your air conditioner system. For additional
information, refer to “Air conditioner sys-
tem refrigerant and oil recommendations”
in the “Technical and consumer informa-
tion” section of this manual.

It is recommended that you visit a NISSAN
dealer to service your “environmentally
friendly” air conditioner system.

WARNING

The air conditioner system contains re-
frigerant under high pressure. To avoid
personal injury, any air conditioner ser-
vice should be done only by an experi-
enced

technician

with

proper

equipment.

SERVICING AIR CONDITIONER

Monitor, climate, audio, phone and voice recognition systems

4-41

There is a USB/iPod® charging port located
in the center console. This port will charge
compatible devices.

NOTE:

Only the USB connection port located
below the instrument panel will allow
operation of the USB/iPod® devices
through the audio system.

The vehicle is equipped with a shark fin
antenna.

When installing a CB, ham radio or car
phone in your vehicle, be sure to observe
the following precautions; otherwise, the
new equipment may adversely affect the
engine control system and other electronic
parts.

WARNING

∙ A cellular phone should not be used

for any purpose while driving so full
attention may be given to vehicle op-
eration. Some jurisdictions prohibit
the use of cellular phones while
driving.

∙ If you must make a call while your ve-

hicle is in motion, the hands free cellu-
lar phone operational mode is highly
recommended. Exercise extreme cau-
tion at all times so full attention may
be given to vehicle operation.

∙ If you are unable to devote full atten-

tion to vehicle operation while talking
on the phone, pull off the road to a
safe location and stop your vehicle.

LHA4476

USB/iPod® CHARGING PORT

ANTENNA

CAR PHONE OR CB RADIO

4-42

Monitor, climate, audio, phone and voice recognition systems

CAUTION

∙ Keep the antenna as far away as pos-

sible

from

the

electronic

control

modules.

∙ Keep the antenna wire more than 8 in

(20 cm) away from the electronic con-
trol system harnesses. Do not route
the antenna wire next to any harness.

∙ Adjust the antenna standing-wave

ratio

recommended

the

manufacturer.

∙ Connect the ground wire from the CB

radio chassis to the body.

∙ For additional information, it is rec-

ommended that you visit a NISSAN
dealer.

Monitor, climate, audio, phone and voice recognition systems

4-43

5 Starting and driving

Precautions when starting and driving . . . . . . . . . . 5-4

Ignition switch (if so equipped). . . . . . . . . . . . . . . . . . 5-13

Continuously Variable Transmission . . . . . . . . . 5-13
Key positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
NISSAN Vehicle Immobilizer System . . . . . . . . . 5-14

Push-button ignition switch (if so equipped) . . . . 5-15

Operating range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
Push-button ignition switch positions . . . . . . . 5-16
Emergency engine shut off . . . . . . . . . . . . . . . . . . 5-17
NISSAN Intelligent Key® battery
discharge (if so equipped) . . . . . . . . . . . . . . . . . . . 5-17
NISSAN Vehicle Immobilizer System . . . . . . . . . 5-18

Before starting the engine . . . . . . . . . . . . . . . . . . . . . . 5-18

Starting the engine (models without NISSAN
Intelligent Key® system) . . . . . . . . . . . . . . . . . . . . . . . . 5-19
Starting the engine (models with NISSAN
Intelligent Key® system) . . . . . . . . . . . . . . . . . . . . . . . . 5-20

Remote Engine Start (if so equipped) . . . . . . . . 5-21

Driving the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21

Continuously Variable Transmission
(CVT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21

Parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-27

Pedal type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-27
Switch type (models with electronic
parking brake system). . . . . . . . . . . . . . . . . . . . . . . 5-28

Automatic brake hold (if so equipped) . . . . . . . . . . 5-30

How to activate/deactivate the
automatic brake hold function . . . . . . . . . . . . . . 5-31
How to use the automatic brake hold
function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-32

SPORT mode switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-33
ECO mode switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-33
Lane Departure Warning (LDW)
(if so equipped) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-34

LDW system operation . . . . . . . . . . . . . . . . . . . . . . 5-35
How to enable/disable the LDW system . . . . . 5-36
LDW system limitations. . . . . . . . . . . . . . . . . . . . . . 5-37

System temporarily unavailable . . . . . . . . . . . . . 5-38
System malfunction . . . . . . . . . . . . . . . . . . . . . . . . . 5-38
System maintenance. . . . . . . . . . . . . . . . . . . . . . . . 5-38

Intelligent Lane Intervention (I-LI) . . . . . . . . . . . . . . . 5-39

I-LI system operation . . . . . . . . . . . . . . . . . . . . . . . . 5-40
How to enable/disable the I-LI system. . . . . . . 5-42
I-LI system limitations . . . . . . . . . . . . . . . . . . . . . . . 5-42
System temporarily unavailable . . . . . . . . . . . . . 5-43
System malfunction . . . . . . . . . . . . . . . . . . . . . . . . . 5-44
System maintenance. . . . . . . . . . . . . . . . . . . . . . . . 5-45

Blind Spot Warning (BSW) . . . . . . . . . . . . . . . . . . . . . . . 5-45

BSW system operation . . . . . . . . . . . . . . . . . . . . . . 5-47
How to enable/disable the BSW system . . . . . 5-49
BSW system limitations. . . . . . . . . . . . . . . . . . . . . . 5-49
BSW driving situations . . . . . . . . . . . . . . . . . . . . . . . 5-50
System temporarily unavailable . . . . . . . . . . . . . 5-54
System maintenance. . . . . . . . . . . . . . . . . . . . . . . . 5-55

Rear Cross Traffic Alert (RCTA) . . . . . . . . . . . . . . . . . . 5-56

RCTA system operation. . . . . . . . . . . . . . . . . . . . . . 5-57
How to enable/disable the RCTA
system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-59
RCTA system limitations . . . . . . . . . . . . . . . . . . . . . 5-60
System temporarily unavailable . . . . . . . . . . . . . 5-62

System maintenance. . . . . . . . . . . . . . . . . . . . . . . . 5-63

Cruise control (if so equipped) . . . . . . . . . . . . . . . . . . 5-64

Precautions on cruise control. . . . . . . . . . . . . . . . 5-64
Cruise control operations. . . . . . . . . . . . . . . . . . . . 5-65

Intelligent Cruise Control (ICC) (for vehicles
without ProPILOT Assist) (if so equipped). . . . . . . . 5-66

ProPILOT Assist (if so equipped). . . . . . . . . . . . . . . . . 5-90

ProPILOT Assist system operation . . . . . . . . . . . 5-92
Turning the conventional (fixed speed)
cruise control mode on. . . . . . . . . . . . . . . . . . . . . . 5-95
Operating ProPILOT Assist . . . . . . . . . . . . . . . . . . . 5-96

How to enable/disable the Steering
Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-101
Intelligent Cruise Control (ICC)
(for vehicles with ProPILOT Assist). . . . . . . . . . . 5-102
Steering Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-112
Conventional (fixed speed) cruise
control mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-119

Automatic Emergency Braking (AEB)
(if so equipped) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-123

AEB system operation . . . . . . . . . . . . . . . . . . . . . . 5-124
Turning the AEB system on/off . . . . . . . . . . . . . 5-126
AEB system limitations . . . . . . . . . . . . . . . . . . . . . 5-127
System temporarily unavailable . . . . . . . . . . . . 5-128
System malfunction . . . . . . . . . . . . . . . . . . . . . . . . 5-129
System maintenance. . . . . . . . . . . . . . . . . . . . . . . 5-129

Automatic Emergency Braking (AEB) with
Pedestrian Detection (if so equipped) . . . . . . . . . . 5-131

AEB with Pedestrian Detection system
operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-132
Turning the AEB with Pedestrian
Detection system on/off . . . . . . . . . . . . . . . . . . . 5-134
AEB with Pedestrian Detection system
limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-135
System temporarily unavailable . . . . . . . . . . . . 5-137

System malfunction . . . . . . . . . . . . . . . . . . . . . . . . 5-138
System maintenance. . . . . . . . . . . . . . . . . . . . . . . 5-138

Rear Automatic Braking (RAB)
(if so equipped) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-140

RAB system operation . . . . . . . . . . . . . . . . . . . . . . 5-141
Turning the RAB system on/off . . . . . . . . . . . . . 5-142
RAB system limitations . . . . . . . . . . . . . . . . . . . . . 5-143
System malfunction . . . . . . . . . . . . . . . . . . . . . . . . 5-144
System maintenance. . . . . . . . . . . . . . . . . . . . . . . 5-145

Break-in schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-145
Fuel efficient driving tips . . . . . . . . . . . . . . . . . . . . . . . 5-146
Increasing fuel economy . . . . . . . . . . . . . . . . . . . . . . 5-147
All-Wheel Drive (AWD) (if so equipped) . . . . . . . . . . 5-147

All-Wheel Drive (AWD) LOCK switch
operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-148

Parking/parking on hills . . . . . . . . . . . . . . . . . . . . . . . 5-150
Power steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-151
Brake system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-152

Brake precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 5-152
Anti-lock Braking System (ABS) . . . . . . . . . . . . . 5-153
Brake Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-154

Vehicle Dynamic Control (VDC) system . . . . . . . . 5-154

Brake force distribution . . . . . . . . . . . . . . . . . . . . . 5-156

Chassis Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-157

Intelligent Trace Control (I-TC) . . . . . . . . . . . . . . . 5-157
Intelligent Engine Brake (I-EB) . . . . . . . . . . . . . . . 5-158
Active Ride Control (ARC) . . . . . . . . . . . . . . . . . . . 5-159

Hill start assist system. . . . . . . . . . . . . . . . . . . . . . . . . 5-160
Rear Sonar System (RSS) (if so equipped) . . . . . . 5-161

System operation . . . . . . . . . . . . . . . . . . . . . . . . . . 5-162
How to enable/disable the sonar
system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-164
Sonar limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-165
System temporarily unavailable . . . . . . . . . . . . 5-165

System maintenance. . . . . . . . . . . . . . . . . . . . . . . 5-166

Cold weather driving . . . . . . . . . . . . . . . . . . . . . . . . . . 5-166

WARNING

∙ Do not leave children or adults who

∙ Properly secure all cargo with ropes or

straps to help prevent it from sliding
or shifting. Do not place cargo higher
than the seatbacks. In a sudden stop
or collision, unsecured cargo could
cause personal injury.

∙ To avoid raising the center of gravity

excessively, do not exceed the rated
capacity

the

roof

rack

(if

equipped) and evenly distribute the
load.

EXHAUST GAS (carbon monoxide)

WARNING

∙ Do not breathe exhaust gases; they

contain colorless and odorless carbon
monoxide. Carbon monoxide is dan-
gerous. It can cause unconsciousness
or death.

∙ If you suspect that exhaust fumes are

entering the vehicle, drive with all
windows fully open, and have the ve-
hicle inspected immediately.

∙ Do not run the engine in closed spaces

such as a garage.

∙ Do not park the vehicle with the en-

gine running for any extended length
of time.

∙ Keep the rear vent windows, liftgates,

doors and trunk lids (if so equipped)
closed while driving, otherwise ex-
haust gases could be drawn into the
passenger compartment. If you must
drive with one of these open, follow
these precautions:

1. Open all the windows.

2. Set the

air recirculation but-

ton to off and the fan control dial to
high to circulate the air.

∙ If electrical wiring or other cable con-

nections

must

pass

trailer

through the seal on the liftgate or the
body, follow the manufacturer’s rec-
ommendation

prevent

carbon

monoxide entry into the vehicle.

∙ The exhaust system and body should

be inspected by a qualified mechanic
whenever:

a. The vehicle is raised for service.

b. You suspect that exhaust fumes

are entering into the passenger
compartment.

c. You notice a change in the sound of

the exhaust system.

d. You have had an accident involving

damage to the exhaust system,
underbody, or rear of the vehicle.

PRECAUTIONS WHEN STARTING AND
DRIVING

5-4

Starting and driving

THREE-WAY CATALYST

The three-way catalyst is an emission con-
trol device installed in the exhaust system.
Exhaust gases in the three-way catalyst
are burned at high temperatures to help
reduce pollutants.

WARNING

∙ The exhaust gas and the exhaust sys-

tem are very hot. Keep people, ani-
mals or flammable materials away
from

the

exhaust

system

components.

∙ Do not stop or park the vehicle over

flammable materials such as dry
grass, waste paper or rags. They may
ignite and cause a fire.

CAUTION

∙ Do not use leaded gasoline. Deposits

from leaded gasoline will seriously re-
duce the three-way catalyst’s ability
to help reduce exhaust pollutants.

∙ Keep your engine tuned up. Malfunc-

tions in the ignition, fuel injection, or
electrical systems can cause over rich
fuel flow into the three-way catalyst,
causing it to overheat. Do not keep
driving if the engine misfires, or if no-
ticeable loss of performance or other
unusual operating conditions are de-
tected. Have the vehicle inspected
promptly. It is recommended that you
visit a NISSAN dealer for this service.

∙ Avoid driving with an extremely low

fuel level. Running out of fuel could
cause the engine to misfire, damag-
ing the three-way catalyst.

∙ Do not race the engine while warming

it up.

∙ Do not push or tow your vehicle to

start the engine.

TIRE PRESSURE MONITORING
SYSTEM (TPMS)

Each tire, including the spare (if provided),
should be checked monthly when cold and
inflated to the inflation pressure recom-
mended by the vehicle manufacturer on
the vehicle placard or tire inflation pressure
label. (If your vehicle has tires of a different
size than the size indicated on the vehicle

placard or tire inflation pressure label, you
should determine the proper tire inflation
pressure for those tires.)

As an added safety feature, your vehicle
has been equipped with a Tire Pressure
Monitoring System (TPMS) that illuminates
a low tire pressure telltale when one or
more of your tires is significantly under-
inflated. Accordingly, when the low tire
pressure telltale illuminates, you should
stop and check your tires as soon as pos-
sible, and inflate them to the proper pres-
sure. Driving on a significantly under-
inflated tire causes the tire to overheat and
can lead to tire failure. Under-inflation also
reduces fuel efficiency and tire tread life,
and may affect the vehicle’s handling and
stopping ability.

Please note that the TPMS is not a substi-
tute for proper tire maintenance, and it is
the driver’s responsibility to maintain cor-
rect tire pressure, even if under-inflation
has not reached the level to trigger illumi-
nation of the TPMS low tire pressure telltale.

Your vehicle has also been equipped with a
TPMS malfunction indicator to indicate
when the system is not operating properly.
The TPMS malfunction indicator is com-
bined with the low tire pressure telltale.

Starting and driving

5-5

Content .. 14 15 16 17 ..
